Sommario
S30 Voice List ................................2
Quick Access Voice List................8
Drum Voice List..............................9
Wave List ......................................12
Performance List..........................13
Control List ..................................14
Arpeggio Type List ......................15
Effect Type List ............................16
Effect Parameter List ..................16
A proposito di MIDI......................25
Formato dei dati MIDI ..................25
Tabella dei dati MIDI ....................29
Tabella di implementazione MIDI 37
DATA LIST
DATA LIST
MUSIC SINTHESIZER
MUSIC SYNTHESIZER
2
Preset 1 (MSB=63, LSB=0)
No. Voice Name Category Reverb Type Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS Kn1 Kn2
StereoGrnd Pf Hall 1 Chorus 1 3band EQ Thru ChoSend off off off off off ChoSend RevSend
StereoGnd2 Pf Hall 1 Chorus 1 3band EQ Thru ChoSend off off off off off FLT-Frq RevSend
CF Grand M Pf Hall 1 Chorus 1 3band EQ Thru ChoSend off off off off off ChoSend RevSend
Dark Grand Pf Hall 1 Chorus 1 Thru Thru ChoSend off off off off off FLT-Frq RevSend
Difference Pf Hall 1 Chorus 1 3band EQ Thru ChoSend off off off off off FLT-Frq RevSend
Piano/Ep Pf Hall 1 Chorus 1 Chorus 1 3Band EQ ChoSend, Volume off off off off off FLT-Frq ELM-Lvl, ELM-Lvl
Piano/Strg Co Hall 1 Chorus 1 3band EQ Thru ELM-Lvl off off off off off FLT-Frq RevSend
Piano/Oohs Pf Hall 1 Chorus 1 3band EQ Thru ELM-Lvl off off off off off FLT-Frq RevSend
CP2000 Pf Hall 1 Flanger 3 3band EQ Thru ChoSend off off off off off ELM-Lvl FLT-Frq
Piano/DX Pf Hall 1 Chorus 1 3band EQ Chorus 5 CLFO-D1 off off off off off ChoSend, Volume RevSend
Wurlitrm Pf Room 1 Celeste 1 Thru Tremolo InsL prm2, Volume off off off off off FLT-Frq ChoSend, RevSend
DF EP IV Pf Hall 1 Chorus 1 3band EQ Pitch Change 1 InsS prm2 off off off off off FLT-Frq ChoSend, RevSend
DF EP III Pf Hall 2 Chorus 1 Compressor Celeste 1 InsL prm3, InsL prm1 off off off off off InsL prm10 RevSend
Herb Roadz Pf Hall 2 Chorus 1 Auto Pan Comp Distortion InsS prm1 off off off off off InsS prm2 RevSend
BasicRoadz Pf Hall 2 Chorus 1 3band EQ Auto Pan InsL prm1 off off off off off InsL prm2 ChoSend, RevSend
19 Roadz Pf Stage 2 Chorus 1 Compressor Phaser 1 InsL prm2 off off off off off InsL prm4 RevSend
Vic’sRoadz Pf Hall 1 Celeste 2 3band EQ Auto Pan InsL prm2, InsL prm1 off off off off off ChoSend RevSend
ErlyFusion Pf Hall 1 Phaser Touch Wah 3Band EQ CLFO-D1 off off off off off RevSend ChoSend
Grapevine Pf Room 2 Chorus 1 Auto Pan V-Distortion ELFO-PM off off off off off AEG-D1 RevSend
VintgCond Pf Hall 1 Chorus 1 3band EQ Auto Pan InsL prm1, InsL prm2,
InsL prm3 off off off off off RevSend ChoSend
DXAtacky Pf Hall 1 Celeste 1 Chorus 3 Thru CLFO-D1 off off off off off RevSend ChoSend
DigiX Wave Pf Hall 1 Chorus 5 3band EQ Thru CLFO-D1 off off off off off RevSend ChoSend
Dark DX Pf Hall 1 Chorus 1 Thru Thru CLFO-D1 off off off off off FLT-Frq ChoSend, RevSend
Ice Piano Pf Hall 1 Chorus 1 Thru Thru CLFO-D1 off off off off off FLT-Frq ChoSend, RevSend
ChorusBel Pf Stage 1 Delay LR 3band EQ Ensemble Detune InsL prm10 off off off off off RevSend ChoSend
Bel Roadz Pf Hall 1 Chorus 4 Thru Thru ELFO-AM off off off off off RevSend ELFOSpd
Glass EP Pf Hall 1 Chorus 1 Thru Thru ELFO-AM off off off off off RevSend ChoSend
SuperDyno Pf Hall 1 Chorus 1 Compressor Pitch Change 1 InsL prm11, InsL prm13 off off off off off InsS prm4, InsS prm3 RevSend
PowerKeys Sc Room 1 Chorus 1 3band EQ Phaser 2 InsL prm2, InsL prm4,
InsL prm10 off off off off off InsL prm1 RevSend
Harpsicode Pf Room 3 Celeste 1 Thru Thru ChoSend, Volume off off off off off FLT-Frq FEG-D1
Clav Pf Stage 2 Celeste 1 Thru Thru ChoSend, Volume off off off off off FLT-Frq AEG-D1, AEG-D2
Clav Wah Pf Stage 2 Phaser Touch Wah Thru ChoSend, Volume RevSend off off off off FLT-Frq FEG-D1
Perc Org Or Hall 1 Chorus 1 3band EQ 2Way Rotary
Speaker 3 InsL prm16, ChoSend,
ELM-Lvl off off off off off InsL prm9 RevSend
Cool Or Room 1 Chorus 1 Thru 2Way Rotary
Speaker 3 InsL prm16 off off off off off InsL prm9 InsL prm1
ClickOrgan Or Hall 1 Chorus 1 Overdrive Rotary Speaker 1 InsL prm1 off off off off off ELM-Lvl ELM-Lvl
Jazz Or Room 1 Chorus 1 Overdrive Rotary Speaker 1 InsL prm1 off off off off off InsL prm9 InsL prm1
Soft Rock Or Hall 1 Chorus 1 Overdrive Rotary Speaker 1 InsL prm1, ChoSend,
ELM-Lvl off off off off off InsS prm10 ChoSend
Tube Or Hall 1 Chorus 3 AMP Simulator 2Way Rotary
Speaker 3 InsL prm16, InsL prm9 off off off off off InsS prm1, Volume InsL prm9, FLT-Frq
Contnental Or Stage 1 Chorus 1 3band EQ 2Way Rotary
Speaker InsL prm1 off off off off off FLT-Frq RevSend
Swish Or Room 1 Chorus 1 Thru Thru ChoSend, Volume off off off off off FLT-Frq RevSend
4 Bars Or Hall 1 Chorus 1 Overdrive Rotary Speaker 1 InsL prm1 off off off off off RevSend ELM-Lvl
Full Or Hall 1 Chorus 1 3band EQ 2Way Rotary
Speaker 3 InsL prm16, ChoSend,
ELM-Lvl off off off off off ELM-Lvl ELM-Lvl
GiantDrbr Or Room 1 Chorus 1 Thru 2Way Rotary
Speaker 3 InsL prm16 InsL prm2,
InsL prm3 off off off off InsL prm14 InsL prm5, InsL prm6
Sunday Or Hall 2 Chorus 3 2band EQ Thru FLT-Frq off off off off off ELM-Lvl RevSend
Pipes Or Hall 2 Chorus 3 Thru Thru ChoSend off off off off off RevSend ELFO-PM
New Nylon Gt Hall 1 Chorus 1 3band EQ Thru CLFO-D1 off off off off off ELM-Lvl ELM-Lvl, FLT-Frq
JazzGTmelo Gt Hall 1 Chorus 1 3band EQ 3Band EQ CLFO-D1 off off off off off InsS prm4 ChoSend
Melo Trmlo Gt Hall 1 Delay LR Tremolo Comp Distortion FLT-Frq off off off off off InsS prm1 InsS prm2
Strat Chor Gt Hall 1 Delay LR Chorus 1 Comp Distortion ELFO-PM off off off off off InsL prm1, InsL prm4,
Volume, InsL prm14 InsS prm10
StratChor2 Gt Hall 1 Chorus 4 3band EQ AMP Simulator ELFO-PM off off off off off ChoSend, Volume RevSend
18 String Gt Hall 2 Chorus 1 3band EQ 2Band EQ CLFO-D1 off off off off off ChoSend FLT-Frq
Acoustic Gt Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off FEG-D1 ChoSend
MuteGtr Gt Room 3 Phaser Thru Compressor ELFO-PM, ChoSend off off off off off RevSend FLT-Frq, FLT-Rez
DirtyTwn Gt Room 3 Chorus 4 3band EQ V-Distortion ELFO-PM off off off off off InsL prm1 InsL prm11, RevSend
Feedback Gt Room 3 Chorus 4 3band EQ V-Distortion ELFO-PM off off off off off InsL prm1 InsL prm11, RevSend
VOODOO MAN
Gt Room 3 Phaser Touch Wah V-Distortion ELFO-PM, InsS prm4 off InsS prm2 off off off InsL prm1 InsL prm11
Rockabilly Gt Room 3 Chorus 4 3band EQ V-Distortion ELFO-PM off off off off off InsL prm1, Volume InsL prm11, RevSend
Funk It!! Gt Room 3 Delay LR Compressor Auoto WAH
Overdrive FLT-Frq off off off off off InsS prm3, Volume ChoSend
Upright Ba Room 1 Chorus 1 3band EQ Thru ELFO-PM off off off off off FLT-Frq, FLT-Frq ELM-Lvl
Finger Ba Room 3 Chorus 4 Compressor Thru CLFO-D1 off off off off off InsS prm3, Volume ChoSend
PickBass Ba Room 1 Chorus 1 Thru Thru ELFO-PM off off off off off FLT-Frq ChoSend, RevSend
Fretless Ba Hall 1 Chorus 1 3band EQ Thru ELFO-PM off off off off off FLT-Frq ChoSend, RevSend
Slap Ba Room 1 Chorus 1 Compressor Thru ELFO-PM off off off off off FLT-Frq ChoSend, RevSend
Fngr & RW Ba Room 1 Chorus 1 Thru Thru ELFO-PM off ELFO-PM off off off FLT-Frq, FLT-Frq ChoSend, RevSend
1(A01)
2(A02)
3(A03)
4(A04)
5(A05)
6(A06)
7(A07)
8(A08)
9(A09)
10(A10)
11(A11)
12(A12)
13(A13)
14(A14)
15(A15)
16(A16)
17(B01)
18(B02)
19(B03)
20(B04)
21(B05)
22(B06)
23(B07)
24(B08)
25(B09)
26(B10)
27(B11)
28(B12)
29(B13)
30(B14)
31(B15)
32(B16)
33(C01)
34(C02)
35(C03)
36(C04)
37(C05)
38(C06)
39(C07)
40(C08)
41(C09)
42(C10)
43(C11)
44(C12)
45(C13)
46(C14)
47(C15)
48(C16)
49(D01)
50(D02)
51(D03)
52(D04)
53(D05)
54(D06)
55(D07)
56(D08)
57(D09)
58(D10)
59(D11)
60(D12)
61(D13)
62(D14)
63(D15)
64(D16)
S30 Voice List
3
No. Voice Name Category Reverb Type Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS Kn1 Kn2
Background St Hall 2 Chorus 1 3band EQ 3Band EQ CLFO-D1 off off off off off ChoSend, RevSend AEG-Atk, AEG-Rel
Big String St Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off RevSend FLT-Frq, FLT-Rez
Cello Big St Hall 1 Chorus 1 Thru Thru FLT-Frq off off off off off AEG-Rel, AEG-Atk ChoSend, RevSend
Chamberz St Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off RevSend FLT-Frq, FLT-Rez
SmallSect St Hall 1 Chorus 1 3band EQ Thru ChoSend, Volume off off off off off FLT-Frq AEG-Atk, AEG-Rel
CelloSmall St Hall 1 Chorus 1 Thru Thru FLT-Frq off off off off off AEG-Rel, AEG-Atk ChoSend, RevSend,
Volume
Pizz St Hall 1 Chorus 3 Thru Thru ChoSend off off off off off FLT-Frq AEG-D1
Harp St Hall 1 Celeste 2 Thru Thru ELFO-PM off off off off off RevSend ChoSend
Oboe Rd Hall 1 Chorus 1 Thru Thru ELFO-PM, ELFO-AM off off off off off RevSend FLT-Frq
Bssoon Rd Hall 1 Chorus 1 Thru Thru ELFO-PM ELFO-AM off off off off RevSend FLT-Frq
Clarnet Rd Hall 1 Chorus 1 3band EQ Thru ELFO-PM, ELFO-AM off off off off off RevSend FLT-Frq, FLT-Rez
Wind Orch Co Hall 1 Ensemble 3band EQ Thru CLFO-D1, CLFO-D2,
ELFO-PM, ELFO-FM off off off off off FLT-Frq ELM-Lvl
SynthStrgs St Hall 1 Chorus 1 3band EQ Cross Delay FLT-Frq off off off off off ChoSend, Volume RevSend
ObiStrings St Hall 2 Chorus 5 Exciter Cross Delay FLT-Frq, FLT-Rez off off off off off InsS prm1 ChoSend
Fanfare Br Hall 1 Chorus 1 3band EQ Thru CLFO-D1 off off off off off ChoSend, Volume RevSend
MediumBrss Br Hall 1 Chorus 1 3band EQ Thru CLFO-D1 off off off off off ChoSend, Volume RevSend
Two Brass Br Hall 1 Chorus 1 Thru Thru ELFO-FM, ELFO-PM off off off off off FLT-Frq ChoSend, Volume
Brass&Sax Br Hall 1 Chorus 1 Thru Thru ELFO-FM, ELFO-PM off off off off off FLT-Frq ChoSend, Volume
Dark Class Br Hall 1 Chorus 1 Thru Thru ELFO-FM, ELFO-PM off off off off off FLT-Frq ChoSend, Volume
Stereo Brs Br Hall 1 Chorus 1 Thru Thru ELFO-FM, ELFO-PM off off off off off FLT-Frq ChoSend, Volume
Trumpet Br Hall 1 Ensemble Thru Delay LCR ELFO-PM, ELFO-FM off off off off off RevSend ChoSend, FLT-Rez
Mute Trpt Br Hall 1 Chorus 1 3band EQ Thru ELFO-PM ELFO-AM off off off off RevSend HPF-Frq
Tenor Sax Rd Hall 1 Chorus 1 3band EQ Thru ELFO-PM, ELFO-AM off off off off off FLT-Frq ChoSend
Alto Sax Rd Hall 1 Chorus 1 3band EQ Thru ELFO-PM, ELFO-AM off off off off off FLT-Frq ChoSend
Bari Sax Rd Hall 1 Chorus 1 3band EQ Thru ELFO-PM, ELFO-FM off off off off off FLT-Frq ChoSend
Soprano Rd Hall 1 Delay LR 3band EQ Thru ELFO-PM off off off off off RevSend ChoSend
ObrBrass Br Hall 1 Chorus 4 3band EQ Chorus 4 CLFO-D1 off off off off off RevSend FLT-Frq, FLT-Rez
PowerSynth Br Hall 1 Chorus 1 3band EQ Harmonic Enhancer CLFO-D1 off off off off off InsL prm3 RevSend
Synth Horn Br Hall 2 Chorus 1 Thru Tempo Cross Delay FLT-Frq, ChoSend,
RevSend off off off off off InsL prm10 FLT-Rez
M Brass Br Hall 1 Delay LR Thru Thru ELFO-PM off off off off off FLT-Frq, FLT-Rez PEG-Dpt, PEG-Atk
Moon AT Br Hall 1 Chorus 1 3band EQ Harmonic Enhancer CLFO-D1 off FLT-Frq,
Volume off off off PCH-Crs RevSend
SquishBrs Br Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off FLT-Rez RevSend, ChoSend
Ooh Choir Vo Hall 2 Delay LR Exciter 3Band EQ CLFO-D1 off off off off off AEG-Atk, AEG-Rel RevSend, ChoSend
Ahh Choir Vo Hall 2 Delay LR 3band EQ Talking Modulator CLFO-D1 off off off off off AEG-Atk, AEG-Rel RevSend, ChoSend
Panmonks Vo Plate Delay LR Tremolo Ensemble Detune InsS prm2 off off off off off AEG-Rel RevSend, ChoSend
Pad Ooh En Hall 1 Ensemble Chorus 1 Thru InsS prm10, ChoSend off off off off off FLT-Frq AEG-Atk, AEG-Rel
Soft Pad Pd Hall 1 Chorus 1 Thru V-Flanger InsL prm14 off off off off off ELM-Lvl ChoSend
FatSweep Pd Hall 2 Symphonic Chorus 4 Cross Delay ELFO-PM off off off off off ChoSend InsL prm10
Cumulus Pd Hall 1 Delay LR Celeste 3 Harmonic Enhancer ELFO-FM off off off off off RevSend ChoSend
Big Wing Pd Stage 1 Ensemble Celeste 4 Harmonic Enhancer ELM-Lvl off off off off off InsL prm3 RevSend
Slide in Pd Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off PEG-Atk ChoSend
BPFx Pd Hall 2 Ensemble Chorus 4 Cross Delay CLFO-D1, ELM-Lvl off CLFO-D1 off off off FEG-Dpt InsL prm10
DigiSweep Pd Hall 2 Chorus 5 Compressor Tempo Cross Delay FLT-Frq, FEG-Dpt,
RevSend off off off off off ChoSend RevSend
JM Pad Pd Hall 2 Chorus 4 Thru Phaser 2 ELFO-PM, InsL prm1,
InsL prm2 off off off off off FLT-Frq FLT-Rez
Vermillion Pd Hall 1 Tempo Delay2 Thru Pitch Change 1 ELFO-PM off off off off off FLT-Frq ChoSend, RevSend
Magenta Pd Hall 1 Chorus 1 Flanger 1 Delay LCR ELFO-PM, FLT-Frq off ELFO-PM off off off FLT-Frq RevSend, ChoSend
Liquito Sc Hall 1 Chorus 1 Compressor V-Flanger AEG-Rel, FLT-Frq,
AEG-D1 off off off off off FLT-Rez ChoSend, RevSend
Shadow Fx Hall 2 Flanger 1 Celeste 4 Jump InsL prm2, ChoSend off off off off off FLT-Frq InsL prm9
Vibes Cp Hall 1 Celeste 2 Thru 3Band EQ ChoSend off off off off off ELFO-AM ELFOSpd
Marimba Cp Hall 1 Celeste 2 Thru Thru ELFO-AM off off off off off FLT-Frq, FLT-Rez RevSend, ChoSend
Gamelan Cp Hall 1 Symphonic Thru Thru ChoSend off off off off off FLT-Frq AEG-Atk, AEG-Rel
Xylo Cp Hall 1 Celeste 2 Thru Thru ELFO-FM off off off off off RevSend ChoSend
Glocken Cp Hall 2 Celeste 2 Thru Thru ChoSend off off off off off RevSend ELFO-PM
Crotales Cp Hall 1 Celeste 2 Thru Thru FLT-Frq off off off off off FLT-Frq RevSend
Timpani Pc Hall 1 Celeste 2 Thru Thru ELFO-AM off off off off off AEG-Atk FLT-Frq
SteelDrum Cp Hall 1 Celeste 2 Thru Thru ELFO-FM, ChoSend off off off off off AEG-Rel RevSend
Sitar Et Hall 1 Flanger 1 3band EQ Ensemble Detune ELFO-PM off off off off off ChoSend RevSend
BrthFlute Pi Hall 1 Chorus 1 Thru Thru CLFO-D1, CLFO-D2 off off off off off FLT-Frq ELM-Lvl
Pan Flute Pi Hall 1 Chorus 1 Thru Thru ELFO-AM, ELFO-FM off off off off off FLT-Frq, FLT-Rez AEG-Atk
Accordion Or Hall 1 Ensemble Thru Thru ChoSend off off off off off HPF-Frq FLT-Frq
Monica Rd Stage 1 Ensemble AMP Simulator Touch WAH ELFO-PM FLT-Frq ELFO-PM off off off ChoSend RevSend
BluesHarp Rd Stage 2 Chorus 1 Touch Wah V-Distortion ELFO-AM, CLFO-D1,
ELFO-PM FLT-Frq off off off off InsL prm1 RevSend
Amandla Co Stage 1 Delay LR 2band EQ Celeste 4 ELFO-PM off ELFO-PM off off off RevSend ChoSend
AnalogSplt Co Hall 1 Chorus 1 Phaser Tempo Delay 2 ELFO-PM off ELFO-PM off off off InsS prm1 InsL prm10
65(E01)
66(E02)
67(E03)
68(E04)
69(E05)
70(E06)
71(E07)
72(E08)
73(E09)
74(E10)
75(E11)
76(E12)
77(E13)
78(E14)
79(E15)
80(E16)
81(F01)
82(F02)
83(F03)
84(F04)
85(F05)
86(F06)
87(F07)
88(F08)
89(F09)
90(F10)
91(F11)
92(F12)
93(F13)
94(F14)
95(F15)
96(F16)
97(G01)
98(G02)
99(G03)
100(G04)
101(G05)
102(G06)
103(G07)
104(G08)
105(G09)
106(G10)
107(G11)
108(G12)
109(G13)
110(G14)
111(G15)
112(G16)
113(H01)
114(H02)
115(H03)
116(H04)
117(H05)
118(H06)
119(H07)
120(H08)
121(H09)
122(H10)
123(H11)
124(H12)
125(H13)
126(H14)
127(H15)
128(H16)
4
Preset 2 (MSB=63, LSB=1)
No. Voice Name Category
Reverb Type
Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS Kn1 Kn2
1001 Sub Ba Stage 2 Ensemble Thru Echo ChoSend, ELM-Lvl off off off off off FLT-Frq, FEG-D1 InsL prm10
Trancy Ba Hall 1 Chorus 4 Thru Delay LR ChoSend, ELM-Lvl off off off off off FEG-Atk InsL prm10
Velo Ba Stage 2 Chorus 1 Thru Auto WAH InsL prm10, RevSend off off off off off FEG-Atk ChoSend
Wonk Ba Hall 1 Ensemble 3band EQ Thru ELFO-PM off off off off off FLT-Rez RevSend, ChoSend
Mini 1 Ba Room 1 Chorus 1 3band EQ Pitch Change 1 ELFO-PM off off off off off InsL prm10 RevSend
Mini 2 Ba Room 1 Chorus 1 3band EQ Pitch Change 1 ELFO-PM off off off off off InsL prm10 RevSend
D-sub Ba Hall 1 Flanger 1 Thru Thru ELFO-PM off off off off off FLT-Frq ChoSend
Lately Ba Room 3 Control Delay1 Compressor AMP Simulator ELFO-PM off off off off off InsL prm10 ELFOSpd
Dark Ba Stage 2 Chorus 1 Thru Thru FLT-Frq off off off off off FEG-Atk, FEG-D1 ChoSend, ELM-Lvl
Moonbass Ba Hall 1 Flanger 1 Thru Thru ELFO-PM off off off off off FLT-Frq ChoSend
Snoop Bs Ba Hall 1 Phaser 3band EQ Thru ELFO-PM off off off off off FLT-Frq ChoSend, RevSend
LoTic Bass Ba Room 1 Chorus 1 Thru Chorus 1 ELFO-PM, Volume off ELFO-PM off off off AEG-Atk, AEG-Rel ChoSend
Taurus Ba Hall 1 Flanger 1 Thru Thru ELFO-PM off off off off off FLT-Frq, FLT-Rez ChoSend
Fuzzline Ba Hall 1 Phaser Distortion Delay LR ChoSend, ELM-Lvl off off off off off InsS prm10, ELM-Lvl InsL prm10
Deep One Ba Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off FLT-Frq FLT-Rez
Squbase Ba Hall 1 Tempo Cross
Delay Flanger 1 Thru ELFO-FM, ELM-Lvl off off off off off InsS prm10, ChoSend InsS prm3
Portachrd Sc Hall 1 Chorus 4 Thru Delay LR FLT-Rez, FLT-Frq,
ChoSend off off off off off FEG-Atk ChoSend
Thin man Sc Hall 2 Ensemble Compressor Cross Delay FLT-Frq off off off off off AEG-Atk, AEG-Rel ChoSend, ELM-Lvl
PopularSyn Sc Hall 1 Chorus 1 Auto Wah Cross Delay InsS prm2 off off off off off ChoSend InsL prm10
Straight Sc Hall 1 Ensemble Celeste 4 Cross Delay ELFO-PM off off off off off FLT-Rez, InsS prm1 AEG-Rel, FLT-Rez
