1480412R-CGO2-User Manual



CGO2UserManual



TABLEOFCONTENTS

Systemrequirements(windows)

Systemrequirements(Mac)

Technicalspecifications

Introduction

Overview

Gettingstarted

Defaultcamerasettings

PoweringONandOFF

Cameramodes

Video

Photo

Transferringfiles

CGO2smartphoneFPVapp

UsingST24tocontrolCGO2

Safetywarnings

Warranty

Aboutthequickstartmanual



SYSTEMREQUIREMENTS(Windows)

WindowsXP(ServicePack2orlater)orvista

3.2GHzPentium4orfaster

Minimum1GBofsystemRAM



SYSTEMREQUIREMENTS(Mac)

MacOS×10.4.11orlater

2.0GHzIntelCoreDuoorfaster

Minimum1GBofsystemRAM



TECHNICALSPECIFICATIONS

DimensionsL×W×H(withlensandwithoutmushroomantenna):65.1×45.5×33.5mm

Weight:80.5g(withmushroomantenna）

Battery:1050mAh1‐Cell3.7V

Li‐Po

WorkingVoltage:3.7‐4.2V

OperatingTimePerCharge:60min‐90min(basedonWi‐FiEnvironment)

MicroSDHCSDClass4:4GB‐128GB

OpticalZoom:fixedfocus

PhotoResolution/Format:16MP/JPEG

Resolution/FPSVideoRecording:1080P/60p

DownlinkResolution/FPS/Latency:720P/30FPS/200ms

VideoFormat:MP4(H.264)

AudioFormat:AAC

Internal‐Microphone:included

Wi‐FiFrequency:5.8GHz

Wi‐FiPower:16dBm

Antenna:Ext.‐MushroomType

CommunicationDistance:upto1700feetwithST24

CommunicationChannel:149,153,157,161,165

Frequency:5745‐5826MhZ

LensSensor:16M

FieldofView:155°

WhiteBalance:Automaticwhitebalance

FocusingSystem:FixedFocus

StorageTemperature:‐20°C‐60°C

WorkingTemperature:0°C‐40°C



INTRODUCTION:

CGO2isahigh‐resolutioncamera(1080p/30FPS)specificallydevelopedbyYuneecforsmallUAVs.

Thecompactandlight‐weightCGO2issuitableforhighqualityfirstpersonview(FPV)foranarray

offlyingplatforms.CGO2includeslongrangeandlow‐latencydigitalWi‐Fivideolink（LINK还是

downlink?）,providinguserswithahighdefinition,portablereal‐timevideosolution.CGO2can

beremotelycontrolledbyYuneec'sPersonalGroundStations‐ST24/ST15,CGO2'svideodownlink

performancereachesnearly1700feet.



Overview:



modelight

shutterbutton

modebutton

MIC

MicroUSB5pinconnector(usedfor

charging(5V/500mA)anddata

readingandwriting

MicroHDMIoutputport(usedtobe

connectedwithHDMIcablefordata

reading)



batteryhouse

Tcardslot

WIFIindicationlight

powerindicationlight



POWERINGONANDOFF

TopowerON:Shortpresstheshutterbuttonandthethreeindicatorlightsflash,thenthepower

indicatorlightflashes.AfterWi‐Fiison,Wi‐Fiindicatorlightflashes.



TopowerOFF:Continuepressingtheshutterbuttonuntilthethreeindicatorlightsturnoff.



Tostartrecording:Afterpoweringon,continuepressingVideo/Photobuttonuntilitflashes.(PS：

recordingcanalsoperformwithWi‐Fioff)



TotakeaPhoto:afterpoweringonorduringvideorecording,pressvideo/photobuttonandthe

indicatorlightglowsfor2second,thenphotoistaken.(PS：recordingcanalsoperformwithWi‐Fi

off)

Mushroom

antennaport

toopenthebattery

house



Wi‐FiConnectBuilding:

Afterpoweringon,iftheWi‐Fiindicatorlightglowssolid,SSIDofCGO2‐XXXXXXwillbesearched.

Connectingpassword:1234567890



Pictureoverview:AfterconnectingWi‐Fi,openVLCplayermedia‐opentheinternetserialinput

rtspaddress:rtsp://192.168.42.1/live,click"play"andthentheplayershowsrealtimevideos.

PS:Wi‐Fioverviewneedstobebuiltforthecertificationtester.



Channelmodification:

1)Macofthetwoprototypesaresetrespectivelyas00E04C1BD511and00E04C1BD522and

theirrespondingSSIDdefaultareCGO2_1BD511andCGO2_1BD522.

2)TwoTcardswithover4Gareneeded.Acommoncardisforbiddensothatitwouldn'tleadto

SSIDchaos.BeforeinsertingTcard,bothshouldbeformat,thendefaultSSIDwillbeused.

