ZTE E821S WCDMA/GSM(GPRS) Dual-Mode Digital Mobile Phone User Manual E821S UM Brazil vivo V1 2
ZTE Corporation WCDMA/GSM(GPRS) Dual-Mode Digital Mobile Phone E821S UM Brazil vivo V1 2
ZTE >
UM (Brazil vivo)V1.2
Confidential and Proprietary Information of ZTE CORPORATION 1
E821S
User Manual
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: (86) 755 26779999
Website: http://www.zte.com.cn
E-mail: mobile@zte.com.cn
E821SE821S User Manual
2 Confidential and Proprietary Information of ZTE CORPORATION
LEGAL INFORMATION
Copyright © 2011 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any
means, electronic or mechanical, including photocopying and microfilm, without the prior written
permission of ZTE Corporation.
The manual is published by ZTE Corporation. The content here may be different from your device. We
reserve the right to make modifications on print errors or update specifications without prior notice.
Version No. : R1.0
Edition Time: April 2011
Manual No. : 07958450
E821SE821S User Manual
Confidential and Proprietary Information of ZTE CORPORATION 3
Contents
Safety Information ........................................................................................................................... 5
General Care ................................................................................................................................ 5
General Guidelines ...................................................................................................................... 6
Road Safety ................................................................................................................................. 6
Hospital Safety ............................................................................................................................ 7
Emergency Service ...................................................................................................................... 7
Third Party Equipment ................................................................................................................ 7
Vehicles Equipped with an Airbag .............................................................................................. 8
Aircraft Safety ............................................................................................................................. 8
Privacy Information ..................................................................................................................... 8
Copyright Notice ......................................................................................................................... 8
Radio Frequency (RF) Energy .................................................................................................... 8
FCC Compliance ......................................................................................................................... 9
Limitation of Liability ................................................................................................................. 9
Your Phone .................................................................................................................................... 10
Instruction .................................................................................................................................. 10
Overview ................................................................................................................................... 10
Starting Up .................................................................................................................................... 11
Open the Back Cover ................................................................................................................ 11
Installing the Battery ................................................................................................................. 11
Installing the (U)SIM Card ....................................................................................................... 12
Inserting the Memory Card ....................................................................................................... 12
Charging .................................................................................................................................... 13
Security Code ............................................................................................................................ 13
Phone Password ..................................................................................................................... 13
PIN Code ............................................................................................................................... 14
PIN2 Code ............................................................................................................................. 14
PUK Code ............................................................................................................................. 14
Basic .............................................................................................................................................. 15
Power On/Off ............................................................................................................................ 15
Standby Mode ........................................................................................................................... 15
Indicator Icons ........................................................................................................................... 15
Main Menu ................................................................................................................................ 16
Keypad Lock ............................................................................................................................. 17
Multitasking .............................................................................................................................. 18
Making Calls ............................................................................................................................. 18
Options for Voice Call .......................................................................................................... 18
Calls History .............................................................................................................................. 18
Text Input ...................................................................................................................................... 19
Contacts ......................................................................................................................................... 20
Adding a Contact ....................................................................................................................... 20
Searching Contact ..................................................................................................................... 20
Setting Speed Dial ..................................................................................................................... 20
Making a Speed Dial ............................................................................................................. 20
Other Options ............................................................................................................................ 20
Message ......................................................................................................................................... 22
Sending SMS ............................................................................................................................. 22
Sending MMS ........................................................................................................................... 22
Sending Email ........................................................................................................................... 22
Message Settings ....................................................................................................................... 22
E821SE821S User Manual
4 Confidential and Proprietary Information of ZTE CORPORATION
E-mail Settings .......................................................................................................................... 23
Browser ......................................................................................................................................... 24
Browser Settings ....................................................................................................................... 24
Downloading via Browser ......................................................................................................... 24
Bluetooth ....................................................................................................................................... 25
Connecting the Bluetooth Device ............................................................................................. 25
Sending Files via Bluetooth ...................................................................................................... 25
Receiving Files via Bluetooth ................................................................................................... 25
Modem Function ........................................................................................................................... 26
Modem Settings ......................................................................................................................... 26
Use the Handset as Modem ....................................................................................................... 26
Multimedia .................................................................................................................................... 27
Camera ...................................................................................................................................... 27
Video Camera ............................................................................................................................ 27
FM Radio ................................................................................................................................... 27
Picture ........................................................................................................................................ 27
Music Player .............................................................................................................................. 27
Video Player .............................................................................................................................. 27
Voice Recorder .......................................................................................................................... 28
Other Facilities .............................................................................................................................. 29
Alarm ......................................................................................................................................... 29
Calendar .................................................................................................................................... 29
Stop Watch and Countdown ...................................................................................................... 29
World Clock .............................................................................................................................. 29
Calculator .................................................................................................................................. 29
Converter ................................................................................................................................... 29
Notepad ..................................................................................................................................... 29
Gallery ........................................................................................................................................... 30
Accessing the Memory Card ..................................................................................................... 30
Settings .......................................................................................................................................... 31
Display ...................................................................................................................................... 31
Handset ...................................................................................................................................... 31
Profiles ...................................................................................................................................... 31
Call ............................................................................................................................................ 31
Connection and Network ........................................................................................................... 32
Security ...................................................................................................................................... 32
PC Suite ......................................................................................................................................... 33
Installing the PC Suite ............................................................................................................... 33
Unstalling the PC Suite ............................................................................................................. 33
Running the PC Suite ................................................................................................................ 33
Troubleshooting and FAQs ........................................................................................................... 34
Technical Parameters .................................................................................................................... 36
E821SE821S User Manual
Confidential and Proprietary Information of ZTE CORPORATION 5
C h a p t e r 1
Safety Information
General Care
Your handset contains delicate electronic circuitry, magnets and battery systems. You should treat it with
care and give particular attention to the following points:
• Do not allow the handset, battery or accessories to come into contact with liquids or moisture at any time.
Do not immerse the handset in any liquid.
• Do not place the handset alongside computer disks, credit cards, travel cards and other magnetic media.
