User Manual
Quick Installation Guide
AC650 Wireless Dual Band USB Adapter
Suitable for: A650UA
Information in this document is subject to change without prior notice.
V1.1705
The driver installation process for Windows 10/8.1/8/7/XP are similar, here we take
Windows 8.1 for example.
After hardware installation, you will see below window showing
automatically. Click Run RTLautoInstallSetup.exe. (Note: if
the window not pop up, please refer to FAQ 1)
Click Install.
Copyrights TOTOLINK All rights reserved. Website: http://www.totolink.net
Please plug the wireless adapter into your PC or Laptop's USB port.
For more information, please visit www.totolink.net .
A650UA
Computer found the wireless LAN adapter
hardware, need to install the driver.
Hardware Installation
1
1. What to do if the auto run CD Drive window not pop up?
Please go to Computer/This PC and double-click CD Drive disk, see below:
2. How to put the antenna of A650UA to get best Wi-Fi signal? In order to
get best Wi-Fi in your house, we suggest you to keep the antenna.
perpendicular to the horizontal plane.
FAQ
4
Driver Installation
2
Click icon on the bottom right of the computer desktop.Choose your Wireless
network name,click Connect automatically and then Connect.
Wireless Network Connection
3
Wait for a few seconds.The window will close up when the
initialization complete.
FCC warning:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment .
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