Poly Sc Hall 1 Ensemble Auto Wah Delay LR ELFO-PM off off off off off FLT-Frq, FEG-Dpt InsS prm9
Zap Comp Sc Hall 1 Chorus 1 Touch Wah Cross Delay ELFO-PM off off off off off FLT-Rez RevSend, ChoSend
AnaTonk Sc Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off FEG-D1, FEG-D2 ChoSend
Insomnia Sc Hall 1 Tempo Phaser Compressor Thru FLT-Frq off off off off off ELM-Lvl RevSend
Q Hit Sc White Room Control Delay1 Exciter Gate Reverb ELFO-PM off off off off off ELM-Lvl, FLT-Frq RevSend
BPF1 Sc Hall 1 Chorus 1 Thru Thru CLFO-D1 off off off off off FLT-Frq, FLT-Frq FEG-Atk
T-Eight Sc Hall 1 Delay LR Chorus 1 Compressor ELFO-PM, CLFOSpd,
InsS prm10 off off off off off FLT-Frq, FEG-Dpt FEG-Atk
L7 octs Sc Hall 1 Celeste 3 Thru Thru ELFO-PM off off off off off FLT-Frq ChoSend, Volume
NoizRezz Sc Hall 1 Chorus 2 Thru Tempo Cross Delay ELFO-PM off off off off off InsL prm10, ChoSend RevSend
GX Sc Hall 1 Celeste 4 Thru Thru CLFO-D1 off off off off off FLT-Frq ChoSend, RevSend
Noise Harp Sc Room 3 Celeste 2 Thru Hall 1 ELFO-PM off off off off off ChoSend RevSend
Syntax Ld Hall 1 Ensemble Flanger 3 Delay LCR FLT-Frq off off off off off InsS prm10 ChoSend
Tri Solo Ld Hall 1 Delay LR 3band EQ Thru ELFO-PM off off off off off FLT-Frq ChoSend, Volume,
RevSend
Smooth Saw Ld Hall 1 Delay LR Thru Thru ELFO-PM off off off off off FLT-Frq ChoSend, Volume,
RevSend
Frontline Ld Hall 1 Ensemble Distortion Cross Delay ChoSend, ELM-Lvl off off off off off PCH-Fin ChoSend
Lucky Ld Hall 1 Chorus 3 Thru Thru ELFO-PM off off off off off FLT-Frq ChoSend, Volume
Sneaky Ld Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off FEG-Dpt FLT-Rez
Rap Lead 1 Ld Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off FLT-Frq FLT-Rez
Rap Lead 2 Ld Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off FLT-Frq FLT-Rez
Rap Lead 3 Ld Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off FLT-Frq FLT-Rez
PhazFilter Ld Hall 1 Tempo Phaser Chorus 1 Ensemble Detune ELFO-PM off off off off off InsS prm10, InsL prm10,
InsS prm2 PEG-Dpt
SpaceWhirl Ld Tunnel Tempo Delay2 Compressor Tempo Phaser InsL prm10, FLT-Frq,
AEG-Rel off off off off off RevSend ChoSend
X-File Ld Stage 1 Delay LR Thru V-Flanger ELFO-PM off off off off off PorTime RevSend
BreathSaw Ld Hall 1 Delay LR 2band EQ Ambience CLFO-D1, CLFO-D2 off off off off off ELM-Lvl RevSend
1 is more Ld Hall 1 Ensemble Thru Delay LR ELFO-PM off off off off off ChoSend AEG-Atk
Mini Pulse Ld Hall 2 Chorus 2 Compressor Tempo Cross Delay ELFO-PM off off off off off ChoSend RevSend, InsL prm10
Syntrump Ld Hall 1 Tempo Delay1 Thru Thru ELFO-PM off off off off off FLT-Frq ChoSend
Eagle Ld Hall 1 Tempo Delay1 Thru Thru ELFO-PM off off off off off FLT-Frq ChoSend
Oberweich Pd Hall 1 Chorus 1 Thru Thru CLFO-D1 off off off off off ChoSend RevSend
5thBreath Pd Hall 2 Ensemble Exciter Cross Delay CLFO-D1 off off off off off FLT-Frq, FLT-Rez InsL prm10
Rain Pad Pd Hall 1 Chorus 1 Thru Thru ChoSend, Volume off off off off off FLT-Rez ELM-Lvl, ELM-Lvl
Vortex Pd White Room Chorus 1 Flanger 3 Thru ELFO-PM, ELFO-FM off off off off off PEG-Dpt InsS prm1
Sprinkler Pd Hall 1 Chorus 1 Thru V-Flanger PCH-Crs, Volume off off off off off ELM-Lvl AEG-Atk, AEG-Rel
Astronaut Pd Stage 1 Celeste 4 Phaser Ambience FLT-Frq off off off off off ChoSend RevSend, InsL prm10
BrassyPad Pd Hall 1 Delay LR Chorus 1 V-Flanger ELM-Lvl off off off off off FLT-Frq InsL prm14, InsL prm2
Sine Pad Pd Hall 2 Chorus 1 Thru Symphonic CLFO-D1 off off off off off ChoSend RevSend
Big Syn St Hall 2 Chorus 5 Exciter Cross Delay FLT-Frq, FLT-Rez off off off off off ELM-Lvl ELM-Lvl
Berlin Sc Hall 2 Flanger 3 Chorus 4 Cross Delay ChoSend, ELM-Lvl,
FLT-Frq off off off off off FLT-Frq PEG-Dpt
Filtopia Sc Hall 1 Chorus 1 Compressor Hall 2 ELM-Lvl, ChoSend,
FLT-Frq off off off off off FEG-Atk FLT-Frq
Poppy Vox Sc Hall 1 Symphonic Exciter Hall 1 ELFO-PM FLT-Frq off off off off ChoSend RevSend
Arabesque Sc Hall 1 Chorus 1 Compressor Hall 2 FLT-Frq, ELM-Lvl,
ELM-Pan off off off off off InsL prm13 AEG-D1
Crecendar Sc Hall 1 Chorus 1 Flanger 1 Delay LCR ELFO-PM, FLT-Frq off ELFO-PM,
InsS prm1 off off off FLT-Frq FLT-Rez
Soft Dream Co Hall 2 Symphonic Celeste 4 Thru CLFO-D1, ChoSend off off off off off FLT-Frq ChoSend
ChimzArt Co Hall 1 Chorus 1 Compressor Hall 2 ELM-Lvl, ELM-Lvl,
Volume off off off off off ChoSend ELM-Pan
1(A01)
2(A02)
3(A03)
4(A04)
5(A05)
6(A06)
7(A07)
8(A08)
9(A09)
10(A10)
11(A11)
12(A12)
13(A13)
14(A14)
15(A15)
16(A16)
17(B01)
18(B02)
19(B03)
20(B04)
21(B05)
22(B06)
23(B07)
24(B08)
25(B09)
26(B10)
27(B11)
28(B12)
29(B13)
30(B14)
31(B15)
32(B16)
33(C01)
34(C02)
35(C03)
36(C04)
37(C05)
38(C06)
39(C07)
40(C08)
41(C09)
42(C10)
43(C11)
44(C12)
45(C13)
46(C14)
47(C15)
48(C16)
49(D01)
50(D02)
51(D03)
52(D04)
53(D05)
54(D06)
55(D07)
56(D08)
57(D09)
58(D10)
59(D11)
60(D12)
61(D13)
62(D14)
63(D15)
64(D16)
5
No. Voice Name Category Reverb Type Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS Kn1 Kn2
Seal Sq Hall 2 Tempo Cross
Delay Chorus 4 Ensemble Detune FLT-Rez, ELM-Lvl off off off off off ELM-Lvl ChoSend
Shine Seq Sq Hall 1 Tempo Cross
Delay Chorus 1 Ensemble Detune FLT-Rez off off off off off FLT-Frq, ELM-Lvl,
CLFO-D1 FLT-Rez
Kickwheel Sq Hall 1 Tempo Flanger Distortion Delay LR ELM-Lvl, ChoSend off off off off off InsL prm10, ELM-Lvl HPF-Frq
Supersnap Sq Hall 1 Phaser Compressor Delay LR ELM-Lvl off off off off off ELM-Lvl ChoSend, InsL prm10
Opener Sq Hall 1 Tempo Cross
Delay Chorus 4 Tempo Phaser FLT-Frq, InsL prm10 off off off off off FEG-Atk ChoSend, InsL prm10
Rosy Sq Hall 1 Ensemble Thru Delay LR FLT-Frq off off off off off FEG-Atk InsL prm10
LAizer Sq Hall 2 Chorus 2 Compressor Tempo Delay 2 ELM-Lvl, FLT-Frq,
ChoSend off off off off off ELM-Dly InsL prm10
2 Friends Sq Hall 2 Tempo Delay2 Phaser Hall 2 ELM-Lvl, ChoSend,
AEG-D1 off off off off off InsS prm10 FLT-Frq
Synfonic Sq Hall 2 Chorus 1 Thru Tempo Cross Delay InsL prm10, ChoSend,
FLT-Frq off off off off off InsL prm10 RevSend
Hard road Sq Hall 1 Flanger 2 AMP Simulator Delay LR FEG-Atk, FLT-Frq off off off off off FEG-Atk, FLT-Frq InsS prm6
Quartz Sq Tunnel Control Delay1 Flanger 3 Voice Cancelar ELM-Lvl off off off off off InsL prm11 InsL prm12
Atom Dr White Room Phaser Touch Wah Talking Modulator ELFOSpd off off off off off InsL prm1 RevSend
Chordal Sq Hall 1 Chorus 4 Thru Delay LR AEG-D2, FLT-Frq off off off off off PEG-Dpt InsL prm10, ChoSend
Orgmatic Sq Hall 2 Phaser Compressor Tempo Delay 2 InsL prm10, ELM-Lvl,
ELM-Lvl off off off off off FLT-Frq RevSend
Ana Plus Sq Hall 1 Tempo Cross
Delay Compressor Ensemble Detune ELM-Lvl, InsL prm10 off off off off off ELM-Lvl InsS prm3, InsS prm5
Frequencyz Se off Tempo Cross
Delay Thru Gate Reverb ChoSend off off off off off FLT-Frq, FLT-Frq InsL prm10
Psycho Se Hall 1 Chorus 1 Thru Harmonic Enhancer ELFO-PM off FLT-Rez off off off RevSend PCH-Crs
S - E Se Stage 2 Chorus 1 Flanger 3 Tempo Cross Delay ELFO-PM off off off off off InsS prm3 InsS prm1
Voltage Se Hall 2 Flanger 2 AMP Simulator Auto Synth InsL prm13 off off off off off InsL prm1 ChoSend, ELM-Lvl
Ectoplasm Se Hall 1 Tempo Cross
Delay Chorus 2 Symphonic InsL prm1 off off off off off FLT-Frq ELFO-AM
Millenium Se Hall 1 Flanger 1 Exciter Hall 2 ELFO-PM, ELFO-FM off off off off off FLT-Frq ELFO-PM
Noire Se Plate Delay LR Flanger 3 Ensemble Detune ELFO-PM off off off off off InsS prm3, InsS prm2 PCH-Crs
Falling Se Hall 1 Chorus 1 Thru Hall 1 ChoSend, Volume off off off off off FLT-Rez ELM-Lvl, ELM-Lvl
Topnotched Se Hall 1 Tempo Delay2 Thru Thru ELFO-AM, Volume off off off off off ELFOSpd FLT-Frq, FLT-Frq
Drumnotize Se Hall 1 Chorus 1 3band EQ AMP Simulator ELFO-PM off off off off off FLT-Frq FLT-Rez
Creature Se Hall 1 Control Delay1 Thru Pitch Change 2 FLT-Frq off off off off off ChoSend RevSend
Develop Se Basement Phaser Phaser Pitch Change 2 InsS prm1 off off off off off ELM-Lvl RevSend
Twilight Se Canyon Tempo Cross
Delay Celeste 4 Pitch Change 1 ELFO-AM, ELFOSpd off off off off off ELFOSpd, CLFOSpd PCH-Crs
RisingHigh Fx Hall 1 Chorus 1 Thru Thru ELFO-AM off off off off off RevSend ChoSend
90th Jimi Fx Hall 1 Flanger 2 AMP Simulator Jump ChoSend, FLT-Frq off off off off off FEG-Atk, FLT-Frq InsS prm6
Dew-drop Fx Stage 1 Tempo Delay1 Phaser Pitch Change 2 InsS prm1 off off off off off ELM-Lvl InsL prm10, ChoSend
SpaceTrain Fx Hall 1 Ensemble Phaser Ensemble Detune ELFOSpd off off off off off ChoSend RevSend
Brown Eyes Fx Plate Symphonic Exciter Auto Synth InsL prm10, FEG-Atk off off off off off InsL prm12 InsL prm3
Glacier Fx Stage 1 Tempo Cross
Delay Celeste 4 Harmonic Enhancer InsS prm1 off off off off off ELM-Lvl ChoSend
Sahara Fx Hall 1 Chorus 1 Flanger 1 Hall 1 FLT-Frq off off off off off AEG-Atk ChoSend
Sunnydaze Fx Stage 1 Tempo Cross
Delay Chorus 1 Chorus 1 ELFO-AM, ELM-Lvl off off off off off InsL prm10, InsS prm10 ELFOSpd
Starlight Fx Hall 1 Chorus 1 Thru Pitch Change 2 ELM-Lvl off off off off off FLT-Frq ChoSend
Roxy Fx Hall 2 Ensemble Chorus 4 Thru CLFO-D1, CLFO-D2,
ELM-Lvl off off off off off FEG-Dpt CLFOSpd
Bel Air Fx Hall 2 Chorus 4 Exciter Flanger 3 InsS prm1, FLT-Rez,
FLT-Frq off off off off off InsL prm10 ChoSend
Answers Fx Hall 1 Chorus 1 Thru Delay LR Volume off off off off off ELM-Dly RevSend
Bassline Ba Hall 1 Flanger 2 Distortion Delay LCR ChoSend, ELM-Lvl off off off off off FEG-Atk InsS prm10, InsL prm10
Boom Bass Ba Room 3 Symphonic Compressor Voice Cancelar PEG-Atk off off off off off ELFO-PM ELFOSpd
Drone Ba Hall 2 Chorus 2 Compressor Tempo Delay 2 FLT-Frq, CLFOSpd,
FLT-Rez off off off off off InsL prm10, ChoSend RevSend
Sweepy Ba Hall 2 Chorus 4 Thru Delay LR FLT-Frq, ChoSend off off off off off FEG-Atk InsL prm10, ChoSend
Super DX Ba Room 1 Chorus 1 Exciter Ensemble Detune ELFO-PM off off off off off FLT-Frq FLT-Rez
GangstaM Ba Room 1 Symphonic Compressor Tempo Cross Delay FLT-Frq, RevSend off off off off off ChoSend, Volume RevSend
FM Perko Ba Room 1 Chorus 2 Compressor V-Flanger ChoSend, ELM-Lvl,
Volume off off off off off RevSend FLT-Frq
DX100 Ba Room 3 Chorus 1 Thru Thru FLT-Frq off off off off off ELFO-FM RevSend
BriteGrand Pf Hall 1 Chorus 1 3band EQ Flanger 3 InsL prm10 off off off off off ChoSend RevSend
Slamming Pf Room 3 Tempo Delay2 Compressor Voice Cancelar AEG-D1 off off off off off InsL prm11 InsL prm12
Danzze Pf Room 1 Control Delay1 Overdrive Thru ChoSend, RevSend off off off off off ELM-Pan FLT-Frq
House Pf Room 2 Control Delay2 Compressor Ambience RevSend off off off off off InsL prm10 ChoSend, FLT-Frq
M25 Pf Hall 1 Tempo Delay1 Exciter Pitch Change 1 InsL prm10 off off off off off PCH-Fin ChoSend
AcidFly Pf Stage 1 Delay LR AMP Simulator Digital Scratch ChoSend, RevSend off off off off off InsL prm5 InsL prm11
Nite Roadz Pf Hall 2 Chorus 1 Compressor Celeste 4 InsL prm1, InsL prm2 off off off off off InsL prm10 RevSend
GS Brassy Sc Hall 1 Chorus 1 Chorus 1 Thru ELFO-PM off off off off off FEG-D2, FEG-D1, AEG-D2 RevSend
Grand Pad Co Hall 1 Chorus 1 3band EQ Tempo Cross Delay AEG-Atk off off off off off FLT-Frq InsL prm10
Ibiza Co Hall 1 Tempo Delay1 Compressor Celeste 4 FLT-Frq off off off off off RevSend ChoSend
Meltpiano Co Plate Chorus 1 Thru Symphonic ELM-Lvl off off off off off ELM-Lvl RevSend
HonkyTonk Pf Room 1 Chorus 1 Thru Pitch Change 1 ChoSend off off off off off FLT-Frq RevSend
For Ballad Pf Hall 1 Delay LR Thru Chorus 4 ELM-Lvl off off off off off ChoSend RevSend
ShineHarmo Pf Hall 1 Chorus 1 3band EQ Chorus 5 ChoSend, Volume off off off off off PCH-Crs RevSend
TripleDark Pf Hall 1 Chorus 1 3band EQ Thru ChoSend off off off off off FLT-Frq RevSend
StageBrite Pf Hall 1 Chorus 1 Thru Harmonic Enhancer ChoSend off off off off off FLT-Frq RevSend
65(E01)
66(E02)
67(E03)
68(E04)
69(E05)
70(E06)
71(E07)
72(E08)
73(E09)
74(E10)
75(E11)
76(E12)
77(E13)
78(E14)
79(E15)
80(E16)
81(F01)
82(F02)
83(F03)
84(F04)
85(F05)
86(F06)
87(F07)
88(F08)
89(F09)
90(F10)
91(F11)
92(F12)
93(F13)
94(F14)
95(F15)
96(F16)
97(G01)
98(G02)
99(G03)
100(G04)
101(G05)
102(G06)
103(G07)
104(G08)
105(G09)
106(G10)
107(G11)
108(G12)
109(G13)
110(G14)
111(G15)
112(G16)
113(H01)
114(H02)
115(H03)
116(H04)
117(H05)
118(H06)
119(H07)
120(H08)
121(H09)
122(H10)
123(H11)
124(H12)
125(H13)
126(H14)
127(H15)
128(H16)
6
Internal (MSB=63, LSB=8)
No. Voice Name Category Reverb Type Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS Kn1 Kn2
Hybrid Pf Hall 1 Chorus 1 Thru Thru ChoSend off off off off off FLT-Frq, FLT-Rez RevSend
DarkGrand2 Pf Room 2 Chorus 1 3band EQ Thru ChoSend off off off off off FLT-Frq RevSend
BrtStereo Pf Hall 1 Celeste 1 3band EQ Phaser 2 InsL prm10 off off off off off ChoSend RevSend
HonkyTnk2 Pf Room 3 Chorus 1 Thru Thru ChoSend off off off off off FLT-Frq RevSend
Differenc2 Pf Hall 1 Chorus 1 3band EQ Harmonic Enhancer InsL prm3 off off off off off ChoSend RevSend
Piano/Ep2 Pf Hall 1 Chorus 1 Chorus 1 Thru FLT-Frq, ELM-Lvl off off off off off ELM-Lvl, ELM-Lvl InsS prm10
Pno/Oo/Str Co Hall 1 Chorus 1 Chorus 2 Thru ELM-Lvl off off off off off ELM-Lvl ChoSend
Grand Pad2 Co Hall 1 Delay LR Chorus 1 Thru ELM-Lvl off off off off off FLT-Frq ChoSend
Phase CP Pf Room 1 Chorus 1 Thru Phaser 2 FLT-Frq off off off off off InsL prm10, InsL prm4,
InsL prm2 RevSend
CP Layer Pf Room 2 Ensemble Thru Thru RevSend off off off off off FLT-Frq ChoSend
Wurli Amp Pf Room 1 Celeste 1 Overdrive Tremolo InsL prm2, Volume off off off off off FLT-Frq InsS prm1, RevSend
SunShine Pf Room 2 Chorus 1 Auto Pan Compressor InsS prm1 off off off off off InsS prm2 RevSend
Phaser EP Pf Hall 2 Flanger 1 Flanger 1 Phaser 1 ELFO-PM off off off off off InsL prm4, InsL prm1 RevSend
RB Roadz Pf Hall 1 Chorus 1 Compressor Celeste 3 InsL prm1 off off off off off InsS prm4, InsS prm3 RevSend
BasicRoad2 Pf Hall 1 Chorus 1 3band EQ Auto Pan InsL prm1 off off off off off InsL prm2 RevSend, ChoSend
Early70Rhd Pf Stage 1 Chorus 1 Tremolo V-Distortion InsS prm2 off off off off off AEG-D1 RevSend
Doogie Pf Hall 1 Chorus 1 Thru Thru CLFO-D1 off off off off off FLT-Frq ChoSend, RevSend
RT Roadz Pf Stage 1 Chorus 1 Auto Pan Phaser 1 InsS prm1, InsL prm1 off off off off off InsS prm2 RevSend
Dyno Pad Co Hall 1 Chorus 1 Chorus 1 Thru ELM-Lvl off off off off off FLT-Frq ChoSend, RevSend
Roadz Pad Co Stage 2 Chorus 1 Auto Pan Chorus 3 InsS prm2 off off off off off FLT-Frq ChoSend, Volume
NiteBallad Pf Hall 2 Chorus 1 Compressor Celeste 4 InsL prm1, InsL prm2 off off off off off InsL prm10 RevSend
DXTinyVel Pf Hall 1 Symphonic Celeste 4 Harmonic Enhancer ELFO-AM off off off off off InsL prm3 RevSend
DX Hard Pf Hall 1 Chorus 1 Exciter Symphonic ELFO-AM off off off off off InsS prm3 RevSend
Superstit Pf Room 3 Chorus 2 AMP Simulator Phaser 2 InsL prm10 off off off off off AEG-D1, AEG-D2 ChoSend
Puls Clav Sc Hall 1 Phaser Thru Thru ELFO-PM off off off off off FLT-Rez AEG-D1, AEG-D2
Handbel Cp Hall 1 Chorus 1 Thru Thru ELFO-AM off off off off off FLT-Frq ChoSend, RevSend
Estrn Bel1 Cp Hall 1 Celeste 1 Chorus 1 Thru ChoSend off off off off off FLT-Frq PCH-Crs
Tiny bell Cp Hall 1 Chorus 1 Chorus 1 Thru ChoSend off off off off off FLT-Frq AEG-Atk
Argent Or Room 1 Chorus 1 Overdrive Rotary Speaker 1 InsL prm1 off off off off off InsL prm9 InsL prm1
Como Va Or Room 1 Chorus 1 Overdrive Rotary Speaker 1 InsL prm1, InsL prm2 off off off off off InsL prm9 InsL prm1
Blackpool Or White Room Chorus 1 Thru 2Way Rotary
Speaker InsL prm1 off InsL prm1 off off off ELM-Lvl RevSend
Tonewheels Or Room 1 Chorus 5 Thru Thru ELFO-PM, ELFO-AM,
CLFOSpd off off off off off ELM-Lvl ChoSend
BowNL Or Room 1 Chorus 1 Thru Thru RevSend, ELFO-PM off off off off off FLT-Frq FLT-Rez
BassWalk Or Room 1 Chorus 1 Thru Rotary Speaker 1 InsL prm1 off off off off off InsL prm9 InsL prm1
WhiteShade Or Hall 1 Chorus 1 3band EQ Amp Simu + 2Way
Rotary Speaker InsL prm1 off off off off off FLT-Frq RevSend
Draws Or Room 1 Chorus 1 Thru 2Way Rotary
Speaker 3 InsL prm16 InsL prm2,
InsL prm3 off off off off InsL prm14 InsL prm5, InsL prm6
PercMellow Or Room 1 Chorus 1 Thru Rotary Speaker 1 InsL prm1 off off off off off InsL prm9 InsL prm1
RhoBassFiz Or Room 1 Chorus 1 AMP Simulator Rotary Speaker 1 InsL prm1, InsL prm2 off off off off off RevSend InsL prm1
Knob Drive Or Room 1 Chorus 1 AMP Simulator Rotary Speaker 1 InsL prm1 off off off off off InsS prm1 InsL prm1
E Bird Or Hall 1 Chorus 4 Thru Rotary Speaker 1 InsL prm1 off off off off off RevSend ELM-Lvl
16-*-*-4 Or Hall 1 Chorus 5 Thru 2Way Rotary
Speaker InsL prm1, InsL prm9 off off off off off RevSend ChoSend
16-5-4-1-1 Or Hall 1 Chorus 5 Thru Rotary Speaker 1 InsL prm1, InsL prm9 off off off off off RevSend ChoSend
Mw Church Or Hall 2 Celeste 1 Thru Thru ChoSend, ELM-Lvl off off off off off FLT-Frq RevSend
Big Church Or Hall 2 Celeste 1 Thru Thru FLT-Frq off off off off off ChoSend RevSend
Hawks Gt Hall 1 Chorus 1 Exciter Harmonic Enhancer ELFO-PM off off off off off FEG-D1 ChoSend
GoldGuitar Gt Room 3 Chorus 4 Thru 2Band EQ ELFO-PM off off off off off RevSend ChoSend