The information contained on disks or cards may be affected by the handset.
• Do not place anything in the folded handset.
• Do not paint the handset.
• Do not leave the handset or the battery in places where the temperature could exceed 60 °C, e.g. on a car
dashboard or a windowsill, behind glass in direct sunlight, etc.
• Do not remove the handset’s battery while the handset is switched on.
• Take care not to allow metal objects, such as coins or key rings to contact or short-circuit the battery
terminals.
• Do not dispose of battery packs in a fire. The handset’s Li-ION batteries may be safely disposed of at a
Li-ION recycling point.
• Do not put the handset’s battery in your mouth, as battery electrolytes may be toxic if swallowed.
• Do not attempt to dismantle the handset or any of its accessories.
• There is a risk of explosion if the battery is replaced with an incorrect battery type. Dispose of the used
battery in accordance with the manufacturer’s instructions.
• Do not put a battery into a microwave oven, dryer, or high-pressure container.
• Do not contact battery directly to an electric outlet or cigarette lighter charger. Use only approved
charger units.
• Do not pierce battery with a sharp object such as a needle.
• When the battery is thrown away, be sure it is non-conducting by applying vinyl tape to the (+) and (-)
terminals.
• Do not disassemble or modify the battery.
• Do not drop, throw, or subject the handset to rough treatment.
• Stop using the battery if abnormal heat, odor, discoloration, deformation, or abnormal condition is
detected during use, charge, or storage.
• In the unlikely event of a battery leak, keep the battery discharge away from your eyes or skin. If the
leakage does come into contact with the eyes or skin, please flush thoroughly in clean water and consult
with a doctor.
• Do not use a damaged or deformed battery.
• Do not solder a battery directly.
• Remove the battery whose life cycle has expired from equipment immediately.
• The earpiece may become warm during normal use. Also, the handset itself may become warm while the
battery is being charged.
E821SE821S User Manual
6 Confidential and Proprietary Information of ZTE CORPORATION
• When a handset is in vibration mode, the vibration can sometimes cause the handset to move.
• Be careful not to place the handset near heat sources (such as a heater) or too close to the edge of the
table.
• Use a damp or anti-static cloth to clean the handset. Do not use an ordinary dry cloth or electrostatic
cloth. Do not use chemical or abrasive cleaners as these could damage the casing.
• Third party equipment: The use of third party equipment, cables or accessories, not made or authorized
by manufacturer, may invalidate the warranty of your handset and also adversely affect the phone’s
safety/operation.
• Remember to make backup copies of all important data on your handset.
• Remember to recycle: the cardboard packing supplied with this handset is ideal for recycling.
Caution:
Caution explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the
instructions.
General Guidelines
• In some countries national law unapproved private copying of copyrighted material. Please check the
national legislation of the applicable country concerning the use of such material.
• Many jurisdictions have laws and regulations about taking pictures in public or private areas and
regarding the processing and further use of such pictures. The manufacturer encourages its customers to
obey all laws and to respect the personal rights of others.
• Please check roaming agreement availability with your service provider.
• The use of mobile phones is not allowed in some radiation sensitive areas, such as hospitals, research
centers and airplanes. The user is responsible to power-off the device. If there is any uncertainty, you
should remove the battery from the handset.
• Observe any signs that indicate powering off your handsets, such as those near gas stations, or explosives
and power off the handset/device immediately.
• If you have a heart condition, be careful with the settings of call vibration or tone volume.
• Do not allow children to play with the handset, charger or batteries.
• Do not use the handset where blasting is in progress.
• Do not try to make a call or conversation while the temperature of charging battery is above 50°C.
• Take care not to put your handset in the back pocket of your trousers or skirt and then sit on it. Also, do
not put your phone at the bottom of bag where it may subject to excessive weight or pressure. Doing so
may damage the LCD and camera lens and cause them malfunction.
• The operation of some medical electronic devices, such as hearing aids and pacemakers, may be affected
if a handset is used next to them. Observe any caution signs and the manufacturer’s recommendations.
• Do not leave the handset discharged or without a battery for a long time, otherwise some data may be
erased.
• Your phone contains metal, which may cause you an itch, a rash or eczema depending on your physical
condition.
• Turn off your phone during a thunderstorm – unless you are in premises protected by a lighting
conductor.
Road Safety
• You must exercise proper control of your vehicle at all times. Give your full attention to driving.
E821SE821S User Manual
Confidential and Proprietary Information of ZTE CORPORATION 7
• Observe all of the recommendations contained in your local traffic safety documentation.
• Pull off the road and park before making or answering a call, if driving conditions require so.
• Check if local laws and/or regulations restrict the use of handsets while driving.
• You MUST NOT stop on the hard shoulder of a motorway to answer or make a call, except in an
emergency.
• Switch off your handset at a refueling point, such as a gas station, even if you are not refueling your own
car.
• Do not store or carry flammable or explosive materials in the same compartment as the handset.
• Electronic vehicle systems, such as anti-lock brakes, speed control and fuel injection systems are not
normally affected by radio transmissions. The manufacturer of such equipment can advise if it is
adequately shielded from radio transmissions. If you suspect vehicle problems caused by radio
transmissions, consult your dealer and do not switch on the handset until it has been checked by
qualified approved installers.
Hospital Safety
• Switch off your phone and remove the battery in areas where the use of handsets is prohibited.
• Follow the instructions given by the respective medical facility regarding the use of handsets on their
premises.
Emergency Service
Notes:
Emergency service numbers vary by country. It helps you get emergency service from the operator.
To make an emergency call in any country:
1. Ensure that your handset is on and in service.
2. Press the End Key as many times as needed to clear the display and ready the device for calls.
3. Enter the local emergency number for your current location, for example, 911.
4. Press the Send Key to dial the number. Follow the instructions you receive and do not end the call until
told to do so.
When the (U)SIM card is not inserted or when the dial lock function is on, press the Left Soft Key [SOS]
and then enter the official emergency number for your present location. Press OK Key [Call] to dial the
number.
