EN
Thank you for purchasing this Yamaha Digital Workstation!
We recommend that you read this manual carefully so that you can fully take advantage of the advanced and
convenient functions of the instrument.
We also recommend that you keep this manual in a safe and handy place for future reference.
Before using the instrument, be sure to read “PRECAUTIONS” on pages 6-7.
Owner's Manual
DIGITAL WORKSTATION
2 PSR-S910/S710 Owner’s Manual
PLEASE KEEP THIS MANUAL
This product utilizes batteries or an external power supply
(adapter). DO NOT connect this product to any power supply or
adapter other than one described in the manual, on the name plate,
or specifically recommended by Yamaha.
WARNING: Do not place this product in a position where anyone
could walk on, trip over, or roll anything over power or connecting
cords of any kind. The use of an extension cord is not recom-
mended! If you must use an extension cord, the minimum wire size
for a 25’ cord (or less) is 18 AWG. NOTE: The smaller the AWG
number, the larger the current handling capacity. For longer exten-
sion cords, consult a local electrician.
This product should be used only with the components supplied or;
a cart, rack, or stand that is recommended by Yamaha. If a cart,
etc., is used, please observe all safety markings and instructions
that accompany the accessory product.
SPECIFICATIONS SUBJECT TO CHANGE:
The information contained in this manual is believed to be correct at
the time of printing. However, Yamaha reserves the right to change
or modify any of the specifications without notice or obligation to
update existing units.
This product, either alone or in combination with an amplifier and
headphones or speaker/s, may be capable of producing sound lev-
els that could cause permanent hearing loss. DO NOT operate for
long periods of time at a high volume level or at a level that is
uncomfortable. If you experience any hearing loss or ringing in the
ears, you should consult an audiologist.
IMPORTANT: The louder the sound, the shorter the time period
before damage occurs.
Some Yamaha products may have benches and / or accessory
mounting fixtures that are either supplied with the product or as
optional accessories. Some of these items are designed to be
dealer assembled or installed. Please make sure that benches are
stable and any optional fixtures (where applicable) are well secured
BEFORE using.
Benches supplied by Yamaha are designed for seating only. No
other uses are recommended.
NOTICE:
Service charges incurred due to a lack of knowledge relating to
how a function or effect works (when the unit is operating as
designed) are not covered by the manufacturer’s warranty, and are
therefore the owners responsibility. Please study this manual care-
fully and consult your dealer before requesting service.
ENVIRONMENTAL ISSUES:
Yamaha strives to produce products that are both user safe and
environmentally friendly. We sincerely believe that our products and
the production methods used to produce them, meet these goals.
In keeping with both the letter and the spirit of the law, we want you
to be aware of the following:
Battery Notice:
This product MAY contain a small non-rechargeable battery which
(if applicable) is soldered in place. The average life span of this type
of battery is approximately five years. When replacement becomes
necessary, contact a qualified service representative to perform the
replacement.
This product may also use “household” type batteries. Some of
these may be rechargeable. Make sure that the battery being
charged is a rechargeable type and that the charger is intended for
the battery being charged.
When installing batteries, do not mix batteries with new, or with bat-
teries of a different type. Batteries MUST be installed correctly. Mis-
matches or incorrect installation may result in overheating and
battery case rupture.
Warning:
Do not attempt to disassemble, or incinerate any battery. Keep all
batteries away from children. Dispose of used batteries promptly
and as regulated by the laws in your area. Note: Check with any
retailer of household type batteries in your area for battery disposal
information.
Disposal Notice:
Should this product become damaged beyond repair, or for some
reason its useful life is considered to be at an end, please observe
all local, state, and federal regulations that relate to the disposal of
products that contain lead, batteries, plastics, etc. If your dealer is
unable to assist you, please contact Yamaha directly.
NAME PLATE LOCATION:
The name plate is located on the bottom of the product. The model
number, serial number, power requirements, etc., are located on
this plate. You should record the model number, serial number, and
the date of purchase in the spaces provided below and retain this
manual as a permanent record of your purchase.
Model
Serial No.
Purchase Date
SPECIAL MESSAGE SECTION
92-BP (bottom)
PSR-S910/S710 Owner’s Manual 3
CANADA
This Class B digital apparatus complies with Canadian ICES-
003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
• This applies only to products distributed by Yamaha Canada Music Ltd. (class B)
• Ceci ne s’applique qu’aux produits distribués par Yamaha Canada Musique Ltée.
OBSERVERA!
Apparaten kopplas inte ur växelströmskällan (nätet) så länge
som den ar ansluten till vägguttaget, även om själva appa-
raten har stängts av.
ADVARSEL: Netspændingen til dette apparat er IKKE
afbrudt, sålæenge netledningen siddr i en stikkontakt, som er t
endt — også selvom der or slukket på apparatets afbryder.
VAROITUS: Laitteen toisiopiiriin kytketty käyttökytkin ei irroita
koko laitetta verkosta.
(standby)
Information for Users on Collection and Disposal of Old Equipment
This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic
products should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products, please take them to applicable collection points, in
accordance with your national legislation and the Directives 2002/96/EC.
By disposing of these products correctly, you will help to save valuable resources and prevent any potential negative
effects on human health and the environment which could otherwise arise from inappropriate waste handling.
For more information about collection and recycling of old products, please contact your local municipality, your waste
disposal service or the point of sale where you purchased the items.
[For business users in the European Union]
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
[Information on Disposal in other Countries outside the European Union]
This symbol is only valid in the European Union. If you wish to discard these items, please contact your local
authorities or dealer and ask for the correct method of disposal.
(weee_eu)
4 PSR-S910/S710 Owner’s Manual
Welcome to Digital Workstation
Explore the Demos Starting Up
The Demos showcase the variety of stunning Voices and Styles on the
instrument, and give you hands-on experience using it.
Play a Wide Variety of Instrument Voices Chapter 1 Voices
The instrument gives you not only
various realistic piano Voices, but also
features an exceptionally wide variety
of authentic instruments, both acoustic
and electronic.
Perform Along with a Backing Band
Chapter 2 Styles
Playing a chord with your left hand automatically
plays the auto accompaniment backing (Style
function). Select an accompaniment style —
such as pop, jazz, Latin, and various other music
genres in the world — and let the instrument be
your backing band!
Play Along with Song Data Chapter 3 Songs
Displaying Music Score ................page 52
While playing back a Song, you can have the music score (notation)
automatically shown on the display — an exceptionally convenient tool for
learning and practicing pieces.
Recording Your Performance ................page 56
The instrument lets you easily record your own performance and save it to
internal memory or a USB flash memory. The instrument also lets you
listen back to your performance, and further edit it or utilize it for your
music production.
Playing Back Songs ................page 49
Play along with a Song data, and fill out your solo performance with the sounds of an entire band or orchestra.
Enjoy a wide variety of songs — commercially available music data or preset songs.
PSR-S910/S710 Owner’s Manual 5
Add Phrases and Rhythms to Your Performance
Chapter 4 Multi Pads
The instrument can add spice to your performance
with short phrases and rhythms.
Call Up the Ideal Voice and Style for Each Song
Chapter 5 Music Finder
By using the convenient Music Finder function, you can call up the ideal panel settings including the most
suitable Voice, Style, effects, etc. for each song. By registering the Song/audio data saved in various places into
Music Finder, the instrument can call up song data easily from the song title. Moreover, the Music Finder Plus
function gives you the capability, by connecting the instrument to the Internet, of searching for and adding
desired panel settings and song data via the Internet to the instrument.
Audio Playing and Recording from USB Flash Memory
Chapter 7 USB Audio
Audio files (WAV or MP3*) stored to USB flash memory can be
played back on the instrument.
Moreover, you can record your performance as audio data to a USB
flash memory device.
On the PSR-S910, connect a microphone to the instrument and
enjoy recording your singing along with the keyboard performance.
* The MP3 format is supported only by the PSR-S910.
Connect Directly to the Internet Chapter 9 Internet Direct Connection
The instrument also connects directly to the Internet, letting you
download Song and Style data from special websites, and save
them to internal memory or a USB storage device.
Add vocal backing to your singing (PSR-S910)
The amazing Vocal Harmony feature automatically produces backup
vocal harmonies for lead vocals that you sing into a microphone. You
can even change the gender of the harmony voices — for example,
letting you add female backup to your own male voice (or vice versa).
Chapter 10 Connections
(Connecting a Microphone or Guitar)
6 PSR-S910/S710 Owner’s Manual
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
* Please keep this manual in a safe place for future reference.
WARNING
Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical
shock, short-circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following:
• Only use the voltage specified as correct for the instrument. The required
voltage is printed on the name plate of the instrument.
•Use the specified adaptor (page 105) only. Using the wrong adaptor can result
in damage to the instrument or overheating.
•Check the electric plug periodically and remove any dirt or dust which may have
accumulated on it.
• Do not place the AC adaptor cord near heat sources such as heaters or
radiators, and do not excessively bend or otherwise damage the cord, place
heavy objects on it, or place it in a position where anyone could walk on, trip
over, or roll anything over it.
•Do not open the instrument or attempt to disassemble the internal parts or
modify them in any way. The instrument contains no user-serviceable parts. If it
should appear to be malfunctioning, discontinue use immediately and have it
inspected by qualified Yamaha service personnel.
• Do not expose the instrument to rain, use it near water or in damp or wet
conditions, or place containers on it containing liquids which might spill into
any openings. If any liquid such as water seeps into the instrument, turn off the
power immediately and unplug the power cord from the AC outlet. Then have
the instrument inspected by qualified Yamaha service personnel.
• Never insert or remove an electric plug with wet hands.
• Do not put burning items, such as candles, on the unit.
A burning item may fall over and cause a fire.
•If the AC adaptor cord or plug becomes frayed or damaged, or if there is a
sudden loss of sound during use of the instrument, or if any unusual smells or
smoke should appear to be caused by it, immediately turn off the power switch,
disconnect the adaptor plug from the outlet, and have the instrument inspected
by qualified Yamaha service personnel.
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage
to the instrument or other property. These precautions include, but are not limited to, the following:
•When removing the electric plug from the instrument or an outlet, always hold
the plug itself and not the cord.
• Unplug the AC power adaptor when not using the instrument, or during
electrical storms.
•Do not connect the instrument to an electrical outlet using a multiple-connector.
Doing so can result in lower sound quality, or possibly cause overheating in the
outlet.
• Do not expose the instrument to excessive dust or vibrations, or extreme cold
or heat (such as in direct sunlight, near a heater, or in a car during the day) to
prevent the possibility of panel disfiguration or damage to the internal
components.
• Do not use the instrument in the vicinity of a TV, radio, stereo equipment,
mobile phone, or other electric devices. Otherwise, the instrument, TV, or radio
may generate noise.
•Do not place the instrument in an unstable position where it might accidentally
fall over.
• Before moving the instrument, remove all connected adaptor and other cables.
•When setting up the product, make sure that the AC outlet you are using is
easily accessible. If some trouble or malfunction occurs, immediately turn off
the power switch and disconnect the plug from the outlet. Even when the power
switch is turned off, electricity is still flowing to the product at the minimum
level. When you are not using the product for a long time, make sure to unplug
the power cord from the wall AC outlet.
•Use only the stand specified for the instrument. When attaching the stand or
rack, use the provided screws only. Failure to do so could cause damage to the
internal components or result in the instrument falling over.
•Do not place objects in front of the instrument’s air vent, since this may prevent
adequate ventilation of the internal components, and possibly result in the
instrument overheating.
Power supply/AC power adaptor
Do not open
Water warning
Fire warning
If you notice any abnormality
Power supply/AC power adaptor
Location
(3)-13 1/2
PSR-S910/S710 Owner’s Manual 7
• Before connecting the instrument to other electronic components, turn off the
power for all components. Before turning the power on or off for all
components, set all volume levels to minimum. Also, be sure to set the volumes
of all components at their minimum levels and gradually raise the volume
controls while playing the instrument to set the desired listening level.
•When cleaning the instrument, use a soft, dry cloth. Do not use paint thinners,
solvents, cleaning fluids, or chemical-impregnated wiping cloths.
• Do not insert a finger or hand in any gaps on the instrument.
•Never insert or drop paper, metallic, or other objects into the gaps on the panel
or keyboard. If this happens, turn off the power immediately and unplug the
power cord from the AC outlet. Then have the instrument inspected by
qualified Yamaha service personnel.
•Do not place vinyl, plastic or rubber objects on the instrument, since this might
discolor the panel or keyboard.
• Do not rest your weight on, or place heavy objects on the instrument, and do
not use excessive force on the buttons, switches or connectors.
•Do not use the instrument/device or headphones for a long period of time at a
high or uncomfortable volume level, since this can cause permanent hearing
loss. If you experience any hearing loss or ringing in the ears, consult a
physician.
Saving and backing up your data
• Edited Songs/Styles/Voices/Multi Pads and MIDI settings are lost when you
turn off the power to the instrument. Save the data to the USER tab display
(page 58), USB storage device (USB flash memory, etc.).
• Data in the USER tab display may be lost due to malfunction or incorrect
operation. Save important data to a USB storage device.
When you change settings in a display page and then exit from that
page, Data other than above (edited Songs/Styles/Voices/Multi Pads
and MIDI settings, etc.) is automatically stored. However, this edited
data is lost if you turn off the power without properly exiting from the
relevant display.
Backing up the USB storage device
•To protect against data loss through media damage, we recommend that you
save your important data onto two USB storage devices.
Always turn the power off when the instrument is not in use.
Even when the power switch is in the “STANDBY” position, electricity is still flowing to the instrument at the minimum level. When you are not using the instrument for a
long time, make sure you unplug the AC power adaptor from the wall AC outlet.
Connections
Maintenance
Handling caution
Saving data
Yamaha cannot be held responsible for damage caused by improper use or modifications to the instrument, or data that is lost or destroyed.
(3)-13 2/2
8 PSR-S910/S710 Owner’s Manual
Notices and Information
Notices and Information
Copyright Notices
• Copying of the commercially available musical data including but not limited to MIDI data and/or audio data is strictly
prohibited except for your personal use.
• This product incorporates and bundles computer programs and contents in which Yamaha owns copyrights or with
respect to which it has license to use others’ copyrights. Such copyrighted materials include, without limitation, all com-
puter software, style files, MIDI files, WAVE data, musical scores and sound recordings. Any unauthorized use of such
programs and contents outside of personal use is not permitted under relevant laws.
Any violation of copyright has legal consequences.
DON’T MAKE, DISTRIBUTE OR USE ILLEGAL COPIES.
Information about functions/data bundled in the instrument
• Some of the preset songs have been edited for length or arrangement, and may not be exactly the same as the original.
• This device is capable of using various types/formats of music data by optimizing them to the proper format music data
for use with the device in advance. As a result, this device may not play them back precisely as their producers or com-
posers originally intended.
• The bitmap fonts used in this instrument have been provided by and are the property of Ricoh Co., Ltd.
• This product utilizes NF, an embedded Internet browser from ACCESS Co., Ltd. NF may not be separated from this
product, nor may it be sold, lent or transferred in any way. Also, NF may not be
reverse-engineered, reverse-compiled, reverse-assembled or copied.
• This software includes a module developed by the Independent JPEG Group.
• The harp, shown in the displays of the PSR-S910/S710, is on display at the Hamamatsu Museum of Musical Instruments.
• (PSR-S910) MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
The followings are the titles, credits and copyright notices for two (2) of the songs pre-installed in this instrument:
Beauty And The Beast
from Walt Disney’s BEAUTY AND THE BEAST
Lyrics by Howard Ashman
Music by Alan Menken
©1991 Walt Disney Music Company and Wonderland Music Company, Inc.
All Rights Reserved Used by Permission
Can’t Help Falling In Love
from the Paramount Picture BLUE HAWAII
Words and Music by George David Weiss, Hugo Peretti and Luigi Creatore
Copyright ©1961; Renewed 1989 Gladys Music (ASCAP)
Worldwide Rights for Gladys Music Administered by Cherry Lane Music Publishing Company, Inc.
International Copyright Secured All Rights Reserved
PSR-S910/S710 Owner’s Manual 9
Included Accessories
Included Accessories
• Music Rest
• AC Power Adaptor*
• Accessory CD-ROM for Windows
• Owner’s Manual
• Accessory CD-ROM for Windows Installation Guide
• Guide to Yamaha Online Member Product User Registration
* May not be included depending on your particular area. Please check with your Yamaha dealer.
The instrument is compatible with the following formats.
“GM (General MIDI)” is one of the most common Voice allocation formats. “GM System Level 2” is a standard
specification that enhances the original “GM” and improves Song data compatibility. It provides for increased
polyphony, greater Voice selection, expanded Voice parameters, and integrated effect processing.
XG is a major enhancement of the GM System Level 1 format, and was developed by Yamaha specifically to pro-
vide more Voices and variations, as well as greater expressive control over Voices and effects, and to ensure compat-
ibility of data well into the future.
GS was developed by the Roland Corporation. In the same way as Yamaha XG, GS is a major enhancement of the
GM specifically to provide more Voices and Drum kits and their variations, as well as greater expressive control
over Voices and effects.
The Yamaha XF format enhances the SMF (Standard MIDI File) standard with greater functionality and open-
ended expandability for the future. This instrument is capable of displaying lyrics when an XF file containing lyric
data is played.
“SFF (Style File Format)” is an original Style file format by Yamaha which uses a unique conversion system to pro-
vide high-quality automatic accompaniment based on a wide range of chord types. “SFF GE (Guitar Edition)” is an
enhanced format of SFF, which features improved note transposition for guitar tracks.
(PSR-S910)
VH (Vocal Harmony) employs the digital signal processing technology to automatically add appropriate vocal har-
monies to a lead vocal line sung by the user.
10 PSR-S910/S710 Owner’s Manual
About the Manuals
About the Manuals
This instrument has the following documents and instructional
Included Documents
Owner’s Manual (this book)
Provides overall explanations of the PSR-S910/S710 basic functions. See “How to use this Owner’s Manual” below.
Installation Guide
Provides introduction to the contents of the supplied CD-ROM and explains how to install the included software.
Online Materials (Downloadable from the web)
The following instructional materials are available for downloading from the Yamaha Manual Library. Access the Yamaha
Manual Library, then enter your model name (PSR-S910, for example) in the Model Name area to search the manuals.
Reference Manual (only in English, French, German and Spanish)
Explains advanced features of the instrument, not explained in the Owner’s Manual. For example, you can learn how
to create original Styles, Songs or Multi Pads, or find detailed explanations of specific parameters.
Internet Connection Guide (only in English, French, German and Spanish)
Explains how to connect the instrument to the Internet in detail, in order to use the Internet Direct Connection
function.
Data List
Contains various important preset content lists such as Voices, Styles, Effects, as well as MIDI-related information.
MIDI Basics (only in English, French, German and Spanish)
If you want to know more about MIDI and how to use it, refer to this introductory book.
• The illustrations and LCD screens as shown in this manual are for instructional purposes only, and may appear
somewhat different from those on your instrument.
• The example Operation Guide displays shown in this Manual are taken from the PSR-S910, and in English.
• The company names and product names in this manual are the trademarks or registered trademarks of their respec-
tive companies.
Yamaha Manual Library http://www.yamaha.co.jp/manual/
Provides an overview of
the chapter contents.
Shows the location of
buttons which are
explained in the chap-
ter.
The displays are taken
from the PSR-S910,
and in English. (These
may appear somewhat
different from those on
your instrument.)
Provides additional
helpful information in
the frame.
Shows that this function
is only available on one
model.
Ex.: These icons indicate
that this function is only
on the PSR-S910 but not
on the PSR-S710.
Provides supplemen-
tary notes and
detailed information.
Introduces advanced features related
to the chapter contents.
Detailed explanations are provided in
the Reference Manual (above).
Chapter title for navigat-
ing through the manual.
How to use this Owner’s Manual
PSR-S910/S710 Owner’s Manual 11
Contents
Contents
Welcome to Digital Workstation 4
Notices and Information ..................................................... 8
Included Accessories ......................................................... 9
About the Manuals ........................................................... 10
Panel Controls 12
Starting Up 14
Powering Up .................................................................... 14
Attaching the Music Rest ................................................. 15
Using Headphones .......................................................... 16
Changing the Display Language...................................... 16
Adjusting the Contrast of the Display ............... 17
Entering the Owner Name in the Opening Display .......... 17
Playing the Demos........................................................... 18
Display-based Controls.................................................... 19
The Messages Shown in the Display............................... 22
Instant Selection of the Displays — Direct Access .......... 22
Main Display Configuration .............................................. 23
File Selection Display Configuration ................................ 25
Entering Characters ......................................................... 26
Restoring the Factory-programmed Settings ................... 27
Data Backup .................................................................... 28
1 Voices
– Playing the keyboard – 29
Playing Preset Voices ...................................................... 29
Transposing the Pitch of the Keyboard............................ 34
Using the Wheels............................................................. 34
Applying Voice Effects ..................................................... 35
Creating Your Original Organ Flutes Voices.................... 37
2 Styles
– Playing Rhythm and Accompaniment – 39
Playing a Style with the Auto Accompaniment................. 39
Operating Style Playback................................................. 42
Calling up the Panel Settings to Match the Style
(Repertoire)...................................................................... 44
Appropriate Panel Settings for the Selected Style
(One Touch Setting)......................................................... 45
Turning Style Parts On/Off and Changing Voices............ 47
Adjusting the Volume Balance Between the Style and
Keyboard.......................................................................... 48
3 Songs
– Playing, Practice and Recording Songs – 49
Playback of Songs ........................................................... 49
Displaying Music Notation (Score)................................... 52
Displaying Lyrics (Text).................................................... 53
Turning Song Channels On/Off........................................ 54
Practicing the Right-hand Part (Guide Function) ............. 54
Repeat Playback.............................................................. 55
Recording Your Performance (Quick Recording) ............ 56
Saving Files ..................................................................... 58
File Management ............................................................. 59
4 Multi Pads
– Adding Musical Phrases to Your Performance –
63
Playing the Multi Pads ..................................................... 63
Using the Multi Pad Synchro Start Function .................... 64
Using Chord Match .......................................................... 64
5 Music Finder
– Calling Up Ideal Setups (Voice, Style, etc.) for Each Song –
65
Selecting the Desired Song from among the Panel Settings
... 67
Searching the Panel Settings........................................... 67
Registering the Song/Audio data (SONG/AUDIO)........... 68
6 Registration Memory
– Saving and Recalling Custom Panel Setups –71
Registering Your Panel Setups........................................ 71
Saving the Registration Memory as a Bank file ............... 72
Confirming the Registration Memory Information ............ 74
7 USB Audio
– Playback and Recording Audio Files – 75
Playing Back Audio Files ................................................. 75
Recording Your Performance as Audio ........................... 77
8 Mixing Console
– Editing the Volume and Tonal Balance – 79
Basic Procedure............................................................... 79
Changing Voices and Adjusting Panning/Volume for Each Part
... 81
Applying Effects to Each Part .......................................... 83
9 Internet Direct Connection
– Connecting the PSR-S910/S710 Directly to the Internet –
84
Entering the Internet Direct Connection Function ............ 84
Connecting the Instrument to the Internet........................ 84
Operations in the Special Website................................... 86
10 Connections
– Using Your Instrument with Other Devices – 88
Connecting Audio Devices............................................... 88
Connecting a Separate TV Monitor ................. 89
Connecting a Microphone or Guitar ................. 90
Connecting a Footswitch/Foot Controller......................... 93
Connecting a USB Storage Device.................................. 94
Connecting to the Internet................................................ 95
Connecting to a Computer ............................................... 96
Connecting External MIDI Devices .................................. 97
11 Utility
– Making Global Settings – 98
Basic Procedure............................................................... 98
Troubleshooting 99
Panel Button Chart 102
Specifications 104
Index 106
12 PSR-S910/S710 Owner’s Manual
Panel Controls
Panel Controls
1[MASTER VOLUME] control............................Page 15
Adjusts the overall volume.
2[STANDBY/ON] switch ....................................Page 14
Turns the instrument’s power on ( ) or off ( ).
3[DEMO] button .................................................Page 18
Plays the Demos.
4[MIC SETTING/VOCAL HARMONY] button
(PSR-S910) .......................................................Page 91
Adds some effects to Microphone input.
5[PITCH BEND] wheel .......................................Page 34
Bends the pitch of the keyboard played sound up or down.
6[MODULATION] wheel .....................................Page 35
Applies a vibrato effect.
7[PHONES] jack.................................................Page 16
For connecting a pair of headphones.
8SONG buttons..................................................Page 49
These select a Song and control Song playback.
