ZTE GR222 GSM Dual-band GPRS Digital Mobile Phone User Manual user manual Rev1
ZTE Corporation GSM Dual-band GPRS Digital Mobile Phone user manual Rev1
ZTE >
user_manual_Rev1
ZTE-G R222
Mobile Phone
User Manual
LEGAL INFORMATION
Copyright © 2010 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in
any form or by any means, electronic or mechanical, including photocopying and
microfilm, without the prior written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make
modifications on print errors or update specifications without prior notice.
Version No. : R1.0
Edition Time :
Manual No. :
3
Table of Contents
SECURITY ....................................... 4
SAFETY PRECAUTIONS ................ 4
LIMITATION OF LIABILITY ............11
KEY FUNCTIONS ...........................15
LOCK AND UNLOCK THE KEYPAD
........................................................16
INTERFACE ICONS ........................17
TECHNICAL PARAMETERS ..........17
BATTERY .......................................18
REMOVE THE BATTERY ...............19
INSERTING THE SIM CARD ..........19
INSERTING THE MEMORY CARD .21
CHARGING THE BATTERY ...........23
POWERING YOUR PHONE ON/OFF
........................................................25
TURN THE TORCH ON/OFF ..........25
WRITING TEXT ..............................25
HOW TO ADD PEOPLE TO THE
PHONEBOOK ................................ 26
HOW TO MAKE AND RECEIVE
CALLS ........................................... 27
HOW TO SEND MESSAGES ......... 27
HOW TO RECEIVE A MESSAGE ... 28
HOW TO SET USER PROFILES .... 28
HOW TO VIEW CALL HISTORY .... 29
HOW TO CONFIGURE CALL
SETTINGS ...................................... 29
HOW TO SET YOUR PHONE ........ 29
HOW TO SET YOUR ALARM ........ 30
FILE MANAGER ............................ 30
CAMERA ........................................ 31
VIEW IMAGE .................................. 32
HOW TO PLAY MUSIC ................... 32
HOW TO LISTEN TO FM................ 32
HOW TO USE SERVICES .............. 33
4
Security
To protect your mobile phone from illegal use, take the security measures
as follows:
Set PIN codes of the SIM card.
Set handset lock code.
Set call restrictions.
Safety Precautions
This section includes some important information on safe and efficient operation.
Please read this information before using the phone.
Operational Precautions
Please use your phone properly. When making or receiving a call,
please hold your phone as holding a wireline telephone. Make sure that
the phone is at least one inch (about two point five centimeters) from
your body when transmitting.
Do not touch the antenna when the phone is in use. Touching the antenna
area affects call quality and may cause the phone to operate at a higher
power level than needed.
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when watching television or playing
5
video games. If you have experienced seizures or blackouts, or if you
have a family history of such occurrences, please consult your doctor
before playing video games on your phone or enabling a flashing-light feature
on your phone. (The flashing-light feature is not available on all products.)
Keep the phone out of the reach of small children. The phone may cause
injury if used as a toy.
Precautions While Driving
Please pay attention to the traffic safety. Check the laws and regulations
on the use of your phone in the area where you drive. Always obey them.
Use hands-free function of the phone, if available.
Pull off the road and park before making or answering a call if conditions
require.
Precautions for Medical Devices and Facilities
When using your phone near pacemakers, please always keep the phone
more than eight inches (about twenty centimeters) from the pacemaker
when the phone is switched on. Do not carry the phone in the breast pocket.
Use the ear opposite the pacemaker to minimize the potential for
interference. Switch off the phone immediately if necessary.
Some phones may interfere with some hearing aids. In the event of
such interference, you may consult your hearing aids manufacturer to
6
discuss alternatives.
If you use any other personal medical device, please consult the
manufacturer of your device to determine if it is adequately shielded from
RF energy.
In those facilities with special demand, such as hospital or health care
facilities, please pay attention to the restriction on the use of mobile phone.
Switch off your phone if required.
Mobile Phone
Please use original accessories or accessories approved by the
phone manufacturer. Using any unauthorized accessories may affect
your mobile phone’s performance, damage your phone or even cause
danger to your body and violate related local regulations about telecom
terminals.
Turn off your phone before you clean it. Use a damp or anti-static cloth
to clean the phone. Do not use a dry cloth or electrostatically charged
cloth. Do not use chemical or abrasive cleaners as these could damage
the phone.
