Yamaha KP90 Owner’s Manual Owner's En Om A0

User Manual: Yamaha KP90 Owner's Manual

Open the PDF directly: View PDF .
Page Count: 13

Cover
Precautions
Contents
Package Contents
Specifications
Assembling the KP90
Making Connections
Adjusting the Output Level
Troubleshooting

Owner’s Manual

Benutzerhandbuch

Mode d’emploi

Manual do Proprietário

取扱説明書

KP90

EnglishDeutschFrançais

Português

ELECTRONIC DRUM PAD

PAD DE BATTERIE ÉLECTRONIQUE

⭫啉ᢉ࠱ᶵ

電子ドラムパッド

EN PT

(bottom_en_01)

(bottom_de_01)

(bottom_fr_01)

(bottom_pt_01)

(bottom_zh_01)

(bottom_ja_02)

The model number, serial number, power requirements, etc., may be found on or near the name plate, which is at the bottom of the unit.

You should note this serial number in the space provided below and retain this manual as a permanent record of your purchase to aid

identification in the event of theft.

Model No.

Serial No.

Die Nummer des Modells, die Seriennummer, der Leistungsbedarf usw. sind auf dem Typenschild, das sich auf der

Unterseite des Geräts befindet, oder in der Nähe davon angegeben. Sie sollten diese Seriennummer an der unten vor-

gesehenen Stelle eintragen und dieses Handbuch als dauerhaften Beleg für Ihren Kauf aufbewahren, um im Fall eines

Diebstahls die Identifikation zu erleichtern.

Modell Nr.

Seriennr.

Le numéro de modèle, le numéro de série, l'alimentation requise, etc., se trouvent sur ou près de la plaque signalétique du produit, située

dans la partie inférieure de l'unité. Notez le numéro de série dans l'espace fourni ci-dessous et conservez ce manuel en tant que preuve

permanente de votre achat afin de faciliter l'identification du produit en cas de vol.

N° de modèle

N° de série

O número de modelo, número de série, requisitos de energia, etc. podem ser encontrados na placa de nome, que está na parte inferior

da unidade. Anote-o no espaço reservado abaixo e guarde este manual como registro de compra permanente para auxiliar na identifica-

ção do produto em caso de roubo.

N° do modelo

N° de série

本产品的型号、序列号、电源要求等规格可能标在铭牌上或铭牌附近，铭牌位于本机底部。请将该序列号

填写到下方的横线上，并妥善保存本说明书，以便在产品被盗时作为永久购买凭证使用。

型号名称

序列号

機種名(品番)、製造番号(シリアルナンバー )、電源条件などの情報は、製品の底面にある銘板または銘板付近に表示されて

います。製品を紛失した場合などでもご自身のものを特定していただけるよう、機種名と製造番号については以下の欄にご

記入のうえ、大切に保管していただくことをお勧めします。

機種名

製造番号

(weee_eu_en_02)

(weee_eu_de_02)

(weee_eu_fr_02)

(weee_eu_pt_02a)

Information for users on collection and disposal of old equipment:

This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic products should

not be mixed with general household waste.

For proper treatment, recovery and recycling of old products, please take them to applicable collection points, in accordance with

your national legislation.

By disposing of these products correctly, you will help to save valuable resources and prevent any potential negative effects on

human health and the environment which could otherwise arise from inappropriate waste handling.

For more information about collection and recycling of old products, please contact your local municipality, your waste disposal ser-

vice or the point of sale where you purchased the items.

For business users in the European Union:

If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.

Information on Disposal in other Countries outside the European Union:

This symbol is only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer

and ask for the correct method of disposal.

Verbraucherinformation zur Sammlung und Entsorgung alter Elektrogeräte

Befindet sich dieses Symbol auf den Produkten, der Verpackung und/oder beiliegenden Unterlagen, so sollten benutzte elektrische

Geräte nicht mit dem normalen Haushaltsabfall entsorgt werden.

In Übereinstimmung mit Ihren nationalen Bestimmungen bringen Sie alte Geräte bitte zur fachgerechten Entsorgung, Wiederaufbe-

reitung und Wiederverwendung zu den entsprechenden Sammelstellen.