9STYLE category selection buttons ................Page 39
These select a Style.
)[FADE IN/OUT] button .................................... Page 44
Controls fade in/out of the Style/Song playback.
!STYLE CONTROL buttons ............................. Page 42
These control Style playback.
@TRANSPOSE buttons ..................................... Page 34
These transpose the pitch in semitone steps.
#[METRONOME] button ................................... Page 56
Turns the metronome sound on or off.
$[TAP TEMPO]/TEMPO buttons....................... Page 43
These control the tempo for Style, Song and Metronome play-
back.
%[LCD CONTRAST] knob (PSR-S710) ............... Page 17
Adjusts the LCD contrast.
^LCD and related controls............................... Page 19
&[BALANCE] button.......................................... Page 48
Adjusts the volume balance among each part.
*[MIXING CONSOLE] button ........................... Page 79
Controls over aspects of keyboard, Style and Song parts.
1
23
4
56
7
89
@
^
º
£
¡
™
&
*
(
#
$
)!
%
(PSR-S710)
PSR-S910/S710 Owner’s Manual 13
Panel Controls
([CHANNEL ON/OFF] button ................... Pages 47, 54
Turns channels of Style/Song on or off.
º[FUNCTION] button
(See Reference Manual on website.)
Lets you make some advanced settings and create your origi-
nal Styles, Songs and Multi Pads.
¡[USB] button............................................ Pages 25, 75
Loads certain data to the USB storage device and allows you to
record your performance to the USB storage device in audio
format.
™[INTERNET] button ......................................... Page 84
Accesses to Internet website.
£REGISTRATION MEMORY buttons................ Page 71
These register and recall panel setups.
¢MULTI PAD CONTROL buttons ...................... Page 63
These select and play a rhythmic or melodic Multi Pad phrase.
∞[MUSIC FINDER] button ................................. Page 65
Searches the appropriate panel settings or desired song.
§PART SELECT buttons ................................... Page 32
These select a keyboard part.
PART ON/OFF buttons.................................... Page 32
These turn the keyboard part on or off.
•VOICE category selection buttons ................ Page 29
These select a Voice.
ªONE TOUCH SETTING buttons ...................... Page 45
These call up the appropriate panel settings for the Style.
‚VOICE CONTROL buttons .............................. Page 35
These apply some effects to the keyboard performance.
⁄UPPER OCTAVE buttons ................................ Page 34
These shift the pitch of the keyboard in octave steps.
¤[DC IN] terminal............................................... Page 14
For connecting the supplied power adaptor.
For information on the jacks and connectors located on the
rear panel, see pages 88 – 97.
•
¢ ª ‚ ⁄
∞§
¤
Indicates drum instruments assigned to each key when
the Standard Kit is selected.
14 PSR-S910/S710 Owner’s Manual
Starting Up
Starting Up
1Make sure that the instrument’s [STANDBY/ON] switch is set to
STANDBY (off).
2Connect one end of the AC cable to the power adaptor.
3Connect the power adaptor’s DC plug to the instrument’s [DC
IN] terminal on the rear panel.
4Connect the other end (normal AC plug) to the nearest electrical
outlet.
Before you switch the instrument on or off, first turn down the volume of any
connected audio equipment.
1Press the [STANDBY/ON] switch.
The main display appears in the display.
Powering Up
Power supply
WARNING
Use the specified adaptor
(page 105) only.
The use of an incompatible
adaptor may cause irreparable
damage to the PSR-S910/S710,
and may even pose a serious
shock hazard! ALWAYS UNPLUG
THE AC ADAPTOR FROM THE AC
POWER OUTLET WHEN THE
PSR-S910/S710 IS NOT IN USE.
CAUTION
Never interrupt the power sup-
ply (e.g. unplug the AC adaptor)
during any PSR-S910/S710
record operation! Doing so can
result in a loss of data.
CAUTION
Even when the switch is in the
“STANDBY” position, electric-
ity is still flowing to the instru-
ment at a minimum level. When
not using the instrument for an
extended period of time, be
sure to unplug the AC power
adaptor from the wall AC outlet.
CAUTION
In order to avoid possible dam-
age to the speakers or other
connected electronic equip-
ment, always switch on the
power of the PSR-S910/S710
before switching on the power
of the amplified speakers or
mixer and amplifier. Likewise,
always switch off the power of
the PSR-S910/S710 after
switching off the power of the
amplified speakers or mixer and
amplifier.
NOTE
Remove the transparent protective
film that was applied to the display
prior to shipment from the factory.
Turning the Power On
1
PSR-S910/S710 Owner’s Manual 15
Starting Up
2Setting the volume.
Use the [MASTER VOLUME] dial to adjust the volume to an appropriate level.
The PSR-S910/S710 is supplied with a music rest that can be attached to the
instrument by inserting it into the slot at the rear of the control panel.
Air Vents
This instrument has special air vents in the top panel (see below) and rear panel. Do not place
objects where they might block the air vent, since this may prevent adequate ventilation of the
internal components, and possibly result in the instrument overheating.
CAUTION
Air Vents
Air Vents
Attaching the Music Rest
16 PSR-S910/S710 Owner’s Manual
Starting Up
Connect a pair of headphones to the [PHONES] jack. The internal stereo speaker
system is automatically shut off when a pair of headphones is plugged into the
[PHONES] jack.
This determines the language used in the display for messages, file names, and
character input.
1Call up the operation display.
[FUNCTION] → [J] UTILITY → TAB [E][F] OWNER
2Use the [4 ▲▼]/[5 ▲▼] buttons to select the desired language.
Using Headphones
CAUTION
Do not listen with the head-
phones at high volume for long
periods of time. Doing so may
cause hearing loss.
Changing the Display Language
Standard phone plug
NOTE
Throughout this manual, arrows are
used in the instructions, indicating in
shorthand the process of calling up
certain displays and functions.
2
1
PSR-S910/S710 Owner’s Manual 17
Starting Up
You can adjust the contrast of the display by turning the [LCD CONTRAST] knob
located to the left of the display.
You can have your name appear in the opening display (the display that appears
when the power is turned on).
1Call up the operation display.
[FUNCTION] → [J] UTILITY → TAB [E][F] OWNER
2Press the [I] (OWNER NAME) button to call up the Owner Name
display.
Refer to page 26 for character-entry details.
Adjusting the Contrast of the Display
NOTE
Since the color display of the PSR-
S910 has a high level of visibility, no
contrast adjustment function is nec-
essary.
Entering the Owner Name in the Opening Display
NOTE
(PSR-S910) If desired, you can also
change the background picture in the
Main display by pressing the [J]
(MAIN PICTURE) button in step 2
here.
Display the version number
To check the version number of this instrument, press the [7 ▲▼]/[8 ▲▼]
(VERSION) buttons in the display in step 2 above. Press the [EXIT] button
or [8 ▲▼] button to return to the original display.
2
18 PSR-S910/S710 Owner’s Manual
Starting Up
The Demos provide helpful, easy-to-understand introductions to the features and
functions as well as sound demonstrations.
1Press the [DEMO] button to start the Demos.
Overview Demo will play back continuously, calling up the various displays in
sequence.
2Press the [7 ▲▼]/[8 ▲▼] (SKIP OVERVIEW) buttons in the Demo
display to call up the specific Demo menu.
3Press one of the [A] – [E] buttons to show a specific Demo.
Pressing the [J] button returns to the display of step 2.
The sub menus are shown at the bottom of the display. Press one of the [1 ▲▼]
– [8 ▲▼] buttons corresponding to the sub menu.
4Press the [EXIT] button several times to exit from the Demos.
Playing the Demos
NOTE
The demo menu differs depending on
your instrument.
2
3
NOTE
To return to the higher level menu,
press the [EXIT] button.
PSR-S910/S710 Owner’s Manual 19
Starting Up
The LCD provides comprehensive at-a-glance information on all current settings.
The displayed menu can be selected or changed by the controls around the LCD.
The [A] – [J] buttons are used to select the corresponding menu.
• Example 1
• Example 2
Display-based Controls
[A] – [J] buttons
[A] – [E]
buttons
(see below)
[F] – [J]
buttons
(see below)
TAB [E][F]
buttons
(page 20)
[DIRECT
ACCESS]
button
(page 22) [DATA ENTRY] dial
and
[ENTER] button
(page 21)
[1 ▲▼] – [8 ▲▼] buttons
(page 20)
[EXIT]
button
(page 22)
In the File Selection display
(page 25), the [A] – [J] buttons
can be used to select the corre-
sponding respective files.
The [A] and [B] buttons are used
to move the cursor up or down.
The [H] and [I] buttons are used to
select the corresponding parameter.
20 PSR-S910/S710 Owner’s Manual
Starting Up
These buttons are used mainly to change the Pages of displays that have “tabs” at the
top.
The [1 ▲▼] – [8 ▲▼] buttons are used to make selections or adjust settings (up or
down correspondingly) for functions shown directly above them.
TAB [E][F] buttons
[1 ▲▼] – [8 ▲▼] buttons
If a menu appears in this section of the
display, use the [1 ▲] – [8 ▲] buttons.
If a menu appears in this section of the
display, use the [1 ▼] – [8 ▼] buttons.
If list of the menu appears, use the [1 ▲▼]
– [8 ▲▼] button to select the desired item.
If a parameter appears in slider (or knob)
form, use the [1 ▲▼] – [8 ▲▼] button to
adjust the value.
PSR-S910/S710 Owner’s Manual 21
Starting Up
Depending on the selected LCD display, the [DATA ENTRY] dial can be used in the
following two ways.
• Selecting files (Voice, Style, Song, and so on)
When one of the File Selection displays (page 25) is shown, you can use the [DATA
ENTRY] dial and the [ENTER] button to select a file (Voice, Style, Song, and so on).
• Adjusting the parameter values
You can conveniently use the [DATA ENTRY] dial in tandem with the [1 ▲▼] –
[8 ▲▼] buttons to adjust parameters indicated in the display.
This convenient technique also works well with pop-up parameters such as Tempo
and Transpose. Simply press the appropriate button (ex., TEMPO [+]), then rotate
the [DATA ENTRY] dial and press [ENTER] to close the window.
[DATA ENTRY] dial and [ENTER] button
Rotate the [DATA ENTRY] dial
to move the cursor.
Press the [ENTER] button to
actually select the highlighted
file.
Rotate the [DATA ENTRY] dial to
adjust the selected parameter.
Select the desired parameter with the appropriate
[1 ▲▼] – [8 ▲▼] button.
22 PSR-S910/S710 Owner’s Manual
Starting Up
A message (information or confirmation dialog) sometimes appears on the screen to
facilitate operation. When the message appears, simply press the appropriate button.
With the convenient Direct Access function, you can instantly call up the desired
display — with just a single additional button press.
1Press the [DIRECT ACCESS] button.
A message appears in the display prompting you to press the appropriate button.
2Press the button (or move the wheel or connected pedal)
corresponding to the desired setting display to instantly call up
that display.
For example, pressing the [GUIDE] button calls up the display in which the
Guide mode can be set.
Refer to the Data List for a list of the displays that can be called up with the
Direct Access function. The Data List is available at the Yamaha website. (See
page 10.)
[EXIT] button
The Messages Shown in the Display
Instant Selection of the Displays — Direct Access
Pressing the [EXIT] button returns you to the previously indicated
display.
Pressing the [EXIT] button several times returns to the default
Main display (page 23).
PSR-S910/S710 Owner’s Manual 23
Starting Up
The display that appears when the power is turned on is the Main display. The Main
display shows the current basic settings such as the currently selected Voice and
Style, allowing you to see them at a single glance. The Main display is the one you’ll
usually see when you play the keyboard.
1Song name and related information
Displays the currently selected Song name, time signature and tempo. Pressing
the [A] button calls up the Song Selection display (page 49).
2BAR/BEAT/TEMPO
Displays the current position (bar/beat/tempo) in Style playback or Song
playback.
3Current chord name
When the [ACMP] button is set to on, the chord specified in the chord section of
the keyboard will be displayed. When the Song containing the chord data is
played, the current chord name will be displayed.
4Transpose
Displays the amount of transposition in semitone units (page 34).
5Upper Octave
Displays the amount that the octave value is shifted (page 34).
6Style name and related information
Displays the currently selected Style name, time signature and tempo. Pressing
the [E] button calls up the Style Selection display (page 39).
7Voice name
Displays the Voice names currently selected for RIGHT 1, RIGHT 2 and LEFT
parts (page 32). Pressing one of the [F] – [H] buttons calls up the Voice
Selection display for each part.
8Multi Pad Bank name
Displays the names of the selected Multi Pad Bank. Pressing the [I] button calls
up the Multi Pad Bank Selection display (page 63).
Main Display Configuration
NOTE
Here’s a convenient way to return to
the Main display from any other dis-
play: Simply press the [DIRECT
ACCESS] button, then the [EXIT] but-
ton.
1
!#
7
9
8
)
2
3
4
6
5
@
24 PSR-S910/S710 Owner’s Manual
Starting Up
9Registration Memory Bank name
Displays the currently selected Registration Memory Bank name and
Registration Memory number. Pressing the [J] button calls up the Registration
Memory Bank Selection display (page 72).
)Volume Balance
Displays the volume balance among the parts.
Adjust the volume balance among the parts by using the [1 ▲▼] – [7 ▲▼]
buttons.
!USB Audio information
Displays information for the selected audio file (file name, time, etc.) While
recording, a “REC” indication appears.
@Registration Sequence
Appears when the Registration Sequence (page 74) is active.
#Split Point
Displays the Split Point positions (page 32).
NOTE
If the Volume Balance display is not
shown, press the [EXIT] button to
show the Volume Balance display.
NOTE
For detailed information about the
Registration Sequence, refer to the
Reference manual on the website.
PSR-S910/S710 Owner’s Manual 25
Starting Up
The File Selection display is for selecting Voice, Styles, and other data. The File
Selection display appears when you press one of the VOICE or STYLE category
selection buttons, SONG [SELECT] button, etc.
1Location (drive) of data
PRESET Location where pre-programmed (preset) data is stored.
USER Location where recorded or edited data is saved.
USB Location where data on USB storage device (USB flash memory,
floppy disk, etc.) is saved.This appears only when USB storage
device(s) is connected to the [USB TO DEVICE] terminal (page 94).
2Selectable data (files)
The files that can be selected on this display are shown. If more than 10 files
exist, the page numbers (P1, P2 ...) are shown below the files. Pressing the
corresponding button changes the display page. When other pages follow, the
“Next” button appears, and for the previous page, the “Prev.” button appears.
3File/folder operation menu
You can save and manage your data files (copy, move, delete, etc.) from this
menu. For detailed instructions, refer to pages 58 – 61.
File Selection Display Configuration
SONG
selection
button
REGIST BANK
selection button
MULTI PAD CONTROL
[SELECT] button
STYLE category
selection button
VOICE category
selection button
1
2
3
NOTE
Hereafter in this manual, any USB
storage device such as USB flash
memory, floppy disk drive, etc. will be
referred to as “USB storage device.”
NOTE
The data, both pre-programmed and
your own original, are saved as
“files.”
NOTE
You can open the File Selection display
for a specified file from the [USB] button.
[USB] → [A] SONG/[B] STYLE/[C]
REGIST/[F] VOICE/ [G] MULTI PAD.
26 PSR-S910/S710 Owner’s Manual
Starting Up
The instructions that follow show you how to enter characters for naming your files/
folders, inputting keywords, etc. Entering characters should be done in the display
shown below.
1Change the type of character by pressing the [1 ▲] button.
• CASE capital letters, numbers, marks
• case lowercase letters, numbers, marks
2Use the [DATA ENTRY] dial to move the cursor to the desired
position.
Closing the current folder and calling up the next highest level
folder
In the PRESET display, several data (files) are contained together in a folder.
You can also organize your original data in the USER/USB display by creat-
ing several new folders (page 59).
To close the current folder and call up the next highest level folder, press the
[8 ▲] (UP) button.
Example of the PRESET Voice Selection display
The PRESET Voice files are categorized and contained in appropriate folders.
This display shows the Voice
files in a folder.
The next highest level — in this case,
folder — is shown. Each folder
shown in this display contains appro-
priately categorized Voices.
Entering Characters
2
1 4
3
Several different characters are
assigned to each button, and the
characters change each time you
press the button.
NOTE
When inputting lyrics in the Song
Creator function, you may also enter
Japanese characters (kana and kanji).
PSR-S910/S710 Owner’s Manual 27
Starting Up
3Press the [2 ▲▼] – [6 ▲▼] and [7 ▲] buttons, corresponding to
the character you wish to enter.
To actually enter the selected character, move the cursor or press another letter-
input button. Alternately, you can wait for a short time and the characters will be
entered automatically.
For details on entering characters, refer to “Other character-entry operations”
below.
4Press the [8 ▲] (OK) button to actually enter the new name and
return to the previous display.
• Deleting characters
Move the cursor to the character you wish to delete by using the [DATA ENTRY]
dial, and press the [7 ▼] (DELETE) button. To delete all characters on the line at
once, press and hold the [7 ▼] (DELETE) button.
• Entering marks or space
1. Press the [6 ▼] (SYMBOL) button to call up the mark list.
2. Use the [DATA ENTRY] dial to move the cursor to the desired mark or space, then
press the [8 ▲] (OK) button.
• Selecting custom icons for files (shown at left of file name)
1. Press the [1 ▼] (ICON) button to call up the ICON SELECT display.
2. Select the icon by using the [A] – [J] buttons, [3 ▲▼] – [5 ▲▼] buttons or [DATA
ENTRY] dial. The ICON display includes several pages. Press the TAB [E][F]
buttons to select different pages.
3. Press the [8 ▲] (OK) button to apply the selected icon.
While holding the C6 key (right-most key on the keyboard), turn the [STANDBY/ON]
button ON. This restores the all settings (except Internet Settings, etc.) to the factory
default.
You can also restore a specified setting to the factory default value, or save/load your
own reset settings. Call up the operation display: [FUNCTION] → [J] UTILITY →
TAB [E][F] SYSTEM RESET. For details, refer to the Reference Manual on the
website.
NOTE
The file name can contain up to 41
characters and the folder name can
contain up to 50 characters.
NOTE
When entering a password for a web-
site or the WEP key for wireless LAN
connection, the characters are con-
verted to asterisks (*) for security pur-
poses.
NOTE
To cancel the character-entering oper-
ation, press the [8 ▼] (CANCEL) but-
ton.
Other character-entry operations
NOTE
To cancel the operation, press the
[8 ▼] (CANCEL) button.
Restoring the Factory-programmed Settings
NOTE
If you want to initialize only the Regis-
tration Memory setting (page 71),
turn the [STANDBY/ON] button on
while holding the B5 key.
NOTE
To reset the Internet Settings, call up
the operation display: [INTERNET] →
[5 ▼] SETTING → [A] NETWORK
SETTINGS → [E] INITIALIZE SET UP.
C6
28 PSR-S910/S710 Owner’s Manual
Starting Up
This procedure backs up all data stored in USER drive (except Protected Songs) and
all settings including Internet Direct Connection settings.
For maximum data security Yamaha recommends that you copy or save your
important data to a USB storage device. This provides a convenient backup if the
internal memory is damaged.
1Insert/connect the backup USB storage device (destination).
2Call up the operation display.
[FUNCTION] → [J] UTILITY → TAB [E][F] OWNER
3Press the [D] (BACKUP) button to save the data to the USB
storage device.
To restore the data, press the [E] (RESTORE) button in this display. When the
operation is complete, the instrument will be restarted automatically.
Data Backup
NOTE
Before using a USB storage device, be
sure to read “Connecting a USB Stor-
age Device” on page 94.
NOTE
Completing the backup/restore opera-
tion may take a few minutes.
CAUTION
Move the Protected Songs
which are saved to the USER
display before restoring. If the
Songs are not moved, the oper-
ation deletes the data.
NOTE
To save the Song, Style, Multi Pad,
Registration Memory Bank and Voice
independently, execute the Copy and
Paste operation from the File Selec-
tion display (page 60).
NOTE
To save the Music Finder Record,
Effect, MIDI Template and System
File, call up the operation display:
[FUNCTION] → [J] UTILITY → TAB
[E][F] SYSTEM RESET. For more
information, refer to the Reference
Manual on the website.
2
3
1
Voices – Playing the keyboard –
PSR-S910/S710 Owner’s Manual 29
Voices
– Playing the keyboard –
The instrument features a wide variety of exceptionally realistic
instrumental Voices, including piano, guitar, strings, brass, wind
instruments and more.
1Press the PART SELECT [RIGHT 1] button.
Make sure that the PART ON/OFF [RIGHT1] button is also turned on. If it is
turned off, the right-hand part will not sound.
2Press one of the VOICE category selection buttons to select a
Voice category and call up the Voice Selection display.
The preset Voices are categorized and contained in appropriate folders. Voice
category selection buttons on the panel correspond to the categories of the
preset Voices. For example, press the [STRINGS] button to display various
strings Voices.
Playing Preset Voices
Selecting a Voice (RIGHT 1) and playing the keyboard
NOTE
For the Voice part, see page 32.
NOTE
For more information on the VOICE
category selection buttons, refer to
page 33.
30 PSR-S910/S710 Owner’s Manual
Voices – Playing the keyboard –
1
3Press one of the [A] – [J] buttons to select the desired Voice.
To call up the other display pages, press one of the [1 ▲] – [5 ▲] buttons or
press the same VOICE button again.
4Play the keyboard.
1Make sure that PART ON/OFF [RIGHT 1] button is turned on.
2Press the PART ON/OFF [RIGHT 2] button to turn it on.
NOTE
The Voice type and its defining char-
acteristics are indicated above the
Preset Voice name. For details on the
characteristics, see page 33 and the
Reference Manual.
NOTE
(PSR-S910) You can call up the infor-
mation for the selected Voice by
pressing the [7 ▲] (INFO) button.
(Some Voices do not have the infor-
mation display.) To close the informa-
tion display, press the [EXIT] button.
To listen to the demo phrases for each Voice
Press the [8 ▼] (DEMO) button to start the Demo for the selected Voice. To
stop the demo, press the [8 ▼] button again.
Recalling your favorite Voices easily
The instrument has a huge amount of high-quality Voices, covering an
exceptionally broad range of instrument sounds — making it perfect for
virtually every musical application. However, the sheer number of Voices
may seem overwhelming at first. By using the [USER] button, you can easily
recall your favorite Voice.
1. Copy your favorite Voice from the Preset drive to the User drive. Refer
to page 60 for details on the copy operation.
2. Press the [USER] button to call up the User drive of the Voice Selection
display, then press one of the [A] – [J] buttons to select the desired Voice.
Playing Two Voices Simultaneously
3
PSR-S910/S710 Owner’s Manual 31
Voices – Playing the keyboard –
1
3Press one of the VOICE category selection buttons to call up the
Voice Selection display for the Right 2 part.
4Press one of the [A] – [J] buttons to select the desired Voice.
5Play the keyboard.
The Voice selected for RIGHT 1 (page 29) and the Voice selected here are
sounded simultaneously in a layer.
1Make sure that the PART ON/OFF [RIGHT 1] and/or [RIGHT 2]
buttons are turned on.
2Press the PART ON/OFF [LEFT] button to turn it on.
3Press one of the VOICE category selection buttons to call up the
Voice Selection display for the Left part.
4Press one of the [A] – [J] buttons to select the desired Voice.
5Play the keyboard.
The notes you play with your left hand sound one Voice (LEFT Voice selected
above), while the notes you play with your right sound a different Voices
(RIGHT 1 and 2 Voices).
NOTE
You can save the settings to Registra-
tion Memory. See page 71.
Quickly selecting Voices for Right 1 and 2 parts
You can quickly select the Right 1 and 2 part Voices, just from the Voice cat-
egory selection buttons. Press and hold one Voice button, then press another.
The Voice of the first pressed button is automatically set for the Right 1 part,
while the Voice of the second pressed button is set for the Right 2 part.
Playing Different Voices with the Left and Right Hands
NOTE
You can save the settings to Registra-
tion Memory. See page 71.
RIGHT 2 part
RIGHT 1 part
LEFT part
32 PSR-S910/S710 Owner’s Manual
Voices – Playing the keyboard –
1
NOTE
To change the Split Point, press:
[FUNCTION] → [C] STYLE SETTING/
SPLIT POINT/CHORD FINGERING →
TAB [EE
EE][FF
FF] SPLIT POINT. For more
information, refer to the Reference
Manual on the website.
Keyboard Parts
Voices can be assigned independently to each of the three keyboard parts:
Right 1, Right 2 and Left. You can combine these parts by using the PART
ON/OFF buttons to create a rich, ensemble sound.
