ZONDA de C V ZMUM820 GSM Mobile Phone User Manual ZMUM820
ZONDA Corporation, S.A. de C.V. GSM Mobile Phone ZMUM820
Users Manual
1
User's Manual
Mobile phone
Thank you for using our Mobile Phone.
To guarantee the best performance, please read this
manual carefully and keep it for further use.
We reserve the right to make modifications on print errors
or update specifications without prior notice.
2
CONTENTS
Security Requirements ··················· 4
Phone Overview (Picture for reference only)·· 5
Description of Keys ······················ 6
Getting Started·························· 6
Inserting SIM card and Battery ·····························6
Taking out the battery···································7
Charging the Battery ····································7
Security number ·······································8
General Features ························ 9
Turn on the phone ·····································9
To make Domestic calls ·································9
To reject a call ········································9
To answer a call ·······································9
To end a call conversation·······························10
Emergency calls ······································10
To make an international call ····························10
To dial from contacts ··································10
To dial from the Call list ································10
Call options··········································11
Power off ···········································11
Menu ································· 11
Messages (SMS) ························ 14
1. Create message ····································14
2. Inbox ············································15
3. Outbox ···········································16
4. Draftbox ··········································17
5. Templates ·········································17
6. Message settings ···································17
7. Memory status ·····································18
Contacts ······························ 18
1. New contact ·······································18
3
2. View contacts ······································19
3. View groups ·······································19
4. Special numbers ····································19
5. Advanced ·········································20
6. Storage status ······································20
Calls ································· 21
Tools ································· 22
1. Games············································22
2. Alarm ············································23
3. Calculator ·········································23
4. Calendar ··········································23
Settings······························· 23
1. General ···········································24
2. Display ···········································25
3. Sounds ···········································26
4. Call setup ·········································27
5. Network settings····································28
6. Factory default ·····································28
FM Radio······························ 28
SIM Tool Kit ··························· 30
Maintenance ··························· 30
Security Requirements ·················· 31
4
Security Requirements
These instructions are intended for safe and effective use of your
phone. Please follow these guidelines. Failure to do so might cause
the product to malfunction or even a potential hazard to your
health.
Do not use your mobile phone while driving. Park the car before
making a call.
Turn off your phone when refueling.
Do not use your phone near a gas station, flammable, or chemical
substances.
Warning! It may explode when exposed in fire.
Do not use your phone during a flight, it is dangerous.
Do not use your phone near medical equipments like
pacemaker and hearing aids without requesting permission from
the physician or medical staff.
Radio signals may affect the performance of the phone.
Do not touch any exposed parts of the antenna during a call;
otherwise it will affect the call reception and waste battery power.
Do not attempt to disassemble or modify the phone by yourself.
Only authorized personnel should perform this service.
When you connect accessories to your phone, please read the
safety guidelines carefully.
Do not use unauthorized products.
Please use only the original accessories or products that are
authorized by our company.
Keep out of children's reach.
5
Phone Overview (Picture for reference only)
Left Soft key
Answer/Dial key
Right Soft key
End/Power key
Navigation key
6
Description of Keys
Key Description
Left Soft key Activates/selects the menu function at the
left bottom side of the LCD screen.
Right Soft key Activates/selects the menu function at the
right bottom side of the LCD screen.
Answer/Dial key Dials and answers calls. In standby mode,
press to view recent calls.
End/Power key
Ends or reject calls; Power on/Power off;
In the menu programming, press to return
to standby mode.
Navigation key
In standby mode, press;
Left – Date & time setting.
Right – Create message.
Down – Contact list.
Getting Started
Inserting SIM card and Battery
WARNING!
Keep SIM Card out of children's reach.
Any abrasions or bend might easily cause damage. Please take
extra care.
Make sure the phone is power off when you remove the SIM
Card.
Remove the battery cover by sliding downward.
Insert the SIM Card into the sim card slot with the contacts
facing down.
Place the battery into place. Make sure that the charge pins
are in contact with the battery terminals.
Slide the battery cover until it locks into place.
7
Taking out the battery
Remove the battery cover. Insert your fingernail at the bottom
slot of the battery compartment and then pull out the battery.
