Youngshin Electronics JMR600SS Car Alarm User Manual 2WSSR user s guie
Youngshin Electronics Co., LTD. Car Alarm 2WSSR user s guie
User Manual
![](/img.php?id=772089&img=bg1.png)
FCC ID : 044JMR600SS
USER’S GUIDE
2WSSR
YOUNG SHIN Electronics Co., Ltd.
www.MAGICAR.com
USER’S GUIDE
2WSSR
FCC ID : 044JMR600SS
Two-Way Spread Spectrum Remote
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
CAUTION :
Changes or modifications not expressly approved by the party
responsible for compliance could void the user s authority to
operate this device.
![](/img.php?id=772089&img=bg2.png)
Page 2
TABLE OF CONTENTS
Page 3
Spread Spectrum Technology
Introduction
Limited Lifetime Consumer Warranty
Your Warranty
Important Information
Safety Information
System Maintenance
Remote-Pager : 2WSSR w/LCD
CompuGLO color LCD (Liquid Crystal Display)
Remote-Pager Button Functions
Remote-Pager Learning
Remote-Pager Factory Reset Procedure
Using Your System
Alarm Mode
Dual Stage Shock Sensor
Auto-start Function
Panic Mode
Reservation Mode (Manual Transmission only)
Query Function
Trunk Release
Vibration Mode
Car Siren
Valet Mode
Timer Start Mode
Optional Programmable Features
Ignition Lock
Passive Arming
Turbo Mode
Optional Installation Features
RPS (Remote Paging System)
Cold Start Mode
Optional Auxiliary 1 & Auxiliary 2
Safety Shut down Features
Frequently Asked Questions
Troubleshooting
Page 4
Page 4
Page 5
Page 6
Page 6
Page 6
Page 7
Page 7
Page 7
Page 9
Page 10
Page 11
Page 11
Page 11
Page 12
Page 13
Page 13
Page 14
Page 15
Page 15
Page 15
Page 15
Page 15
Page 16
Page 17
Page 17
Page 17
Page 17
Page 18
Page 18
Page 18
Page 18
Page 19
Page 19
Page 20
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
ᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍᴍ
![](/img.php?id=772089&img=bg3.png)
Spread Spectrum Technology
This groundbreaking technology uses a transmitted signal that is spread over a wide
frequency band and the transmitter abruptly changes (or hops) the frequency in accor-
dance with a pseudo random sequence. With this revolutionary technology, the FCC
has allowed Firstech, Inc. to use 28X more power than any of the transmitters currently
marketed in the US and in most case 56X the power. We are using 560K uV/m in
contrast to most transmitters power of 5 K to 20K uV/m. The result is that our range is
extended up to 1.25 miles. The FCC allows massive power usage because the spread
spectrum technology makes it possible for many transmitters to communicate without
interfering with each other.
For the first time in the history of the auto security industry, Firstech has achieved a
remarkable technological break-through in utilizing a FCC-approved Spread Spectrum
and 900 Mhz Technology.
Introduction
Thank you for choosing CompuStar, a state-of-the-art Two-Way alarm/remote start
system for your vehicle that uses Spread Spectrum Technology (SST). We, at Firstech,
Inc., are constantly performing research and development to make you and your vehicle
safe and more comfortable. Security and comfort, that s what Firstech, Inc. is all about.
CompuStar 2WSSR system consists of the following two devices :
Controller : This 5 inch by 3.5 inch by 1 inch rectangular black box is the brain of the
CompuStar 2WSSR system and is installed underneath the dashboard of your vehicle.
Upon receipt of a digital signal from the antenna, the controller can perform car tasks
such as remote keyless entry, auto-start and security alerts.
Remote-Pager : This device allows the user to activate multiple functions of the
CompuStar 2WSSR controller such as auto-start, keyless entry and security features
by pressing a combination of 4 buttons on the unit for up to a 1.25 miles distance.
Also, the unique color LCD display called CompuGLO allows the user to visually,
audibly and through vibration, monitor the security status of your car at all times.