When the LEFT part is off, the RIGHT 1 and 2 Voices can be played over the
entire keyboard. When the LEFT part is on, keys lower than F#2 (the Split
Point) are set for playing the LEFT part and those higher than the Split Point
are set for playing the RIGHT 1 and 2 parts.
You can confirm the currently selected part by checking which lamp of the
PART SELECT buttons is lit. To select the desired keyboard part, press the
corresponding part button.
Holding the LEFT part Voice (Left Hold)
This function causes the LEFT part Voice to be held even when the keys are
released. Non-decaying Voices such as strings are held continuously, while
decay-type Voices such as piano decay more slowly (as if the sustain pedal
has been pressed).
Upper section of the
keyboard
Lower section of the
keyboard
Split Point (F#2)
PSR-S910/S710 Owner’s Manual 33
Voices – Playing the keyboard –
1
• Voice Characteristics
The Voice type and its defining characteristics are indicated above the Voice
name—Live!, Cool!, Sweet!, etc. For detailed explanation, refer to the Reference
Manual.
In this section, only MegaVoice and Super Articulation Voice are explained. These
Voices have special characteristics you should be aware of, and they require specific
performance techniques to bring out all of their expressive qualities.
MegaVoices
What makes MegaVoices special is their use of velocity switching. Each velocity
range (the measure of your playing strength) has a completely different sound.
For example, a guitar MegaVoice includes the sounds of various performance
techniques. In conventional instruments, different Voices having those sounds
would be called up via MIDI and played in combination to achieve the desired
effect. However, now with MegaVoices, a convincing guitar part can be played
with just a single Voice, using specific velocity values to play the desired sounds.
Because of the complex nature of these Voices and the precise velocities need to
play the sounds, they’re not intended for playing from the keyboard. They are,
however, very useful and convenient when creating MIDI data—especially when
you want to avoid using several different Voices just for a single instrument part.
Super Articulation Voices (S.Art!) (PSR-S910)
The Super Articulation Voices provide many of same benefits as the MegaVoices,
but with greater playability and expressive control in real time.
For example, with the Saxophone Voice, if you play a C and then a D in a very
legato way, you will hear the note change seamlessly, as though a saxophone
player played it in a single breath. Similarly with the Concert Guitar Voice, the D
note would sound as a “hammer on,” without the string being plucked again.
Depending on how you play, other effects such as shake or breath noises (for the
Trumpet Voice), or finger noises (for the Guitar Voice) will be produced.
For details on how to best play each Super Articulation Voice, call up the
information window (pressing the [7 ▲] (INFO) button in the Voice Selection
display).
Voice Types
Percussion/Drum Voices
When one of the Voices is selected
from this button, you can play vari-
ous drums and percussion instru-
ments or SFX (sound effects)
sounds on the keyboard. Details
are given in the Drum List provided
in the Data List on the website.
Preset Voices [USER] button (page 30)
Organ Flutes Voices
(page 37)
NOTE
MegaVoices and Super Articulation
Voices are only compatible with other
models which have those types of
Voices installed. Any Song, Style or
Multi Pads data you’ve created on the
instrument using these Voices will not
sound properly when played back on
other instruments.
NOTE
MegaVoices and Super Articulation
Voices sound differently depending
on the keyboard range, velocity,
touch, etc. Hence, if you apply HAR-
MONY/ECHO effect, change the
transpose setting or change the Voice
Set parameters, unexpected or undes-
ired sounds may result.
34 PSR-S910/S710 Owner’s Manual
Voices – Playing the keyboard –
1
The TRANSPOSE [-]/[+] buttons transpose the overall pitch of the instrument (the
keyboard sound, Style playback, Song playback, and so on) in semitone steps. Press
the [+] and [-] buttons simultaneously to instantly reset the transpose value to 0.
The UPPER OCTAVE [-]/[+] buttons allow the pitch of the RIGHT 1 and 2 parts to
be shifted up or down by one octave. Press the [+] and [-] buttons simultaneously to
instantly reset the octave value to 0.
Use the PITCH BEND wheel to bend notes up (roll the wheel away from you) or
down (roll the wheel toward you) while playing the keyboard. The Pitch Bend is
applied to all the keyboard parts (RIGHT 1, 2 and LEFT). The PITCH BEND wheel
is self-centering and will automatically return to normal pitch when released.
The maximum pitch bend range can be changed on the Mixing Console display:
[MIXING CONSOLE] → TAB [EE
EE][FF
FF] TUNE → [H] PITCH BEND RANGE.
Transposing the Pitch of the Keyboard
NOTE
The Transpose functions do not affect
the Drum Kit or SFX Kit Voices.
NOTE
You can also change the transpose
settings in the MIXING CONSOLE
display: [MIXING CONSOLE]→ TAB
[EE
EE][FF
FF] TUNE → [1 ▲▼] – [3 ▲▼]
TRANSPOSE.
Default Pitch setting
By default, the reference pitch of the entire instrument is set to 440.0 Hz, and
the scale to equal temperament. You can change the pitch and scale from
[FUNCTION] → [A] MASTER TUNE/SCALE TUNE.
You can also adjust the pitch for each part (keyboard parts, Style parts and
Song parts) on the TUNE page of the Mixing Console display (page 79).
For details, refer to the Reference Manual on the website.
Using the Wheels
Using the Pitch Bend Wheel
NOTE
The effects caused by using the
PITCH BEND Wheel may not be
applied to the LEFT part during Style
playback depending on the Style set-
ting.
PSR-S910/S710 Owner’s Manual 35
Voices – Playing the keyboard –
1
The Modulation function applies a vibrato effect to notes played on the keyboard.
By default, this is applied to the keyboard parts RIGHT 1 and 2. Moving the
MODULATION wheel down (toward you) decreases the depth of the effect, while
moving it up (away from you) increases it.
You can set whether the effects caused by the MODULATION Wheel will be
applied or not to each of the keyboard part: [FUNCTION] → [D] CONTROLLER
→ TAB [E][F] KEYBOARD/PANEL → [A]/[B] 2 MODULATION WHEEL.
The PSR-S910/S710 features a sophisticated multi-processor effect system which
can add extraordinary depth and expression to your sound. This effect system can be
turned on or off by using the following buttons.
• HARMONY/ECHO
The Harmony/Echo types are applied to the right-hand Voices. Refer to “Applying
Harmony to Your Right-hand Melody” on page 36.
• TOUCH
This button turns the touch response of the keyboard on or off. When OFF, the same
volume is produced no matter how strongly or softly you play the keyboard.
• SUSTAIN
When this Sustain function is on, all notes played on the keyboard with right-hand
part (RIGHT 1 and 2) have a longer sustain.
• MONO
When this button is on, the part’s Voice is played monophonically (only one note at a
time). Using the MONO mode lets you play single, lead sounds (such as brass
instruments) more realistically. It also lets you expressively control the Portamento
effect (depending on the selected Voice) by playing legato.
When this button is off, the part’s Voice played polyphonically.
Using the Modulation Wheel
NOTE
Depending on the selected Voice, the
MODULATION wheel may control vol-
ume, filter or some other parameter
instead of vibrato.
NOTE
To avoid accidentally applying modu-
lation, make sure the MODULATION
Wheel is set at minimum (down)
position before you start playing.
NOTE
The effects caused by using the MOD-
ULATION wheel may not be applied to
the LEFT part during Style playback
depending on the Style setting.
Applying Voice Effects
These three effect systems are applied to the
currently selected keyboard part (RIGHT 1,
2, or LEFT)
NOTE
Portamento is a function that creates a
smooth transition in pitch from the
first note played on the keyboard to
the next.
36 PSR-S910/S710 Owner’s Manual
Voices – Playing the keyboard –
1
• DSP/DSP VARI.
With the digital effects built into the instrument, you can add ambience and depth to
your music in a variety of ways—such as adding reverb that makes you sound like
you are playing in a concert hall.
The [DSP] button is used to turn the DSP (Digital Signal Processor) effect on or off
for the currently selected keyboard part.
The [DSP VARI.] button is used to change between variations of the DSP effect. You
could use this while you play, for example, to change the rotating speed (slow/fast)
of the rotary speaker effect.
Among the Voice Effects, Harmony is one of the most impressive. It automatically
adds harmony parts to the notes you play with your right hand—immediately giving
you a more full and professional sound.
1Turn the [HARMONY/ECHO] button on.
2Turn on both the [ACMP] button and [SYNC START] button
(page 39) and make sure that the RIGHT 1 part is on (page 29).
3Play a chord with your left hand to start the Style (page 40) and
play some notes in the right-hand range of the keyboard.
You can also use the Harmony effect with the Style stopped. Simply hold down a
chord with your left hand and play a melody with your right.
Many of the Voices have been automatically set to play certain Harmony/Echo types
that match the particular Voice. Try out some of Voices. You can also change the
Harmony/Echo type: [FUNCTION] → [H] HARMONY/ECHO.
NOTE
The effect type can be changed. On
the Voice Selection display, select [6
▲] (VOICE SET) → TAB [EE
EE][FF
FF]
EFFECT/EQ → [A]/[B] 2 DSP.
Applying Harmony to Your Right-hand Melody (HARMONY/ECHO)
NOTE
Depending on the harmony/echo
type, harmony will be applied even
when the [ACMP] button is off.
In this example, harmony notes in the scale of
C major (the chord played in the left hand) are
automatically added to the notes played in the
right-hand range of the keyboard.
Split Point
Chord section
PSR-S910/S710 Owner’s Manual 37
Voices – Playing the keyboard –
1
The PSR-S910/S710 uses advanced digital technology to recreate the legendary
sound of vintage organs. Just as on a traditional organ, you can create your own
sound by increasing and decreasing the levels of the flute footages.
1Press the [ORGAN FLUTES] button.
The FOOTAGE Page of the Organ Flutes Voice is called up.
2Use the [1 ▲▼] – [8 ▲▼] buttons to adjust the footage settings.
The footage settings determine the basic sound of the organ flutes.
The [1 ▲▼] buttons control two footages: 16' and 5 1/3'. Pressing the [D]
button switches between these two footages.
If you want, you can select the Organ type, change the Rotary Speaker speed
and adjust the Vibrato setting, by using the [A] – [C] and [F] – [H] buttons.
Creating Your Original Organ Flutes Voices
NOTE
The term “footage” is a reference to
the sound generation of traditional
pipe organs, in which the sound is
produced by pipes of different lengths
(in feet).
3
4
5
6
1
2
NOTE
About the VOLUME/ATTACK Page
and EFFECT/EQ Page, see the Refer-
ence Manual on the website.
1[A]/[B] ORGAN TYPE Specifies the type of organ tone generation to be
simulated: Sine or Vintage.
2[C] ROTARY SP
SPEED
Alternately switches between the slow and fast
rotary speaker speeds when a rotary speaker effect
is selected for the Organ Flutes (DSP TYPE
parameter in the EFFECT/EQ Page), and the
VOICE CONTROL [DSP] button is turned on.
3[F] VIBRATO OFF Alternately turns the vibrato effect for the Organ
Flutes Voice ON or OFF.
4[G] VIBRATO ON
5[H] VIBRATO
DEPTH
Sets the Vibrato depth to one of three levels:
1 (low), 2 (mid), or 3 (high).
6[I] PRESETS Opens the File Selection display of the Organ
Flute Voices for selecting a preset Organ Flutes
Voice.
38 PSR-S910/S710 Owner’s Manual
Voices – Playing the keyboard –
1
3Press the [I] (PRESETS) button to call up the Organ Flutes Voice
Selection display.
4Use the TAB [EE
EE][FF
FF] buttons to select the location to which your
Organ Flutes Voice will be saved.
5Press the [6 ▼] (SAVE) button to call up the Save display.
6Save your Organ Flutes Voice by following the procedure on
page 58.
CAUTION
The setting will be lost if you
select another Voice or turn the
power to the instrument off
without executing the Save
operation.
Advanced Features
Refer to the Reference Manual on the website, Chapter 1.
Selecting GM/XG or other Voices from
the Panel:
Voice Selection display → [8 ▲](UP) → [2 ▲]
(P2)
Effect-related settings
• Setting the touch sensitivity of the
keyboard:
[FUNCTION] → [D] CONTROLLER → TAB
[E][F] KEYBOARD/PANEL
• Selecting the Harmony/Echo type: [FUNCTION] → [H] HARMONY/ECHO
Pitch-related settings
• Fine-tuning the pitch of the entire
instrument:
[FUNCTION] → [A] MASTER TUNE/SCALE
TUNE → TAB [E][F] MASTER TUNE
•Scale Tuning: [FUNCTION] → [A] MASTER TUNE/SCALE
TUNE → TAB [E][F] SCALE TUNE
• Changing the part assignment of the
TRANSPOSE buttons:
[FUNCTION] → [D] CONTROLLER → TAB
[E][F] KEYBOARD/PANEL → [A]/[B] 3
TRANSPOSE ASSIGN
Editing Voices (Voice Set): Voice Selection display → [6 ▲] (VOICE SET)
Disabling automatic selection of Voice
Sets (effects, etc.):
[FUNCTION] → [E] REGIST SEQUENCE/
FREEZE/VOICE SET → TAB [E][F] VOICE
SET
Editing Organ Flutes parameters: [ORGAN FLUTES] → TAB [E][F] VOLUME/
ATTACK or EFFECT/EQ
2
Styles – Playing Rhythm and Accompaniment –
PSR-S910/S710 Owner’s Manual 39
Styles
– Playing Rhythm and Accompaniment –
The instrument features a variety of accompaniment and rhythmic
backing patterns (called “Styles”) in a variety of different musical
genres including pop, jazz, and many others. The Style features
Auto Accompaniment, letting you produce automatic
accompaniment playback simply by playing “chords” with your
left hand. This lets you automatically recreate the sound of a full
band or orchestra—even if you’re playing by yourself.
1Press one of the STYLE category selection buttons to call up
the Style Selection display.
2Press one of the [A] – [J] buttons to select the desired Style.
Pressing one of the [1 ▲] – [4 ▲] buttons or pressing the same STYLE button
again can call up the other display page.
3Press the [ACMP] button to turn on the Auto Accompaniment.
The specific left-hand section of the keyboard (page 32) becomes the Chord
section, and chords played in this section are automatically detected and used as
a basis for fully automatic accompaniment with the selected Style.
4Press the [SYNC START] button to enable synchronized start.
Playing a Style with the Auto Accompaniment
NOTE
The [USER] button in the Style cate-
gory selection buttons can be used as
same as the [USER] button in the
Voice category selection buttons. See
page 30.
2
40 PSR-S910/S710 Owner’s Manual
Styles – Playing Rhythm and Accompaniment –
2
5As soon as you play a chord with your left hand, the selected
Style starts.
Try playing chords with your left hand and play melody with your right hand.
6Press the [START/STOP] button to stop Style playback.
NOTE
For information on chords, see page 41.
NOTE
You can transpose the Style (accompani-
ment). See page 34.
Style Characteristics
The Style type and its defining characteristics are indicated on the Preset
Style icon.
•Pro: These Styles provide professional and exciting arrangements com-
bined with perfect playability. The resulting accompaniment exactly fol-
lows the chords of the player. As a result, your chord changes and colorful
harmonies are instantly transformed into lifelike musical accompaniment.
• Session: These Styles provide even greater realism and authentic backing
by mixing in original chord types and changes, as well as special riffs with
chord changes, with the Main sections. These have been programmed to
add “spice” and a professional touch to your performances of certain
songs and in certain genres. Keep in mind, however, that the Styles may
not necessarily be appropriate—or even harmonically correct-for all songs
and for all chord playing. In some cases for example, playing a simple
major triad for a country song may result in a “jazzy” seventh chord, or
playing an on-bass chord may result in inappropriate or unexpected
accompaniment.
Style file compatibility
The PSR-S910/S710 uses the SFF GE file format (page 9). The PSR-S910/
S710 can play back existing SFF files, but they will be saved in the SFF GE
format when the file is saved (or pasted) in the PSR-S910/S710. Please keep
in mind that the saved file can only be played back on instruments that are
compatible with the SFF GE format.
PSR-S910/S710 Owner’s Manual 41
Styles – Playing Rhythm and Accompaniment –
2
For users who are unfamiliar with chords, this handy chart features common chords for your quick
reference. Since there are many useful chords and many different ways to use them musically, refer to
commercially available chord books for further details.
★ Indicates the root note.
Changing the Chord Fingering Type
By changing the chord fingering type, you can automatically produce appropriate accompaniment even
if you don’t press all of the notes which comprise a chord. Chord fingering type can be changed from:
[FUNCTION] → [C] STYLE SETTING/SPLIT POINT/CHORD FINGERING → TAB [EE
EE][FF
FF]
CHORD FINGERING.
Following types can be selected, for example.
• Single Finger
This method lets you easily play chords in the accompaniment range of the keyboard using only one,
two or three fingers.
• AI Full Keyboard
Playing just about anything, anywhere on the keyboard using both hands – like playing the piano –
produces appropriate accompaniment. You don’t have to worry about specifying the chords. (Depending
on the song arrangement, AI Full Keyboard may not always produce appropriate accompaniment.)
For other types, refer to the Reference Manual on the website.
Chords
Major Minor Seventh Minor Seventh Major Seventh
Major chord
Press the root key only.
Minor chord
Simultaneously press
the root key and a black
key to its left.
Seventh chord
Simultaneously press
the root key and a
white key to its left.
Minor seventh chord
Simultaneously press
the root key and both a
white and black key to
its left.
42 PSR-S910/S710 Owner’s Manual
Styles – Playing Rhythm and Accompaniment –
2
• [START/STOP] button
• [SYNC START] button
• [SYNC STOP] button
• INTRO [I] – [III] buttons
• ENDING/rit. [I] – [III] buttons
Operating Style Playback
To Start/Stop Playing
Style starts playing back as soon as the [START/STOP] button is
pressed. To stop playback, press the button again.
This puts the Style playback in “standby.” The Style starts play-
ing back when you press any note on the keyboard (when
[ACMP] is off) or you play a chord with your left hand (when
[ACMP] is on). During the Style playback, pressing this button
stops playing and puts the playback in “standby.”
NOTE
When the fingering mode is set to
“Full Keyboard” or “AI Full Key-
board,” Synchro Stop cannot be
turned on.
To change the fingering mode:
[FUNCTION] → [C] STYLE SETTING/
SPLIT POINT/CHORD FINGERING →
TAB [E][F] CHORD FINGERING.
You can start and stop the Style anytime you want by simply
playing or releasing the keys in the chord section of the key-
board. Make sure that the [ACMP] button is on, press the [SYNC
STOP] button, then play the keyboard.
The PSR-S910/S710 features three different Intro sections to
add an introduction before starting the Style playback. After
pressing one of the INTRO [I] – [III] buttons, start playback
by using the [START/STOP] button or [SYNC START] but-
ton. When the Intro finishes playing, the Style playback
automatically shifts to the Main section.
The PSR-S910/S710 features three different Ending sections
to add an ending before stopping Style playback. When you
press one of the ENDING [I] – [III] buttons while Style is
playing back, the Style will automatically stop after the
ending is played. You can have the ending gradually slow
down (ritardando) by pressing the same ENDING button
once again, while the ending is playing.
NOTE
If you press the ENDING/rit. [I] button
when the Style is playing, a fill-in
automatically plays before the END-
ING/rit [I].
About the lamp status of the section buttons (INTRO/MAIN VARIATION/
BREAK/ENDING)
•Red: The section is currently selected.
• Red (flashing): The section will be played next, following the currently selected
section.
•Green: The section contains data but not currently selected.
•Off: The section contains no data and cannot be played.
PSR-S910/S710 Owner’s Manual 43
Styles – Playing Rhythm and Accompaniment –
2
Each Style features four different Main sections, four Fill-in sections and a Break
section. By using these sections effectively, you can easily make your performance
sound more dynamic and professional. The section can be freely changed while the
Style is playing back.
• [BREAK] button
• TEMPO [-]/[+] buttons
By pressing the TEMPO [-] or [+] button, you can decrease/increase the tempo over
a range of 5 – 500. While the TEMPO pop-up is shown on the display, you can also
use the [DATA ENTRY] dial to adjust the value.
Pressing the TEMPO [-]/[+] buttons simultaneously resets the tempo to the default
value.
• [TAP TEMPO] button
Changing Pattern Variation (Sections) During Style playback
AUTO FILL function
When the [AUTO FILL IN] button is turned on, pressing any of the
Main [A] – [D] buttons as you play automatically plays fill-in section.
Adjusting the Tempo
Selected Main section’s
lamp is lit in red
• MAIN VARIATION [A] – [D] buttons
Press one of the MAIN VARIATION [A] – [D] buttons to
select the desired Main section (the button lights in red).
Each is an accompaniment pattern of a few measures and
it plays indefinitely. Pressing the selected MAIN VARIA-
TION button again plays an appropriate fill-in pattern to
spice up the rhythm and break the repetition. After the
fill-in finishes playing, it leads smoothly into the Main
section.
Selected Fill In section’s
lamp flashes in red
This lets you add dynamic breaks in the rhythm of the accompa-
niment. Press the [BREAK] button during Style playback. When
the one-measure Break pattern finishes playing, the Style play-
back automatically shifts to the Main section.
NOTE
This operation is common for Song
playback (page 49).
During Style playback, you can change the tempo by tapping the
[TAP TEMPO] button twice at the desired tempo.
When the Style is stopped, tapping the [TAP TEMPO] button
(four times for a 4/4 time signature) starts Style playback at the
tempo you tapped.
44 PSR-S910/S710 Owner’s Manual
Styles – Playing Rhythm and Accompaniment –
2
• [FADE IN/OUT] button
The convenient Repertoire function automatically calls up the most appropriate
panel settings (Voice number, etc.) for the currently selected Style.
1Select the desired Style from the Style Selection display (steps 1
– 2 on page 39).
2Press the [5 ▲] (REPERTOIRE) button.
Various appropriate panel settings matching the selected Style will be shown in
the display.
3Use the [2 ▲▼] – [3 ▲▼] buttons to select the desired panel
setting.
Fading In/Out
NOTE
This operation is common for Song
playback (page 49).
Calling up the Panel Settings to Match the Style (Repertoire)
Before using the Repertoire function, you need to import Music Finder records
(see instructions on page 65).
This produces smooth fade-ins and fade-outs when starting/
stopping playback. Press the [FADE IN/OUT] button when
playback is stopped and press the [START/STOP] button to start
playback with a fade in. To stop the playback with a fade out,
press the [FADE IN/OUT] button during playback.
NOTE
The settings shown here are Music
Finder Records. You can choose addi-
tional settings by using the Music
Finder feature (page 65).
3
2
NOTE
Depending on the particular selected
Style, there may not be any panel set-
tings in the Repertoire function.
PSR-S910/S710 Owner’s Manual 45
Styles – Playing Rhythm and Accompaniment –
2
One Touch Setting is a powerful and convenient feature that automatically calls up
the most appropriate panel settings (Voices or effects, etc.) for the currently selected
Style, with the touch of a single button. If you’ve already decided which Style you
wish to use, you can have One Touch Setting automatically select the appropriate
Voice for you.
1Select a Style (steps 1 – 2 on page 39).
2Press one of the ONE TOUCH SETTING [1] – [4] buttons.
Not only does this instantly call up all the settings (Voices, effects, etc.) that
match the current Style, it also automatically turns on ACMP and SYNC
START, so that you can immediately start playing the Style.
3As soon as you play a chord with your left hand, the selected
Style starts.
Each Style has four One Touch Setting setups. Press other ONE TOUCH
SETTING [1] – [4] button to try out other setups.
Appropriate Panel Settings for the Selected Style (One Touch Setting)
NOTE
You can also create your own One
Touch Setting setups. For details,
refer to the Reference Manual on the
website.
NOTE
You can change the timing in which
the One Touch Settings change with
MAIN VARIATION [A] – [D] change.
Refer to the Reference Manual on the
website.
Automatically changing One Touch Settings with the Main sections
The convenient OTS (One Touch Setting) Link function lets you automati-
cally have One Touch Settings change when you select a different Main sec-
tion (A – D). The Main sections A, B, C and D correspond to One Touch
Settings 1, 2, 3 and 4 respectively. To use the OTS Link function, turn the
[OTS LINK] button on.
46 PSR-S910/S710 Owner’s Manual
Styles – Playing Rhythm and Accompaniment –
2
You can check the information of the One Touch Setting [1] – [4] assigned to
currently selected Style.
1In the Style Selection display, press the [7 ▲] (OTS INFO.) button
to call up the Information display.
2Press the [F] (CLOSE) button to close the Information display.
