ZHUHAI WINGPOW EROTIC and NOVELTY OMBBM01 Blue Motion User Manual Rev01
ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD. Blue Motion Rev01
User Manual Rev01
by
English
OhMiBod is committed to bringing you high quality
technology enabled pleasure products and accessories.
Before you begin enjoying blueMotion™, please take a
moment to review this manual.
How it Works
DOWNLOAD
OhMiBod®
Remote App
TURN ON
blueMotion™
PAIR
devices
+
+
blueMotion™ - What’s in the box
Bluetooth® enabled
wearable vibrator
Power button USB
charging socket
• Blue lace
thong OSFM
(one size ts most)
• USB
charging cable
• Privacy pouch
Bluetooth® Mode:
1. Press 3-4 seconds to turn on.
NOTE: Blinking blue LED power button indicates vibe is
ready to connect via Bluetooth®.
2. Pair to phone/tablet.
Bluetooth® range up to 26ft (8m)
NOTE: Pairing instructions can be found on next page.
3. Launch OhMiBod® Remote App.
4. Press and hold for 3-4 seconds to turn o.
NOTE: After 30 minutes of non-use, the massager with
automatically shut off to conserve battery life.
Using blueMotion™ - 2 Modes of Operation
Manual Mode:
1. Press 3-4 seconds to turn on.
2. Press again to switch to manual mode. First
pulsation is a continuous vibration. This conrms
manual mode is active.
Press to move to next pulsation pattern. There
are a total of 4 pulsations. Pressing the button
again will cycle back to Bluetooth® mode.
NOTE: A white LED power button conrms manual mode.
3. Press for 3-4 seconds to turn o.
How it Works
Blinking
Pairing Your Phone/Tablet
1. Turn on blueMotion™ massager.
NOTE: Blinking blue LED on power button
indicates massager is ready to pair.
2. Open the Bluetooth® settings
on your phone/tablet.
3. Select “OhMiBod”. This is
the blueMotion™ massager.
4. Select “Pair”. When prompted,
enter the PIN 0000.
0000
5. LED on power button glows
steady ( )when massager is
paired to phone/tablet.
Controlling blueMotion™ Via App
1. Download and launch OhMiBod® Remote App.
AVAILABLE FOR DOWNLOAD ON:
2. Blue indicates connection to phone/tablet.
Initial App instructions pop-up upon rst use.
ADDITIONAL SUPPORT can also be found at:
OhMiBod.com/app.
Additional information
provided “in App”
on Support.
Connected to
phone/tablet
Charging blueMotion™
Simply plug the USB charging cable provided with
blueMotion™ into the USB port on your computer
or USB wall charger adapter. Connect the other
end of the cable into the charging socket on the
end of blueMotion™ (see diagram). The LED on
blueMotion™ will blink indicating the massager
is charging. Please be sure that the massager is
completely dry before charging.
LED will glow steady ( ) when fully charged.
NOTE: The USB port is for charging use only, no data
transmission functionality. When product is charging, the
product will not be able to vibrate until the USB cable is
removed from charging socket.
Troubleshooting
If the LED does not blink when the product is
connected to the USB cable, check to make sure
the USB cable is properly connected to the USB
port and blueMotion™.
Battery Disposal
• blueMotion™ contains a rechargeable battery.
Please do not dispose of this product with
normal household waste.
• Please dispose of this product at the appropriate
electrical and electronic equipment recycling
disposal locations in accordance with
government regulations.
• The recycling of this product appropriately will
help to protect our environment
≈ 1.5-2 HRS TO REACH FULL CHARGE
Specications
blueMotion™
Materials: Body-safe ABS
Size: 3 3/4” length, 1 3/4” width, 0.5” depth
(90mm length, 43mm width, 13mm depth)
Weight: 2.3 oz. (65g)
Battery: Lithium-ion, 3.7V with 200mAH
Charging: 1.5-2 hours
User time: 1 hour
WIRELESS SPECIFICATIONS:
Bluetooth® Version 2.0
Frequency: 2.402-2.480GHz
Receive sensitivity: Better than -82dBm
Range: 26ft (8m)
Data rates: Up to 3Mbps (over the air)
UART data transfer rate: 115200bps
Care and Cleaning
• blueMotion™ is splash proof only. When cleaning,
avoid submerging in water and getting any
water into the charging socket.
• Clean after every use with mild soap and water.
Dry thoroughly.
• Store in privacy pouch to keep blueMotion™
clean and safe until next use.
Important Safeguards
• Do not use on areas that are swollen, inamed
or have skin lacerations.
• Stop using the massager if you experience
pain or discomfort.
• Do not submerge in water.
• Do not sure while bathing or in the shower.
No medical claims are warranted or implied by the use of this product.
Warranty
OhMiBod warrants this product for a period of one (1)
year from the date of original purchase, against defects
due to faulty workmanship or materials. In the event
that this product fails during the warranty period, simply
email us at customercare@ohmibod.com and provide
us with a valid proof of the date of original purchase and
we will replace the faulty product at no extra charge.
This warranty does not cover cosmetic deterioration
caused by normal wear and tear or damage caused
by accident, misuse, neglect or other use not in
accordance with this instruction manual. Any attempt
to open or take apart this product or its accessories
will void the warranty.
Contact Us
If you have any questions regarding your new product,
please check out additional information at
www.ohmibod.com/customercare. You can also reach
us via email at customercare@ohmibod.com.
Special Note from Founder
“OhMiBod’s goal is to reect the collective personality
of our customers who have an open, honest attitude
toward sexuality and personal pleasure. My hope is that
OhMiBod becomes a symbol of liberation, reecting
new and progressive attitudes toward personal pleasure
for the young and the young at heart...People who are
comfortable with their bodies, know what feels good and
who, not only aren’t afraid to admit it, are empowered to
go after it.”
FCC ID: XG5OMBBM01
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
CAUTION: The user is cautioned that changes or modications
not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Copyright© Suki, LLC 2014. All rights reserved.
Designed in the United States / assembled in PRC
RoHS