Firstech, LLC Warrants to the original purchaser that this product shall be free of defects
in material and workmanship under normal use and circumstances for the period of time
that the original owner of this product owns the vehicle in which it is installed; except that
the remote controller unit for the period of one year from the date of installation to the origi-
nal owner of this product. When the original purchaser returns the product to the retail store
where it was purchased or pre-paid postal to
Firstech, LLC., 3415 S. 116th St Seattle,
WA 98168, USA within the warranty period, and if the product is defective, Firstech, LLC,
will at its option repair or replace such.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE
EXCLUDED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE
STREAM OF COMMERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT
LIMITED TO, THE EXCLUSION OF ANY AND ALL WARRANTY OF MERCHANTA
BILITY AND/OR ANY AND ALL WARRANTY OF FITNESS FOR A PARTICULAR PUR-
POSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OR PATENTS,
IN THE UNITED STATES OF AMERICA AND/OR ABROAD. NEITHER THE MANUFAC-
TURER OF ANY ENTITIES CONNECTED THEREWITH SHALL BE RESPONSIBLE OR
LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO,
ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR LOSS
OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPOR-
TUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, MANUFACTURER DOES
OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE
AS DESCRIBED ABOVE. Some states do not allow limitations
on how long an implied warranty will last or the exclusion or limitation on how long an
implied warranty will last or the exclusion or limitation of incidental or consequential
damages. This warranty gives you specific legal rights, and you may also have other
rights, which vary State to State.
Firstech, LLC. is not RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER,
INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL
DAMAGES, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL
LOSS, LOSS OF ECOMONIC OPPORTUNITY AND THE LIKE that may or may not result-
ed from the operation of Compustar. NOTHWITHSTANDING THE ABOVE, MANUFAC-
TURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-
TROL MODULE AS DESCRIBED ABOVE.
Page 4 Page 5
Limited Lifetime Consumer Warranty
![](/img.php?id=772089&img=bg4.png)
Under normal circumstances, Reservation Mode is cancelled
when a door or hatchback opens. Please verify if the opening of any door or
hatchback cancels Reservation Mode. If any of the doors or hatchback is not
monitored by CompuStar because of improper installation or a faulty dome light switch,
do not use the CompuStar and take your vehicle to the dealer immediately for repair.
Do not set Reservation Mode when the window(s) are open or if there is anyone
inside of the vehicle including animals.
This system requires no specific maintenance. Your remote-pager is powered by a single
AA battery that will last approximately one month under normal use depending on the
make and model of your vehicle. There is a battery icon in the lower right corner of the
CompuGLO LCD indicating remaining battery life. When the battery weakens, the
operating range will be reduced and the CompuGLO LCD will dim. Contact your
authorized CompuStar dealer if you have additional questions.
The product s warranty is automatically void if its date code or serial number is defaced,
missing or altered. This warranty will not be valid unless you have completed the regis
tration card and mailed it to Firstech, Inc., within 10 days after the purchase to the
address listed on the registration card.
Your Warranty
Congratulations on the purchase of your high-tech vehicle security system and remote
auto-starter. This system has been designed to provide years of trouble-free operation.
Due to the complexity of the system, it must only be installed by an authorized
CompuStar dealer for full warranty and technical support. Installation of this product by
anyone other than an authorized dealer voids the warranty.
The owner s guide should help you to get the most out of your system. Please take
time to read it thoroughly prior to using this system. Additional replacement copies of this
manual are available for downloading at www.compustar.org.
Important Information
System Maintenance
Please take these safety precautions under the following conditions:
1. Servicing the vehicle
When servicing (i.e. changing the oil, washing your car) your automobile, the CompuStar
system should be in Valet Mode. There is a safety shutdown switch under the hood that
deactivates the remote starter function if the hood is open. However, if the switch has
been damaged or the switch has been installed improperly, the vehicle may start when
Button II is pressed for 2 seconds even if the hood is open.
2. Loaning your vehicle to others
Whenever you loan your vehicle to an individual who is not familiar with Compustar,
please put the vehicle in Valet mode. This will prevent the vehicle loaner from accidental-
ly activating the CompuStar auto-security system.
3. For manual transmission vehicles
If the Compustar 2WSSR is installed in a manual transmission vehicle, extra precautions
are required because the Compustar does not monitor the gear shift :
Safety Information
Page 6 Page 7
Important!
The model name, 2WSSR, stands for Two Way Spread Spectrum Remote with
Liquid Crystal Display. This 5-channel transmitter that allows you to activate multiple
functions by pressing a combination of 4 buttons on the unit in order to transmit signals.