Confirming the One Touch Setting contents
NOTE
You can also call up the Information
display by pressing the [DIRECT
ACCESS] button then pressing one of
the ONE TOUCH SETTING [1] – [4]
buttons.
2
1
PSR-S910/S710 Owner’s Manual 47
Styles – Playing Rhythm and Accompaniment –
2
A Style contains eight channels: RHY1 (Rhythm 1) – PHR2 (Phrase 2) below. You
can add variations and change the feeling of a Style by selectively turning channels
on/off as the Style plays.
1Press the [CHANNEL ON/OFF] button once or twice to call up
the CHANNEL ON/OFF (STYLE) display.
2Press the [1 ▼] – [8 ▼] buttons to turn the channels on or off.
To listen to only one channel by itself, hold down the appropriate button for the
channel to set the channel to SOLO. To cancel SOLO, simply press the
appropriate channel button again.
3Press the [EXIT] button to close the CHANNEL ON/OFF display.
Turning Style Parts On/Off and Changing Voices
Style channels
•RHY1/2 (Rhythm 1/2): These are the basic parts of the Style, containing
the drum and percussion rhythm patterns.
•BASS: The bass part uses various appropriate instrument sounds to match
the Style.
• CHD1/2 (Chord 1/ 2): These are the rhythmic chord backing, commonly
used with piano or guitar Voices.
•PAD: This part is used for sustained instruments such as strings, organ,
choir, etc.
• PHR1/2 (Phrase1/2): These parts are used for punchy brass stabs, arpeg-
giated chords, and other extras that make the accompaniment more inter-
esting.
2
NOTE
You can save the settings here to Reg-
istration Memory. See page 71.
Changing the Voice for each channel
If necessary, press the [1 ▲] – [8 ▲] buttons to change the Voice for the cor-
responding channel.
The Voice Selection display is called up from which you can select the Voice
to be used for the channel. See page 29.
NOTE
When the Main display is shown, the
CHANNEL ON/OFF display cannot be
closed.
48 PSR-S910/S710 Owner’s Manual
Styles – Playing Rhythm and Accompaniment –
2
You can adjust the volume balance between Style playback and the sound you play
on the keyboard.
1Press the [BALANCE] button to call up the BALANCE display.
2Adjust the Style volume by using the [2 ▲▼] buttons.
Using the [1 ▲▼] – [7 ▲▼] buttons, you can adjust the volume of Song, Style,
Multi Pad, MIC (for the PSR-910) and keyboard parts.
3Press the [EXIT] button to close the BALANCE display.
Adjusting the Volume Balance Between the Style and Keyboard
2
NOTE
When the Main display is shown, the
BALANCE display cannot be closed.
NOTE
In the Mixing Console display, you
can adjust the volume for each Style
part. See page 82.
Advanced Features
Refer to the Reference Manual on the website, Chapter 2.
Selecting the Chord Fingering type:
[FUNCTION] → [C] STYLE SETTING/
SPLIT POINT/CHORD FINGERING →
TAB [E][F] CHORD FINGERING
Style playback related settings:
[FUNCTION] → [C] STYLE SETTING/
SPLIT POINT/CHORD FINGERING →
TAB [E][F] STYLE SETTING
Split Point settings:
[FUNCTION] → [C] STYLE SETTING/
SPLIT POINT/CHORD FINGERING →
TAB [E][F] SPLIT POINT
Memorizing the Original One Touch Setting: [MEMORY] + ONE TOUCH SETTING [1]
– [4]
Creating/Editing Styles (Style Creator): [FUNCTION] → [F] DIGITAL REC MENU
→ [B] STYLE CREATOR
• Realtime Recording: → TAB [E][F] BASIC
• Step Recording: → TAB [E][F] EDIT → [G] STEP REC
• Style Assembly: → TAB [E][F] ASSEMBLY
• Editing the Rhythmic Feel: → TAB [E][F] GROOVE
• Editing Data for Each Channel: → TAB [E][F] CHANNEL
• Making Style File Format Settings: → TAB [E][F] PARAMETER
3
Songs – Playing, Practice and Recording Songs –
PSR-S910/S710 Owner’s Manual 49
Songs
– Playing, Practice and Recording Songs –
For the PSR-S910/S710, “Song” refers to the MIDI songs which
include preset songs, commercially available MIDI format files,
etc. Not only can you play back a Song and listen to it, but you
can also play the keyboard along with Song playback and record
your own performance as a Song.
You can play back the following types of Songs.
• Preset Songs (in the PRESET Page of the Song Selection display)
• Your own recorded Songs (see page 56 for instructions on recording)
• Commercially available Song data: SMF (Standard MIDI File) or ESEQ
1Press the SONG [SELECT] button to call up the Song Selection
display.
2Press the TAB [EE
EE][F] buttons to select the location of the
desired Song.
If you want to playback of Song in the USB storage device, connect the USB
storage device containing MIDI Song data to the [USB TO DEVICE] terminal
beforehand.
3Select the desired Song by using the [A] – [J] buttons.
You can also select a Song by using the [DATA ENTRY] dial, then press the
[ENTER] button to execute.
Playback of Songs
NOTE
For information on compatible data
formats, refer to page 9.
2
NOTE
You can instantly jump back to the
Main display by “double-clicking” on
one of the [A] – [J] buttons.
50 PSR-S910/S710 Owner’s Manual
Songs – Playing, Practice and Recording Songs –
3
4Press the SONG [F/II] (PLAY/PAUSE) button to start playback.
5Press the SONG [■] (STOP) button to stop playback.
• Synchro Start
You can start playback as soon as you start playing the keyboard. While
playback is stopped, hold down the SONG [■] (STOP) button and press the
[F/II] (PLAY/PAUSE) button.
To cancel the Synchro Start function, hold down the SONG [■] (STOP)
button and press the [F/II] (PLAY/PAUSE) button once again.
• Pause
Press the [F/II] (PLAY/PAUSE) button. Pressing it again resumes Song
playback from the current position.
Queuing the next Song for playback
While a Song is playing back, you can queue up the next Song for playback.
This is convenient for chaining it to the next Song smoothly during stage
performance. Select the Song you want play next in the Song Selection
display, while a Song is playing back. The “NEXT” indication appears at the
upper right of the corresponding Song name. To cancel this setting, press the
[8▼] (NEXT CANCEL) button.
Operations During Playback
PSR-S910/S710 Owner’s Manual 51
Songs – Playing, Practice and Recording Songs –
3
• Rewind/Fast Forward
Press the [G] (REW) or [H] (FF) button once to move back/forward one
measure. Hold the [G] (REW) or [H] (FF) button to scroll backward/
forward continuously.
Pressing the [G] (REW) or [H] (FF) button calls up a pop-up window
showing the current measure number (or Phrase Mark number) in the display.
While the Song Position pop-up is shown on the display, you can also use the
[DATA ENTRY] dial to adjust the value.
• Adjusting the Tempo
Same procedure as with Style tempo. See page 43.
• Fading In/Out
Same procedure as with Style. See page 44.
NOTE
Phrase Mark is a pre-programmed
marker in a certain Song data, which
specifies a certain location in the
Song.
For Songs containing Phrase Marks
You can switch between BAR and PHRASE MARK by pressing the [E] button.
For Songs not containing Phrase Marks
NOTE
You can adjust the Song volume bal-
ance between the Song and Keyboard.
See page 48. In the Mixing Console
display, you can adjust the volume for
each Song part. See page 82.
NOTE
You can also turn the specific part(s)
on or off. See page 54.
NOTE
You can transpose the Song playback.
See page 34.
52 PSR-S910/S710 Owner’s Manual
Songs – Playing, Practice and Recording Songs –
3
You can view the music notation (score) of the selected Song. We suggest that you
read through the music notation before starting to practice.
1Select a Song (steps 1 – 3 on page 49).
2Press the [SCORE] button to call up the Score display.
You can look through the entire notation by using the TAB [E][F] buttons
when the Song playback is stopped.
As starting playback, the “ball” bounces along through the score, indicating the
current position.
You can change the displayed notation style by using the [1 ▲▼] – [8 ▲▼]
buttons. For details, refer to the Reference manual on the website.
Restrictions for protected Songs
Commercially available Song data may be copy protected to prevent illegal
copying or accidental erasure. They are marked by the indications at the
upper left side of the file names. The indications and relevant restrictions are
detailed below.
•Prot. 1: Indicates Preset Songs saved to the User drive. These cannot be
copied/moved/saved to external devices.
•Prot. 2 Orig: Indicates Yamaha-protection-formatted Songs. These cannot
be copied. These can be moved/saved only to the User drive and USB stor-
age devices with ID.
•Prot. 2 Edit: Indicates edited “Prot. 2 Orig” Songs. Make sure to save these
to the same folder containing the corresponding “Prot. 2 Orig” Song. These
cannot be copied. These can be moved/saved only to the User drive and USB
storage devices with ID.
Note for “Prot. 2 Orig” and “Prot. 2 Edit” Song file operation
Make sure to save the “Prot. 2 Edit” Song to the same folder containing its
original “Prot. 2 Orig” Song. Otherwise the “Prot. 2 Edit” Song cannot be
played back. Also, if you move a “Prot. 2 Edit” Song, be sure to move its
original “Prot. 2 Orig” Song to the same location (folder) at the same time.
For information about compatible USB storage devices for saving protected
Songs, visit the Yamaha website.
Displaying Music Notation (Score)
NOTE
The instrument can display the music
notation of commercially-available
music data or your recorded Songs.
NOTE
The displayed notation is generated
by the instrument based on the Song
data. As a result, it may not be exactly
the same as commercially available
sheet music of the same song —
especially when displaying notation
of complicated passages or many
short notes.
PSR-S910/S710 Owner’s Manual 53
Songs – Playing, Practice and Recording Songs –
3
When the selected Song contains lyric data, you can view it on the instrument’s
display during playback.
1Select a Song (steps 1 – 3 on page 49).
2Press the [LYRICS/ TEXT] button to call up the Lyrics display.
When the Song data contains lyrics data, the lyrics are shown on the display.
You can look through the entire lyrics by using the TAB [E][F] buttons when
the Song playback is stopped.
As Song playback starts, the color of the lyrics changes, indicating the current
position.
Even if the Song doesn’t contain lyrics data, you can view the lyrics on the display
by loading the text file (.txt) created on a computer via USB storage device. This
feature enables various useful possibilities, such as the showing of lyrics, chord
names, and text notes.
1When the Lyrics display is shown, press the [1 ▲▼] (TEXT)
button to display the text.
2Press the [5 ▲▼]/[6 ▲▼] (TEXT FILE) button to call up the Text
selection display.
3Select the desired text file.
To return to the Lyrics display, press the [1 ▲▼] (LYRICS) button again.
For more information about the Lyrics/Text display, refer to the Reference manual
on the website.
Displaying Lyrics (Text)
Displaying Text
NOTE
(PSR-S910) The Lyrics (text) can be
displayed on the external monitor. See
page 89.
54 PSR-S910/S710 Owner’s Manual
Songs – Playing, Practice and Recording Songs –
3
A Song consists of 16 separate channels. You can independently turn each channel of
the selected Song playback on or off.
1Press the [CHANNEL ON/OFF] button once or twice to call up
the CHANNEL ON/OFF (SONG) display.
2Use the [1 ▲▼] – [8 ▲▼] button to turn each channel on or off.
If you want to play back only one particular channel (solo playback), press and
hold down one of the [1 ▲▼] – [8 ▲▼] buttons corresponding to the desired
channel. Only the selected channel is turned to on and others are off. To cancel
solo playback, press the same button again.
The Guide function indicates the notes you should play, when you should play them,
and how long you should hold them down. You can also practice at your own pace —
since the accompaniment waits for you to play the notes correctly. Here, mute the
right-hand part and try practicing the part.
1Select a Song and call up the Score display (page 52).
2Turn the [GUIDE] button on.
3Press the SONG [TR 1] button to mute the right-hand part.
The indicator of the [TR 1] button goes out. You can now play that part by
yourself.
Turning Song Channels On/Off
Practicing the Right-hand Part (Guide Function)
2
23
NOTE
Usually, CH 1 is assigned to [TR 1]
button, CH 2 is assigned to [TR 2]
button, and CH 3 – 16 are assigned to
the [EXTRA TR] button.
PSR-S910/S710 Owner’s Manual 55
Songs – Playing, Practice and Recording Songs –
3
4Press the SONG [F/II] (PLAY/PAUSE) button to start playback.
Practice the muted part viewing the Score display.
After your practice, turn the [GUIDE] button off.
The Song Repeat functions can be used to repeatedly play back a Song or a specific
range of measures in a Song. This is useful for repeated practicing of difficult-to-
play phrases.
To repeat a Song, turn the [REPEAT] button on and playback the desired Song.
Turning the [REPEAT] button off cancels Repeat playback.
1Select a Song (steps 1 – 3 on page 49).
2Press the SONG [F/II] (PLAY/PAUSE) button to start playback.
3Specify the repeat range.
Press the [REPEAT] button at the starting point (A) of the range to be repeated.
Press the [REPEAT] button again at the ending point (B). After an automatic
lead-in (to help guide you into the phrase), the range from Point A to Point B is
played back repeatedly.
Other guide functions
There are additional functions in the Guide features, for practicing the tim-
ing of playing the keys (Any Key mode) or for Karaoke.
[FUNCTION] → [B] SONG SETTING → [A]/[B] GUIDE MODE
For more information, refer to the Reference Manual on the website.
Repeat Playback
NOTE
You can play multiple Songs repeat-
edly: [FUNCTION] → [B] SONG SET-
TING → [H] REPEAT MODE.
Specifying a Range of Measures and Playing them
Back Repeatedly (A-B Repeat)
NOTE
Specifying only Point A results in
repeat playback between Point A and
the end of the Song.
NOTE
When you want to repeat from the top
of the song to middle of the song:
1 Press the [REPEAT] button, then
start Song playback.
2 Press the [REPEAT] button again at
the ending point (B).
AB
Top of the song End of the song
56 PSR-S910/S710 Owner’s Manual
Songs – Playing, Practice and Recording Songs –
3
4To stop playback, press the SONG [■] (STOP) button.
The Song position will return to Point A.
5Press the [REPEAT] button to turn off Repeat playback.
You can record all parts of your performance at once or each part (right-hand, left-
hand and Style playback) independently. This is an effective practice tool, allowing
you to easily compare your own performance to the original song you are practicing.
Before starting recording, make the desired panel settings for your keyboard
performance — selecting a Voice, Style, etc.
1Press the SONG [REC] button and the [■] (STOP) button
simultaneously.
A blank Song for recording is automatically set.
2Press the SONG [REC] button.
3Start recording.
Recording begins automatically as soon as you play a note on the keyboard,
start Style playback or start Multi Pad playback.
Specifying the repeat range while Songs are stopped
1. Press the [H] (FF) button to advance to the Point A location.
2. Press the [REPEAT] button to specify Point A.
3. Press the [H] (FF) button to advance to the Point B location.
4. Press the [REPEAT] button again to specify Point B.
Recording Your Performance (Quick Recording)
Recording a specific part
In place of step 2, pressing the SONG [TR1] (or [TR2]) button while holding
the [REC] button enables you to record only the right-hand (or left-hand) part.
Pressing the [EXTRA TR] button while holding the [REC] button enables
recording of only Style playback.
NOTE
When recording without Style playback,
turning the [METRONOME] on makes
your recording sessions much more
efficient. The Metronome tempo can be
adjusted by TEMPO [-]/[+] buttons.
NOTE
For Quick Recording, each part will be
recorded to the following channels.
Keyboard parts: Ch. 1-3
Multi Pad parts: Ch. 5-8
Style parts: Ch. 9-16
PSR-S910/S710 Owner’s Manual 57
Songs – Playing, Practice and Recording Songs –
3
4Press the SONG [■] (STOP) button to stop recording.
A message prompting you to save the recorded performance appears. To close
the message, press the [EXIT] button.
5Press the SONG [F/II] (PLAY/PAUSE) button to play back the
recorded performance.
6Save the recorded performance as a Song.
Press the SONG [SELECT] button to call up the Song Selection display. The
recorded Song can be saved in the Song Selection display. Refer to “Saving
Files” on page 58 for instructions.
CAUTION
The recorded Song will be lost if
you change to another Song or
you turn the power off without
executing the save operation.
Multi Track Recording
A Song consists of 16 separate channels. With this method, you can record
data to each channel independently, one by one. You can also freely change
the channel/part assignments with the Multi Track recording.
The procedure is basically the same as that of “Recording Your Performance”
on page 56, with the following instructions substituted for step 2 above.
While holding down the SONG [REC] button, press the [1 ▲▼] – [8 ▲▼]
buttons to set the desired channels to “REC.” Then assign the desired
part to the channel by using the [C]/[D] buttons.
If you want to record the Right 1 part to channel 1, for example, press the
[1 ▲] button while holding down the [REC] button to set the channel 1 to
“REC.” Then use the [C]/[D] buttons to select “RIGHT 1.”
After proceeding with steps 3 – 5, re-select other channels and record other
parts as desired.
58 PSR-S910/S710 Owner’s Manual
Songs – Playing, Practice and Recording Songs –
3
This operation lets you save your original data (such as Songs you’ve recorded and
Voices you’ve edited) to a file. The explanations here apply when you save your
recorded performance as a Song file.
1In the Song selection display, select the appropriate tab (USER
or USB) to which you want to save the data by using the TAB
[EE
EE][FF
FF] buttons.
2Press the [6 ▼] (SAVE) button to call up the file naming display.
3Enter the file name (page 26).
Even if you skip this step, you can rename the file at any time after saving
(page 60).
4Press the [8 ▲] (OK) button to save the file.
The saved file will be automatically located at the appropriate position among
the files in alphabetical order.
Saving Files
2
1
NOTE
If you want to cancel the Save opera-
tion, press the [8 ▼] (CANCEL) but-
ton.
PSR-S910/S710 Owner’s Manual 59
Songs – Playing, Practice and Recording Songs –
3
If you’ve saved a lot of files to a USB flash memory or USER drive, it may be
difficult to find the desired file quickly. To make it easier to find the files you want,
you can organize your files in folders, rename the files, delete unnecessary files, etc.
These operations are done in the File Selection display.
This operation lets you create new folders. Folders can be created, named and
organized as desired, making it easier to find and select your original data.
1In the file selection display, select the appropriate tab (USER or
USB) to which you want to save the data by using the TAB
[EE
EE][FF
FF] buttons.
If you want to create a new folder within the existing folder, also select the
folder here.
2Press the [7 ▼] (FOLDER) button to call up the naming display
for a new folder.
3Input the name of the new folder (see page 26).
File Management
NOTE
A new folder cannot be made in the
PRESET tab.
Creating a New Folder
NOTE
The maximum number of files/folders
which can be stored in a folder is 250.
NOTE
In the USER tab display, folder direc-
tories can contain up to four levels.
The maximum total number of files/
folders which can be stored differs
depending on the file size and the
length of the file/folder names.
2
1
NOTE
The following marks cannot be
entered for a file/folder name.
¥ / : * ? " < > |
60 PSR-S910/S710 Owner’s Manual
Songs – Playing, Practice and Recording Songs –
3
This operation lets you rename files/folders.
1Call up the display containing the file/folder you want to rename.
2Press the [1 ▼] (NAME) button.
The pop-up window for the Rename operation appears at the bottom of the
display.
3Press one of the [A] – [J] buttons corresponding to the desired
file/folder.
4Press the [7 ▼] (OK) button to confirm the file/folder selection.
5Input the name (characters) of the selected file or folder
(page 26).
The renamed file/ folder appears on the display at the appropriate position
among the files in alphabetical order.
This operation lets you copy or cut a file and paste it to another location (folder).
You can also copy a folder (but not move it) by using the same procedure.
1Call up the display containing the file/folder you want to copy.
2Press the [3 ▼] (COPY) button to copy or [2 ▼] (CUT) to move.
The pop-up window for the Copy/Cut operation appears at the bottom of the
display.
3Press one of the [A] – [J] buttons corresponding to the desired
file/folder.
To cancel the selection, press the same [A] – [J] button again.
Press the [6 ▼] (ALL) button to select all files/folders indicated on the current
display including the other pages. To cancel the selection, press the [6 ▼] (ALL
OFF) button again.
Renaming Files/Folders
NOTE
Files in the PRESET tab cannot be
renamed.
NOTE
To cancel the Rename operation,
press the [8 ▼] (CANCEL) button.
Copying or Moving Files
NOTE
Files in the PRESET tab cannot be
moved. They can only be copied.
PSR-S910/S710 Owner’s Manual 61
Songs – Playing, Practice and Recording Songs –
3
4Press the [7 ▼] (OK) button to confirm the file/folder selection.
5Select the destination tab (USER or USB) to paste the file/folder,
by using the TAB [EE
EE][FF
FF] buttons.
If necessary, select the destination folder by using the [A] – [J] buttons.
6Press the [4 ▼] (PASTE) button to paste the file/folder selected
in step 3.
The pasted file/folder appears on the display at the appropriate position among
the files in alphabetical order.
This operation lets you delete a file/folder.
1Call up the display containing the file/folder you want to delete.
2Press the [5 ▼] (DELETE) button.
The pop-up window for the Delete operation appears at the bottom of the
display.
3Press one of the [A] – [J] buttons corresponding to the desired
file/ folder.
To cancel the selection, press the same [A] – [J] button again.
Press the [6 ▼] (ALL) button to select all files/folders indicated on the current
display including the other pages. To cancel the selection, press the [6 ▼] (ALL
OFF) button again.
4Press the [7 ▼] (OK) button to confirm the file/folder selection.
5Follow the on-display instructions.
• YES Delete the file/folder
• YES ALL Delete all selected files/folders
• NO Leave the file/folder as is without deleting
• CANCEL Cancel the Delete operation
NOTE
To cancel the Copy operation, press
the [8 ▼] (CANCEL) button.
Deleting Files/Folders
NOTE
Files in the PRESET tab cannot be
deleted.
NOTE
To cancel the Delete operation, press
the [8 ▼] (CANCEL) button.
62 PSR-S910/S710 Owner’s Manual
Songs – Playing, Practice and Recording Songs –
3
Advanced Features
Refer to the Reference Manual on the website, Chapter 3.
Editing Music Notation settings: [SCORE] → [1 ▲▼] – [8 ▲▼] buttons
Editing Lyrics/Text display settings: [LYRICS/TEXT] → [1 ▲▼] – [8 ▲▼] buttons
Using the Auto Accompaniment
Features with the Song Playback:
[ACMP] → STYLE CONTROL [SYNC
START] → SONG [■] + [F/II] → STYLE
CONTROL [START/STOP]
Song Playback related parameters: [FUNCTION] → [B] SONG SETTING
•Keyboard and Vocal Practice Using
the Guide Function: → [A]/[B] GUIDE MODE
• Playing Backing Parts with the Perfor-
mance Assistant Technology: → [8 ▲▼] P.A.T.
Creating/Editing Songs
(Song Creator):
[FUNCTION] → [F] DIGITAL REC MENU →
[A] SONG CREATOR
•Recording Melodies (Step Recording): → TAB [E][F] 1-16
• Recording Chords (Step Recording): → TAB [E][F] CHORD
• Re-Recording a Specific Section—
Punch In/Out: → TAB [E][F] REC MODE
• Editing Channel Events: → TAB [E][F] CHANNEL
• Editing Chord events, Notes, System
Exclusive events and Lyrics:
→ TAB [E][F] CHORD, 1-16, SYS/EX.
or LYRICS
4
Multi Pads – Adding Musical Phrases to Your Performance –
PSR-S910/S710 Owner’s Manual 63
Multi Pads
– Adding Musical Phrases to Your Performance –
The Multi Pads can be used to play a number of short pre-
recorded rhythmic and melodic sequences that can be used to
add impact and variety to your keyboard performances.
Multi Pads are grouped in Banks or four each. The PSR-S910/
S710 features a variety of Multi Pad Banks in a variety of
different musical genres.
1Press the MULTI PAD CONTROL [SELECT] button to call up the
Multi Pad Bank Selection display, then select the desired bank.
Select pages using the [1 ▲] – [7 ▲] buttons that correspond to “P1, P2...” in the
display or pressing the MULTI PAD CONTROL [SELECT] button repeatedly,
then use the [A] – [J] buttons to select the desired bank.
2Press any of the MULTI PAD CONTROL [1] – [4] buttons to play a
Multi Pad phrase.
The corresponding phrase (in this case, for Pad 1) starts playing back in its
entirety at the currently set tempo. You can even play two or more Multi Pads at
the same time.
3Press the [STOP] button to stop playback of the Multi Pad(s).