El/Ac Mix Gt Hall 1 Delay LR Chorus 1 Comp Distortion ELFO-PM off off off off off ELM-Lvl, ELM-Lvl ChoSend, RevSend
VintStrat Gt White Room Delay LR AMP Simulator Tremolo InsL prm1 off off off off off ChoSend RevSend
StratChor3 Gt Hall 1 Chorus 4 3band EQ AMP Simulator FLT-Frq off off off off off ChoSend RevSend
VeloGuitar Gt Room 2 Chorus 4 Thru AMP Simulator ELFO-PM, ELFO-FM,
ELFOSpd off off off off off InsL prm10 ChoSend, Volume
Jazz Man Gt Stage 2 Chorus 5 Thru Thru ELFO-PM off off off off off RevSend ChoSend
FMJazzGtr Gt Room 3 Chorus 4 Thru Ambience ELFO-PM off off off off off FLT-Frq RevSend
Cry Gt Hall 1 Chorus 1 Auto Wah Comp+Dist+Delay ELFO-PM InsL prm14 off off off off InsS prm1 ChoSend, Volume
P.F. Echo Gt Room 3 Delay LR 3band EQ Dist + 2Way Rotary
Speaker ELFO-PM off off off off off ChoSend InsL prm14, Volume
Birdy Gt Room 3 Phaser 3band EQ V-Distortion ELFO-PM off off off off off InsL prm1, Volume InsL prm11
Velo Chunk Gt Room 3 off 3band EQ V-Distortion ELFO-PM off off off off off InsL prm4, InsL prm1 InsL prm11
VirtualDis Gt Hall 1 Delay LR AMP Simulator Comp Distortion CLFO-D1 off off off off off InsS prm6 ChoSend
100 Watts Gt Room 3 Phaser 3band EQ V-Distortion ELFO-PM off off off off off InsL prm11 InsL prm1
Acst Vox Co Hall 1 Chorus 1 Thru Delay LCR ELM-Lvl off off off off off FLT-Frq, FLT-Rez ChoSend
Prec Bass Ba Hall 1 Chorus 1 AMP Simulator 3Band EQ CLFO-D1 off off off off off ChoSend InsL prm1
Fing Sting Ba Hall 1 Chorus 1 Exciter 3Band EQ CLFO-D1 off off off off off ChoSend InsL prm1
FretlesAmp Ba Hall 1 Chorus 1 3band EQ AMP Simulator ELFO-PM off off off off off FLT-Frq ChoSend
Slap&Pull Ba Room 1 Chorus 1 Thru Thru ELFO-PM off off off off off FLT-Frq, FLT-Frq ChoSend
Bs+Cmbal Co Hall 1 Chorus 1 Thru Thru ELFO-PM off off off off off PCH-Crs ELM-Lvl
1(A01)
2(A02)
3(A03)
4(A04)
5(A05)
6(A06)
7(A07)
8(A08)
9(A09)
10(A10)
11(A11)
12(A12)
13(A13)
14(A14)
15(A15)
16(A16)
17(B01)
18(B02)
19(B03)
20(B04)
21(B05)
22(B06)
23(B07)
24(B08)
25(B09)
26(B10)
27(B11)
28(B12)
29(B13)
30(B14)
31(B15)
32(B16)
33(C01)
34(C02)
35(C03)
36(C04)
37(C05)
38(C06)
39(C07)
40(C08)
41(C09)
42(C10)
43(C11)
44(C12)
45(C13)
46(C14)
47(C15)
48(C16)
49(D01)
50(D02)
51(D03)
52(D04)
53(D05)
54(D06)
55(D07)
56(D08)
57(D09)
58(D10)
59(D11)
60(D12)
61(D13)
62(D14)
63(D15)
64(D16)
7
No. Voice Name Category
Reverb Type
Chorus Type Insertion1 Type Insertion2 Type MW PB AT FC BC FS Kn1 Kn2
Big Sction St Hall 1 Chorus 1 3band EQ Thru ChoSend, Volume AEG-Rel off off off off FLT-Frq AEG-Atk
EnsemblMix St Hall 1 Ensemble Thru Thru ChoSend, ELM-Lvl off off off off off FLT-Frq AEG-Atk, AEG-Rel
Agitato St Hall 1 Chorus 1 3band EQ Thru ChoSend, Volume off off off off off FLT-Frq ELFO-AM, ELFO-FM,
CLFOSpd
Analog Mix St Hall 1 Ensemble Thru Thru ChoSend, Volume off off off off off FLT-Frq AEG-Atk, AEG-Rel
Violin St Hall 1 Chorus 1 Thru Thru FLT-Frq off off off off off AEG-Rel,AEG-Atk ChoSend, RevSend,
Volume
Big Pizz St Hall 1 Chorus 3 Thru Thru ChoSend off off off off off FLT-Frq ELM-Dly
HarpStrum St Room 3 Celeste 2 Thru Thru ELFO-PM off off off off off RevSend ChoSend
Wood Winds Co Hall 1 Ensemble Thru Thru CLFO-D1, CLFO-D2,
ELFO-PM, ELFO-FM off off off off off FLT-Frq ChoSend
Pan Attack Pi Hall 1 Chorus 1 Thru Thru ELFO-AM, ELFO-FM off off off off off FLT-Frq, FLT-Rez AEG-Atk
AnaString St Hall 2 Ensemble Chorus 1 Cross Delay CLFO-D1, FLT-Frq off off off off off InsS prm10 ChoSend
AnaString2 St Hall 2 Symphonic Chorus 3 Harmonic Enhancer PCH-Fin off off off off off InsS prm3, InsS prm10,
InsS prm6 InsL prm2
Tron St Hall 1 Phaser 3band EQ Thru ELM-Lvl off off off off off RevSend, ChoSend FLT-Frq
Brs/Strgs Br Hall 1 Chorus 1 Thru Thru ELM-Lvl off off off off off ELM-Lvl PCH-Crs
MediumBrs2 Br Hall 1 Chorus 1 3band EQ Thru ChoSend off off off off off FLT-Frq RevSend
SoftBrass Br Hall 2 Chorus 1 Thru Cross Delay ChoSend off off off off off FLT-Frq InsL prm10, RevSend
HybrdBrs Br Hall 1 Chorus 1 Thru Delay LCR ELFO-PM, ELFO-FM off off off off off FLT-Frq, FLT-Rez RevSend
Class Sect Br Hall 1 Chorus 3 Chorus 3 Thru InsS prm10 off off off off off FLT-Frq ELM-Lvl
Sfz Brass Br Stage 2 Chorus 1 Thru Thru ELFO-PM, ELFO-PM off off off off off FLT-Frq FEG-D2, FEG-D1
Pop Brass Br Hall 1 Chorus 1 Thru Thru ELFO-FM, ELFO-PM off off off off off FLT-Frq ChoSend, Volume
Classical Br Hall 1 Chorus 1 Thru Thru ELFO-FM, ELFO-PM off off off off off FLT-Frq ChoSend, Volume
Fr Horns Br Hall 1 Chorus 1 Thru Delay LCR ELFO-PM, ELFO-AM off off off off off RevSend ChoSend
Flugel Br Hall 1 Ensemble 3band EQ Thru CLFO-D1, CLFO-D2 off off off off off FLT-Frq RevSend
Brth Tenor Rd Hall 2 Chorus 1 3band EQ Thru ELFO-PM, ELFO-AM off off off off off FLT-Frq ChoSend, RevSend
Velo Growl Rd Hall 1 Delay LR Thru Thru ELFO-PM, CLFO-D1 off off off off off ChoSend RevSend
NuSoprno Rd Hall 1 Chorus 1 3band EQ Thru ELFO-PM, ELFO-AM off off off off off FLT-Frq ChoSend
J Stabs Br Hall 1 Delay LR Thru Ensemble Detune ELFO-PM off off off off off RevSend ChoSend
Oberhorns Br Hall 1 Chorus 4 Thru Cross Delay CLFO-D1 off off off off off FEG-Atk ChoSend
Africa Br Hall 1 Delay LR Thru Thru ELFO-PM off off off off off FLT-Frq, FLT-Rez PEG-Dpt, AEG-Atk
NuTekBrss Br Hall 1 Chorus 4 Distortion Cross Delay ChoSend, ELM-Lvl off ELFO-PM off off off PCH-Fin ChoSend
CS80Brass Br Hall 1 Delay LR Thru Thru ELFO-PM off off off off off FLT-Frq, FLT-Rez RevSend, ChoSend
Fat Brazz Br Hall 1 Chorus 4 Thru Cross Delay CLFO-D1 off off off off off FEG-Atk ChoSend
EgoSix Br Hall 2 Chorus 2 Compressor Early Ref 1 ChoSend, RevSend,
FLT-Frq off off off off off InsL prm10 ChoSend
Ambi Star Fx Hall 2 Ensemble Flanger 3 Cross Delay FLT-Frq, FLT-Rez,
ChoSend off off off off off InsS prm1 InsS prm10
Champ Fx Hall 2 Delay LR Chorus 1 Ensemble Detune FLT-Rez, ELM-Lvl off off off off off FEG-Atk InsL prm10
Rndm Gruv Fx Hall 2 Ensemble Chorus 4 Cross Delay CLFO-D1, ChoSend off off off off off ChoSend, ELM-Lvl CLFO-D2
Generation Sq Hall 2 Tempo Cross
Delay Exciter Ensemble Detune FLT-Rez, FLT-Frq off off off off off FLT-Rez InsS prm1
Molecule Fx Hall 1 Tempo Cross
Delay Phaser Ensemble Detune ELFO-FM, InsS prm1,
InsS prm2 off off off off off ELFOSpd ELM-Lvl, ELM-Lvl
Teardrops Fx Room 3 Control Delay1 Phaser Compressor InsS prm4, AEG-Atk off off off off off InsS prm10 InsS prm1
Hades Fx Hall 1 Delay LR Thru Celeste 2 ELFO-PM off off off off off RevSend ChoSend
Voyager Fx Canyon Tempo Cross
Delay Phaser Flanger 3 ELFO-FM off off off off off InsL prm1, InsS prm1,
ChoSend ELFOSpd, FLT-Frq
Waterfowl Fx Stage 1 Tempo Cross
Delay Phaser Harmonic Enhancer ELFOSpd off off off off off InsS prm4 RevSend
Mayflower Fx Canyon Tempo Cross
Delay Flanger 3 Compressor ELFO-AM, PCH-Fin off off off off off ELFOSpd, ELFO-PM InsS prm1
Cronen Pd Plate off Chorus 3 Rotary Speaker 1 InsL prm1, InsL prm9 off off off off off ELM-Lvl, ELM-Lvl InsS prm3
Padness Pd Canyon Chorus 2 Touch Wah Pitch Change 1 CLFO-D2 off off off off off InsS prm8 InsL prm10
Luminosity Pd Hall 1 Chorus 1 Flanger 2 Delay LCR ELFO-AM off off off off off RevSend ChoSend
Expanse Pd Hall 1 Chorus 1 Thru Echo ELFO-PM off off off off off ELM-Lvl ChoSend
Vox 5ths Pd Hall 2 Symphonic Thru Delay LCR PCH-Crs, PCH-Crs off off off off off FLT-Frq, FLT-Rez ChoSend
Cleansing Pd Hall 1 Symphonic Chorus 1 Delay LCR CLFO-D1 off off off off off ChoSend FLT-Frq, RevSend
4000 Volts Se Hall 1 Chorus 1 Chorus 3 Flanger 1 FLT-Frq off InsL prm3 off off off PEG-Dpt FEG-Atk
Rainstorm Se Hall 1 Chorus 3 Thru Thru FLT-Frq off off off off off PCH-Crs ELM-Lvl
RadioNoiz Se Hall 1 Chorus 3 3band EQ LO-FI ELFOSpd InsL prm2 off off off off FLT-Frq InsL prm1
Turntablz Se Hall 1 Chorus 1 Thru LO-FI ELFO-PM, ELFO-FM off off off off off ChoSend PCH-Crs
Manufactur Se Room 1 Ensemble Phaser Delay LR ELFO-PM off off off off off ELM-Pan, ELM-Pan RevSend
Zap Se Hall 1 Control Delay1 3band EQ Thru PCH-Crs AEG-D1 off off off off PEG-Hld ChoSend, RevSend
Helicoptr Se Hall 1 Phaser Thru Auto Pan FLT-Rez, FLT-Frq,
FLT-Frq ELFOSpd off off off off ELM-Lvl RevSend
Sirens Se Hall 1 Chorus 1 Thru Thru RevSend off off off off off ELFOSpd ChoSend
Bubbles Se Hall 1 Chorus 3 3band EQ LO-FI ELFOSpd InsL prm2 off off off off FLT-Frq InsL prm1
Beatniks Pc Hall 1 Tempo Delay1 Thru Thru ChoSend off off off off off FLT-Frq, FEG-Dpt ELM-Lvl
Cybr Whip Pc Stage 2 Chorus 1 Thru V-Flanger InsL prm2 off off off off off FLT-Frq AEG-Atk
Voicey En Hall 2 Chorus 1 Compressor Hall 2 ELM-Lvl, ELM-Lvl,
FLT-Frq off off off off off ELM-Pan RevSend
FormantStg En Hall 1 Chorus 1 Chorus 2 Talking Modulator InsL prm1 off off off off off FLT-Frq FLT-Rez
Airy Vo Hall 1 Control Delay2 Thru Thru ELFO-PM off off off off off PCH-Crs AEG-Atk, AEG-Rel
Chandelier Vo Hall 2 Ensemble Exciter Chorus 4 InsS prm1, ELM-Lvl,
FLT-Frq off off off off off InsS prm1 FLT-Frq
Choir Atk Vo Hall 1 Chorus 1 Exciter 3Band EQ ELFO-PM, ELFO-AM off off off off off FLT-Frq FLT-Rez
65(E01)
66(E02)
67(E03)
68(E04)
69(E05)
70(E06)
71(E07)
72(E08)
73(E09)
74(E10)
75(E11)
76(E12)
77(E13)
78(E14)
79(E15)
80(E16)
81(F01)
82(F02)
83(F03)
84(F04)
85(F05)
86(F06)
87(F07)
88(F08)
89(F09)
90(F10)
91(F11)
92(F12)
93(F13)
94(F14)
95(F15)
96(F16)
97(G01)
98(G02)
99(G03)
100(G04)
101(G05)
102(G06)
103(G07)
104(G08)
105(G09)
106(G10)
107(G11)
108(G12)
109(G13)
110(G14)
111(G15)
112(G16)
113(H01)
114(H02)
115(H03)
116(H04)
117(H05)
118(H06)
119(H07)
120(H08)
121(H09)
122(H10)
123(H11)
124(H12)
125(H13)
126(H14)
127(H15)
128(H16)
8
Bank Category Program
Key Memory Voice
Program
Number Voice Name
A A.PIANO 1 PRE1 1 StereoGrnd
2 PRE1 2 StereoGnd2
3 PRE1 3 CF Grand M
4 PRE1 4 Dark Grand
5 PRE1 5 Difference
6 PRE2 114 Slamming
7 PRE1 9 CP2000
8 PRE2 124 For Ballad
9 PRE1 7 Piano/Strg
10 PRE1 8 Piano/Oohs
11 PRE1 6 Piano/Ep
12 PRE1 10 Piano/DX
13 INT 1 Hybrid
14 INT 2 DarkGrand2
15 INT 3 BrtStereo
16 INT 4 HonkyTnk2
B E.PIANO 1 PRE1 17 Vic'sRoadz
2 PRE1 18 ErlyFusion
3 PRE1 16 19 Roadz
4 PRE1 20 VintgCond
5 PRE1 11 Wurlitrm
6 PRE1 13 DF EP IV
7 PRE1 14 Herb Roadz
8 PRE1 21 DXAtacky
9 PRE1 24 Ice Piano
10 PRE1 26 Bel Roadz
11 PRE1 31 Clav
12 PRE1 30 Harpsicode
13 INT 17 Doogie
14 INT 18 RT Roadz
15 INT 19 Dyno Pad
16 INT 20 Roadz Pad
C ORGAN 1 PRE1 33 Perc Org
2 PRE1 34 Cool
3 PRE1 35 ClickOrgan
4 PRE1 36 Jazz
5 PRE1 37 Soft Rock
6 PRE1 38 Tube
7 PRE1 39 Contnental
8 PRE1 40 Swish
9 PRE1 44 Sunday
10 PRE1 45 Pipes
11 PRE1 41 4 Bars
12 PRE1 42 Full
13 INT 33 BowNL
14 INT 34 BassWalk
15 INT 35 WhiteShade
16 INT 36 Draws
D GTR/BASS 1 PRE1 46 New Nylon
2 PRE1 48 Melo Trmlo
3 PRE1 54 DirtyTwn
4 PRE1 49 Strat Chor
5 PRE1 56
BOODOO MAN
6 PRE1 52 Acoustic
7 PRE1 58 Funk It!!
8 PRE1 59 Upright
9 PRE1 60 Finger
10 PRE1 61 PickBass
11 PRE1 62 Fretless
12 PRE1 63 Slap
13 INT 49 StratChor3
14 INT 50 3VeloGuitar
15 INT 51 Jazz Man
16 INT 52 FMJazzGtr
E STRINGS 1 PRE1 65 Background
2 PRE1 66 Big String
3 PRE1 67 Cello Big
4 PRE1 68 Chamberz
5 PRE1 69 SmallSect
6 PRE1 70 CelloSmall
7 PRE1 76 Wind Orch
8 PRE1 77 SynthStrgs
9 PRE1 78 ObiStrings
10 PRE2 57 Big Syn
11 PRE1 71 Pizz
12 PRE1 72 Harp
13 INT 65 Big Sction
14 INT 66 EnsemblMix
15 INT 67 Agitato
16 INT 68 Analog Mix
Bank Category Program
Key Memory Voice
Program
Number Voice Name
F BRASS 1 PRE1 79 Fanfare
2 PRE1 80 MediumBrss
3 PRE1 81 Two Brass
4 PRE1 82 Brass&Sax
5 PRE1 85 Trumpet
6 PRE1 86 Mute Trpt
7 PRE1 87 Tenor Sax
8 PRE1 88 Alto Sax
9 PRE1 90 Soprano
10 PRE1 92 PowerSynth
11 PRE1 94 M Brass
12 PRE1 95 Moon AT
13 INT 81 Class Sect
14 INT 82 Sfz Brass
15 INT 83 Pop Brass
16 INT 84 Classical
G SYNTH 1 PRE1 101 Soft Pad
2 PRE2 50 5thBreath
3 PRE2 63 Soft Dream
4 PRE2 58 Berlin
5 PRE1 111 Liquito
6 PRE2 22 Zap Comp
7 PRE2 36 Lucky
8 PRE2 37 Sneaky
9 PRE2 40 Rap Lead3
10 PRE2 5 Mini 1
11 PRE2 3 Velo
12 PRE2 109 Super DX
13 INT 97 Ambi Star
14 INT 98 Champ
15 INT 99 Rndm Gruv
16 INT 100 Generation
H OTHER 1 PRE1 113 Vibes
2 PRE1 114 Marimba
3 PRE1 117 Glocken
4 PRE1 97 Ooh Choir
5 PRE1 98 Ahh Choir
6 PRE2 101 Starlight
7 PRE2 93 RisingHigh
8 PRE2 67 Kickwheel
9 PRE2 70 Rosy
10 PRE2 73 Synfonic
11 PRE2 74 Hard road
12 PRE2 76 Atom
13 INT 113 4000 Volts
14 INT 114 RainStorm
15 INT 115 RadioNoiz
16 INT 116 Turntablz
Quick Access Voice List
9
Drum Voice List
Preset (MSB=63, LSB=32)
1 Rock Kit 2 House Kit
Note ElmAsgn Wave No. Wave Name Note ElmAsgn Wave No. Wave Name
C 0 378 Dr BdVar5 C 0 off
C#0 389 Dr SdPcBH C#0 off
D 0 391 Dr SdWdH D 0 off
D#0 392 Dr SdVar1 D#0 off
E 0 376 Dr BdVar3 E 0 on 433 Dr Crash
F 0 405 Dr SdRoll F 0 on 373 Dr BdLoJz
F#0 382 Dr SdBldH F#0 on 367 Pc CONG
G 0 400 Dr SdDry G 0 on 382 Dr SdBldH
G#0 408 Dr Stick G#0 on 367 Pc CONG
A 0 377 Dr BdVar4 A 0 on 476 Dr EuroBD
A#0 389 Dr SdPcBH A#0 on 437 Dr T8BdBm
B 0 374 Dr BdVar1 B 0 on 457 Dr T9BD2
C 1 371 Dr BdPop C 1 on 458 Dr T9BD3
C#1 407 Dr C.Rim2 C#1 on 466 Dr T9Rim
D 1 387 Dr SdHvy D 1 on 460 Dr T9SD2
D#1 358 Pc Clap D#1 on 444 Dr T8Rmst
E 1 380 Dr SdGM E 1 on 463 Dr T9SD5
F 1 418 Dr Tom2L F 1 on 467 Dr T9TomL
F#1 423 Dr HHCl5 F#1 on 470 Dr T9HHC1
G 1 418 Dr Tom2L G 1 on 468 Dr T9TomM
G#1 425 Dr HHPdl2 G#1 on 471 Dr T9HHC2
A 1 418 Dr Tom2L A 1 on 469 Dr T9TomH
A#1 426 Dr HHOpn A#1 on 472 Dr T9HHO1
B 1 417 Dr Tom2H B 1 on 469 Dr T9TomH
C 2 417 Dr Tom2H C 2 on 473 Dr T9HHO2
C#2 433 Dr Crash C#2 on 474 Dr T9Crsh
D 2 417 Dr Tom2H D 2 on 475 Dr T9Ride
D#2 429 Dr Ride D#2 on 465 Dr T9Clap
E 2 435 Dr China E 2 on 362 Pc AnvlPp
F 2 431 Dr Cup F 2 on 456 Dr T9BD1
F#2 354 Pc Tmborn F#2 on 389 Dr SdPcBH
G 2 434 Dr Crash2 G 2 on 369 Pc WdBlk
G#2 340 Pc Cowbel G#2 on 362 Pc AnvlPp
A 2 434 Dr Crash2 A 2 on 367 Pc CONG
A#2 356 Pc VbSlp A#2 on 361 Pc AnvlHt
B 2 432 Dr Cup2 B 2 on 368 Pc StlClp
C 3 336 Pc BongoH C 3 on 366 Pc Ripper
C#3 335 Pc BongoL C#3 on 367 Pc CONG
D 3 339 Pc CngSlp D 3 on 452 Dr T8CngH
D#3 338 Pc CongaH D#3 on 452 Dr T8CngH
E 3 337 Pc CongaL E 3 on 452 Dr T8CngH
F 3 345 Pc TmblsH F 3 on 452 Dr T8CngH
F#3 344 Pc TmblsL F#3 on 449 Dr T8Crsh
G 3 341 Pc AgogoL G 3 on 447 Dr T8HHCl
G#3 341 Pc AgogoL G#3 on 448 Dr T8HHOp
A 3 349 Pc Cabasa A 3 on 355 Pc TrangL
A#3 352 Pc Maracs A#3 on 455 Dr T8Mrcs
B 3 435 Dr China B 3 on 355 Pc TrangL
C 4 434 Dr Crash2 C 4 on 353 Pc Shaker
C#4 355 Pc TrangL C#4 on 361 Pc AnvlHt
D 4 101 Cp FngCym D 4 on 361 Pc AnvlHt
D#4 350 Pc Claves D#4 on 454 Dr T8Clve
E 4 348 Pc Wdblck E 4 on 365 Pc VoxDrm
F 4 348 Pc Wdblck F 4 on 477 Dr DstKik
F#4 113 Cp Timpni F#4 on 449 Dr T8Crsh
G 4 113 Cp Timpni G 4 on 357 Pc JnglBl
G#4 355 Pc TrangL G#4 on 354 Pc Tmborn
A 4 355 Pc TrangL A 4 on 354 Pc Tmborn
A#4 353 Pc Shaker A#4 on 322 Fx BigSyn
B 4 357 Pc JnglBl B 4 on 322 Fx BigSyn
C 5 370 Dr BdStd C 5 on 319 Fx Melow
C#5 394 Dr SdRim1 C#5 on 328 Fx VxAlk
D 5 382 Dr SdBldH D 5 on 328 Fx VxAlk
D#5 387 Dr SdHvy D#5 on 328 Fx VxAlk
E 5 392 Dr SdVar1 E 5 on 439 Dr T8SD1
F 5 393 Dr SdVar2 F 5 on 359 Pc Whistl
F#5 396 Dr SdAmb1 F#5 on 388 Dr SdPclH
G 5 383 Dr SdFsnH G 5 on 437 Dr T8BdBm
G#5 398 Dr SdAmb3 G#5
A 5 388 Dr SdPclH A 5
A#5 372 Dr BdHby A#5
B 5 372 Dr BdHby B 5
C 6
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on 373 Dr BdLoJz C 6
3 Hip Kit 4 Trance Kit
Note ElmAsgn Wave No. Wave Name Note ElmAsgn Wave No. Wave Name
C 0 on 477 Dr DstKik C 0 on 437 Dr T8BdBm
C#0 on 378 Dr BdVar5 C#0 on 451 Dr T8CngM
D 0 on 377 Dr BdVar4 D 0 on 438 Dr T8Bd
D#0 on 437 Dr T8BdBm D#0 on 452 Dr T8CngH
E 0 on 456 Dr T9BD1 E 0 on 457 Dr T9BD2
F 0 on 382 Dr SdBldH F 0 on 457 Dr T9BD2
F#0 on 388 Dr SdPclH F#0 on 367 Pc CONG
G 0 on 390 Dr SdPrmH G 0 on 459 Dr T9SD1
G#0 on 439 Dr T8SD1 G#0 on 367 Pc CONG
A 0 on 399 Dr SdBkBt A 0 on 476 Dr EuroBD
A#0 on 404 Dr SdBrsL A#0 on 476 Dr EuroBD
B 0 on 437 Dr T8BdBm B 0 on 457 Dr T9BD2
C 1 on 379 Dr BdAna C 1 on 458 Dr T9BD3
C#1 on 407 Dr C.Rim2 C#1 on 466 Dr T9Rim
D 1 on 394 Dr SdRim1 D 1 on 459 Dr T9SD1
D#1 on 445 Dr T8Clap D#1 on 477 Dr DstKik
E 1 on 389 Dr SdPcBH E 1 on 462 Dr T9SD4
F 1 on 409 Dr TomF F 1 on 467 Dr T9TomL
F#1 on 420 Dr HHCL2 F#1 on 470 Dr T9HHC1
G 1 on 409 Dr TomF G 1 on 468 Dr T9TomM
G#1 on 447 Dr T8HHCl G#1 on 471 Dr T9HHC2
A 1 on 410 Dr TomL A 1 on 469 Dr T9TomH
A#1 on 426 Dr HHOpn A#1 on 472 Dr T9HHO1
B 1 on 411 Dr TomM B 1 on 469 Dr T9TomH
C 2 on 412 Dr TomHL C 2 on 473 Dr T9HHO2
C#2 on 433 Dr Crash C#2 on 474 Dr T9Crsh
D 2 on 413 Dr TomHH D 2 on 475 Dr T9Ride
D#2 on 430 Dr Ride2 D#2 on 465 Dr T9Clap
E 2 on 435 Dr China E 2 on 362 Pc AnvlPp
F 2 on 432 Dr Cup2 F 2 on 456 Dr T9BD1
F#2 on 354 Pc Tmborn F#2 on 389 Dr SdPcBH
G 2 on 434 Dr Crash2 G 2 on 369 Pc WdBlk
G#2 on 367 Pc CONG G#2 on 362 Pc AnvlPp
A 2 on 434 Dr Crash2 A 2 on 366 Pc Ripper
A#2 on 356 Pc VbSlp A#2 on 361 Pc AnvlHt
B 2 on 429 Dr Ride B 2 on 368 Pc StlClp
C 3 on 331 Fx AHoseL C 3 on 437 Dr T8BdBm
C#3 on 332 Fx AHoseR C#3 on 367 Pc CONG
D 3 on 339 Pc CngSlp D 3 on 452 Dr T8CngH
D#3 on 338 Pc CongaH D#3 on 452 Dr T8CngH
E 3 on 337 Pc CongaL E 3 on 452 Dr T8CngH
F 3 on 345 Pc TmblsH F 3 on 452 Dr T8CngH
F#3 on 344 Pc TmblsL F#3 on 449 Dr T8Crsh
