MICROPHONE/MICRO/

MICRÓFONO/MИKPOФOH

话筒/マイクロフォン

DM-105

Owner’s Manual

Benutzerhandbuch

Mode d’emploi

Manual de instrucciones

Manuale di istruzioni

Manual do Proprietário

Руководство пользователя

EN

DE

FR

ES

PT

IT

RU

ZH-CN

ZH-TW

JA

使用说明书

使用說明書

取扱説明書

2

A

B

3

A

B

4

C

D

3

1 2

3 4

HOT

1 2

2 1

3

-40

(dBV / Pa)

-50

-60

-70

-80

-90 20 50 100 200

0°

180°

330° 30°

210° 150°

300° 60°

240° 120°

270° 90°

500 1k 2k 5k 10k 20k (Hz)

1 kHz

–10 dB

–20 dB

5

English

CAUTIONS

READ THIS BEFORE OPERATING YOUR MICROPHONE.

• To assure the nest performance, please read this manual carefully.

Keep it in a safe place for future reference.

• Due to the high sensitivity of the cartridge, do not drop it from a high

place or apply a strong shock to it.

• To maintain the sensitivity and quality of the sound reproducing, avoid

exposing it to moisture, dust, or extreme temperatures.

• Avoid placing this microphone in any of the following locations:

- Locations that are exposed to extremely high temperature (e.g.,

near a heater or inside a car), as they may cause damage to this

microphone, and/or personal injury.

- Locations that are exposed to water or close to containers with liquid

in them, as entering of liquid or foreign object into the microphone

may cause damage to this microphone.

• Keep this product out of the reach of children.

• Do not use force on the switch or cable of the microphone.

• When disconnecting the microphone cable, grasp the connector and

do not pull the cable.

• Since the microphone consists of precise parts, do not attempt to

modify or x it. Contact qualied Yamaha service personnel when

any service is needed. Do not disassemble the microphone for any

reasons.

• Do not clean this unit with chemical solvents; this might damage the

nish. Use a clean, dry cloth.

• Also please refer to the owner’s manual of the component to be

connected to this microphone.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS UNIT TO RAIN OR MOISTURE.

6

Accessory

Microphone Cable: 5 m (16.4 ft) × 1

A Connecting and Disconnecting the Microphone

Cable

• Before making the connection, make sure that the microphone and the

component (e.g., amplier) are switched off.

• Insert the connector into the microphone socket. Align the key on

the connector with the groove in the microphone, and then push the

connector into the microphone until it clicks.

• Lower the volume of the component (e.g., amplier) before connecting

the microphone.

• To disconnect the cable from the microphone, pull the connector away

from the microphone while depressing the latch lock.

B How to Use

• Set the switch to ON when using the microphone, and set it to OFF

when not in use.

• When using the microphone, do not cover any part of the grille with

your hand to ensure sound quality.

C Hints

• In order to prevent howling:

- Lower the volume.

- Place this microphone so that it is not pointed to the speaker and

that there is a sufficient distance between the microphone and the

speaker.

- Do not cover the lower part of the grille with your hand.

• Positioning the microphone close to the sound source causes the

so-called proximity effect (a boost in the low-frequency response). This

phenomenon can be used to create a richer and warmer bass sound.

D 1 2 Wiring

3 Frequency Response

4 Polar Pattern

7

Specications

Type Dynamic Microphone

Polar Pattern Unidirectional

Frequency Response 60 Hz – 15,000 Hz

Sensitivity / 2.83 V, 1 m -54 dB ± 3 dB (0 dB = 1 V/Pa, 1 kHz)

Output Impedance 500 Ω ± 30 % (1 kHz)

Connector 3-pin XLR-M type

Cable ø6 mm × 5 m with XLR-F type connector

and 6.3 mm plug

Dimensions (Microphone only)

(max. diameter × length)

ø51 × 169 mm (2 × 6-5/8 in)

Weight (Microphone only) 220 g (7.80 oz.)

* Specications are subject to change without notice.

Information for users on collection and disposal of old

equipment:

This symbol on the products, packaging, and/or accompanying

documents means that used electrical and electronic products

should not be mixed with general household waste.

For proper treatment, recovery and recycling of old products,

please take them to applicable collection points, in accordance

with your national legislation.

