XN-623 User manual

FCC Statement
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11.
CAUTION:
To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm
must be maintained between the antenna of this device and all persons.
This Transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter
This device is intended only for OEM integrators under the following conditions:
The antenna must be installed such that 20 cm is maintained between the antenna and users. For
laptop installations, the antenna must be installed to ensure that the proper spacing is maintained
in the event the users places the device in their lap during use (i.e. positioning of antennas must be
placed in the upper portion of the LCD panel only to ensure 20 cm will be maintained if the user
places the device in their lap for use) and The transmitter module may not be co-located with any
other transmitter or antenna. As long as the 2 conditions above are met, further transmitter testing
will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed (for example,
digital device emissions, PC peripheral requirements, etc.).

IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no longer
considered valid and the FCC ID can not be used on the final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end
product (including the transmitter) and obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in devices where the antenna may be installed
such that 20 cm may be maintained between the antenna and users (for example access points,
routers, wireless ASDL modems, certain laptop configurations, and similar equipment). The final
end product must be labeled in a visible area with the following: "Contains TX FCC
ID:M4Y-XN623V01 ".
RF Exposure Manual Information That Must be Included
The users manual for end users must include the following information in a prominent location
"IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used
for this transmitter must be installed to provide a separation distance of at least 20 cm from all
persons and must not be co-located or operating in conjunction with any other antenna or
transmitter."
Additional Information That Must be Provided to OEM Integrators
The end user should NOT be provided any instructions on how to remove or install the device.
Service Center in U.S.A
Company Name : Zcomax.
Company Address:14545 Valley View Ave., Suite S Santa Fe Springs, CA 90670
Tel:562-926-4588
ࠉᖕʳʳ ܅פሽंᘿ୴ࢤሽᖲጥᙄऄʳ
ʳรԼԲයʳʳ ᆖীڤᎁᢞٽհ܅פ୴᙮ሽᖲΔॺᆖױΔֆΕᇆࢨࠌشृ݁լ
ᖐ۞᧢ޓ᙮ΕףՕפࢨ᧢ޓૠհࢤ֗פ౨Ζʳ
ʳรԼයʳʳ ܅פ୴᙮ሽᖲհࠌشլᐙଆڜ٤֗եឫٽऄຏॾΙᆖ࿇ڶեឫ
ွழΔᚨمܛೖشΔࠀޏ۟ྤեឫழֱᤉᥛࠌشΖছႈٽऄຏॾΔਐࠉ
ሽॾࡳ܂ᄐհྤᒵሽॾΖ܅פ୴᙮ሽᖲႊݴ࠹ٽऄຏॾࢨՠᄐΕઝᖂ֗
᠔᛭شሽंᘿ୴ࢤሽᖲໂհեឫΖʳ

1. Introduction
IEEE 802.11b/g/n WIRELESS miniPCI CARD is the perfect solution for your wireless network applications
based on the IEEE 802.11g standard offering a data rate of 54Mbps in a wireless LAN environment.
XN-623 is designed for Access Point, Router, ATUR, Printer Server series, IP Camera series and
Internet Video Server gives you wireless access the web and network resource without the wire.
XN-623 provides high-speed access to network resources and has built-in 40/64-bit, and 128 bit of
WEP (Wired Equivalent Privacy) data encryption. With Direct Spread Spectrum Signaling (DSSS)
and Orthogonal Frequency Division Multiplexing (OFDM), domain access control, WEP encryption
and group security, the modules will safeguard all your wireless data transmissions from your nosy
neighbors.
XN-623 allows you to take full advantage of your devices mobility with access to real-time
information and online services anytime and anywhere.
2. Feature
ˁʳComplies with IEEE 802.11b/g Standard for 2.4GHz Wireless LAN.
ˁʳWorks with All Existing Network Infrastructures.
ˁʳCompatible with Wi-Fi Wireless Products and Services
ˁʳCapable of up to 128-Bit WEP Encryption.
ˁʳFreedom to Roam While staying Connected
ˁʳ54 Mbps High-Speed Transfer Rate
ˁʳTwo UF-L Connectors for External Antenna
ˁʳSupport Antenna diversity for Better Sensitivity
ˁʳLower Power Consumption.

3. SPECIFICATION
Hardware specification
The Hardware specifications of the product are as below:
Table2.1 Hardware specification
Items Description
Standard IEEE 802.11b
IEEE 802.11g
IEEE 802.11n Draft 2.0
Chipset MAC/BBP AR9223
Antenna 2 U.FL-R-SMT compliant
connectors
Antenna
Configuration
2T2R
Host Interface 32-bit miniPCI, Type III A
Operating Voltage DC 3.3V ± 5%
Power
Consumption
Normal Mode1
IEEE 802.11b
TX: Љ550mA
RX: Љ350mA
IEEE 802.11g
TX: Љ550mA
RX: Љ350mA
IEEE 802.11n
TX: 550mAЉ
RX: 350mAЉ
IEEE 802.11b 26.63 dBm (2TX)
IEEE 802.11g 21.51 dBm (2TX)
HT20 19.72dBm (2TX)
Output Power2 @
25к
IEEE 802.11gn HT40 19.19dBm (2TX)
Sensitivity IEEE 802.11b
11Mbps: Љ-83dBm
IEEE 802.11g
54Mbps:Љ-70dBm
IEEE 802.11n
2.4GHz
HT20 Љ -64dBm
HT40 Љ -61dBm
IEEE 802.11b (DSSS)
i5.5/11 Mbps (CCK)
i2 Mbps (DQPSK)
i1 Mbps (DBPSK)
Modulation
IEEE 802.11g (OFDM/DSSS)
i48/54 Mbps (QAM-64)
i24/36 Mbps (QAM-16)
i12/18 Mbps (QPSK)
i6/9 Mbps (BPSK)
1 When the device is initialized, linked and pinging AP, it is defined as operating in Normal mode
2 Measured with power meter (CW sensor) under 25к room temperature