G 3 on 362 Pc AnvlPp G 3 on 447 Dr T8HHCl
G#3 on 362 Pc AnvlPp G#3 on 448 Dr T8HHOp
A 3 on 353 Pc Shaker A 3 on 355 Pc TrangL
A#3 on 352 Pc Maracs A#3 on 455 Dr T8Mrcs
B 3 on 363 Pc Scrch1 B 3 on 355 Pc TrangL
C 4 on 438 Dr T8Bd C 4 on 320 Fx WndChm
C#4 on 368 Pc StlClp C#4 on 321 Fx BelAir
D 4 on 383 Dr SdFsnH D 4 on 322 Fx BigSyn
D#4 on 465 Dr T9Clap D#4 on 326 Fx Electr
E 4 on 393 Dr SdVar2 E 4 on 327 FX HH Hit
F 4 on 357 Pc JnglBl F 4 on 328 Fx VxAlk
F#4 on 470 Dr T9HHC1 F#4 on 328 Fx VxAlk
G 4 on 355 Pc TrangL G 4 on 329 Fx HiLo
G#4 on 471 Dr T9HHC2 G#4 on 329 Fx HiLo
A 4 on 355 Pc TrangL A 4 on 318 Fx VoxBel
A#4 on 472 Dr T9HHO1 A#4 on 318 Fx VoxBel
B 4 on 329 Fx HiLo B 4 on 325 Fx Eery
C 5 on 325 Fx Eery C 5 on 258 Wv FMBs1
C#5 on 474 Dr T9Crsh C#5 on 258 Wv FMBs1
D 5 on 435 Dr China D 5 on 258 Wv FMBs1
D#5 on 318 Fx VoxBel D#5 on 258 Wv FMBs1
E 5 on 319 Fx Melow E 5 on 258 Wv FMBs1
F 5 on 255 Wv MogBs1 F 5 on 258 Wv FMBs1
F#5 on 354 Pc Tmborn F#5 on 258 Wv FMBs1
G 5 on 364 Pc Scrch2 G 5 on 258 Wv FMBs1
G#5 on 475 Dr T9Ride G#5 on 258 Wv FMBs1
A 5 on 325 Fx Eery A 5 on 258 Wv FMBs1
A#5 on 327 FX HH Hit A#5 on 258 Wv FMBs1
B 5 on 323 Fx TrnCho B 5 on 258 Wv FMBs1
C 6 on 323 Fx TrnCho C 6 on 258 Wv FMBs1
off
off
off
off
off
10
5 Nasty Kit 6 Brush Kit
Note ElmAsgn Wave No. Wave Name Note ElmAsgn Wave No. Wave Name
Dr T8Bd C 0
Dr BdVar4 C#0
Pc CongaL D 0
Dr BdAna D#0
Dr T9BD3 E 0
Dr SdAmb2 F 0
Dr SdRim2 F#0
Dr T8SD1 G 0
Dr T8SD3 G#0
Dr SdBrsH A 0
Dr SdAmb3 A#0
Dr EuroBD B 0
Dr T9BD3 C 1
Fx HiLo C#1
Dr T9SD4 D 1
Dr T8Clap D#1
Pc WdBlk E 1
Wv Noise F 1
Dr HHCl5 F#1
Wv Noise G 1
Dr T9HHC1 G#1
Wv Noise A 1
Dr T9HHO1 A#1
Dr Tom2L B 1
Dr Tom2H C 2
Dr T9Crsh C#2
Dr Tom2H D 2
Fx Eery D#2
Dr China E 2
Dr Cup2 F 2
Pc Tmborn F#2
Dr Crash G 2
Wv MogBs1 G#2
Dr Crash2 A 2
Pc VbSlp A#2
Dr Ride B 2
Fx VxAlk C 3
FX HH Hit C#3
Pc TmblsH D 3
Pc CongaH D#3
Pc CongaL E 3
Fx BelAir F 3
Fx Electr F#3
Pc AnvlPp G 3
Pc AnvlPp G#3
Pc Shaker A 3
Pc Maracs A#3
Pc Bltree B 3
Dr T8Bd C 4
Fx VoxBel C#4
Dr SdAmb2 D 4
Dr T9Clap D#4
Dr SdRim1 E 4
Fx MltPno F 4
Dr T8HHCl F#4
Pc AnvlHt G 4
Dr T9HHC2 G#4
Pc AnvlHt A 4
Dr T8HHOp A#4
Fx Eery B 4
Fx Eery C 5
350
404
401
403
401
405
351
404
408
376
403
377
373
403
404
358
402
414
422
414
424
414
426
415
416
433
416
429
430
431
354
434
340
434
429
432
336
335
339
338
337
345
344
341
341
349
352
359
359
343
342
350
348
348
346
347
355
355
353
357
360
Pc Claves
Dr SdBrsL
Dr SdSwep
Dr SdBrsH
Dr SdSwep
Dr SdRoll
Pc Castnt
Dr SdBrsL
Dr Stick
Dr BdVar3
Dr SdBrsH
Dr BdVar4
Dr BdLoJz
Dr SdBrsH
Dr SdBrsL
Pc Clap
Dr SdBrsS
Dr TmJzL
Dr HHCl4
Dr TmJzL
Dr HHPdl
Dr TmJzL
Dr HHOpn
Dr TmJzM
Dr TmJzH
Dr Crash
Dr TmJzH
Dr Ride
Dr Ride2
Dr Cup
Pc Tmborn
Dr Crash2
Pc Cowbel
Dr Crash2
Dr Ride
Dr Cup2
Pc BongoH
Pc BongoL
Pc CngSlp
Pc CongaH
Pc CongaL
Pc TmblsH
Pc TmblsL
Pc AgogoL
Pc AgogoL
Pc Cabasa
Pc Maracs
Pc Whistl
Pc Whistl
Pc GiroCl
Pc GuiroL
Pc Claves
Pc Wdblck
Pc Wdblck
Pc CuicaL
Pc CuicaH
Pc TrangL
Pc TrangL
Pc Shaker
Pc JnglBl
Pc Bltree
Dr T9Crsh C#5
Dr China D 5
Fx VoxBel D#5
Dr T8Crsh E 5
En VxNoiz F 5
Pc Tmborn F#5
Pc Ripper G 5
Dr T9Ride G#5
Dr T8CngL A 5
Dr T8CngM A#5
Dr TmJzH B 5
C 0
C#0
D 0
D#0
E 0
F 0
F#0
G 0
G#0
A 0
A#0
B 0
C 1
C#1
D 1
D#1
E 1
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
D 2
D#2
E 2
F 2
F#2
G 2
G#2
A 2
A#2
B 2
C 3
C#3
D 3
D#3
E 3
F 3
F#3
G 3
G#3
A 3
A#3
B 3
C 4
C#4
D 4
D#4
E 4
F 4
F#4
G 4
G#4
A 4
A#4
B 4
C 5
C#5
D 5
D#5
E 5
F 5
F#5
G 5
G#5
A 5
A#5
B 5
C 6
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
438
377
337
379
458
397
395
439
441
403
398
476
458
329
462
445
369
314
423
314
470
314
472
418
417
474
417
325
435
432
354
433
255
434
356
429
328
327
345
338
337
321
326
362
362
353
352
360
438
318
397
465
394
330
447
361
471
361
448
325
325
474
435
318
449
209
354
366
475
450
451
416
448 Dr T8HHOp C 6
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
off
7 Pop Kit 8 8o8 Kit
Note ElmAsgn Wave No. Wave Name Note ElmAsgn Wave No. Wave Name
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
350
404
401
403
401
405
351
442
444
379
441
437
438
443
439
445
440
446
447
446
448
446
448
446
446
449
446
449
435
431
354
434
453
434
356
430
336
335
452
451
450
345
344
341
341
349
455
359
359
343
342
454
348
348
346
347
355
355
353
357
360
Pc Claves
Dr SdBrsL
Dr SdSwep
Dr SdBrsH
Dr SdSwep
Dr SdRoll
Pc Castnt
Dr T8SD4
Dr T8Rmst
Dr BdAna
Dr T8SD3
Dr T8BdBm
Dr T8Bd
Dr T8Side
Dr T8SD1
Dr T8Clap
Dr T8SD2
Dr T8Tom
Dr T8HHCl
Dr T8Tom
Dr T8HHOp
Dr T8Tom
Dr T8HHOp
Dr T8Tom
Dr T8Tom
Dr T8Crsh
Dr T8Tom
Dr T8Crsh
Dr China
Dr Cup
Pc Tmborn
Dr Crash2
Dr T8Cwbl
Dr Crash2
Pc VbSlp
Dr Ride2
Pc BongoH
Pc BongoL
Dr T8CngH
Dr T8CngM
Dr T8CngL
Pc TmblsH
Pc TmblsL
Pc AgogoL
Pc AgogoL
Pc Cabasa
Dr T8Mrcs
Pc Whistl
Pc Whistl
Pc GiroCl
Pc GuiroL
Dr T8Clve
Pc Wdblck
Pc Wdblck
Pc CuicaL
Pc CuicaH
Pc TrangL
Pc TrangL
Pc Shaker
Pc JnglBl
Pc Bltree
C 0
C#0
D 0
D#0
E 0
F 0
F#0
G 0
G#0
A 0
A#0
B 0
C 1
C#1
D 1
D#1
E 1
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
D 2
D#2
E 2
F 2
F#2
G 2
G#2
A 2
A#2
B 2
C 3
C#3
D 3
D#3
E 3
F 3
F#3
G 3
G#3
A 3
A#3
B 3
C 4
C#4
D 4
D#4
E 4
F 4
F#4
G 4
G#4
A 4
A#4
B 4
C 5
C#5
D 5
D#5
E 5
F 5
F#5
G 5
G#5
A 5
A#5
B 5
C 6
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
350
404
401
403
401
405
351
400
408
376
389
377
372
406
380
358
380
410
423
410
425
411
427
411
412
433
413
429
435
431
354
434
340
434
356
432
336
335
339
338
337
345
344
341
341
349
352
359
359
343
342
350
348
348
346
347
355
355
353
357
360
399
381
392
386
394
391
382
389
384
371
372
378
Pc Claves
Dr SdBrsL
Dr SdSwep
Dr SdBrsH
Dr SdSwep
Dr SdRoll
Pc Castnt
Dr SdDry
Dr Stick
Dr BdVar3
Dr SdPcBH
Dr BdVar4
Dr BdHby
Dr C.Rim1
Dr SdGM
Pc Clap
Dr SdGM
Dr TomL
Dr HHCl5
Dr TomL
Dr HHPdl2
Dr TomM
Dr HHOpn2
Dr TomM
Dr TomHL
Dr Crash
Dr TomHH
Dr Ride
Dr China
Dr Cup
Pc Tmborn
Dr Crash2
Pc Cowbel
Dr Crash2
Pc VbSlp
Dr Cup2
Pc BongoH
Pc BongoL
Pc CngSlp
Pc CongaH
Pc CongaL
Pc TmblsH
Pc TmblsL
Pc AgogoL
Pc AgogoL
Pc Cabasa
Pc Maracs
Pc Whistl
Pc Whistl
Pc GiroCl
Pc GuiroL
Pc Claves
Pc Wdblck
Pc Wdblck
Pc CuicaL
Pc CuicaH
Pc TrangL
Pc TrangL
Pc Shaker
Pc JnglBl
Pc Bltree
Dr SdBkBt
Dr SdBldS
Dr SdVar1
Dr SdSonD
Dr SdRim1
Dr SdWdH
Dr SdBldH
Dr SdPcBH
Dr SdLdwH
Dr BdPop
Dr BdHby
Dr BdVar5
C 0
C#0
D 0
D#0
E 0
F 0
F#0
G 0
G#0
A 0
A#0
B 0
C 1
C#1
D 1
D#1
E 1
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
D 2
D#2
E 2
F 2
F#2
G 2
G#2
A 2
A#2
B 2
C 3
C#3
D 3
D#3
E 3
F 3
F#3
G 3
G#3
A 3
A#3
B 3
C 4
C#4
D 4
D#4
E 4
F 4
F#4
G 4
G#4
A 4
A#4
B 4
C 5
C#5
D 5
D#5
E 5
F 5
F#5
G 5
G#5
A 5
A#5
B 5
C 6
11
1 HipHop Kit 2 Urbanguard
ElmAsgn Wave No. Wave Name Note ElmAsgn Wave No. Wave Name
Fx HiLo
Fx HiLo
C 0
C#0
D 0
D#0
E 0
F 0
F#0
G 0
G#0
A 0
A#0
B 0
C 1
C#1
D 1
D#1
E 1
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
D 2
D#2
E 2
F 2
F#2
G 2
G#2
A 2
A#2
B 2
C 3
C#3
D 3
D#3
E 3
F 3
F#3
G 3
G#3
A 3
A#3
B 3
C 4
C#4
D 4
D#4
E 4
F 4
F#4
G 4
G#4
A 4
A#4
B 4
C 5
C#5
D 5
D#5
E 5
F 5
F#5
G 5
G#5
A 5
A#5
B 5
C 6
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
437
440
439
441
442
462
327
460
444
438
463
458
456
406
459
465
461
467
471
467
473
468
472
468
469
474
469
475
449
475
354
449
453
474
477
449
452
450
451
255
266
399
399
453
341
349
455
329
329
361
366
454
454
351
363
364
355
355
353
357
360
394
388
358
390
379
447
457
423
374
448
476
372
Dr T8BdBm
Dr T8SD2
Dr T8SD1
Dr T8SD3
Dr T8SD4
Dr T9SD4
FX HH Hit
Dr T9SD2
Dr T8Rmst
Dr T8Bd
Dr T9SD5
Dr T9BD3
Dr T9BD1
Dr C.Rim1
Dr T9SD1
Dr T9Clap
Dr T9SD3
Dr T9TomL
Dr T9HHC2
Dr T9TomL
Dr T9HHO2
Dr T9TomM
Dr T9HHO1
Dr T9TomM
Dr T9TomH
Dr T9Crsh
Dr T9TomH
Dr T9Ride
Dr T8Crsh
Dr T9Ride
Pc Tmborn
Dr T8Crsh
Dr T8Cwbl
Dr T9Crsh
Dr DstKik
Dr T8Crsh
Dr T8CngH
Dr T8CngL
Dr T8CngM
Wv MogBs1
Wv Late-S
Dr SdBkBt
Dr SdBkBt
Dr T8Cwbl
Pc AgogoL
Pc Cabasa
Dr T8Mrcs
Pc AnvlHt
Pc Ripper
Dr T8Clve
Dr T8Clve
Pc Castnt
Pc Scrch1
Pc Scrch2
Pc TrangL
Pc TrangL
Pc Shaker
Pc JnglBl
Pc Bltree
Dr SdRim1
Dr SdPclH
Pc Clap
Dr SdPrmH
Dr BdAna
Dr T8HHCl
Dr T9BD2
Dr HHCl5
Dr BdVar1
Dr T8HHOp
Dr EuroBD
Dr BdHby
C 0
C#0
D 0
D#0
E 0
F 0
F#0
G 0
G#0
A 0
A#0
B 0
C 1
C#1
D 1
D#1
E 1
F 1
F#1
G 1
G#1
A 1
A#1
B 1
C 2
C#2
D 2
D#2
E 2
F 2
F#2
G 2
G#2
A 2
A#2
B 2
C 3
C#3
D 3
D#3
E 3
F 3
F#3
G 3
G#3
A 3
A#3
B 3
C 4
C#4
D 4
D#4
E 4
F 4
F#4
G 4
G#4
A 4
A#4
B 4
C 5
C#5
D 5
D#5
E 5
F 5
F#5
G 5
G#5
A 5
A#5
B 5
C 6
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
on
378
404
401
403
401
405
314
385
408
378
389
375
373
407
380
358
391
409
419
410
424
410
426
411
412
433
413
429
435
431
354
434
453
434
356
449
336
335
339
338
337
345
344
341
341
349
352
359
359
343
342
350
348
348
346
347
355
355
353
357
360
477
477
477
477
477
477
477
477
477
477
477
477
Dr BdVar5
Dr SdBrsL
Dr SdSwep
Dr SdBrsH
Dr SdSwep
Dr SdRoll
Wv Noise
Dr SdSonA
Dr Stick
Dr BdVar5
Dr SdPcBH
Dr BdVar2
Dr BdLoJz
Dr C.Rim2
Dr SdGM
Pc Clap
Dr SdWdH
Dr TomF
Dr HHCl1
Dr TomL
Dr HHPdl
Dr TomL
Dr HHOpn
Dr TomM
Dr TomHL
Dr Crash
Dr TomHH
Dr Ride
Dr China
Dr Cup
Pc Tmborn
Dr Crash2
Dr T8Cwbl
Dr Crash2
Pc VbSlp
Dr T8Crsh
Pc BongoH
Pc BongoL
Pc CngSlp
Pc CongaH
Pc CongaL
Pc TmblsH
Pc TmblsL
Pc AgogoL
Pc AgogoL
Pc Cabasa
Pc Maracs
Pc Whistl
Pc Whistl
Pc GiroCl
Pc GuiroL
Pc Claves
Pc Wdblck
Pc Wdblck
Pc CuicaL
Pc CuicaH
Pc TrangL
Pc TrangL
Pc Shaker
Pc JnglBl
Pc Bltree
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Dr DstKik
Note
Internal (MSB=63, LSB=32)
12
No. Cat./WaveName No. Cat./WaveName No. Cat./WaveName No. Cat./WaveName No. Cat./WaveName No. Cat./WaveName
1 Pf Grand 86 Or D1 1/3 171 Gt Single 256 Wv MogBs2 341 Pc AgogoL 426 Dr HHOpn
2 Pf Grand+ 87 Or D1 172 Gt SnglHi 257 Wv MogBs3 342 Pc GuiroL 427 Dr HHOpn2
3 Pf Grand- 88 Or LesGrt 173 Gt StrtF 258 Wv FMBs1 343 Pc GiroCl 428 Dr HHTip
4 Pf Brit 89 Or LesGr2 174 Gt ES335 259 Wv FMBs2 344 Pc TmblsL 429 Dr Ride
5 Pf Brit+ 90 Or Rotar 175 Gt DistCl 260 Wv FMBs3 345 Pc TmblsH 430 Dr Ride2
6 Pf Brit- 91 Or Clack 176 Gt DistMt 261 Wv FMBs4 346 Pc CuicaL 431 Dr Cup
7 Pf CP80 92 Or LesWho 177 Gt FeedBk 262 Wv FMBs5 347 Pc CuicaH 432 Dr Cup2
8 Pf CP80+ 93 Or SftTmp 178 Gt StlHrm 263 Wv FMBs6 348 Pc Wdblck 433 Dr Crash
9 Pf CP80- 94 Or Perc 179 Gt StrHrm 264 Wv FMFnk 349 Pc Cabasa 434 Dr Crash2
10 Pf Rho1P 95 Or Perc+ 180 Gt Dist2 265 Wv FMGtr 350 Pc Claves 435 Dr China
11 Pf Rho1P+ 96 Or Perc- 181 Ba Acstic 266 Wv Late-S 351 Pc Castnt 436 Dr China2
12 Pf Rho1P- 97 Or Harmnc 182 Ba Acstc+ 267 Wv Late-L 352 Pc Maracs 437 Dr T8BdBm
13 Pf Rho1L 98 Or Acrdn 183 Ba Acstc- 268 Wv P5Saw 353 Pc Shaker 438 Dr T8Bd
14 Pf Rho1L+ 99 Or Acrdn+ 184 Ba Fing 269 Wv Saw2 354 Pc Tmborn 439 Dr T8SD1
15 Pf Rho1L- 100 Or Acrdn- 185 Ba Fing+ 270 Wv 1o1Saw 355 Pc TrangL 440 Dr T8SD2
16 Pf Rho2S 101 Cp FngCym 186 Ba Fing- 271 Wv 1o1Sub 356 Pc VbSlp 441 Dr T8SD3
17 Pf Rho2S+ 102 Cp Hibasi 187 Ba Harmnc 272 Wv SawSqu 357 Pc JnglBl 442 Dr T8SD4
18 Pf Rho2S- 103 Cp StoneH 188 Ba Precsn 273 Wv SquSaw 358 Pc Clap 443 Dr T8Side
19 Pf Rho2M 104 Cp StoneS 189 Ba Prcsn+ 274 Wv MgRamp 359 Pc Whistl 444 Dr T8Rmst
20 Pf Rho2M+ 105 Cp Gamln1 190 Ba Pecsn- 275 Wv P10-1 360 Pc Bltree 445 Dr T8Clap
21 Pf Rho2M- 106 Cp Gamln2 191 Ba PrsRw 276 Wv P10-2 361 Pc AnvlHt 446 Dr T8Tom
22 Pf Rho2H 107 Cp Glock 192 Ba PrsRw+ 277 Wv P10-3 362 Pc AnvlPp 447 Dr T8HHCl
23 Pf Rho2H+ 108 Cp Marimb 193 Ba PrsRw- 278 Wv P25-1 363 Pc Scrch1 448 Dr T8HHOp
24 Pf Rho2H- 109 Cp Vibra 194 Ba Pick 279 Wv P25-2 364 Pc Scrch2 449 Dr T8Crsh
25 Pf Rho3 110 Cp Xylo 195 Ba Slap 280 Wv P50-1 365 Pc VoxDrm 450 Dr T8CngL
26 Pf Rho3+ 111 Cp HndBel 196 Ba Slap+ 281 Wv P50-2 366 Pc Ripper 451 Dr T8CngM
27 Pf Rho3- 112 Cp Crotls 197 Ba Slap- 282 Wv Tri 367 Pc CONG 452 Dr T8CngH
28 Pf Rho4 113 Cp Timpni 198 Ba Slap2 283 Wv Digi01 368 Pc StlClp 453 Dr T8Cwbl
29 Pf Rho4+ 114 Br SectnL 199 Ba Slap2+ 284 Wv Digi02 369 Pc WdBlk 454 Dr T8Clve
30 Pf Rho4- 115 Br SectnR 200 Ba Slap2- 285 Wv Digi03 370 Dr BdStd 455 Dr T8Mrcs
31 Pf Wurli 116 Br SctnSt 201 Ba Frtl1 286 Wv Digi04 371 Dr BdPop 456 Dr T9BD1
32 Pf Wurli+ 117 Br SctnL- 202 Ba Frtl1+ 287 Wv Digi05 372 Dr BdHby 457 Dr T9BD2
33 Pf Wurli- 118 Br SctnR- 203 Ba Frtl1- 288 Wv Digi06 373 Dr BdLoJz 458 Dr T9BD3
34 Pf DX1 119 Br SctSt- 204 Ba Frtl2 289 Wv Digi07 374 Dr BdVar1 459 Dr T9SD1
35 Pf DX2 120 Br Sctn2L 205 Ba Frtl2+ 290 Wv Digi08 375 Dr BdVar2 460 Dr T9SD2
36 Pf DX3 121 Br Sctn2R 206 Ba Frtl2- 291 Wv Digi09 376 Dr BdVar3 461 Dr T9SD3
37 Pf Clav1 122 Br Sct2St 207 Ba SyBass 292 Wv Digi10 377 Dr BdVar4 462 Dr T9SD4
38 Pf Clav1+ 123 Br Sct2L+ 208 En SynVox 293 Wv Digi11 378 Dr BdVar5 463 Dr T9SD5
39 Pf Clav1- 124 Br SctnR+ 209 En VxNoiz 294 Wv Digi12 379 Dr BdAna 464 Dr T9SD6
40 Pf Clav2 125 Br Sct2S+ 210 En Aah 295 Wv Bel1Wv 380 Dr SdGM 465 Dr T9Clap
41 Pf Clav2+ 126 Br Sct2L- 211 En Aah+ 296 Wv Bel2Wv 381 Dr SdBldS 466 Dr T9Rim
42 Pf Clav2- 127 Br Sct2R- 212 En Aah- 297 Wv DgVox1 382 Dr SdBldH 467 Dr T9TomL
43 Pf Clav3 128 Br Sct2S- 213 En Oooo 298 Wv DgVox2 383 Dr SdFsnH 468 Dr T9TomM
44 Pf Clav3+ 129 Br Trmbn 214 En Oooo+ 299 Wv DgVox3 384 Dr SdLdwH 469 Dr T9TomH
45 Pf Clav3- 130 Br Trmbn- 215 En Oooo- 300 Wv DgVox4 385 Dr SdSonA 470 Dr T9HHC1
46 Pf Hrpscd 131 Br SftTrb 216 En Itopia 301 Wv DgVox5 386 Dr SdSonD 471 Dr T9HHC2
47 Or JmPrc 132 Br SftFlg 217 Rd Alto 302 Wv VoxG2 387 Dr SdHvy 472 Dr T9HHO1
48 Or JmPrc- 133 Br SftFl- 218 Rd Alto+ 303 Wv VoxE3 388 Dr SdPclH 473 Dr T9HHO2
49 Or Jazz 134 Br Hermn 219 Rd Alto- 304 Wv Ep1 389 Dr SdPcBH 474 Dr T9Crsh
50 Or Jazz+ 135 Br Strgt 220 Rd Tenor 305 Wv Ep2 390 Dr SdPrmH 475 Dr T9Ride
51 Or Jazz- 136 Br TrpMed 221 Rd Tenor+ 306 Wv Ep3 391 Dr SdWdH 476 Dr EuroBD
52 Or Rock 137 Br TrpSft 222 Rd Tenor- 307 Wv Ep4 392 Dr SdVar1 477 Dr DstKik
53 Or Rock+ 138 Br Trmpt 223 Rd Bari 308 Wv Ep5 393 Dr SdVar2 478 Dr Bd Kit
54 Or Rock- 139 Br Trmpt+ 224 Rd BigSx1 309 Wv EP6 394 Dr SdRim1 479 Dr Sn Kit
55 Or Argent 140 Br Trmpt- 225 Rd BigSx2 310 Wv Org1Wv 395 Dr SdRim2 480 Pf Grand2
56 Or BowVb 141 Br PiclTp 226 Rd SxBrth 311 Wv Org2Wv 396 Dr SdAmb1 481 Pf Grand2St
57 Or BowNv 142 Br F.Horn 227 Rd Soprn 312 Wv Org3Wv 397 Dr SdAmb2 482 Pf Grand2L
58 Or Gospel 143 Br Combi1 228 Rd Soprn+ 313 Wv Sin 398 Dr SdAmb3 483 Pf Grand2R
59 Or Green 144 Br Combi2 229 Rd Soprn- 314 Wv Noise 399 Dr SdBkBt 484 Pf Grand2+
60 Or Santana 145 Br Combi3 230 Rd Clari 315 Wv PnoNP 400 Dr SdDry 485 Pf Grnd2St+
61 Or Farfis 146 Br Combi4 231 Rd Clari+ 316 Wv EPNP 401 Dr SdSwep 486 Pf Grand2L+
62 Or Farfi- 147 St Vln 232 Rd Clari- 317 Wv VibeNP 402 Dr SdBrsS 487 Pf Grand2R+
63 Or VoxOrg 148 St Vln2 233 Rd Oboe 318 Fx VoxBel 403 Dr SdBrsH 488 Pf Grand2-
64 Or VxOrg- 149 St Cello 234 Rd Oboe+ 319 Fx Melow 404 Dr SdBrsL 489 Pf Grnd2St-
65 Or Swish 150 St EnsMx 235 Rd Oboe- 320 Fx WndChm 405 Dr SdRoll 490 Pf Grand2L-
66 Or Swish- 151 St EnsMx- 236 Rd Basoon 321 Fx BelAir 406 Dr C.Rim1 491 Pf Grand2R-
67 Or Dw1+3 152 St SmlEns 237 Rd Basoon+ 322 Fx BigSyn 407 Dr C.Rim2 492 Pf Grand3
68 Or Dw1+3+ 153 St SmlEn+ 238 Rd Basoon- 323 Fx TrnCho 408 Dr Stick 493 Pf Grand3St
69 Or Dw1+3- 154 St SmlEn- 239 Pi Flute 324 Fx HanSol 409 Dr TomF 494 Pf Grand3L
70 Or Dw2+4 155 St Pizz 240 Pi Flute+ 325 Fx Eery 410 Dr TomL 495 Pf Grand3R
71 Or Dw2+4+ 156 St Pizz2 241 Pi Flute- 326 Fx Electr 411 Dr TomM 496 Pf Grand3+
72 Or Dw2+4- 157 St Harp 242 Pi PnFlt 327 FX HH Hit 412 Dr TomHL 497 Pf Grnd3St+
73 Or DrwEv 158 Gt Nylon 243 Pi PnFlt- 328 Fx VxAlk 413 Dr TomHH 498 Pf Grand3L+
74 Or DrwEv+ 159 Gt NylnHi 244 Wv ModSaw 329 Fx HiLo 414 Dr TmJzL 499 Pf Grand3R+
75 Or DrwEv- 160 Gt Nylhrm 245 Wv ObStr 330 Fx MltPno 415 Dr TmJzM 500 Pf Grand3-
76 Or DrwOd 161 Gt Steel 246 Wv JpStr 331 Fx AHoseL 416 Dr TmJzH 501 Pf Grnd3St-
77 Or DrwOd+ 162 Gt StelHi 247 Wv SyzStr 332 Fx AHoseR 417 Dr Tom2H 502 Pf Grand3L-
78 Or DrwOd- 163 Gt StelLo 248 Wv Padd 333 Et StlDrm 418 Dr Tom2L 503 Pf Grand3R-
79 Or D16 164 Gt JzGtr 249 Wv ObBrs 334 Et Sitar 419 Dr HHCl1 504 Pf Rho5H
80 Or D5 1/3 165 Gt Strt 250 Wv SyncLd 335 Pc BongoL 420 Dr HHCL2 505 Pf Rho5M
81 Or D8 166 Gt StrtN 251 Wv CS80Br 336 Pc BongoH 421 Dr HHCl3 506 Pf Rho5L
82 Or D4 167 Gt StrtSl 252 Wv 3o3Saw 337 Pc CongaL 422 Dr HHCl4 507 Pf Rho5H+
83 Or D2 2/3 168 Gt StrtSp 253 Wv 3o3Sw2 338 Pc CongaH 423 Dr HHCl5 508 Pf Rho5M+
84 Or D2 169 Gt StrtMt 254 Wv 3o3Squ 339 Pc CngSlp 424 Dr HHPdl 509 Pf Rho5L+
85 Or D1 3/5 170 Gt Front 255 Wv MogBs1 340 Pc Cowbel 425 Dr HHPdl2 510 Pf Rho5H-
No. Cat./WaveName
511 Pf Rho5M-
512 Pf Rho5L-
513 Pf Rho6H
514 Pf Rho6L
515 Pf Rho6H+
516 Pf Rho6L+
517 Pf Rho6H-
518 Pf Rho6L-
519 Or Pipe1St
520 Or Pipe1L
521 Or Pipe1R
522 Or Pipe2
523 Or Pipe3St
524 Or Pipe3L
525 Or Pipe3R
526 Or Pipe4
527 Or Pipe5
528 Or Pipe6
529 Or Pipe7
530 En AahSt
531 En AahL
532 En AahR
533 En AahC
534 En AahSt+
535 En AahL+
536 En AahR+
537 En AahC+
538 En AahSt-
539 En AahL-
540 En AahR-
541 En AahC-
542 En OohSt
543 En OohL
544 En OohR
545 En OohRich
546 En OohSt+
547 En OohL+
548 En OohR+
549 En OohRich+
550 En OohSt-
551 En OohL-
552 En OohR-
553 En OohRich-
Wave List
13
Performance List
*1 Performance adatte per esecuzione sulla tastiera.
