ZAGG ZKMFOL WIRELESS KEYBOARD User Manual ZAGGkeys FOLIO Instructions 052813 V04 Print
ZAGG Inc. WIRELESS KEYBOARD ZAGGkeys FOLIO Instructions 052813 V04 Print
ZAGG >
User Manual
NEED MORE HELP? PLEASE SEE OUR FAQ SECTION AT:
www.ZAGG.com/faq
NEED MORE HELP? PLEASE SEE OUR FAQ SECTION AT: www.ZAGG.com/faq
To reach a trained customer service representative, please use one of the following:
ZAGG.com/support/contact.php | questions@zagg.com
1-800-700-ZAGG [9244] | 00-1-801-839-3906 for international customers
For unparalleled scratch protection for your iPad, we recommend ZAGG’s invisibleSHIELD®.
©2005 - 2013 ZAGG Inc. All Rights Reserved.
PATENT PENDING | NASDAQ: ZAGG | MADE IN CHINA
iPad®, Apple®, and iTunes® are registered trademarks of Apple Inc.
ZAGG®, invisibleSHIELD®, and ZAGGkeys™ Folio are trademarks or registered trademarks of ZAGG Inc.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1: This device may not cause harmful interference, and 2: This device must accept any interference
received, including interference that may cause undesired operation
FOLIO
*WARRANTY REGISTRATION
Your ZAGGkeys™ Folio comes with a one-year manufacturer’s warranty. In order to activate the warranty,
you must register your Folio as well as keep your purchase receipt. If you purchased your ZAGGkeys
Folio from ZAGG.com, ZAGG® has already registered it and has a copy of your proof of purchase.
FOLD
FRONT
BACK
INSERTING/REMOVING YOUR iPAD® TROUBLESHOOTING
If your iPad® does not respond to your Folio there may be a simple
explanation such as a dead battery or an unsuccessful pairing. Please use
the following to help troubleshoot your situation. If none of the following
solve your issue, then please contact ZAGG customer service and one of
our trained professionals will be happy to assist you.
1. Restart your iPad by holding down the home and power button
simultaneously until it restarts. Let go of the buttons when you see the
Apple logo.
2. Turn your Folio o and back on. You should see the LED status light
illuminate briefly, if not, charge your Folio.
3. After charging, turn your Folio on. If the LED status light does not
illuminate, and your keyboard doesn’t operate correctly, please contact
ZAGG’s customer support.
4. Forget and re-pair your Folio. On your iPad, select: Settings > General >
Bluetooth > On. If you see “ZAGGkeys Folio” listed as an available
device, touch the arrow to the right of it and choose to have your iPad
forget the device.
5. Push the PAIR button on your Folio and watch for the LED status light
to flash blue.
6. Your iPad should display “ZAGGkeys Folio” as an available device.
Select it.
7. If your iPad gives you an error message, repeat the pairing process.
8. If you still can’t get your Folio to pair, it is possible your iPad needs to
have its software updated.
To update your iPad’s software, follow these steps:
1. Plug your iPad into your computer, and open iTunes®.
2. In iTunes, select your iPad.
3. Choose to check for software updates.
4. If an update is available, please install it. This will take a few minutes to
download from Apple®.
5. After your update is complete, repeat the troubleshooting process*.
* If you continually receive the same error message during pairing, or the above steps don’t work, please
contact ZAGG’s customer support for assistance.
To insert your iPad mini into the Folio, start
with the Folio’s keyboard facing you. Then,
with your iPad in landscape mode and the
volume control buttons facing out (the
Home button is on your right) set the
bottom half of your iPad in the Folio,
making sure it is settled (you may need to
apply light pressure to your iPad to ensure
it is settled at the bottom of the cover).
Next, snap the top half into the Folio. Check
all corners to make sure they have seated
properly as well.
To easily remove your iPad, simply grasp
the top of the Folio’s cover in the middle
and apply a light pressure to the back of
your iPad. Grasp your iPad’s exposed side
and lift/pull away from the Folio.
When your iPad is secure in the Folio, you
can close it, and cleverly placed magnets will
activate your iPad’s sleep/wake feature to
help preserve battery life. Simply open your
Folio to wake your iPad.
FOLD
INSIDE RIGHT
INSIDE LEFT
POWERING ON AND OFF
PAIRING YOUR ZAGGkeys™ FOLIO
THE FUNCTION (fn) KEY
To turn your Folio on, switch the POWER button to the ON position. A red
LED light will illuminate briefly while the keyboard powers up. To turn your
Folio o, simply switch the POWER button to the OFF position.