Notes:
Tell the operator which service you require: Police, Ambulance, Fire Brigade, Coastguard or Mountain
Rescue Service. Tell them where you are and remain stationary to maintain contact if possible.
Due to the nature of the cellular system, the connection of emergency calls cannot be guaranteed. You
should never rely solely on any wireless device for essential communications like medical emergencies.
Third Party Equipment
The use of third party equipment, cables or accessories, not made or authorized by the manufacturer, may
invalidate the warranty of your handset and also adversely affect the handset’s operation. For example,
use only the manufacturer mains cable supplied with the AC charger.
E821SE821S User Manual
8 Confidential and Proprietary Information of ZTE CORPORATION
Vehicles Equipped with an Airbag
An airbag inflates with great force. Do not place objects, including either installed or portable wireless
equipment, in the area over the airbag or in the airbag deployment area. If in-vehicle wireless equipment
is improperly installed and the airbag inflates, serious injury could result.
Aircraft Safety
• Power off your phone before the airplane takes off. In order to protect airplane’s communication system
from interference, it is prohibited to use mobile phone in flight. If you want to use mobile phone before
the airplane takes off, you should get aircrew’s permission according to safety regulations.
• If the mobile phone has the function of automatic timing power-on, please check your alarm setting to
ensure that your phone will not be automatically powered on during the flight.
Privacy Information
Camera usage and photo/audio/video recordings carried out with the phone can offend the confidentiality
of the subjects. The user therefore is held to respect legislation in matters of confidentiality and remains
the only responsible subject in the case of eventual violations of the enforced norm.
Copyright Notice
The video/audio recordings you make/download are protected by copyright laws. They are for personal
use only and must not otherwise be used without the permission of the copyright owner.
Radio Frequency (RF) Energy
This model phone meets the government’s requirements for exposure to radio waves.
This phone is designed and manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of the U.S. Government:
The exposure standard for wireless mobile phones employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are
conducted using standard operating positions accepted by the FCC with the phone transmitting at its
highest certified power level in all tested frequency bands. Although the SAR is determined at the
highest certified power level, the actual SAR level of the phone while operating can be well below the
maximum value. This is because the phone is designed to operate at multiple power levels so as to use
only the power required to reach the network. In general, the closer you are to a wireless base station
antenna, the lower the power output.
The highest SAR value for this model phone as reported to the FCC when tested for use at the ear is
W/kg and when worn on the body, as described in this user guide, is W/kg (Body-worn
measurements differ among phone models, depending upon available enhancements and FCC
requirements.)
While there may be differences between the SAR levels of individual E821 phones and at various
positions, they all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/ea/fccid after searching on
FCC ID:
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for
use with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from
the body. Use of other enhancements may not ensure compliance with FCC RF exposure guidelines. If
you do not use a body-worn accessory and are not holding the phone at the ear, position the handset a
minimum of 1.5 cm from your body when the phone is switched on.
E821SE821S User Manual
Confidential and Proprietary Information of ZTE CORPORATION 9
FCC Compliance
• This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device
does not cause harmful interference.
• This device has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
• The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages
resulting from or arising out of or in connection with using this product, whether or not ZTE had been
advised, knew or should have known the possibility of such damages.
Confidential and Proprietary Information of ZTE CORPORATION 10
C h a p t e r 2
Your Phone
Instruction
Your phone supports WCDMA, GSM networks and GPRS.
Overview
Earpiece
Send Key
Make or answer phone
calls.
Open the call history in
standby mode.
End/Power Key
End phone calls.
Hold to power on/off
the phone.
Earphone Jack
Screen
Volume Keys
Camera Key
Back Camera
Back Cover
Speaker
Navigation Keys
and OK Key
Left Soft Key
Execute operations
shown at the bottom
left of the screen.
Clear Key
Delete characters
when entering text.
USB/Charger
Jack
Right Soft Key
Execute the operation
shown at the bottom
right of the screen.
Switch Key
Press to return to the
main menu. Hold to
choose and switch tasks.
Confidential and Proprietary Information of ZTE CORPORATION 11
C h a p t e r 3
Starting Up
Open the Back Cover
Slide down the back cover.
Installing the Battery
Notes:
• If you are not going to use the battery for a long time, remove it from the phone and store it in a cool dry
place.
1. Carefully insert the battery with the contacts located against the metal springs.
2. Push down the battery until it clicks into place.
E821S User Manual
12 Confidential and Proprietary Information of ZTE CORPORATION
Installing the (U)SIM Card
Notes:
• Do not bend or scratch your (U)SIM card. Keep the card away from electricity and magnetism.
• Don’t touch the metal surface of the (U)SIM card. Doing so could cause information on the card to be
lost or destroyed.
• Disconnect the charger and other accessories from your phone and remove the battery before inserting
and removing your (U)SIM card.
1. Hold the (U)SIM card with the metal contacts facing downward and the cut corner at the bottom right. .
2. Insert the card into the card holder and push it until it clicks into position.
Inserting the Memory Card
Tips:
Your phone can support a memory card with capacity up to 8GB.
Caution:
Only use approved memory cards for this device. Any use of unapproved memory cards might cause loss
of data or damage to your phone.
Carefully insert the memory card into the memory card slot and place the card into position.
E821S User Manual
Confidential and Proprietary Information of ZTE CORPORATION 13
Charging
Your phone is powered by a rechargeable battery. The battery is not fully charged when first unpacked,
but there may be enough power to power on your phone. You should use it up completely before charging
the battery for the first three times. Charge the battery with the procedure indicated below.
1. Open the USB jack cover on the side of the phone and connect the USB charger, making sure it’s
inserted the right way round. Don’t try and force it in.
2. Connect the charger to a standard AC outlet.
3. Remove the charger from both the AC outlet and the phone once the charging is completed.
Notes:
The phone automatically switches off if the battery power is too low.
If you are not going to use the battery for a long time, remove it from the phone and store it in a cool dry
place.
The battery will be fully charged for 3~4 hours.
Charging is only possible within a temperature range of 0℃ to 45℃.