*2 Performance adatte per playback multi-part usando la funzione sequencer.
*3 Performance adatte per le impostazioni della master keyboard.
La funzione Arpeggio Hold è preset per le Performance contrassegnate da " ."
Ruotando Knob2 in senso antiorario si imposta su off la funzione Arpeggio.
Internal (MSB=63, LSB=64)
No. Performance Name Category Notes No. Performance Name Category Notes
AGE2000NEW Co RayOfLight Co
Hallelujah Vo NotreDame Co
MetalPiano Pf Montuno Pf
MayanMagic Fx 80Sphere Pd
HipHop Pop Co TheIslands Co
Oktavian Sc SweepPerf Sc
Bass/Piano Co Jazz It! Co
Overture Fx Mobutu Se
Opus 12 St Harp@Orch Co
EP+Strings Co PF/Strings Co
MuteTrp/EP Co Gnu Age Co
Rock It! Co Cookin' Co
WhirlPool Fx A.Gt/Lucky Co
Marrakesh Et PhazeEuro Co
SuperStrgs St Classical4 Co
Mysterioso Pd Scare-isma Fx
Clockworks Se Shagundala Co
ChurchEns Co Sevenths Br
TX816 EP Pf BreathPian Pf
Neonist Co It Grows! Pd
Busta' Co Flute Funk Co
Trancitar Co Real World Co
Bss/Pno+EP Co Cool Vibe Co
CirqDeAna Co Paradise Co
ScratchIt Co Balladeer Co
EP/Strings Co Strg/Piano Co
Sax/EP Co Barcelona Co
Rollin' Co Girl Co
GuitInAPad Co 1973! Co
SafariTech Et Flying Co
Classical1 Co Classical5 Co
Horror Se PatchCords Fx
Dreamloopr Co Pops --
Messiah Co Ballad 1 --
CrystalPno Pf Ballad 2 --
Pad Sweep Pd Unplugged --
Ottomatic Co 80's Disco --
Rockie Sc Funk Rock --
Club Blues Co Hard Rock --
Drumantics Dr HeavyMetal --
Fairy Dust Co ProgreRock --
Piano&Str. Co Blues Rock --
Bavarian Co West Coast --
SlowGroove Co BritishRck --
Bell&Str Co Big Band --
Rezzies Co Combo Jazz --
Classical2 Co JazzBallad --
911 Call Se Fusion --
Seekwencer Co Club Jazz --
Sanctuary Co House --
Wire+Piano Pf Techno --
DeepBreeze Pd Trance --
DiscoDucks Co Big Beat --
BigFive Sc Drum'nBass --
Bs/PercOrg Co HipHop --
Night Byte Sq Reggae --
Sonority Co R&B --
Folk Trio Co India --
Funk It! Co Salsa --
Police Men Co Gamelan --
2 Mini's Ld Ambient --
Aquamarine Co Tango --
Classical3 Co SoundTrack --
Nitechills Se Master KB --
Ved. *1
Ved. *1
Ved. *2
Ved. *3
65(E01)
66(E02)
67(E03)
68(E04)
69(E05)
70(E06)
71(E07)
72(E08)
73(E09)
74(E10)
75(E11)
76(E12)
77(E13)
78(E14)
79(E15)
80(E16)
81(F01)
82(F02)
83(F03)
84(F04)
85(F05)
86(F06)
87(F07)
88(F08)
89(F09)
90(F10)
91(F11)
92(F12)
93(F13)
94(F14)
95(F15)
96(F16)
97(G01)
98(G02)
99(G03)
100(G04)
101(G05)
102(G06)
103(G07)
104(G08)
105(G09)
106(G10)
107(G11)
108(G12)
109(G13)
110(G14)
111(G15)
112(G16)
113(H01)
114(H02)
115(H03)
116(H04)
117(H05)
118(H06)
119(H07)
120(H08)
121(H09)
122(H10)
123(H11)
124(H12)
125(H13)
126(H14)
127(H15)
128(H16)
1(A01)
2(A02)
3(A03)
4(A04)
5(A05)
6(A06)
7(A07)
8(A08)
9(A09)
10(A10)
11(A11)
12(A12)
13(A13)
14(A14)
15(A15)
16(A16)
17(B01)
18(B02)
19(B03)
20(B04)
21(B05)
22(B06)
23(B07)
24(B08)
25(B09)
26(B10)
27(B11)
28(B12)
29(B13)
30(B14)
31(B15)
32(B16)
33(C01)
34(C02)
35(C03)
36(C04)
37(C05)
38(C06)
39(C07)
40(C08)
41(C09)
42(C10)
43(C11)
44(C12)
45(C13)
46(C14)
47(C15)
48(C16)
49(D01)
50(D02)
51(D03)
52(D04)
53(D05)
54(D06)
55(D07)
56(D08)
57(D09)
58(D10)
59(D11)
60(D12)
61(D13)
62(D14)
63(D15)
64(D16)
14
Control List
15
CONTROLLER
Name No. Osservazioni
Osservazioni
PB:PITCH BEND Pitch Bend
MW:MODULATION WHELL 1Modulation
AT:AFTER TOUCH After Touch
BC:BREATH CONTROLLER (2)
RB:RIBBON CONTROLLER (22)
FC:FOOT CONTROLLER (11)
FS:FOOT SWITCH (64)
ASSIGNABLE KNOB
Name No.
[KNOB A] (18)
[KNOB B] (19)
[KNOB C] (20)
[KNOB 1] (16)
[KNOB 2] (17)
Control Change Number List
Impostato nel modo Utility o Performance
Impostato nel modo Utility o Performance
Impostato nel modo Utility o Performance
Impostato nel modo Utility o Performance
Impostato nel modo Utility o Performance
Impostato nel modo Utility
Impostato nel modo Utility
Impostato nel modo Utility
Impostato nel modo Utility
I numeri di controllo tra parentesi sono quelli di default.
No. Name No. Name
1 UpOct1:Sq
86 Guit4Arp:Ph
2 UpOct2:Sq
87 Harp Arp:Ph
3 UpOct4:Sq
88 BigBeat1:Dr
4 DownOct1:Sq
89 BigBeat2:Dr
5 DownOct2:Sq
90 BigBeat3:Dr
6 DownOct4:Sq
91 BigBeat4:Dr
7 U/DAOct1:Sq
92 Rock1:Dr
8 U/DAOct2:Sq
93 Rock2:Dr
9 U/DAOct4:Sq
94 Rock3:Dr
10 U/DBOct1:Sq
95 BigBeat5:Dr
11 U/DBOct2:Sq
96 BigBeat6:Dr
12 U/DBOct4:Sq
97 BigBeat7:Dr
13 RndmOct1:Sq
98 BigBeat8:Dr
14 RndmOct2:Sq
99 BigBeat9:Dr
15 RndmOct4:Sq
100 BrkTrnce:Dr
16 Oct2Up:Sq
101 House1:Dr
17 Oct4Up:Sq
102 House2:Dr
18 UnisonUp:Sq
103 House3:Dr
19 Up&Down1:Sq
104 Garage:Dr
20 Up&Down2:Sq
105 House4:Dr
21 Up&Down4:Sq
106 House5:Dr
22 Up&Alt1:Sq
107 HipHop:Dr
23 Up&Rndm1:Sq
108 JazzHop:Dr
24 Up&Rndm2:Sq
109 Abstract:Dr
25 Up&Rndm4:Sq
110 LoBeat1:Dr
26 ChdAltB1:Sq
111 LoBeat2:Dr
27 ChdAltB2:Sq
112 LoBeat3:Dr
28 ChdAltB4:Sq
113 LoBeat4:Dr
29 ChdRndm1:Sq
114 LoBeat5:Dr
30 ChdRndm2:Sq
115 LoBeat6:Dr
31 ChdRndm4:Sq
116 Drm&Bs1:Dr
32 TechnoA:Ph
117 Drm&Bs2:Dr
33 TechnoB:Ph
118 Linear:Dr
34 TechnoC:Ph
119 08beat1:Dr
35 DAHouse:Ph
120 08beat2:Dr
36 SyncopaA:Ph
121 08beat3:Dr
37 SyncopaB:Ph
122 16beat1:Dr
38 SyncpEco:Ph
123 16beat2:Dr
39 TekEchoA:Ph
124 1Bar:Dr
40 TekEchoB:Ph
125 1BarRndm:Dr
41 PulsLine:Ph
126 GateCut1:Ct
42 SeqS&H1:Ph
127 GateCut2:Ct
43 SeqS&H2:Ph
128 GateCut3:Ct
44 CleanGt1:Ph
45 CleanGt2:Ph
46 CleanGt3:Ph
47 CleanGt4:Ph
48 Pno16Bt:Ph
49 PnoLatin:Ph
50 CrvBass:Ph
51 Ocean:Ph
52 Orbit:Ph
53 X-Sweep1:Ph
54 X-Sweep2:Ph
55 X-Sweep3:Ph
56 Lamb:Ph
57 Thips:Ph
58 Hardcore:Ph
59 Harmo:Ph
60 Ascorbic:Ph
61 Doves:Ph
62 Chodal:Ph
63 Simple:Ph
64 Waggle:Ph
65 SuperArp:Ph
66 MuteArp1:Ph
67 MuteArp2:Ph
68 VelGruv1:Ph
69 VelGruv2:Ph
70 SpaceArp:Ph
71 MuteLine:Ph
72 StepLine:Ph
73 AcidLine:Ph
74 SplitArp:Ph
75 Step Seq:Ph
76 PolyArp1:Ph
77 PolyArp2:Ph
78 Ana Seq:Ph
79 Planet:Ph
80 Rosync:Ph
81 StrumArp:Ph
82 Guit1Arp:Ph
83 RolliArp:Ph
84 Guit2Arp:Ph
85 Guit3Arp:Ph
Arpeggio Type List
16
Effect Category Effect Name LCD
MSB LSB
REV CHO
InsEF1 InsEF2
--- NO EFFECT off 00 00 0 0
--- THRU Thru 00 00 0 0
REVERB
REV HALL 1 Hall1 01 00 1 1
REV HALL 2 Hall2 01 01 2 2
REV ROOM 1 Room1 01 10 3 3
REV ROOM 2 Room2 01 11 4 4
REV ROOM 3 Room3 01 12 5 5
REV STAGE 1 Stage1 01 20 6 6
REV STAGE 2 Stage2 01 21 7 7
REV PLATE Plate 01 30 8 8
REV WHITE ROOM WhiteRm 01 40 9
REV TUNNEL Tunnel 01 41 10
REV BASEMENT
Basement
01 42 11
REV CANYON Canyon 01 43 12
DELAY DLY DELAY L,C,R
DelayLCR
02 00 9
DLY DELAY L,R DelayLR 02 10 18 10
DLY ECHO Echo 02 20 11
DLY CROSS DELAY CrossDly 02 30 12
DLY CONTROL DELAY1 (MONO) CtrlDly1 02 40 19 13
DLY CONTROL DELAY2 (STEREO) CtrlDly2 02 48 20 14
DLY TEMPO DELAY1 (MONO)
TempDly1
02 50 21 15
DLY TEMPO DELAY2 (STEREO)
TempDly2
02 58 22 16
DLY TEMPO CROSS DELAY
TempCDly
02 60 23 17
EARLY REFLECTION
ER EARLY REFLECTION 1 ER 1 03 00 18
ER EARLY REFLECTION 2 ER 2 03 01 19
ER GATE REVERB GateRev 03 10 20
ER REVERSE GATE RvrsGate 03 20 21
KARAOKE
KAR KARAOKE 1 Karaoke1 04 00 22
KAR KARAOKE 2 Karaoke2 04 01 23
KAR KARAOKE 3 Karaoke3 04 02 24
CHORUS
CHO CHORUS 1 Chorus1 05 00 1 1 25
CHO CHORUS 2 Chorus2 05 01 2 2 26
CHO CHORUS 3 Chorus3 05 02 3 3 27
CHO CHORUS 4 Chorus4 05 08 4 4 28
CHO CHORUS 5 Chorus5 05 09 5 29
CHO CELESTE 1 Celeste1 05 10 6 5 30
CHO CELESTE 2 Celeste2 05 11 7 6 31
CHO CELESTE 3 Celeste3 05 12 8 7 32
CHO CELESTE 4 Celeste4 05 18 9 8 33
CHO SYMPHONIC
Symphonc
05 20 10 34
CHO ENSEMBLE DETUNE Ensemble 05 30 11 35
FLANGER
FLG FLANGER 1 Flanger1 06 00 12 9 36
FLG FLANGER 2 Flanger2 06 01 13 10 37
FLG FLANGER 3 Flanger3 06 08 14 11 38
FLG V-FLANGER V-Flange 06 10 39
FLG TEMPO FLANGER
TempFlng
06 50 15 40
PHASER
PHA PHASER 1 Phaser1 07 00 16 12 41
PHA PHASER 2 Phaser2 07 08 42
PHA TEMPO PHASER
TempPhas
07 50 17 43
MODULATION
MOD TREMOLO Tremolo 08 00 13 44
MOD AUTO PAN AutoPan 08 10 14 45
MOD ROTARY SPEAKER1 RotrySp1 08 50 46
MOD DISTORTION+ROTARY SPEAKER1 Dt+RSp1 08 51 47
MOD OVERDRIVE+ROTARY SPEAKER1 Od+RSp1 08 52 48
MOD AMP SIM.+ROTARY SPEAKER1
Amp+RSp1
08 53 49
MOD ROTARY SPEAKER2 RotrySp2 08 60 50
MOD DISTORTION+ROTARY SPEAKER2 Dt+RSp2 08 61 51
MOD OVERDRIVE+ROTARY SPEAKER2 Od+RSp2 08 62 52
MOD AMP SIM.+ROTARY SPEAKER2
Amp+RSp2
08 63 53
MOD ROTORY SPEAKER3 RotrySp3 08 70 54
MOD ROTORY SPEAKER4 RotrySp4 08 71 55
DISTORTION
DST DISTORTION Dist 09 00 15 56
DST COMP DISTORTION Comp+Dt 09 01 57
DST V-DISTORTION V-Dist 09 10 58
DST OVER DRIVE OverDrv 09 20 16 59
DST AMP SIMULATOR AmpSim 09 30 17 60
DST DIST+DELAY Dist+Dly 09 40 61
DST OVERDRIVE+DELAY Odrv+Dly 09 41 62
DYNAMIC
DYN COMPRESSOR1 Comp1 0A 00 18 63
DYN NOISE GATE NoisGate 0A 20 19 64
DYN COMP+DIST+DELAY
CmpDtDly
0A 40 65
DYN COMP+OVERDRIVE+DELAY
CmpOdDly
0A 41 66
PITCH CHANGE
PCH PITCH CHANGE 1
PchChng1
0B 00 67
PCH PITCH CHANGE 2
PchChng2
0B 01 68
WAH
WAH AUTO WAH AutoWah 0C 00 20 69
WAH AUTO WAH + DIST AWah+Dt 0C 01 70
WAH AUTO WAH + OVERDRIVE
AWah+Od
0C 02 71
WAH TOUCH WAH
TouchWah
0C 10 21 72
WAH TOUCH WAH + DIST TWah+Dt 0C 11 73
WAH TOUCH WAH + OVERDRIVE
TWah+Od
0C 12 74
WAH WAH+DIST+DELAY WahDtDly 0C 40 75
WAH WAH+OVERDRIVE+DELAY
WahOdDly
0C 41 76
LO-FI
L-F LO-FI Lo-Fi 0D 00 77
L-F LOW RESOLUTION LowReso 0D 10 78
L-F NOISY Noisy 0D 20 79
L-F ATTACK LOFI AtkLoFi 0D 30 80
L-F DIGITAL TURNTABLE DTurnTbl 0D 50 81
TECH
TEC DIGITAL SCRATCH DScratch 0E 00 82
TEC AUTO SYNTH AutoSyn 0E 10 83
TEC TECH MODULATION TechMod 0E 20 84
TEC JUMP Jump 0E 30 85
MISC
MSC 3BAND EQ 3BandEQ 0F 00 22 86
MSC 2BAND EQ 2BandEQ 0F 01 23 87
MSC HARMONIC ENHANCER Enhancer 0F 10 24 88
MSC VOICE CANCEL VceCancl 0F 20 89
MSC AMBIENCE Ambience 0F 30 90
MSC TALKING MODULATOR TalkMod 0F 40 91
MSC BEAT CHANGE BeatChng 0F 50 92
(HEX) No.MIDI
Effect Type List Effect Parameter List
1. Reverb
[1] HALL1 ~ [8] PLATE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
9
10
[9] WHITE ROOM ~ [12] CANYON
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Reverb Time
Initial Delay
Reverb Delay
HPF Cutoff Frequency
LPF Cutoff Frequency
Diffusion
Width
Height
Depth
Wall Vary
Reverb Time
Initial Delay
Reverb Delay
HPF Cutoff Frequency
LPF Cutoff Frequency
Diffusion
Density
ER / Rev Balance
Feedback High Damp
Feedback Level
0.3s~30.0s
0.1ms~200.0ms
0.1ms~200.0ms
20Hz~8.0kHz
1.0kHz~20.0kHz
0~10
0.5m~30.2m
0.5m~30.2m
0.5m~30.2m
0~30
0.3s~30.0s
0.1ms~200.0ms
0.1ms~200.0ms
20Hz~8.0kHz
1.0kHz~20.0kHz
0~10
0~4
E63>R ~ E=R ~ E<R63
0.1~1.0
-63~+63
RevTime
InitDly
RevDly
HPF
LPF
Diffuse
Width
Height
Depth
Wall
RevTime
InitDly
RevDly
HPF
LPF
Diffuse
Density
ER/Rev
FBHiDmp
FBLevel
1
3
6
4
5
2
7
8
9
10
Ø
Ø
Ø
Ø
2
3
4
5
6
7
8
9
10
1
3
10
4
5
2
6
7
8
9
Ø
Ø
No. Parameter Value LCD
MIDI Parameter Number
Controller
No. Parameter Value LCD
MIDI Parameter Number
Controller
Ø
Ø
Ø
Ø
Ø
Ø
No. Parameter Value LCD
MIDI Parameter Number
Controller
Ø
Ø
Ø
Ø
Ø
Ø
No. Parameter Value LCD
MIDI Parameter Number
Controller
Ø
Ø
Ø
Ø
Ø
Ø
17
[15] TEMPO FLANGER
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 LFO Frequency
LFO Depth
LFO Phase Difference
LFO Phase Reset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Delay Offset
Feedback Level
5~21
0~127
-180deg~+180deg
off(free run), KeyOnReset, SEQ Start Reset
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
0.0ms~50.0ms
-63~+63
Speed
Depth
Phase
Reset
L.Freq
L.Gain
H.Freq
H.Gain
DlyOfst
FBLevel
2
3
4
5
6
7
8
9
10
1
2
6
5
7
8
9
10
4
3
Ø
Ø
Ø
Ø
Ø
Ø
[16] PHASER1
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 LFO Frequency
LFO Depth
Diffusion
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level
0.0Hz~39.70Hz
0~127
mono/stereo
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
4, 5, 6
0~127
-63~+63
Speed
Depth
Diffuse
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel
2
3
4
5
6
7
8
9
10
1
2
6
7
8
9
10
5
3
4
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[17] TEMPO PHASER
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
LFO Phase Reset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level
5~21
0~127
off(free run), KeyOnReset, SEQ Start Reset
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
4, 5, 6
0~127
-63~+63
Speed
Depth
PhaseReset
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel
1
2
6
7
8
9
10
5
3
4
Ø
Ø
Ø
Ø
Ø
Ø
Ø
9
10
[18] DELAY L,R(stereo)
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Delay Time L
Delay Time R
Feedback Time 1
Feedback Time 2
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.1ms~740.0ms
0.1ms~740.0ms
0.1ms~740.0ms
0.1ms~740.0ms
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
TimeL
TimeR
FBTime1
FBTime2
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
2
3
4
5
6
7
1
2
3
4
5
6
7
8
9
10
Ø
Ø
Ø
Ø
Ø
8
9
10
[19] CONTROL DELAY1(mono)
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Delay Time
Delay Transition Rate
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.1ms~1480.0ms
1~48
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Time
Trnsitn
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
2
3
1
2
3
4
5
6
7
8
Ø
Ø
Ø
Ø
Ø
Ø
Ø
4
5
6
7
8
[20] CONTROL DELAY2(stereo)
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Delay Time
Delay Transition Rate
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.1ms~740.0ms
1~48
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Time
Trnsitn
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gainl
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[21] TEMPO DELAY1(mono)
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Delay Time
Lag
L/R Diffusion
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
2~14
-63ms~+63ms
-63ms~+63ms
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Time
Lag
Diffuse
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
2
3
4
5
6
7
8
9
1
5
4
2
3
6
7
8
9
Ø
Ø
Ø
Ø
Ø
[22] TEMPO DELAY2(stereo)
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Delay Time
Lag
L/R Diffusion
Feedback Level
Feedback High Dump
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
2~14
-63ms~+63ms
-63ms~+63ms
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Time
Lag
Diffuse
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
2
3
4
5
6
7
8
9
1
5
4
2
3
6
7
8
9
Ø
Ø
Ø
Ø
Ø
[23] TEMPO CROSS DELAY
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Delay Time L>R
Delay Time R>L
Input Select
Lag
Feedback Level
Feedback High Dump
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
2~14
2~14
L, R, L&R
-63ms~+63ms
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
TimeL>R
TimeR>L
Input
Lag
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
2
3
4
5
6
7
8
9
10
1
2
5
6
3
4
7
8
9
10
Ø
Ø
Ø
Ø
Ø
3. Insertion Effect 1
[5]~[8]CELESTE1~4
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
Input Mode
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Delay Offset
Feedback Level
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
mono/stereo
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
0.0ms~50.0ms
-63~+63
D63>W ~D=W ~D<W63
Speed
Depth
Input
L.Freq
L.Gain
H.Freq
H.Gain
DlyOfst
FBLevel
Dry/Wet
1
2
9
5
6
7
8
4
3
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[1]~[4]CHORUS1~4
9
10
[0] THRU (None)
[9]~[11] FLANGER1~3
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 LFO Frequency
LFO Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Delay Offset
Feedback Level
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
-180deg~+180deg
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
0.0ms~50.0ms
-63~+63
D63>W ~ D=W ~ D<W63
Speed
Depth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
DlyOfst
FBLevel
Dry/Wet
2
3
4
5
6
7
1
2
9
5
6
7
8
4
3
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
8
9
10
18
[12] PHASER1
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 LFO Frequency
LFO Depth
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
4, 5, 6
0~127
-63~+63
D63>W ~ D=W ~ D<W63
Speed
Depth
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel
Dry/Wet
2
3
1
2
6
7
8
9
5
3
4
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
4
5
6
7
8
9
10
[13] TREMOLO
No. Parameter Value LCD
MIDI Parmeter Number
Controller
1 LFO Frequency
AM Depth
PM Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Input Mode
0.0Hz~39.70Hz
0~127
0~127
-180deg~+180deg
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
mono/stereo
Speed
AMDepth
PMDepth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
Input
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[14] AUTO PAN
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 LFO Frequency
L/R Depth
F/R Depth
PAN Direction
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.0Hz~39.70Hz
0~127
0~127
L<>R, L>>R, L<<R, Lturn, Rturn, L/R (0 ~5)
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Speed
L/RDpth
F/RDpth
Directn
L.Freq
L.Gain
H.Freq
H.Gain
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[16] OVERDRIVE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Drive
Edge
Output Level
EQ Low Frequency
EQ Low Gain
LPF Cutoff Frequency
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Dry / Wet Balance
0~127
0~127
0~127
32Hz~2.0kHz
-12dB~+12dB
1.0kHz~20.0kHz
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
D63>W ~ D=W ~ D<W63
Drive
Edge
OutLvl
L.Freq
L.Gain
LPF
M.Freq
M.Gain
M.Width
Dry/Wetl
2
3
4
5
6
7
8
9
10
1
8
9
2
3
7
4
5
6
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[15] DISTORTION
[17] AMP SIMULATOR
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
AMP Type
Drive
Edge
Output Level
LPF Cutoff Frequency
Dry / Wet Balance
off, stack, combo, tube
0~127
0~127
0~127
1.0kHz~20.0kHz
D63>W ~ D=W ~ D<W63
AmpType
Drive
Edge
OutLvl
LPF
Dry/Wet
2
1
4
5
3
6
Ø
Ø
Ø
Ø
Ø
[18] COMPRESSOR
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Attack
Release
Threshold
Ratio
Output Level
1ms~40ms
10ms~680ms
-48dB~-6dB
1~20.0
0~127
Attack
Release
Thrshld
Ratio
OutLvl
2
3
4
5
1
2
3
4
5
Ø
Ø
Ø
Ø
Ø
[19] NOISE GATE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Attack
Release
Threshold
Output Level
1ms~40ms
10ms~680ms
-72dB~-30dB
0~127
Attack
Release
Thrshld
Out Lvl
2
3
1
2
3
4
Ø
Ø
Ø
Ø
4
[20] AUTO WAH
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 LFO Frequency
LFO Depth
Cutoff Frequency Offset
Resonanse
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
0~127
1~12.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
D63>W ~ D=W ~ D<W63
Speed
Depth
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Dry/Wet
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
9
[21] TOUCH WAH
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 Sensitive
Cutoff Frequency Offset
Resonanse
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry / Wet Balance
0~127
0~127
1~12.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
D63>W ~ D=W ~ D<W63
Sens
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Dry/Wet
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[22] 2BAND EQ
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
L.Freq
L.Gain
H.Freq
H.Gain
2
3
4
1
2
3
4
Ø
Ø
Ø
Ø
[23] 3BAND EQ
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Input Mode
50Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
mono/stereo
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Input
2
3
4
5
6
7
8
1
2
6
7
3
4
5
8
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[24] HARMONIC ENHANCER
No. Parameter Value LCD
MIDI Parameter Number
Controller
1 HPF Cutoff Frequency
Drive
Mix Level
500Hz~+16.0kHz
0~127
0~127
HPF
Drive
Mix Lvl
2
3
1
2
3
Ø
Ø
Ø
4. Insertion Effect 2
[0] THRU (None)
[1] HALL1 ~ [8] PLATE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Reverb Time
Initial Delay
Reverb Delay
Dry / Wet Balance
HPF Cutoff Frequency
LPF Cutoff Frequency
Diffusion
Density
ER / Rev Balance
