Contents
Features ........................................................................................................................3
Package Contents .......................................................................................................3
About AccDrone App ..................................................................................................3
Compatibility ...............................................................................................................................3
Specications ..............................................................................................................4
Fly Safely .......................................................................................................................4
Charge the Drone Battery ..........................................................................................4
Lithium Battery Notes .............................................................................................................5
Install Batteries in the Remote Control ....................................................................5
Battery Notes ..............................................................................................................................5
Drone Design Overview .........................................................................................6-7
Remote Control Design Overview ........................................................................8-9
Pairing ........................................................................................................................ 10
Multiple Player Pairing ........................................................................................................... 10
Fly Your Drone ........................................................................................................... 10
Land Your Drone ....................................................................................................... 10
Trim Your Drone .........................................................................................................11
Fly in "Headless" Mode ..............................................................................................11
Perform Air Flip Stunt ...............................................................................................11
Using the Camera .................................................................................................... 12
Taking Photos and Videos ...................................................................................................12
Download AccDrone App ........................................................................................ 12
App Controls Overview ........................................................................................... 13
Playback Photos/ Video ........................................................................................... 14
Replace Damaged Propellers .................................................................................. 14
Troubleshooting ....................................................................................................... 15
Need Spare Parts? .................................................................................................... 15
FCC Information ....................................................................................................... 16
Limited Warranty ...................................................................................................... 16
We hope you enjoy your Accelerator HD Video Streaming Drone from
RadioShack. Congratulations! No FAA Registration is required for this drone.
Please read this user’s guide before setting up and using your drone.
Features
• 2 ways to y, control and shoot video/ pictures using remote control or
Wi-Fi app
• Air pressure sensor for enhanced hovering
• Built-in HD camera • Digital proportional control
• One touch takeo/ landing • 6-axis gyro stablilization
Package Contents
• Accelerator • Remote Control
• AC Adapter • Mobile Device Holder
• Spare Propeller with screw (6) • 3.7V, 2000mAh Drone Battery
• User’s Guide
About AccDrone App
Functions and controls are basically the same as those on the included remote
control, but the app has a few extra tricks to enjoy:
• You can leave the remote control at home, because you want to travel light
and cannot bear to separate from your smart device...
• You prefer touch screen controls, plus there's a cool motion sensor
navigation option
• You can stream photo/ video footage live to your friends on social media
• Last but not least, for remote control users, the app allows quick access to
view photos/ video shot using the included remote control and a SD card
(not included) loaded in your drone. Snap the device holder onto the remote
to use your device as a monitor (see page 9). This conveniently eliminates
transferring the SD card to your device or a card reader.
Accelerator pilots, you have nothing to lose, the world is
your oyster! Master ight rst by getting to grips with the
remote control, and then discover the extras oered in app
control. Download the free AccDrone app from App Store®
or Google PlayTM,
Compatibility
•iOS8 or above
• Android 4.0 or above. Note, app functions and compatibility may vary
depending on device brand and models
4 5
3. To install the battery, plug the two ends of the
red battery connectors.They only t one way,
so do not use force. Neatly slot the battery and
cables into the drone's battery compartment.
CAUTION:
• After playing, let the built-in battery cool before
charging again.
• Always unplug the drone's battery when not in use.
Lithium Battery Notes
• Do not charge longer than recommended. Unplug the charging cable when
the battery is charged.
• Do not attempt to charge or operate damaged toys.
• Do not puncture or crush. Do not disassemble.
• Do not dispose of lithium batteries in the trash.
• If the electrolyte in the cells should get on your skin, thoroughly wash with soap
and water. If in the eyes, rinse thoroughly with cool water. Immediately seek
medical attention.
Install Batteries in the Remote Control
1. Make sure the remote control is turned o.
2. Use a screwdriver to open the battery
compartment. Then insert four AAA
batteries (not included), matching the
polarities (+ and –) marked inside. Use
alkaline batteries for optimal performance.
Replace the cover.
Note: If the remote control’s LED ashes during
use, the batteries are low and should be replaced.
Battery Notes
• Dispose of old batteries promptly and properly. Do not burn or bury them.
Use only fresh batteries of the required size and recommended type.