If the phone is over-used in shortage of battery or not used for a long time, the screen may not display
the charge indicator until it is charged for 10 to 40 minutes.
To charge the battery, you can use the provided charger or the USB data cable from your computer.
Security Code
Phone Password
Phone password can protect your handset efficiently and avoid illegal usage. If phone password protection
is activated, you should input the correct password at handset start-up.
• For a new bought handset, the protection function is not activated and the default password is 0000.
• In standby mode, select Main Menu > Settings > Security Settings > Lock Settings > Lock Setings to
start or stop password protection.
• In standby mode, select Main Menu > Settings > Security Settings > Change Codes > Phone
Password to change handset password. It is suggested to change the password according to your
requirement.
E821S User Manual
14 Confidential and Proprietary Information of ZTE CORPORATION
Notes:
Please remember the password you set, without it your phone cannot be used normally and you will need
to contact your service provider to unlock it.
PIN Code
PIN code is the personal identification code of (U)SIM card, used to avoid illegal usage for your (U)SIM
card. Once PIN code is started, the correct PIN code should be input at handset start-up, otherwise the
handset can only execute emergency call.
• For the new bought card, the default code is supplied by the service provider.
• In standby mode, select Main Menu > Settings > Security Settings > Lock Settings > PIN Lock to
start or stop PIN code.
• In standby mode, select Main Menu > Settings > Security Settings > Change Codes > PIN code to
change PIN code.
• If you input wrong PIN code continuously for three times, the (U)SIM card will be locked, and you are
prompted to input PUK code to unlock.
Notes:
If you change PIN code, please remember it clearly.
PIN2 Code
PIN2 is needed for some settings.
For the new bought card, the default code is supplied by the service provider.
In standby mode, select Main Menu > Settings > Security Settings > Change Codes > PIN2 code to
change PIN2 code.
PUK Code
PUK code is the specified unlock code for (U)SIM card. when the (U)SIM PIN code is incorrectly entered
continuously for three times, the card will be locked. Enter the correct PUK code and then input the new
PIN code, the (U)SIM card then can be used normally.
• PUK code may be supplied with the newly bought (U)SIM card. For the detail, refer to the service
provider.
• PUK code can only be input continuously for 10 times. If you input wrong PUK code for 10 times, the
(U)SIM card will be locked permanently.
Notes:
If PUK code is supplied with the new bought card, please keep it safely.
Confidential and Proprietary Information of ZTE CORPORATION 15
C h a p t e r 4
Basic
Power On/Off
Caution:
Do not turn your phone on in areas in which wireless phone use is not permitted, or when it could cause
interference or danger.
Press and hold the End Key to turn on the phone.
1. When being asked, enter your (U)SIM PIN (Personal Identification Number) code or handset unlock
code and press the OK Key to confirm.
Tips:
The PIN code is the password provided by your network service provider. You need this password to
use the (U)SIM card.
2. When the entered PIN code or handset unlock code is accepted, the phone will automatically search for
the designated network. After a few seconds, your phone will show the standby mode.
To power off the phone, press and hold the End Key from the standby mode.
Standby Mode
After power on the phone, when the name of network is displayed on the screen, the phone is in the
standby mode and ready for use.
Indicator Icons
Signal strength
Remaining battery power
2G network
EDGE network
3G network
Roaming
Status bar
Shortcuts
E821S User Manual
16 Confidential and Proprietary Information of ZTE CORPORATION
Missed voice call
Call forwarding active
Data transfer in progress
New SMS
New cell broadcast message
New MMS
New WAP PUSH message
New Email
Upcoming calendar event
Downloading
Vibrate mode
Silent mode
Flight mode
Outdoor mode
Bluetooth on
Bluetooth headset connected
Alarm set
Earphone inserted
microSD card inserted
Main Menu
In standby mode, press the Left Soft Key [Main Menu] to enter main menu.
Call Log
• All Calls
• Missed Calls
• Dialed Calls
• Received Calls
Gallery
• Phone
• Memory Card
Browser
Vivo Chip
Loja Vivo
Contacts
Message
• New Message
• (U)SIM Card
• Inbox
• Drafts
• Sent
• Outbox
• My Folders
• Voicemail
• Cell Broadcast
• Email
Multimedia
E821SUser Manual
Confidential and Proprietary Information of ZTE CORPORATION 17
• Picture
• Music Player
♦ All Songs
♦ Playlists
♦ Artists
♦ Genres
♦ Albums
♦ Folders
• Video Player
♦ Videos
♦ Camera
♦ Stream
• FM Radio
• Voice Recorder
• Camera
Settings
• Display Settings
♦ Wallpaper
♦ Backlight
♦ Dialing Font
♦ Greetings
• Phone Settings
♦ Language
♦ Network Time
♦ Date and Time
♦ Auto Keypad Lock
♦ Main Menu Style
♦ Default Storage Location
♦ Phone Info
• Profiles
♦ General
♦ Silent
♦ Meeting
♦ Outdoor
♦ Flight
• Call Settings
♦ Earphone Auto Answer
♦ Any Key to Mute
♦ Connection Reminder
♦ Minute Reminder
♦ Send My Caller ID
♦ Auto Redial
♦ Call Forwarding
♦ Call Waiting
♦ Call Barring
• Connection Settings
♦ Bluetooth
♦ Network Mode
♦ Network Selection
♦ Access Point
♦ Internet Profiles
♦ Modem
♦ PC Connection
• Security Settings
♦ Lock Settings
♦ Change Codes
♦ Fixed Dialing
♦ Restore Factory Settings
Messenger
Tools
• Stop Watch
• Calendar
• Notepad
• Countdown
• World Clock
• Alarm
• Calculator
• Converter
• Download
Vivo Busca
Keypad Lock
Use the keypad lock to prevent the keys from being pressed accidentally.
Press the OK Key [Main Menu], select Settings > Phone Settings > Auto Keypad Lock and set the
keypad to lock automatically when idle for 10 seconds, 15 seconds, 30 seconds or 60 seconds. Or cancel
the automatic lock.
In standby mode, press and hold the Space Key ( ) to lock the keypad manually.