Feedback Level
Feedback High Damp
0.3s~30.0s
0.1ms~99.3ms
0.1ms~99.3ms
D63>W ~ D=W ~ D<W63
20Hz~8.0kHz
1.0kHz~20.0kHz
0~10
0~4
E63>R ~ E=R ~ E<R63
-63~+63
0.1~1.0
RevTime
InitDly
RevDly
Dry/Wet
HPF
LPF
Diffuse
Density
ER/Rev
FBLevel
FBHiDmp
1
3
11
10
4
5
2
12
13
15
14
9
10
11
Ø
Ø
Ø
Ø
Ø
19
[9] DELAY L,C,R
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Delay Time L
Delay Time R
Delay Time C
Dry / Wet Balance
Delay Level C
Feedback Time
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.1ms~1486.0ms
0.1ms~1486.0ms
0.1ms~1486.0ms
D63>W ~ D=W ~ D<W63
0~127
0.1ms~1486.0ms
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
TimeL
TimeR
TimeC
Dry/Wet
LevelC
FBTime
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
1
2
3
10
6
4
5
7
13
14
15
16
9
10
11
12
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[10] DELAY L,R
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Delay Time L
Delay Time R
Dry / Wet Balance
Feedback Time 1
Feedback Time 2
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.1ms~1486.0ms
0.1ms~1486.0ms
D63>W ~ D=W ~ D<W63
0.1ms~1486.0ms
0.1ms~1486.0ms
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
TimeL
TimeR
Dry/Wet
FBTime1
FBTime2
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
1
2
10
3
4
5
6
13
14
15
16
9
10
11
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[11] ECHO
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Delay Time L1
Delay Time R1
Dry / Wet Balance
Feedback Level L
Feedback Level R
Feedback High Damp
Delay Time L2
Delay Time R2
Delay Level
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.1ms~743.0ms
0.1ms~743.0ms
D63>W ~ D=W ~ D<W63
-63~+63
-63~+63
0.1~1.0
0.1ms~743.0ms
0.1ms~743.0ms
0~127
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
TimeL1
TimeR1
Dry/Wet
FBLvlL
FBLvlR
FBHiDmp
TimeL2
TimeR2
Level2
L.Freq
L.Gain
H.Freq
H.Gain
1
3
10
2
4
5
6
7
8
13
14
15
16
9
10
11
12
13
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[12] CROSS DELAY
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Delay Time L>R
Delay Time R>L
Input Select
Dry / Wet Balance
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.1ms~743.0ms
0.1ms~743.0ms
L, R, L&R
D63>W ~ D=W ~ D<W63
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
TimeL>R
TimeR>L
Input
Dry/Wet
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
1
2
4
10
3
5
13
14
15
16
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[13] CONTROL DELAY1(mono)
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Delay Time
Delay Transition Rate
Dry / Wet Balance
Control Type
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.1ms~1486.0ms
1~48
D63>W ~ D=W ~ D<W63
normal, scratch
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Time
Trnsitn
Dry/Wet
CtrType
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
1
2
10
11
3
4
6
7
8
9
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[14] CONTROL DELAY2(stereo)
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Delay Time
Delay Transition Rate
Dry / Wet Balance
Control Type
Feedback Level
Feedback High Damp
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.1ms~743.0ms
1~48
D63>W ~ D=W ~ D<W63
normal, scratch
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Time
Trnsitn
Dry/Wet
CtrType
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
1
2
10
11
3
4
6
7
8
9
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[15] TEMPO DELAY1(mono)
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Delay Time
Dry / Wet Balance
Lag
L/R Diffusion
Feedback Level
Feedback High Dump
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
2~14
D63>W ~ D=W ~ D<W63
-63ms~+63ms
-63ms~+63ms
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Time
Dry/Wet
Lag
Diffuse
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
1
10
6
5
3
4
13
14
15
16
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[16] TEMPO DELAY2(stereo)
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Delay Time
Dry / Wet Balance
Lag
L/R Diffusion
Feedback Level
Feedback High Dump
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
2~14
D63>W ~ D=W ~ D<W63
-63ms~+63ms
-63ms~+63ms
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Time
Dry/Wet
Lag
Diffuse
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
1
10
6
5
3
4
13
14
15
16
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[17] TEMPO CROSS DELAY
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Delay Time L>R
Delay Time R>L
Input Select
Dry / Wet Balance
Lag
Feedback Level
Feedback High Dump
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
2~14
2~14
L, R, L&R
D63>W ~ D=W ~D<W63
-63ms~ +63ms
-63~+63
0.1~1.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
TimeL>R
TimeR>L
Input
Dry/Wet
Lag
FBLevel
FBHiDmp
L.Freq
L.Gain
H.Freq
H.Gain
1
2
6
10
8
4
5
13
14
15
16
9
10
11
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[18]~[19] EARLY REF1~2
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Type
Room Size
Dry / Wet Balance
Diffusion
Initial Delay
Liveness
Density
HPF Cutoff Frequency
LPF Cutoff Frequency
Feedback Level
Feedback High Damp
S-hall, L-hall, random,
reverse, plate, spring
0.1~20.0
D63>W ~ D=W ~ D<W63
0 ~ 10
0.1ms~200.0ms
0 ~ 10
0 ~ 3
20Hz~8.0kHz
1.0kHz~20.0kHz
-63~+63
0.1~1.0
Type
Size
Dry/Wet
Diffuse
InitDly
Livenss
Density
HPF
LPF
FBLevel
FBHiDmp
1
2
10
3
4
11
12
6
7
5
13
9
10
11
Ø
Ø
Ø
Ø
20
[21] REVERSE GATE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Type
Room Size
Dry / Wet Balance
Diffusion
Initial Delay
Liveness
Density
HPF Cutoff Frequency
LPF Cutoff Frequency
Feedback Level
Feedback High Damp
Type-A, Type-B
0.1~20.0
D63>W ~ D=W ~ D<W63
0 ~ 10
0.1ms~200.0ms
0 ~ 10
0 ~ 3
20Hz~8.0kHz
1.0kHz~20.0kHz
-63~+63
0.1~1.0
Type
Size
Dry/Wet
Diffuse
InitDly
Livenss
Density
HPF
LPF
FBLevel
FBHiDmp
1
2
10
3
4
11
12
6
7
5
13
9
10
11
Ø
Ø
Ø
Ø
[20] GATE REVERB
[22]~[24] KARAOKE1~3
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
Delay Time
Feedback Level
Dry / Wet Balance
HPF Cutoff Frequency
LPF Cutoff Frequency
0.1ms~400.0ms
-63~+63
D63>W ~ D=W ~ D<W63
20Hz~8.0kHz
1.0kHz~20.0kHz
DlyTime
FBLevel
Dry/Wet
HPF
LPF
1
2
10
3
4
Ø
Ø
Ø
Ø
[30]~[33] CELESTE1~4
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
Input Mode
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Delay Offset
Feedback Leve
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
mono/stereo
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
0.0ms~50.0ms
-63~+63
D63>W ~ D=W ~ D<W63
Speed
Depth
Input
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
DlyOfst
FBLevel
Dry/Wet
1
2
15
6
7
8
9
11
12
13
4
3
10
9
10
11
12
13
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[25]~[29] CHORUS1~5
[34] SYMPHONIC
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
Delay Offset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
0.0ms~50.0ms
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
D63>W ~ D=W ~ D<W63
Speed
Depth
DlyOfst
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Dry/Wet
1
2
4
6
7
8
9
11
12
13
10
9
10
11
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[35] ENSEMBLE DETUNE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Detune
Initial Delay Lch
Initial Delay Rch
Dry / Wet Balance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
-50cent~+50cent
0.0ms~50.0ms
0.0ms~50.0ms
D63>W ~ D=W ~ D<W63
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Detune
DelayL
DelayR
Dry/Wet
L.Freq
L.Gain
H.Freq
H.Gain
1
2
3
10
11
12
13
14
Ø
Ø
Ø
Ø
Ø
[36]~[38] FLANGER1~3
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Delay Offset
Feedback Leve
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
-180deg~+180deg
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
0.0ms~50.0ms
-63~+63
D63>W ~ D=W ~ D<W63
Speed
Depth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
DlyOfst
FBLevel
Dry/Wet
1
2
14
6
7
8
9
11
12
13
4
3
10
9
10
11
12
13
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[39] V-FLANGER
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
LFO Wave
Modulation Phase
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Analog Feel
Feedback Gain
Feedback High Damp
Delay Offset
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
Triangle, Sine, Random
-180~+180
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
0~10
-100~+100%
0.1~1.0
0.09~36.21ms
D63>W ~ D=W ~ D<W63
Speed
Depth
Wave
Phase
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Analog
FBLevel
FBHiDmp
DlyOfst
Dry/Wet
1
2
3
5
6
7
8
9
11
12
13
16
14
15
4
10
9
10
11
12
13
14
15
16
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[40] TEMPO FLANGER
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
LFO Phase Difference
LFO Phase Reset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Delay Offset
Feedback Level
Dry / Wet Balance
5~21
0~127
-180deg~+180deg
off(free run), KeyOnReset, SEQ Start Reset
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
0.0ms~50.0ms
-63~+63
D63>W ~ D=W ~ D<W63
Speed
Depth
Phase
Reset
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
DlyOfst
FBLevel
Dry/Wet
1
2
14
5
6
7
8
9
11
12
13
4
3
10
9
10
11
12
13
14
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[41] PHASER1
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
Diffusion
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
mono/stereo
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
4, 5, 6, 7, 8, 9, 10, 11, 12
0~127
-63~+63
D63>W ~ D=W ~ D<W63
Speed
Depth
Diffuse
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel
Dry/Wet
1
2
12
6
7
8
9
11
3
4
10
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
11
21
[42] PHASER2
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
-180deg~+180deg
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
3, 4, 5, 6
0~127
-63~+63
D63>W ~ D=W ~ D<W63
Speed
Depth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel
Dry/Wet
1
2
13
6
7
8
9
11
3
4
10
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
11
[43] TEMPO PHASER
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
LFO Phase Difference
LFO Phase Reset
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Stage
Phase Shift Offset
Feedback Level
Dry / Wet Balance
5~21
0~127
-180deg~+180deg
off(free run), KeyOnReset, SEQ Start Reset
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
3, 4, 5, 6
0~127
-63~+63
D63>W ~ D=W ~ D<W63
Speed
Depth
Phase
Reset
L.Freq
L.Gain
H.Freq
H.Gain
Stage
PhShift
FBLevel
Dry/Wet
1
2
13
5
6
7
8
9
11
3
4
10
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
11
12
[44] TREMOLO
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
AM Depth
PM Depth
LFO Phase Difference
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Input Mode
0.0Hz~39.70Hz
0~127
0~127
-180deg~+180deg
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
mono/stereo
Speed
AMDepth
PMDepth
Phase
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Input
1
2
3
14
6
7
8
9
11
12
13
15
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
11
12
[45] AUTO PAN
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
L/R Depth
F/R Depth
PAN Direction
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
0.0Hz~39.70Hz
0~127
0~127
L<>R, L>>R, L<<R, Lturn, Rturn, L/R(0~5)
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
Speed
L/RDpth
F/RDpth
Directn
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
1
2
3
4
6
7
8
9
11
12
13
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
11
[46] ROTARY SPEAKER1
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
D63>W ~ D=W ~ D<W63
Speed
Depth
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Dry/Wet
1
2
6
7
8
9
11
12
13
10
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[47] DISTORTION+ROTARY SPEAKER1
[48] OVERDrive+ROTARY SPEAKER1
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
Dist. Drive
Dist. LPF Cutoff Freq
Dist. Output Level
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.0Hz~39.70Hz
0 ~ 127
0 ~ 127
1.0kHz~18.0kHz, thru
0 ~ 127
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Speed
Depth
Drive
LPF
DrivOut
L.Freq
L.Gain
H.Freq
H.Gain
1
2
14
15
16
6
7
8
9
9
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[49] AMP SIMULATOR+ROTARY SPEAKER1
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
AMP Type
AMP Drive
AMP LPF Cutoff Freq
AMP Output Level
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.0Hz~39.70Hz
0 ~ 127
off, stack, combo, tube
0 ~ 127
1.0kHz~18.0kHz, thru
0 ~ 127
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Speed
Depth
AmpType
Drive
LPF
AmpOut
L.Freq
L.Gain
H.Freq
H.Gain
1
2
3
14
15
16
6
7
8
9
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[50] ROTARY SPEAKER2
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
9
10
Rotor Speed
Drive Low
Drive High
Low / High Balance
Mic L-R Angle
Divide Frequency
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.0Hz~39.70Hz
0~127
0~127
L63>H ~ L=H ~ L<H63
0deg~180deg
100Hz~10.0kHz
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Speed
DriveLo
DriveHi
Low/Hi
MicAngl
CrosOvr
L.Freq
L.Gain
H.Freq
H.Gain
1
2
3
4
5
11
6
7
8
9
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[52] OVERDrive+ROTARY SPEAKER2
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Rotor Speed
Drive Low
Drive High
Low/High Balance
Mic L-R Angle
Divide Frequency
Dist.Drive
Dist. LPF Cutoff Freq
Dist. Output Level
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.0Hz~39.70Hz
0 ~ 127
0 ~ 127
L63>H ~ L=H ~ L<H63
0deg~180deg
100Hz~10.0kHz
0 ~ 127
1.0kHz~18.0kHz, thru
0 ~ 127
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Speed
DriveLo
DriveHi
Low/Hi
MicAngl
CrosOvr
Drive
LPF
DrivOut
L.Freq
L.Gain
H.Freq
H.Gain
1
2
3
4
12
11
14
15
16
6
7
8
9
9
10
11
12
13
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[51] DISTORTION+ROTARY SPEAKER2
[53] AMP SIM.+ROTARY SPEAKER2
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Rotor Speed
Drive Low
Drive High
Low/High Balance
Mic L-R Angle
Divide Frequency
AMP Type
AMP Drive
AMP LPF Cutoff Freq
AMP Output Level
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.0Hz~39.70Hz
0 ~ 127
0 ~ 127
L63>H ~ L=H ~ L<H63
0deg~180deg
100Hz~10.0kHz
off, stack, combo, tube
0 ~ 127
1.0kHz~18.0kHz, thru
0 ~ 127
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Speed
DriveLo
DriveHi
Low/Hi
MicAngl
CrosOvr
AmpType
Drive
LPF
AmpOut
L.Freq
L.Gain
H.Freq
H.Gain
1
2
3
4
12
11
13
14
15
16
6
7
8
9
9
10
11
12
13
14
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
22
[55] ROTARY SPEAKER4
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Speed Control
SLow-Fast Time of R
SLow-Fast Time of H
Rotor Speed SLow
Horn Speed SLow
Rotor Speed Fast
Horn Speed Fast
Mic L-R Angle
Drive Low
Drive High
Low/High Balance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
sLow, fast
0~127
0~127
0.0Hz~2.65Hz
0.0Hz~2.65Hz
2.69Hz~39.70Hz
2.69Hz~39.70Hz
0deg~180deg
0~127
0~127
L63>H ~ L=H ~ L<H63
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
Speed
Trans:Rotor
Trans:Horn
Rotor-Slw
Horn-Slw
Rotor-Fst
Horn-Fst
MicAngl
DriveLo
DriveHi
Low/Hi
L.Freq
L.Gain
H.Freq
H.Gain
16
5
6
1
2
3
4
15
7
8
9
11
12
13
14
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[54] ROTARY SPEAKER3
10
11
12
13
14
15
9
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Drive
Edge
Output Level
EQ Low Frequency
EQ Low Gain
LPF Cutoff Frequency
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Dry / Wet Balance
0~127
0~127
0~127
32Hz~2.0kHz
-12dB~+12dB
1.0kHz~20.0kHz
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
D63>W ~ D=W ~ D<W63
Drive
Edge
OutLvl
L.Freq
L.Gain
LPF
M.Freq
M.Gain
M.Width
Dry/Wet
1
11
5
2
3
4
7
8
9
10
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[59] OVERDRIVE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Drive
Edge
Output Level
EQ Low Frequency
EQ Low Gain
LPF Cutoff Frequency
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Dry / Wet Balance
0~127
0~127
0~127
32Hz~2.0kHz
-12dB~+12dB
1.0kHz~20.0kHz
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
D63>W ~ D=W ~ D<W63
Drive
Edge
OutLvl
L.Freq
L.Gain
LPF
M.Freq
M.Gain
M.Width
Dry/Wet
1
11
5
2
3
4
7
8
9
10
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[56] DISTORTION
[57] COMP DISTORTION
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Attack
Release
Threshold
Ratio
EQ Low Frequency
EQ Low Gain
Drive
Output Level
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Edge
LPF Cutoff Frequency
Dry / Wet Balance
1ms~40ms
10ms~680ms
-48dB~'-6dB
1~20.0
32Hz~2.0kHz
-12dB~+12dB
0~127
0~127
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
0~127
1.0kHz~20.0kHz
D63>W ~ D=W ~ D<W63
Attack
Release
Thrshld
Ratio
L.Freq
L.Gain
Drive
OutLvl
M.Freq
M.Gain
M.Width
Edge
LPF
Dry/Wet
12
13
14
15
2
3
1
5
7
8
9
11
4
10
9
10
11
12
13
14
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[58] V-DISTORTION
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Over Drive
Device
Speaker Type
Presence
Delay Time L
Delay Time R
Feedback Time
Feedback Level
Feedback High Damp
Output Level
Delay Mix
Dry/Wet Balance
0 ~ 100%
Transister, Vintage Tube,Dsitortion1, Dsitortion2, Fuzz
Flat, Stack, Combo, Twin, Radio, Megaphone
-10 ~ 10
0.1ms~1486.0ms
0.1ms~1486.0ms
0.1ms~1486.0ms
-63~+63
0.1~1.0
0 ~ 100%
0 ~ 127
D63>W ~ D=W ~ D<W63
OverDr
Device
Speaker
Presenc
DelayL
DelayR
FBTime
FBLevel
FBHiDmp
DistLvl
DlyMix
Dry/Wet
1
2
3
4
6
7
8
9
12
5
11
10
9
10
11
12
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[62] OVERDRIVE+DELAY
No. Parameter Value LCD
1
2
3
4
5
6
7
8
Dist. Drive
Dist. EQ Low Gain
Dist. EQ Mid Gain
Dist Output Level
Delay Time L
Delay Time R
Delay Feedback Time
Delay Feedback Leve
Delay mix
Dry / Wet Balance
0~127
-12dB~+12dB
-12dB~+2dB
0~127
0.1ms~1486.0ms
0.1ms~1486.0ms
0.1ms~1486.0ms
-63~+63
0~127
D63>W ~ D=W ~ D<W63
Drive
EQ-Low
EQ-Mid
DrivOut
DelayL
DelayR
FBTime
FBLevel
DlyMix
Dry/Wet
9
10
[61] DIST+DELAY
MIDI Parameter Number
Controller
6
8
9
7
1
2
3
4
5
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[63] COMPRESSOR1
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
Attack
Release
Threshold
Ratio
Output Level
1ms~40ms
10ms~680ms
-48dB~'-6dB
1~20.0
0~127
Attack
Release
Thrshld
Ratio
OutLvl
1
2
3
4
5
Ø
Ø
Ø
Ø
Ø
[64] NOISE GATE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
Attack
Release
Threshold
Output Level
1ms~40ms
10ms~680ms
-72dB~'-30dB
0~127
Attack
Release
Thrshld
OutLvl
1
2
3
4
Ø
Ø
Ø
Ø
[66] COMP+ODRV+DELAY
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Comp. Attack
Comp. Release
Comp. Threshold
Comp. Ratio
Dist. Drive
Dist. EQ Low Gain
Dist. EQ Mid Gain
Dist Output Level
Delay Time
Delay Feedback Level
Delay Mix
Dry / Wet Balance
1ms~40ms
10ms~680ms
-48dB~-6dB
1~20.0
0~127
-12dB~+12dB
-12dB~+12dB
0~127
0.1ms~1486.0ms
-63~+63
0~127
D63>W ~ D=W ~ D<W63
Attack
Release
Thrshld
Ratio
Drive
EQ-Low
EQ-Mid
DrivOut
DlyTime
FBLevel
DlyMix
Dry/Wet
11
12
13
14
4
6
7
5
1
2
3
10
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
11
12
[65] COMP+DIST+DELAY
[68] PITCH CHANGE2
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Pitch
Initial Delay
Feedback Level
Dry / Wet Balance
Fine1
Fine2
Pan1
Output Level1
Pan2
Output Level2
-24~+24
0.1ms~248.9ms
-63~+63
D63>W ~ D=W ~ D<W63
-50~+50
-50~+50
L63~C~R63
0~127
L63~C~R63
0~127
Pitch
InitDly
FBLevel
Dry/Wet
Fine1
Fine2
Pan1
OutLvl1
Pan2
OutLvl2
1
2
5
10
3
4
11
12
13
14
9
10
Ø
Ø
Ø
Ø
Ø
Ø
[67] PITCH CHANGE1
In [68] PITCH CHANGE 2, l'unità di Fine 1 e Fine 2
(numeri 5 e 6) è il centesimo.
