Yunmai Technology M1680 Yunmai SE Smart Scale User Manual SE YUNMAI2
SHENZHEN YUNMAI TECHNOLOGY CO., LTD. Yunmai SE Smart Scale SE YUNMAI2
User Manual
YUNMAI SE
Smart Weight Scale Instructions
Product Introduction and Installation 1 Install YUNMAI App on your phone
Thank you for choosing YUNMAI SE Search “YUNMAI” in the Android Application Market or the iOS App
Store or scan the following QR Code to download, install it and it
will get connected to the scale once turned on.
Concealed Display Screen
Battery Cover
① Note: Remove the battery insulation to start
Scale Foot
Surface
Scan QR code
Download <YUNMAI App>
Note: To ensure the accuracy please stand on the scale barefoot with
the right posture.
3 Start Using
Set each foot on each side of the central point naturally as shown
below:
Correct
Each foot on each side of
the central point naturally
Wrong
Feet go out of the verge
may affect the accuracy
Wrong
Stand in wrong direction
will shield the screen
Wrong
Feet not in a line may affect
the accuracy
Display Screen Product Specifications
Warning
Body Mass Index comparison table
Mobile Device Support
Maintenance
Warranty
Bluetooth
Low battery
indicator
Weighing figures
Pounds
Kilograms
Body Mass Index (BMI) = weight (kg) ÷ height ^ 2 (m)
For example: BMI = 70kg ÷ (1.75m × 1.75m) = 22.86，belongs to the
normal range.
Note: BMI Index is a standard that is widely used to judge a person’s
health condition.
iOS8.0 and above
iPhone 4S /5/5S /6/6 Plus/SE/6S/6S Plus /7/7 Plus/iPod touch /iPad
Android 4.3 and above with Bluetooth 4.0
Use a wet cloth to clean the scale. Do not use any detergent and don’t
use water to wash it directly.
YUNMAI SE guarantees a year of technical support and hardware
warranty.
Do not disassemble, squeeze, puncture the product or put it into water,
fire, or exposes it to temperature higher than 60 ° C (140 ° F).
Product Name: YUNMAI SE Smart Weight Scale
Model : M1680
Measurement Unit: Kg/Lb
Connection : Bluetooth 4.0
Size: 260 × 260 × 26 mm
Executive Standard: Q / HC 1 - 2015
Net Weight: 1.2 Kg
Weighing Range: 3 - 180 Kg
Accuracy: ±50g
Working Temperature: -5 ℃ - 40 ℃
Exterior Material: Eco-friendly ABS
Power: 1.5V AA Battery x3
For more information please visit www.iyunmai.com
Hotline: +86-755-8671-6230
Facebook : www.facebook.com/iyunmai
Twitter: twitter.com/YunmaiGlobal
Manufacturer: Shenzhen YUNMAI Technology Co., Ltd
Address: Room 10D, 10F, 4C Building, Software Industry Base,
Nanshan District, Shenzhen, China
BMI (for men and women)
Age Overweight
Underweight Normal Obese Grossly Overweight
18.5-24.9 25-29.9 30-34.9 ≥ 35＜ 18.5
2 Connect to the scale via Bluetooth
Open YUNMAI App and Bluetooth and it will get connected automatically,
and your real-time data will sync to the App.
iOS： Slide from the bottom
of the screen to open the
Control Center and click on
the
Android: Click on【Allow】
to turn on Bluetooth when
the system reminds you
when open YUNMAI App
【Bluetooth】 Logo
AllowIgnore
An application wants to open Bluetooth
AllowReject
An application wants to open Bluetooth
Easy life, lighter! Using YUNMAI SE together with the App, you can not only
record exercise consumption, food intake and other basic information, but
also track your weight trends. YUNMAI helps to analyze on the Cloud and
provide health reports and improvement recommendations.
YUNMAI App
Notice: Due to the frequent updates of YUNMAI App, this picture is for
reference only. Please adhere to the real products in case of any change!
FCC ID: 2ADEB-M1680
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received, including interference
that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC Statement
Me
2 App Installation
1 Activation 3 Get Connected
Set each foot on each side of the central point naturally
as shown below:
4 Start Using
Click on【Me】
3-2 Connect via WiFi
1
Place in the scope of WiFi in first connection
Device
PM
connect to
YUNMAI mini
smart scale
YUNMAI Color
smart scale
Device Management
YUNMAI 2
smart scale
Cancel
PM
“YUNMAI 2”
Searching...keep close to the device
Click on【Device】
2
Click on
【Device Connection】
3Finish the process as
indicated
4
Product Introduction
A ITO conductive coating x 4
B Concealed Display Screen
C Reset Key
D USB Type-C charge port
E Speaker
A
D
B
C E
Thank you for choosing YUNMAI 2 Smart Scale Place YUNMAI 2 on a flat floor and press the surface until the
screen shows “YUNMAI” to activate it.