By disposing of these products correctly, you will help to save valuable

resources and prevent any potential negative effects on human health and

the environment which could otherwise arise from inappropriate waste

handling.

For more information about collection and recycling of old products, please

contact your local municipality, your waste disposal service or the point of

sale where you purchased the items.

For business users in the European Union:

If you wish to discard electrical and electronic equipment, please contact

your dealer or supplier for further information.

Information on Disposal in other Countries outside the

European Union:

This symbol is only valid in the European Union. If you wish to discard

these items, please contact your local authorities or dealer and ask for the

correct method of disposal.

(weee_eu_en_02)

48

Important Notice: Guarantee Information for

customers in European Economic Area (EEA) and

Switzerland

English

Important Notice: Guarantee Information for customers in EEA* and

Switzerland

For detailed guarantee information about this Yamaha product, and Pan-EEA* and

Switzerland warranty service, please either visit the website address below (Printable

le is available at our website) or contact the Yamaha representative oce for your

country. * EEA: European Economic Area

Deutsch

Wichtiger Hinweis: Garantie-Information für Kunden in der EWR* und der

Schweiz

Für nähere Garantie-Information über dieses Produkt von Yamaha, sowie über den

Pan-EWR*- und Schweizer Garantieservice, besuchen Sie bitte entweder die folgend

angegebene Internetadresse (eine druckfähige Version bendet sich auch auf unserer

Webseite), oder wenden Sie sich an den für Ihr Land zuständigen Yamaha-Vertrieb.

*EWR: Europäischer Wirtschaftsraum

Français

Remarque importante: informations de garantie pour les clients de l’EEE

et la Suisse

Pour des informations plus détaillées sur la garantie de ce produit Yamaha et sur le

service de garantie applicable dans l’ensemble de l’EEE ainsi qu’en Suisse, consultez

notre site Web à l’adresse ci-dessous (le chier imprimable est disponible sur notre site

Web) ou contactez directement Yamaha dans votre pays de résidence. * EEE : Espace

Economique Européen

Nederlands

Belangrijke mededeling: Garantie-informatie voor klanten in de EER* en

Zwitserland

Voor gedetailleerde garantie-informatie over dit Yamaha-product en de garantieservice

in heel de EER* en Zwitserland, gaat u naar de onderstaande website (u vind een

afdrukbaar bestand op onze website) of neemt u contact op met de vertegenwoordiging

van Yamaha in uw land. * EER: Europese Economische Ruimte

Español

Aviso importante: información sobre la garantía para los clientes del

EEE* y Suiza

Para una información detallada sobre este producto Yamaha y sobre el soporte de

garantía en la zona EEE* y Suiza, visite la dirección web que se incluye más abajo

(la version del archivo para imprimir esta disponible en nuestro sitio web) o póngase

en contacto con el representante de Yamaha en su país. * EEE: Espacio Económico

Europeo

49

Italiano

Avviso importante: informazioni sulla garanzia per i clienti residenti

nell’EEA* e in Svizzera

Per informazioni dettagliate sulla garanzia relativa a questo prodotto Yamaha e

l’assistenza in garanzia nei paesi EEA* e in Svizzera, potete consultare il sito Web

all’indirizzo riportato di seguito (è disponibile il le in formato stampabile) oppure

contattare l’ucio di rappresentanza locale della Yamaha. * EEA: Area Economica

Europea

Português

Aviso importante: informações sobre as garantias para clientes da AEE*

e da Suíça

Para obter uma informação pormenorizada sobre este produto da Yamaha e sobre o

serviço de garantia na AEE* e na Suíça, visite o site a seguir (o arquivo para impressão

está disponível no nosso site) ou entre em contato com o escritório de representação

da Yamaha no seu país. * AEE: Área Econômica Européia

Ελληνικά

Σημαντική σημείωση: Πληροφορίες εγγύησης για τους πελάτες στον

ΕΟΧ* και Ελβετία

Για λεπτομερείς πληροφορίες εγγύησης σχετικά με το παρόν προϊόν της Yamaha και

την κάλυψη εγγύησης σε όλες τις χώρες του ΕΟΧ και την Ελβετία, επισκεφτείτε την

παρακάτω ιστοσελίδα (Εκτυπώσιμη μορφή είναι διαθέσιμη στην ιστοσελίδα μας) ή

απευθυνθείτε στην αντιπροσωπεία της Yamaha στη χώρα σας. * ΕΟΧ: Ευρωπαϊκός

Οικονομικός Χώρος

Svenska

Viktigt: Garantiinformation för kunder i EES-området* och Schweiz

För detaljerad information om denna Yamahaprodukt samt garantiservice i hela

EES-området* och Schweiz kan du antingen besöka nedanstående webbaddress (en

utskriftsvänlig l nns på webbplatsen) eller kontakta Yamahas ociella representant i