Durch die fachgerechte Entsorgung der Elektrogeräte helfen Sie, wertvolle Ressourcen zu schützen, und verhindern mögliche nega-

tive Auswirkungen auf die menschliche Gesundheit und die Umwelt, die andernfalls durch unsachgerechte Müllentsorgung auftreten

könnten.

Für weitere Informationen zum Sammeln und Wiederaufbereiten alter Elektrogeräte kontaktieren Sie bitte Ihre örtliche Stadt- oder

Gemeindeverwaltung, Ihren Abfallentsorgungsdienst oder die Verkaufsstelle der Artikel.

Information für geschäftliche Anwender in der Europäischen Union:

Wenn Sie Elektrogeräte ausrangieren möchten, kontaktieren Sie bitte Ihren Händler oder Zulieferer für weitere Informationen.

Entsorgungsinformation für Länder außerhalb der Europäischen Union:

Dieses Symbol gilt nur innerhalb der Europäischen Union. Wenn Sie solche Artikel ausrangieren möchten, kontaktieren Sie bitte Ihre

örtlichen Behörden oder Ihren Händler und fragen Sie nach der sachgerechten Entsorgungsmethode.

Informations concernant la collecte et le traitement des déchets d’équipements électriques et électroniques

Le symbole sur les produits, l'emballage et/ou les documents joints signifie que les produits électriques ou électroniques usagés ne

doivent pas être mélangés avec les déchets domestiques habituels.

Pour un traitement, une récupération et un recyclage appropriés des déchets d’équipements électriques et électroniques, veuillez les

déposer aux points de collecte prévus à cet effet, conformément à la réglementation nationale.

En vous débarrassant correctement des déchets d’équipements électriques et électroniques, vous contribuerez à la sauvegarde de

précieuses ressources et à la prévention de potentiels effets négatifs sur la santé humaine qui pourraient advenir lors d'un traitement

inapproprié des déchets.

Pour plus d'informations à propos de la collecte et du recyclage des déchets d’équipements électriques et électroniques, veuillez

contacter votre municipalité, votre service de traitement des déchets ou le point de vente où vous avez acheté les produits.

Pour les professionnels dans l'Union européenne :

Si vous souhaitez vous débarrasser des déchets d’équipements électriques et électroniques, veuillez contacter votre vendeur ou

fournisseur pour plus d'informations.

Informations sur la mise au rebut dans d'autres pays en dehors de l'Union européenne :

Ce symbole est seulement valable dans l'Union européenne. Si vous souhaitez vous débarrasser de déchets d’équipements électri-

ques et électroniques, veuillez contacter les autorités locales ou votre fournisseur et demander la méthode de traitement appropriée.

Informações para os utilizadores relativas à recolha e eliminação de equipamentos usados

Este símbolo, presente em produtos, embalagens e/ou incluído na documentação associada, indica que os produtos elétricos e ele-

trónicos usados não devem ser eliminados juntamente com os resíduos domésticos em geral.

O procedimento correto consiste no tratamento, recuperação e reciclagem de produtos usados, pelo que deve proceder à respetiva

entrega nos pontos de recolha adequados, em conformidade com a legislação nacional em vigor.

A eliminação destes produtos de forma adequada permite poupar recursos valiosos e evitar potenciais efeitos prejudiciais para a

saúde pública e para o ambiente, associados ao processamento incorreto dos resíduos.

Para mais informações relativas à recolha e reciclagem de produtos usados, contacte as autoridades locais, o serviço de eliminação

de resíduos ou o ponto de venda onde foram adquiridos os itens relevantes.

Informações para utilizadores empresariais na União Europeia:

Para proceder à eliminação de equipamento elétrico e eletrónico, contacte o seu revendedor ou fornecedor para obter informações

adicionais.

Informações relativas à eliminação em países não pertencentes à União Europeia:

Este símbolo é válido exclusivamente na União Europeia. Caso pretenda eliminar este tipo de itens, contacte as autoridades locais

ou o seu revendedor e informe-se acerca do procedimento correto para proceder à respetiva eliminação.

English

The purpose of the precautions detailed below is to ensure that this product is used safely without fear either of accidental

injury to you or other people or of damage to property. As a means, furthermore, of indicating the severity and immediacy of

any risk of injury or damage associated with incorrect operation, these precautions are classified as either WARNING or

CAUTION. The instructions presented together with precautions are extremely important in terms of ensuring safety, and

therefore, they should be fully observed.