REMOTE-PAGER : 2WSSR w/LCD
The remote-pager comes with CompuGLO which is a unique color LCD display that
visually tells the vehicle owner the security status of your car at all times. There are
differing icons that will appear on your CompuGLO LCD indicating what your vehicle is
currently doing.
CompuGLO color LCD
(Liquid Crystal Display)
![](/img.php?id=772089&img=bg5.png)
Page 8
Shock
Turbo
Timer
Passive
Indicates if the Shock Sensor is on or off. See page 12.
Indicate if Turbo Mode is on or off. See page 17.
Indicates if Timer Start Mode is on or off. See page 16.
Indicates if Passive Arming Mode is on or off. See page 17.
Icon Explanation
Indicates that the second stage shock sensor has been triggered.
If the icon appears continuously, you are in mute(vibration) mode. If the
icon blinks, the first stage shock sensor has been triggered. See page 15.
Indicates if you are in Valet Mode. See page 15.
Indicates if your car parking lights are flashing.
Indicates that your car siren is turned on or off when you lock or
unlock the vehicle.
Indicates that someone is paging you from your vehicle.
Displays if your car is locked or unlocked.
Indicates if your remote-pager is transmitting signals to the controller unit.
Displays remaining battery life.
Displays if your door is open.
Displays if your vehicle has auto-started properly or ignition on.
Displays if your trunk is open.
Page 9
Remote-Pager Button Functions
1
2
3
4
5
6
7
8
9
10
11
12
13
I
II
III
IV
I
-
II
-
III
-
IV
-
( I+ II)
( I+ III)
( II+III)
(II+ IV)
(III+IV)
( I + III)
-
14
15
16
17
1/2 sec
1/2 sec
1/2 sec
1/2 sec
2 sec
2 sec
2 sec
2 sec
1/2 sec
1/2 sec
1/2 sec
1/2 sec
1/2 sec
2 sec
Alarm Mode - on/off, RPS - on/off
Auxiliary Option 1
Auxiliary Option 2
Query Function
Alarm Mode - on/off, RPS - on/off
Auto-start Function - on/off
Trunk Release - on/off
Panic Mode
Car Siren for Lock/ Unlock-on/off
Valet Mode - on/off
Passive Arming - on/off
Timer Start Mode - on/off
Turbo Mode - on/off
On
Off
Off
Off
Off
On
Off
Shock Sensor – on/off.
( II + III)
-
2 sec Mute mode (Vibration only) – on/off.
( I + II)
-
2 sec Programming Menu 1
( I + III)
-
2 sec Programming Menu 2
Button
Channel
Press for
Function
Factory
Setting
Note :
"
( )
"means simultaneously pressing the buttons
"
( )
-
" means simultaneously pressing the buttons for 2 seconds.
The user can activate differing functions of CompuStar 2WSSR system by pressing
one or two buttons simultaneously (ex.(
I
+
IV
) ) located on the antenna side of your
Compu Star remote-pager.
![](/img.php?id=772089&img=bg6.png)
Page 11
Remote-Pager Factory Reset Procedure
USING YOUR SYSTEM
You can reset the remote-pager by removing the AA battery and reinsert it back into the
remote-pager. Please perform this procedure in close proximity to the vehicle.
Your CompuStar 2WSSR system has many different modes and functions that can be
activated by using your remote-pager unit.
Alarm Mode
You can arm or disarm alarm mode by pressing Button
I
for a second or 2 seconds.
A bolted padlock icon will appear on your CompuGLO LCD indicating that your car is
armed and a lock icon will appear showing that your car doors are locked. Also, your
car will chirp when you arm or disarm your car.
Press Buttons (
I+II
) for a second to make your car siren mute when arming or
disarming your vehicle. A car siren icon will disappear on the bottom left-hand corner
of your CompuGLO LCD indicating that you are in car siren mute mode.
Keep in mind that your car siren will still activate for all other modes (i.e. panic, alarm,
shock sensor) regardless of whether or not your car siren is in mute mode.
The car siren will be mute only when arming or disarming your vehicle.
When alarm mode is armed, the following will trigger the remote-pager security alerts :
Unauthorized car door opening will activate the car siren for 30 to 60 seconds and
the parking lights will flash for 60 seconds. The remote-pager will be notified audibly,
vibrate and the door icon will appear in the CompuGLO LCD. Press Button
I
for a
second to turn off the car siren and flashing lights. Repeat this step ( press
Button
I
for a second ) again to disarm alarm mode.