If you want to unlock the keypad, press the OK Key, and then press the Space Key ( ).
Tips:
If there is an incoming call when the keypad is locked, you can press the Send Key to answer. After
ending or rejecting the call, the keypad will be locked automatically.
When the keypad lock is on, you can still dial emergency numbers. Ask your carrier what emergency
numbers they support.
E821S User Manual
18 Confidential and Proprietary Information of ZTE CORPORATION
Multitasking
Multiple applications can run at the same time on your phone. You can launch new applications without
terminating the ones you have already opened, or switch among the running applications.
• To launch a new application, press the Switch Key to get the main menu and open the application. The
old application would still run in the background.
• To switch among running applications, press and hold the Switch Key to get the task manager screen,
which shows the running applications as well as the idle screen and the main menu. Press the
Left/Right Key to choose the screen you want to see and the OK Key to resume it. You can also end
the selected application by pressing the Left Soft Key.
Making Calls
You can call the numbers of the other party directly or you can make a call through contacts, calls log, or
speed dial.
1. In standby mode, enter a phone number.
2. Press the Send Key to make a voice call.
3. Press the End Key to end the call.
Options for Voice Call
During a call, you can press the Left Soft Key [Options] for more options. The options vary depending
on the function you are currently using.
• Record: Record the current call. You can also press the OK Key [Stop] to stop recording.
• Create Note: Create a text note during the call.
• Hold /Active: Put the current call on hold or retrieve the call.
• Go to: Switch to the Message, Contacts, Browser, Call menu or the main menu during the call.
• DTMF off/on: Enable or disable sending the DTMF tone.
• End call: End the current call.
Calls History
In standby mode, press the Left Soft Key [Main Menu] and select Call Log to check the call history and
the duration of the calls.
Confidential and Proprietary Information of ZTE CORPORATION 19
C h a p t e r 5
Text Input
With a compact version of the standard computer keyboard, your phone provides the following input
methods: Predictive Text Mode Input (T9Pt/T9Word), Multitap Input (abc/Abc/ABC), and Numbers
Input (123). Press to change input method.
Operation
Method
Input Words
T9Pt/T9Word Input — Press each key once that
corresponds to the letter you want to enter. The letters are
shown on the display as they are entered. The list of
candidate words changes as each key is pressed. Press the
Up/Down Key to choose the correct word and the OK Key
to enter the word.
Input Letters
abc/Abc/ABC Input — Press a key to enter the letter.
Press to switch between abc, Abc, and ABC mode.
Input Numbers
123 Input — Press the number keys to input numbers
directly.
Input Space
Press .
Input Symbols
Press to choose symbols, emoticons, or pre-defined
text.
Start a new paragraph
Press .
Delete text
press to delete one character before the
cursor. Hold to delete all characters before
the cursor.
Move the cursor up, down, left , or right
Press the Navigation Keys.
Confidential and Proprietary Information of ZTE CORPORATION 20
C h a p t e r 6
Contacts
Adding a Contact
You can store contacts with a variety of phone and fax numbers and additional address details.
The phone can store up to 1000 items. The capacity of the phone book on your (U)SIM card depends on
the type of (U)SIM card provided by your service provider. The save location is identified by the icon
shown before the contacts.
1. Select Main Menu > Contacts > Left Soft Key [Options] > New, and press the OK Key.
2. Enter the information of contact, such as name, phone numbers, and so on.
3. Press the OK Key [Save] to save the new contact.
Searching Contact
1. Select Main Menu > Contacts. All contacts on the phone and the (U)SIM card will be displayed.
2. Enter the contact name. The phone will find the closest match and highlight it.
Setting Speed Dial
1. In standby mode, select Main Menu > Contacts.
2. Use the Navigation Keys to select a phone contact. Press the Left Soft Key [Options] and select Set
as Speed Dial.
3. Press the Up Key or Down Key to select an Unassigned slot.
4. Press the OK Key [SET] and choose Yes to confirm.
5. Press the Right Soft Key to return to the previous menu. Or press the End Key to return to standby
mode.
Making a Speed Dial
1. In standby mode, press and hold the corresponding number key (1 to 9) in the speed dial list to make
the call.
2. Press the End Key to end the call.
Other Options
Open Contacts and press the Left Soft Key to enter the submenu list, and you can do the following
operations:
Options
Function
Send Message
Send a message to the contact highlighted.
Call
You can make a voice call.
New
Add a new contact.
Edit
Edit the contact information.
E821S User Manual
Confidential and Proprietary Information of ZTE CORPORATION 21
Options
Function
Send Name Card
You can send the contact information via SMS, MMS, Email, or Bluetooth.
Batch Processing
Select multiple contacts. You can send them a message or an Email, send the contact
information via Bluetooth, add them to a contact group, or delete, copy or move
them.
Set as Speed Dial
You can set a speed dial number for the selected contact.
Delete
Delete currently selected contact.
Setting &
Status
Storage and
Display
Change settings for contacts to be displayed and default storage location.
Speed Dials
View the current list of speed dial, and set new speed dial or remove existing
assignment.
Service
Number
Check service numbers in your SIM card.
Memory
Info
Shows the capacity used and the total capacity of the memory in the phone and the
(U)SIM card.
Confidential and Proprietary Information of ZTE CORPORATION 22
C h a p t e r 7
Message
Sending SMS
1. Select Main Menu > Message > New Message, and press the OK Key [Select].
2. Enter the recipient(s) party’s number. (Or Press the OK Key [Recipients] to choose from contacts or
recent calls.)
3. Press Down Key to edit the message text.
Select Left Soft Key > Insert Quick Text to insert preset message or my words.
4. Press the OK Key [Send] to send the message.
Sending MMS
1. Select Main Menu > Message > New Message, and press the OK Key [Select].
2. Enter the recipient’s number and message text, as you do with an SMS.
3. Scroll down to find the MMS toolbar
4. With the toolbar, select different buttons to add subject and Cc recipients, insert picture/audio/ video/
slide and attachments, or preview the message.