IEEE 802.11n (OFDM/DSSS)
i QAM-64
i QAM-16
i QPSK
i BPSK
IEEE 802.11b/g ISM Band
iUSA(FCC)Κ 2.412GHz ~ 2.462 GHz (CH1 ~ CH11)
iEurope(ETSI) Κ 2.412 GHz ~ 2.472 GHz (CH1 ~ CH13)
iJapan(TELEC) Κ2.412 GHz ~ 2..472 GHz (CH1 ~ CH13)
IEEE 802.11gn 20MHz Band
iUSA(FCC): 2.412GHz ~ 2.462 GHz
iEurope(ETSI): 2.412 GHz ~ 2.472 GHz
iJapan(TELEC) : 2.412 GHz ~ 2.472 GHz
Operating
Frequency
IEEE 802.11gn 40MHz Band
iUSA(FCC): 2.422GHz ~ 2.452 GHz(CH3 ~ CH9)
iEurope(ETSI) : 2.422 GHz ~ 2.462 GHz(CH3 ~ CH11)
iJapan(TELEC) : 2.422 GHz ~ 2.462 GHz(CH3 ~ CH11)
Software specification
The Software specifications of the product are as below:
Software specification
Items Description
Standard IEEE 802.11i security standard
IEEE 802.1x security standard
Operating Mode Infrastructure mode
Power Management Power save mode
Security WPA/WPA2/WPA-PSK/WPA2-PSK
64-bit, 128-bit, WEP
TKIP
AES
EAP-TLS/EAP-TTLS/EAP-PEAP
Supported OS Linux 2.6
PID/VID SUBSYS_2093168C

Physical specification
The Physical specifications of the product are as below:
Physical specification
Items Description
Housing Dimension 59.6mm(L) * 50.9mm(W) * 3.55mm(H)
Weight Љ50g
Environment specification
The Environment specifications of the product are as below:
Environment l specification
Items Description
Operating
Temperature
0~+55°C
Operating Humidity
(non-condensing)
<90 [%RH]
Storage
Temperature
-20 ~ +80°C
Storage Humidity
(non-condensing)
5~90 [%RH]
Warranty 12 Months
Green RoHs Compliant
Safety/Country Approval
The Country Approvals of the product are as below: TBD
Packaging Specification
The following items will be required for the bulk packaging:
Item Comments
FCC label z TBD
ESD bag zSuitable size and material to protect product
Inner box zSuitable size and material to protect product
Carton zSuitable size and material to protect product

4. Hardware Installation
The following sections in this chapter describe how to install XN-623 Module
4.1. Installation Overview
XN-623 wireless module is design for Access Point, Router, ATU-R, Printer Server series, IP Camera
series and Internet Video Server only.
4.2. Safety Recommendations
The safety guidelines are as follows:
ӳʳ Keep the board area clear and dust-free before, during, and after installation.
ӳʳ Keep tools away from walk areas where you and others could fall over them.
ӳʳ Do not wear loose clothing or jewelry, such as earrings, bracelets, or chains, that could get
caught in the board.
ӳʳ Wear safety glasses if you are working under any conditions that might be hazardous to your
eyes.
ӳʳ Do not perform any action that creates a potential hazard to people or makes
the equipment unsafe.
ӳʳ Never attempt to lift an object that is too heavy for one person to handle.
4.3. Maintaining Safety with Electricity
Warning: Before working on a board or working near power supplies, unplug the power cord on AC units;
on DC units, disconnect the power at the circuit breaker.
Follow these guidelines when working on equipment powered by electricity:
ӳʳ Do not work alone if potentially hazardous conditions exist anywhere in your
work space.
ӳʳ Never assume that power is disconnected from a circuit; always check the
circuit.
extension cables, frayed power cords, and missing safety grounds.
ӳʳ If an electrical accident occurs, proceed as follows:
–Use caution; do not become a victim yourself.
–Disconnect power from the system.
–If possible, send another person to get medical aid. Otherwise, assess the condition of the victim
and then call for help.
–Determine if the person needs rescue breathing or external cardiac compressions; then take
appropriate action.
- 7 -
4.4. Installing a XN-623
ӳʳ Remove the XN-623 module from its protective packaging.
ӳʳ Avoiding Electrostatic Discharge
Before you install the XN-623 module, ground yourself by touching a piece of metal
to avoid electrostatic discharge (ESD). You should also take the following
precautions to prevent damage to the XN-623 module:
ӳʳ Keep the XN-623 module in its antistatic-shielded bag until you are ready to
install it.
ӳʳ Handle the XN-623 module by its edges.
ӳʳ Ensure the connector is connected to above Model’s board tightly.
