Yifang Digital Technology M7U Android MID User Manual M7U Manual
Shenzhen Yifang Digital Technology Co., Ltd. Android MID M7U Manual
user manual
![](/img.php?id=1405871&img=bg1.png)
1
Precautions
z Do not subject the device to severe impact or drop it from high position.
z Do not use the player in extreme hot or cold, dusty or damp field. Do not
expose it to direct sunshine.
z Excessive sound pressure from earphones and headphones can cause
hearing loss.
z Avoid using the player in strong magnetic field.
z Keep the device away from water or other liquids. In the event that water or
other liquids enter the device, power off the product immediately, and clean
the device.
z Do not use chemical solution to clean the device in order to avoid corrosion.
Clean it with a dry cloth.
z We are not responsible for the damages or lost data caused by malfunction,
misusing, repairing the device or battery replacement.
z Do not attempt to disassemble, repair or modify the product. This will
invalidate guarantee.
z When not using the device for an extended period of time, please charge
the battery at least once per month to extend the battery life.
z Do not use the device in extremely hot, cold, dusty or damp environments.
z Avoid dropping or striking the unit .This may cause external and internal
physical damage to the player.
z Charge the battery if:
a) The battery level icon displays (An empty battery)
b) The device powers off automatically and off again when restarted.
c) No response when pressing keys with keys unlocked and battery
installed.
z To prevent damage from static shock, never use the device in very dry
conditions.
z When the device is being formatted or transferring a file, do not interrupt
the connection. Otherwise, data may be corrupt of lost.
z When the device is used as a portable HD, please use only per instructions.
Otherwise, permanent data loss could occur.
z This manual may not reflect the actual device’s operation since it is subject
to change without prior notification. Please comply with your actual
device’s operations always.
2
Table of Content
Introduction..........................................................................................................3
Feature Summary................................................................................................ 3
Package Content.................................................................................................3
Buttons & Ports....................................................................................................3
Charging Battery..................................................................................................4
Installing Memory card ........................................................................................5
Transferring Files.................................................................................................5
Turning On/Off .....................................................................................................6
Home Screen.......................................................................................................6
Using the Touch Screen ......................................................................................8
Using the Virtual Keyboard..................................................................................9
Access Internet..................................................................................................10
Playing Music ....................................................................................................12
Playing Video.....................................................................................................16
Viewing Photos..................................................................................................17
Using the Camcorder.........................................................................................18
Using the Camera..............................................................................................19
File Explorer ......................................................................................................19
E-mail ................................................................................................................21
Manage Applications .........................................................................................22
System Settings.................................................................................................23
Troubleshooting.................................................................................................25
Specifications ....................................................................................................25
Listening Cautions.............................................................................................27
FCC Warning: ....................................................................................................28
3
Introduction
MID is a mobile device that gives you an amazing Internet experience --
allowing you to communicate with others, enjoy your favorite entertainment, and
access information on the Internet at anytime and anywhere. This latest
generation of small, powerful, highly portable Internet-connected devices
combines many great capabilities with the convenience of a pocket-sized
solution for your life on-the-go.
Feature Summary
z Built-in Android Operating System
With the built-in Android OS, your MID supports most of popular
applications. You can install or uninstall applications such as MSN,
YouTube, g-email etc. on your MID.
z Wi-Fi / 3G Connectivity
With the latest Wi-Fi and 3G technology, your MID can connect you to the
Internet wherever you are.
z 7-inch Touch Screen
Touch or slide your finger in the screen, the screen responds instantly.
z Entertainment
Allows you to enjoy music, movie or pictures any time and any where.
Package Content
z Main Unit
z Stereo earphones
z USB cable
Buttons & Ports
Front View
z AC Adaptor
z User Manual
z Warranty Card
b
a. LCD Display
b. Camera Lens
c. Home: Go to the Home
Screen.
d. Menu: Display an overlay
menu.
e. SCROLL button: roll in all
ways to make selection; press
to confirm selection.
f. ESC: Return
![](/img.php?id=1405871&img=bg4.png)
4
Top View
Bottom View
Side View
Charging Battery
The device has built-in rechargeable battery. No extra battery installation is
required. Just charge the device when it indicates low battery.
To charge the battery, connect the device to any standard wall outlet through
the AC adaptor via the DC-IN port. It takes about 3 hours to fully charge the
battery.
Note:
a. You can operate the device even when it is being charged. But for extending the battery
life, you are suggested NOT to use the device when it is in charge.
a
c
d
e
f
gh
i
j
k
l
g. USB Port: connect to computer, USB flash drive, mouse or keyboard
through USB cable.
h. Power button: press and hold to turn on or off the device; briefly
press to turn on or off the screen.
i. Micro-SD Card Slot
j. Earphone Jack
k. DC-IN Port: connect to
any standard electronic
outlet through AC
adaptor.
l. Reset pin hole
m. Built-in microphone
n. 3G Card Slot: open to
insert a 3G network
card.
m
n
![](/img.php?id=1405871&img=bg5.png)
5
b. You are recommended to charge the battery when you use the device for the first time.
c. For maximum performance, lithium-ion batteries need to be used often. If you don’t use
the device often, be sure to recharge the battery at least once per month.