*: After reading this Owner’s Manual, ensure that it is kept in a safe, convenient location for future reference.

NOTICE

• Do not expose the product to rain, use it near water or in damp or wet conditions, or place on it any containers (such as

vases, bottles or glasses) containing liquids which might spill into any openings. Doing so can result in possibility cause

malfunction or damage to the product.

• Avoid using or storing this product in very hot locations (i.e., in direct sunlight, in close proximity to a heater, or in a closed

vehicle) or in highly-humid locations (i.e., in a bathroom or outdoors in wet weather). Failure to observe this precaution

can lead to warping, discoloration, malfunction, or breakdown.

• Avoid cleaning this product with organic solvents, paint thinner, or alcohol as these substances can cause warping and

discoloration. Instead, we recommend that you remove dust using a soft dry cloth or wipe clean using a moist, tightly-

wrung cloth. If the product is very dirty, wipe the dirt away using a cloth moistened with a neutral detergent solution and

tightly wrung. Following this, wipe away the detergent solution using a cloth soaked in water and tightly wrung.

• When connecting and disconnecting cables, be sure to hold the plug and not the cable itself. In addition, avoid placing

heavy items on top of cables, and do not allow them to come into contact with sharp edges and the like. Failure to avoid

these precautions can to cable breakage and unintended disconnection.

INFORMATION

• The illustrations as shown in this manual are for instructional purposes only, and may appear somewhat different from

those on your product.

• The company names and product names in this manual are the trademarks or registered trademarks of their respective

companies.

PRECAUTIONS Please read carefully before Proceeding.

WARNING

Always follow the basic precautions listed below to avoid the possibility of seri-

ous injury or even death from fire or other hazards. These precautions include,

but are not limited to, the following:

• Do not put burning items, such as candles, near the unit. A burning item may fall over and cause a fire.

CAUTION

Always follow the basic precautions listed below to avoid the possibility of physi-

cal injury to you or others, or damage to the instrument or other property. These

precautions include, but are not limited to, the following:

• Assemble this product in the proper sequence by following the assembly instructions in this manual. Also, make sure to

tighten the bolts regularly. Failure to do so might result in damage to the product or even injury.

• When assembling this product (i.e., when connecting the base or a foot pedal to the body), take care to avoid squeez-

ing, crushing, or otherwise injuring fingers, feet, and other body parts.

• The tips of the anti-slip stoppers have sharp points. In order to avoid injury, therefore, special care should be taken

whenever handling these items.

• Do not setup this product on an incline, on an unstable platform, or on any other unsafe surface. If this precaution is not

observed, the product may topple over or fall, resulting in injury or equipment damage.

• Be sure to securely tighten bolts and other fasteners when setting up this product. In addition, be sure to proceed slowly

when loosening bolts. If this precaution is not observed, the product may fall or topple over, resulting in injury or equip-

ment damage.

• Whenever setting up this product, ensure that cables and the like are arranged safely. If anyone were to trip on a cable,

the product could topple over and cause injury.

• Under no circumstances should this product be disassembled or customized. Failure to observe this precaution can

result in injury or malfunction.

• Do not rest your weight on, or place heavy objects on the product, and do not use excessive force on the knob, jack or connector.

• Keep small parts out of the reach of infants. Your children may accidentally swallow them.

Yamaha cannot be held responsible for damage caused by improper use or modifications to the product.

Precautions

Precautions .................................................................. 5

Package Contents........................................................ 7

Specifications............................................................... 7

Assembling the KP90................................................... 8

Making Connections .................................................... 9

Adjusting the Output Level......................................... 10

Troubleshooting.......................................................... 10

Contents

*: If you have purchased a pad set, please refer to the “Assembly Manual” that came with it.

-KP90: q KP90 main unit × 1 (a: body × 1, b: base × 1)

w Stereo phone cable × 1

e Anti-slip stoppers (incl. springs) × 2

r Owner’s Manual (this booklet) × 1

Package Contents

* Foot pedal is sold separately.