Unauthorized trunk door opening will activate the car siren for 30 to 60 seconds and
the parking lights will flash for 60 seconds. The remote-pager will beep, vibrate and
the trunk door icon will appear in the CompuGLO LCD. Press Button
I
for a
second to turn off the car siren and flashing lights. Repeat this step ( press Button
I
for a second ) again to disarm alarm mode.
Page 10
Remote-Pager Learning
1.
Remote Learning :
Take the AA battery out from the remote.
Turn the key on/off 5 times. If you hear a
relay clicking sound, you are in the learning
mode. Then, put the battery in.
You will hear a clicking sound once, that
means the controller module learned the
remote. Soon, you will hear two relay clicking
sounds, that means the controller is exiting
the learning mode. A few seconds later,
you will hear a confirmation beep from the
remote. If you do not hear the confirmation
within 20 seconds after you put the battery
in, Remove the battery, and put it back in
without cycling the ignition on/off 5 times.
2.
Replacing a battery :
Whenever you replace a battery, do so within
the transmitting range between the remote
and the antenna. If you take the battery out,
the synchronization between the antenna and
remote is broken. When you put the battery in,
the remote will attempt to synchronize with the
antenna. Within a few seconds the remote
will confirm with two beeps indicating synchro
nization has been completed. If you do not
hear any confirmation beeps within 20
seconds, you will have to remove the battery
and put it back in.
![](/img.php?id=772089&img=bg7.png)
Dual Stage Shock Sensor
The dual stage shock sensor on the CompuStar 2WSSR can detect between light and
heavy impact to your vehicle by sensing vibration produced by differing impacts.
Press Buttons (
I+III
) for 2 seconds to activate or deactivate the dual stage shock sensor.
A red-bordered indicator box labeled Shock will darken in the top left-hand corner of your
CompuGLO LCD showing that your dual stage shock sensor is activated.
The dual stage shock sensor will activate 30 seconds after the CompuStar alarm mode
is armed. When the dual shock sensor is engaged, the remote-pager security alerts will
be triggered by the following :
Light impact to your vehicle will activate the first stage shock sensor and the car
siren will chirp 4 times in addition to the parking lights flashing 4 times.
The remote pager unit will beep and a vibration icon will blink in the CompuGLO LCD.
Heavy impact to your vehicle will activate the second stage shock sensor and the car
siren will chirp for 30 to 60 seconds and the parking lights will flash for 30 to 60 seconds.
The remote-pager will be notified audibly and a hammer icon will blink in the Compu
GLO LCD. Press Button
I
for a second to turn off the second stage shock sensor
sirens and flashing lights.
Note :
You may want to deactivate the dual-stage shock sensor if you park your
vehicle where there is significant vibration.
Press Button
II
for 2 seconds to auto-start an automatic transmission engine.
You will hear one beep from your remote-pager if there is successful communication
with your vehicle. The engine will start and give you a visual confirmation by an exhaust
fume icon coming out from the tailpipe on the remote-pager CompuGLO LCD.
Remember that a manual key in the ignition is required to drive the car. In addition, the
anti-grind circuit (this maybe an optional feature provided by your installer) prevents
you from re-cranking the starter on a remote-started vehicle. Press Button
II
for 2
seconds in order to turn off an auto-started car. For manual transmission vehicles,
please use reservation mode.
The engine will run 15 or 25 minutes (25 or 40 min for diesel) depending on preset
options at the time of installation, and then shut off. If your remote-pager has a problem
starting the vehicle, the CompuStar controller will try 2 additional times. If the engine
does not start after the third attempt, please call your authorized CompuStar dealer.
Diagnosing problems with Auto-Start
If there is a problem in auto-starting your car, you will hear three chirps when you attempt
to auto-start the car. Wait for 2 seconds and the cause for the error will be indicated by
the number of times the car chirps and parking lights flash.
Page 12 Page 13
Auto-Start Function
In alarm mode, the starter kill function ( this maybe an optional feature provided by
your installer) is activated. This feature disengages the starter mechanism on your car
that prevents you from starting your car even with a manual key when your vehicle s
alarm mode is activated.
Note :
(Siren duration is 30 to 60 sec depending on the options set at the time
of initial installation.)
