ZIONCOM ELECTRONICS WL0159 WIFI MODULE User Manual WL0159 PIN SPEC

ZIONCOM ELECTRONICS (SHENZHEN) LTD. WIFI MODULE WL0159 PIN SPEC

user manual

Wireless
802.11g/b Adapter
ZC-WL0159 is a high-gain wireless PIN Interface adapter
which provides a simple and easy way to add or upgrade
wireless connectivity to your desktop or notebook
computer. You can just plug it into computer's A-type
USB 2.0 Connector port and enjoy incredible high-speed
wireless network access.
Complies with IEEE 802.11g; 802.11b standard for
2.4GHz Wireless LAN.
Supports Ad-Hoc/Infrastructure modes
Supports PC Card hot-SWAP and true Plug & Play.
Works with all existing network infrastructure.
Supports Wi-Fi Protected Setup (WPS) configuration
function
Capable of up to 128-Bit WEP Encryption.
Freedom to roam while staying connected.
22-Mbps Packet Binary Convolution Coding (PBCC)
(according to the IEEE Std 802.11b high-rate
specification ).
UP to 54 Mbps High-Speed Transfer Rate in 802.11g
mode of operation.
Rich diagnostic LED indicators with Integrated Antenna.
Supports Windows 2000, XP32/64,Vista32/64,
Linux,Mac
Low power consumption.
Easy to install and configure.
Standard IEEE802.11g; IEEE 802.11b
Modulation
Type
OFDM with BPSK, QPSK,
16QAM,64QAM (11g)
BPSK, QPSK, CCK (11b)
Interface 4PIN Interface
Frequency 2.4~2.4835 GHz
Transmission
Distance
Indoor up to 100m , outdoor up to
300m (it is limited in an
environment)
Data Rate
11b 1/2/5.5/11Mbps
11g 6/9/12/24/36/48/54Mbps
Auto fallback
Transmit Powe
r
15 dBm (Typical)
Data Security
64/128-bit WEP Data Encryption,
WPA (TKIP with IEEE 802.1x) and
AES
LED Indicator Link/Activity
Operating
Temperature 0 ~ 55
Storage -40°C~70°C (-40~158)
Humidity 5 ~ 95% non-condensing
Operating
System Windows 2000, XP32/64,
Vista32/64, Linux,Mac
WIFI MODULE
IEEE 802.11g/b
Model No: WL0159
Product Description
Product Features
Product
Specification
FCC Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and
receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician
for help.
To assure continued compliance, any changes or
modifications not expressly approved by the party
responsible for compliance could void the users authority
to operate this equipment. (Example- use only shielded
interface cables when connecting to computer or peripheral
devices).
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment and it also
complies with Part 15 of FCC RF Rules. Operation is
subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
Caution!
The manufacturer is not responsible for any radio or
TV interference caused by unauthorized
modifications to this equipment. Such modifications
could void the user authority to operate the
equipment.
1. This device and its antenna(s) must not be
co-located or operating in conjunction with any
other antenna or transmitter.
2. This compliance to FCC radiation exposure limits
for an uncontrolled environment, and minimum of
20 cm separation between antenna and body.
3. Only the type of chip antenna tested may be used.
4. The end product must carry a label stating
"Contains TX FCC ID: X7D-WL0159".