ditt land. * EES: Europeiska Ekonomiska Samarbetsområdet

Norsk

Viktig merknad: Garantiinformasjon for kunder i EØS* og Sveits

Detaljert garantiinformasjon om dette Yamaha-produktet og garantiservice for

hele EØS-området* og Sveits kan fås enten ved å besøke nettadressen nedenfor

(utskriftsversjon nnes på våre nettsider) eller kontakte kontakte Yamaha-kontoret i

landet der du bor. *EØS: Det europeiske økonomiske samarbeidsområdet

Dansk

Vigtig oplysning: Garantioplysninger til kunder i EØO* og Schweiz

De kan nde detaljerede garantioplysninger om dette Yamaha-produkt og den fælles

garantiserviceordning for EØO* (og Schweiz) ved at besøge det websted, der er

angivet nedenfor (der ndes en l, som kan udskrives, på vores websted), eller ved at

kontakte Yamahas nationale repræsentationskontor i det land, hvor De bor. * EØO: Det

Europæiske Økonomiske Område

50

Suomi

Tärkeä ilmoitus: Takuutiedot Euroopan talousalueen (ETA)* ja Sveitsin

asiakkaille

Tämän Yamaha-tuotteen sekä ETA-alueen ja Sveitsin takuuta koskevat

yksityiskohtaiset tiedot saatte alla olevasta nettiosoitteesta. (Tulostettava tiedosto

saatavissa sivustollamme.) Voitte myös ottaa yhteyttä paikalliseen Yamaha-edustajaan.

*ETA: Euroopan talousalue

Polski

Ważne: Warunki gwarancyjne obowiązujące w EOG* i Szwajcarii

Aby dowiedzieć się więcej na temat warunków gwarancyjnych tego produktu rmy

Yamaha i serwisu gwarancyjnego w całym EOG* i Szwajcarii, należy odwiedzić

wskazaną poniżej stronę internetową (Plik gotowy do wydruku znajduje się na naszej

stronie internetowej) lub skontaktować się z przedstawicielstwem rmy Yamaha w

swoim kraju. * EOG — Europejski Obszar Gospodarczy

Česky

Důležité oznámení: Záruční informace pro zákazníky v EHS* a ve

Švýcarsku

Podrobné záruční informace o tomto produktu Yamaha a záručním servisu v celém

EHS* a ve Švýcarsku naleznete na níže uvedené webové adrese (soubor k tisku je

dostupný na našich webových stránkách) nebo se můžete obrátit na zastoupení rmy

Yamaha ve své zemi. * EHS: Evropský hospodářský prostor

Magyar

Fontos gyelmeztetés: Garancia-információk az EGT* területén és

Svájcban élő vásárlók számára

A jelen Yamaha termékre vonatkozó részletes garancia-információk, valamint az EGT*-

re és Svájcra kiterjedő garanciális szolgáltatás tekintetében keresse fel webhelyünket

az alábbi címen (a webhelyen nyomtatható fájlt is talál), vagy pedig lépjen kapcsolatba

az országában működő Yamaha képviseleti irodával. * EGT: Európai Gazdasági Térség

Eesti keel

Oluline märkus: Garantiiteave Euroopa Majanduspiirkonna (EMP)* ja

Šveitsi klientidele

Täpsema teabe saamiseks selle Yamaha toote garantii ning kogu Euroopa

Majanduspiirkonna ja Šveitsi garantiiteeninduse kohta, külastage palun veebisaiti

alljärgneval aadressil (meie saidil on saadaval prinditav fail) või pöörduge Teie regiooni

Yamaha esinduse poole. * EMP: Euroopa Majanduspiirkond

Latviešu

Svarīgs paziņojums: garantijas informācija klientiem EEZ* un Šveicē

Lai saņemtu detalizētu garantijas informāciju par šo Yamaha produktu, kā arī garantijas

apkalpošanu EEZ* un Šveicē, lūdzu, apmeklējiet zemāk norādīto tīmekļa vietnes adresi