The fn key operates all key functions listed below. To activate these
functions, hold the fn key down and press the desired key. For keys with
two function symbols, the fn key operates the bottom symbol. Holding
SHIFT and the fn key simultaneously operates the upper symbol.
FN + CAPS – Activates the CAPS Lock feature. When CAPS Lock is
on a blue indicator light will remain lit until it is turned o. To turn
CAPS Lock o, simply hold the fn key and press CAPS again.
FN + World Symbol – Toggles between international keyboards
(when activated in your iPad®’s settings)
FN + Battery Symbol – Indicates remaining battery life
FN + Backlight On – Activates your Folio’s backlight feature. Pressing
this key once will turn on the backlights at their dimmest setting,
pressing it twice will brighten the lights, and pressing it three times
will brighten them to their brightest setting.
NOTE: The backlights will automatically turn o after a couple seconds if not being used. Simply
begin typing again to activate them.
FN + Backlight O – Dims the backlights according to their selected
brightness until they turn o. For example, if your lights are at their
brightest setting, you would press this button once to dim the lights,
twice to set them at their dimmest setting, and three times to turn
the backlights o.
FN + Backlight Color Palette – Press to select your preferred
backlight color. Press repeatedly to cycle through available colors.
NOTE: The backlight feature must be turned on in order for the palette to work.
Pairing your Folio with your iPad® is easy. It should only need to be paired
once, using the following directions. If the connection between your iPad
and Folio is ever lost, simply repeat these steps.
1. On your iPad select: SETTINGS > GENERAL > BLUETOOTH > ON.
2. Press the PAIR button on your Folio keyboard. A blue LED light will
flash until your Folio and iPad are paired.
3. Your iPad will display “ZAGGkeys Folio” as an available device.
Select this option to complete pairing.
LED LIGHT PAIR BUTTON
LED LIGHT
ON POSITION
OFF POSITION
POWER BUTTON
SHIFT
DEFAULT
FN + SHIFT
FN
SHIFT
DEFAULT
DEFAULT
FN + SHIFT
FN
FN + SHIFT
FN
FOLD
PAGE 1
PAGE 4
CHARGING
SPECIAL FUNCTION KEYS
BATTERY LIFE
Your Folio features a powerful lithium-polymer battery that lasts for up to
three months of normal use* between charges. It comes with a charging
cable you can use to charge your keyboard quickly and conveniently. To
charge your Folio, simply follow these steps:
1. Plug the micro USB connector into the charging port.
2. Plug the regular USB connector into any USB outlet (including a
ZAGGsparq™, your computer, your iPad®, etc.).
3. A red LED light near the charging port will illuminate to indicate the
Folio is charging. Wait until this light turns o, indicating a full charge. It
usually takes 2-4 hours to completely charge your Folio.
4. Remove the Micro USB connector and enjoy your Folio for up to three
months before you need to charge it again.
* Normal use is approximately 2-3 hours of use per day without the backlit
feature. Using the backlit feature will impact battery life and may require
more frequent charging.
LED LIGHT
CHARGING PORT
As mentioned, the Folio features a powerful, rechargeable battery that
lasts up to three months between charges*. To check your Folio’s remaining
battery power, simply hold down the function (fn) key and press the battery
key (also the alt key). The LED indicator will flash one of three ways.
1. Three green flashes indicate 50% or more battery life remaining.
2. Three yellow flashes indicate between 25%-50% battery life remaining.
3. Three red flashes indicate less than 25% battery life remaining. When
your Folio reaches critical battery level, the LED backlights will not
function* and the red light will flash once every five minutes.
To help preserve battery life, your Folio will enter sleep mode if left on and
not used for several minutes. To wake your Folio, simply press any key. The
Folio’s battery has no memory and therefore may be charged whenever
you wish. For optimal battery life, we recommend turning your Folio o
when idle for a prolonged time.
* This is a safeguard to conserve power until the battery is charged.
Your Folio keyboard has been designed with the following special function
keys to give you more control of your iPad®:
Home – Displays your iPad’s home screen
Lock – Activates and deactivates your iPad’s sleep mode
Mic – Activates Siri from your keyboard
Keyboard Hide/Show – Hides or shows your iPad’s on-screen keyboard
Copy – Copies selected text to your clipboard
Paste – Pastes clipboard content in your selected field
Previous Track – Skips to the previous track on your current playlist
Play/Pause – Starts or stops your current playlist
Next Track – Skips to the next track on your current playlist
Mute – Mutes your iPad’s audio
Volume Down – Decreases your iPad’s volume
Volume Up – Increases your iPad’s volume
FOLD
PAGE 3
PAGE 2
FCC WARNING
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
NOTE 1: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