1
2
3
4
5
6
7
Error Number (# of times the
car chirps& parking lights flash) Error Reason
Engine On
Key On
Door Open
Trunk Open
Brake On
Hood Open
Reservation Off (Manual Transmission Only)
Panic Mode allows the owner to draw attention to the car in case of an emergency or in
order to easily locate your vehicle in a large parking lot. Press Button
IV
for 2 seconds
on the remote-pager to enter Panic Mode. In this mode, the car will arm if not armed
already and the siren will activate and the parking lights will flash. In order to disengage
Panic Mode, press Button
IV
for 2 seconds. Then, press Button
I
for a second to
unlock/ disarm your vehicle.
Panic Mode
![](/img.php?id=772089&img=bg8.png)
Page 14
Your vehicle is now ready for auto-starting. However, the reservation mode will be can
celled if the door is opened or the CompuStar system is put in Valet mode after the re
servation has been set. Once cancelled, you will have to start the vehicle with the manual
key and repeat the above 5 steps if you want to restore reservation mode.
In order to auto-start your manual transmission car, you must first set the CompuStar
system to Reservation Mode before leaving your vehicle. The purpose of Reservation
Mode is to leave the transmission gear in the neutral position when you leave your vehicle.
Reservation mode is intended for use in MANUAL TRANSMISSIONS ONLY and NOT
FOR AUTOMATIC TRANSMISSIONS. Reservation Mode must be engaged each and
every time you leave your manual transmission car in order to auto-start the vehicle.
Note :
The system is not recommended for vehicles with removable tops.
ᵉ
Important Requirements to activate Reservation Mode
⍥The transmission must be in the NEUTRAL position.
⍥The vehicle windows must be rolled up.
⍥Do not set the reservation mode with people in the vehicle.
⍥Do not auto-start the car with people in the vehicle.
ᵉ
Activating Reservation Mode (MANUAL TRANSMISSION ONLY)
Step1 :
After arriving at your destination, and BEFORE TURNING YOUR
ENGINE OFF, place the transmission in the Neutral position.
Step2 :
Remove your foot from the foot brake.
Step3 :
Activate the parking brake.
Step4 :
Remove the key from the ignition. The engine will remain running.
Step5 :
Exit the vehicle and close the door within two minutes after activating
the parking break. The engine will shut off and reservation mode for
the remote starter is now complete.
Reservation Mode
(manual transmission only)
Important!
If you try to auto-start the vehicle when reservation mode has
not been set or turned on, the auto-start feature will not work.
When you press the auto-start button, the car parking lights will flash three times
and the door icon in the CompuGLO LCD will be flashing to inform you that reserva-
tion mode has not been set.
Page 15
ᵉ
Canceling Reservation Mode
If you do not want to set reservation mode, shut off the engine before you exit the
vehicle. The engine will shut off for the following reasons :
⍥You did not activate the parking brake or pressed the foot brake when you
turned the manual key to the off position.
⍥You released the parking brake while the engine was running.
⍥You entered Valet Mode after the Reservation Mode has been completed.
Trunk Release
Press Button
III
for 2 seconds in order to unlock and release your trunk door.
Note that the trunk release function will not only release the trunk but will unlock all the
doors as well.
Query Function
Query Function allows the owner to visually monitor the status of your car by looking at
the remote-pager CompuGLO LCD icons. Press Button
IV
for a second to activate
the Query Function.
Vibration Mode
If the vibration mode is turned on, the Remote-Pager will vibrate instead of beep only
when one of the entry points or shock sensor inputs is triggered. You can turn vibration
mode on or off by pressing Buttons (
II
+
III
)for 2 seconds.
Car Siren
The car siren chirps once for lock and twice for unlock. You can delete this audible
chirping by pressing Buttons (
I
+
II
) for a second and the car siren icon will disappear
on the CompuGLO LCD.
Valet Mode is intended to deactivate most of the features of your CompuStar 2WSSR
system especially the security alerts/monitoring and remote starting. The only feature
operating in valet mode is the keyless entry function and optional auxiliary functions.
Valet Mode
![](/img.php?id=772089&img=bg9.png)
Page 16 Page 17
This mode allows a valet to operate your car with your authorization without him or her
triggering all the security features or remote-starting your vehicle. Also, Valet Mode is
very useful when washing your vehicle or having it serviced.
In order to enter Valet mode, press Buttons (
I+III
) simultaneously for a second.
The remote-pager CompuGLO LCD will display a ZZZ icon indicating that you are in Valet
Mode. In order to manually enter Valet Mode, insert your car key into the ignition and turn
the ignition on and off five times within 10 seconds.
