Yifang Digital Technology XF195T Car MP3 Player User Manual users manual
Shenzhen Yifang Digital Technology Co., Ltd. Car MP3 Player users manual
Users Manual
![](/img.php?id=732707&img=bg1.png)
1
XF195T Car MP3 Player User Guide
◎Please read this manual carefully before using.
◎This manual is subject to change without prior notification.
◎ There may be discrepancy between this manual and the actual operation, please refer to the actual
operation or display.
For the sake of your safety, please read the following safety cautions before operation.
Safety Precautions
Do not subject the device to severe impact or drop it from high position.
Do not use the player in extreme hot or cold, dusty or damp field.
Do not expose it to direct sunshine.
Avoid using the player in strong magnetic field.
Keep the device away from water or other liquids. In the event that water or other liquids
enter the device, power off the product immediately and clean it.
Do not use chemical solution to clean the device in order to avoid corrosion. Clean it with
a dry cloth.
We are not responsible for the damages caused by malfunction, misusing, repairing the
device or battery replacement.
Do not attempt to disassemble, repair or modify the product, or it will be out of guarantee.
![](/img.php?id=732707&img=bg2.png)
2
Features
Read audio files from the USB flash disk directly and transmit the music to the car FM
tuner.
Transmit music from an external audio player (CD, MD player etc.) to the FM radio.
Two optional play mode: Normal and Random
Frequency Display and work state (play, pause or shuffle) indicator
Hinge design convenient for you to adjust the device’s position
12 Preset channels within two frequency bands: 88.1~88.9MHz and 106.7~107.9MHz
Car cigarette lighter power supply (12V DC power)
Restore the last frequency, track number and volume when you restart the device
Package Content
Main Unit
Line-in Cable
Safety Fuse
User Manual
Keys Description
Play Music
[Basic Operations]
Function Operation
Play/Pause Press the key to play music, the LED is
flashing during playback, and the frequency
display displays current channel.
Press the key to pause, after about 30
seconds, the device stop transmitting and
displays nothing with LED steadily on. To
resume, press it again.
Switch Play Mode Press and hold the key for a while to switch
A. LED Indicator
B. Play/Pause/Shuffle
C. Frequency Display
D. Previous
E. Next
F. Channel Switch button
G. Line-in jack
H. USB port
I. 12 V DC adapter
![](/img.php?id=732707&img=bg3.png)
3
play mode. The device provides two play
modes: Repeat All and Random.
Note: In the Repeat All mode, the LED flashes slowly.
In the Random mode, the LED flashes quickly.
Previous/Next Press the key to play the previous track or
press the key to play the next track.
Switch Channel Press the “CH” key to switch between 12 preset
channels. When you switch to a certain channel,
the frequency is indicated on the display.
Note: The 12 preset channels are 88.1, 88.3, 88.5,
88.7, 88.9, 106.7, 106.9, 107.1, 107.3, 107.5, 107.7,
107.9 MHz.
[Play music on a removable disk]
1.
Plug the USB flash disk that stores audio files into the USB port.
2.
Insert the device into the cigarette lighter socket to draw 12 V DC power.
3.
Press the “CH” key to select the preset channel without signal interference. You see the
selected frequency indicated on the display.
4.
Tune the car FM radio to the same channel as indicated on the display.
5.
Now you can enjoy your music by controlling the keys on the device. For detail
information about operation, see “Basic Operation” section.
[Play music on an extra audio player]
The device supports LINE-IN feature that enables you to enjoy the music from an external
audio device such as CD, MD player, iPod etc. The external audio source comes into the
device through the line-in jack and is transmitted to the FM tuner by the built-in FM
transmitter. You enjoy the music through the FM stereo audio system.
1.
Connect one end of the LINE-IN cable to the line-in jack of the device and connect the
other end to the earphone jack of the external audio device.
2.
Turn on the external audio player and play the music.
3.
Press the “CH” key to select the preset channel without signal interference. You see
the selected frequency indicated on the display.
4.
Tune the car FM radio to the same channel as indicated on the display.
5.
Now you can enjoy music with keys on the audio player.
Note: (1) All keys except channel switch are unavailable when you use the line-in function. You
can only use the keys on the extra audio player to control the playback. (2) When the playback
pauses, the device stops transmitting and displays nothing.
![](/img.php?id=732707&img=bg4.png)
4
Troubleshooting
Problem Solution
The indicator or frequency display
does not light up when I install the
device in the car.
Reinsert the device to the cigarette lighter.
If the problem still exists, try to replace the
safety fuse.
I cannot play the music on the
removable disk.
● Reload the music files
● Reinsert the removable disk
The indicator lights up, but the
keys don’t function
Reinsert the device to the cigarette lighter.
The indicator lights up, but there is
no sound.
● Check whether the removable disk is
inserted well.
● Check whether the LINE-IN cable is
connected well.
● Check whether the music file is in a
supported format
● Adjust the volume
There is noise when I tune to a
station
Please switch to a station where there is no
signal interference.
When I use LINE-IN function, the
external audio player is playing,
but the device displays nothing
with no sound.
Adjust the volume on the external audio
player.
Notice
Operation voltage for the device is +12V. Too high or too low voltage could cause the
device damaged or failed.
For the sake of safety, please insert the USB flash disk before you plug the device into
the car cigar socket.
The device cannot guarantee compatibility with all USB flash disks from every
manufacturer.
Frequency of the car FM tuner should be the same as that of the device.
You’d better not pull out the USB flash disk during playback. Pause the playback first.
The progress may be slow when the USB flash disk stores too many audio files.
In order to extend the device life, please do not keep it in use for too long.
Safety Fuse Replacement
When the device cannot work properly, it may due to the safety fuse failure. Please replace the
safety fuse following these steps if necessary:
1.
Remove the device from the cigarette lighter socket.
![](/img.php?id=732707&img=bg5.png)
5
2.
Twist the tip of the cigar plug.
3.
Remove the bad safety fuse and insert a new one (provided with the package)
Technical Specification
Item Description
Supported USB storage USB flash disk with USB 1.1 /USB2.0 interface
FM frequency range 88.1~88.9MHz, 106.7~107.9MHz
SNR 60dB
Frequency Responding 20HZ-15KHZ
File Type Support MP3, WMA
Audio Source USB flash disk or audio player
Safety Fuse 500mA, 250V
FCC Statement
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