If you want to stop specific pads, simultaneously hold down the [STOP] button
and press the pad(s) you wish to stop.
Playing the Multi Pads
1
1
NOTE
There are two types of Multi Pad data.
Some types will play back once and
stop when they reach to the end. Oth-
ers will be play back repeatedly.
NOTE
Pressing the pad during its playback
will stop playing and begin playing
from the top again.
About the color of the Multi Pads
•Green: Indicates that the corresponding pad contains data (phrase).
•Red: Indicates that the corresponding pad is playing back.
•Red (flashing): Indicates that the corresponding pad is in standby (Syn-
chro Start).
3
64 PSR-S910/S710 Owner’s Manual
Multi Pads – Adding Musical Phrases to Your Performance –
4
While holding the MULTI PAD CONTROL [SELECT] button, press one of the
MULTI PAD CONTROL [1] – [4] buttons to put the Multi Pad playback in standby.
The corresponding button will flash in red. You can even play two, three, or four
Multi Pads at the same time.
The Multi Pad currently set to standby will start playing when you play back a Style,
press any note on the keyboard (when [ACMP] is off), or play a chord with your left
hand (when [ACMP] is on). If you put the Multi Pad in standby during Song/Style
playback, pressing any note on the keyboard will start the Multi Pad playback at the
top of next bar.
When two or more Multi Pads are in standby, pressing one of them simultaneously
starts all Multi Pads that are set to standby.
To cancel Synchro Start, while holding the MULTI PAD CONTROL [SELECT] (or
[STOP]) button, press one of the [1] – [4] buttons. Pressing the MULTI PAD
CONTROL [STOP] button once cancels Synchro Start of all buttons.
Many of the Multi Pad phrases are melodic or chordal and you can have these
phrases automatically change chords along with the chords you play with your left
hand. When the [ACMP] is on or LEFT part is on, simply play a chord with your left
hand and press any of the Multi Pads— Chord Match changes the pitch to match the
chords you play. Keep in mind that some Multi Pads are not affected by Chord
Match.
In this example, the phrase for Pad 1 will be transposed into F major before playing
back. Try out other various chord types while playing the Multi Pads.
Using the Multi Pad Synchro Start Function
Using Chord Match
Chord Section
Advanced Features
Refer to the Reference Manual on the website, Chapter 4.
Multi Pad creating (Multi Pad
Creator):
[FUNCTION] → [F] DIGITAL REC MENU → [C] MULTI
PAD CREATOR
Multi Pad editing: Multi Pad Bank Selection display → [8▼] (EDIT)
5
Music Finder – Calling Up Ideal Setups (Voice, Style, etc.) for Each Song –
PSR-S910/S710 Owner’s Manual 65
Music Finder
– Calling Up Ideal Setups (Voice, Style, etc.) for Each Song –
If you want to play in a certain genre of music but don’t know
which Style and Voice settings would be appropriate, the
convenient Music Finder function can help you out. Simply
select the desired music genre (or song title) from among the
Music Finder panel settings, and the instrument automatically
makes all appropriate panel settings to let you play in that music
style. Moreover, by registering the Song/Audio data saved in
various places into Music Finder, the instrument can easily call
up the relevant data from the song title. The Music Finder Plus
function gives you the added capability, by connecting the
instrument to the Internet, of searching for and adding desired
panel settings and song data via the Internet to the instrument.
NOTE
Before using a USB storage device, be
sure to read “Connecting a USB Stor-
age Device” on page 94.
CAUTION
Replacing automatically over-
writes all your records (panel
settings/song data shown in the
MUSIC FINDER display). Make
sure that all important data has
been saved to the USER or USB
in the File Section display (step
4 as described at left).
Loading panel settings from the website
As a factory default, some sample records (panel settings) are provided in the Music
Finder. By downloading many panel settings from Yamaha website and importing
them to the instrument, you can use the Music Finder function more conveniently and
effectively. Moreover, the Repertoire function (page 44) can also be enhanced by
importing the panel settings. Before using the Music Finder function, we recommend
that you load the panel settings from the website following the instructions below.
http://services.music.yamaha.com/musicfinder/
1Download the Music Finder panel settings file from the website
to the USB storage device.
2Connect the USB storage device which contains the panel
settings file to the [USB TO DEVICE] terminal of the instrument.
3Press the [MUSIC FINDER] button to call up the MUSIC FINDER
display.
4Press the [7 ▲▼] (FILES) button to call up the File Selection
display.
66 PSR-S910/S710 Owner’s Manual
Music Finder – Calling Up Ideal Setups (Voice, Style, etc.) for Each Song –
5
NOTE
Even after replacing the Music Finder
records, you can restore them to their
original factory settings by selecting
the “MusicFinderPreset” file in PRE-
SET display of the step.
5Use the TAB [E][F] buttons to call up the USB display containing
the panel settings file downloaded from the website.
6Press the button which corresponds to the file to display the
message for selecting REPLACE/APPEND of the panel settings.
7Press the [F] (REPLACE) button to delete all records currently in
the instrument and replace them with the records of the selected
file.
Press the [G] (YES) button at the confirmation prompt.
8Press the [F] (YES) button in the message display (indicating
completion of the replace operation) to call up the MUSIC
FINDER display.
By checking the number of records in the MUSIC FINDER display, you can
confirm the record has been replaced.
The number
of records
NOTE
For information on registering the
Song/Audio data to the Music Finder,
refer to page 68.
About the Music Finder Records
Each data which can be called up from the MUSIC FINDER display is called a
“record.” There are three following different records.
•Panel Settings
Setting data, such as Styles, Voices, etc.
• Song (SONG)
Song data which is registered to the Music Finder from the Song Selection display
(page 49)
•Audio (AUDIO)
Audio data which is registered to the Music Finder from the USB Audio Selection
display (page 75)
PSR-S910/S710 Owner’s Manual 67
Music Finder – Calling Up Ideal Setups (Voice, Style, etc.) for Each Song –
5
1Press the [MUSIC FINDER] button to call up the MUSIC FINDER
display.
In the ALL display, all the records are shown.
2Use the [2 ▲▼]/[3 ▲▼] buttons to select the desired Panel
Settings.
You can also use the [DATA ENTRY] dial and the [ENTER] button.
3Play the chords in the left-hand section (page 32) of the
keyboard.
You can search the records by specifying a song name or keyword, using the Search
function of the Music Finder.
1From the ALL page of the MUSIC FINDER display, press the [6
▲] (SEARCH 1) button to call up the Search display.
Selecting the Desired Song from among the Panel Settings
NOTE
Refer to page 70 for information on
selecting SONG and AUDIO records.
Sorting the records
Press [F] (SORT BY) button to sort the records by MUSIC, STYLE, BEAT
and TEMPO. Press the [G] (SORT ORDER) button to change the order of
the records (ascending or descending).
When sorting records by MUSIC, you can use the [1 ▲▼] button to skip up
or down through the songs alphabetically. When sorting records by STYLE,
you can use the [4 ▲▼]/[5 ▲▼] button to skip up or down through the
Styles alphabetically. Simultaneously press the [▲] and [▼] buttons to move
the cursor to the first record.
Shows the song title
and information of the
Style assigned to the
panel settings.
NOTE
If you want to avoid changing the
Tempo during Style playback when
selecting another record, turn on the
Tempo Lock function by pressing the
[I] (STYLE TEMPO) button in the
Music Finder display.
Searching the Panel Settings
68 PSR-S910/S710 Owner’s Manual
Music Finder – Calling Up Ideal Setups (Voice, Style, etc.) for Each Song –
5
2Enter the search criteria.
To cancel searching, press the [8 ▼] (CANCEL) button.
3Press the [8 ▲] (START SEARCH) button to start the search.
The Search 1 display appears, showing the results of the search.
By registering the Song/Audio data saved in various places (Song Selection display:
page 49; USB Audio Selection display: page 75) into Music Finder, the instrument
can call up song data easily from the song title.
1Display the Song data.
Song data (SONG) in the Song Selection display
Press the SONG [SELECT] button to display the song data (Song file) in the
Song Selection display.
NOTE
You can search several different Key-
words simultaneously by inserting a
separator (comma) between each.
NOTE
If you select a beat of 2/4 or 6/8, a
Style suitable for performing a song
in 2/4 and 6/8 beat can be searched,
but the actual Style is created by
using a 4/4 beat.
NOTE
When searching Song/Audio files
(page 66), it is necessary to set the
search criteria as follows.
STYLE: Blank
BEAT: ANY
TEMPO: “---” - “---”
[A] MUSIC Searches by song name. Pressing the [A] button calls
up the pop-up window to enter the song name. To clear
the entered Music, press the [F] (CLEAR) button.
[B] KEYWORD Searches by keyword. Pressing the [B] button calls
up the pop-up window to enter the keyword. To clear
the entered Keyword, press the [G] (CLEAR) button.
[C] STYLE Searches by Style. Pressing the [C] button calls up
the Style Selection display. After selecting the
desired Style, press the [EXIT] button to return back
to the Search display. To clear the entered Style,
press the [H] (CLEAR) button.
[D] BEAT Specifies the time signature for the search. All beat
settings are included in the search if you select ANY.
[E] SEARCH
AREA
Selects a specific location (the tab of the upper part of
the MUSIC FINDER display) for searching.
[1 ▲▼] ALL CLEAR Clears all entered search criteria.
[3 ▲▼] TEMPO FROM Sets the range of the tempo you want to use for the
search.
[4 ▲▼] TEMPO TO
[5 ▲▼]/
[6 ▲▼]
GENRE Selects the desired music genre.
NOTE
If you wish to search another criteria,
press the [6 ▼] (SEARCH 2) button
in the Music Finder display. The
search result is displayed in the
SEARCH 2 display.
Registering the Song/Audio data (SONG/AUDIO)
NOTE
If you want to register the Song/Audio
data of the USB storage device, con-
nect the USB storage device contain-
ing the data to the [USB TO DEVICE]
terminal.
NOTE
Before using a USB storage device, be
sure to read “Connecting a USB Stor-
age Device” on page 94.
PSR-S910/S710 Owner’s Manual 69
Music Finder – Calling Up Ideal Setups (Voice, Style, etc.) for Each Song –
5
Song data (AUDIO) in the USB Audio Selection display
1-1 Press the [USB] button to call up the Playback display (AUDIO PLAYER
display).
1-2 Press the [8 ▲▼] (FILE SELECT) button to display the song data (Audio
file) in the connected USB storage device.
2Press the [A] – [J] buttons corresponding to the desired file.
3Press the [6 ▲] (ADD TO MF) button to register the selected data
to Music Finder.
The display automatically changes to the Music Finder Record Edit display.
4Press [8 ▲] (OK) button to start the registration.
Press the [8 ▼] (CANCEL) button to cancel the registration.
5Check the song data (SONG/AUDIO) is added in the MUSIC
FINDER display.
The song data is shown as SONG or AUDIO in the STYLE column.
3
70 PSR-S910/S710 Owner’s Manual
Music Finder – Calling Up Ideal Setups (Voice, Style, etc.) for Each Song –
5
You can recall the registered song data in the same way as done in the “Selecting the
Desired Song from among the Panel Settings” and “Searching the Panel Settings”
(page 67).
•To play back the recalled Song data, press the SONG [F/II] button after selecting
the SONG record.
•To play back the recalled audio data, press the [USB] button, then press the [2
▲▼] (F/II) button after selecting the AUDIO record.
NOTE
If you want to play back Song/Audio
data in the USB storage device, con-
nect the USB storage device contain-
ing the data to the [USB TO DEVICE]
terminal beforehand.
Recalling the registered song data from Music Finder
NOTE
The available contents of the Music
Finder Plus service are subject to
change.
Added convenience using the Internet (Music Finder+)
This service gives you the capability, by connecting the instrument to the Internet,
of searching for and adding desired panel settings and song data via the Internet to
the instrument. Let’s connect the instrument to the Internet, and press the [J]
(MUSIC FINDER+) button on the MUSIC FINDER display!
For more details about this service, refer to the following website.
http://services.music.yamaha.com/musicfinder/
Advanced Features
Refer to the Reference Manual on the website, Chapter 5.
Creating a Set of Favorite Records: [MUSIC FINDER] → TAB [E][F] ALL →
[H] (ADD TO FAVORITE)
Editing Records: [MUSIC FINDER] → [8 ▲▼] (RECORD
EDIT)
Saving the Record as a Single File: [MUSIC FINDER] → [7 ▲▼] (FILES)
Viewing Record Information on the
Internet (MUSIC FINDER Plus): [MUSIC FINDER] → [J] (MUSIC FINDER +)
6
Registration Memory – Saving and Recalling Custom Panel Setups –
PSR-S910/S710 Owner’s Manual 71
Registration Memory
– Saving and Recalling Custom Panel Setups –
The Registration Memory function allows you to save (or
“register”) virtually all panel settings to a Registration Memory
button, and then instantly recall your custom panel settings by
simply pressing a single button. The registered settings for eight
Registration Memory buttons should be saved as a single Bank
(file).
1Set up the panel controls (such as Voice, Style, effects, and so
on) as desired.
2Press the [MEMORY] button in the REGISTRATION MEMORY
section.
The display for selecting the items to be registered appears.
3Determine the items you want to register.
Select the desired item by using the [2▲▼] – [7▲▼] buttons, then enter or
remove the checkmark by using the [8▲] (MARK ON)/ [8▼] (MARK OFF)
buttons.
To cancel the operation, press the [I] (CANCEL) button.
Registering Your Panel Setups
3
72 PSR-S910/S710 Owner’s Manual
Registration Memory – Saving and Recalling Custom Panel Setups –
6
4Press one of the REGISTRATION MEMORY [1] – [8] buttons to
which you wish to memorize the panel setup.
The memorized button becomes red, which indicates the number button
contains data and its number is selected.
5Register various panel setups to other buttons by repeating
steps 1 – 4.
The registered panel setups can be recalled by simply pressing the desired
number button.
You can save all the eight registered panel setups as a single Registration Memory
Bank file.
1Press the REGIST BANK [+] and [-] buttons simultaneously to
call up the Registration Bank Selection Display.
2Press the [6▼] (SAVE) button to save the Bank file.
For instructions on saving, refer to page 58.
CAUTION
If you select the button whose
lamp is lit in red or green here,
the panel setup previously
memorized to the button will be
erased and replaced by the new
settings.
About the lamp status
•Red: Data registered and currently selected
•Green: Data registered but not currently selected
•Off: No data registered
NOTE
The panel setups registered in the
numbered buttons are preserved even
when you turn off the power. If you
want to delete all the eight current
panel setups, turn the [STANDBY/ON]
button on while holding the B5 key
(right-most B key on the keyboard).
Saving the Registration Memory as a Bank file
Bank 01
Bank 02
Bank 03
Bank 04
2
PSR-S910/S710 Owner’s Manual 73
Registration Memory – Saving and Recalling Custom Panel Setups –
6
The saved Registration Memory Bank files can be recalled by using the REGIST
BANK [-]/[+] buttons or the following procedure.
1Press the REGIST BANK [+] and [-] buttons simultaneously to
call up the REGISTRATION BANK Selection Display.
2Press one of the [A] – [J] buttons to select a Bank.
You can also use the [DATA ENTRY] dial and the [ENTER] button to select a
Bank.
3Press one of the green-lit numbered buttons ([1] – [8]) in the
Registration Memory section.
Recalling a Registered Panel Setup
NOTE
When recalling the setups including
Song/Style file selection from a USB
storage device, make sure that the
appropriate USB storage device
including the registered Song/Style is
connected into the [USB TO DEVICE]
terminal.
NOTE
Turning the [FREEZE] button on dis-
ables recall of specific item(s). To use
this function, you need to select the
item(s) not to be recalled by access-
ing [FUNCTION] → [E] REGIST
SEQUENCE/FREEZE/VOICE SET →
TAB [E][F] FREEZE.
2
2
74 PSR-S910/S710 Owner’s Manual
Registration Memory – Saving and Recalling Custom Panel Setups –
6
You can call up the information display to take a look which Voices and Style are
memorized to the [1] – [8] buttons of a Registration Memory Bank.
1Simultaneously press the REGIST BANK [+] and [-] buttons to
call up the Registration Bank Selection display, then use the
[A] – [J] buttons to select the desired Bank.
2Press the [7▲] (INFO.) button to call up the information display.
By using the TAB [E][F] buttons, you can switch between the two information
display pages: information for the Registration Memory [1] – [4] buttons and
information for the [5] – [8] buttons.
3Press the [F] (CLOSE) button to close the information display.
Confirming the Registration Memory Information
NOTE
You can instantly call up the informa-
tion display of the currently selected
Registration Memory Bank by press-
ing the [DIRECT ACCESS] button and
one of the REGISTRATION MEMORY
[1] – [8] buttons in sequence.
3
2
NOTE
If some Voice part is set to off (PSR-
S910), the Voice name for corre-
sponding part is shown in gray.
(On the PSR-S710, the Voice part
name for corresponding part is shown
in gray.)
Advanced Features
Refer to the Reference Manual on the website, Chapter 6.
Disabling recall of specific
items:
[FUNCTION] → [E] REGIST SEQUENCE/FREEZE/
VOICE SET → TAB [E][F] FREEZE
Calling up Registration
Memory numbers in order:
[FUNCTION] → [E] REGIST SEQUENCE/FREEZE/
VOICE SET → TAB [E][F] REGISTRATION SEQUENCE
7
USB Audio – Playback and Recording Audio Files –
PSR-S910/S710 Owner’s Manual 75
USB Audio
– Playback and Recording Audio Files –
The convenient USB Audio function allows you to play back
audio files (WAV or MP3) stored to a USB flash memory
device—directly from the instrument. Moreover, since you can
record your performances and recordings as audio data (.WAV)
to a USB flash memory device, it is possible to play back the
files on computer, share them with your friends, and record your
own CDs to enjoy as well.
Try playing back audio files from USB flash memory on this instrument.
File formats that can be played back
Connect the USB flash memory device containing the audio files to play back to the
[USB TO DEVICE] terminal.
1Press the [USB] button to call up the Playback display (AUDIO
PLAYER display).
2Press the [8 ▲▼] (FILE SELECT) button to display the audio
files saved to the connected USB flash memory.
3Press one of the [A] – [J] buttons corresponding to the file you
want to listen to.
Playing Back Audio Files
NOTE
The instrument cannot be play back
DRM protected files.
.wav 44.1 kHz sample rate, 16 bit resolution, stereo PSR-S910
PSR-S710
.mp3 44.1/48.0 kHz sample rate, 64-320 kbps and variable bit
rate, mono/stereo
PSR-S910
NOTE
Before using a USB flash memory, be
sure to read “Connecting a USB Stor-
age Device” on page 94.
2
76 PSR-S910/S710 Owner’s Manual
USB Audio – Playback and Recording Audio Files –
7
4Press the [EXIT] button to return to the Playback display (AUDIO
PLAYER display).
5Press the [2 ▲▼](F/II) button to play back.
You can stop, pause, select, rewind, and forward by using the [1 ▲▼] – [6 ▲▼]
buttons. Moreover, you can set the REPEAT mode by pressing the [7 ▲] button and
adjust the volume by pressing the [7 ▼] button.
• Playing back audio files repeatedly
Press the [7 ▲] (REPEAT) button then set the REPEAT mode of the audio file by
using the [7 ▲▼] buttons. To close the setting display, press the [8 ▲▼] (CLOSE)
button.
OFF Plays through the selected file, then stops.
SINGLE Plays through the selected file repeatedly.
ALL Continues playback through all the files in the folder containing the cur-
rent file repeatedly.
RANDOM Randomly and repeatedly plays back all files in the folder containing
the current file.
CAUTION
Never attempt to disconnect the
USB flash memory or turn the
power off during playback.
Doing so may corrupt the USB
flash memory data.
Playback-related Operations
PSR-S910/S710 Owner’s Manual 77
USB Audio – Playback and Recording Audio Files –
7
• Adjusting volume for audio playback
Press the [7 ▼] (VOL.) button then adjust the volume for audio files by using the
[7 ▲▼] buttons. To close the setting display, press the [8 ▲▼] (CLOSE) button.
Try recording your performance as audio data (WAV file) to a USB flash memory.
For example, when using the PSR-S910, you can record an ensemble performance of
guitar and keyboard together or record yourself singing along with song playback by
connecting a guitar, microphone or other device to the instrument. The maximum
amount of recording time is 80 minutes per recording, though this may differ
depending on the capacity of the particular USB flash memory.
The following sounds can be recorded.
• Internal tone generator of the instrument.
Keyboard parts (Right 1, Right 2, Left), Song parts, Style parts, Multi Pad parts
• (PSR-S910) Input from a microphone, guitar or other instrument (via the [MIC/
LINE IN] jack).
•(PSR-S910) Input from another audio device, such as a CD player, MP3 player or
the like (via the [MIC/LINE IN] jack).
The recorded data using this function is saved as:
•Stereo WAV data
• 44.1 kHz sample rate/16 bit resolution
1Connect the USB flash memory to the [USB TO DEVICE]
terminal.
2Set the desired Voice, etc. which you want to use for your
performance. (For information setting the Voice, see page 29; for
setting the Style, see page 39; for connecting a microphone on
the PSR-S910, see page 90.)
3Press the [USB] button.
Recording Your Performance as Audio
NOTE
To record your performance by USB
Audio function, use the compatible
USB flash memory. Before using a
USB flash memory, be sure to read
“Connecting a USB Storage Device”
on page 94.
NOTE
Input from the [AUX IN] jacks cannot
be recorded.
NOTE
Songs protected by copyright, such
as preset songs, and the metronome
sound cannot be recorded.
NOTE
Recording methods on the instrument
include MIDI recording as well as
audio recording (page 56).
78 PSR-S910/S710 Owner’s Manual
USB Audio – Playback and Recording Audio Files –
7
4Press the [E] (RECORDER) button to call up the Recording
display (USB AUDIO RECORDER display).
5Start recording by pressing the [J] (REC) button, then start your
performance.
When recording begins, the elapsed recording time is shown on the right side of
the Recording display.
6Stop recording by pressing the [J] (STOP) button.
The file name is automatically named, and a message indicating the file name is
displayed.
NOTE
The USB storage device of “USB1” is
selected as the recording destination
when multiple USB storage devices
are connected. The destination is
skipped when “USB1” is a floppy disk
drive.
Check the information of the USB flash memory as a recording
destination
On the display of step 4, press the [E] (PROPERTY) button to check the
number of the USB flash memory device, memory size of the device, avail-
able recording space on the device, and available time for recording.
Press the [F] (OK)/[EXIT] button to close the PROPERTY display.
CAUTION
Never attempt to disconnect the
USB flash memory or turn the
power off during playback.
Doing so may corrupt the USB
flash memory data or the
recording data.
NOTE
Even if you make a mistake in your
performance, you cannot overwrite an
existing file. Delete the recorded file
on the File Selection display, then
record your performance again.
NOTE
The recording operation continues,
even if you close the Recording dis-
play by pushing the [EXIT] button.
Press the [E] (RECORDER) button to
call up the Recording display again,
then stop the recording by pressing
the [J] (STOP) button.
8
Mixing Console – Editing the Volume and Tonal Balance –
PSR-S910/S710 Owner’s Manual 79
Mixing Console
– Editing the Volume and Tonal Balance –
The Mixing Console gives you intuitive control over aspects of
the keyboard parts and Song/Style channels, including volume
balance and the timbre of the sounds. It lets you adjust the levels
and stereo position (pan) of each Voice to set the optimum
balance and stereo image, and lets you set how the effects are
applied.
1Press the [MIXING CONSOLE] button to call up the MIXING
CONSOLE display.
2Use the TAB [EE
EE][F] buttons to call up the desired page.
For details about each display Page, refer to the Reference Manual on the
website.
• VOL/VOICE
Changes the Voice for each part and adjusts panning and volume for each part
(page 81). Using the Auto Revoice function, you can also convert the sound of
commercially available XG song to the special sound using this instrument’s
special Voices.
• FILTER
Adjusts the Harmonic Content (resonance) and sound brightness.
• TUNE
Pitch-related settings (tuning, transpose, etc.).
• EFFECT
Selects effect type and adjusts its depth for each part (page 83).
• EQ
Adjusts equalization parameters to correct the tone or timbre of the sound.
Basic Procedure
2
80 PSR-S910/S710 Owner’s Manual
Mixing Console – Editing the Volume and Tonal Balance –
8
3Press the [MIXING CONSOLE] button repeatedly to call up the
MIXING CONSOLE display for the relevant parts.
The part name is indicated at the top of the display.