Specifications

 KP90 Kick Pad

- Size (assembled): 335 (w) × 299 (d) × 438 (h) mm

- Weight: 4.4 kg

- Sensing method: Piezoelectric trigger-sensor element × 1

- Output connector: Standard stereo phone jack

- Input connector: Standard mono phone jack

*: The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the

Yamaha website then download the manual file. Since specifications, equipment or separately sold accessories may not be the same

in every locale, please check with your Yamaha dealer.

q a

q b

1. As shown in the illustration, remove the base attachment wing bolts q, and use them to attach the base w to the main

body e. Do not fully tighten the wing bolts in this step.

If damage to the floor is not a concern, connect the spurs r to the base so that the tip of the spurs dig into

the riser or floor. To prevent damage to the floor, retract the spurs r, place a mat or carpet under the KP90

and use the Velcro™ strip t, attached to the underside of the KP90’s base to prevent the KP90 from moving

during performance.

2. Attach your foot pedal to the KP90. Adjust the base’s position so that the pad surface of the KP90 is vertical when the

foot pedal is attached, and the KP90 is stable when the beater hits the pad. After the position is determined, firmly

tighten the wing bolts q to secure.

3. Adjust the position of the pedal and the length of the beater shaft so that the foot pedal’s beater y hits in the center of

the kick pad u.

The KP90 can be used with a double foot pedal (YAMAHA DFP series, etc). When using a double foot pedal,

please adjust the position of the pedal and the length of the beater y so that the space between the two

beaters is positioned in the center of the pad. [Fig. A]

Assembling the KP90

Figure A

Using a stereo phone cable q (included), connect the KP90’s OUTPUT jack w to an appropriate input jack on a DTX

Series drum trigger module. Be sure to connect the L-shaped end of the cable to the KP90.

• On the drum trigger module, set the corresponding pad type as a kick pad. Setting of any other pad type

may have unintended consequences such as double triggering (where a single strike produces two dis-

tinct sounds). For more details, refer to the Owner’s Manual that came with the drum trigger module.

• If using the KP90 as a standalone pad with no other pad connected to it, a mono phone cable can also be

used to make this connection to the drum trigger module.

- Connecting an additional pad

The PAD INPUT jack e provided on the KP90 can be used to add an additional pad (sold separately). To do so, connect

the output connector on the additional pad to the PAD INPUT jack e using a mono or stereo phone cable.

• When connecting a drum trigger module and a KP90 having a pad connected via its PAD INPUT jack e, the

most suitable jack will depend on the type of module being used. For more details, refer to the Owner’s

Manual that came with the drum trigger module.

• When you hit a pad connected to the PAD INPUT jack e, only the main surface (head or pad on the snare/

tom pad, or bow on the hi-hat/cymbal pad) produce sound. No sound will be produced on any other sec-

tion, such as the rim or edge. In addition, special functions using the rim switch (such as choking and mut-

ing) will not supported in such a case.

Making Connections

ELECTRONIC DRUM PAD

The output level from the KP90 can be raised by turning the level adjuster q clockwise and vice-versa. Be sure to adjust

this level to best suit the strength with which you strike the pad, your desired dynamic range (i.e., the difference between

loudest and quietest volumes), and the type of DTX Series drum trigger module being used. If the level adjustment knob is

turned all the way up but the output level is still low, raise the DTX Series Drum Trigger Module’s input level using the Gain

parameter from the trigger area.

If playing fortissimo (ff) passages with the KP90 connected to a DTX Series drum trigger module, the gain level

on the module’s trigger setup screen should be adjusted to between 90% and 95% of the displayed input level.

For more details, refer to the Owner’s Manual that came with the drum trigger module. Excessively large output

levels can have unintended consequences such as a reduced dynamic range and double triggering (where a sin-

gle strike produces two distinct sounds).

No sound is produced or the volume is too low.

-Ensure that the KP90 is correctly connected to a DTX Series drum trigger module using the stereo phone cable pro-

vided. (See Making Connections.)

-Check the pad’s output level. If this level is too low, use the level adjuster to increase it. (See Adjusting the Output Level.)

-If no sound is produced when the pad is struck softly, lower the setting of the Minimum Level parameter from the mod-

ule’s trigger area.

-Check that the base’s position is adjusted so that the beater hits the center of the pad correctly. (See Assembling the

KP90.)

Two or more sounds are produced in response to a single strike (i.e., double-triggering).

