User manual
cdma2000 Wireless Data Terminal
User Manual
The manual is applicable for the AC3633
Copyright © 2012 by ZTE Corporation
All rights reserved.
No part of this publication may be quoted, reproduced, translated or used
in any form or by any means, electronic or mechanical, including
photocopying and microfilm, without the prior written permission of ZTE
Corporation.
ZTE Corporation reserves the right to make modifications on print errors or
update specifications in this manual without prior notice.
Version 1.0 in Nov. 2012
Contents
Let’s get started ...................................................................................................... 1
Lost or stolen? ...................................................................................................... 1
Using your router safely ....................................................................................... 2
Inserting and removing the SIM ............................................................................ 6
Restore factory settings ........................................................................................ 6
LED .......................................................................................................................... 7
Functions of Data card ........................................................................................... 8
Install .................................................................................................................... 8
Onscreen icons .................................................................................................. 10
Uninstall ............................................................................................................. 10
Functions of router ............................................................................................... 11
Visit WEB UI ....................................................................................................... 11
Onscreen icons .................................................................................................. 12
Wireless Settings ............................................................................................... 12
Basic settings ............................................................................................. 12
Web UI dial settings .................................................................................... 13
Security settings ......................................................................................... 14
Appendix ............................................................................................................... 15
Care and maintenance ....................................................................................... 15
FCC regulations ................................................................................................. 17
Declaration of RoHS compliance........................................................................ 21
Disposal of your old router ................................................................................. 22
Problems and their solutions .............................................................................. 23
Let’s get started
1
Let’s get started
Thanks for choosing the AC3633. It’s a cdma2000 Wireless Data Terminal,
which we’ll simply call ‘router’ from now on.
If you’d like your router to live a long and fruitful life, please read this guide
carefully and keep it for future reference. You never know when you might
need it.
And don’t worry if the pictures we use to demonstrate your router’s
functions look a little different from what you see on its screen. It’s the
functions they show that matter.
Lost or stolen?
If your router goes missing, please tell your service provider as soon as
you know. That way other people can be barred from using it.
We’d strongly advise you to set a PIN, and change it from time to time.
Let’s get started
2
Using your router safely
on the road
Using a router while driving is illegal in many countries. Please follow
local laws and drive safely at all times.
near sensitive electronics
Don’t use your router near sensitive electronic equipment – particularly
medical devices such as pacemakers – as it could cause them to
malfunction. It can also interfere with the operation of fire detectors and
other automatic-control equipment.
For more information about how your router affects pacemakers or
other electronic equipment, please contact the manufacturer or your
local distributor.
Your router may cause interference when used near TVs, radios or
automated office equipment.
while flying
Your router can cause interference with aircraft equipment. So it’s
Let’s get started
3
essential you follow airline regulations. And if airline personnel ask you
to switch off your router, or disable its wireless functions, please do as
they say.
in hospital
Your router may interfere with the normal operation of medical
equipment. Follow all hospital regulations and turn it off when you’re
asked to by posted warnings or medical staff.
at a petrol station
Don’t use your router at petrol stations. In fact, it’s always best to switch
off whenever you’re near fuels, chemicals or explosives.
around water
Keep your router away from water (or any other liquid). It’s not a
waterproof model.
making repairs
Never take your router apart. Please leave that to the professionals.
Unauthorised repairs could break the terms of your warranty.
Let’s get started
4
around children
Keep your mobile out of children’s reach. It should never be used as a
toy and it might not be good for their health.
original accessories
Only use the original accessories supplied with your router or those
approved by the manufacturer. Using unapproved accessories may
affect performance, make the warranty void, break national regulations
on the use of routers, or even cause injury.
near explosives
Turn off your router in or near areas where explosive materials are used.
Always obey local laws and turn off your router when requested.
working temperature
The working temperature for the router is between 0℃ and 40℃.
Please don’t use the router outside the range. Using the router under
Let’s get started
5
too high or too low temperature might cause problems.
Let’s get started
6
Inserting and removing the SIM
1. Take out USB interface and SIM card cover in the direction indicated by
the arrow.
2. Insert SIM card as below.
3. Push back SIM card cover.
Restore factory settings
As the router is working, long press Reset key to restore factory settings.