7. Press the OK Key [Send] or the Left Soft Key [Options] and select Send to send your message.
Sending Email
To send the first Email on the phone, you need to set up the Email account in Main Menu > Message >
Email. Select an Email service provider and enter the user name, password, and display name. Then press
the OK Key.
Note: If your Email service provider is Other, you need to highlight the Email account and select
Options > Edit Account to set up download mode, outgoing server, incoming server, APN, etc. Consult
your Email service provider on information such as server type and servers. Contact your mobile service
provider for the correct APN choice.
1. Select Main Menu > Message > Email and select an Email account you have set.
2. Select New Email.
3. Enter the recipient’s Email address, or press the OK Key [Recipients] to choose the recipient(s).
4. Enter the title of your Email in the Subject field.
5. Edit the Email text.
6. Press Options to add attachment, or add Cc/Bcc recipients.
6. Press the OK Key [Send] to send your Email.
Message Settings
You can view or change the message settings. The message centre number is stored on your (U)SIM card
supplied by your service provider. The MMS and SMS settings are preset by your service provider.
Select Main Menu > Message > Options > Settings.
MMS Settings
E821S User Manual
Confidential and Proprietary Information of ZTE CORPORATION 23
Retrieval Settings
Delay: Retrieve the new multimedia message manually.
Immediately: Retrieve the new multimedia message automatically without selecting the
notification message and receiving.
Delay When Roaming: Retrieve the new multimedia message automatically except in roaming
state.
Delivery Mode
You can set immediate delivery or defer it for a specified period of time.
Delivery Time
You can set a specified period of time to send MMS when you set After sending in Delivery
mode. The max delivery time is 99 hours.
Slide Timing
You can set the playing time of each page.
Validity
You can configure the validity period of outgoing messages. Your network will save your
messages in this specified period of time.
Delivery Receipt for
Sent
If you request delivery reports for messages, you will receive a popup message to inform you
when the message is delivered to the recipient.
Priority
Set message priority.
Anonymous
Message
You can choose to accept or refuse anonymous message.
Connections
Please consult the service provider for detailed information.
SMS Settings
SMS Center
Number
Enter the SMS center number. Contact your service provider for more information.
Validity
You can configure the validity period of outgoing messages. Your network will save your
messages in this specified period of time.
Delivery Receipt for
Sent
If you request delivery reports for messages, you will receive a popup message to inform you
when the message is delivered to the recipient.
Quick Text: Add, edit, or delete preset text.
SMS for Reject Call: Edit the message text that you can choose to send when rejecting an incoming call.
General Settings: Set up font size, signature, auto delete, or auto save.
Voicemail#: Set voicemail number.
Cell Broadcast Settings: You can turn on the function, choose language and channels.
Email Settings
Select Main Menu > Message > Email. Highlight an Email account. Select Options > Edit Account to
set the Email account, or select Options > System Settings to set auto retrieve and Email font size
options.
Confidential and Proprietary Information of ZTE CORPORATION 24
C h a p t e r 8
Browser
Browser Settings
Select Main Menu > Browser > Options > Settings to do the following setting.
Browse Mode
Choose the display mode of web pages.
Connection
Choose the connection profile.
Advanced Settings
Customize the picture, animation, background music, cache, cookies, etc.
Clear Cache
Clear all cache data.
Clear Cookies
Clear all cookie information.
Clear Autofill List
Delete all input history items.
Certificate
List the root, CA and trusted certificates on the phone.
Downloading via Browser
1. When viewing network page, use the Up Key or Down Key to select the link, press the OK Key to
open the objective link.
2. Press the Left Soft Key [Yes] to confirm and start downloading. The downloading information will be
saved in the handset memory or the memory card.
Caution:
Do not download and use software and file from an unknown source.
Confidential and Proprietary Information of ZTE CORPORATION 25
C h a p t e r 9
Bluetooth
Connecting the Bluetooth Device
1. In idle screen, press the OK Key [Main Menu] to enter main menu.
2. Select Settings > Connection Settings > Bluetooth > Bluetooth Switch to turn on Bluetooth.
3. Select Search Device to search the available Bluetooth devices.
4. Select one device from the displayed list and press the OK Key to confirm.
5. Enter the pass key for permission to connect to the device. After the paired device verifies the pass key,
the device will be added successfully.
Sending Files via Bluetooth
Firstly please confirm following two items:
• Enable Bluetooth function.
• The paired device is visible.
1. Select Main Menu > Gallery and highlight your desired file. Then select Left Soft Key [Options] >
Send > Via Bluetooth.
2. Select the aim device from the device list, and press the OK Key [OK] to send.
Receiving Files via Bluetooth
Firstly please enable Bluetooth function.
1. If the paired device tries to send a file to your phone, one popup dialogue will appear in your screen.
2. Press the Left Soft Key [Yes] to accept the incoming file, or press the Right Soft Key [No] to reject
the incoming file.
3. After the file is received, you can press Yes to open the file.
Confidential and Proprietary Information of ZTE CORPORATION 26
C h a p t e r 10
Modem Function
Modem Settings
Please confirm :
• Valid (U)SIM card is inserted.
• Data configuration or dialing connection is available.
Select Main Menu > Settings > Connection Settings > Modem.
Use the parameters obtained from your service provider to complete the modem settings.
Use the Handset as Modem
Connect your phone to computer with supplied data cable; your phone can work as one external modem
for the computer. For detailed information, please consult your service provider.
Confidential and Proprietary Information of ZTE CORPORATION 27
C h a p t e r 11
Multimedia
Camera
1. Select Main Menu > Multimedia > Camera.
2. If necessary, press the Left Soft Key to set the camera parameters.
3. Aim the camera lens at a person/place.
4. Press the OK Key or Camera Key to take the photo.
Press the OK Key to send the photo via MMS, Email, or Bluetooth, or set the photo as wallpaper or
contact icon.
Press the Right Soft Key to save the photo and exit to the camera’s viewfinder.
Press the Left Soft Key to delete the photo.