[69] AUTO WAH
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
Cutoff Frequency Offset
Resonance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
0~127
1~12.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
D63>W ~ D=W ~ D<W63
Speed
Depth
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Dry/Wet
1
2
3
4
6
7
8
9
10
9
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[60] AMP SIMULATOR
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
AMP Type
Drive
Edge
Output Level
LPF Cutoff Frequency
Dry / Wet Balance
off, stack, combo, tube
0~127
0~127
0~127
1.0kHz~20.0kHz
D63>W ~ D=W ~ D<W63
AmpType
Drive
Edge
OutLvl
LPF
Dry/Wet
2
1
11
4
3
10
Ø
Ø
Ø
Ø
Ø
23
[71] AUTO WAH + OVERDRIVE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
LFO Frequency
LFO Depth
Cutoff Frequency Offset
Resonance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dist Low Gain
Dist Mid Gain
LPF Cutoff Frequency
Drive
Output Level
Dry / Wet Balance
0.0Hz~39.70Hz
0~127
0~127
1~12.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
-12dB~+12dB
-12dB~+12dB
1.0kHz~20.0kHz
0~127
0~127
D63>W ~ D=W ~ D<W63
Speed
Depth
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Drive:EQ-Low
Drive:EQ-Mid
LPF
Drive
DrivOut
Dry/Wet
1
2
3
4
6
7
8
9
12
13
14
11
15
10
9
10
11
12
13
14
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[70] AUTO WAH + DIST
[72] TOUCH WAH
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
Sensitive
Cutoff Frequency Offset
Resonance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dry / Wet Balance
0~127
0~127
1~12.0
32Hz~12.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
D63>W ~ D=W ~ D<W63
Sens
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Dry/Wet
1
2
3
6
7
8
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
6
7
8
[74] TOUCH WAH + OVERDRIVE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Sensitive
Cutoff Frequency Offset
Resonance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
Dist Low Gain
Dist Mid Gain
LPF Cutoff Frequency
Drive
Output Level
Dry / Wet Balance
0~127
0~127
1~12.0
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
-12dB~+12dB
-12dB~+12dB
1.0kHz~20.0kHz
0~127
0~127
D63>W ~ D=W ~ D<W63
Sens
Cutoff
Reso
L.Freq
L.Gain
H.Freq
H.Gain
Drive:EQ-Low
Drive:EQ-Mid
LPF
Drive
DrivOut
Dry/Wet
1
2
3
6
7
8
9
12
13
14
11
15
10
9
10
11
12
13
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[73] TOUCH WAH + DIST
[76] WAH + OVERDRIVE + DELAY
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Wah sensitive
Wah Cutoff Frequency
Wah Resonance
Wah release
Dist. Drive
Dist. EQ Low Gain
Dist. EQ Mid Gain
Dist Output Level
Delay Time
Delay Feedback Leve
Delay mix
Dry / Wet Balance
0~127
0~127
1~12.0
10ms~680ms
0~127
-12dB~+12dB
-12dB~+12dB
0 ~127
0.1ms~1486.0ms
-63~+63
0~127
D63>W ~ D=W ~ D<W63
WahSens
Cutoff
Reso
Release
Drive
EQ-Low
EQ-Mid
DrivOut
Delay
FBLevel
DlyMix
Dry/Wet
11
12
13
14
4
6
7
5
1
2
3
10
9
10
11
12
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[75] WAH + DIST + DELAY
[77] LO-FI
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Sampling Freq. Control
Word Length
Output Gain
Filter Type
Pre-LPF Cutoff Frequency
Pre-LPF Resonance
Bit Assign
Emphasis
Input Mode
Dry / Wet Balance
44.1KHz~344Hz
1~127
-6dB~+36dB
thru, PowerBass, Radio, Telephone, Clean, Low
63Hz~20.0kHz
1~12.0
0~6
off/on
mono/stereo
D63>W ~ D=W ~ D<W63
SmplFrq
WordLen
OutGain
FltType
Cutoff
Reso
BitAsgn
Emphasi
Input
Dry/Wet
1
2
3
5
4
6
7
8
15
10
Ø
Ø
Ø
Ø
Ø
Ø
10
9
[78] LOW RESOLUTION
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
Mod Depth
Mod Delay Offset
Mod Mix Balance
Resolution
Mod Feedback
Phase Inverse R
Dry/Wet Balance
0~127
1~127
0~127
1,1/2~1/128
-63~+63
off, wet, wet+dry
D63>W ~ D=W ~ D<W63
ModDpth
ModDly
ModMix
Resoltn
ModFB
PhasInv
Dry/Wet
1
2
5
4
3
6
7
Ø
Ø
Ø
Ø
[79] NOISY
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Mod Depth
Mod Speed
Mod Feedback
Mod Mix Balance
Drive
AM Speed
AM Depth
LPF Frequency
LPF Resonance
EQ Frequency
EQ Gain
EQ Width
Dry/Wet Balance
0~10
0~127
-63~+63
1~127
0~127
0.00Hz~39.7Hz
0~127
1.0kHz~20.0kHz
1.0~12.0
100Hz~10.0kHz
-12~+12dB
1.0~12.0
D63>W ~ D=W ~ D<W63
ModDpth
ModSpd
ModFB
ModMix
Drive
AMSpeed
AMDepth
Cutoff
Reso
EQFreq
EQGain
EQWidth
Dry/Wet
2
3
4
7
1
5
6
8
9
10
11
12
13
9
10
11
12
13
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[80] ATTACK LOFI
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Sensitive
Resolution
Peak Frequency
LPF Frequency
Flanger Speed
Flanger LFO Wave
Flanger Depth
Fln Depth Ofst R
Flanger Delay
Fln Delay Ofst R
Flanger Feedback
Flanger FB Ofst R
Flanger FB HiDamp
FB HiDamp Ofst R
Fln Mix Balance
Dry/Wet Balance
0~127
1,1/2~1/32
100Hz~10.0kHz
1.0kHz~20.0kHz
0.00Hz~39.7Hz
tri, sine, saw up, saw down
0~127
-63~+63
0.1~650.0ms
0~884
-63~+63
-63~+63
0.1~1.0
-0.9~+0.9
1~127
D63>W ~ D=W ~ D<W63
Sens
Resoltn
PeakFrq
LPF
FlgSpd
FlgWave
FlgDpt
FlgDptR
FlgDly
FlgDlyR
Flg FB
FlgFB R
FBHiDmp
FBHiDmR
FlgMix
Dry/Wet
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
9
10
11
12
13
14
15
16
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
[81] DIGITAL TURNTABLE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
Click Density
Click Level
Noise Tone
Dry Send to Noise
Noise Mod Speed
Noise Mod Depth
Noise LPF Freq
Noise LPF Q
Noise Level
Dry LPF Frequency
Dry Level
0~5
0~127
0~6
0~127
0.00Hz~39.7Hz
0~127
1.0kHz~20.0kHz
1.0~12.0
0~127
1.0kHz~20.0kHz
0~127
Density
Click
NoisTon
DryNois
ModSpd
ModDpth
NoisLPF
NoiseQ
NoisLvl
DryLPF
DryLvl
1
2
3
6
4
5
7
8
9
10
11
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
7
8
9
10
11
[82] DIGITAL SCRATCH
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Input Level
Initial Delay
Scratch Speed
Scratch Depth
HPF Frequency
Auto Pan Speed
Auto Pan Depth
EQ Frequency
EQ Gain
EQ Width
Dry/Wet Balance
0~127
0.1~460.0ms
1~127
0~127
20Hz~8.0kHz
0.00Hz~39.7Hz
0~127
100Hz~10.0kHz
-12~+12dB
1.0~12.0
D63>W ~ D=W ~ D<W63
Input
Delay
ScrSpd
ScrDpth
HPF
PanSpd
PanDpth
EQFreq
EQGain
EQWidth
Dry/Wet
1
2
3
4
10
5
6
7
8
9
11
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
11
24
[83] AUTO SYNTH
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Mod Speed
Mod Wave Type
Mod Depth
Mod Depth Ofst R
HPF Frequency
LPF Frequency
Dry Mix Level
Delay Level
Delay Time
Delay Time Ofst R
Feedback Level
FB Level Ofst R
AM Speed
AM Wave
AM Depth
AM Inverse R
0~127
TypeA, TypeB, TypeC, TypeD
0~127
-63~+63
20Hz~8.0kHz
1.0kHz~20.0kHz
0~127
0~127
0.1~370.0ms
0~884
-63~+63
-63~+63
0.00Hz~39.7Hz
tri, sine, saw up, saw down
0~127
normal, inverse
ModSpd
ModWave
ModDpth
ModDpth-R Ofst
HPF
LPF
DryMix
DlyLvl
Delay
Delay-R Ofst
FBLevel
FBLevel-R Ofst
AMSpeed
AM Wave
AMDepth
AM InvR
1
2
3
4
6
5
7
12
8
9
10
11
13
14
15
16
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
11
12
13
14
15
16
[84] TECH MODULATION
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Mod Speed
Mod Depth
Mod Gain
Mod Mix Balance
Pre Mod HPF Freq
Mod LPF Frequency
Mod LPF Resonance
Delay Time
Delay Time Ofst R
Feedback Level
FB Level Ofst R
Feedback Hi Damp
FB Hi Damp Ofst R
Dry/Wet Balance
0~127
0~127
-12~+12dB
D63>W ~ D=W ~ D<W63
20Hz~8.0kHz
1.0kHz~20.0kHz
1.0~12.0
0.1~740.0ms
0~884
-63~+63
-63~+63
0.1~1.0
-0.9~+0.9
D63>W ~ D=W ~ D<W63
Speed
Depth
Gain
ModMix
HPF
LPF:Cutoff
LPF:Reso
Delay
Delay-R Ofst
FBLevel
FBLevel-R Ofst
FBHiDmp
FBHiDmp-R Ofst
Dry/Wet
1
2
4
7
3
5
6
8
9
10
11
12
13
14
9
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
1
11
12
13
14
[85] JUMP
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
8
Depth
Speed
Direction
Type
Jump Wave Type
Resolution
HPF Frequency
LPF Frequency
Dry/Wet Balance
0~127
0~127
L<>R,L>>R
TypeA,TypeB,TypeC
TypeA, TypeB, TypeC, TypeD
1,1/2~1/256
20Hz~8.0kHz
1.0kHz~20.0kHz
D63>W ~ D=W ~ D<W63
Depth
Speed
Directn
Type
JumpWave
Resolution
HPF
LPF
Dry/Wet
1
2
3
4
5
6
8
7
9
9
Ø
Ø
Ø
Ø
Ø
[86] 2BAND EQ
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
L.Freq
L.Gain
H.Freq
H.Gain
1
2
3
4
Ø
Ø
Ø
Ø
1
[87] 3BAND EQ
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
EQ Mid Frequency
EQ Mid Gain
EQ Mid Width
Input Mode
50Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
100Hz~10.0kHz
-12dB~+12dB
0.1~12.0
mono/stereo
L.Freq
L.Gain
H.Freq
H.Gain
M.Freq
M.Gain
M.Width
Input
6
1
7
5
2
3
4
15
Ø
Ø
Ø
Ø
Ø
Ø
Ø
5
6
7
8
[88] HARMONIC ENHANCER
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
HPF Cutoff Frequency
Drive
Mix Level
500Hz~16.0kHz
0~127
0~127
HPF
Drive
MixLvl
1
2
3
Ø
Ø
Ø
[89] VOICE CANCELAR
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
Low Adjust
High Adjust
0~26
0~26
LowAdj
HighAdj
11
12
Ø
Ø
[90] AMBIENCE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
6
7
Delay Time
Wet Output Phase
Dry / Wet Balance
EQ Low Frequency
EQ Low Gain
EQ High Frequency
EQ High Gain
0.0ms~50.0ms
normal/inverse
D63>W ~ D=W~ D<W63
32Hz~2.0kHz
-12dB~+12dB
500Hz~16.0kHz
-12dB~+12dB
DlyTime
WetPhase
Dry/Wet
L.Freq
L.Gain
H.Freq
H.Gain
1
2
10
6
7
8
9
Ø
Ø
Ø
Ø
Ø
Ø
[91] TALKING MODULATOR
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
Vowel
Move Speed
Drive
Output Level
a/i/u/e/o
1~ 62
0~127
0~127
Vowel
Speed
Drive
OutLvl
1
2
3
4
Ø
Ø
Ø
Ø
[92] BEAT CHANGE
No. Parameter Value LCD
MIDI Parameter Number
Controller
1
2
3
4
5
Beat Change
Beat Range
Pitch Change
Pitch Range
EQ Frequency
EQ Gain
EQ Width
Accuracy Type
Dry/Wet Balance
-63~+63
0~12
-63~+63
0~12
32Hz~2.0kHz
-12dB~+12dB
1.0~12.0
sound4~normal~rythm4
D63>W ~ D=W ~ D<W63
BeatChg
BeatRng
PchChg
PchRng
EQFreq
EQGain
EQWidth
AccType
Dry/Wet
1
2
3
4
6
7
8
5
10
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
9
6
7
8
25
A proposito di MIDI
MIDI è l’acronimo di Musical Instrument Digital Interface, che consente agli
strumenti musicali elettronici di “comunicare” fra loro, mediante l’invio e la
ricezione di dati compatibili di Note, Control Change, Program Change e vari
altri tipi di dati MIDI, o messaggi.
L’S30 può controllare un dispositivo MIDI trasmettendo i dati relativi alle note
e vari tipi di dati del controller. L’S30 può essere controllato dai messaggi MIDI
in arrivo che selezionano automaticamente i canali MIDI, le voci e gli effetti, i
valori di cambio parametro, e naturalmente suonano le voci specificate per le
varie Parti in una Performance.
Messaggi MIDI trasmessi/ricevuti dall’S30
I messaggi MIDI possono essere divisi in due gruppi: i messaggi di canale (Channel Messages)
e i messaggi di sistema (System Messages). Qui di seguito troverete una breve spiegazione dei
vari tipi di messaggi MIDI che l’S30 può ricevere/trasmettere.
CHANNEL MESSAGES
I Channel Messages sono i dati relativi alla performance sulla tastiera per il canale specifico.
•Note On/Note Off (Key On/Key Off)
Messaggi generati quando viene suonata la tastiera. Ciascun messaggio include uno
specifico numero di nota che corrisponde al tasto premuto, oltre a un valore di velocity
basato sulla pressione esercitata sul tasto.
•Control Change
I messaggi di Control Change vi consentono di selezionare una voice bank (Bank Select),
control volume, panning, modulation, portamento time, brightness e vari altri parametri del
controller, attraverso numeri specifici di Control Change che corrispondono a ciascuno dei
vari parametri.
•Program Change
Messaggi che indicano quale voce selezionare per ciascuna Part.
Con una combinazione di Bank Select, potete selezionare non solo i numeri di voice base,
ma anche i numeri di voice bank variation.
•Channel Aftertouch
Messaggi che vi consentono di controllare i suoni mediante la forza applicata ai tasti dopo
la pressione iniziale degli stessi, sull’intero canale.
•Polyphonic Key Pressure
Messaggi che vi consentono di controllare i suoni mediante la forza applicata ai tasti dopo
la pressione iniziale degli stessi, per ciascun tasto individuale. Il sequencer interno (S30)
può inviare questo messaggio.
•Pitch Bend
I messaggi di Pitch Bend sono messaggi continui del controller che consentono al pitch
delle note designate di essere innalzato o abbassato di un’entità specificata per una
durata specificata.
SYSTEM MESSAGES
I System Messages sono i dati relativi al sistema generale del dispositivo.
•Exclusive Messages
I messaggi esclusivi controllano varie funzioni dell’S30, compresi bulk dump, master
volume e master tuning, effect type e diversi altri parametri.
•Realtime Messages
Messaggi che controllano il sequencer compresi i messaggi di Start, Stop, Continue, MIDI
clock e Active Sensing.
•Common Messages
Messaggi che controllano anch’essi il sequencer compresi i messaggi di Song Select e
Song Position Pointer.
Formato dei dati MIDI
Molti messaggi MIDI elencati nella sezione Formato dei dati MIDI sono espressi come numeri
esadecimali o binari. I numeri esadecimali potrebbero includere la lettera “H” come suffisso. La
lettera “n” indica un certo numero intero.
La tabella sottostante elenca il numero decimale corrispondente per ciascun numero
esadecimale/binario.
Note aggiuntive
•Per esempio, 144 - 159(Decimal)/9nH/1001 0000 - 1001 1111(Binary) indicano i messaggi di
note-on rispettivamente per i canali da 1 a 16. 176 - 191/BnH/1011 0000 - 1011 1111 indicano
i messaggi di control change rispettivamente per i canali da 1 a 16. 192 - 207/CnH/1100 0000
- 1100 1111 indicano i messaggi di program change rispettivamente per i canali da 1 a 16.
240/F0H/1111 0000 è posizionato all’inizio dei dati per indicare un messaggio system
exclusive. 247/F7H/1111 0111 è posizionato alla fine del messaggio system exclusive.
•aaH(Hexadecimal)/0aaaaaaa(Binary) indica gli indirizzi dei dati. L’indirizzo dei dati è costituito
da High, Mid e Low.
• bbH/0bbbbbbb indica i byte counts.
• ccH/0ccccccc indica le tcheck sums.
• ddH/0ddddddd indica i data/value.
Decimal Hexadecimal Binary Decimal Hexadecimal Binary
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A
1B
1C
1D
1E
1F
20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F
0000 0000
0000 0001
0000 0010
0000 0011
0000 0100
0000 0101
0000 0110
0000 0111
0000 1000
0000 1001
0000 1010
0000 1011
0000 1100
0000 1101
0000 1110
0000 1111
0001 0000
0001 0001
0001 0010
0001 0011
0001 0100
0001 0101
0001 0110
0001 0111
0001 1000
0001 1001
0001 1010
0001 1011
0001 1100
0001 1101
0001 1110
0001 1111
0010 0000
0010 0001
0010 0010
0010 0011
0010 0100
0010 0101
0010 0110
0010 0111
0010 1000
0010 1001
0010 1010
0010 1011
0010 1100
0010 1101
0010 1110
0010 1111
0011 0000
0011 0001
0011 0010
0011 0011
0011 0100
0011 0101
0011 0110
0011 0111
0011 1000
0011 1001
0011 1010
0011 1011
0011 1100
0011 1101
0011 1110
0011 1111
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
40
41
42
43
44
45
46
47
48
49
4A
4B
4C
4D
4E
4F
50
51
52
53
54
55
56
57
58
59
5A
5B
5C
5D
5E
5F
60
61
62
63
64
65
66
67
68
69
6A
6B
6C
6D
6E
6F
70
71
72
73
74
75
76
77
78
79
7A
7B
7C
7D
7E
7F
0100 0000
0100 0001
0100 0010
0100 0011
0100 0100
0100 0101
0100 0110
0100 0111
0100 1000
0100 1001
0100 1010
0100 1011
0100 1100
0100 1101
0100 1110
0100 1111
0101 0000
0101 0001
0101 0010
0101 0011
0101 0100
0101 0101
0101 0110
0101 0111
0101 1000
0101 1001
0101 1010
0101 1011
0101 1100
0101 1101
0101 1110
0101 1111
0110 0000
0110 0001
0110 0010
0110 0011
0110 0100
0110 0101
0110 0110
0110 0111
0110 1000
0110 1001
0110 1010
0110 1011
0110 1100
0110 1101
0110 1110
0110 1111
0111 0000
0111 0001
0111 0010
0111 0011
0111 0100
0111 0101
0111 0110
0111 0111
0111 1000
0111 1001
0111 1010
0111 1011
0111 1100
0111 1101
0111 1110
0111 1111
26
SYNTHESIZER/SEQUENCER PART
1) TRANSMIT FLOW
MIDI <-[SW1]-+--- NOTE ON/OFF 9nH
OUT | |
| +--- CONTROL CHANGE
| +-[SW8]--BANK SEL MSB BnH,00H
| | BANK SEL LSB BnH,20H
| | MODULATION BnH,01H
| | ASSIGNABLE CONTROLLER BnH,(00H .. 5FH)
| |
| |
| |
| +--- PROGRAM CHANGE CnH
| |
| +--- CHANNEL AFTER TOUCH DnH
| |
| +--- PITCH BEND CHANGE EnH
|
|-[SW3,4]--SYSTEM REALTIME MESSAGE
| TIMING CLOCK F8H
|
|-[SW4]---- SYSTEM REALTIME MESSAGE
| START FAH
| CONTINUE FBH
| STOP FCH
|
|
+[SW5]-+---
SYSTEM EXCLUSIVE MESSAGE
| |
||-[SW7]-<BULK DUMP>
F0H 43H 0nH 64H bhH blH ahH amH alH ddH....ddH ccH F7H
| |
||-[SW7]-
<PARAMETER CHANGE>
F0H 43H 1nH 64H ahH amH alH ddH.....ddH F7H
|
|----------
SYSTEM EXCLUSIVE MESSAGE
|IDENTITY REPLY
F0H 7EH 7FH 06H 02H 43H 00H 41H ddH ddH 00H 00H 00H 7FH F7H
|
|---------- ACTIVE SENSING FEH
[SW1] MIDI Transmit Channel
Master Keyboard Mode = on: conforme a Zone Transmit Channel.
Master Keyboard Mode = off: conforme a Keyboard Transmit Channel.
I dati eseguiti usando Sequencer Part verranno emessi attraverso i canali impostati per
i dati di sequence, ignorando le impostazioni [SW1].
[SW3] MIDI Sync
[SW4] MIDI Control
[SW5] MIDI Device Number
Quando è impostato su all, i dati verranno emessi attraverso il canale 1.
[SW7] Nel VOICE MODE, soltanto i dati relativi a VOICE. Nel PERFORMANCE MODE, soltanto i dati
relativi a PERFORMANCE.
I dati SYSTEM verranno trasmessi/ricevuti in tutti i modi.
