Z Com XG-603 802.11b/g Wireless mini-PCI Module User Manual
Z Com Inc 802.11b/g Wireless mini-PCI Module Users Manual
Z Com >
Users Manual
FCC Statement
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user authority to operate the
equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
The user’s manual or instruction manual for an intentional or unintentional radiator shall caution the
user that changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is needed.
Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm
must be maintained between the antenna of this device and all persons.
This Transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter
This device is intended only for OEM integrators under the following conditions:
The antenna must be installed such that 20 cm is maintained between the antenna and users. For
laptop installations, the antenna must be installed to ensure that the proper spacing is maintained
in the event the users places the device in their lap during use (i.e. positioning of antennas must be
placed in the upper portion of the LCD panel only to ensure 20 cm will be maintained if the user
places the device in their lap for use) and The transmitter module may not be co-located with any
other transmitter or antenna. As long as the 2 conditions above are met, further transmitter testing
will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed (for example,
digital device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no longer
considered valid and the FCC ID can not be used on the final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end
product (including the transmitter) and obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in devices where the antenna may be installed
such that 20 cm may be maintained between the antenna and users (for example access points,
routers, wireless ASDL modems, certain laptop configurations, and similar equipment). The final
end product must be labeled in a visible area with the following: "Contains TX FCC ID:M4Y-XG-603
".
XG-603 802.11G mini-PCI
RF Exposure Manual Information That Must be Included
The users manual for end users must include the following information in a prominent location
"IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used
for this transmitter must be installed to provide a separation distance of at least 20 cm from all
persons and must not be co-located or operating in conjunction with any other antenna or
transmitter."
Additional Information That Must be Provided to OEM Integrators
The end user should NOT be provided any instructions on how to remove or install the device.
Service Center in U.S.A
Company Name : Zcomax.
Company Address:14545 Valley View Ave., Suite S Santa Fe Springs, CA 90670
Tel:562-926-4588
1. Introduction
54Mbps IEEE802.11g Wireless Network Mini PCI Adapter is the perfect solution for your wireless network
applications based on the IEEE 802.11g standard offering a data rate of 54Mbps in a wireless LAN
environment.
XG-603 is designed for Access Point, Router, ATUR, Printer Server series, IP Camera series and
Internet Video Server gives you wireless access the web and network resource without the wire.
XG-603 provides high-speed access to network resources and has built-in 40/64-bit, and 128 bit of
WEP (Wired Equivalent Privacy) data encryption. With Direct Spread Spectrum Signaling (DSSS)
and Orthogonal Frequency Division Multiplexing (OFDM), domain access control, WEP encryption
and group security, the modules will safeguard all your wireless data transmissions from your nosy
neighbors.
XG-603 allows you to take full advantage of your devices mobility with access to real-time
information and online services anytime and anywhere.
2. Feature
. Complies with IEEE 802.11b/g Standard for 2.4GHz Wireless LAN.
. Works with All Existing Network Infrastructures.
. Compatible with Wi-Fi Wireless Products and Services
. Capable of up to 128-Bit WEP Encryption.
. Freedom to Roam While staying Connected
. 54 Mbps High-Speed Transfer Rate
. Two UF-L Connectors for External Antenna
. Support Antenna diversity for Better Sensitivity
. Lower Power Consumption.