4Use the [A] – [J] buttons to select a parameter, then use the
[1 ▲▼] – [8 ▲▼] buttons to set the value for each part.
5Save your MIXING CONSOLE settings.
NOTE
The Style/Song part components are
the same as those that appear in the
display when you press the panel
[CHANNEL ON/OFF] button once or
twice.
PANEL PART
STYLE PART
SONG CH 1-8
SONG CH 9-16
Song, Style, Multi Pad, MIC (only PSR-S910),
Keyboard parts (Left, Right 1, 2)
Rhythm 1, 2, Bass, Chord 1, 2, Pad, Phrase 1, 2
Song channels 1 – 8
Song channels 9 – 16
NOTE
If you simultaneously hold down one
of the [A] – [J] buttons and use the [1
▲▼] – [8 ▲▼] buttons (or the
DATA ENTRY dial), you can instantly
set the same value to all other parts.
•To save the PANEL PART display settings:
Register them to Registration Memory (page 71).
•To save the STYLE PART display settings:
Save them as Style data.
1. Call up the operation display.
[FUNCTION] → [F] DIGITAL REC MENU →
[B] STYLE CREATOR
2. Press the [EXIT] button to close the REC CHANNEL display.
3. Press the [I] (SAVE) button to call up the Style Selection display for
saving your data, then save it (page 58).
•To save the SONG CH 1-8/9-16 display settings:
First register the edited settings as part of the Song data (SETUP), then
save the Song.
1. Call up the operation display.
[FUNCTION] → [F] DIGITAL REC MENU →
[A] SONG CREATOR
2. Use the TAB [EE
EE][FF
FF] buttons to select the CHANNEL Page.
3. Use the [A]/[B] buttons to select “SETUP.”
4. Press the [D] (EXECUTE) button.
5. Press the [I] button to call up the Song Selection display for saving
your data, then save it (page 58).
PSR-S910/S710 Owner’s Manual 81
Mixing Console – Editing the Volume and Tonal Balance –
8
You can change the Voice and adjust panning and volume for each keyboard part,
Style channel or Song channel.
1Same operation as in the “Basic Procedure” on page 79. In step
2, select VOL/VOICE tab.
2Press the [C] (or [H]) button to select the VOICE parameter.
3Press one of the [1 ▲▼] – [8 ▲▼] buttons to select the desired
part.
The Voice Selection display appears.
4Select a Voice.
Press one of the Voice category selection buttons on the panel, then select a
Voice by using the [A] – [J] buttons (page 29).
5Press the [EXIT] button to return to the MIXING CONSOLE
display.
6Save your settings (step 5 on page 80).
Changing Voices and Adjusting Panning/Volume for Each Part
Changing the Voice for each part
22
3
NOTE
• Some Voices (such as Organ
Flutes) cannot be selected for Style
channels.
• The RHY2 channel in the STYLE
PART display can only be assigned
Drum kit Voices and SFX kit
Voices.
• When playing GM Song data, chan-
nel 10 can only be used for a Drum
kit Voice.
82 PSR-S910/S710 Owner’s Manual
Mixing Console – Editing the Volume and Tonal Balance –
8
1Same operation as in the “Basic Procedure” on page 79. In step
2, select VOL/VOICE tab.
2Press the [D] (or [I]) button to select the PANPOT parameter or
press the [E] (or [J]) button to select the VOLUME parameter.
3Use the [1 ▲▼] – [8 ▲▼] buttons to adjust panning/volume for
the desired part.
4Save your settings (step 5 on page 80).
Adjusting Panning/Volume for each part
3
2
PANPOT
VOLUME
PSR-S910/S710 Owner’s Manual 83
Mixing Console – Editing the Volume and Tonal Balance –
8
1Same operation as in the “Basic Procedure” on page 79. In step
2, select EFFECT tab.
2Use the [C]/[D]/[E] buttons to select the desired effect.
• REVERB:
Reproduce the warm ambience of playing in a concert hall or jazz club.
• CHORUS:
Produces a rich “fat” sound as if several parts are being played
simultaneously.
• DSP:
By default, the most appropriate effect for the selected Voice has been
selected.
3Use the [1 ▲▼] – [8 ▲▼] buttons to adjust the depth of each
effect for the desired part.
4Save your settings (step 5 on page 80).
Applying Effects to Each Part
NOTE
You can change the effect type by
pressing the [F] (TYPE) button. Refer
to the Reference Manual.
Advanced Features
Refer to the Reference Manual on the website, Chapter 8.
Converting XG Song Voice to this instru-
ment’s Voice (Song Auto Revoice):
[MIXING CONSOLE] → TAB [E][F] VOL/
VOICE → [G] SET UP
Editing FILTER parameters: [MIXING CONSOLE] → TAB [E][F] FILTER
Editing TUNE parameters: [MIXING CONSOLE] → TAB [E][F] TUNE
Changing an Effect type: [MIXING CONSOLE] → TAB [E][F]
EFFECT → [F] TYPE
Editing EQ parameters:
[MIXING CONSOLE]
→
TAB [
E][F
] EQ
9
84 PSR-S910/S710 Owner’s Manual
Internet Direct Connection – Connecting the PSR-S910/S710 Directly to the Internet –
Internet Direct Connection
– Connecting the PSR-S910/S710 Directly to the Internet –
You can purchase and download Song data and other types of
data from the special website by directly connecting to the
Internet. This section provides the overview of the Internet Direct
Connection. For specific instructions on connecting and Internet-
related terms, refer to the Internet Connection Guide, which can
be downloaded from the Yamaha Manual Library website.
Press the [INTERNET] button. If the instrument is connected to the Internet, the
special website appears on the display. If it is not connected, first connect by
referring to the section “Connecting the Instrument to the Internet” below.
To quit the Internet Direct Connection function and return to the operation display of
the instrument, press the [EXIT] button.
You can connect the instrument to a full-time online connection (ADSL, optical fiber,
cable Internet, etc.) via a router or a modem equipped with a router. (To use the
Internet connection, you will first need to subscribe to an Internet service or provider.)
Use a computer to connect to the Internet and get online before connecting the
instrument, since no modem or router settings can be made from the instrument itself.
The setting procedure differs depending on your connecting environment (devices
for connection, etc.). For more information, refer to the Internet Connection Guide.
Entering the Internet Direct Connection Function
NOTE
Only the special website can be
opened when the instrument is
directly connected to the Internet.
Connecting the Instrument to the Internet
NOTE
Depending on the Internet connec-
tion, the number of connectable
devices may be limited. This may
mean that your instrument cannot be
connected to the Internet. If in doubt,
check your contract or contact your
provider.
Viewing the Internet Connection Guide
You can view the Internet Connection Guide on the computer’s browser.
(The computer must be connected to the internet.)
1. Access the Manual Library website on the computer browser.
Click “Manual Library” from the menu of included CD-ROM, or enter
the following URL directly.
http://www.yamaha.co.jp/manual/
2. Enter your model name (PSR-S910, for example) in the Model Name
area, then click “Search.”
3. Click “Internet Connection Guide” from Search Results.
PSR-S910/S710 Owner’s Manual 85
Internet Direct Connection – Connecting the PSR-S910/S710 Directly to the Internet –
9
• Connection example 1:
Connecting by cable (using a LAN cable)
• Connection example 2:
Wireless connection (using a wireless LAN Ethernet Converter)
• Connection example 3:
Wireless connection (using a USB wireless LAN adaptor)
Connection Examples
IMPORTANT
Due to EU/Korea regulations,
users within Europe and Korea
should use an STP (shielded
twisted pair) cable to prevent
electromagnetic interference.
NOTE
Some types of modems require an
optional hub network for simulta-
neously connecting to several devices
(such as computer, musical instru-
ment, etc.).
NOTE
When you are using a modem with
router, connect the instrument to the
modem by LAN cable.
Modem*
No router capability
Router
Cable type
LAN cable
LAN cable
*Here, “modem” refers to an ADSL modem, optical network unit (ONU) or
cable modem.
LAN
terminal
Access point
Modem*
Wireless LAN
Ethernet Converter LAN
terminal
*Here, “modem” refers to an ADSL modem, optical network unit (ONU) or
cable modem.
Access point
Modem*
USB Wireless
LAN Adaptor
USB TO DEVICE
terminal
*Here, “modem” refers to an ADSL modem, optical network unit (ONU) or
cable modem.
86 PSR-S910/S710 Owner’s Manual
Internet Direct Connection – Connecting the PSR-S910/S710 Directly to the Internet –
9
After connecting the instrument to the internet, use these operations to take
advantage of Internet services directly from the instrument.
By using the [DATA ENTRY] dial and [ENTER] button, you can follow links and
navigate through the website. You can also use the [6 ▼]/[7 ▲▼]/[8 ▼] buttons and
the [8 ▲] (ENTER) button instead of the [DATA ENTRY] dial and [ENTER] button.
Use the [1 ▲▼] (BACK)/[2 ▲▼] (FORWARD) buttons to navigate through
previously selected web pages. To return to the top page of the special website, press
the [3 ▲▼] (HOME) button.
Press the [5 ▲] (REFRESH) button to reload a web page and press the [6 ▲]
(STOP) to cancel loading.
Operations in the Special Website
Following Links
Return to the Previous Web Page/Refreshing a Web Page
PSR-S910/S710 Owner’s Manual 87
Internet Direct Connection – Connecting the PSR-S910/S710 Directly to the Internet –
9
NOTE
SSL (Secure Sockets Layer) is an
industry-standard method for protect-
ing web communications by using
data encryption and other tools.
Monitoring the Internet Connection Status
The messages and icons at the bottom right of the Internet display indicate
the current Internet connection status.
The following three messages are displayed according to the loading status
of the web page.
Disconnected.: This appears when the instrument is not connected with the
Internet. When this message is displayed, the web page cannot be seen. Icon
1 is displayed.
Now opening web page...: The web page is being loaded. Icon 2 flashes.
Web page has been displayed.: Loading of the web page is completed, and
the page is displayed completely. Icon 2 stops flashing. When the displayed
web page uses SSL, icon 3 is displayed, and information is encrypted for
communication.
Strength of the reception is displayed in 4 when connecting to the Internet
by wireless LAN. When reception is weak, move the instrument near the
access point to improve reception.
Advanced Features
Refer to the Reference Manual on the website, Chapter 9.
Editing the Browser settings: [INTERNET] → [5 ▼] SETTING → [D]
BROWSER SETTINGS
Registering bookmarks of your favorite
pages:
[INTERNET] → [4 ▲▼] BOOKMARK → [3
▲▼] ADD
134
2
Message
10
88 PSR-S910/S710 Owner’s Manual
Connections – Using Your Instrument with Other Devices –
Connections
– Using Your Instrument with Other Devices –
Before connecting the instrument to other electronic components, turn off the power of all the
components. Also, before turning any components on or off, make sure to set all volume
levels to minimum (0). Otherwise, electrical shock or damage to the components may occur.
You can connect a stereo system to amplify the instrument’s sound by using the
OUTPUT [L/L+R]/[R] jacks. When using the PSR-S910, the microphone or guitar
sound connected to the instrument’s [MIC/LINE IN] jack is output at the same time.
When these are connected, you can use the instrument’s [MASTER VOLUME]
control to adjust the volume of the sound output to the external device.
You can connect the output jacks of an external device (such as CD player, tone
generator, etc.) to the instrument’s AUX IN [L/L+R]/[R] jacks, letting you hear the
sound of that device through the built-in speakers of the instrument.
Connecting Audio Devices
NOTE
Use only the [L/L+R] jack for connec-
tion with a monaural device.
CAUTION
When the instrument’s sound is
output to an external device,
first turn on the power to the
instrument, then to the external
device. Reverse this order when
you turn the power off.
CAUTION
Do not route the output from the
[OUTPUT] jacks to the [AUX IN]
jacks. If you make this connec-
tion, the signal input at the
[AUX IN] jacks is output from
the [OUTPUT] jacks. These con-
nections could result in a feed-
back loop that will make normal
performance impossible, and
may even damage both pieces
of equipment.
CAUTION
When the sound of an external
device is output to the instru-
ment, first turn on the power to
the external device, then to the
instrument. Reverse this order
when you turn the power off.
NOTE
Use only the [L/L+R] jack for connec-
tion with a monaural device.
NOTE
The instrument’s [MASTER VOL-
UME] setting affects the input signal
from the [AUX IN] jacks.
Using External Audio Devices for Playback
Playing External Audio Devices with the Built-in Speakers
Phone plug
(standard)
Audio cable
Phone plug
(standard)
Input jack
Powered speaker
Phone plug
(standard)
Audio cable
Pin plug
LINE OUT
CD player,
Tone generator
CAUTION
NOTE
Use audio cables and adaptor plugs
having no (zero) resistance.
PSR-S910/S710 Owner’s Manual 89
Connections – Using Your Instrument with Other Devices –
10
Connect the instrument to an external TV monitor, and you can have the current
display contents, lyrics (for group sing-alongs and the like, or text files) displayed on
the TV.
1Call up the operation display.
[FUNCTION] → [J] UTILITY → TAB [E][F] SCREEN OUT
2Set the monitor type and screen contents.
Connecting a Separate TV Monitor
CAUTION
Avoid looking at the television
or video monitor for prolonged
periods of time since doing so
could damage your eyesight.
Take frequent breaks and focus
your eyes on distant objects to
avoid eyestrain.
Screen Out Settings
1[1 ▲▼]/
[2 ▲▼]
MONITOR
TYPE
Selects the desired output monitor type (NTSC
or PAL) to correspond to the standard used by
your video equipment.
2[3 ▲▼]/
[4 ▲▼]
SCREEN
CONTENT
Determines the contents of the Video Out signal.
LYRICS/TEXT: Only the lyrics of the Song or
text files are output, regardless of the display
that is called up on the instrument.
LCD: The currently selected display is output.
RCA pin plug VIDEO IN
VIDEO OUT
1 2
90 PSR-S910/S710 Owner’s Manual
Connections – Using Your Instrument with Other Devices –
10
By connecting a microphone or guitar to the [MIC/LINE IN] jack (standard 1/4"
phone jack), you can enjoy singing along with your own performance or playing
guitar along with Song playback. The instrument outputs your vocals or guitar
sounds through the built-in speakers. The following instructions show how to
connect a microphone. Please note that when connecting a guitar or other devices of
high output level, make sure to set the [LINE MIC] switch to “LINE.”
1Set the [INPUT VOLUME] knob to the minimum position.
2Connect the microphone to the [MIC/LINE IN] jack.
3Set the [LINE MIC] switch to “MIC.”
4(For microphones having a power source, turn on the power
first.) Adjust the [INPUT VOLUME] knob while singing into the
microphone.
Adjust the control while checking the SIGNAL lamp. Make sure to adjust the
control so the lamp lights in green or orange. Make sure that the lamp does not
light in red, since this indicates that the input level is too high.
Connecting a Microphone or Guitar
NOTE
Make sure you have a conventional
dynamic microphone.
NOTE
Always set the INPUT VOLUME to
minimum when nothing is connected
to the [MIC/LINE IN] jack. Since the
[MIC/LINE IN] jack is highly sensi-
tive, it may pick up and produce noise
even when nothing is connected.
3
Make sure lamp does
not light in red.
NOTE
Set the [INPUT VOLUME] knob to the
minimum position before turning off
the power.
Disconnecting the microphone
1. Set the [INPUT VOLUME] knob to the minimum position.
2. Disconnect the microphone from the [MIC/LINE IN] jack.
PSR-S910/S710 Owner’s Manual 91
Connections – Using Your Instrument with Other Devices –
10
You can also apply various effects to your voice.
1Press the [MIC SETTING/VOCAL HARMONY] button to call up
the Mic Setting display.
2Use the [2 ▲▼] – [7 ▲▼] buttons to turn the effect on/off.
You can also automatically apply various harmony vocals to your voice.
1Press the [MIC SETTING/VOCAL HARMONY] button to call up
the harmony vocals (Vocal Harmony) Setting display.
2Press the [6 ▲]/[7 ▲] buttons to turn the harmony vocals (Vocal
Harmony) on.
Applying Effects to Your Voice
[2 ▲▼]/
[3 ▲▼]
TALK Turning TALK on lets you temporarily cancel
the microphone effects or vocal harmony. This is
especially useful when you talk between songs
during a performance.
[4 ▲▼]/
[5 ▲▼]
MIC EFFECT Turning MIC EFFECT on applies an effect to
your voice. The effect type can be selected in the
Mixing Console display (page 83).
[6 ▲▼]/
[7 ▲▼]
VOCAL
HARMONY
See below.
Adding Harmony Vocals to Your Voice
2
3
92 PSR-S910/S710 Owner’s Manual
Connections – Using Your Instrument with Other Devices –
10
3Press the [H] button to call up the Vocal Harmony selection
display.
4Select a Vocal Harmony type by using the [A] – [J] buttons.
5Turn the [ACMP] button on.
6Play and hold down chords in the left-hand section of the
keyboard or play back a Song which contains chord data, as you
sing along with it.
The harmony is applied to your voice according to the chord.
NOTE
You can adjust the volume balance
between the keyboard performance
and the microphone by using the
[BALANCE] button (page 48).
Advanced Features
Refer to the Reference Manual on the website, Chapter 10.
Microphone overall settings:
[MIC SETTING/VOCAL HARMONY] → [I]
MIC SETTING → TAB [E][F] OVERALL
SETTING
Talk settings: [MIC SETTING/VOCAL HARMONY] → [I]
MIC SETTING → TAB [E][F] TALK SETTING
Editing Vocal Harmony: [MIC SETTING/VOCAL HARMONY] → [H]
VOCAL HARMONY TYPE → [8 ▼] (EDIT)
PSR-S910/S710 Owner’s Manual 93
Connections – Using Your Instrument with Other Devices –
10
Optional footswitches (Yamaha FC4 or FC5) and an optional Foot controller
(Yamaha FC7) can be connected to one of the FOOT PEDAL jacks. A footswitch
can be used for switching functions on and off, while a foot controller controls
continuous parameter such as volume.
Default functions
By assigning the function for each foot switch/controller, you can conveniently
control sustain and volume with either pedal jack or control many other functions by
pedal.
•Example: Controlling Song Start/Stop by footswitch
Connect a footswitch (FC4 or FC5) to one of the FOOT PEDAL jacks.
To assign the function to the connected pedal, select “SONG PLAY/PAUSE” in the
operation display: [FUNCTION] → [D] CONTROLLER → TAB [E][F] FOOT
PEDAL.
Connecting a Footswitch/Foot Controller
FOOT PEDAL 1 Switches sustain on or off. Use the FC4 or FC5 footswitch.
FOOT PEDAL 2 (PSR-S910) Controls the Super Articulation Voices
(page 33). Use the FC4 or FC5 footswitch.
(PSR-S710) Controls the volume (expression function). Use
the FC7 foot controller.
CAUTION
Make sure to connect or discon-
nect the pedal only when the
power is off.
Advanced Features
Refer to the Reference Manual on the website, Chapter 10.
Assigning specific functions to each
foot pedal:
[FUNCTION] → [D] CONTROLLER → TAB
[E][F] FOOT PEDAL
FC4 FC7
FC5
94 PSR-S910/S710 Owner’s Manual
Connections – Using Your Instrument with Other Devices –
10
By connecting a USB storage device to the instrument’s [USB TO DEVICE] terminal, you can save data you’ve
created to the device.
Connecting a USB Storage Device
Precautions when using the [USB TO DEVICE] terminal
When connecting a USB device to the terminal, be sure to handle the USB device with care. Follow the important precautions below.
Compatible USB devices
• USB storage devices (flash memory, floppy disk drive,
hard disk drive, etc.)
• USB-LAN adaptor
• USB hub
The instrument does not necessarily support all commer-
cially available USB devices. Yamaha cannot guarantee
operation of USB devices that you purchase. Before pur-
chasing a USB device for use with this instrument, please
visit the following web page:
http://music.yamaha.com/download/
Connecting a USB device
•When connecting a USB device to the [USB TO
DEVICE] terminal, make sure that the connector on the
device is appropriate and that it is connected in the
proper direction.
• If you intend to connect two or three devices at the same
time to a terminal, you should use a USB hub device.
The USB hub must be self-powered (with its own power
source) and the power must be on. Only one USB hub
can be used. If an error message appears while using the
USB hub, disconnect the hub from the instrument, then
turn on the power of the instrument and re-connect the
USB hub.
• Though the instrument supports the USB 1.1 standard,
you can connect and use a USB 2.0 storage device with
the instrument. However, note that the transfer speed is
that of USB 1.1.
Using USB Storage Devices
By connecting the instrument to a USB storage device, you
can save data you’ve created to the connected device, as well
as read data from the connected device.
NOTE
Although CD-R/RW drives can be used to read data to the instrument, they can-
not be used for saving data.
The number of USB storage device to be used
Up to two USB storage devices can be connected to the [USB
TO DEVICE] terminal. (If necessary, use a USB hub. The
number of USB storage devices that can be used simulta-
neously with musical instruments even when a USB hub is
used is a maximum of two.) This instrument can recognize up
to four drives in one USB storage device.
Formatting USB storage media
When a USB storage device is connected or media is inserted,
a message may appear prompting you to format the device/
media. If so, execute the Format operation (page 95).
CAUTION
The format operation overwrites any previously existing data. Make
sure that the media you are formatting does not contain important
data. Proceed with caution, especially when connecting multiple
USB storage media.
To protect your data (write-protect)
To prevent important data from being inadvertently erased,
apply the write-protect provided with each storage device or
media. If you are saving data to the USB storage device, make
sure to disable write-protect.
Connecting/removing USB storage device
Before removing the media from the device, make sure that
the instrument is not accessing data (such as in the Save,
Copy and Delete operations).
CAUTION
Avoid frequently turning the power on/off to the USB storage device,
or connecting/disconnecting the device too often. Doing so may
result in the operation of the instrument “freezing” or hanging up.
While the instrument is accessing data (such as during Save, Copy,
Delete, Load and Format operations) or is mounting the USB stor-
age device (shortly after the connection), do NOT unplug the USB
connector, do NOT remove the media from the device, and do NOT
turn the power off to either device. Doing so may corrupt the data on
either or both devices.
NOTE
For more information about the handling of USB devices, refer to the owner’s manual of the USB device.
NOTE
Other USB devices such as a computer keyboard or mouse cannot be used.
PSR-S910/S710 Owner’s Manual 95
Connections – Using Your Instrument with Other Devices –
10
When a USB storage device is connected or media is inserted, a message may appear
prompting you to format the device/media. If so, execute the format operation.
1Insert a USB storage device for formatting into the [USB TO
DEVICE].
2Call up the operation display.
[FUNCTION] → [J] UTILITY → TAB [E][F] MEDIA
3Press the [A]/[B] buttons to select the USB device to be
formatted from the device list.
The indications USB 1, USB 2, etc. will be displayed depending on the number
of the connected devices.
4Press the [H] (FORMAT) button to format the device/media.
By using the [LAN] or [USB TO DEVICE] terminal, you can connect the instrument
to the Internet. For instructions on connecting, refer to page 85 and Internet
Connection Guide downloadable from the Yamaha website.
Formatting a USB Storage Device
CAUTION
The format operation deletes
any previously existing data.
Make sure that the media you
are formatting does not contain
important data. Proceed with
caution, especially when con-
necting multiple USB storage
medias.
Confirming the remaining memory
You can check the remaining memory of the connected USB storage device
by pressing the [F] (PROPERTY) button in step 4 above.
Connecting to the Internet
2
4
3
96 PSR-S910/S710 Owner’s Manual
Connections – Using Your Instrument with Other Devices –
10
By connecting a computer to the [USB TO HOST] terminal, you can transfer data
between the instrument and the computer via MIDI, and use the computer to control,
edit and organize data on the instrument.
Connecting to a Computer
IMPORTANT
You need to install a USB-MIDI
driver to connect the computer
and the instrument. Refer to the
separate Installation Guide.
NOTE
You can also use the MIDI IN/OUT
terminals to connect to a computer. In
this case, a MIDI interface (such as
the Yamaha UX16) is needed. For
more information, refer to the owner’s
manual of the MIDI interface.
NOTE
• The instrument will begin transmis-
sion a short time after the USB
connection is made.
• When using a USB cable to connect
the instrument to your computer,
make the connection directly with-
out passing through a USB hub.
• For information on setting up your
sequence software, refer to the
owner’s manual of the relevant soft-
ware.
Precautions when using the [USB TO HOST] terminal
When connecting the computer to the [USB TO HOST] terminal, make sure
to observe the following points. Failing to do so risks freezing the computer
and corrupting or losing the data. If the computer or the instrument freezes,
restart the application software or the computer OS, or turn the power to the
instrument off then on again.