Video Camera
1. Select Main Menu > Multimedia > Camera, and press the Right Key to switch to video camera.
2. Press the Left Soft Key to set the video parameters.
3. Press the OK Key start or stop recording.
Press the Left Soft Key to send the video file via MMS, Email, or Bluetooth, or to delete the file.
Press the OK Key to play the video file.
Press the Right Soft Key to save the video and exit to the video camera’s viewfinder.
FM Radio
1. Insert the ear phone compatible with your handset.
2. In standby mode, select Main Menu > Multimedia > FM Radio, the radio will be started.
3. Press the Left Soft Key [Options]. You can search for channels automatically, view channel list, turn
on/off the speaker, or turn off the radio.
1. Select Main Menu > Multimedia > Picture.
2. Press the OK Key to open an image. You can view it in full screen, zoom, rotate, delete, send, rename,
set as wallpaper/contact icon, etc.
Music Player
1. Select Main Menu > Multimedia > Music Player.
2. Choose All Songs, Playlists, Artists, Genres, Albums, Folders to locate the file you want to play.
Video Player
1. In standby screen, select Main Menu > Multimedia > Video Player.
2. Use the Left/Right Key to switch among Videos, Camera, and Stream tabs. And select a video file
or a stream bookmark.
E821S User Manual
28 Confidential and Proprietary Information of ZTE CORPORATION
Voice Recorder
1. In standby screen, select Main Menu > Multimedia > Voice Recorder.
2. Press the OK Key [Start] to start recording your voice memo. Use the Volume Keys to adjust
recording volume.
3. Press the OK Key [Pause] to pause, press the OK Key [Cont.] to resume recording, and press the Left
Soft Key [STOP] to stop recording.
4. After recording a voice memo, you can continue the following operations:
Press the OK Key [Play] to play the memo.
Press the Right Soft Key to save the memo and exit.
Press the Left Soft Key [Options] to send, delete, rename the memo file, set it as ringtone for calls
or messages, or go to your voice record folder.
Confidential and Proprietary Information of ZTE CORPORATION 29
C h a p t e r 12
Other Facilities
Alarm
You can set the alarm to ring if required. Select your desired alarm to configure in the alarm list.
Notes:
The alarm will ring at the set time, even when the phone is powered off.
Calendar
You can conveniently access and modify your agenda.
Stop Watch and Countdown
You can measure time and take split times or lap times.
World Clock
You can check the current local time and date for major cities around the world.
Calculator
The phone provides simple calculating functions, such as addition, subtraction, multiplication and
division.
Converter
This function allows you to convert currency and units.
Notepad
You can create text memos, and send it to others.
Confidential and Proprietary Information of ZTE CORPORATION 30
C h a p t e r 13
Gallery
Select Main Menu > Gallery to manage picture, audio, video, and other files.
Notes:
Preloaded files on the phone are read only and cannot be deleted.
Accessing the Memory Card
1. Select Main Menu > Gallery.
2. Press the Right Key to select Memory Card and view the files on memory card. By pressing the Left
Soft Key [Options], you can search or delete files, establish new folder, etc.
Confidential and Proprietary Information of ZTE CORPORATION 31
C h a p t e r 14
Settings
Display
In standby screen, press the Left Soft Key [Main Menu] and select Settings > Display Settings.
Select Wallpaper to change the background image for the standby screen.
Select Backlight to adjust the screen and keypad light.
Select Dialing Font to change font size in the dialing screen.
Select Greetings to input greeting words, displayed in standby screen.
Handset
In standby screen, press the Left Soft Key [Main Menu] and select Settings > Phone Settings.
Select Language to set the current display language.
Select Network Time to use or stop using the date and time data provided by the network.
Select Date and Time to set time, date and display mode. You need to turn off network time first.
Select Auto Keypad Lock to set handset keypad auto lock time or disable keypad auto lock.
Select Main Menu Style to switch between grid or list display.
Select Default Storage Location to set the default location for downloaded files.
Select Phone Info to check device number, version info and icon glossary.
Profiles
In standby screen, press the Left Soft Key [Main Menu] and select Settings > Profiles.
Your handset supplies several predefined user profiles, and you can choose a certain profile according to
your surroundings.
You can also edit the appropriate profile depending on the current condition.
Call
In standby screen, press the Left Soft Key [Main Menu] and select Settings > Call Settings.
Earphone Auto Answer: Answer incoming calls automatically when earphone is plugged in.
Any Key to Mute: Mute incoming call ringtone by pressing any key, except the Send Key, the End
Key, the OK Key, the Right Soft Key and the Left Soft Key.
Connection Reminder: Use audio reminder when a call is connected.
Minute Reminder: Use audio reminder when the call timer reach every full minute.
Send My Caller ID: Send or hide your phone number when making calls.
Auto Redial: Automatically redial unanswered calls.
Call Forwarding: Forward your incoming calls to another phone number. Contact your service
provider for more information and availability.
Call Waiting: Notify you of new calls when you are already on another call. Contact your service
provider for more information.
Call Barring: Restrict the calls that you make or receive. Contact your service provider for more
information.
E821S User Manual
32 Confidential and Proprietary Information of ZTE CORPORATION
Connection and Network
In standby screen, press the Left Soft Key [Main Menu] and select Settings > Connection Settings.
Bluetooth: Manage Bluetooth settings and paired Bluetooth devices.
Network Mode: Set the type of network you want to use.
Network Selection: Select network automatically, or search for networks and choose manually.
Access Point: Set access point for using the phone’s data service. Contact your service provider for
more information.
Internet Profiles: Set the profiles for using the phone’s data service. Contact your service provider for
more information.
Modem: Use the phone as a modem for your computer.
PC Connection: Connect the phone and your PC via USB cable or Bluetooth.
Security
In standby screen, press the Left Soft Key [Main Menu] and select Settings > Security Settings.
See Starting Up – Security Code for instructions on the phone password, PIN and PIN2 codes.
Fixed Dialing
If you activate this function, you cannot dial the numbers out of the fixed dial list. Fixed Dialing shows
the fixed dial numbers.
Restoring Factory Settings
Restoring factory settings can reset all the items in Settings menu to the default values.