LED
7
LED
Functions Descriptions
Power on，WiFi function normal WiFi blue light slow flash
WiFi connect built WiFi blue light is normally on
WiFi off or abnormal WiFi blue light is off
Not register to the net 3G red light slow flash
Register to the net 3G green light flash
Dial success and connect to the net 3G green light is normally on
Power is given WiFi blue light、3G red and green light is on
Functions of Data card
8
Functions of Data card
When connected with the PC, the router can be used as a data card. It
supports Windows XP/Vista/7, MAC and Linux operating system. In the
area where there is signal, it allows you to go surfing on the Internet.
Note:
As the router is used as a data card, the Wi-Fi function is Off
automatically.
Install
1. Please connect the router with PC through USB interface. You could
use the USB extension cable to connect.
2. The installation driver will automatically run. Please follow the wizard to
install.
3. The system will automatically find new hardware and install the driver.
Wait for a while. Click “Finish” after the installation is completed.
Functions of Data card
9
Note:
If your CD-ROM autorun function is prohibited by the firewall,
the auto installation interface will not appear. In this case, go to
“My computer” to find the virtual CD-ROM and run the relevant
installation application in the virtual CD-ROM.
After the application is installed successfully, the application icon will
appear on your desktop. Double-click this icon, run the application to
display the user interface.
The icons on the interface are used to access the following functions in the
table below:
Open URL NetConne
ct
NetConne
ct Log
Functions of Data card
10
Settings Help
Onscreen icons
Icons Descriptions Icons Descriptions
EVDO Rev A network indication Sleep indication
Signal strength indication, the
more bars there are, the
stronger the signal is. Roaming indication
CDMA network unavailable No SIM card inserted
indication
Connection indication SIM card inserted indication
Uninstall
1. Select Start All Programs ZTEMT Uninstall ZTEMT UI,
and you will be asked if you want to remove the program. Click “Yes”.
2. Please wait and then click “OK” when un-installation is completed.
Functions of router
11
Functions of router
Note:
1. Prior to use, please check if your computer has Wi-Fi
function or not.
2. The router only supports the main stream browsers, e.g.,
IE6+, firefox 3+, etc.
Visit WEB UI
1. Click the icon “Wireless Network Connection” in the right-down corner,
find AC3633-XXX in the network list and click “Connect”.
2. Run IE browser and input http://192.168.1.1.
3. Input the username: admin and password: admin to enter the user
interface.
4. In the user interface, go to Management homepage Network
connection Auto connect or not and select “Yes” or “No”. Click
Functions of router
12
“Connect” to manually connect to the network if you select “No”; after
settings, please click “Apply” to save the settings.
Onscreen icons
Icons Descriptions Icons Descriptions
CDMA network
indication Battery capacity
Connected Disconnected
Connecting Disconnection
Wireless Settings
Basic settings
Current profile: display the current network status.
Network name: display the current router’s part number.
Network broadcast: the default is ON. The terminal can find the
wireless network during wireless network scanning only as the
Functions of router
13
network broadcast is turned ON.
MAC address: display the current MAC address in use.
Network mode: G-only, B-only, B/G Mixed, The default is B/G
Mixed.
Channel: auto, from 1 to 13; the default is auto.
After settings, please click “Apply” to save the settings, click “Reset” to
reset the modified data sheets.
Web UI dial settings
In user interface, go to Advanced settings PPP settings to set the
relevant network parameters (dial number, username, password) and
authentication type.
After settings, please click “Apply” to save the current settings, click
“Reset” and then “Apply” button to restore the current settings to the factory
default settings.
Dial number: #777
Username: card
Password: card
Authentication type: AUTO/PAP/CHAP
Functions of router
14
Security settings
Security type: there are five types: Open, WEP, WPA-PSK,
WPA2-PSK and WPA/WPA2 Mixed. The default is Open.
WPA arithmetic: TKIP, AES and TKIP+AES.
WPA password: display WPA password.
Group key update time: set the relevant time.
After settings, please click “Apply” to save the current settings, click
“Reset” to reset the modified data sheets.