As your mobile phone can produce electromagnetic field, do not place it
near magnetic items such as computer disks.
Using the phone near electrical appliances such as TV, telephone, radio
and personal computer can cause interference.
7
Do not expose your mobile phone to direct sunlight or store it in hot areas.
High temperatures can shorten the life of electronic devices.
Keep your phone dry. Any liquid may damage your phone.
Do not drop, knock or harshly treat the phone. Rough handling can
break internal circuit boards.
Do not connect the phone with any incompatible enhancement.
Do not attempt to disassemble the mobile phone or battery.
Do not store the phone with flammable or explosive articles.
Do not charge the mobile phone without battery.
Some electronic devices are susceptible to electromagnetic interference
sent by phone if inadequately shielded. Please use phone at least 20 cm
or as far away as you can from TV set, radio and other automated office
equipment so as to avoid electromagnetic interference.
Operating phone may interfere with medical devices like hearing aides and
pacemakers, or other medical devices in hospital. Consult a physician or
the manufacturer of the medical device before using phone.
Be aware of the usage limitation when using phone at places such as oil
warehouses, or chemical factories, where there are explosive gases or
explosive products being processed, because even if your phone is in idle
state, it still transmits radio frequency (RF) energy. Therefore, power off
your phone if required.
8
Do not touch the antenna while calling. Otherwise it will affect the quality of
calling and waste battery energy. The damaged antenna will cause slight
burn while touching your skin.
Keep phone out of the reach of small children. Phone may cause injury if
used as a toy.
Do not put other things on the terminal to avoid overlaying radiator.
Keep the antenna free from obstructions and position the antenna straight
up. This will ensure best call quality.
Precautions for Potentially Explosive Atmospheres
Switch off your phone prior to entering any area with potentially
explosive atmospheres, such as fueling areas, fuel or chemical transfer or
storage facilities.
Do not remove, install, or charge batteries in such areas. Spark in a
potentially explosive atmosphere can cause an explosion or fire resulting in
bodily injury or even death.
To avoid possible interference with blasting operations, switch off your
phone when you are near electrical blasting caps, in a blasting area, or
in areas posted “Turn off electronic devices.” Obey all signs and
instructions.
Precautions for Electronic Devices
9
Some electronic devices are susceptible to electromagnetic interference
sent by mobile phone if inadequately shielded, such as electronic system of
vehicles. Please consult the manufacturer of the device before using the phone
if necessary.
Safety and General Use in Vehicles
Safety airbag, brake, speed control system and oil eject system shouldn’t
be affected by wireless transmission. If you do meet problems above,
please contact your automobile provider. Do not place your phone in the
area over an airbag or in the airbag deployment area. Airbags inflate with
great force. If a phone is placed in the airbag deployment area and the
airbag inflates, the phone may be propelled with great force and cause
serious injury to occupants of the vehicle.
Please turn off your mobile phone at a refueling point, and the same to
the place where the use of two-way radio is prohibited.
Aircraft Safety
Please turn off your mobile phone before the airplane takes off. In order
to protect airplane’s communication system from interference, it is
forbidden to use mobile phone in flight. Safety regulations require you to
have permission from a crew member to use your phone while the plane is
on the ground.
10
If the mobile phone has the function of automatic timing power-on,
please check your alarm setting to make sure that your phone will not be
automatically turned on during flight.
Battery Use
Do not short-circuit the battery, as this can cause the unit to overheat or
ignite.
Do not store battery in hot areas or throw it into fire. Otherwise, it will
cause explosion.
Do not disassemble or refit the battery. Otherwise, it will cause liquid
leakage, overheating, explosion and ignition of the battery.
Please store the battery in a cool dry place if you don’t use it for a long
period.
The battery can be recharged for hundreds of times, but it will eventually
wear out. When the operating time (talk time and standby time) is noticeably
shorter than normal, it is time to replace it with a new one.
Please stop using the charger and battery when they are damaged or
show evidence of aging.
Return the worn-out battery to the provider or dispose of it in accordance
with environment regulations. Do not dispose of it in household rubbish.
Please use original batteries or batteries approved by the phone
manufacturer. Using any unauthorized battery may affect your handset
11
performance or may cause danger of explosion, etc.
Warning: If the battery is damaged, do not discharge it. If the leakage does come
into contact with the eyes or skin, wash thoroughly in clean water and consult a
doctor.
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
12
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
Health and safety information
Radio Frequency (RF) Energy
This model phone meets the government’s requirements for exposure to
radio waves.