Charging the Battery
Insert the connector of the charger into the top-left side of the
phone (Note: Ensure that the charger connector is plugged in.
Plug the charger into the AC wall outlet.
When the power comes on, “Charging…” will be displayed on
the LCD screen, and the battery indicator will start to scroll. It
will only stop after the battery comes to full charge. If a battery
is completely discharged, it may take a few minutes before the
charge indicator appears on the LCD screen.
After charging is completed, disconnect charger from phone
and the socket of the alternating current.
Notice:
When charging, please place the phone in an environment that
has a normal room temperature and good ventilation. It is
recommended to charge the phone in an environment with a
temperature that ranges from 5℃~40℃. Please ensure to use
only the charger offered by the manufacturer. Using
unauthorized charger may cause danger and violate the
authorization of the phone and the guarantee article.
When the phone automatically turns off or indicates the alarm
information of power shortage, please charge the battery in
time.
The duration time of the standby and conversation of the
phone offered by manufacturer is based on ideal working
environment. In may vary according to the network condition,
working environment, and application methods.
8
Warnings!
Do not take the battery out when it is being charged.
To ensure best performance, please use original accessories.
Using any unauthorized accessories may affect your mobile
phone’s performance.
Personal data and settings in your phone and SIM card might
lose when you take out the battery.
Security number
PIN
PIN (Personal Identity Number), usually provided to a SIM Card by
the network operator.
If you enter the wrong PIN three times in a row, it will be locked.
You need to enter your PUK (Personal Unblocking Key) number to
unlock. Please contact your network operator for more
information.
PIN2
PIN2 is provided to some SIM. If you enter the wrong PIN three
times in a row, it will be locked. You need to enter your PUK2 to
unlock. Please contact your network operator for more
information.
PUK
PUK (Personal Unblocking Key) is used to unblock the PIN. PUK is
provided to a SIM card. If you lose or forget the password, contact
your network operator.
Phone code
Protects your phone against unauthorized use. You can turn on the
Phone code for your personal security use.
9
General Features
Turn on the phone
1. Press and hold Power key to turn on the phone. The LCD screen
will turn on.
2. If SIM card is not properly installed, a warning prompt will
appear on the screen. Press and hold Power key to turn off, and
re-install the SIM card properly.
3. If you have set a phone password, you will be asked to enter your
password.
4. If your SIM card is protected by PIN, the phone will instruct you
to enter the PIN number.
5. You will be asked to enter the PUK number if SIM card is locked.
6. The phone will search for network automatically after turned on.
Warning!
If the phone has found an authorized network operator, the
name of the network and signal intensity will be displayed.
If not, you can only use the emergency calls and other
non-communication service.
To make Domestic calls
In standby, enter a phone number (with region code and area code),
Press Clear key to delete a wrong entry. Then press Dial key to dial
the number. When the call gets connected, the call status will be
displayed.
To reject a call
When you have incoming call, press End call or End key to reject it.
To answer a call
When a call comes in, phone will ring and/or vibrate. It will show
the caller's name if the network support it. The caller’s name
display depends on whether you have saved it in your phonebook.
10
Press Dial key to answer, or press
Options -> Accept
.
To end a call conversation
When you have finished talking, press End key to end a call
Also, you can press End key if you want to terminate a call after you
dialed.
Emergency calls
You do not need to own a SIM card to make emergency calls.
Emergency calls may differ from different network operators,
please contact your network operator to get your local emergency
call number.
To make an international call
To make a international call, press and hold【0】to switch until a +
sign appear.
Then enter the country/region code, area code (without the first
zero), and the phone number:
After you have entered the + sign, enter the country code and the
number you want to dial. For example, 49 for Germany, 44 for UK,
46 for Sweden, 86 for China.
Ex.: dial +8613798297223, when making an international call to
China.
As you dial a common international call, you don’t have to enter the
0 of the city code.
To dial from contacts
Find the number you want to call in your phone book, press Dial
key to automatically dial the displayed contact.
To dial from the Call list
All the numbers that you have dialed are saved in the calls record.
When the calls memory turns full, the old numbers are
11
automatically deleted. To scroll the call list:
1. In standby, press Dial key. The call records will display starting
from the most recently called number. Press Dial key to
automatically dial the displayed record.