Installing Memory card
In addition to the built-in memory, your MID features a memory card slot to
extend its memory space. You can read e-book, music, image or video files
from a SD card directly.
To install a memory card, find the card slot at the bottom of the machine, and
then insert a Micro-SD card into the slot with the correct direction.
To access the memory card, enter the Explorer mode and then select the
“SDCard”directory.
Transferring Files
Before reading or playing files, make sure your MID’s internal memory or the
external memory card has media files. If not, transfer files from computer to
your MID.
(1) Connect your MID to a computer with the supplied USB cable.
(2) Once connected, two removable disk drives appear in your computer. One
represents the internal memory of your MID, and the other represents the
memory card inserted into your MID. Now you can copy files from or to these
disk drives.
(3) Once the data transfer completes, drag from the top bar downwards to
display the USB notification message. Choose “Turn off USB Storage” and
then tap on “Turn Off” to disconnect the device from computer.
(4) Remove the player from the PC safely.
Drag downwards
![](/img.php?id=1405871&img=bg6.png)
6
a) Left-click the icon at the right bottom corner of the computer
desktop.
b) Click the pop-up mini-window with message of “Stop the USB Mass
Storage Device – Drive (X)”.
c) Remove the player from the computer.
Turning On/Off
To turn on the device, press and hold the Power button on the unit until you see
the boot-up screen. It may take a few minutes to start up the system, please
wait before you proceed.
You should see the following locked screen once the device turns on. Before you
start using the device, you need to unlock the screen first. To unlock the screen, drag
the lock icon upward.
To turn off the device, press and hold the Power button until you see the option
“Power Off”, tap on “Power Off” and then tap on “OK”.
Tip: Your MID will sleep with the screen off if it stays inactive for a few seconds. You can
briefly press the Power button to turn on the screen and wake it up.
Home Screen
Indications
a b c d e f g h i j
k
l
m
![](/img.php?id=1405871&img=bg7.png)
7
a. Home: Go back to the Home Screen wherever you are in the interface.
b. Memory Card: the exclamation mark indicates no available memory card,
and it should disappear once a memory card is available.
c. Wi-Fi Network
d. 3G Network
e. Battery Charge
f. Current Time
g. Volume Down: Tap briefly or continuously to decrease the volume.
h. Volume Up: Tap briefly or continuously to increase the volume.
i. Return: Return to the previous directory.
j. Menu: Tap to display an overlay setting menu.
k. Address Inputting Area. You can input the website address by tapping
this field. A virtual keyboard should appear. Use the keyboard to type in
letters. Tapping will hide the keyboard.
l. Applications Tab: Tap on this icon to reveal all applications installed on
your MID (alarm clock, calculator, GlobalTime etc.).
- You can copy the applications onto the Home screen by pressing and
holding on their icons.
- You can delete the application from the Home Screen by dragging
their icons to the Application Tab. To delete a Home screen item, hold
your finger onto it until it is highlighted, then drag it to the Application
Tab which has become a trash icon.
m. Default shortcuts (“Browser”, “Video Player”, “Audio Player”, etc.)
- Tap on an icon to open the corresponding application.
- Roll the SCROLL button on the unit to select an item.
- You can customize the Home Screen by adding/removing shortcuts
and widgets, changing the wallpaper, etc.
z Customizing the Home screen items
- To add a Home screen item (shortcuts, widgets, folders etc.), tap on the
![](/img.php?id=1405871&img=bg8.png)
8
Menu icon and then select “Add” , or hold your tap on the Home
Screen until a pop-up menu displays.
- To move a Home screen item, hold your finger onto it until it is highlighted,
then drag it to the desired location, and release it.
z Changing the wallpaper
Tap on the Menu icon , and then tap on “Wallpaper”. Tap on one picture
and then tap on “Set Wallpaper” to confirm.
z Go to the extended Home Screen
Slide your finger horizontally on the screen OR roll the SCROLL button to go to
the left or right panel of the extended Home Screen.
You may see the following extended Home Screen in which you have some
useful shorcuts. Tapping on these shorcuts can activate their function.
z Changing the System Settings
Tap on the Menu icon , and then tap on “Settings” . Choose a category:
“Wireless& networks”, “Sound & Display”, “Date & Time”, etc. For more
information on the different settings, see the System Settings section.
Using the Touch Screen
Your MID is equipped with a touch-screen. Below are a few tips on how to use
the touch screen.
Main Touch Screen Actions
a b c a. Connect to available Wi-Fi
network
b. Refresh the media library
c. Adjust the screen brightness
![](/img.php?id=1405871&img=bg9.png)
9
y In different applications, you can go back one level in the interface by
tapping on the Back icon (at the top right corner of the screen).
y Wherever you are in the interface, you can go back directly to the Home
Screen by tapping on the Home icon (in the top left corner of the
screen).