-Check the pad’s output level. If this level is too high, use the level adjuster to reduce it. Note that triggering of two or

more sounds occurs when the output level is excessively high due to the fact that the signal being input into the drum

trigger module remains large for a relatively long period of time. (See Adjusting the Output Level.)

For more troubleshooting tips, refer to the Owner’s Manual that came with the DTX Series drum trigger module. If

you still cannot find the information you need to resolve a problem, please contact your Yamaha dealer or the cus-

tomer support center indicated at the end of this manual for assistance.

Adjusting the Output Level

Troubleshooting

Drums Limited Warranty

LIMITED WARRANTY ON YAMAHA DRUMS, HARDWARE AND ACCESSORY PRODUCTS

Thank you for selecting a YAMAHA product. YAMAHA products are designed and manufactured to provide a high level of defect-free

performance. Yamaha Corporation of America (“YAMAHA”) is proud of the experience and craftsmanship that goes into each and every

YAMAHA product. YAMAHA sells its products through a network of reputable, specially authorized dealers and is pleased to offer you, the

Original Owner, the following Limited Warranty, which applies only to products that have been (1) directly purchased from YAMAHA’s

authorized dealers in the fifty states of the USA and District of Columbia (the “Warranted Area”) and (2) used exclusively in the Warranted

Area. YAMAHA suggests that you read the Limited Warranty thoroughly, and invites you to contact your authorized YAMAHA dealer or

YAMAHA Customer Service if you have any questions.

THIS WARRANTY COVERS THE LISTED PRODUCTS AGAINST DEFECTS IN MATERIALS OR WORKMANSHIP.

Warranty Term

Duration of Warranty from Date of

Type of Product Purchase by or for the Original Owner

Acoustic Drum Shells, Finish, Drum Hardware, Freestanding Hardware, Pedals, Hardware Accessories 5 Years

Electronic Drums Modules, Pads, Accessories, Hardware, Pedals 1 Year

Coverage: YAMAHA will, at its option, repair or replace the product covered by this warranty if it becomes defective, malfunctions or

otherwise fails to conform with this warranty under normal use and service during the term of this warranty, without charge for labor or

materials. Repairs may be performed using new or refurbished parts that meet or exceed YAMAHA specifications for new parts. If

YAMAHA elects to replace the product, the replacement may be a reconditioned unit. You will be responsible for any installation or

removal charges and for any initial shipping charges if the product(s) must be shipped for warranty service. However, YAMAHA will pay

the return shipping charges to any destination within the USA if the repairs are covered by the warranty. This warranty does not cover (a)

damage, deterioration or malfunction resulting from accident, negligence, misuse, abuse, improper installation or operation or failure to

follow instructions according to the Owner’s Manual for this product; any shipment of the product (claims must be presented to the

carrier); repair or attempted repair by anyone other than YAMAHA or an authorized YAMAHA Service Center; (b) any unit which has been

altered or on which the serial number has been defaced, modified or removed; (c) normal wear and any periodic maintenance; (d)

deterioration due to perspiration, corrosive atmosphere or other external causes such as extremes in temperature or humidity; (e)

damages attributable to power line surge or related electrical abnormalities, lightning damage or acts of God; or (f) RFI/EMI (Interference/

noise) caused by improper grounding or the improper use of either certified or uncertified equipment, if applicable. Any evidence of

alteration, erasing or forgery of proof-of-purchase documents will cause this warranty to be void. This warranty covers only the Original

Owner and is not transferable.

In Order to Obtain Warranty Service: Warranty service will only be provided for defective products within the Warranted Area. Contact

your local authorized YAMAHA dealer who will advise you of the procedures to be followed. If this is not successful, contact YAMAHA at

the address, telephone number or website shown below. YAMAHA may request that you send the defective product to a local authorized

YAMAHA Servicer or authorize return of the defective product to YAMAHA for repair. If you are uncertain as to whether a dealer has been

authorized by YAMAHA, please contact YAMAHA’s Service Department at the number shown below, or check Yamaha’s website at http://

usa.yamaha.com. Product(s) shipped for service should be packed securely and must be accompanied by a detailed explanation of the

problem(s) requiring service, together with the original or a machine reproduction of the bill of sale or other dated, proof-of-purchase

document describing the product, as evidence of warranty coverage. Should any product submitted for warranty service be found

ineligible therefore, an estimate of repair cost will be furnished and the repair will be accomplished only if requested by you and upon

receipt of payment or acceptable arrangement for payment.