See the illustration below for a typical ignition harness of a vehicle.
In Timer Start Mode, your car automatically starts every 1.5 or 3.0 hours depending on
preset options during the time of installation for a 24-hour period. This mode is deleted
automatically after 24 hours or once you start your car with either your manual key or
remote-pager. In order to enter Timer Start Mode, press Buttons (
II+IV
) simultaneously
for a second.
You can exit Valet Mode only by pressing Buttons
(
I+III
) simultaneously for a second.
Timer Start Mode
A red-bordered indicator box labeled Timer will darken on the top of your CompuGLO
LCD demonstrating that you are in Timer Start Mode.
Press Buttons (
II+IV
) simultaneously for a second to exit Timer Start Mode.
Timer Start Mode is automatically cancelled when you start the vehicle with the key
or by remote.
Also, note that Timer Start Mode becomes Cold Start Mode once an optional
temperature sensor is installed. See page 18 for more details.
Important!
Timer Start Mode should be used only in open areas.
Never start and run the vehicle in an enclosed space such
as a garage or carport.
OPTIONAL PROGRAMMABLE FEATURES
These additional programmable features can be programmed to the CompuStar
system by your authorized CompuStar dealer.
Passive Arming
You can turn this function on or off by pressing Buttons (
II+III
)for a second.
When set to passive arming, your security system will arm automatically 30 seconds
after all the car doors are closed. There are two types of passive arming that can be
programmed by your CompuStar dealership : (1) passive arming with passive lock and
(2) passive arming without passive lock.
Passive locking means the door will lock when the system passively arms. In the default
factory setting, the system is armed and locked actively which means the system will only
arm/lock when the remote-pager is utilized.
Ignition Lock
This programmable option enables your vehicle to automatically lock the doors upon
pressing the brake pedal after the vehicle has been started with a key. In addition, the
vehicle will automatically unlock the doors upon pulling the key out from the ignition.
This option must be chosen at the time of installation.
Safety Shut Down Features
If this optional Turbo Mode has been programmed at the time of installation,
you can turn this feature on and off by pressing Buttons (
III
+
IV
)for a second.
Under this mode, engine continues running for 2 minutes after key has been taken out
from the ignition if emergency brake was on when the key is taken out. To utilize this
mode, the emergency brake sensing wire has to be connected to the emergency brake
wire of the vehicle. Consult the authorized dealer for this mode.
Turbo Mode
![](/img.php?id=772089&img=bga.png)
Page 18 Page 19
Cold Start Mode
If the optional temperature sensor has been installed, Timer Start Mode becomes
Cold Start Mode. Under this mode, your car automatically starts if the temperature of the
inside of the vehicle goes below the preset temperature. The minimum interval between
the starts will be 1.5 or 3.0 hours depending on preset options during the time of installa-
tion. Cold Start Mode is activated or deactivated by pressing Buttons (
II
+
IV
)for a
second.
Optional Auxiliary 1 & Auxiliary 2
The auxiliary system is an optional car feature that can be tailored for your vehicle by
your local authorized CompuStar dealership. The auxiliary feature allows you to
customize the buttons on your remote-pager to add more functionality to your car.
For example, you can customize your car to have remote power control of your windows,
radio, and sunroof in addition to the rooftop on your convertible car. The remote-pager
has two outputs (Aux 1 & Aux 2) that can be custom utilized with optional features.
Please contact your local authorized CompuStar dealer for more information.
RPS (Remote Paging System)
The RPS is a feature that allows an individual to page the owner of a vehicle by simply
tapping on the front windshield of the car. RPS is automatically turned on upon
activating alarm mode (pressing Button
I
for a second) on the CompuStar 2WSSR.
The RPS module is a single sensor on the outside edge of your driver s side front win-
dow shield that can be activated by tapping a manual key producing a high-frequency
vibration. This high-frequency vibration is detected and your remote-pager will beep and
a telephone icon will appear on the CompuGLO LCD indicating that someone is paging
you from your vehicle. Press Button
I, II
,
III
or
IV
for a second to deactivate the
RPS visual and audible paging alerts.
OPTIONAL INSTALLATON FEATURES
The CompuStar 2WSSR remote-pager has additional features and expansion
possibilities that require additional parts and labor. CompuStar 2WSSR system has several shut down safety features.