CAUTION
• Use an AB type USB cable of less than about 3 meters.
• Before connecting the computer to the [USB TO HOST] terminal, exit from any power-saving
mode of the computer (such as suspend, sleep, standby).
• Before turning on the power to the instrument, connect the computer to the [USB TO HOST] ter-
minal.
• Execute the following before turning the power to the instrument on/off or plugging/unplugging
the USB cable to/from the [USB TO HOST] terminal.
• Quit any open application software on the computer.
•Make sure that data is not being transmitted from the instrument. (Data is transmitted only by
playing notes on the keyboard or playing back a song.)
• While the computer is connected to the instrument, you should wait for six seconds or more
between these operations: (1) when turning the power of the instrument off then on again, or (2)
when alternately connecting/disconnecting the USB cable.
PSR-S910/S710 Owner’s Manual 97
Connections – Using Your Instrument with Other Devices –
10
Use the [MIDI] terminals and standard MIDI cables to connect external MIDI
devices (keyboard, sequencer, etc.).
• MIDI IN
Receives MIDI messages from another MIDI device.
• MIDI OUT
Transmits MIDI messages generated by the instrument to another MIDI
device.
For detailed information about the instrument’s MIDI settings, refer to the Reference
Manual.
Connecting External MIDI Devices
MIDI IN MIDI OUT
MIDI transmit
MIDI receive
(playback)
MIDI IN
MIDI OUT
MIDI device
NOTE
For a general overview of MIDI and
how you can effectively use it, refer to
“MIDI Basics” (downloadable from
the Yamaha website).
Advanced Features
Refer to the Reference Manual on the website, Chapter 10.
MIDI settings: [FUNCTION] → [I] MIDI → [8 ▼] EDIT
11
98 PSR-S910/S710 Owner’s Manual
Utility – Making Global Settings –
Utility
– Making Global Settings –
The Utility section in the Function menu provides a variety of
convenient tools and settings for the instrument. These include
general settings that affect the entire instrument, as well as
detailed settings for specific functions. Also included are data
reset functions and storage media control, such as media
formatting.
1Call up the operation display.
[FUNCTION] → [J] UTILITY
2Use the TAB [EE
EE][FF
FF] buttons to call up desired page.
• CONFIG 1
General settings such as Fade in/out time, Metronome sound, Tap Tempo
sound, etc.
• CONFIG 2
General settings such as displayed items for Voice/Style selection display,
pop-up display time, etc.
• SCREEN OUT (PSR-S910)
Monitor type and display content settings which are necessary when
connecting a TV monitor (page 89).
• MEDIA
Settings related to a connected USB storage device, such as formatting
(page 95) and confirmation of memory size.
• OWNER
Settings of Owner name (page 17) and Message language (page 16). Parameter
setting backup/restore operations (page 28) can also be done in this page.
• SYSTEM RESET
Resets the settings of the instrument.
3If necessary, use the [A]/[B] buttons to select the desired parameter.
4Change the settings by using the [1 ▲▼] – [8 ▲▼] buttons or
execute the operation by using the [F] – [J] buttons.
For details of the Utility settings, refer to the Reference Manual on the website.
Basic Procedure
2
Troubleshooting
PSR-S910/S710 Owner’s Manual 99
Troubleshooting
Overall
A click or pop is heard when the power is turned on or off. Electrical current is being applied to the instrument. This is normal.
Noise is heard from the instrument’s speakers. Noise may be heard if a mobile phone is used near the instrument or
if the phone is ringing. Turn off the mobile phone, or use it further
away from the instrument.
There is a slight difference in sound quality among different notes
played on the keyboard.
This is normal and is a result of the instrument’s sampling system.
Some Voices have a looping sound.
Some noise or vibrato is noticeable at higher pitches, depending
upon the Voice.
The overall volume is too low, or, no sound is heard. The master volume may be set too low. Set it to an appropriate level
with the [MASTER VOLUME] dial.
All keyboard parts are set to off. Use the PART ON/OFF [RIGHT 1]/
[RIGHT 2]/[LEFT] button to turn it on.
The volume of the individual parts may be set too low. Raise the vol-
ume in the BALANCE display (page 48).
Make sure the desired channel is set to ON (pages 47, 54).
Headphones are connected, disabling the speaker output. Unplug the
headphones.
The [FADE IN/OUT] button is on, muting the sound. Press the [FADE
IN/OUT] button to turn the function off.
The sound is distorted or noisy. The volume may be turned up too high. Make sure all relevant volume
settings are appropriate.
This may be caused by certain effects or filter resonance settings.
Check the effect or filter settings and change them accordingly,
referring to the Reference Manual.
Not all simultaneously played notes sound. You are probably exceeding the maximum polyphony (page 104) of
the instrument. When the maximum polyphony is exceeded, the earli-
est played notes will stop sounding, letting the latest played notes
sound.
The keyboard volume is lower than the Song/Style playback vol-
ume.
The volume of the keyboard parts may be set too low. Raise the vol-
ume in the BALANCE display (page 48).
The Main display does not appear even when turning the power on. This may occur if a USB storage device has been installed to the
instrument. Installation of some USB storage device may result a long
interval between turning the power on and appearance of the Main
display. To avoid this, turn the power on after disconnecting the
device.
Some characters of the file/folder name are garbled. The language settings have been changed. Set the appropriate lan-
guage for the file/folder name (page 16).
An existing file is not shown. The file extension (.MID, etc.) may have been changed or deleted.
Manually rename the file, adding the appropriate extension, on a
computer.
Data files with names of more than 50 characters cannot be handled
by the instrument. Rename the file, reducing the number of charac-
ters to 50 or less.
100 PSR-S910/S710 Owner’s Manual
Troubleshooting
Voice
The Voice selected from the Voice Selection display does not
sound.
Check whether or not the selected part is turned on (page 32).
To select the Voice for the right-hand key range, press the PART
SELECT [RIGHT 1] button. For the Voice to be layered in the right-
hand range, press the PART SELECT [RIGHT 2] button. To select the
Voice for the left-hand key range, press the PART SELECT [LEFT]
button.
A strange “flanging” or “doubling” sound occurs. The sound is
slightly different each time the keys are played.
The RIGHT 1 and RIGHT 2 parts are set to “ON,” and both parts are
set to play the same Voice. Turn off the RIGHT 2 part or change the
Voice of one of the parts.
Some Voices will jump an octave in pitch when played in the upper
or lower registers.
This is normal. Some voices have a pitch limit which, when reached,
causes this type of pitch shift.
Style
The Style does not start even when the [START/STOP] button is
pressed.
The Rhythm channel of the selected Style may not contain any data.
Turn the [ACMP] button on and play left-hand section on the keyboard
to sound the accompaniment part of the Style.
Only the rhythm channel plays. Make sure the Auto Accompaniment function is turned on; press the
[ACMP] button.
You may be playing keys in the right hand range of the keyboard.
Make sure to play keys in the chord range of the keyboard.
Styles in a USB storage device cannot be selected. If the size of the Style data is large (about 120 KB or greater), the
Style cannot be selected because the data is too large to be ready by
the instrument.
Song
Songs cannot be selected. This may be because the language settings have been changed. Set
the appropriate language for the Song file name.
If the size of the Song data is large (about 300 KB or greater), the
Song cannot be selected because the data is too large to be read by
the instrument.
Song playback does not start. The Song has been stopped at the end of the Song data. Return to
the beginning of the Song by pressing the SONG [■] (STOP) button.
In the case a Song to which write-protect has been applied (“Prot. 2
Edit” is shown at the upper left of the Song name), the original file
may not be in the same folder. It cannot be played back unless the
original file (showing “Prot.2 Orig” at the upper left of the Song name)
is in the same folder.
In case of a Song to which write-protect has been applied (“Prot. 2
Edit” is shown at the upper left of the Song name), the original file
name may have been changed. Rename the file with the original file
name (so that “Prot.2 Orig” is shown at the upper left of the Song
name).
In case of a Song to which write-protect has been applied (“Prot. 2
Edit” is shown at the upper left of the Song name), the file icon may
have been changed. Songs to which write-protect has been applied
cannot be played back when the file icon of the original has been
changed.
Song playback stops before the Song is finished. The Guide function is turned on. (In this case, playback is “waiting” for
the correct key to be played.) Press the [GUIDE] button to turn off the
guide function.
The measure number is different from that of the score in the Song
Position display, shown by pressing the [REW]/[FF] buttons.
This happens when playing back music data for which a specific, fixed
tempo is set.
When playing back a Song, some channels do not play. Playback of these channels may be set to “OFF.” Turn playback on for
those channels that are set to “OFF” (page 54).
The tempo, beat, measure and music notation is not displayed cor-
rectly.
Some Song data for the instrument has been recorded with special
“free tempo” settings. For such Song data, the tempo, beat, measure
and music notation will not be displayed correctly.
PSR-S910/S710 Owner’s Manual 101
Troubleshooting
USB Audio function
The message “This drive is busy now.” appeared, and then the
recording was aborted.
Make sure to use a compatible USB storage device (page 94).
Make sure that the USB storage device has enough memory
(page 78).
If you are using a USB memory device to which data has already
been recorded, check first that no important data remains on the
device, then format it (page 95) and try recording again.
Audio files cannot be selected. The file format may not be compatible with the instrument. The com-
patible formats are: MP3 and WAV (PSR-S910), WAV (PSR-S710).
The DRM protected files cannot be played back.
Recorded file is played back at a different volume compared to
when it was recorded.
The audio playback volume has been changed. Setting the volume
value to 100 plays back the file as the same volume when it was
recorded (page 77).
Mixing Console
The sound seems strange or different than expected when chang-
ing a rhythm Voice (drum kit, etc.) of the Style or Song from the
Mixer.
When changing the rhythm/percussion Voices (drum kits, etc.) of the
Style and Song from the VOICE parameter, the detailed settings
related to the drum voice are reset, and in some cases you may be
unable to restore the original sound. In the case of Song playback,
you can restore the original sound by returning to the beginning of the
Song and playing back from that point. In the case of Style play, you
can restore the original sound by selecting the same Style again.
Microphone/Vocal Harmony (PSR-S910)
The microphone input signal cannot be recorded. The microphone input signal cannot be recorded by Song recording.
Use the USB Audio function (page 77).
Harmony can be heard in addition to the microphone sound. Vocal Harmony is set to “ON.” Turn Vocal Harmony off (page 91).
The Vocal Harmony effect sounds distorted or out-of-tune. Your vocal microphone may be picking up extraneous sounds, such
as the Style sound from the instrument. In particular, bass sounds
can cause mistracking of the Vocal Harmony. To remedy this:
• Sing as closely to the microphone as possible.
• Use a unidirectional microphone.
•Turn down the Master volume, Style volume, or Song volume control
(pages 15, 48).
Foot Pedal
The on/off setting of the footswitch connected to the FOOT PEDAL
jack is reversed.
Turn the instrument’s power off, then turn on again without pressing
the footswitch.
102 PSR-S910/S710 Owner’s Manual
Panel Button Chart
Panel Button Chart
No. ............................................Corresponds to the number in the “Panel Controls” on page 12.
Button/Control.......................Indicates the button/controller that you should use at first for entering the
corresponding function.
Display.....................................Indicates the display title (and tab title) called up by operating the button/controller.
Reference Manual.................“●” indicates that the detailed information is described in the Reference Manual
(downloadable from website).
No. Button/Control Display Page
Reference
Manual
1
MASTER VOLUME control
—15—
2
[STANDBY/ON]
Opening display 14 —
3[DEMO] Demo display 18 —
4[MIC SETTING/VOCAL
HARMONY] (PSR-S910)
MIC SETTING/VOCAL HARMONY display 91 ●
5PITCH BEND wheel — 34 —
6MODULATION wheel — 35 —
7PHONES jack — 16 —
8SONG [SELECT] Song Selection display 49 —
[SCORE] SCORE display 52 ●
[LYRICS/TEXT] LYRICS or TEXT display 53 ●
[REPEAT] — 55 —
[GUIDE] — 54 ●
[EXTRA TR] — 54 —
[TR 2] — 54 —
[TR 1] — 54 —
[REC] CHANNEL ON/OFF (SONG) (pop-up) 56 —
[■] (STOP) — 50 —
[F/II] (PLAY/PAUSE) — 50 —
[G] (REW) / [H] (FF) SONG POSITION (pop-up) 51 —
9STYLE [POP & ROCK]–[WORLD] Style Selection display (PRESET) 39 —
[USER] Style Selection display (USER) 39 —
)[FADE IN/OUT] 44 —
!STYLE
CONTROL
[ACMP] — 39 —
[OTS LINK] — 45 —
[AUTO FILL IN] — 43 —
INTRO [I]–[III] — 42 —
MAIN VARIATION [A]–[D] — 43 —
[BREAK] — 43 —
ENDING/rit. [I]–[III] — 42 —
[SYNC STOP] — 42 —
[SYNC START] — 42 —
[START/STOP] — 42 —
@TRANSPOSE [-]/[+] TRANSPOSE (pop-up) 34 —
#[METRONOME] — 56 —
$(TEMPO) [TAP TEMPO] — 43 —
TEMPO [-]/[+] TEMPO (pop-up) 43 —
%[LCD CONTRAST] knob
(PSR-S710)
—17
—
^(LCD related
controls)
TAB [E][F]— 20—
[A]–[J] — 19 —
[DIRECT ACCESS] (message) 22 —
[EXIT] — 22 —
[1 ▲▼]–[8 ▲▼] buttons — 20 —
DATA ENTRY dial — 21 —
[ENTER] — 21 —
&[BALANCE] BALANCE (pop-up) 48 —
PSR-S910/S710 Owner’s Manual 103
Panel Button Chart
*[MIXING CONSOLE] MIXING CONSOLE display VOL/VOICE 81, 82 ●
FILTER 79 ●
TUNE 79 ●
EFFECT 83 ●
EQ 79 ●
([CHANNEL ON/OFF] CHANNEL ON/OFF (pop-up) SONG 54 —
STYLE 47 —
º[FUNCTION] MASTER TUNE/SCALE TUNE MASTER TUNE 38 ●
SCALE TUNE 38 ●
SONG SETTING 62 ●
STYLE SETTING/SPLIT POINT/
CHORD FINGERING
STYLE SETTING 48 ●
SPLIT POINT 48 ●
CHORD FINGERING 41 ●
CONTROLLER FOOT PEDAL 93 ●
KEYBOARD/PANEL 35, 38 ●
REGIST SEQUENCE/FREEZE/
VOICE SET
REGISTRATION
SEQUENCE
74 ●
FREEZE 74 ●
VOICE SET 38 ●
DIGITAL REC MENU SONG CREATOR 62 ●
STYLE CREATOR 48 ●
MULTI PAD CREATOR 64 ●
HARMONY/ECHO 38 ●
MIDI MIDI template selec-
tion display
97 ●
UTILITY CONFIG 1 98 ●
CONFIG 2 98 ●
SCREEN OUT
(PSR-S910)
89 —
MEDIA 95 ●
OWNER
16, 17, 28
●
SYSTEM RESET 98 ●
¡[USB] USB/AUDIO PLAYER display 75 —
™[INTERNET] Special Website (only when connected to the Internet) 84 ●
£REGISTRATION
MEMORY
REGIST BANK [-]/[+] REGISTRATION BANK (pop-up) 73 —
[FREEZE] — 73 ●
[MEMORY] REGISTRATION MEMORY CONTENTS display 71 —
[1]–[8] — 72 —
¢MULTI PAD
CONTROL
[SELECT] Multi Pad Selection display 63 ●
[1]–[4] — 63 —
[STOP] — 63 —
∞[MUSIC FINDER] MUSIC FINDER display ALL 67 —
FAVORITE 70 ●
SEARCH 1 67 —
SEARCH 2 67 —
§PART SELECT [LEFT]–[RIGHT 2] — 32 —
PART ON/OFF [LEFT HOLD] — 32 —
[LEFT]–[RIGHT 2] — 32 —
•VOICE [PIANO]–
[PERC. & DRUM KIT]
Voice Selection display (PRESET) 29 —
[ORGAN FLUTES] Organ Flutes VOICE SET display FOOTAGE 37 —
VOLUME/ATTACK 37 ●
EFFECT/EQ 37 ●
[USER] Voice Selection display (USER) 30 —
ªONE TOUCH
SETTING
[1]–[4] — 45 ●
‚VOICE
CONTROL
[HARMONY/ECHO] — 35 —
[TOUCH] — 35 —
[SUSTAIN] — 35 —
[MONO] — 35 —
[DSP] — 36 —
[VARI.] — 36 —
⁄UPPER OCTAVE [-]/[+] UPPER OCTAVE (pop-up) 34 —
No. Button/Control Display Page
Reference
Manual
104 PSR-S910/S710 Owner’s Manual
Specifications
Specifications
PSR-S910 PSR-S710
Size/Weight Dimensions
Width 1,003 mm (39 5/8")
Height 148 mm (5 7/8")
Depth 433 mm (17 1/8")
Weight Weight 11 kg (24 lbs.) 10 kg (22 lbs.)
Control
Interface
Keyboard
Number of Keys 61
Type Organ
Touch Response Hard2/Hard1/Normal/Soft1/Soft2
Other Controllers
Pitch Bend Yes
Modulation Yes
Multi Pads Yes
Display
Type TFT Color QVGA LCD B/W QVGA LCD
Contrast
-
Ye s
Score Display Function Yes
Lyrics Display Function Yes
Text Viewer Function Yes
Wallpaper Customization Yes
-
Language English, German, French, Spanish, Italian
Panel Language English
Voices
Tone Generation Tone Generating
Technology AWM Stereo Sampling
Polyphony Number of Polyphony
(Max.) 128
Preset
Number of Voices
678 Voices + 28 Drum/SFX Kits + 480
XG Voices + GM2 + GS (for GS Song
Playback)
387 Voices + 24 Drum/SFX Kits + 480
XG Voices + GM2 + GS (for GS Song
Playback)
Featured Voices
38 Super Articulation Voices, 18 Mega
Voices, 24 Sweet! Voices, 46 Cool! Voices,
29 Live! Voices, 10 Organ Flutes!
15 Mega Voices, 23 Sweet! Voices, 33
Cool! Voices, 19 Live! Voices, 10 Organ
Flutes!
Custom Voice Creating/Voice Set Yes
Compatibility
XG Yes
XF Yes
GS Yes
GM Yes
GM2 Yes
Effects
Types
Reverb 42 Preset + 3User
Chorus 71 Preset + 3 User
DSP DSP 1: 271 Preset + 3 User, DSP 2-4: 128 Preset + 10 User
Master EQ 5 Preset
Part EQ 28 Parts (Right 1, Right 2, Left, Multi Pad, Style x 8, Song x 16)
Voice Controls
Voice Layer
(Right-hand parts) Yes (Right 1, Right 2)
Split (Left-hand part) Yes (Left)
Panel Sustain Yes
Mono/Poly Yes
Accompany Style
Related Vocal Harmony 60 Preset + 10 User
-
Accompaniment Styles
Number of Preset Styles 322 232
Featured Styles 293 Pro Styles, 29 Session Styles 216 Pro Styles, 16 Session Styles
File Format Style File Format GE
Fingering Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered,
Full Keyboard, AI Full Keyboard
Style Control INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3
PSR-S910/S710 Owner’s Manual 105
Specifications
* Specifications and descriptions in this owner’s manual are for information purposes only. Yamaha Corp. reserves the right to change or modify products or
specifications at any time without prior notice. Since specifications, equipment or options may not be the same in every locale, please check with your Yamaha dealer.
Accompaniment
Styles
Custom Style Creator Yes
Other Features Music Finder 2,500 Records (maximum) 1,200 Records (maximum)
One Touch Setting (OTS) 4 for each Style
Songs
Preset Number of Preset Songs 5 Sample Songs
Recording
Number of Songs Unlimited (depending on the storage media’s capacity)
Number of Tracks 16
Data Capacity 300 KB
Recording Function Quick Recording/Multi Recording/Step Recording
Compatible Data
Format
Playback SMF (Format 0 & 1), ESEQ, XF
Recording SMF (Format 0)
Functions
Registration Memory Number of Buttons 8 x unlimited banks (depending on the storage media’s capacity)
Control Regist. Sequence, Freeze
Lesson/Guide
Lesson/Guide Follow Lights, Any Key, Karao-Key,
Vocal CueTIME Follow Lights, Any Key, Karao-Key
Performance Assistant
Technology (P.A.T.) Ye s
Demo Demonstration Yes
USB Audio Playback .wav, .mp3 .wav
Recording .wav
Overall Controls
Metronome Yes
Tempo Range 5 – 500, Tap Tempo
Transpose -12 – 0 – +12
Tuning 414.8 – 440 – 466.8 Hz
Octave Button Yes
Scale Type 9 presets
Miscellaneous Direct Access Yes
Storage and
Connectivity
Storage Internal Memory 2.4 MB 1.4 MB
External Drives USB Flash Memory, USB Hard Disk Drive, etc. (via USB to DEVICE)
Connectivity
DC IN 16V
Headphones Yes
Microphone Yes
-
MIDI In/Out
AUX IN (R, L/L+R)
FOOT PEDAL (optional) Switch or Volume x 2
OUTPUT (R, L/L+R)
VIDEO OUT Yes
-
USB TO DEVICE Yes
USB TO HOST Yes
LAN Yes
Amplifiers and
Speakers
Amplifiers 12 W x 2
Speakers (12 cm + 4 cm (dome)) x 2 (12 cm + 5 cm) x 2
Pedals Assignable Functions
VOLUME, SUSTAIN, SOSTENUTO,
SOFT, GLIDE, S. Articulation, SONG
PLAY/PAUSE, STYLE START/STOP, etc.
VOLUME, SUSTAIN, SOSTENUTO,
SOFT, GLIDE, SONG PLAY/PAUSE,
STYLE START/STOP, etc.
Power Supply AC Power Adaptor PA-300B or an equivalent PA-301 or an equivalent
Included Accessories
• Music Rest
•AC Power Adaptor*
* May not be included depending on your particular area. Please check with your Yamaha
dealer.