3. Specification
Hardware Version: V1.1
Updated Date: 2006/03/13
Product Description
IEEE 802.11g compliant 2.4 GHz WLAN miniPCI card
Host Interface
32-bit miniPCI, Type III B
Operating Voltage
DC3.3V ± 5%
Chipset
Mac/BB Processor Conexant ISL3886IKZ
RF Chip Conexant ISL3686BIRZ-TK
Power Consumption
11b TX: ≦ 450 mA RX: ≦ 350 mA
11g TX: ≦ 450 mA RX: ≦ 350 mA
Radio
Antenna two U.FL-R-SMT connectors
IEEE 802.11b Minimum Typical Maximum
11Mbps 14.5dBm 16dBm 17.5dBm
IEEE 802.11g Minimum Typical Maximum
54Mbps 12.5dBm 14dBm 15.5dBm
6Mbps 12.5dBm 14dBm 15.5dBm
Output Power1
IEEE 802.11b Minimum Typical Maximum
11Mbps 14.5dBm 16dBm 17.5dBm
IEEE 802.11g Minimum Typical Maximum
54Mbps 12.5dBm 14dBm 15.5dBm
6Mbps 12.5dBm 14dBm 15.5dBm
IEEE 802.11g
Sensitivity @ Packet Error Rate: 10% IEEE 802.11b
Sensitivity @ Packet Error Rate: 8%
Sensitivity
♦ 54Mbps:≦-65dBm
♦ 48Mbps:≦-66dBm
♦ 36Mbps:≦-70dBm
♦ 24Mbps:≦-74dBm
♦ 18Mbps:≦-77dBm
♦ 12Mbps:≦-79dBm
♦ 9Mbps:≦-81dBm
♦ 6Mbps:≦-82dBm
♦ 11Mbps:≦-80dBm
♦ 5.5Mbps:≦-83dBm
♦ 2Mbps:≦-84dBm
♦ 1Mbps:≦-87dBm
Modulation IEEE 802.11g (OFDM/DSSS)
♦ 48/54 Mbps (QAM-64)
♦ 24/36 Mbps (QAM-16)
♦ 12/18 Mbps (QPSK)
♦ 6/9 Mbps (BPSK)
1 Measured with power meter (CW sensor) under 25℃ room temperature
IEEE 802.11b (DSSS)
♦ 5.5/11 Mbps (CCK)
♦ 2 Mbps (DQPSK)
♦ 1 Mbps (DBPSK)
Range Coverage
(Typical range in open
environment with 0 dBi
Antenna)
IEEE 802.11g
♦ 54Mbps:≧ 60 meter
♦ 48Mbps:≧70 meter
♦ 36Mbps:≧80 meter
♦ 24/18Mbps:≧ 120 meter
♦ 12/9/6Mbps:≧120 meter
♦ 11Mbps:≧80 meter
IEEE 802.11b
♦ 11Mbps:≧80 meter
♦ 5.5Mbps:≧120 meter
♦ 2Mbps:≧200 meter
♦ 1Mbps:≧300 meter
Operating
Frequency IEEE 802.11b/g ISM Band
♦ USA(FCC): 2.412GHz ~ 2.462 GHz (CH1 ~ CH11)
♦ Europe(ETSI): 2.412 GHz ~ 2.472 GHz (CH1 ~ CH13)
♦ Japan(TELEC) : 2.412 GHz ~ 2.472 GHz (CH1 ~ CH13)
Software Specification
Supported OS Identical to Atheros Latest Version
Security Identical to Atheros Latest Version
Physical Specification
Dimension 59.6mm(L) * 44.45mm(W) * 2.7mm(H)
Weight ≦ 50 g
Environment Specification
Temperature (Ambient) Humidity (non-condensing)
Operating 0 ~ 65 ℃
Storage -20 ~ 80 ℃ 0 ~ 90%
Lead Free
RoHS Compliant
Warranty
12 months
4. Hardware Installation
The following sections in this chapter describe how to install XG-603 Module
4.1. Installation Overview
XG-603 wireless module is design for Access Point, Router, ATU-R, Printer Server series, IP Camera
series and Internet Video Server only.
4.2. Safety Recommendations
The safety guidelines are as follows:
λ Keep the board area clear and dust-free before, during, and after installation.
λ Keep tools away from walk areas where you and others could fall over them.
λ Do not wear loose clothing or jewelry, such as earrings, bracelets, or chains, that could get
caught in the board.
λ Wear safety glasses if you are working under any conditions that might be hazardous to your
eyes.
λ Do not perform any action that creates a potential hazard to people or makes
the equipment unsafe.
λ Never attempt to lift an object that is too heavy for one person to handle.
4.3. Maintaining Safety with Electricity
Warning: Before working on a board or working near power supplies, unplug the power cord on AC units;
on DC units, disconnect the power at the circuit breaker.
Follow these guidelines when working on equipment powered by electricity:
λ Do not work alone if potentially hazardous conditions exist anywhere in your
work space.
λ Never assume that power is disconnected from a circuit; always check the
circuit.
extension cables, frayed power cords, and missing safety grounds.
λ If an electrical accident occurs, proceed as follows:
– Use caution; do not become a victim yourself.
– Disconnect power from the system.
– If possible, send another person to get medical aid. Otherwise, assess the condition of the victim
and then call for help.
– Determine if the person needs rescue breathing or external cardiac compressions; then take
appropriate action.
- 7 -
4.4. Installing a XG-603
λ Remove the XG-603 module from its protective packaging.
λ Avoiding Electrostatic Discharge
Before you install the XG-603 module, ground yourself by touching a piece of metal
to avoid electrostatic discharge (ESD). You should also take the following
precautions to prevent damage to the XG-603 module:
λ Keep the XG-603 module in its antistatic-shielded bag until you are ready to
install it.
λ Handle the XG-603 module by its edges.
λ Ensure the connector is connected to above Model’s board tightly.