Other Touch Screen Actions
y When watching a video or listening to music,
you can tap on the progression bar to go
directly to a different location in the video or
song. You can also use your finger to
drag the cursor in the progression bar to
another location in the video or song.
y In the different browsers (File, Music,
Video, Photo, etc.), you can drag your
finger up and down to scroll the file list up
and down.
y In the Web browser, you can scroll up and down by tapping on the page and
dragging it up or down (be careful however not to tap on a link!).
y Tap on the link to open the page.
Using the Virtual Keyboard
Tapping on any text input field can show up the virtual board. With the virtual
keyboard, you can enter website address or any text if required.
Indications
Selecting Input Method
If you have installed more than one input method on your MID, you can select one
method by a) holding your tap on the button until the Android keyboard settings
appear; b) choosing “Input Method” and then choosing your desired one.
a. Caps Lock
b. Backspace.
c. Number and Characters
/Letter keyboard.
d. Space
e. Enter
cb
d
a
e
![](/img.php?id=1405871&img=bga.png)
10
Access Internet
You can surf on the Internet with your slim MID.
You MID features built-in Wi-Fi technology and 3G card slot so that you can
access the internet via Wi-Fi and 3G network.
First of all, you need to configure a Wi-Fi or 3G network. For the Wi-Fi
configuration procedure to work, you need to be in a Wi-Fi zone that will allow
you to connect to it. Every time Your MID is in range of a network that you have
already configured once, it will attempt to make a connection. For the 3G
network configuration to work, you need to insert a 3G card into the device.
Making WIFI Connection
(1) Go on the Home screen, tap on the Menu icon and then select
“Settings”.
(2) In the “Settings” screen, select “Wireless & Networks”.
(3) If the WiFi is off, tap on the “Wi-Fi” setting to turn it on. Then select “Wi-Fi
settings”. Your MID will scan automatically for available WiFi networks
and display them. The list of available networks shows all the wireless
networks in range of your device.
- The list is constantly refreshed automatically.
- When the WiFi is enabled, Your MID will connect automatically to your
configured networks when they are in range.
- If Your MID finds a network that has never been configured, it will display
a notification icon.
(4) Tap on the network you want to connect to, enter the required network
information (password) and then tap on “Connect”. Your MID will now
attempt to establish a connection to that WiFi hot spot with the network
parameters you entered. If the connection is successful, the message
Connected to XXX will appear under the WIFI setting.
Note:
a) The available network list is constantly refreshed automatically.
b) When the Wi-Fi is enabled, Your MID will connect automatically to your configured
networks when they are in range.
c) If Your MID finds a network that has never been configured, it will display a notification
icon.
Advanced Connection
To manually scan for available Wi-Fi networks,
(1) In the “Wi-Fi settings” screen, tap on the Menu icon , and then tap on
“Scan”.
![](/img.php?id=1405871&img=bgb.png)
11
(2) If the Wi-Fi network you want to connect to does not appear in the list, scroll
down the screen, then tap on “Add a Wi-Fi network”. Enter the required
settings, then tap on “Save”.
To access the advanced network parameters (“Regulatory domain”, “IP
address”, etc), tap on the Menu icon , and then tap on “Advanced”. Other
parameters will appear. The required information can be obtained from the
person who manages the network.
Making 3G Network Connection
(1) Go on the Home screen, tap on the Menu icon and then select
“Settings”.
(2) In the “Settings” screen, select “Wireless & Networks”.
(3) If the 3G is off, tap on the “3G” setting to turn it on. Select “3G settings” to
set up the Access Point. Fill in all required parameters and then tap on
to save or discard the settings.
Launching the WEB browser
Tap on the “Browser” icon in the Home Sreen to launch the WEB browser.
If you are already connected to a network, the Web browser will simply open
and you can start browsing the Web.
Note: Not all wireless networks offer access to the Internet. Some WiFi networks only link
several computers together, without any Internet connection.
Using WEB Browser
y You can scroll up and down the screen by tapping on the page and dragging
it up or down (be careful however not to tap on a link!).
y To open a link, simply tap on it.
y You can open several web pages at a time, view them all at once on the
screen, and then tap on one of them to view it in full screen.
y To go back to the previous page that you browsed, tap on the Back icon .
y To display the available menu items, tap on the Menu icon .
y To go back directly to the Home screen, tap on the Home icon .
y Depending on where you are in the web browser, holding down on an item
will give you access to more options.
y To fill in a text field, tap in the field, then use the virtual keyboard to type in
the required text.
WEB Browser Menu Items
![](/img.php?id=1405871&img=bgc.png)
12
When you are viewing page, you can tap on the menu icon to display the
menu items.
Go Allows you to enter the address of a Web site you’d like to
visit. Enter the address with the virtual keyboard. Select “Go”
to open the website in the current window.
Bookmarks Will open the “Bookmarks” manager. You will see three tabs:
“Bookmarks”, “Most visited”, and “History”.