Limitation of Implied Warranties and Exclusion of Damages: ANY IMPLIED WARRANTIES, INCLUDING WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE SHALL BE LIMITED IN DURATION TO THE APPLICABLE PERIOD OF

TIME SET FORTH ABOVE. YAMAHA SHALL NOT BE RESPONSIBLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OR FOR

DAMAGES BASED UPON INCONVENIENCE, LOSS OF USE, DAMAGE TO ANY OTHER EQUIPMENT OR OTHER ITEMS AT THE SITE OF

USE OR INTERRUPTION OF PERFORMANCES OR ANY CONSEQUENCES. YAMAHA’S LIABILITY FOR ANY DEFECTIVE PRODUCT IS

LIMITED TO REPAIR OR REPLACEMENT OF THE PRODUCT, AT YAMAHA’S OPTION. SOME STATES DO NOT ALLOW LIMITATIONS ON

HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO

THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. This Warranty gives you specific legal rights, and you may also have

other rights which vary from state to state. This is the only express warranty applicable to the product specified herein; Yamaha neither

assumes nor authorizes anyone to assume for it any other express warranty.

If you have any questions about service received or if you need assistance in locating an authorized YAMAHA Servicer, please contact:

CUSTOMER SERVICE

Yamaha Corporation of America

6600 Orangethorpe Avenue, Buena Park, California 90620-1373

Telephone: 800-854-1569 • http://usa.yamaha.com

Do not return any product to the above address without a written Return Authorization issued by YAMAHA.

For details of products, please contact your nearest Yamaha

representative or the authorized distributor listed below.

Die Einzelheiten zu Produkten sind bei Ihrer unten aufgeführten

Niederlassung und bei Yamaha Vertragshändlern in den jeweiligen

Bestimmungsländern erhältlich.

Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou

au distributeur le plus proche de vous figurant dans la liste suivante.

Para obter detalhes de produtos, entre em contato com o representante

mais próximo da Yamaha ou com o distribuidor autorizado relacionado a

seguir.

关于各产品的详细信息，请向就近的 Yamaha 代理商或下列经销商

询问。

CANADA

Yamaha Canada Music Ltd.

135 Milner Avenue, Toronto, Ontario M1S 3R1,

Canada

Tel: +1-416-298-1311

U.S.A.

Yamaha Corporation of America

6600 Orangethorpe Avenue, Buena Park, CA 90620,

U.S.A.

Tel: +1-714-522-9011

MEXICO

Yamaha de México, S.A. de C.V.

Av. Insurgentes Sur 1647 Piso 9, Col. San José

Insurgentes, Delegación Benito Juárez, México,

D.F., C.P. 03900, México

Tel: +52-55-5804-0600

BRAZIL

Yamaha Musical do Brasil Ltda.

Rua Fidêncio Ramos, 302 – Cj 52 e 54 – Torre B –

Vila Olímpia – CEP 04551-010 – São Paulo/SP,

Brazil

Tel: +55-11-3704-1377

ARGENTINA

Yamaha Music Latin America, S.A.,

Sucursal Argentina

Olga Cossettini 1553, Piso 4 Norte,

Madero Este-C1107CEK,

Buenos Aires, Argentina

Tel: +54-11-4119-7000

PANAMA AND OTHER LATIN

AMERICAN COUNTRIES/

CARIBBEAN COUNTRIES

Yamaha Music Latin America, S.A.

Edificio Torre Davivienda, Piso: 20

Avenida Balboa, Marbella, Corregimiento de Bella

Vista, Ciudad de Panamá, Rep. de Panamá

Tel: +507-269-5311

THE UNITED KINGDOM/IRELAND

Yamaha Music Europe GmbH (UK)

Sherbourne Drive, Tilbrook, Milton Keynes,

MK7 8BL, U.K.

