Z Com XG-623G 802.11b/g Wireless mini PCI module User Manual
Z Com Inc 802.11b/g Wireless mini PCI module Users Manual
Z Com >
Users Manual
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures: Reorient or
relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect
the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult
the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications
to this unit not expressly approved by the party responsible for compliance could void the user authority
to operate the equipment.
IMPORTANT NOTE:
This module is intended for OEM integrator. The OEM integrator is still responsible for
the FCC compliance requirement of the end prouduct which integrates this
module.
20cm minimum distance has to be able to be maintained between the antenna and
the users for the host this module is integrated into. Under such configuration, the
FCC radiation exposure limits set forth for an population/uncontrolled environment
can be satisfied.
Any changes or modifications not expressly approved by the manufacturer
could void the user's authority to operate this equipment.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep
at least 20cm separation with the antenna while this end product is installed and
operated. The end user has to be informed that the FCC radio-frequency
exposure guidelines for an uncontrolled environment can be satisfied. The end
user has to also be informed that any changes or modifications not expressly
approved by the manufacturer could void the user's authority to operate this
equipment. If the size of the end product is smaller than 8x10cm, then additional
FCC part 15.19 statement is required to be available in the users manual: This
device complies with Part 15 of FCC rules. Operation
is subject to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received, including
interference that may cause undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following
" Contains TX FCC ID: M4Y-XG-623G ". If the size of the end product is larger than
8x10cm, then the following FCC part 15.19 statement has to also
be available on the label: This device complies with Part 15 of FCC rules. Operation
is subject to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Antenna Requirement:
RF Cable: RG-178 Coaxial cable (with Core). Core Brand: King core (K5B RH 9*16*5)
1. Introduction
108Mbps IEEE802.11g Wireless Network Mini PCI card with Super G is the perfect solution for your wireless
network applications based on the IEEE 802.11g standard offering a data rate of 108Mbps in a
wireless LAN environment.
XG-623G is designed for Access Point, Router, ATUR, Printer Server series, IP Camera series and
Internet Video Server gives you wireless access the web and network resource without the wire.
XG-623G provides high-speed access to network resources and has built-in 40/64-bit, 128 bit and 256
bit of WEP (Wired Equivalent Privacy) data encryption. With Direct Spread Spectrum Signaling
(DSSS) and Orthogonal Frequency Division Multiplexing (OFDM), domain access control, WEP
encryption and group security, the modules will safeguard all your wireless data transmissions from
your nosy neighbors.
XG-623G allows you to take full advantage of your devices mobility with access to real-time
information and online services anytime and anywhere.
2. Feature
. Complies with IEEE 802.11b/g Standard for 2.4GHz Wireless LAN with Super G.
. Works with All Existing Network Infrastructures.
. Compatible with Wi-Fi Wireless Products and Services
. Capable of up to 256-Bit WEP Encryption.
. Freedom to Roam While staying Connected
. 108 Mbps High-Speed Transfer Rate
. Two UF-L Connectors for External Antenna
. Support Antenna diversity for Better Sensitivity
. Lower Power Consumption.