“Bookmarks” show you a list of bookmarks. Just tap on one
of them to open it in the current window. Holding down on a
bookmark will give you access to several options (you will be
able to edit it, rename it, delete it, etc.). You can also use the
Menu icon which will allow you to bookmark the
last-viewed page.
“Most visited” and “History” allow you to access your “Most
visited” sites and your “History”. In the “History” tab, the Menu
icon allows you to clear the history.
New
window/
Windows
Allows you to open new windows. When you have several
windows currently opened, tap on “Windows” to display them
all at once on the screen. Just tap on one of the small
windows to view it in full screen, or tap on the Close icon in
the small window to close the window.
Refresh/
Stop
“Stop” will stop loading the web page, if it is currently loading.
“Refresh” will refresh the current web page, if it has stopped
loading.
Forward Will go to the next page that you browsed.
More Will give you access to other options (“Find on page”, “Select
text”, “Page info”, “Downloads”, “Settings” etc.).
Playing Music
Your MID provides two applications for you to play music files: Audio Player and
Music. You can choose “Music” or “Audio Player” in the Home Screen to enter
the music player mode. Let’s take the Audio Player as example to explain how
to play music.
Music Library
You should enter the music library once you start up the music player. The
Music Library shows your music files sorted by categories (Artist, Album, Genre,
etc.) if your music files contain these song information tags. If some of your
music files do not contain information tags, they will be classified as (Unknown)
![](/img.php?id=1405871&img=bgd.png)
13
in the Music Library. When new music is copied to Your MID, the Music Library
will be updated automatically.
y You can drag your finger up and down on the file list to scroll through the list.
y Tap on a track to play a track.
y To return to the Home Screen, tap on / / .
Music Library Menu
Once you enter the music library, you should see the toolbar at the bottom of
the screen. Tap and hold your finger on the icon and you should see its name.
All Music List all music files.
Internet Search
Allows you to search for a specific song on
Internet by entering a few letters or a word and
download the song from the Internet.
Artist List music files by artist.
Album List music files by album.
Genre List music files by genre.
Playlist Display playlists.
Directory Browsing Navigate through music files and folders stored
in the internal memory and memory card.
Enter Play Interface Go to the Now Playing screen.
Return Return to Home Screen.
Search for Tracks
You can search for tracks in the internal memory or memory card by inputting a
few key words.
(1) In the music library, tap on the Directory Browsing icon in the menu.
(2) Choose the memory device in which you want to search for tracks.
(3) Tap on the Search icon , and then input a few key words of the track.
(4) Tap on to start searching. The track should be listed if found.
Sort Tracks/Folders
![](/img.php?id=1405871&img=bge.png)
14
You can sort all tracks/folders by their leading leters in order of A to Z, the
creation time of the track/folder, the file size or the file type.
(1) In the music library, tap on the Directory Browsing icon in the menu.
(2) Choose the memory device to be sorted.
(3) Tap on the Sort icon (by file size) / (by file type) / (by leading
letter)/ (by creation time) to sort the tracks/folders stored in the selected
memory device.
Set EQ Mode Manually
When you are listening to the music, tap on the Menu icon which allows
you to customize your equalizer setting. Your MID features a 7-band equalizer.
(1) Select a band, then drag your finger up/ down on the band to change the
gain level for these frequency ranges.
(2) Tap on “Save Effect” to confirm or tap on to return.
Playback Screen
y Slide your finger vertically on the screen or roll the SCROLL button to
browse through the music list.
y Tap on the track or press the SCROLL button to play it.
y To pause/resume the song, tap on the Pause / Play icon.
y To play the previous/next song, tap on / .
y You can tap on the progression bar to go directly to a different location in
the song. You can also drag the cursor in the progression bar to another
location in the song.
y Tap on / to adjust the volume.
y To change the EQ mode, tap on “EQ”.
y To play the specified section from A to B, tap on “A-B”.
a. Track title
b. ID3 Information (artist, album etc.)
c. Search for information about the
track from Internet.
d. Progression bar
e. Previous track
f. Play/Pause
g. Next track
h. Change EQ mode
i. A-B Section Repeat
j. Change repeat mode
k. Add the track to playlist
l. Display lyric
m. Decrease volume
n. Increase volume
o. Return
a
b
c
d
e f g
h i j k l m n o
![](/img.php?id=1405871&img=bgf.png)
15
y To change the repeat mode, tap on .
y To add current track to playlist, tap on .
y To display lyric/ID3 information, tap on .
y To define the equalizer mode manually, tap on .
y Tapping continuously on the ID3 information tag will search for the
information about the track from the Internet.
y To go back to the music library, tap on .
y To go back directly to the Home screen, tap on the Home icon or
Return icon .
Playlist
A playlist is a list of audio tracks that the music player will automatically play
one after the other. On your MID, you can play, create and edit as many
playlists as you want.
Create a Playlist
(1) While you are in the music list, select the Playlist menu item “ ”, a playlist
panel will open. You can now start modifying the playlist.
(2) Tap on the New Playlist icon to create a new playlist.
(3) Tap on the Edit icon beside the playlist name to add songs to the
playlist.