The following actions will shut down the engine or prevent the car from auto-starting :
⍥Opening of the car engine hood.
⍥Pressing of the car engine break.
⍥Valet mode is turned on.
Q : Is the CompuStar Remote compatible with an existing alarm or auto-start system ?
A : The CompuStar transmitter is not compatible with other systems due to our unique
Spread Spectrum frequency modulation. It is proprietary to CompuStar.
Q : Is there a monthly charge for the remote-pager ?
A : No, the CompuStar system is based on Spread Spectrum modulation with up to a
1.25 mile transmitting and receiving distance without a monthly fee.
Q : How can I find the nearest Authorized CompuStar Dealer in my area ?
A : CompuStar dealers have expanded worldwide in over 24 countries. Finding a
dealer near you is as easy as a toll-free call to our customer support telephone
number at 888-820-3690 or via email to dealerlocator@compustar.org.
Q : What is the warranty coverage on a CompuStar system ?
A : There is a Limited lifetime warranty on the brain as installed by an Authorized
CompuStar Dealer (US and Canada Only), and the remote-pager device s
warranty is one year from the date of purchase.
Q : What type of battery does the remote-pager use and how long will it last?
A : The remote-pager uses a standard AA battery and will last typically 1 to 2 months
with normal use depending on the frequency of use and features used, i.e.: vibration
mode.
Q : Can I buy the CompuStar through the Internet ?
A : All Internet sales of CompuStar are prohibited and all applicable warranties and
registration will be voided and no technical support will be offered.
Safety Shut Down Features
Frequently Asked Questions
![](/img.php?id=772089&img=bgb.png)
First, check to see if you have enough battery life in remote-pager unit by looking at the
battery life indicator icon in the bottom right hand corner of your CompuGLO LCD screen.
Replace your battery if indicated. A standard AA battery will last 1 to 2 months depending
on usage and the paging mode you choose. i.e.: Vibration mode. You will notice a loss
of transmitting distance and backlight function with declining battery life.
Second, take the battery out and reinsert within a 10 second period. You have just reset
the computer chip of the remote pager. This may happen sometimes, not always, if your
remote becomes out of sync.
Third, in rare instances, a power surge and/or electrical shock will disable the CompuStar
system when servicing your vehicle. This brief moment of increased electrical power to
the CompuStar brain will erase all the programming functions of your system.
In this case, you must reprogram the remote-pager unit to learn the CompuStar brain.
Read page 10 for the remote-pager learning procedure.
Otherwise, the most likely cause is that the radio frequency mechanism inside your
remote-pager that transmits the 900 MHz frequency is damaged. Physical damage such
as dropping the remote-pager is usually the cause of the crystal not working. In this
case, you must get a new remote-pager by contacting your nearest CompuStar autho-
rized dealer for a replacement.
My automatic transmission car is not auto-starting remotely.
Most likely, you did not push Button
II
for the required 2 seconds. Pushing Button
II
for
only a second engages the optional auxiliary function instead of auto-start.
Another reason maybe that you are in Valet Mode. If there is a ZZZ icon on your remote-
pager unit, you are in this mode and all the functions of the CompuStar 2WSSR are dis
abled except for keyless entry. Press Button (
I
+
III
)simultaneously for a second to
deactivate Valet Mode.
If there is a problem in auto-starting your car, you will hear three chirps from your remote-
pager when you attempt to auto-start the vehicle. After waiting two seconds, the diagno-
sis for the auto-start error will be indicated depending on the number of times the car
chirps and parking lights flash. For example, 4 car chirps and parking light flashes
indicates that the car did not auto-start because the trunk was open. Please see page 13
of the user s manual for the error diagnosis table.
Page 21
Troubleshooting
I cannot turn off Panic Mode s car siren and flashing parking lights.
In order to turn off Panic Mode, press Button
I
for a second to disengage the car
siren and flashing parking lights. However, the car is still armed in alarm mode. You must
press Button
I
for a second again to disarm alarm mode and unlock your doors.
I cannot turn off Alarm Mode s car siren and flashing parking lights.
In order to turn off Alarm Mode, press Button
I
for a second to disengage the car
siren and flashing parking lights. However, the car is still armed in alarm mode.
You must press Button
I
a second again to disarm alarm mode and unlock
your doors.
I keep banging on my car but my dual stage shock sensor will not work.