(tīmekļa vietnē ir pieejams drukājams fails) vai sazinieties ar jūsu valsti apkalpojošo

Yamaha pārstāvniecību. * EEZ: Eiropas Ekonomikas zona

51

Lietuvių kalba

Dėmesio: informacija dėl garantijos pirkėjams EEE* ir Šveicarijoje

Jei reikia išsamios informacijos apie šį „Yamaha“ produktą ir jo techninę priežiūrą visoje

EEE* ir Šveicarijoje, apsilankykite mūsų svetainėje toliau nurodytu adresu (svetainėje

yra spausdintinas failas) arba kreipkitės į „Yamaha“ atstovybę savo šaliai. *EEE –

Europos ekonominė erdvė

Slovenčina

Dôležité upozornenie: Informácie o záruke pre zákazníkov v EHP* a

Švajčiarsku

Podrobné informácie o záruke týkajúce sa tohto produktu od spoločnosti Yamaha a

garančnom servise v EHP* a Švajčiarsku nájdete na webovej stránke uvedenej nižšie

(na našej webovej stránke je k dispozícii súbor na tlač) alebo sa obráťte na zástupcu

spoločnosti Yamaha vo svojej krajine. * EHP: Európsky hospodársky priestor

Slovenščina

Pomembno obvestilo: Informacije o garanciji za kupce v EGP* in Švici

Za podrobnejše informacije o tem Yamahinem izdelku ter garancijskem servisu v

celotnem EGP in Švici, obiščite spletno mesto, ki je navedeno spodaj (natisljiva

datoteka je na voljo na našem spletnem mestu), ali se obrnite na Yamahinega

predstavnika v svoji državi. * EGP: Evropski gospodarski prostor

Български език

Важно съобщение: Информация за гаранцията за клиенти в ЕИП* и

Швейцария

За подробна информация за гаранцията за този продукт на Yamaha и

гаранционното обслужване в паневропейската зона на ЕИП* и Швейцария или

посетете посочения по-долу уеб сайт (на нашия уеб сайт има файл за печат),

или се свържете с представителния офис на Yamaha във вашата страна. * ЕИП:

Европейско икономическо пространство

Limba română

Noticare importantă: Informaţii despre garanţie pentru clienţii din SEE*

şi Elveţia

Pentru informaţii detaliate privind acest produs Yamaha şi serviciul de garanţie Pan-

SEE* şi Elveţia, vizitaţi site-ul la adresa de mai jos (şierul imprimabil este disponibil pe

site-ul nostru) sau contactaţi biroul reprezentanţei Yamaha din ţara dumneavoastră.

* SEE: Spaţiul Economic European

Hrvatski

Važna obavijest: Informacije o jamstvu za države EGP-a i Švicarske

Za detaljne informacije o jamstvu za ovaj Yamahin proizvod te jamstvenom servisu

za cijeli EGP i Švicarsku, molimo Vas da posjetite web-stranicu navedenu u nastavku

ili kontaktirate ovlaštenog Yamahinog dobavljača u svojoj zemlji. * EGP: Europski

gospodarski prostor

https://europe.yamaha.com/warranty/

52

NORTH AMERICA

CANADA

Yamaha Canada Music Ltd.

135 Milner Avenue, Toronto, Ontario,

M1S 3R1, Canada

Tel: +1- 416-298-1311

U.S.A.

Yamaha Corporation of America

6600 Orangethorpe Avenue, Buena Park,

CA 90620, U.S.A.

Tel: +1-714-522-9011

CENTRAL & SOUTH AMERICA

MEXICO

Yamaha de México, S.A. de C.V.

Av. Insurgentes Sur 1647 Piso 9, Col.

San José Insurgentes, Delegación Benito

Juárez, CDMX,

C.P. 03900, México

Tel: +52-55-5804-0600

BRAZIL

Yamaha Musical do Brasil Ltda.