Tel: +44-1908-366700

GERMANY

Yamaha Music Europe GmbH

Siemensstrasse 22-34, 25462 Rellingen, Germany

Tel: +49-4101-303-0

SWITZERLAND/LIECHTENSTEIN

Yamaha Music Europe GmbH, Branch

Switzerland in Thalwil

Seestrasse 18a, 8800 Thalwil, Switzerland

Tel: +41-44-3878080

AUSTRIA/CROATIA/

CZECH REPUBLIC

HUNGARY/ROMANIA/SLOVAKIA/

SLOVENIA

Yamaha Music Europe GmbH, Branch Austria

Schleiergasse 20, 1100 Wien, Austria

Tel: +43-1-60203900

POLAND

Yamaha Music Europe GmbH

Sp.z o.o. Oddział w Polsce

ul. Wielicka 52, 02-657 Warszawa, Poland

Tel: +48-22-880-08-88

BULGARIA

Dinacord Bulgaria LTD.

Bul.Iskarsko Schose 7 Targowski Zentar Ewropa

1528 Sofia, Bulgaria

Tel: +359-2-978-20-25

MALTA

Olimpus Music Ltd.

Valletta Road, Mosta MST9010, Malta

Tel: +356-2133-2093

NETHERLANDS/BELGIUM/

LUXEMBOURG

Yamaha Music Europe, Branch Benelux

Clarissenhof 5b, 4133 AB Vianen, The Netherlands

Tel: +31-347-358040

FRANCE

Yamaha Music Europe

7 rue Ambroise Croizat, Zone d'activités de Pariest,

77183 Croissy-Beaubourg, France

Tel: +33-1-6461-4000

ITALY

Yamaha Music Europe GmbH, Branch Italy

Via Tinelli N.67/69 20855 Gerno di Lesmo (MB),

Italy

Tel: +39-039-9065-1

SPAIN/PORTUGAL

Yamaha Music Europe GmbH Ibérica, Sucursal

en España

Ctra. de la Coruña km. 17,200, 28231

Las Rozas de Madrid, Spain

Tel: +34-91-639-88-88

GREECE

Philippos Nakas S.A. The Music House

19th klm. Leof. Lavriou 190 02 Peania – Attiki,

Greece

Tel: +30-210-6686260

SWEDEN

Yamaha Music Europe GmbH Germany filial

Scandinavia

JA Wettergrensgata 1, 400 43 Göteborg, Sweden

Tel: +46-31-89-34-00

DENMARK

Yamaha Music Denmark,

Fillial of Yamaha Music Europe GmbH, Tyskland

Generatorvej 8C, ST. TH., 2860 Søborg, Denmark

Tel: +45-44-92-49-00

FINLAND

F-Musiikki Oy

Antaksentie 4

FI-01510 Vantaa, Finland

Tel: +358 (0)96185111

NORWAY

Yamaha Music Europe GmbH Germany -

Norwegian Branch

Grini Næringspark 1, 1332 Østerås, Norway

Tel: +47-6716-7800

ICELAND

Hljodfaerahusid Ehf.

Sidumula 20

IS-108 Reykjavik, Iceland

Tel: +354-525-5050

CYPRUS

Nakas Music Cyprus Ltd.

Nikis Ave 2k

1086 Nicosia

Tel: + 357-22-511080

Major Music Center

21 Ali Riza Ave. Ortakoy

P.O.Box 475 Lefkoşa, Cyprus

Tel: (392) 227 9213

RUSSIA

Yamaha Music (Russia) LLC.

Room 37, entrance 7, bld. 7, Kievskaya street,

Moscow, 121059, Russia

Tel: +7-495-626-5005

OTHER EUROPEAN COUNTRIES

Yamaha Music Europe GmbH

Siemensstrasse 22-34, 25462 Rellingen, Germany

Tel: +49-4101-303-0

Yamaha Music Gulf FZE

JAFZA-16, Office 512, P.O.Box 17328,

Jebel Ali FZE, Dubai, UAE

Tel: +971-4-801-1500

TURKEY

Yamaha Music Europe GmbH

Merkezi Almanya Türkiye İstanbul Şubesi

Mor Sumbul Sokak Varyap Meridian Business

1.Blok No:1 113-114-115

Bati Atasehir Istanbul, Turkey

Tel: +90-216-275-7960

ISRAEL

RBX International Co., Ltd.