First, check to see that the dual stage shock sensor is activated by observing that a red-
bordered indicator box labeled Shock that is darkened in the top left-hand corner of your
CompuGLO LCD. If the indicator box is not darkened, your dual stage shock sensor is
not activated.
Turn on the dual stage shock sensor by pressing Button (
I
+
IV
) simultaneously for a
second. Note that the dual stage shock sensor will only activate 30
seconds after the alarm mode is armed. Press Buttons (
I
+
IV
) simultaneously for a
second to deactivate the dual stage shock sensor.
My remote pager is not working. I press all the buttons and nothing happens.
I am sure that I am within the transmitting range.
Q : Are the 2W Series, 2000 Series and SST Series compatible with each other ?
A : Unfortunately, the three systems are not compatible with one another due to the
advances in the technology and use of additional features.
Q : Will the CompuStar Auto-start system work safely on a manual transmission vehicle?
A : Yes, the CompuStar system will operate safely on manual transmission vehicles with
the proper and professional installation at your Authorized CompuStar dealer.
However, this installation procedure is entirely up to the dealer.
Page 20
![](/img.php?id=772089&img=bgc.png)
My manual transmission car is not auto-starting remotely.
Most likely, you did not push Button
II
for the required 2 seconds. Pushing Button
II
for
only a second engages the optional auxiliary function instead of auto-start.
For manual transmission cars, the vehicle must be in reservation mode before you can
auto-start your car remotely. If your remote-pager door icon flashes and beeps three
times along with your car s parking light flashing three times when you try to auto-start
your manual-transmission car, reservation mode has not been set. Please see page 11
of this manual for instructions and important requirements to activate reservation mode.
Another reason maybe that you are in Valet Mode. If there is a ZZZ icon on your remote-
pager unit, you are in this mode and all the functions of the CompuStar 2WSSR are dis-
abled except for keyless entry. Press Button (
I
+
III
) simultaneously for a second to
deactivate Valet Mode.
If there is a problem in auto-starting your car, you will hear three chirps from your remote-
pager when you attempt to auto-start the vehicle. After waiting two seconds, the diagno-
sis for the auto-start error will be indicated depending on the number of times the car
chirps and parking lights flash. For example, 4 car chirps and parking light flashes indi-
cates that the car did not auto-start because the trunk was open. Please see page 13
of the user s manual for the error diagnosis table.
My car is armed in alarm mode and my remote-pager is not working or I do not have my
remote-pager. How do I avoid triggering the CompuStar starter kill function so I can drive
my car ?
Unlock the car door with your manual key, which will trigger the car s siren and parking
lights. You must manually override the CompuStar security and auto-start functions by
putting the car into Valet Mode. This mode will disable all the functions of the CompuStar
except for keyless entry.
In order to enter Valet Mode, cycle the ignition key from the off position to the on position
5 times within a 10 second period. You are now in Valet Mode and have disabled the
CompuStar 2WSSR security system except for keyless entry.
I keep banging on my RPS (remote paging system) sensor but it is not working.
RPS sensor is usually located on the outside edge of the driver s side front window
shield and detects high frequency vibration. Therefore, in order to properly activate RPS,
the user must produce a high-frequency sound by tapping with a car key where the RPS
sensor is located. Simply pounding on the front windshield with your hand will not pro-
duce the required high frequency vibration and therefore will not activate the RPS
system.
How do I deactivate my RPS audible and visual (telephone icon) paging alerts on my
remote-pager?
Press Button
I
,
II
,
III
or
IV
for a second to deactivate the RPS paging alerts.
My remote pager unit is not beeping audibly when I push the buttons.
Check to see if you are in remote-pager vibration mode by observing a vibration icon
that appears continuously in the upper left-hand corner of your CompuGLO LCD screen.
Press Buttons (
II
+
III
) for 2 seconds to deactivate vibration mode and the vibration icon
will disappear.
My car is not chirping when I arm or disarm alarm mode.
Check to see if you are in silent arm/ disarm mode by observing a car siren icon in the
bottom left-hand corner of your CompuGLO LCD Screen. Press Buttons (
I
+
II
)for a
second to deactivate the car siren when arming/disarming your vehicle and the car siren
icon will disappear. Keep in mind that your car siren will still activate for all other modes
(i.e. panic, alarm, shock sensor, etc) regardless of whether or not your car siren is in
mute mode.
Page 22 Page 23