Please lay the scale at a place with strong WiFi signal or near
the router when it first get connected. WiFi signal will influence
connecting time and stability.
Under WiFi mode, as long as the scale and the phone are
placed in the scope of the WiFi, then the data will be
synchronized automatically to the App even without opening it.
Open WiFi option on the phone and YUNMAI App and get
connected as the following instructions:
Search“YUNMAI” in the iOS App Store or Android Application
Market or scan the following QR Code to download, install it
and it will get connected to the scale once turned on.
Download <YUNMAI App>
Scan QR Code
Wrong
Feet go out of the verge
may affect the accuracy
Correct
Each foot on each side
of the central point
naturally
Wrong
Feet not in a line may
affect the accuracy
Wrong
Stand in wrong direction
will shield the screen
Note: To ensure the accuracy please stand on the scale barefoot
with the right posture.
iOS 8.0 and above
iPhone 4S/5/5S/6/6 Plus/SE/6S/6S Plus/7/7 Plus
iPod touch /iPad
Android 4.3 and above with Bluetooth 4.0
Mobile Device Support
Measurement results of YUNMAI 2 is only for reference,
but professional medical advice.
Measurement Range: 3-150 Kg.
Important Note
Do not use low-quality plugs and cables.
Refrain from long-time charging in case of short circuit.
Do not charge in damp environment in case of electric
leakage.
Safe Power Charging
Use a wet cloth to clean the scale.
Do not use any detergent and don’t use water to wash it
directly.
Maintenance
YUNMAI 2 Smart Scale guarantees a year of technical
support and hardware warranty.
Warranty
Display and Status
WiFi Connection
Bluetooth Alarm Clock
WiFi Signal Error
Low Battery PowerFull Battery Power
Body Fat
Upgrading
Kg（Unit）
lb (Unit)
Weight gained Weight lost
Sunny
Rainy Snowy
Temperature
Cloudy
Body Statistics Table
18-39
Age
40-59
60-120
＜51% Low
≥51% Normal
Body Fat Muscle Ratio
Male
BMI
0-9.9% Low
10-20.9% Normal
21-25.9% Slightly obese
26-60% Obese
0-10.9% Low
11-21.9% Normal
22-26.9% Slightly obese
27-60% Obese
0-12.9% Low
13-23.9% Normal
24-28.9% Slightly obese
29-60% Obese
18-39
Age
40-59
60-120
＜46% Low
≥46% Normal
Body Fat Muscle Ratio
Female
BMI
0-9.9% Low
10-33.9% Normal
34-38.9% Slightly obese
39-60% Obese
0-20.9% Low
21-34.9% Normal
35-39.9% Slightly obese
40-60% Obese
0-21.9% Low
22-35.9% Normal
36-40.9% Slightly obese
41-60% Obese
＜ 18.5 Underweight
18.5-24.9 Normal
25-29.9 Overweight
30-34.9 Obese
≥ 35 Grossly Overweight
＜ 18.5 Underweight
18.5-24.9 Normal
25-29.9 Overweight
30-34.9 Obese
≥ 35 Grossly Overweight
Note: Juveniles have rapid physical developments and their body
statistics, such as body fat, BMI and muscle rate may fluctuate
largely, so it is difficult to get an accurate result except the
weight.
Product Specification
Product Name: YUNMAI 2 Smart Scale
Model : M1601
Measurement Unit: Kg /Lb
Connection : Bluetooth 4.0, WiFi
Size: 300 × 300 × 23 mm
Executive Standard: Q / HC 1 - 2015
Net Weight: 1.9 Kg
Weighing Range: 3 - 180 Kg
Accuracy: ±50g
Working Temperature: -5 ℃ - 40 ℃
Exterior Material: Eco-friendly ABS + PC
Battery Type : Li-Polymer Battery
For more information please visit www.iyunmai.com
Hotline: +86-755-8671-6230
Facebook : www.facebook.com/iyunmai
twitter: twitter.com/YunmaiGlobal
Manufacturer: Shenzhen YUNMAI Technology Co., Ltd
Address: Room 10D, 10F, 4C Building, Software Industry Base,
Nanshan District, Shenzhen, China
Smart Scale Instructions
3-1 Connect to the scale via Bluetooth
Open YUNMAI App and Bluetooth and it will get connected automatically,
and your real-time data will sync to the App.
iOS： Slide from the bottom
of the screen to open the
Control Center and click on
the
Android: Click on【Allow】
to turn on Bluetooth when
the system reminds you
when open YUNMAI App
【Bluetooth】 Logo
AllowIgnore
An application wants to open Bluetooth
AllowReject
An application wants to open Bluetooth
FCC ID: 2ADEB-M1601
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
FCC Statement
Me