3)Therearealtogetherfivevaluestomodifythechannels,whichare149,153,157161,165.The

ruleisadifferencevalueof4.

4)TherouteofchannelmodificationisTcardMISC/wireless.conffile.Thesecondlinefromthe

endWUCHAOFAN=149.Defaultis149,



IMPORTANTNOTE:

PleasemakesurethecameraispoweredoffwhenyouremovetheMicroSDcard.Removingthe

MicroSDcardpriortopoweringthecameraoffmayleadtofilelossorcorruption.Alsomakesure

to"stoprecording"priortopoweringoffyourCGO2toensureyourvideoisproperlystoredinthe

MicroSDcard.Additionally,beforepoweringoffyourCGO2,werecommendpressingandholding

theSHUTTERButtonfor2secondsuntiltheVideo/PhotoandWi‐Fiindicatorlightsflash.This

stepwillhelppreserveyourpreviousphoto/videofiles.



SAFETYWARNINGS:

1.Makesurethecameraispoweredoffwhilecharging.

2.Pleaseavoiddirectlytouchingthealuminumalloybackcover.WhenCGO2isworkingwith

Wi‐Fion,thecamerabodymaybecomehottotouchbecauseofthehigh‐performancenatureof

theproduct.CGO2'saluminumalloybackcoverisspeciallydesignedtohelpdissipateheatunder

normaloperatingconditions.



CAUTION:RiskofexplosionifCGO2batteryisreplacedbyanincorrectbattery.UseonlyYuneec's

CGO2batterythatisspeciallydevelopedfortheCGO2.Disposeofbatteriesaccordingtoyour

locallaws.



Thissymbolmeansthataccordingtothelocallawsandregulationsyourproductshouldbe

disposedofseparatelyfromhouseholdwaste.Whenthisproductreachesitsendoflife,takeitto

acollectionpointdesignatedbylocalauthorities.Somecollectionpointsacceptproductsforfree.

Theseparatecollectionandrecyclingofyourproductatthetimeofdisposalwillhelpconserve

naturalresourcesandensurethatitisrecycledinamannerthatproductshumanhealthandthe

environment.



WARRANTY

LimitedWarranty

Yuneecwarrantsthatforaperiodofone(1)yearfromoriginaldateofpurchase,theproductwill

befreefromdefectsinmaterialsandworkmanshipundernormaluse.Intheeventofadefect,

pleasecontactYuneecCustomerSupport(www.Yuneec.com)forassistance.Yuneec'ssole

obligationunderthiswarrantywillbe,atitsoption,torepairorreplacetheproduct.This

warrantydoesnotapplytoproductsdamagedbymisuse,accident,waterdamageornormal

wearandtear.Yuneecdisclaimsallotherexpressedorimpliedwarrantiesorconditions.Tothe

extentnotprohibitedbylaw,innoeventwillYuneecbeliableforanylossofdata,revenueor

profit,orforanyspecial,indirect,consequential,incidentalorpunitivedamages,howevercaused,

arisingoutoforrelatedtotheuseoforinabilitytousetheproduct,evenifYuneechasbeen

advisedofthepossibilityofsuchdamages.InnoeventwillYuneec'sliabilitiesexceedtheamount

paidbyyoufortheproduct.Somejurisdictionsdonotallowlimitationsonhowlonganimplied

warrantylasts,orexclusionsmaynotapplytoyou.Thiswarrantygivesyouspeciallegalrights,

andyoumayalsohaveotherrights,whichvarybyjurisdiction.



ABOUTTHEQUICKSTARTMANUAL

Yuneecreservestherighttoupdatemanuals,quickstartguidesandwarrantyinformationatany

time.Forthelatestmanualandquickstartinformation,aswellaswarrantyinformation,please

visitYUNEEC.COM.



FCC Statement:

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforPart15oftheFCCrules.

Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceina

residentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergy

and,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterference

toradiocommunications.

However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthis

equipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbe

determinedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe

interferencebyoneormoreofthefollowingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmenttoanoutletonacircuitdifferentfromthattowhichthereceiveris

connected.



Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwo

conditions:

(1) Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptany

interferencereceived,includinginterferencethatmaycauseundesiredoperation.



CAUTION:

Any changes or modifications not expressly approved by the grantee of this device

could void the user's authority to operate the equipment.

RF exposure warning

·This equipment must be installed and operated in accordance with provided

instructions and the antenna(s) used for this transmitter must be installed to provide a

separation distance of at least 20 cm from all persons and must not be co-located or

operating in conjunction with any other antenna or transmitter. End-users and

installers must be provide with antenna installation instructions and transmitter

operating conditions for satisfying RF exposure compliance.

IC Radiation Exposure Statement for Canada

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including interference

that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux

appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions

suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de

l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est

susceptible d'en compromettre le fonctionnement.