(4) Tap on the songs you would like to add to your playlist. A check mark
“√”should appear before the song if selected.
(5) When you are satisfied with your new playlist, tap on the “ ” icon to save
the playlist.
Edit a Playlist
You can add track to or delete track from the playlist.
(1) In the Music Library, tap on the Playlist icon to display the playlists.
(2) Tap on the icon beside the playlist that you want to edit. You can now
add tracks to or delete tracks from the playlist.
(3) Tap on the songs you would like to add or delete, a check mark should
appear or disappear before the song. The song with check mark will be
added to the playlist, while the song without check mark will be deleted from
the playlist.
(4) When you are satisfied with your playlist, tap on the icon to save the
playlist.
Delete a Playlist
To delete an existing playlist,
(1) In the Music Library, tap on the Playlist icon to display the playlists.
![](/img.php?id=1405871&img=bg10.png)
16
(2) Tap on the icon beside the playlist that you want to delete, and then the
playlist will be deleted.
Note: You cannot delete the Recently Played playlist since a track is playing.
Playing a Playlist
(1) In the Music Library, tap on the Playlist icon to display the playlists.
(2) Tap on a playlist to open it. A panel showing the contents of the playlist will
open.
(3) Tap on the first item in the playlist to start playing from the first track.
Playing Video
Tap on the Application Tab to display all applications, and then select “Video
Player” to enter the video mode.
Navigate through Video Files
You should see the video list when you enter the video player.
y You can drag your finger up and down on the video list to scroll the video list
up and down.
y Tap on a video to start playing.
y You can go back directly to the Home screen by tapping on the Return icon
or Home icon .
Playback Screen
y Tap on the / icon to pause/resume the video,
y Tap on “ ” to display the menu items.
y Tap on the progression bar to go directly to a different location in the video.
You can also use your finger to drag the cursor in the progression bar to
another location in the video.
y Tap on / to adjust the volume.
y Tap on “ ” to set a bookmark at the current spot in the video. Please
a b
d e f g h i j k
a. Decrease volume
b. Progression bar
c. Increase volume
d. Bookmark
e. Brightness
f. Previous video
g. Play/Pause icon
h. Next video
i. Change View Mode
j. Return
k. Video settings
c
![](/img.php?id=1405871&img=bg11.png)
17
note only one bookmark can be set for one video, and the new bookmark
should cover the old one. To resume playing a video from the bookmark,
go to the Home Screen, enter the Video Player, and tap on the
bookmarked video. You should be prompted to “Play from beginning” and
“Play from bookmark”. Select “Play from bookmark”. In default, the video
plays from beginning. To remove the bookmark, tap on “ ” to display the
menu, and then choose “Delete Bookmark”.
y Tap on to adjust the brightness of screen.
y Tap on / to play the previous or next video.
y Tap on to change the aspect ratio of screen.
y Tap on to stop playing and return the video list.
Video Playback Settings
Tap on the icon to display the video settings.
Play from beginning(this
will delete bookmark)
Delete bookmark and play from beginning.
Delete Bookmark Delete the video bookmark.
Help Get instructions on playing video.
Repeat Single – plays the current video and then
stops ater playing.
Repeat One – Repeat the current video.
Repeat All – Repeat all videos.
Return Exit from the menu.
Viewing Photos
Tap on the Application Tab to display all applications, and then select “Photo
Viewer” to enter the photo mode.
Photo Thumbnails
The first screen of the Photo mode
shows all the photos and subfolders
located in your MID or memory card
in thumbnails.
To view a photo, tap on its thumbnail
to open it. If a photo is in a subfolder,
open the subfolder, and you will see
your photo.
Viewing Photo
![](/img.php?id=1405871&img=bg12.png)
18
When you are viewing picture, you can tap on the screen to show a floating
toolbar at the bottom of the screen.
y To start/pause a slideshow, tap on the Slideshow icon .
y To display the previous/next picture, tap on the left / right arrow
beside the picture.
y To rotate the picture 90° counterclockwise, tap on the Rotate Left icon .
To rotate the picture 90° clockwise, tap on the Rotate Right icon .
y To magnify the current picture, tap on the Zoom In icon . When the
picture is enlarged, you can drag the picture vertically or horizontally to
move the picture. To decrease the picture size, tap on the Zoom Out icon
.
y To set brightness of the screen, tap on .
y To display the available menu items, tap on the Setting icon .
y To go back to the photo browser, tap on the Back icon .
Using the Camcorder
Your MID features built-in VCR which allows you make video clips. Tap on the
Application Tab to display all applications, and then select “Camcorder” to
enter the VCR mode.
z To make video clips, tap on the Start/Stop button to start video recording.