Praça Professor José Lannes, 40, Cjs 21

e 22, Brooklin Paulista Novo CEP 04571-

100 – São Paulo – SP, Brazil

Tel: +55-11-3704-1377

ARGENTINA

Yamaha Music Latin America, S.A.,

Sucursal Argentina

Olga Cossettini 1553, Piso 4 Norte,

Madero Este-C1107CEK,

Buenos Aires, Argentina

Tel: +54-11- 4119-70 00

PANAMA AND OTHER LATIN

AMERICAN/CARIBBEAN REGIONS

Yamaha Music Latin America, S.A.

Edif. Torre Banco General, Piso 7,

Urbanización Marbella, Calle 47 y

Aquilino de la Guardia,

Ciudad de Panamá, República de

Panamá

Tel: +507-269-5311

EUROPE

THE UNITED KINGDOM/IRELAND

Yamaha Music Europe GmbH (UK)

Sherbourne Drive, Tilbrook, Milton

Keynes, MK7 8BL, U.K.

Tel: +44-1908-366700

GERMANY

Yamaha Music Europe GmbH

Siemensstrasse 22-34, 25462 Rellingen,

Germany

Tel: +49-4101-303-0

SWITZERLAND/LIECHTENSTEIN

Yamaha Music Europe GmbH,

Branch Switzerland in Thalwil

Seestrasse 18a, 8800 Thalwil,

Switzerland

Tel: +41-44-3878080

AUSTRIA/BULGARIA/CZECH

REPUBLIC/HUNGARY/ROMANIA/

SLOVAKIA/SLOVENIA

Yamaha Music Europe GmbH

Branch Austria

Schleiergasse 20, 1100 Wien, Austria

Tel: +43-1-60203900

POLAND

Yamaha Music Europe GmbH

Sp.z o.o. Oddział w Polsce

ul. Wielicka 52, 02-657 Warszawa,

Poland

Tel: +48-22-880-08-88

MALTA

Olimpus Music Ltd.

Valletta Road, Mosta MST9010, Malta

Tel: +356-2133-2093

ADDRESS LIST

53

NETHERLANDS/BELGIUM/

LUXEMBOURG

Yamaha Music Europe Branch

Benelux

Clarissenhof 5b, 4133 AB Vianen,

The Netherlands

Tel: +31-347-358040

FRANCE

Yamaha Music Europe

7 rue Ambroise Croizat, Zone d’activités

de Pariest, 77183 Croissy-Beaubourg,

France

Tel: +33-1-6461-4000

ITALY

Yamaha Music Europe GmbH,

Branch Italy

Via Tinelli N.67/69 20855 Gerno di Lesmo

(MB), Italy

Tel: +39-039-9065-1

SPAIN/PORTUGAL

Yamaha Music Europe GmbH

Ibérica, Sucursal en España

Ctra. de la Coruña km. 17,200, 28231

Las Rozas de Madrid, Spain

Tel: +34-91-639-88-88

GREECE

Philippos Nakas S.A. The Music

House

19th klm. Leof. Lavriou 190 02 Peania –

Attiki, Greece

Tel: +30-210-6686168

SWEDEN/FINLAND/ICELAND

Yamaha Music Europe GmbH

Germany lial Scandinavia

JA Wettergrensgata 1, 400 43 Göteborg,

Sweden

Tel: +46-31-89-34-00

DENMARK

Yamaha Music Denmark,

Fillial of Yamaha Music Europe

GmbH, Tyskland

Generatorvej 8C, ST. TH. , 2860 Søborg,

Denmark

Tel: +45-44-92-49-00

NORWAY

Yamaha Music Europe GmbH

Germany - Norwegian Branch

Grini Næringspark 1, 1332 Østerås,

Norway

Tel: +47-6716 -7800

CYPRUS

Yamaha Music Europe GmbH

Siemensstrasse 22-34, 25462 Rellingen,

Germany

Tel: +49-4101-303-0

RUSSIA

Yamaha Music (Russia) LLC.