P.O Box 10245, Petach-Tikva, 49002

Tel: (972) 3-925-6900

OTHER COUNTRIES

Yamaha Music Gulf FZE

JAFZA-16, Office 512, P.O.Box 17328,

Jebel Ali FZE, Dubai, UAE

Tel: +971-4-801-1500

THE PEOPLE’S REPUBLIC OF CHINA

Yamaha Music & Electronics (China) Co., Ltd.

2F, Yunhedasha, 1818 Xinzha-lu, Jingan-qu,

Shanghai, China

Tel: +86-400-051-7700

HONG KONG

Tom Lee Music Co., Ltd.

11/F., Silvercord Tower 1, 30 Canton Road,

Tsimshatsui, Kowloon, Hong Kong

Tel: +852-2737-7688

INDIA

Yamaha Music India Private Limited

P-401, JMD Megapolis, Sector-48, Sohna Road,

Gurugram-122018, Haryana, India

Tel: +91-124-485-3300

INDONESIA

PT. Yamaha Musik Indonesia (Distributor)

Yamaha Music Center Bldg. Jalan Jend. Gatot

Subroto Kav. 4, Jakarta 12930, Indonesia

Tel: +62-21-520-2577

KOREA

Yamaha Music Korea Ltd.

11F, Prudential Tower, 298, Gangnam-daero,

Gangnam-gu, Seoul, 06253, Korea

Tel: +82-2-3467-3300

MALAYSIA

Yamaha Music (Malaysia) Sdn. Bhd.

No.8, Jalan Perbandaran, Kelana Jaya, 47301

Petaling Jaya, Selangor, Malaysia

Tel: +60-3-78030900

SINGAPORE

Yamaha Music (Asia) Private Limited

Block 202 Hougang Street 21, #02-00,

Singapore 530202, Singapore

Tel: +65-6740-9200

TAIWAN

Yamaha Music & Electronics Taiwan Co., Ltd.

2F., No.1, Yuandong Rd., Banqiao Dist.,

New Taipei City 22063, Taiwan (R.O.C.)

Tel: +886-2-7741-8888

THAILAND

Siam Music Yamaha Co., Ltd.

3, 4, 15, 16th Fl., Siam Motors Building,

891/1 Rama 1 Road, Wangmai,

Pathumwan, Bangkok 10330, Thailand

Tel: +66-2215-2622

VIETNAM

Yamaha Music Vietnam Company Limited

15th Floor, Nam A Bank Tower, 201-203 Cach

Mang Thang Tam St., Ward 4, Dist.3,

Ho Chi Minh City, Vietnam

Tel: +84-28-3818-1122

OTHER ASIAN COUNTRIES

https://asia-latinamerica-mea.yamaha.com/

index.html

AUSTRALIA

Yamaha Music Australia Pty. Ltd.

Level 1, 80 Market Street, South Melbourne,

VIC 3205 Australia

Tel: +61-3-9693-5111

NEW ZEALAND

Music Works LTD

P.O.BOX 6246 Wellesley, Auckland 4680,

New Zealand

Tel: +64-9-634-0099

COUNTRIES AND TRUST

TERRITORIES IN PACIFIC OCEAN

https://asia-latinamerica-mea.yamaha.com/

index.html

NORTH AMERICA

CENTRAL & SOUTH AMERICA

EUROPE

AFRICA

MIDDLE EAST

ASIA

OCEANIA

DMI27 Head Office/Manufacturer: Yamaha Corporation 10-1, Nakazawa-cho, Naka-ku, Hamamatsu, 430-8650, Japan

(For European Countries) Importer: Yamaha Music Europe GmbH Siemensstrasse 22-34, 25462 Rellingen, Germany

Manual Development Group

Published 04/2020

2020年4月发行

POMA*.*- **A0

VCR4450

雅马哈乐器音响（中国）投资有限公司

上海市静安区新闸路1818 号云和大厦2楼

客户服务热线：4000517700

公司网址：http://www.yamaha.com.cn

制造商：雅马哈株式会社

制造商地址：日本静冈县滨松市中区中泽町10-1

进口商：雅马哈乐器音响（中国）投资有限公司

进口商地址：上海市静安区新闸路1818号云和大厦2楼

原产地：印度尼西亚

Yamaha KP90 Owner’s Manual Owner's En Om A0

Navigation menu

Versions of this User Manual:

Views

Navigation