[SW8] SYSTEM Bank Select Switch
2) RECEIVE FLOW
MIDI >-[SW11]+--- NOTE OFF 8nH
| |
| +--- NOTE ON/OFF 9nH
| |
| +--- CONTROL CHANGE
| | MODULATION BnH,01H
| | PORTAMENTO TIME BnH,05H
| | DATA ENTRY MSB BnH,06
| | DATA ENTRY LSB BnH,26H
| | MAIN VOLUME BnH,07H
| | PAN BnH,0AH
| | EXPRESSION BnH,0BH
| | SUSTAIN SWITCH BnH,40H
| | PORTAMENTO SWITCH BnH,41H
| | SOSTENUTO BnH,42H
| | HARMONIC CONTENT BnH,47H
| | EG RELEASE TIME BnH,48H
| | EG ATTACK TIME BnH,49H
| | BRIGHTNESS BnH,4AH
| | EG DECAY TIME BnH,4BH
| | EFFECT1 DEPTH BnH,5BH
| | EFFECT3 DEPTH BnH,5DH
| | DATA ENTRY INC BnH,60H
| | DATA ENTRY DEC BnH,61H
| | ASSIGNABLE CONTROLLER BnH,(00H .. 5FH)
| | RPN
| | PITCH BEND SENS BnH,64H,00H,65H,00H,06H,mmH
| | FINE TUNING BnH,64H,01H,65H,00H,06H,mmH,26H,llH *1
| | COARSE TUNING BnH,64H,02H,65H,00H,06H,mmH *1
| | RPN RESET BnH,64H,7FH,65H,7FH
| | ALL SOUND OFF BnH,78H
| | RESET ALL CONTROLLERS BnH,79H
| | ALL NOTE OFF BnH,7BH
| | OMNI MODE OFF BnH,7CH
| | OMNI MODE ON BnH,7DH
| | MONO MODE BnH,7EH
| | POLY MODE BnH,7FH
| |
| |
| +-[SW8]--BANK SEL MSB BnH,00H
| | BANK SEL LSB BnH,20H
| |
| +-[SW9]--PROGRAM CHANGE CnH
| |
| +--------
CHANNEL AFTER TOUCH
DnH
| |
|+--------PITCH BEND CHANGE EnH
|
|
+------+ SYSTEM EXCLUSIVE MESSAGE
| | IDENTITY REQUEST F0H 7EH 0nH 06H 01H F7H
| | REMOTE SWITCH F0H 43H 10H 64H 0AH 00H alH ddH F7H
| |
| +-[SW12]- GM MODE ON F0H 7EH 7FH 09H 01H F7H
|
+[SW5]-
+ SYSTEM EXCLUSIVE MESSAGE
| | MIDI MASTER VOLUME F0H 7FH 7FH 04H 01H llH mmH F7H
| |
| |
| +-[SW10]-<BULK DUMP>
F0H 43H 0nH 64H bhH blH ahH amH alH ddH....ddH ccH F7H
| |
|+-[SW7]--<PARAMETER CHANGE> F0H 43H 1nH 64H ahH amH alH ddH.....ddH F7H
| |
| +-[SW7]--
<BULK DUMP REQUEST>
F0H 43H 2nH 64H ahH amH alH ddH.....ddH F7H
| |
| +-[SW7]--
<PARAMETER REQUEST>
F0H 43H 3nH 64H ahH amH alH F7H
| |
| +-[SW12]-XG SYSTEM ON F0H 43H 1nH 4CH 00H 00H 7EH 00H F7H
|
+[SW3]--------- SYSTEM REALTIME MESSAGE
| TIMING CLOCK F8H
|
+[SW4]--------- SYSTEM REALTIME MESSAGE
| START FAH
| CONTINUE FBH
| STOP FCH
|
|
+-------------- ACTIVE SENSING FEH
[SW3] MIDI Sync
[SW4] MIDI Control
[SW5] MIDI Device Number
Quando è impostato su un numero diverso da off, verrà ricevuto MIDI MASTER VOLUME.
[SW7] Nel VOICE MODE, soltanto i dati relativi a VOICE. Nel PERFORMANCE MODE, soltanto i dati
relativi a PERFORMANCE.
I dati SYSTEM verranno trasmessi/ricevuti in tutti i modi.
[SW8] SYSTEM Bank Select Switch
[SW9] SYSTEM Program Change Switch (Ricevuto soltanto nel modo Play quando è selezionato Voice
Mode.)
[SW10] SYSTEM Bulk Protect e le condizioni esposte nel precedente SW7.
[SW11] MIDI Receive Channel e Receive Filter.
Nel modo Performance, è conforme a Part Receive Channel e Part Receive Switch.
Nei modi diversi da Performance Mode, è conforme a Basic Receive Channel.
[SW12] SYSTEM Receive GM/XG On
*1 Solo Performance Mode.
27
3) TRANSMIT/RECEIVE DATA
(3-1) CHANNEL VOICE MESSAGES
(3-1-1) NOTE OFF
STATUS 1000nnnn(8nH) n = 0 ~ 15 CHANNEL NUMBER
NOTE NUMBER 0kkkkkkk k = 0 (C-2) ~ 127 (G8)
VELOCITY 0vvvvvvv ignora "v"
Receive only.
(3-1-2) NOTE ON/OFF
STATUS 1001nnnn(9nH) n = 0 ~ 15 CHANNEL NUMBER
NOTE NUMBER 0kkkkkkk k = 0 (C-2) ~ 127 (G8)
VELOCITY 0vvvvvvv(v≠0) NOTE ON
0vvvvvvv(v=0) NOTE OFF
(3-1-3) CONTROL CHANGE
STATUS 1011nnnn(BnH) n = 0 ~ 15 CHANNEL NUMBER
CONTROL NUMBER 0ccccccc
CONTROL VALUE 0vvvvvvv
* TRANSMITTED CONTROL NUMBER
c = 0 BANK SEL MSB ; v = 0,63,127 *3
c = 32 BANK SEL LSB ; v = 0,1,8,9,24,25,32,40,41,64,65 *3
c = 1 MODULATION ; v = 0 - 127
c = 0..95 ASSIGNABLE CONTROLLER ; v = 0 - 127 *6
La Sequencer Part eseguirà tutti i messaggi di control change registrati.
* RECEIVED CONTROL NUMBER
c = 0 BANK SEL MSB ; v = 0 - 127 *3
c = 32 BANK SEL LSB ; v = 0 - 127 *3
c = 1 MODULATION ; v = 0 - 127
c = 5 PORTAMENTO TIME ; v = 0 - 127 *2
c = 6 DATA ENTRY MSB ; v = 0 - 127 *1
c = 38 DATA ENTRY LSB ; v = 0 - 127 *1
c = 7 MAIN VOLUME ; v = 0 - 127
c = 10 PAN ; v = 0 - 127
c = 11 EXPRESSION ; v = 0 - 127
c = 31 EG SUSTAIN LEVEL ; v = 0:-64 - 64:0 - 127:+63 *2,*5
c = 64 SUSTAIN SWITCH ; v = 0-63:OFF , 64-127:ON *2
c = 65 PORTAMENTO SWITCH ; v = 0-63:OFF , 64-127:ON *2
c = 66 SOSTENUTO ; v = 0-63:OFF , 64-127:ON *2
c = 71 HARMONIC CONTENT ; v = 0:-64 - 64:0 - 127:+63
c = 72 EG RELEASE TIME ; v = 0:-64 - 64:0 - 127:+63 *2
c = 73 EG ATTACK TIME ; v = 0:-64 - 64:0 - 127:+63
c = 74 BRIGHTNESS ; v = 0:-64 - 64:0 - 127:+63
c = 75 EG DECAY TIME ; v = 0:-64 - 64:0 - 127:+63
c = 91 EFFECT1 DEPTH ; v = 0 - 127
c = 93 EFFECT3 DEPTH ; v = 0 - 127
c = 96 DATA ENTRY INC ; v = 127 *1
c = 97 DATA ENTRY DEC ; v = 127 *1
c = 0..95 ASSIGNABLE CONTROLLER ; v = 0 - 127 *6
c = 0..95 ARPEGGIO SW ; v = 0-63:OFF , 64-127:ON *6
c = 0..95 ARPEGGIO HOLD ; v = 0-63:OFF , 64-127:ON *6
*1 Usato soltanto quando un valore viene impostato usando RPN.
*2 Non valido con le Drum Voices.
*3 La relazione tra BANK CHANGE e PROGRAM è la seguente:
CATEGORY |MSB |LSB |PROGRAM No
Visualizzato su LCD
----------------------------------+--------+--------+---------------------------
Normal Voice Internal |0 |0 |0..127 (1..128)
Drum Voice Internal |127 |0 |0..1 (1..2)
Normal Voice Preset 1 |63 |0 |0..127 (1..128)
Preset 2 |63 |1 |0..127 (1..128)
Internal |63 |8 |0..127 (1..128)
External |63 |9 |0..127 (1..128)
Plug-in Voice Plug-in |63 |25 |0..63 (1..64)
Drum Voice Preset |63 |32 |0..7 (1..8)
Internal |63 |40 |0..1 (1..2)
External |63 |41 |0..1 (1..2)
Performance Internal |63 |64 |0..127 (1..128)
External |63 |65 |0..63 (1..64)
*5 Trasmesso/ricevuto soltanto quando nel CONTROL CHANGE MODE è selezionato MODE2.
*6 I CONTROL NUMBER di default di ASSIGNABLE CONTROLLER sono i seguenti:
FOOT CONTROLLER 11
KNOB 1 16
KNOB 2 17
KNOB A 18
KNOB B 19
KNOB C 20
RIBBON CONTROLLER 22 (Solo ricezione)
CONTROL SLIDER 7
FOOT SWITCH 64
ARPEGGIO HOLD 89 (Solo ricezione)
ARPEGGIO SWITCH 90 (Solo ricezione)
PORTAMENTO TIME imposta il tempo impiegato dal pitch per raggiungere la nota successiva
suonata quando PORTAMENTO SWITCH è impostato su on.
La posizione di PAN cambia di conseguenza in base al valore preset per ciascuna voce.
EFFECT1 DEPTH controlla il reverb send level.
EFFECT3 DEPTH controlla il chorus send level.
HARMONIC CONTENT regola la resonance preset per ciascuna voce.
Impostando un valore lo si aggiunge o lo si sottrae dal valore centrale, 64, dal momento
che è un parametro di offset.
Più grande è il valore più risonante sarà il suono prodotto. La gamma effettiva potrebbe
essere più ristretta della gamma che potete designare in base alla voce selezionata.
I parametri EG ATTACK TIME, EG DECAY TIME, EG SUSTAIN LEVEL, EG RELEASE TIME regolano
gli inviluppi presettati per ciascuna voce.
Impostando questi valori li si aggiungono o li si sottraggono dal valore centrale, 64,
dal momento che questi sono parametri di offset.
BRIGHTNESS regola la frequenza di cutoff presettata per ciascuna voce.
Impostando un valore lo si aggiunge o lo si sottrae dal valore centrale, 64, dal momento
che è un parametro di offset.
Più piccolo è il valore e più verrà abbassata la frequenza di cutoff. La gamma effettiva
potrebbe essere più ristretta della gamma che potete designare in base alla voce
selezionata.
Bank Select verrà eseguita effettivamente al ricevimento del messaggio di Program Change.
I numeri di Bank Select e Program Change non supportati dalla Yamaha verranno ignorati.
(3-1-4) PROGRAM CHANGE
STATUS 1100nnnn(CnH) n = 0 ~ 15 CHANNEL NUMBER
PROGRAM NUMBER 0ppppppp p = 0 ~ 127
(3-1-5) CHANNEL AFTER TOUCH
STATUS 1101nnnn(DnH) n = 0 ~ 15 CHANNEL NUMBER
VALUE 0vvvvvvv v = 0 ~ 127 AFTER TOUCH VALUE
(3-1-6) PITCH BEND CHANGE
STATUS 1110nnnn(EnH) n = 0 ~ 15 CHANNEL NUMBER
LSB 0vvvvvvv PITCH BEND CHANGE LSB
MSB 0vvvvvvv PITCH BEND CHANGE MSB
Trasmesso con una risoluzione di 7 bit.
(3-2) CHANNEL MODE MESSAGES
STATUS 1011nnnn(BnH) n = 0 ~ 15 CHANNEL NUMBER
CONTROL NUMBER 0ccccccc c = CONTROL NUMBER
CONTROL VALUE 0vvvvvvv v = DATA VALUE
(3-2-1) ALL SOUNDS OFF (CONTROL NUMBER = 78H , DATA VALUE = 0)
Tutti i suoni eseguiti correntemente inclusi i messaggi di canale come note-on e hold-
on in un determinato canale vengono esclusi alla ricezione di questo messaggio.
(3-2-2)
RESET ALL CONTROLLERS
(CONTROL NUMBER = 79H , DATA VALUE = 0)
Ripristina i valori impostati per i seguenti controller.
PITCH BEND CHANGE 0 (center)
CHANNEL AFTER TOUCH 0 (minimum)
MODULATION 0 (minimum)
EXPRESSION 127 (maximum)
FOOT CONTROLLER 127 (maximum)
KNOB 1 0 (center)
KNOB 2 0 (center)
SUSTAIN SWITCH 0 (off)
SOSTENUTO SWITCH 0 (off)
RPN Non assegnato; Nessun cambiamento
Non ripristina i seguenti dati:
PROGRAM CHANGE, BANK SELECT MSB/LSB, VOLUME, PAN.
HARMONIC CONTENT, SUSTAIN LEVEL, RELEASE TIME, ATTACK TIME, DECAY TIME, BRIGHTNESS
EFFECT SEND LEVEL 1, EFFECT SEND LEVEL 3, PORTAMENTO SWITCH
PITCH BEND SENSITIVITY, FINE TUNING, COARSE TUNING
ASSIGNABLE CONTROLLER
(3-2-3) ALL NOTES OFF (CONTROL NUMBER = 7BH , DATA VALUE = 0)
Tutte le note correntemente impostate su on in un determinato/i canale/i vengono
escluse al ricevimento di questo messaggio. Tuttavia, se Sustain o Sostenuto sono su
on, le note continueranno a suonare finché questi vengono impostati su off.
(3-2-4) OMNI MODE OFF (CONTROL NUMBER = 7CH , DATA VALUE = 0)
Esegue la stessa funzione come quando riceve ALL NOTES OFF.
Imposta VOICE RECEIVE CHANNEL su "OMNI OFF," channel 1.
(3-2-5) OMNI MODE ON (CONTROL NUMBER = 7DH , DATA VALUE = 0)
Esegue la stessa funzione come quando riceve
ALL NOTES OFF.
Imposta VOICE RECEIVE CHANNEL su "OMNI ON."
(3-2-6) MONO (CONTROL NUMBER = 7EH , DATA VALUE = 0..16)
Esegue la stessa funzione come quando riceve ALL SOUNDS OFF. Se il 3° byte (mono) è
tra 0 e 16, il canale sarà Mode4(m = 1).
Nel VOICE MODE, il modo può essere Mode2(m=1) in base al VOICE RECEIVE CHANNEL.
(3-2-7) POLY (CONTROL NUMBER = 7FH , DATA VALUE = 0)
Esegue la stessa funzione come quando riceve ALL SOUNDS OFF. Il canale sarà Mode3.
Nel VOICE MODE, il modo può essere Mode1 in base a VOICE RECEIVE CHANNEL.
(3-3) REGISTERED PARAMETER NUMBER
STATUS 1011nnnn(BnH) n = 0 ~ 15 CHANNEL NUMBER
LSB 01100100(64H)
RPN LSB 0ppppppp p = RPN LSB(fate riferimento alla tabella
sottostante)
MSB 01100101(65H)
RPN MSB 0qqqqqqq q = RPN MSB(fate riferimento alla tabella
sottostante)
DATA ENTRY MSB 00000110(06H)
DATA VALUE 0mmmmmmm m = Data Value
DATA ENTRY LSB 00100110(26H)
DATA VALUE 0lllllll l = Data Value
Innanzitutto, designate il parametro usando i numeri RPN MSB/LSB. Quindi, impostatene
il valore con l’immissione dei dati MSB/LSB.
RPN D.ENTRY
LSB MSB MSB LSB PARAMETER NAME DATA RANGE
00H 00H mmH --- PITCH BEND SENSITIVITY 00H - 18H (0 - 24 semitoni)
01H 00H mmH llH MASTER FINE TUNE {mmH,llH}={00H,00H}-{40H,00H}-{7FH,7FH}
(-8192*100/8192) - 0 - (+8192*100/8192)
02H 00H mmH --- MASTER COARSE TUNE 28H - 40H - 58H (-24 - 0 - +24 semitoni)
7FH 7FH --- --- RPN RESET I numeri RPN rimarranno non designati.
Non influisce sui valori interni.
(3-4) NON-REGISTERED PARAMETER NUMBER
Non ci sono parametri applicabili.
(3-5) SYSTEM REAL TIME MESSAGES
(3-5-1) ACTIVE SENSING
STATUS 11111110(FEH)
Trasmesso ogni 200 msec.
Una volta ricevuto questo codice, lo strumento inizia la verifica di interscambio dati.
Quando non vengono ricevuti né condizione né dati per oltre 350 ms circa, il buffer di
ricezione MIDI verrà cancellato, e i suoni correntemente eseguiti e l’interruttore
sustain vengono disattivati. In tal caso, ciascun dato di controllo verrà resettato su
un determinato valore.
(3-6) SYSTEM EXCLUSIVE MESSAGE
(3-6-1)UNIVERSAL NON REALTIME MESSAGE
(3-6-1-1)GENERAL MIDI MODE ON
F0H 7EH 7FH 09H 01H F7H
Ricevuto soltanto quando SYSTEM Receive GM/XG on è impostato su on nel PERFORMANCE
MODE. I valori di Part verranno resettati in base all impostazioni di SYSTEM Internal
Part.
(3-6-1-2)IDENTITY REQUEST(Solo ricezione)
F0H 7EH 0nH 06H 01H F7H ("n" = Device No. Tuttavia, questo strumento riceve sotto
"omni.")
(3-6-1-3)IDENTITY REPLY (Solo trasmissione)
F0H 7EH 7FH 06H 02H 43H 00H 41H ddH ddH 00H 00H 00H 7FH F7H
dd;Device Number Code: 23 04
(3-6-2)UNIVERSAL REALTIME MESSAGE
(3-6-2-1) MIDI MASTER VOLUME
F0H 7FH 7FH 04H 01H llH mmH F7H
Imposta il valore di MASTER VOLUME.
Il valore "mm" viene usato per impostare il master volume (il valore "ll" dovrebbe
essere ignorato).
(3-6-3)PARAMETER CHANGE
(3-6-3-1) XG SYSTEM ON
11110000 F0 Exclusive status
1000011 43 YAMAHA ID
0001nnnn 1n device Number
1001100 4C Model ID
0aaaaaaa 0 Address High
0aaaaaaa 0 Address Mid
0aaaaaaa 7E Address Low
0 0 Data
11110111 F7 End of Exclusive
Ricevuto solo quando SYSTEM Receive GM/XG on è impostato su on nel PERFORMANCE MODE.
I valori di Part verranno resettati in base alle impostazioni di SYSTEM Internal Part.
Poiché per l’esecuzione di questo messaggio occorrono circa 170ms, è necessario un
certo intervallo prima di eseguire il messaggio successivo.
(3-6-3-2) NATIVE PARAMETER CHANGE, REMOTE SWITCH
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0001nnnn 1n device Number
01100100 64 Model ID
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
0ddddddd ddddddd Data
| |
11110111 F7 End of Exclusive
Per i parametri con dimensione dati di 2 o più, verrà trasmesso il numero di byte di
dati appropriato.
Vedere la seguente Tabella dei dati MIDI per Address e Byte Count.
Ricevuto sempre a prescindere dal numero di dispositivo selezionato, nel caso di REMOTE
SWITCH.
(3-6-4)BULK DUMP
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0000nnnn 0n device Number
01100100 64 Model ID
0bbbbbbb bbbbbbb Byte Count
0bbbbbbb bbbbbbb Byte Count
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
0 0 Data
| |
0ccccccc ccccccc Check-sum
11110111 F7 End of Exclusive
Vedere la seguente Tabella dei dati MIDI per Address e Byte Count.
La Check sum (somma di controllo) è il valore che produce uno 0 per i 7 bit inferiori
quando vengono aggiunti Byte Count, Start Address, Data e la Check sum stessa.
(3-6-5) DUMP REQUEST
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0010nnnn 2n device Number
01100100 64 Model ID
0aaaaaaa aaaaaaa Address High
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
11110111 F7 End of Exclusive
Vedere la seguente Tabella dei dati MIDI per Address e Byte Count.
(3-6-6) PARAMETER REQUEST
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0011nnnn 3n device Number
01100100 64 Model ID
0aaaaaaa aaaaaaa Address Hig
0aaaaaaa aaaaaaa Address Mid
0aaaaaaa aaaaaaa Address Low
11110111 F7 End of Exclusive
Vedere la seguente Tabella dei dati MIDI per Address e Byte Count.
4) SYSTEM OVERVIEW (Keyboard, Sequencer e Tone Generator)
Sebbene si distinguano tre tipi di dati di note on/note off, ricevuti via MIDI, suonati
dal sequencer interno e sulla tastiera, gli altri controller (messaggi di canale)
influenzano egualmente le note.
ALL SOUNDS OFF cancella tutti i suoni nel/i canale/i specifico/i eseguiti dalla
tastiera e dai dati via MIDI.
ALL NOTES OFF ricevuto via MIDI cancella i suoni nel/i canale/i specifico/i eseguiti
via MIDI.
SEQ KBD
TG
MIDI In
MIDI Out
From Host
To Host
Local Sw
HOST MODE = PC1/PC2/MAC
SEQ KBD
TG
MIDI In
MIDI Out
From Host
To Host
Local Sw
HOST MODE = MIDI
28
29
Tabella dei dati MIDI
Bank Select
Bank Select/Program Change disponibili
MSB (HEX) LSB (HEX) Program No. Type Memory Descrizione
0 00 0 00 0 - 127 Normal Voice Internal
127 7F 0 00 0 - 1 Drum Voice User(Internal)
63 3F 0 00 0 - 127 Normal Voice Preset 1
1 01 0 - 127 Preset 2
8 08 0 - 127 User(Internal)
9 09 0 - 127 User(External)
25 19 0 - 63 Plug-in Voice User(Plug-in)
32 20 0 - 7 Drum Voice Preset
40 28 0 - 1 User(Internal)
41 29 0 - 1 User(External)
63 3F 64 40 0 - 127 Performance User(Internal)
65 41 0 - 127 User(External)
Plug-in Voice Bank Display
Bank Select/Program Change disponibili delle Plug-in Boards (schede di plug-in)
(Prima di selezionare un numero, occorre installare una Plug-in Board e selezionare PLG nel modo Voice.)
MSB (HEX) LSB (HEX) Program No. Type LCD Display Descrizione
63 3F 0 - 63 Internal PLG_INT LSB = 25H: Plug-in
0 00 0 - 127 XG Normal NORM/LLL LLL: Bank LSB
64 40 0 - 127 XG SFX NORM/SFX
126 7E 0 - 127 XG SFX kit KIT/SFX
127 7F 0 - 127 XG Drum kit KIT/DRM
*** ** 0 - 127 altri MMM/LLL MMM: Bank MSB, LLL: Bank LSB
Vengono mostrati soltanto i bank che possono essere ricevuti da Plug-in Board.
00 - 7F
18 - 19
00 - 7F
00 - 7F
00 - 7F
00 - 7F
Bank Select/Program Change fatti qui potrebbero
non avere effetto in base all’impostazione di Bank
Select nel modo Utility. Per ulteriori informazioni
fate riferimento al manuale di istruzioni.
●
●
●
●
●
30
→
→
→
→
31
" "
" "
" "
" "
" "
" "
" "
" "
" "
" "
32
" "
" "
" "
" "
" "
" "
" "
" "
" "
" "
→
→
33
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
" "
" "
" "
" "
" "
" "
" "
" "
" "
"
" "
" "
" "
" "
" "
" "
" "
" "
" "
" "
" "
" "
" "
" "
" "
→
→
34
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
" "
" "
" "
" "
" "
" "
" "
" "
" "
35
"
" "
" "
" "
" "
" "
" "
" "
" "
" "
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
→
→
36
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
Ø
˛
˛
Ø
Ø
˛
˛
˛
˛
˛
˛
˛
˛
˛
˛
Ø
Ø
˛
˛
˛
˛
˛
˛
˛
˛
˛
Ø
˛
˛
Ø
Ø
Ø
˛
˛
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
Ø
˛
˛
˛
Ø
˛
Ø
Ø
˛
Ø
Ø
˛
˛
Ø
Ø
Ø
˛
Ø
˛
Ø
˛
Ø
Ø
Ø
Ø
˛
˛
˛
Ø
Ø
Ø
Ø
Ø
Ø
Ø
˛
˛
˛
Ø
Ø
˛
˛
˛
˛
˛
˛
˛
˛
˛
˛
˛
Ø
Ø
˛
˛
˛
˛
˛
˛
˛
˛
˛
˛
˛
˛
˛
Ø
˛
YAMAHA MUSICA ITALIA S.p.A.
Viale Italia, 88 - 20020 Lainate (Mi)
e-mail: yline@eu.post.yamaha.co.jp
YAMAHA Line (da lunedì a venerdì):
per Chitarre, Batterie e Audio Professionale (dalle ore 10.00 alle ore 12.30) Tel. 02/93572342 - Telefax 02/93572119
per prodotti Keyboards e Multimedia (dalle ore 14.30 alle ore 17.15) Tel. 02/93572760 - Telefax 02/93572119
per Masterizzatori (dalle ore 14.00 alle ore 17.00) Tel. 02/93577269 - Telefax 02/9370956