2. Or, press Up or Down key to scroll the list and then press Dial
key to automatically dial the selected record.
Call options
While in a phone conversation, press Left soft key to enter the
calling options or press Right soft key to activate the Handsfree
mode.
In the call options, you can
Mute
Hold
End
View contacts
Power off
In standby, press and hold Power key to turn off your phone.
Menu
Messages
1. Create message
2. Inbox
3. Outbox
4. Draftbox
5. Templates
6. Message settings
7. Memory status
Contacts
1. New contact
12
2. View contacts
3. View groups
1. Family
2. Friends
3. Office
4. Others
4. Special numbers
1. My numbers
2. Voice mail
5. Advanced
1. Speed dial
2. Choose contact
3. Copy
4. Delete all contacts
6. Memory status
Calls
1. Incoming calls
2. Outgoing calls
3. Missed calls
4. Call duration
Tools
1. Games
2. Alarm
3. Calculator
4. Calendar
Settings
1. General
1. Language
2. Time and date
1. Date & time setting
2. Date display format
13
3. Date separator
4. Time display format
3. Answer mode
1. Normal answer
2. Any key answer
4. Security
1. PIN protection
2. Phone lock
3. Keypad locking settings
4. Change password
2. Display
1. Idle display
1. Time and date
2. Idle text
3. Wallpaper
2. Contrast
3. Backlight
3. Sounds
1. Ringtones
1. Incoming call
2. Message
3. Key tone
2. Volume
1. Call
2. Ring tone
3. Key tone
3. Alert type
Ring only
Vibrate only
Vibrate and ring
4. Call setup
1. Call divert
2. Call barring
3. Call waiting
14
4. Auto redial
5. Caller ID
5. Network settings
Automatic mode
Manual mode
6. Factory default
FM Radio
SIM Tool Kit
Messages (SMS)
SMS is a network service, which enables you to send, receive, and
edit text messages from your mobile phone.
1. Create message
In the Message window, select
‘Create message’
menu. Before you
start, make sure that the number of the service center is set. The
number is supplied by the service provider and is usually saved on
the SIM card.
If you have entered a wrong letter or number, press Clear to erase
the last entry or press and hold Clear to erase the whole writing.
15
Using traditional text input ABC, Abc, or abc
Check what is shown at the top of the display. Press a key one
or more times until the desired character is displayed. Not all
available characters are printed on the keys. The characters
available depend on the Phone language setting.
If the next letter you want is located on the same key as the
present one, wait until the cursor is shown and key in the
letter.
To add a common punctuation mark, press 1 key repeatedly
until the character is displayed.
To add a symbol, press * key, scroll to the character and
press OK key to input.
To insert a space, press 0 key.
To move the cursor, press Up-Down, Left-Right keys.
To delete the character to the left of the cursor, press Clear
key. Press and hold Clear key to delete all characters.
To change the text input, press # key repeatedly until the
desired input;
language guobi, ABC, Abc, abc, or 123
is
displayed at the top of the screen.
After completing the message, press Options and then select;
Send
- to send the message by dialing the recipient number
or by selecting a number from the Contact list.
Save
- to store the message in the Archive.
Send to many
- to send the message to two or more
recipients. You can add up to 5 recipients.
Note: You can cancel the write message operation at any
time by pressing End key and return to standby mode.
2. Inbox
You can check the messages you received in the Inbox menu. A
16
closed and opened envelope icon indicates the messages you have
and haven’t read.
When you received a new message, your phone will ring and or
vibrate. Press the left soft key to read the message. You can also go
to the Inbox menu to read the message/s.
When the inbox gets full, a message will prompt will to inform that
the message memory is full. To continue receiving messages,
delete some messages. If a new message comes in and is too long
for the current memory capacity, some of the message content may
not be displayed and might lose.
After viewing a message, press Options key and then select;
Reply:
to reply the message sender.
Forward:
to forward the message.
Call:
to call the message sender.
Save number:
to save the telephone number of the message
sender into the SIM or phone memory.
Delete:
to delete the current inbox message.
Delete all:
to delete all of the messages.
3. Outbox
The Outbox automatically stores the messages you sent when the
‘Auto save SMS’ on the Message settings is set to On.