Appendix
15
Appendix
Care and maintenance
Your router is a delicate device. The following advice will help you to keep it
looking good and performing well…
Use a soft dry cloth to clean your router, battery and charger. Don’t use
liquids such as alcohol, dilution agents or benzene.
From time-to-time, clean the socket where the charger cable connects
to the router. Dust tends to gather there. This will ensure a really good
connection.
Don’t use needles, pen points or other sharp objects on the keypad or
screen.
Don’t use your router with wet hands – it could injure you and damage
the router.
Don’t use your router in dusty or dirty environment.
Keep your router away from extremes of heat – like radiators or ovens.
It may explode if it gets too hot.
If your router gets wet and the colour of the label on it changes, the
warranty will be void, even if the warranty period hasn’t expired.
Appendix
16
If there’s anything wrong with the router, battery, charger, or any
accessory, please send them to your nearest service centre for
inspection.
Appendix
17
FCC regulations
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiated radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
Appendix
18
compliance could void the user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Appendix
19
4RF exposure information (SAR)
This device meets the government’s requirements for exposure to radio waves. This
device is designed and manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy set by the Federal Communications Commission of
the U.S. Government. The exposure standard for wireless device employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by
the FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating positions
accepted by the FCC with the device transmitting at its highest certified power level in
all tested frequency bands. Although the SAR is determined at the highest certified
power level, the actual SAR level of the device while operating can be well below the
maximum value. This is because the device is designed to operate at multiple power
levels so as to use only the poser required to reach the network. In general, the closer
you are to a wireless base station antenna, the lower the power output. SAR
compliance has been established in the host product(s) (laptop computers), tested at
5mm separation distance to the human body, and tested with USB slot configurations
including Horizontal-UP, Horizontal-Down, Vertical-Front, Vertical-Back. This device
can be used in host product(s) with substantially similar physical dimensions,
construction, and electrical and RF characteristics. The highest SAR value, tested per
FCC RF exposure guidelines for USB dongle, as described in this user guide, is 1.247
Appendix
20
W/kg. The FCC has granted an Equipment Authorization for this device with all
reported SAR levels evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this device is on file with the FCC and can be found
under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC
ID: Q78-AC3633 .
This device is compliance with SAR for general population /uncontrolled exposure
limits in ANSI/IEEE C95.1-1999 and had been tested in accordance with the
measurement methods and procedures specified in OET Bulletin 65 Supplement C.
Appendix
21
Declaration of RoHS compliance
We’re determined to reduce the impact we have on the environment and take
responsibility for the earth we live on. So this document allows us to formally declare
that the AR910, manufactured by ZTE CORPORATION, fully complies with the
European Parliament’s RoHS (Restriction of Hazardous Substances) Directive
2002/95/EC, with respect to all the following substances:
(1) Lead (Pb)
(2) Mercury (Hg)
(3) Cadmium (Cd)
(4) Hexavalent Chromium (Cr (VI))
(5) Polybrominated biphenyl (PBB)
(6) Polybrominated diphenyl ether (PBDE)
Our compliance is witnessed by written declaration from our suppliers. This confirms
that any potential trace contamination levels of the substances listed above are below
the maximum level set by EU 2002/95/EC, or are exempt due to their application.
The AR910 manufactured by ZTE CORPORATION, meets all the requirements of EU
2002/95/EC.
Appendix
22
Disposal of your old router
1. When the wheelie bin symbol is attached to a product, it
means the product is covered by the European Directive
2002/96/CE.
2. All electrical and electronic products should be disposed of
separately from normal household waste via designated
collection points provided by government or local
authorities.
3. The correct disposal of electrical and electronic products
will help protect the environment and human health.
Problems and their solutions
23
Problems and their solutions
Symptoms Possible Causes Solutions
Unable to turn on
the phone
Inadequate battery
capacity Charge the battery
Poor contact Reinstall the battery
Automatic
power-off
Seriously poor
battery capacity Recharge the battery
Inadequate
standby time
Deceasing of
battery
performance
Replace the battery
Poor network
si
g
nal
Turn off the phone as the
si
g
nal is
p
oo
r
Unable to
connect the
network
Poor network
il
Move to other places
Out of the service
area
Make sure your phone is in
CDMA network service area