• Accessory CD-ROM for Windows
• Owner’s Manual
• Accessory CD-ROM for Windows Installation Guide
Optional
Accessories
Footswitches FC4/FC5
Foot controller FC7
Service Internet Direct Connection (IDC) Yes
PSR-S910 PSR-S710
106 PSR-S910/S710 Owner’s Manual
Symbols
[F/ II] (PLAY/PAUSE) ..................... 50
[G ](REW)...................................... 51
[H] (FF).......................................... 51
[■] (STOP)........................................ 50
Numerics
[1 ▲▼] – [8 ▲▼] buttons ................. 20
1-16................................................... 62
A
[A] – [J].............................................. 19
A-B Repeat ....................................... 55
ACMP................................................ 39
ADD TO FAVORITE.......................... 70
ADD TO MF ...................................... 69
ASSEMBLY....................................... 48
AUDIO PLAYER ............................... 75
Audio Record (Music Finder) ............ 66
Auto Accompaniment........................ 39
AUTO FILL IN ................................... 43
AUX IN .............................................. 88
B
Backup .............................................. 28
BALANCE ......................................... 48
BASIC ............................................... 48
BASS ................................................ 47
Bookmark.......................................... 87
BREAK.............................................. 43
Browser............................................. 87
C
CD-ROM ............................................. 9
CHANNEL (Song Creator) ................ 62
CHANNEL (Style Creator)................. 48
CHANNEL ON/OFF .................... 47, 54
Character entry ................................. 26
CHD1/2 (Chord 1/ 2) ......................... 47
Chord ................................................ 41
CHORD (Song Creator)..................... 62
CHORD FINGERING .................. 41, 48
Chord Match...................................... 64
CHORUS ........................................... 83
Computer........................................... 96
CONFIG 1.......................................... 98
CONFIG 2.......................................... 98
Connection ........................................ 88
Contrast ............................................. 17
COPY ................................................ 60
CUT ................................................... 60
D
DATA ENTRY dial ............................. 21
Data List ............................................ 10
DC IN terminal................................... 14
DELETE............................................. 61
DEMO................................................ 18
DEMO (Voice) ................................... 30
Dial (Data Entry)................................ 21
DIRECT ACCESS ............................. 22
Drum Voice........................................ 33
DSP ............................................. 36, 83
E
EFFECT............................................. 79
EFFECT/EQ ...................................... 38
ENDING/rit......................................... 42
ENTER .............................................. 21
Entering Characters........................... 26
EQ ..................................................... 79
Ethernet Converter ............................ 85
EXIT................................................... 22
EXTRA TR......................................... 54
F
Factory Reset .................................... 27
FADE IN/OUT.................................... 44
Fast Forward ..................................... 51
FAVORITE......................................... 70
File..................................................... 25
File Selection Display.........................25
Fill-in section......................................43
FILTER...............................................79
Folder.................................................26
FOLDER (File Selection Display).......59
Foot Controller ...................................93
FOOT PEDAL jacks...........................93
Footage..............................................37
Footswitch..........................................93
FORMAT............................................95
FREEZE.............................................73
G
GM .................................................9, 38
GROOVE ...........................................48
GS........................................................9
GUIDE................................................54
GUIDE MODE....................................55
Guitar .................................................90
H
HARMONY/ECHO .............................35
Headphones.......................................16
HOME ................................................86
I
INFO (Voice)................................30, 33
INFO. (Registration Memory).............74
Initial Touch (TOUCH) .......................35
Initialize (Factory Reset) ....................27
INPUT VOLUME................................90
INTERNET.........................................84
Internet Connection Guide.................10
Internet Direct Connection .................84
INTRO................................................42
K
Keyboard Part....................................32
KEYBOARD/PANEL ....................35, 38
Index
Index
PSR-S910/S710 Owner’s Manual 107
L
LAN terminal...................................... 85
Language .......................................... 16
LCD ................................................... 12
LEFT.................................................. 32
Left Hold ............................................ 32
LINE MIC switch................................ 90
Link .................................................... 86
Lyrics ................................................. 53
LYRICS (Song Creator)..................... 62
LYRICS/ TEXT .................................. 53
M
Main Display...................................... 23
MAIN PICTURE................................. 17
Main section ...................................... 43
MAIN VARIATION ............................. 43
MASTER TUNE................................. 38
MASTER VOLUME ........................... 15
MEDIA ............................................... 95
MegaVoice ........................................ 33
MEMORY .................................... 48, 71
Message ............................................ 22
METRONOME................................... 56
MIC EFFECT..................................... 91
MIC SETTING/VOCAL HARMONY... 91
MIC/LINE IN ...................................... 90
Microphone........................................ 90
MIDI Basics ....................................... 10
MIDI IN .............................................. 97
MIDI OUT .......................................... 97
MIXING CONSOLE ........................... 79
Modulation Wheel.............................. 35
MONITOR TYPE ............................... 89
MONO ............................................... 35
MP3 ................................................... 75
Multi Pad ........................................... 63
MULTI PAD CONTROL..................... 63
Multi Pad Creator............................... 64
Multi Track Recording........................ 57
MUSIC FINDER................................. 65
Music Finder +................................... 70
Music Notation................................... 52
Music Rest......................................... 15
N
NAME ................................................ 60
NEXT (Song Playback) ..................... 50
NEXT CANCEL..................................50
O
ONE TOUCH SETTING.....................45
ORGAN FLUTES...............................37
ORGAN TYPE ...................................37
OTS INFO..........................................46
OTS LINK...........................................45
OUTPUT ............................................88
OWNER .................................16, 17, 28
Owner Name......................................17
P
P.A.T..................................................62
PAD....................................................47
Panel Button Chart...........................102
PANPOT ............................................82
PARAMETER.....................................48
PART ON/OFF...................................32
PART SELECT ..................................32
PASTE ...............................................61
Pause.................................................50
Percussion Voice ...............................33
Performance Assistant.......................62
PHONES............................................16
PHR1/2 (Phrase1/2)...........................47
Phrase Mark.......................................51
PITCH BEND RANGE .......................34
Pitch Bend Wheel ..............................34
Pitch setting .......................................34
Powered speaker...............................88
PRESET.............................................25
Preset Voice.......................................33
PRESETS (Organ Flutes)..................37
Pro .....................................................40
Prot. ...................................................52
Protected Song ..................................52
Q
Quick Recording ................................56
R
REC ...................................................56
REC MODE (Song Creator)...............62
Record (Music Finder) .......................66
RECORD EDIT ..................................70
Recording (Audio)..............................77
Recording (Song) .............................. 56
Reference Manual............................. 10
REFRESH ......................................... 86
REGIST BANK .................................. 72
REGISTRATION MEMORY .............. 72
REGISTRATION SEQUENCE .......... 74
REPEAT (Audio playback) ................ 76
REPEAT (Song) ................................ 55
REPERTOIRE................................... 44
RESTORE......................................... 28
REVERB............................................ 83
Rewind .............................................. 51
RHY1/2 (Rhythm 1/2)........................ 47
RIGHT 1-2......................................... 32
ROTARY SP SPEED ........................ 37
S
S.Art! ................................................. 33
SAVE................................................. 58
Scale ................................................. 34
SCALE TUNE.................................... 38
SCORE.............................................. 52
SCREEN CONTENT......................... 89
SCREEN OUT................................... 89
SEARCH (Music Finder) ................... 67
Section .............................................. 43
SELECT (Multi Pad).......................... 63
SELECT (Song)................................. 49
Session.............................................. 40
SFF...................................................... 9
SFF GE ............................................. 40
SIGNAL lamp .................................... 90
SONG................................................ 49
Song Creator..................................... 62
Song Record (Music Finder) ............. 66
SONG SETTING ............................... 62
Specifications .................................. 104
Split Point .................................... 32, 48
STANDBY/ON switch........................ 14
START/STOP.............................. 40, 42
STEP REC ........................................ 48
STOP (Multi Pad) .............................. 63
STYLE............................................... 39
Style Creator ..................................... 48
Style File Format ................................. 9
STYLE SETTING .............................. 48
Super Articulation Voice.................... 33
SUSTAIN........................................... 35
SYNC START.............................. 40, 42
Index
108 PSR-S910/S710 Owner’s Manual
SYNC STOP ..................................... 42
Synchro Start (Multi Pad).................. 64
Synchro Start (Song) ........................ 50
SYS/EX. ............................................ 62
SYSTEM RESET ........................ 27, 98
T
TAB ................................................... 20
TALK ................................................. 91
TAP TEMPO ..................................... 43
TEMPO ............................................. 43
Text ................................................... 53
TOUCH ............................................. 35
TR1, TR2 .......................................... 54
TRANSPOSE.................................... 34
TRANSPOSE ASSIGN ..................... 38
Troubleshooting ................................ 99
TUNE ................................................ 79
TV Monitor ........................................ 89
U
UP ..................................................... 26
UPPER OCTAVE.............................. 34
USB (File Selection Display)............. 25
USB Audio ........................................ 75
USB AUDIO RECORDER................. 78
USB button........................................ 75
USB Storage Device ......................... 94
USB TO DEVICE .............................. 94
USB TO HOST.................................. 96
USB Wireless LAN Adaptor .............. 85
USB-MIDI driver................................ 96
USER ................................................ 25
USER (Voice).................................... 30
Utility ................................................. 98
V
VARI.................................................. 36
VERSION.......................................... 17
VH ....................................................... 9
Vibrato............................................... 35
VIBRATO (Organ Flutes) .................. 37
VIDEO OUT ...................................... 89
VOCAL HARMONY........................... 91
VOICE............................................... 29
Voice Effect....................................... 35
VOICE SET................................. 36, 38
Voice Type ........................................ 33
VOL/VOICE ....................................... 79
Volume .............................................. 48
Volume (Audio playback)................... 77
VOLUME/ATTACK ............................ 38
W
WAV .................................................. 75
X
XF ........................................................ 9
XG ................................................. 9, 38
Index
PSR-S910/S710 Owner’s Manual 109
1-YEAR LIMITED WARRANTY
ON ARRANGER WORKSTATION KEYBOARDS
Thank you for selecting a Yamaha product. Yamaha products are designed and manufactured to provide a high level of defect-free
performance. Yamaha Corporation of America (“Yamaha”) is proud of the experience and craftsmanship that goes into each and
every Yamaha product. Yamaha sells its products through a network of reputable, specially authorized dealers and is pleased to offer
you, the Original Owner, the following Limited Warranty, which applies only to products that have been (1) directly purchased from
Yamaha’s authorized dealers in the fifty states of the USA and District of Columbia (the “Warranted Area”) and (2) used exclusively in
the Warranted Area. Yamaha suggests that you read the Limited Warranty thoroughly, and invites you to contact your authorized
Yamaha dealer or Yamaha Customer Service if you have any questions.
Coverage: Yamaha will, at its option, repair or replace the product covered by this warranty if it becomes defective, malfunctions
or otherwise fails to conform with this warranty under normal use and service during the term of this warranty, without charge for labor
or materials. Repairs may be performed using new or refurbished parts that meet or exceed Yamaha specifications for new parts. If
Yamaha elects to replace the product, the replacement may be a reconditioned unit. You will be responsible for any installation or
removal charges and for any initial shipping charges if the product(s) must be shipped for warranty service. However, Yamaha will
pay the return shipping charges to any destination within the USA if the repairs are covered by the warranty. This warranty does not
cover (a) damage, deterioration or malfunction resulting from accident, negligence, misuse, abuse, improper installation or operation
or failure to follow instructions according to the Owner’s Manual for this product; any shipment of the product (claims must be
presented to the carrier); repair or attempted repair by anyone other than Yamaha or an authorized Yamaha Service Center; (b) any
unit which has been altered or on which the serial number has been defaced, modified or removed; (c) normal wear and any periodic
maintenance; (d) deterioration due to perspiration, corrosive atmosphere or other external causes such as extremes in temperature
or humidity; (e) damages attributable to power line surge or related electrical abnormalities, lightning damage or acts of God; or (f)
RFI/EMI (Interference/noise) caused by improper grounding or the improper use of either certified or uncertified equipment, if
applicable. Any evidence of alteration, erasing or forgery of proof-of-purchase documents will cause this warranty to be void. This
warranty covers only the Original Owner and is not transferable.
In Order to Obtain Warranty Service: Warranty service will only be provided for defective products within the Warranted
Area. Contact your local authorized Yamaha dealer who will advise you of the procedures to be followed. If this is not successful,
contact Yamaha at the address, telephone number or website shown below. Yamaha may request that you send the defective
product to a local authorized Yamaha Servicer or authorize return of the defective product to Yamaha for repair. If you are uncertain
as to whether a dealer has been authorized by Yamaha, please contact Yamaha’s Service Department at the number shown below, or
check Yamaha’s website at www.Yamaha.com. Product(s) shipped for service should be packed securely and must be
accompanied by a detailed explanation of the problem(s) requiring service, together with the original or a machine reproduction of
the bill of sale or other dated, proof-of-purchase document describing the product, as evidence of warranty coverage. Should any
product submitted for warranty service be found ineligible therefore, an estimate of repair cost will be furnished and the repair will be
accomplished only if requested by you and upon receipt of payment or acceptable arrangement for payment.
Limitation of Implied Warranties and Exclusion of Damages: ANY IMPLIED WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE SHALL BE LIMITED IN DURATION TO THE
APPLICABLE PERIOD OF TIME SET FORTH ABOVE. YAMAHA SHALL NOT BE RESPONSIBLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR FOR DAMAGES BASED UPON INCONVENIENCE, LOSS OF USE, DAMAGE TO ANY OTHER
EQUIPMENT OR OTHER ITEMS AT THE SITE OF USE OR INTERRUPTION OF PERFORMANCES OR ANY CONSEQUENCES.
YAMAHA’S LIABILITY FOR ANY DEFECTIVE PRODUCT IS LIMITED TO REPAIR OR REPLACEMENT OF THE PRODUCT, AT
YAMAHA’S OPTION. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY
NOT APPLY TO YOU. This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
This is the only express warranty applicable to the product specified herein; Yamaha neither assumes nor authorizes anyone to
assume for it any other express warranty.
If you have any questions about service received or if you need assistance in locating an authorized Yamaha Servicer, please
contact:
CUSTOMER SERVICE
Yamaha Corporation of America
6600 Orangethorpe Avenue, Buena Park, California 90620-1373
Telephone: 800-854-1569
www.yamaha.com
Do not return any product to the above address without a written Return Authorization issued by Yamaha.
©2009 Yamaha Corporation of America.
110 PSR-S910/S710 Owner’s Manual
* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA. (class B)
FCC INFORMATION (U.S.A.)
1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the instructions con-
tained in this manual, meets FCC requirements. Modifications
not expressly approved by Yamaha may void your authority,
granted by the FCC, to use the product.
2. IMPORTANT: When connecting this product to accessories
and/or another product use only high quality shielded cables.
Cable/s supplied with this product MUST be used. Follow all
installation instructions. Failure to follow instructions could void
your FCC authorization to use this product in the USA.
3. NOTE: This product has been tested and found to comply with
the requirements listed in FCC Regulations, Part 15 for Class
“B” digital devices. Compliance with these requirements pro-
vides a reasonable level of assurance that your use of this prod-
uct in a residential environment will not result in harmful
interference with other electronic devices. This equipment gen-
erates/uses radio frequencies and, if not installed and used
according to the instructions found in the users manual, may
cause interference harmful to the operation of other electronic
devices. Compliance with FCC regulations does not guarantee
that interference will not occur in all installations. If this product
is found to be the source of interference, which can be deter-
mined by turning the unit “OFF” and “ON”, please try to elimi-
nate the problem by using one of the following measures:
Relocate either this product or the device that is being affected
by the interference.
Utilize power outlets that are on different branch (circuit breaker
or fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the
antenna. If the antenna lead-in is 300 ohm ribbon lead, change
the lead-in to co-axial type cable.
If these corrective measures do not produce satisfactory results,
please contact the local retailer authorized to distribute this type
of product. If you can not locate the appropriate retailer, please
contact Yamaha Corporation of America, Electronic Service
Division, 6600 Orangethorpe Ave, Buena Park, CA90620
The above statements apply ONLY to those products distributed
by Yamaha Corporation of America or its subsidiaries.
IMPORTANT NOTICE FOR THE UNITED KINGDOM
Connecting the Plug and Cord
IMPORTANT. The wires in this mains lead are coloured in
accordance with the following code:
BLUE : NEUTRAL
BROWN : LIVE
As the colours of the wires in the mains lead of this apparatus
may not correspond with the coloured makings identifying the
terminals in your plug proceed as follows:
The wire which is coloured BLUE must be connected to the ter-
minal which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the
terminal which is marked with the letter L or coloured RED.
Making sure that neither core is connected to the earth terminal
of the three pin plug.
* This applies only to products distributed by Yamaha Music U.K. Ltd. (2 wires)
This product contains a high intensity lamp that
contains a small amount of mercury. Disposal of
this material may be regulated due to environmen-
tal considerations.
For disposal information in the United States, refer
to the Electronic Industries Alliance web site:
www.eiae.org
COMPLIANCE INFORMATION STATEMENT
(DECLARATION OF CONFORMITY PROCEDURE)
Responsible Party : Yamaha Corporation of America
Address : 6600 Orangethorpe Ave., Buena Park,
Calif. 90620
Telephone : 714-522-9011
Type of Equipment : Digital Keyboard
Model Name : PSR-S910/S710
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received including
interference that may cause undesired operation.
See user manual instructions if interference to radio reception is
suspected.
* This applies only to products distributed by
YAMAHA CORPORATION OF AMERICA.
(FCC DoC)
(mercury)* This applies only to products distributed by
YAMAHA CORPORATION OF AMERICA.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
The serial number of this product may be found on the bottom of
the unit. You should note this serial number in the space pro-
vided below and retain this manual as a permanent record of
your purchase to aid identification in the event of theft.
Model No.
Serial No.
(bottom)
For details of products, please contact your nearest Yamaha
representative or the authorized distributor listed below.
Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou
au distributeur le plus proche de vous figurant dans la liste suivante.
Die Einzelheiten zu Produkten sind bei Ihrer unten aufgeführten
Niederlassung und bei Yamaha Vertragshändlern in den jeweiligen
Bestimmungsländern erhältlich.
Para detalles sobre productos, contacte su tienda Yamaha más cercana
o el distribuidor autorizado que se lista debajo.
CANADA
Yamaha Canada Music Ltd.
135 Milner Avenue, Scarborough, Ontario,
M1S 3R1, Canada
Tel: 416-298-1311
U.S.A.
Yamaha Corporation of America
6600 Orangethorpe Ave., Buena Park, Calif. 90620,
U.S.A.
Tel: 714-522-9011
MEXICO
Yamaha de México S.A. de C.V.
Calz. Javier Rojo Gómez #1149,
Col. Guadalupe del Moral
C.P. 09300, México, D.F., México
Tel: 55-5804-0600
BRAZIL
Yamaha Musical do Brasil Ltda.
Rua Joaquim Floriano, 913 - 4' andar, Itaim Bibi,
CEP 04534-013 Sao Paulo, SP. BRAZIL
Tel: 011-3704-1377
ARGENTINA
Yamaha Music Latin America, S.A.
Sucursal de Argentina
Olga Cossettini 1553, Piso 4 Norte
Madero Este-C1107CEK
Buenos Aires, Argentina
Tel: 011-4119-7000
PANAMA AND OTHER LATIN
AMERICAN COUNTRIES/
CARIBBEAN COUNTRIES
Yamaha Music Latin America, S.A.
Torre Banco General, Piso 7, Urbanización Marbella,
Calle 47 y Aquilino de la Guardia,
Ciudad de Panamá, Panamá
Tel: +507-269-5311
THE UNITED KINGDOM/IRELAND
Yamaha Music U.K. Ltd.
Sherbourne Drive, Tilbrook, Milton Keynes,
MK7 8BL, England
Tel: 01908-366700
GERMANY
Yamaha Music Europe GmbH
Siemensstraße 22-34, 25462 Rellingen, Germany
Tel: 04101-3030
SWITZERLAND/LIECHTENSTEIN
Yamaha Music Europe GmbH
Branch Switzerland in Zürich
Seefeldstrasse 94, 8008 Zürich, Switzerland
Tel: 01-383 3990
AUSTRIA
Yamaha Music Europe GmbH Branch Austria
Schleiergasse 20, A-1100 Wien, Austria
Tel: 01-60203900
CZECH REPUBLIC/SLOVAKIA/
HUNGARY/SLOVENIA
Yamaha Music Europe GmbH Branch Austria
Schleiergasse 20, A-1100 Wien, Austria
Tel: 01-602039025
POLAND
Yamaha Music Europe GmbH
Branch Sp.z o.o. Oddzial w Polsce
ul. 17 Stycznia 56, PL-02-146 Warszawa, Poland
Tel: 022-868-07-57
THE NETHERLANDS/
BELGIUM/LUXEMBOURG
Yamaha Music Europe Branch Benelux
Clarissenhof 5-b, 4133 AB Vianen, The Netherlands
Tel: 0347-358 040
FRANCE
Yamaha Musique France
BP 70-77312 Marne-la-Vallée Cedex 2, France
Tel: 01-64-61-4000
ITALY
Yamaha Musica Italia S.P.A.
Viale Italia 88, 20020 Lainate (Milano), Italy
Tel: 02-935-771
SPAIN/PORTUGAL
Yamaha Música Ibérica, S.A.
Ctra. de la Coruna km. 17, 200, 28230
Las Rozas (Madrid), Spain
Tel: 91-639-8888
GREECE
Philippos Nakas S.A. The Music House
147 Skiathou Street, 112-55 Athens, Greece
Tel: 01-228 2160
SWEDEN
Yamaha Scandinavia AB
J. A. Wettergrens Gata 1, Box 30053
S-400 43 Göteborg, Sweden
Tel: 031 89 34 00
DENMARK
YS Copenhagen Liaison Office
Generatorvej 6A, DK-2730 Herlev, Denmark
Tel: 44 92 49 00
FINLAND
F-Musiikki Oy
Kluuvikatu 6, P.O. Box 260,
SF-00101 Helsinki, Finland
Tel: 09 618511
NORWAY
Norsk filial av Yamaha Scandinavia AB
Grini Næringspark 1, N-1345 Østerås, Norway
Tel: 67 16 77 70
ICELAND
Skifan HF
Skeifan 17 P.O. Box 8120, IS-128 Reykjavik,
Iceland
Tel: 525 5000
RUSSIA
Yamaha Music (Russia)
Office 4015, entrance 2, 21/5 Kuznetskii
Most street, Moscow, 107996, Russia
Tel: 495 626 0660
OTHER EUROPEAN COUNTRIES
Yamaha Music Europe GmbH
Siemensstraße 22-34, 25462 Rellingen, Germany
Tel: +49-4101-3030
Yamaha Corporation,
Asia-Pacific Music Marketing Group
Nakazawa-cho 10-1, Naka-ku, Hamamatsu,
Japan 430-8650
Tel: +81-53-460-2312
TURKEY/CYPRUS
Yamaha Music Europe GmbH
Siemensstraße 22-34, 25462 Rellingen, Germany
Tel: 04101-3030
OTHER COUNTRIES
Yamaha Music Gulf FZE
LOB 16-513, P.O.Box 17328, Jubel Ali,
Dubai, United Arab Emirates
Tel: +971-4-881-5868
THE PEOPLE’S REPUBLIC OF CHINA
Yamaha Music & Electronics (China) Co.,Ltd.
2F, Yunhedasha, 1818 Xinzha-lu, Jingan-qu,
Shanghai, China
Tel: 021-6247-2211
HONG KONG
Tom Lee Music Co., Ltd.
11/F., Silvercord Tower 1, 30 Canton Road,
Tsimshatsui, Kowloon, Hong Kong
Tel: 2737-7688
INDIA
Yamaha Music India Pvt. Ltd.
5F Ambience Corporate Tower Ambience Mall Complex
Ambience Island, NH-8, Gurgaon-122001, Haryana, India
Tel: 0124-466-5551
INDONESIA
PT. Yamaha Music Indonesia (Distributor)
PT. Nusantik
Gedung Yamaha Music Center, Jalan Jend. Gatot
Subroto Kav. 4, Jakarta 12930, Indonesia
Tel: 21-520-2577
KOREA
Yamaha Music Korea Ltd.
8F, 9F, Dongsung Bldg. 158-9 Samsung-Dong,
Kangnam-Gu, Seoul, Korea
Tel: 080-004-0022
MALAYSIA
Yamaha Music Malaysia, Sdn., Bhd.
Lot 8, Jalan Perbandaran, 47301 Kelana Jaya,
Petaling Jaya, Selangor, Malaysia
Tel: 3-78030900
PHILIPPINES
Yupangco Music Corporation
339 Gil J. Puyat Avenue, P.O. Box 885 MCPO,
Makati, Metro Manila, Philippines
Tel: 819-7551
SINGAPORE
Yamaha Music Asia Pte., Ltd.
#03-11 A-Z Building
140 Paya Lebor Road, Singapore 409015
Tel: 747-4374
TAIWAN
Yamaha KHS Music Co., Ltd.
3F, #6, Sec.2, Nan Jing E. Rd. Taipei.
Taiwan 104, R.O.C.
Tel: 02-2511-8688
THAILAND
Siam Music Yamaha Co., Ltd.
4, 6, 15 and 16th floor, Siam Motors Building,
891/1 Rama 1 Road, Wangmai,
Pathumwan, Bangkok 10330, Thailand
Tel: 02-215-2626
OTHER ASIAN COUNTRIES
Yamaha Corporation,
Asia-Pacific Music Marketing Group
Nakazawa-cho 10-1, Naka-ku, Hamamatsu,
Japan 430-8650
Tel: +81-53-460-2317
AUSTRALIA
Yamaha Music Australia Pty. Ltd.
Level 1, 99 Queensbridge Street, Southbank,
Victoria 3006, Australia
Tel: 3-9693-5111
NEW ZEALAND
Music Works LTD
P.O.BOX 6246 Wellesley, Auckland 4680,
New Zealand
Tel: 9-634-0099
COUNTRIES AND TRUST
TERRITORIES IN PACIFIC OCEAN
Yamaha Corporation,
Asia-Pacific Music Marketing Group
Nakazawa-cho 10-1, Naka-ku, Hamamatsu,
Japan 430-8650
Tel: +81-53-460-2312
NORTH AMERICA
CENTRAL & SOUTH AMERICA
EUROPE
AFRICA
MIDDLE EAST
ASIA
OCEANIA
HEAD OFFICE Yamaha Corporation, Pro Audio & Digital Musical Instrument Division
Nakazawa-cho 10-1, Naka-ku, Hamamatsu, Japan 430-8650
Tel: +81-53-460-3273
EKB49
U.R.G., Digital Musical Instruments Division
© 2009 – 2011 Yamaha Corporation
WR35340 109MWAPX.X-XXC0
Printed in China
Yamaha Home Keyboards Home Page
http://music.yamaha.com/homekeyboard/
Yamaha Manual Library
http://www.yamaha.co.jp/manual/

Navigation menu