After viewing a message in the Outbox, press Options key and then
select;
Send:
to re send the message to the same recipient.
Forward:
to forward the message.
Call:
to call the number of the message recipient.
Save number:
to save the telephone number of the message
recipient into the SIM or phone memory.
Delete:
to delete the current outbox message.
Delete all:
to delete all of the messages.
17
4. Draftbox
The Draftbox stores the messages that you save.
After viewing a message in the Draftbox, press Options key and
then select;
Forward:
to forward the message.
Edit:
to edit the content of the message.
Delete:
to delete the current draftbox message.
Delete all:
to delete all of the messages.
5. Templates
The Templates menu contains pre-drafted messages. You can
choose a template message and then press
Options -> Send
to
send the message at an instant.
Or, edit the template message by adding more before sending.
6. Message settings
Includes options for changing the settings of message services
such as; Service Center, Validity Period, Auto save SMS, Deliver
report, Preferred Storage, and Broadcast message.
Service Center:
1. In the Message settings display, select Service Center .
2. Press Ok key to view/change the service center number,
then press Ok key to confirm.
Note: The Service Center number is usually assigned by
your SIM card provider.
Validity period
1. In the Message settings display, select Validity period.
2. Press Ok key to view/change the length of time for which
the network should attempt to deliver your message.
3. Press Ok key to confirm.
18
Auto save SMS
1. In the Message settings display, select Auto save SMS.
2. Select “On” to automatically save the message on the
Outbox memory, otherwise select “Off” option.
Delivery report
1. In the Message settings display, select Delivery report.
2. Set to "On" to request the network to send a reply back
information to the receiver, or select "Off" option.
Preferred storage
1. In the Message settings display, select Preferred storage.
2. Select; SIM or Phone.
3. Press Ok key to confirm.
Broadcast message
Request the network to send text messages on the selected
topics. The availability of this service depends on the network
operator.
In the broadcast message options, select Receive mode.
Set to “On” to receive, otherwise set to “Off.”
7. Memory status
In the Message set up, select Memory status.
Press Ok key to display the total and used capacity for both SIM and
Phone memory.
Contacts
Stores your contact list in the SIM or Phone memory.
1. New contact
Adds contact to the Phone memory.
19
1. In the Contacts display, select New contact.
2. Input the name and then press OK key.
3. Input the number and then press OK key.
4. The new contact will be saved automatically in the phone
memory.
5. Repeat steps 1 to 4 to add more contacts.
2. View contacts
Note: To screen the contacts display, set the ‘Advanced/Choose
contacts list’ option to
SIM only, Phone only, or All contacts
.
1. In the Contacts display, select View contacts.
2. Input the first letter of a name, and the search will jump to
the first entry beginning with that letter.
3. Press Up or Down key to scroll through the list.
3. View groups
You can store the phonebook records into groupings and
designate a distinctive ring tone for each group.
1. In the Contacts display, select View groups.
2. Select;
Family, Friends, Office, or Others
.
3. Press Ok.
4. Select;
Group member -> Options -> Add member.
5. Select the record from the phonebook and press Add.
To assign a Ring tone in a Group
1. Select the group;
Family, Friends, Office, or Others
.
2. Select
Alert tone
.
3. Use Up or Down key to scroll through the ring tone list and
then press Ok key to confirm the selection.
4. Special numbers
1. In the Contacts display, select Special numbers.
2. From the options, select; My numbers or Voice mail.
In the ‘My numbers’ menu, you can store your SIM card
number.
20
The ‘Voice mail’ menu allows you to connect to the voice
Mail message server to retrieve your voice mail message.
The voice mail service requires subscription to the mobile
network. Please call your local network operator for details.
5. Advanced
1. In the Contacts display, select Advanced.
2. Select;
Speed dial, Choose contacts list, Copy, or Delete all
contacts.
Speed dial
1. Select the speed dial memory.
2. Press Set/Change and then select the phonebook record you
wish to store in the selected speed dial memory.
3. Press Ok key.
To make a Speed dial call;
In standby mode, press the Speed dial key and then press
Dial key to automatically dial out the stored number.
Choose contacts list
To set the contacts display on the View Contacts menu.