• Do not mix old and new batteries, dierent types of batteries (standard,
alkaline, or rechargeable), or rechargeable batteries of dierent capacities.
• Remove batteries during longer storage periods. Batteries can leak
chemicals that can damage electronic parts.
Specifications
Power ...............................................................................................................................................
Drone ........................................................ 3.7V, 2000mAh lithium polymer battery
Remote Control ................................................................................4 × AAA batteries
Control Distance .................................................................................... max. 190 ft. (58m)
App Distance .............................................................................................max. 130 ft (40m)
Camera ...........................................................................................................................................
Lens Resolution (video) .......................................................................1280 × 720 MP4
Photo Resolution ................................................................................1280 × 720 JPEG
Maximum SD card support ......................................................................................32G
Specications are subject to change and improvement without notice. Actual product
may vary from the images found in this document.
Fly Safely
• This drone is designed for outdoor play. However, the drone is neither
waterproof nor weatherproof. Do not play in rain, snow, or windy conditions.
• Do not y the drone near or at other people or animals.
• Do not y your drone where emergency responders are working, or
emergency aircraft are operating.
• Keep the drone away from power lines, trees, weeds, and water.
• Do not y your drone over private property where you are not welcomed.
• Keep eyes, hands, hair, and loose clothing away from moving propellers.
• Fly safely. If the drone crashes, the SD card may fall out.
• Adult supervision is recommended at all times.
Charge the Drone Battery
Make sure you use the supplied battery and AC adapter, or one of the same
type: 3.7 V, 2000mAh lithium polymer.
1. Connect the supplied AC adapter as shown below. The LED on the
adapter lights red during charging, and turns green when charging is
complete.
A full charge takes about 120 minutes. A fully charged battery provides up
to 10 minutes of ight and camera time.
2. After charging, unplug the adapter and separate the battery connectors.
Do not attempt to overcharge the battery.
LED
2 hr
6 7
ON/OFF
Back LED (green)
Front LEDs (white)
Propeller
Wi-Fi Antenna
Drone Design Overview
Camera Lens
Adjustable. Rotate
90� to point down for
lming or snapping
aerial views
90°
Battery compartment
8 9
LED
Trim Control
Forward
Left Right
Reverse
6
Steering
Forward
Backward
Slide rightSlide left
Headless navigation
mode on/o
Take a photo
Start/ stop video recording
Remote Control Overview
One-touch takeo
º
Power on /o
Using the Detachble Device Holder
1. Slot holder onto antenna's groove until
it clicks.
2. Pull up holder bracket to extend and
insert your smart device (max. screen
width 3 inches).
3. Rotate lock to adjust and lock holder at
desired viewing angle.
4. Push holder up and o the groove with
both hands to release.
Antenna/ Support for
Device Holder
Start/ stop recording
video in beeline cruise
mode
Start/ stop recording
video in auto 360°
rotation mode
One-touch landing
13
2
Throttle
Ascend
Descend
Turn rightTurn left
Push
(Stunt
mode)
Push
(High/low
speed)
10 11
Pairing
1. Turn on the drone. The LEDs on the drone ash.
2. Place the drone on level ground.
3. Turn on the remote control. The remote control's LED lights up.
4. Move the throttle all the way up and then down to pair the remote control
with the drone. The drone’s propellers remain still during pairing. When
paired, all LEDs on both the remote control and drone light steadily.
Note: If pairing fails, turn o the drone and remote control and repeat the steps
above, or change locations to avoid electrical interference.
Multiple Player Pairing
You can play together with friends to y up to 6 Accelerators side by side.
Before pairing, make sure all players have switched o their Accelerators and
remotes. Players must pair their unit separately to avoid interference. Once
paired, keep your unit switched on, until the other players have also completed
pairing.
Fly Your Drone
1. There are 2 ways to take o. Place your drone on the ground and then either:
•Press the button. The drone will automatically take o, ascending
about 5 ft (150cm) and then hover.
• Move the throttle forward to ascend. To avoid ground air turbulence, y
the drone at least 1 ft. (30cm) o the ground.
2. For speed options, push the steering control in to switch between high
speed (double beep) and low speed (single beep).
IMPORTANT: If your drone crashes upside down, pull the throttle all the way
down. Wait till the propellers have stopped still before you handle the drone.