Once you finish recording, tap on the Start/Stop button again to stop. A
video is then created and previewed it in the Preview Window.
z To play the video clip that you have made, enter the Video Player, choose
a
b
c
a. Mode Switch button
b. Start/stop button
c. Preview Window
![](/img.php?id=1405871&img=bg13.png)
19
the video clip and then play it (see “Playing Video” for details).
z You can take photos in the VCR mode. Slide the Mode Switch button to the
camera mode , and then tap on the Start/Stop button to start
capturing picture. Once you finish, tap on the Start/Stop button again to
stop. A photo is then created and previewed it in the Preview Window.
z To view the photo that you have taken, enter the Photo Viewer mode,
choose the photo and then view it (see “Viewing Photo” for details).
Using the Camera
Instructions of using the camera are similar to using camcorder. Please refer to
the “Using the Camcorder” for details.
File Explorer
The file browser gives you the possibility to navigate the file system of your MID
internal memory and memory card. Tap on the Application Tab to display all
applications, and then select “Explorer” to enter the file explorer mode.
Navigate through Files and Folders
y You can drag your finger up and
down to scroll the file list up and
down.
y To open a file or folder, tap on
the file/folder.
y Tap on the menu icon , you
can manage the applications (see
details in the “Manage
Application” section).
y You can go back or forward one level in the interface by tapping on the Back
icon or Next icon .
y You can go back one level in the directory by tapping on the LevelUp button
.
y Wherever you are in the interface, you can go back directly to the Home
screen by tapping on the Return icon or Home icon .
y Tap on the Home icon to go to the root directory.
Using the Toolbar
You can use the toolbar to navigate through your device’s internal memory/
memory card, delete or copy files.
Tapping on the grey area can hide/display the toolbar.
![](/img.php?id=1405871&img=bg14.png)
20
Home Go to the Home Screen.
LevelUp Go back one level in the directory.
Multi Select more than one file together.
Editor Copy, delete, move, paste or rename the file or folder.
Back Go back one level in the interface.
Next Go forward one level in the interface.
Copy/Move Files and Folders
(1) In the file list, scroll up and down by sliding your finger to
select the file/folder that you want to copy or move.
(2) Hold your tap on the selected file/folder until a pop-up
menu appears.
(3) Select “Copy” or “Move” from the pop-up menu.
(4) Navigate to the location where you wish to copy or move
the file/folder to.
(5) Select the Editor icon from the toolbar and then choose “Paste”.
Delete Files and Folders
(1) In the file list, scroll up and down the list by sliding finger to select the
file/folder that you want to delete.
(2) Hold your tap on the selected file/folder until a pop-up menu appears.
(3) Select “Delete” from the pop-up menu, then select “Delete”to confirm or
“Cancel”to quit.
Rename Files and Folders
(1) In the file list, scroll up and down the list by sliding finger to select the
file/folder that you want to rename.
(2) Hold your tap on the selected file/folder until a pop-up menu appears.
(3) Select “Rename” from the pop-up menu.
(4) Tap on the inputting field to display the virtual keyboard, and then choose
letters from the virtual keyboard to rename the file/folders.
(5) Tap on “OK” to confirm the new name.
Select Multiple Items
You can select more than one file or folder together.
(1) In the top toolbar, tap on the Multi icon “ ”.
(2) Tap the files/folders you want to choose. The file/folder name turns red
when selected. Tapping it again can cancel the selection. Once you
![](/img.php?id=1405871&img=bg15.png)
21
finished selection, you can delete, copy or move the selected files together
by tapping on the Editor icon .
E-mail
Your MID has pre-installed an E-mail application. You can send or receive
e-mails from the Internet at any time with Your MID. Make sure you have an
internet connection before using the email service.
Tap on the Application Tab to display all applications, and then select “Email”
to launch the email application. You should enter the inbox if you have set up
an email account. Otherwise, set up an account first.
Setup a Email Account
First you need to setup an E-mail account for receiving or sending emails.
(1) You are prompted to setup an account once you start up the email
application. Tap on “Next” to continue.
(2) Input your email address and login password. You can set the account as
default by selecting the option “Send email from this account by default”.
Then tap on “Next” to continue.
(3) Type in required information for setting up the PO3/IMAP server. You can
get the information from the service provider, network administrator or the
Internet.
(4) Tap on “Next” to continue after you set up the POP3 server. Your MID will
check the server settings and will proceed to the IMAP server setting if the
setting is correct. Setup the IMAP server as you do to POP3 server. Please
note in the “IMAP Server” field, you should input “imap.+ domain name”.
(5) Your MID will check the settings. When it prompts you that “Your account is
set up, and email is on its way”, your account is set up successfully.
(6) Input your name to be displayed in every email and then tap on “Done” to
finish.
Note: If you have more than one account, every time when you start up the email
application, you enter the default email account.
Manage Accounts
You can setup more than one account and manage these accounts by checking
information about the account, adding another account or deleting an account.
Add another Account
Following these steps to add another account if you want.
(1) Launch the email application and then tap on the Menu icon to display
![](/img.php?id=1405871&img=bg16.png)
22
the menu item. Choose “Accounts” to display accounts.
(2) Tap on the Menu icon to display the menu item, and then choose “Add
account”.
(3) Follow the steps of setting up a Email Account to add an account.