1. Select;
SIM only, Phone only, or All contacts.
2. Press Ok key.
Copy
To copy all phone contacts to SIM or vice versa.
1. Select;
Copy to phone or Copy to SIM
2. Press Ok key.
Delete all
To delete all of phone or SIM contacts.
1. Select;
Delete all phone contacts or Delete all SIM contacts.
2. Press Ok key.
6. Storage status
Displays the memory condition of the SIM and phone.
1. In the Contacts display, select Storage status.
21
2. The memory status will display, press Back key to return
to the previous menu.
Calls
This phone can record Incoming calls, Outgoing calls, Missed calls,
and Call duration.
1. Incoming calls
Shows the answered incoming calls. It shows the telephone
number or the name, if the caller's number is identified with the
name and number that is stored in the Phonebook memory, date,
and time of the call.
1. In the Calls display, select Incoming calls.
2. The incoming call list will display, select the record you wish
to view.
3. Press
Options
and then;
Call, Send SMS, Delete, Save number, Delete all, or Show
number.
4. Press Ok key.
2. Outgoing calls
Shows the list of phone numbers that you have most recently
dialed or attempted to call.
1. In the Calls display, select Outgoing calls.
2. Select the record you wish to view.
3. Press
Options
and then;
Call, Send SMS, Delete, Save number, Delete all, or Show
number.
4. Press Ok key.
3. Missed calls
22
Shows the latest records of unanswered incoming calls, if available
from the network.
1. In the Calls display, select Missed calls.
2. Select the record you wish to view.
3. Select
Options
and then;
Call, Send SMS, Delete, Save number, Delete all, or Show
number.
4. Press Ok key.
4. Call duration
Shows the elapsed time of incoming calls, Outgoing calls, and the
most recent last call.
1. In the Calls display, select Call duration.
2. The LCD screen will display the
Outgoing duration,
Incoming duration, and the Last call duration.
3. Press Reset key to reset the time duration back to zero.
Tools
1. Games
Your phone is equipped with games;
Sokoban and Minesweeper
.
To access the Games;
1. In the Tools display, select Games.
2. Select the game you want to play.
3. Select;
Start
- to start playing the game, or
Games Help
- to familiarize yourself with the controls before
playing the game.
3. Press Ok key to confirm.
23
2. Alarm
You can set three alarm times options in your phone.
Setting the Alarm clock
1. In the Tools display, select Alarm.
2. Select;
Alarm 1, 2, or 3.
3. Press Right or Left key to select;
Off, Once, Mon~Fri, or
Everyday.
4. Press Down key once.
5. Input the alarm time.
6. Press Down key again.
7. Press Right or Left key to select the Alarm tone.
8. Press Ok key to confirm the setting.
3. Calculator
The calculator in your phone only performs basic calculation.
To use;
1. Input the first set of numbers (up to 9 digits including the
decimal).
2. Press the arithmetic operation.
Up key: +, Down key: -, Right key: /, Left key: X
3. Input the second set of numbers (up to 9 digits including the
decimal).
4. Press Equals key to display the result.
4. Calendar
Select to display the calendar menu.
Settings
In Settings, you can set the general functionality of the phone
according to your preference.
24
1. General
1. In the Settings display, select General.
2. Select;
Language, Time and date, Answer mode, or Security.
Language
Sets the language display on the phone.
1. Select;
English or Chinese.
2. Press Ok key to confirm.
Time and date
Sets the time and date and display format.
1. Select;
Date & time settings. Date display format, Date
separator, or Time display format.
2. Press Ok key.
Time and date settings
Sets the time and date.
1. Input the current date.
2. Press Down key once.
3. Input the time
4. Press Ok key.
Date display format
1. Select the preferred date display format.
2. Press Ok key.
Date separator
1. Select the preferred date display setting.
2. Press Ok key.
Time display format
1. Select the time display format;
12 or 24 Hours
.
2. Press Ok key.
Answer mode
1. Select;
Normal answer or Any key answer.
2. Press Ok key.
Security
1. Select;
PIN protection, Phone lock, Keypad locking settings,
25
or Change password.
2. Press Ok key.
PIN protection
1. Select;
SIM lock, Change PIN1, or Change PIN2.