E821S User Manual
Confidential and Proprietary Information of ZTE CORPORATION 33
C h a p t e r 15
PC Suite
Installing the PC Suite
• This software only supports Windows XP (SP2&SP3), Microsoft Vista and Windows 7. It does not
support Macintosh OS or Windows Me, 95, 98 or 2000.
• If you get an error message “No device available in the hardware list”, please reinstall the drivers using
Windows Device Manager. See the ReadMe file on the CD for help.
• If you connect your phone to your PC before installing the software, then Windows will install the wrong
drivers. Please view the CD for assistance.
1. Insert the CD provided into the CD-ROM of your PC.
2. The installation shield should launch. If it does not, please browse your CD and run the executable (.exe)
file.
3. Follow the prompts to install the software.
4. When the installation is complete, plug your handset into your PC using the USB lead supplied.
5. The USB lead is unique and should not be used for other devices. (It is not the same as digital camera
leads)
6. The PC will automatically install the drivers.
7. Double click the desktop icon and run the Join Me program.
Unstalling the PC Suite
1. Select Start > Program > Join Me > Uninstall Join Me.
Notes:
Before uninstall, please close the program.
2. Complete uninstall according to the prompt information.
Running the PC Suite
Make sure that Join Me application software is installed before powering on your phone and connect it to
your PC.
1. Double click the Join Me icon on the desktop.
2. Click Connect and click OK after selecting your phone model. Now you can use the PC Suite to
manage your messages, contacts, media files and calendar events on your phone, or connect to the
Internet with the phone as your modem.
Tips:
When copying a file from your computer to the memory card or the phone memory, you can drag the
file into the corresponding folder.
E821S User Manual
34 Confidential and Proprietary Information of ZTE CORPORATION
C h a p t e r 16
Troubleshooting and FAQs
If you encounter problems while using the phone, or if it performs erratically, you can consult the
information in the chart below. If your particular problem cannot be resolved using the information in the
chart, contact the dealer of handset.
Problem
Possible causes
Possible solution
Poor reception
The network signal is too weak at your
current location, for example, in a basement
or near a tall building, because wireless
transmissions cannot effectively reach it.
Move to a location where the network signal
can be properly received.
The network is busy at the current time (for
example, during peak times, there may be too
much network traffic to handle additional
calls).
Avoid using the phone at such times, or try
again after waiting a short time.
You are too far away from a base station for
your service provider.
You can request a service area map from your
service provider.
Echo or noise
Poor network trunk quality on the part of your
service provider.
Press the End Key and dial again. You may
be switched to a better-quality network trunk
or phone line.
Poor local telephone line quality.
Press the End Key and dial again. You may
be switched to a better-quality network trunk
or phone line.
Unable to select
certain features.
Your service provider does not support these
features, or you have not applied for services
that provide these features.
Contact your service provider.
Battery will not
charge.
The battery or battery charger is damaged.
Contact the dealer.
The phone’s temperature is below 0℃ or
higher than 45 ℃.
Adjust the battery charging environment to
avoid extremes of temperature.
Poor contact between the battery and charger.
Check all connectors to make sure all
connections have been properly made.
Shortened standby
time
The standby time is related to your service
provider system configuration. The same
phone used with different service providers’
systems will not provide exactly the same
length of standby time.
If you are located in an area where signaling
is weak, temporarily switch off the phone.
The battery is depleted. In high-temperature
environments, battery life will be shortened.
Use a new battery.
If you are not able to connect to the network,
the phone will continue to send out signals as
it attempts to locate a base station. Doing so
consumes battery power and will
consequently shorten standby time.
Change your location to one where the
network is accessible, or temporarily turn off
your phone.
You cannot switch
your phone on.
Battery power has been depleted.
Recharge the phone’s battery.
E821S User Manual
Confidential and Proprietary Information of ZTE CORPORATION 35
Problem
Possible causes
Possible solution
(U)SIM card error
(U)SIM card malfunction or damage.
Take the (U)SIM card to your service
provider for testing.
(U)SIM card inserted improperly.
Insert the (U)SIM card properly.
Debris on the (U)SIM card contacts.
Use a soft, dry cloth to clean the (U)SIM card
contacts.
Unable to connect
to the network.
(U)SIM card invalid.
Contact your service provider.
You are not within the network’s service area.
Check the service area with your service
provider.
Poor signal.
Move to an open space, or if you are inside a
building, move closer to a window.
You cannot answer
incoming calls.
You have activated the Call Barring feature.
Go to Settings > Call Settings > Call
Barring, and then select Cancel all barring.
You cannot make
outgoing calls.
You have activated the Call Barring feature.
Go to Settings > Call Settings > Call
Barring, and then select Cancel all barring.
You have activated the Fixed Dial Number
feature.
Go to Settings > Security Settings > Fixed
Dialing > Fixed Dialing Status, and select
Off to turn this feature off.
PIN code is
blocked.
You have entered an incorrect PIN code three
consecutive times.
Contact your service provider. If the service
provider provides the (U)SIM card’s PUK
code, use the PUK code to unlock the (U)SIM
card.
Unable to enter
information into the
phone book.
The phone book’s memory is already full.
Delete unnecessary data from the Directory.
Confidential and Proprietary Information of ZTE CORPORATION 36
C h a p t e r 17
Technical Parameters
Handset specifications are shown in the following table.
Handset Standards
WCDMA/GSM
Dimensions (H×W×D)
Approx 110mm × 61mm × 12.5mm
Weight
Approx 106g (including battery)
Display
2.4” 262K LCD color screen
Back camera
2.0 M pixel camera
Extended memory
8G microSD card
Battery
900 mA hours, Lithium ion (Li-ion)
Continuous standby time
Up to 150 hours (GSM) / 200 hours (WCDMA
Continuous talk time
About 180 minutes (GSM) / 240 minutes (WCDMA)
Charge time
Approximately 3 to 4 hours
Notes:
The phone’s talk time and standby time are based on ideal working environments. The use of extended
backlighting, browser, and network conditions can reduce battery life and talk/standby time.