Delete a Email Account
(1) When you are in the email box, tap on the Menu icon to display the
menu items.
(2) Tap on “Accounts” to display all email accounts.
(3) Hold your tap on the account that you want to delete until a menu pop up.
(4) Tap on “Remove Account”,and then tap on “OK” to confirm.
Check the Account Setting
(1) When you are in the email box, tap on the Menu icon to display the
menu items.
(2) Tap on “Accounts” to display all email accounts.
(3) Hold your tap on the account that you want to delete until a menu pop up.
(4) Tap “Account settings”,and then you should see all setting information about
the account. You can edit these settings as you want.
View Emails
You should enter your mailbox when you start up the email application.
y In the mailbox, you can slide your finger up and down to scroll through the
email list.
y Tap on an email to open it.
y Holding your tap on the email can display a menu. With the menu, you can
open, reply, forward or delete the email.
Email Menu Items
In the email list, tap on the Menu icon to display the menu.
Refresh Refresh the emails.
Compose Compose a new email.
Accounts View all email accounts.
Account Settings Check your account settings.
Manage Applications
Your MID provides support to many useful third-party applications. You can
purchase the applications to add more functions to your device. They are
available online at the Internet or directly on your product.
Pre-installed Applications
![](/img.php?id=1405871&img=bg17.png)
23
The device has pre-installed applications when it was manufactured. You can
see them by tapping Application Tab. They are video player, audio player,
photo viewer, alarm clock, calculator, calendar etc.
Install Applications
You can install applications manually following these steps:
(1) Download the installation file to your computer. Make sure the file is in
format of .apk which is supported by Your MID system.
(2) Connect Your MID to computer with the USB cable.
(3) Copy the installation file to your MID.
(4) Disconnect your MID form the computer.
(5) Turn on your MID and enter the file explorer mode with the Explorer.
(6) Locate the installation file and open it.
(7) Follow the on-screen instructions to install the application.
(8) Once the application is installed successfully, you can find it in the
application tab.
Uninstall Applications
(1) Display all applications by tapping on Application Tab.
(2) Select “Settings”, and then select “Applications”.
(3) Select “Manage Applications”.
(4) Tab on the application that you want to uninstall.
(5) Tab on “Uninstall” to uninstall the application.
Note: You cannot uninstall the pre-installed applications.
System Settings
In the Home screen, tap on “Settings” and choose a category: “Networks
Controls”, “Sound & Display”, “Date & Time”, etc.
y When a down arrow appears on the right of a parameter, this means that
this setting includes sub-parameters. Tap on it to reveal the list of
sub-parameters.
y When a check box appears on the right of a parameter, tap on it to enable or
disable this option.
y When it is possible, you can use your finger to scroll the screen up and down
to reveal settings that you don’t initially see.
y When you have finished adjusting your settings, tap on the Back icon to
go back to the list of settings, or tap on the Home icon to go directly to
the Home screen. Your settings are saved instantly.
Wireless & This menu allows you to manage your Wi-Fi and Bluetooth
![](/img.php?id=1405871&img=bg18.png)
24
networks connections as well as set up the Airplane mode.
Wi-Fi – tap on this line to enable or disable the Wi-Fi
connection.
Wi-Fi settings – allows you to set up and manage your Wi-Fi
networks.
Sound &
Display
Sound settings:
Media volume –Sets the volume for music and videos. You
can also adjust the sound by using the Volume buttons, on
the top of the device.
Notification Ringtone –Set your default notification ringtone.
Audible selection –enables/disables the touchscreen click
sound.
SD card notifications –Disable SD card notification sounds.
Display settings:
Animation –enables/disables the display of animations when
opening and closing applications.
Brightness –allows you to adjust the brightness of the
screen.
Screen timeout –allows you to adjust the delay before the
screen automatically turns off and locks itself. To turn the
screen back on, press the Power button once, and press it
again to unlock the screen.
Location &
Security
This screen gives you the possibility to allow certain
Android™ applications to determine your current location via
the WiFi or the GPS. You can also define a screen unlock
pattern and other security parameters.
Applications This screen allows you to manage your Android™
applications. You can view information about all the
applications installed on your device.
SD card & MID
Storage
This setting allows you un-mount the SD card or check SD
card and internal storage space.
Language &
keyboard
Set your preferred language and region, and configure text
settings for faster and more accurate text input.
Date & Time This setting allows you set up the date, time, time zone and
formats.
Touch Panel
calibration
If the touch-screen is not responding properly, use this setting
and follow the instructions on the screen.
USB Mode
Select
Select this option if you connect to a USB flash drive with
built-in 3G technology instead of a 3G network card.
Update Media
Library
Update the media library of your MID manually.
About Device Display information about Your MID system.
![](/img.php?id=1405871&img=bg19.png)
25
Troubleshooting
Reset your MID
y In the event that your MID freezes, you can force the device to shut down by
holding the Power button for 15 seconds.
y Only if the Power button does not reset your device, then should you use
the “pinhole reset” button, located on the back the device.