2. Press Ok key.
Phone lock
1. Select;
On or Off.
2. Press Ok key.
Keypad Locking Settings
1. Select the desired keypad lock time, otherwise set to
“Off.”
2. Press Ok key.
Change password
1. Enter the old password and then press Ok key.
2. Enter the new password and then press Ok key.
3. Enter the confirm password and then press Ok key.
2. Display
1. In the Settings display, select Display.
2. Select;
Idle display, Contrast, or Backlight.
Idle display
Turns on/off the time and date display, enables/disables the
idle text display, and sets the wallpaper.
1. Select;
Time and
date, Idle text, or Wallpaper.
2. Press Ok key.
Time and date
1. Select;
Enable or Disable
.
2. Press Ok key.
Idle text
1. Select;
Enable or Disable
. When enabled, input the
greetings you wish to display.
2. Press Ok key.
Wallpaper
1. On the wallpaper display, press Ok key to view the
26
picture.
2. Press Right or Left key to scroll through the wallpaper
files.
3. Press Ok key to confirm the selection.
Contrast
1. Press Right or Left key to adjust the contrast setting of the
LCD screen.
2. Press Ok key to confirm.
Contrast
1. Select the desired time when the backlight turns off or set to
Always on
.
2. Press Ok key to confirm.
3. Sounds
1. In the Settings display, select Sounds.
2. Select;
Ringtones, Volume, or Alert type.
Ringtones
Sets the incoming call ring, message tone, and key tone.
1. Select;
Incoming call, Message, or Key tone.
2. Press Ok key.
Incoming call
1. Press Up or Down key to scroll through the ring tones.
2. Press Ok key to confirm the selection.
Message
1. Press Up or Down key to scroll through the SMS tones.
2. Press Ok key to confirm the selection.
Key tone
1. Select;
On or Off.
2. Press Ok key.
Volume
Sets the volume level of the call, ring tone, and key tone.
1. Select;
Call, Ring tone, or Key tone.
2. Press Ok key.
3. Press Up or Down key to adjust the volume level to your
27
desired setting.
4. Press Ok key to confirm.
Alert type
1. Select;
Ring only, Vibrate only, or Vibrate and ring.
2. Press Ok key to confirm.
4. Call setup
1. In the Settings display, select Call setup.
2. Select;
Call divert, Call barring, Call waiting, Auto redial, or
Caller ID.
Call divert
1. Select;
All calls, If busy, If no reply, or If out of reach.
2. Press Ok key.
3. Select;
Check status, Activate, or Deactivate.
To activate,
enter the call divert phone number.
4. Press Ok key.
Call barring
1. Select;
All outgoing calls, All international calls, Only here
and home, All incoming calls, or Incoming calls if abroad.
2. Press Ok key.
3. Select;
Check status, Activate, or Deactivate.
4. Press Ok key to confirm.
Call waiting
1. Select;
Check status, Activate, or Deactivate.
2. Press Ok key to confirm.
Auto redial
1. Select;
Enable or Disable.
2. Press Ok key to confirm.
Caller ID
1. Select;
Set by network, Hide number, or Show number.
2. Press Ok key to confirm.
28
5. Network settings
1. In the Settings display, select Network settings.
2. Select;
Automatic mode or Manual mode.
3. Press Ok key.
6. Factory default
1. In the Settings display, select Factory default.
2. The LCD display will prompt “Enter phone code.”
3. Input the number code
(the factory default number setting is
0000.)
4. Press Ok key.
Note: After restoring to the factory default setting, all of the
current settings will return to the factory preset condition.
FM Radio
Note: The FM radio function can only be activated after inserting
the headset. Use only the headset type that comes with this phone.
FM Channel manual search
In the FM radio display, use Left or Right arrow keys to scan for
an active FM channel station.
29
To save an active FM channel
1. After scanning an active FM channel , press
Options -> Save
channel.
2. Input a name and then press Ok key.
FM Channel Auto Search
1. In the FM radio display, press
Options -> Auto search.
2. The phone will automatically search for clear FM channels
and stores them all in the FM Channel memory.
Note: This operation may take a few minutes.
Play FM Radio on the background
While tuned in to a current channel, press
Options -> Play in
background.