Land Your Drone
Automatically: Press and the drone will steadily descend and land.
Manually: Slowly move the throttle backward to descend. Avoid moving the
throttle too quickly, as it can stop the propellers instantly and cause the drone to
crash.
• When you nish ying the drone, turn o the remote control and drone.
Trim Your Drone
Push the throttle forward and observe how the drone reacts.
Forward/Reverse Movement Trim: If the drone tends to move forward, press
6
; if it tends to move backward, press .
Left/Right Slide Trim: If the drone tends to slide right, press
; if it tends to
slide left, press
.
Note: The remote control beeps when you press a trim control but stops
beeping when you reach maximum trim adjustment.
Fly in "Headless" Mode
Featuring an integrated true-north compass, the drone can automatically align
to y "headless". This simplies steering:
1. During ight, press on the remote. The drone's front LEDs ash when
headless mode is activated.
2. The drone will now y according to steering, regardless which way the
drone's head faces.
3. Press again to exit headless mode.
Perform 360° Air Flip Stunt
1. Push the throttle control to activate stunt mode. The remote control
beeps repeatedly.
2. Move the steering lever right or left to perform a 360 ° barrel roll.
3. The drone automatically exits stunt mode after performing a stunt, or
push in the throttle control again to exit immediately.
IMPORTANT: Make sure there is enough space, at least 6 feet in the air and
minimum clearance of 6 feet in all directions for the drone to perform stunts
without crashing into objects or people.
12 13
Using the Camera
For good pictures, use the camera in daylight or well-lit environments.
1. For players using the remote control, align and insert
a Micro SD card (not included) into the card slot in the
direction as marked. Push the SD card in until it clicks.
2. To remove the SD card, press it to eject.
Taking Photos and Videos
When the drone ies stably, on the remote control:
•Press once to take a photo. The remote control beeps and the drone's
back LEDs ash once.
•Press to record a video. Press again to stop recording and save
your le recording.
• To y and shoot video in a beeline, press .
• To shoot video in 360° panoramic view, press and the drone will
automatically steadily rotate whilst hovering. Press again to stop
shooting and return to normal ight mode.
Note:
• Video recordings are without audio, in order to omit the roaring drone motor.
• The remote control beeps and the drone's back LEDs ash repeatedly
during recording.
• The video recorded may fail to play in some video applications if (1) the SD
card falls out due to a crash; (2) you remove the SD card before stopping
recording; (3) battery power was too low during recording.
Download AccDrone App
1. For Android and iOS users, go to Google PlayTM or App Store® respectively
to download AccDrone app.
2. Follow screen instructions to install the app.
3. After installation, turn on the drone. The drone's LEDs start ashing
indicating pairing mode.
4. On your smart device, open the Wi-Fi setting to start searching for the list
of available Wi-Fi networks. Select the network named RS-xxxxxx (where
x represents an unique code.)
5. On your smart device, tap on the
AccDrone
app icon to open the app. When
the main menu screen appears, select "TAP TO BEGIN" to enter the app
control screen.
6. Upon successful connection with your drone, the drone LEDs stop
ashing and light up steadily.
7. Familiarize yourself with the onscreen app controls. Have fun ying!
App Controls Overview
KEY
1 Go to previous page
2 Take a photo
3 Start/ stop video recording
4 Start/ stop recording video in auto 360° rotation mode
5 Start/ stop recording video in beeline cruise mode
6 Enter folder view for playback of photos/ video. See page 14, "Playback
Photos/ Video."
7 Speed setting: 30/60/100%. Default 30%.
8 Activate/ deactivate headless mode
9 Activate/ deactivate stunt mode
10 Show/ hide throttle, steering and trim controls. Button icon toggles when
touched
11 Trim control: adjust forward
12 Steering control: forward/backward/slide left/ slide right
13 Trim control: adjust backward
14 Trim control: adjust right
15 Trim control: adjust left
16 Activate/ deactivate motion sensor control
17 Onebuttontakeo/landing: button icon toggles when touched
18 STOP: activate emergency landing. Motors will stop immediately and cause
the drone to fall in a hard landing. Avoid using STOP if drone is ying above 10
feet in the air to reduce damage from crash impact.