3. Specification
Hardware Version: V1.1
Updated Date: 2005/10/06
Product Description
IEEE 802.11g compliant 2.4 GHz WLAN miniPCI card with Super G
Host Interface
32-bit miniPCI, Type III B
Operating Voltage
DC3.3V ± 5%
Chipset
Atheros AR2414 (Single chip)
Power Consumption
11b TX: ≦ 550 mA RX:
≦ 450 mA
11g TX: ≦ 550 mA RX: ≦ 450 mA
Radio
Antenna two U.FL-R-SMT connectors
IEEE 802.11b:
17dBm @ 1/2/5.5/11Mbps
Output Power
(Average Power)
IEEE 802.11g:
16dBm @ 54Mbps
16dBm @108Mbps (Super G)
IEEE 802.11g / Super G
Sensitivity @ Packet Error Rate: 10% IEEE 802.11b
Sensitivity @ Packet Error Rate: 8%
Sensitivity
♦ 54 / 108 Mbps:≦-65dBm
♦ 48 / 96 Mbps:≦-66dBm
♦ 36 / 72 Mbps:≦-70dBm
♦ 24 / 48 Mbps:≦-74dBm
♦ 18 36 Mbps:≦-77dBm
♦ 12 / 24 Mbps:≦-79dBm
♦ 9 / 18 Mbps:≦-81dBm
♦ 6 / 12Mbps:≦-82dBm
♦ 11Mbps:≦-80dBm
♦ 5.5Mbps:≦-83dBm
♦ 2Mbps:≦-84dBm
♦ 1Mbps:≦-87dBm
IEEE 802.11g (OFDM/DSSS)
♦ 48/54 Mbps (QAM-64)
♦ 24/36 Mbps (QAM-16)
♦ 12/18 Mbps (QPSK)
♦ 6/9 Mbps (BPSK)
Modulation
IEEE 802.11b (DSSS)
♦ 5.5/11 Mbps (CCK)
♦ 2 Mbps (DQPSK)
♦ 1 Mbps (DBPSK)
Range Coverage
(Typical range in
open environment
with 0 dBi
Antenna)
IEEE 802.11g
♦ 54Mbps:≧ 60 meter
♦ 48Mbps:≧70 meter
♦ 36Mbps:≧80 meter
♦ 24/18Mbps:≧ 120 meter
♦ 12/9/6Mbps:≧120 meter
♦ 11Mbps:≧80 meter
IEEE 802.11b
♦ 11Mbps:≧80 meter
♦ 5.5Mbps:≧120 meter
♦ 2Mbps:≧200 meter
♦ 1Mbps:≧300 meter
Operating
Frequency IEEE 802.11b/g ISM Band
♦ USA(FCC): 2.412GHz ~ 2.462 GHz (CH1 ~ CH11)
♦ Europe(ETSI): 2.412 GHz ~ 2.472 GHz (CH1 ~ CH13)
♦ Japan(TELEC) : 2.412 GHz ~ 2.472 GHz (CH1 ~ CH13)
Software Specification
Supported OS Identical to Atheros Latest Version
Security Identical to Atheros Latest Version
Physical Specification
Dimension 59.6mm(L) * 44.5mm(W) * 3.25mm(H)
Weight ≦ 50 g
Environment Specification
Temperature (Ambient) Humidity (non-condensing)
Operating 0 ~ 55 ℃
Storage -20 ~ 80 ℃ 5 ~ 90%
Warranty
12 months
4. Hardware Installation
The following sections in this chapter describe how to install XG-623G Module
4.1. Installation Overview
XG-623G wireless module is design for Access Point, Router, ATU-R, Printer Server series, IP Camera
series and Internet Video Server only.
4.2. Safety Recommendations
The safety guidelines are as follows:
λ Keep the board area clear and dust-free before, during, and after installation.
λ Keep tools away from walk areas where you and others could fall over them.
λ Do not wear loose clothing or jewelry, such as earrings, bracelets, or chains, that could get
caught in the board.
λ Wear safety glasses if you are working under any conditions that might be hazardous to your
eyes.
λ Do not perform any action that creates a potential hazard to people or makes
the equipment unsafe.
λ Never attempt to lift an object that is too heavy for one person to handle.
4.3. Maintaining Safety with Electricity
Warning: Before working on a board or working near power supplies, unplug the power cord on AC units;
on DC units, disconnect the power at the circuit breaker.
Follow these guidelines when working on equipment powered by electricity:
λ Do not work alone if potentially hazardous conditions exist anywhere in your
work space.
λ Never assume that power is disconnected from a circuit; always check the
circuit.
extension cables, frayed power cords, and missing safety grounds.
λ If an electrical accident occurs, proceed as follows:
– Use caution; do not become a victim yourself.
– Disconnect power from the system.
– If possible, send another person to get medical aid. Otherwise, assess the condition of the victim
and then call for help.
– Determine if the person needs rescue breathing or external cardiac compressions; then take
appropriate action.
- 7 -
4.4. Installing a XG-623G
λ Remove the XG-623G module from its protective packaging.
λ Avoiding Electrostatic Discharge
Before you install the XG-623G module, ground yourself by touching a piece of metal
to avoid electrostatic discharge (ESD). You should also take the following
precautions to prevent damage to the XG-623G module:
λ Keep the XG-623G module in its antistatic-shielded bag until
you are ready to install it.
λ Handle the XG-623G module by its edges.
λ Ensure the connector is connected to above Model’s board tightly.