You can open the Menu programming options
while listening to the radio.
Changing channels
While tuned in to a current channel, press Up or Down key to
change channel, Or;
1. Press
Options -> Channel list
.
2. Select the desired channel and then press
Options -> Play.
Select band function
You can input the channel band of your favorite FM station.
1. In the FM radio display, press
Options -> Select band.
2. Input the channel band.
Example for 104.3 Mhz, enter: 1043
3. Press Ok key.
Adjusting the receiver volume
30
While tuned in to a current channel, press # or * key to increase
or decrease the receiver volume.
Listening to the FM radio over the phone speaker
1. While tuned in to a current FM channel, press
Options ->
Loud speaker
.
2. Select On to listen to the radio on the phone speaker.
Important: While tuned in, do not unplug the headphone.
SIM Tool Kit
Maintenance
Battery instructions
When the phone automatically turns off or indicates the alarm
information of power shortage, please charge the battery in time.
For the first few times, please charge the battery fully.
When not in use, please separate the battery with power
supply. Overcharging will shorten the life of the battery.
31
Do not expose your products to extreme high or low
temperatures. Do not expose the battery to temperatures
above+40℃.
Do not use damaged battery.
Do not expose your mobile phone to direct sunlight or in hot
areas. High temperatures can shorten the life of electronic
devices.
Do not expose the battery into fire or throw it away. Return the
wear-out battery to the provider or put it in the appointed
recycle place. Do not put it in familial rubbish.
Follow these guidelines to protect your products:
keep the products out of children's reach
Keep your product dry. Do not expose it to liquid or moisture.
Do not short-circuit the battery, as this can cause excessive
heat to bring about fire.
Do not expose your mobile phone to direct sunlight or in hot
areas. High temperatures can shorten the life of electronic
devices.
Do not attempt to disassemble the phone and battery by
yourself.
Prevent any liquid from leaking into your phone.
Please only use original accessories. Using any unauthorized
accessory may affect your mobile phone’s performance.
Security Requirements
Before making or answering a call, you should pay attention to the
local laws about the use of wireless mobile phones and take them
into account in practical use.
Traffic safety
Pay attention to traffic safety. Do not use your mobile phone
while driving. Park before making or answering a call.
32
Without enough shield, some electronic devices in the car
might
interfere to the radio frequency of your phone.
If you have to use your phone in a car, make sure it has an
antenna.
Only qualified technician can install your phone into your
automobile.
Flight Safety
Please turn off your GSM mobile phone before the airplane takes
off. In order to protect airplane’s communication system from
interference, it is never allowed to use mobile phone when it is in
flight.
Using mobile phone before the plane taking off should get
aircrew’s permission according to safety regulations.
Do not use your phone where a potentially dangerous atmosphere
exists.
Operating of mobile phone may interfere with medical devices like
hearing aids and pacemakers.
Please strictly observe with the restrictions on the use of wireless
devices.
Warning!
1. The performance of your phone depends on your local network
operator’s card and how you actually use it.
2. We are not responsible for any damages due to inappropriate
use.
3. We reserve the right to make any modifications on this manual
without prior notice.
33
It is recommended that you do not use your cellular phone near a telephone, TV set, radio or other
radio frequency sensitive devices.
Requirements for the Battery
When not in use, store the battery in a cool, well-ventilated place.
If you will not be using the cellular phone for an extended period of time, charge the battery on a regular
basis to avoid battery breakdown.
The phone battery wears out fast. If charging the battery does not improve its performance, it is time to
replace the battery. Properly dispose of the battery according to local regulations. Do not throw it into a
fire.
Requirements for the Charger and AC Adapter
Do not charge your phone under the following circumstances: sunshine, temperatures equal to or lower
than 0ºC, temperatures equal to or higher than 40ºC, high humidity, dust, high vibration areas, or near a
TV, a radio, etc.
Specific Absorption Rate (SAR) information
This Model wireless phone meets the government’s requirements for exposure to radio waves.
The guidelines are based on standards that were developed by independent scientific organizations
through periodic and thorough evaluation of scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons regardless of age or health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the
Specific Absorption Rate, or SAR, The SAR limit set by the FCC is 1.6 W/Kg.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