19 Throttle control: ascend/ descend/turn left/ turn right
1 2 3 4 5 6 7 8 9 10
11
12
13
18 17 16 15 14
19
14 15
Playback Photos/ Video
Accelerator photo and video shoots are stored in the app's 3 playback folders:
PICTURES, VIDEO and VIDEO Card.
• To playback, tap on the relevant folder to access content.
Note:
• For easy folder management, operate the camera either with the app
controls on your smart device, or with the remote control buttons.
• Remote control pilots: need to insert a SD card in the drone. Your media is
stored in the folder VIDEO Card.
• App pilots: there is no need to insert a SD card into the drone, unless you
like to use a SD card as backup. To view SD card content, the drone needs to
be switched on. Follow your device screen to access and view.
• For remote control pilots with smart device in holder: use your device
for instant playback. As well as shooting video and photos with your remote
control, you can also use the app's camera control buttons. In mixed control
mode shoots, app screen control shoots prioritize over remote control
shoots for storage.
Replace Damaged Propellers
The left and right propellers of the drone are
dierent (see A/B orientation marking on
propellers and on the rotor axles). You must use
the correct propeller in the correct location,
otherwise the drone will fail to take o.
WARNING:
• To avoid injury and damage, inspect the propellers for nicks and breaks and
make sure they are securely attached before and after each ight. Replace
nicked, chipped, cracked or broken propellers.
• Use only the supplied propellers. Do not alter, modify, or customize.
Troubleshooting
Drone does not respond
•Make sure the drone and remote control are switched on and paired.
•The drone battery may be low. Fully charge the battery. See “Charge the
Drone Battery.“
• Remote control battery may be low. Replace the batteries. For app pilots,
recharge your smart device if the battery status is low.
•Make sure the drone is within the control range and in line of sight.
Drone difficult to control
•The propellers may be deformed due to a crash. Adjust deformed propellers by
hand. If you cannot adjust the propellers, replace with the spare propellers.
• The throttle control is very sensitive. Use small, ne movements to control.
• If you are a beginner, set to low speed, use the takeo and landing buttons
, and select headless mode.
Drone swerves or moves erratically before taking off
• After a crash, the gyroscope inside your drone may need calibrating. On the
remote control, do the following:
1. Switch on your drone and remote control, and pair them.
2. Move the throttle all the way down and the steering forward at the same
time. Hold this position until the drone LEDs start to blink rapidly. Then
release the controls.
3. The drone LEDs light steadily. Calibration is successfully
completed, and you are now ready for takeo.
•See “Trim Your Drone" to further ne tune and improve
control of your drone after calibration, if necessary.
• For app pilots, calibration is similar to the above. Move and
hold the app's onscreen throttle and steering controls for 3 seconds, and
then observe the drone LED status described in steps 2-3.
Need Spare Parts?
Need more spare propellers, or lost some of the accessories? Consult your
dealer for details on the 6001462 Crash Pack for 6001436 Accelerator.
To replace a damaged propeller, use a screwdriver
to remove the old propeller. Insert a new matching
propeller onto the propeller axle, then screw
securely, but do not overtighten otherwise the
propeller won't turn.
B
B
A
A
B
A
16
© 2016 General Wireless Operations Inc.
All rights reserved. RadioShack is a registered trademark
used by General Wireless Operations Inc. dba RadioShack.
radioshack.com
Printed
in China
09A16
6001436
Complies with the European Union’s “Restriction of
Hazardous Substances Directive,” which protects
the environment by restricting specic hazardous
materials and products.
iPod, iPhone, iPad, iPad mini, iPad Air and iPod touch are trademarks of Apple Inc.
App Store is a service mark of Apple Inc.
Google Play and Android are trademarks of Google Inc.
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult your dealer or an experienced radio/TV technician for help.
If you cannot eliminate the interference, the FCC requires that you stop using your
equipment. Changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC Radiation Exposure
This equipment complies with FCC radiation exposure limit set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator and your body.
Limited Warranty
Go to www.radioshack.com/help for details.
RadioShack Customer Relations
300 RadioShack Circle, Fort Worth, TX 76102
CHOKING HAZARD! Small parts. Not for children under 3 years.