Touch-screen Problems
If the touch-screen is not responding properly try to go to the “Touch-Screen
Calibration” settings screen.
Specifications
MID Configurations
CPU
Based on ARM926EJ (dual-core)
Main CPU frequency:600MHz
Auxiliary CPU Frequency(DSP digital command control):550MHz
SDRAM 2X64MB
Built-in
operating
system
Android OS 2.2
Hardware IBM PC or compatible PC, Note-book or Macintosh with USB port
Internal
Memory NAND Flash: 512MB,1GB,2GB,4GB,8GB,16GB(optional)
Memory Card
type
SD card: 1GB, 2GB, 4GB (SDHC), 8GB(SDHC),
16GB(SDHC)(optional)
System Requirements
Operation
System Windows2000/XP/Vista/windows 7and MAC OS 10.4 or above
USB Interface USB2.0 High speed
Features
Output Port 3.5mm earphone port, built-in speakers
Audio
MP3(MPEG1/2/2.5 Audio Layer 1/2/3);
WMA(Version 4,4.1,7,8,9)
WAV(MS-ADPCM,IMA-ADPCM,PCM)
APE(Version 3.95,3.97,3.98,3.99,normal and fast except high and
extra high)
FLAC(FLAC Audio)
AAC(ADIF ,ATDS Header AAC-LC and AAC-HE ) (For license)
OGG
Video Format AVI(Xvid, Divx 4/5/6 except GMC&QPEL, Divx for License, Audio
Codec:MP3, AC3)
![](/img.php?id=1405871&img=bg1a.png)
26
RM/RMVB(Real Video Codec 8/9/10 except G2, Audio Codec: Real
Audio)
FLV( Sonnati H.263, H.264 except O2 VP6) (For license)
MKV(H.264, MPEG4, XVID, DIVX4/5/6)
MOV(MPEG4, H.264, Audio Codec:MP3)
Photo Format JPEG, BMP, GIF
Language Multinational languages
Technical Parameter
Read speed 8.7-9MB/S(MLC flash)
Write speed 4.5-4.8MB/S(MLC flash)
SD read/write
speed Read speed:2.5-4MB/S; Write speed:1.5-3MB/S
Audio Bit Rate
MP3: 8~320Kbps
WMA: 8~320Kbps
OGG: Q1- Q10
Video
Resolution
AVI(Max.1280X720);RM/RMVB(Max.1280X720);FLV(Max.1280*720);
MKV(Max. 1280X720);MOV(Max. 1280X720)
Video Bit rate
Max. 6Mbps (MPEG4, XVID, DIVX4/5/6);
Max. 2.5Mbps (H.264, Real video 8/9/10);
Max. 2Mbps (Sorenson H.263).
Resolution JPEG(Baseline)(Max.8000*8000),GIF(Static)(Max.1000*1000)
Recording
format 3gpp(general quality:6kbps/8kHz)
Network
Connection
Media
WiFi (802.11 b/g)
Battery Charge
Time About 5 Hours
Battery Life
About10 hours of music playback;
About 6 hours of video playback;
About 6 hours of web browsing.
Display 7-inch TFT LCD, Touchpad (resistive touch pad), 800X480 pixel.
SNR 90dB above
Frequency
Response
Range
20Hz—20KHz
Power Supply Rechargeable lithium-ion polymer battery;
AC Adapter: AC Input 100-240V~50/60Hz, DC Output 5V/2A
Physical Parameters
Storage Temp. -20 ℃~ +65℃
![](/img.php?id=1405871&img=bg1b.png)
27
Ambient Temp. 0 ℃~ +50℃
Operation
Relative
Humidity
20% ~ 90%(40℃)
Storage
Relative
Humidity
20% ~ 93%(40℃)
Listening Cautions
z Do not play your earphones or headphones at a high volume. Hearing experts
advise against continuous extended play.
z If you experience a ringing in your ears, reduce volume or discontinue use.
z Do not use while operating a motorized vehicle. It may create a traffic hazard
and is illegal in many areas.
z You should use extreme caution or temporarily discontinue use in potentially
hazardous situations.
z Even if your headphones or earphones are the open-air type designed to let
you hear outside sounds, don’t turn up the volume so high that you can’t hear
what’s around you.
z Sound can be deceiving. Over time you hearing “comfort level” adapts to
higher volumes of sound. So what sounds “normal” can actually be loud and
harmful to your hearing. Guard against this by setting your equipment at a safe
level BEFORE your hearing adapts.
To establish a safe level:
a. Start your volume control at a low setting.
b. Slowly increase the sound until you can hear it comfortably and clearly,
and without distortion. Once you have established a comfortable
sound level, leave it there.
28
FCC Warning:
z RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The
device can be used in portable exposure condition without restriction.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
z (1) this device may not cause harmful interference, and
z (2) this device must accept any interference received, including interference
that may cause undesired operation.
z Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
z NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
z -- Reorient or relocate the receiving antenna.
z -- Increase the separation between the equipment and receiver.
z -- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
z -- Consult the dealer or an experienced radio/TV technician for help.