Room 37, entrance 7, bld. 7, Kievskaya

street, Moscow, 121059, Russia

Tel: +7-495-626-5005

OTHER EUROPEAN REGIONS

Yamaha Music Europe GmbH

Siemensstrasse 22-34, 25462 Rellingen,

Germany

Tel: +49-4101-3030

AFRICA

Yamaha Music Gulf FZE

JAFZA-16, Oce 512, P.O.Box 17328,

Jebel Ali FZE, Dubai, UAE

Tel: +971-4-801-1500

MIDDLE EAST

TURKEY

Yamaha Music Europe GmbH

Merkezi Almanya Türkiye İstanbul

Şubesi

Mor Sumbul Sokak Varyap Meridian

Business 1.Blok No:1 113 -114-115

Bati Atasehir Istanbul, Turkey

Tel: +90-216-275-7960

OTHER REGIONS

Yamaha Music Gulf FZE

JAFZA-16, Oce 512, P.O.Box 17328,

Jebel Ali FZE, Dubai, UAE

Tel: +971-4-801-1500

54

ASIA

THE PEOPLE’S REPUBLIC OF

CHINA

Yamaha Music & Electronics

(China) Co.,Ltd.

2F, Yunhedasha, 1818 Xinzha-lu, Jingan-

qu, Shanghai, China

Tel: +86-400-051-7700

INDIA

Yamaha Music India Private

Limited

P-401, JMD Megapolis, Sector-48, Sohna

Road, Gurugram-122018, Haryana, India

Tel: +91-124-485-3300

INDONESIA

PT Yamaha Musik Indonesia

Distributor

Yamaha Music Center Bldg. Jalan Jend.

Gatot Subroto Kav. 4, Jakarta 12930,

Indonesia

Tel: +62-21-520-2577

KOREA

Yamaha Music Korea Ltd.

11F, Prudential Tower, 298, Gangnam-

daero, Gangnam-gu, Seoul, 06253, Korea

Tel: +82-2-3467-3300

MALAYSIA

Yamaha Music (Malaysia) Sdn. Bhd.

No.8, Jalan Perbandaran, Kelana Jaya,

47301 Petaling Jaya, Selangor, Malaysia

Tel: +60-3-78030900

SINGAPORE

Yamaha Music (Asia) Private

Limited

Block 202 Hougang Street 21, #02-00,

Singapore 530202, Singapore

Tel: +65-6740- 9200

TAIWAN

Yamaha Music & Electronics

Taiwan Co.,Ltd.

2F., No.1, Yuandong Rd., Banqiao Dist.,

New Taipei City 22063, Taiwan (R.O.C.)

Tel: +886-2-7741-8888

THAILAND

Siam Music Yamaha Co., Ltd.

3, 4, 15, 16th Fl., Siam Motors Building,

891/1 Rama 1 Road, Wangmai,

Pathumwan, Bangkok 10330, Thailand

Tel: +66-2215-2622

VIETNAM

Yamaha Music Vietnam Company

Limited

15th Floor, Nam A Bank Tower, 201-203

Cach Mang Thang Tam St., Ward 4,

Dist.3, Ho Chi Minh City, Vietnam

Tel: +84-8-3818-1122

OTHER ASIAN REGIONS

http://asia.yamaha.com/

OCEANIA

AUSTRALIA

Yamaha Music Australia Pty. Ltd.

Level 1, 80 Market Street, South

Melbourne, VIC 3205, Australia

Tel: +61- 3-9693 - 5111

REGIONS AND TRUST

TERRITORIES IN PACIFIC OCEAN

http://asia.yamaha.com/

Head Oce/Manufacturer: Yamaha Corporation

10-1, Nakazawa-cho, Naka-ku, Hamamatsu, 430-8650, Japan

Importer (European Union): Yamaha Music Europe GmbH

Siemensstrasse 22-34, 25462 Rellingen, Germany

Importer (United Kingdom): Yamaha Music Europe GmbH (UK)

Sherbourne Drive, Tilbrook, Milton Keynes, MK7 8BL, United Kingdom

PA57

55

雅马哈乐器音响（中国）投资有限公司

上海市静安区新闸路 1818 号云和大厦 2 楼

客户服务热线：4000517700

公司网址：https://www.yamaha.com.cn

制造商：雅马哈株式会社

制造商地址：日本静冈县滨松市中区中泽町 10-1

󳦕󲨌󰶢󵞙

󽶶󽶵󽶲󽶺󽶸󽶷󽶲󹆑󲕮󵐉󴊖󳢌󲠬󰱉󱑲󰱉󴆈󵃅 󽶳󽶲󽶳

Yamaha Pro Audio global website

http://www.yamahaproaudio.com/

Yamaha Downloads

https://download.yamaha.com/

Manual Development Group

© 2019 Yamaha Corporation

Published 04/2021

2021 年4月发行

MWOE-A0

VFE9100