This phone is designed and manufactured not to exceed the emission limits
for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government:
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using
standard operating positions accepted by the FCC with the phone
transmitting at its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the
actual SAR level of the phone while operating can be well below the
maximum value. This is because the phone is designed to operate at
multiple power levels so as to use only the poser required to reach the
13
network. In general, the closer you are to a wireless base station antenna,
the lower the power output.
The highest SAR value for the model phone as reported to the FCC when
tested for use at the ear is 1.040 W/kg and when worn on the body, as
described in this user guide, is 1.040 W/kg (Body-worn measurements differ
among phone models, depending upon available enhancements and FCC
requirements.)
While there may be differences between the SAR levels of various phones
and at various positions, they all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone with
all reported SAR levels evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this model phone is on file with
the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on
FCC ID: Q78-GR222.
For body worn operation, this phone has been tested and meets the FCC RF
exposure guidelines for use with an accessory that contains no metal and
the positions the handset a minimum of 1.5 cm from the body. Use of other
enhancements may not ensure compliance with FCC RF exposure
guidelines. If you do not use a body-worn accessory and are not holding the
phone at the ear, position the handset a minimum of 1.5 cm from your body
when the phone is switched on.
14
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or
consequential damages resulting from or arising out of or in connection with
using this product, whether or not ZTE had been advised, knew or should have
known the possibility of such damages. The user should refer to the enclosed
warranty card for full warranty and service information.
Note: The pictures and icons shown in the manual are just schematic drawings
for function demonstration. If they are inconsistent with your handset, please take
your handset as the standard. If the inconsistency exits in the manual because of
the handset function updating, please refer to the follow-up public information
from ZTE CORPORATION.
15
Key Functions
End/Power key
Left/Right soft key
Send key
4-Way Navigation
keys and Centre key
* key
# key
Earpiece
Alpha numeric keys
Charger interface
Headset interface
Torch
16
Function
Description
Left soft key Performs the function indicated at the left bottom of the screen.
Right soft key Performs the function indicated at the right bottom of the screen.
Centre key
Press to confirm actions and make selections.
4-Way
Navigation keys
These keys (UP, DOWN, LEFT and RIGHT) allow for navigation
through menu options and quick accessing to some function
menus.
Send key Press to dial a phone number or answer a call, or view the call
history.
End/Power key Press to exit to the standby mode.
Hold to switch on/off the phone.
Alpha numeric keys
Press to enter characters 0-9 and the alphabets from a-z.
Note: In this User Manual, “press a key” means to press the key and release it,
while “hold a key” means to press the key for at least two seconds and then release
it.
Lock and Unlock the Keypad
In the standby mode, press the Left soft key and then press the * key within two
17
seconds to lock the keypad. The unlock method is the same.
Locking the keypad can prevent unintentional operations on it. You can answer
an incoming call with the regular operation when the keypad is locked.
Interface icons
Signal strength New SMS, message full when blinking
Keypad locked New MMS
GPRS Silent
Battery status General
Alarm clock set Headset
Outdoor Meeting
Missed call Call diverting
Technical Parameters
Handset
Type ZTE-G R222
Dimensions（L×W×H） 108.6 mm x 47 mm x 14.5 mm
Weight Approx. 80 g (with battery)
Battery
Continuous standby time max. 280 hours (subject to network status)
18
Continuous talk time max. 540 minutes (subject to network status)
For other parameters about battery and charger, refer to their labels.
Battery
The lithium ion battery of the mobile phone can be immediately used after unpacking.
Install the battery
1. Pull the battery cover downward and remove it.
2. Insert the battery by aligning the metal contacts with the contacts in the
battery slot.
3. Push down the upper section of the battery until it clicks into place.
4. Replace the battery cover and close it gently until you hear a click.
19
Remove the battery cover Push down the battery Replace the battery cover
Remove the battery
1. Make sure that your mobile phone is switched off.
2. Remove the battery cover.
3. Pull the battery up and remove it from the mobile phone.
Remove the battery cover Pull up the battery from here
Inserting the SIM card
Insert the SIM card as follows:
1. Make sure that the phone is switched off and the charger is disconnected
from the phone.
2. Turn the phone over and remove the battery cover.
20
3. Remove the battery if it is already installed.
4. Hold your SIM card with the cut corner oriented as shown and then slide it
into the card holder with the metal contacts facing downward.
5. Replace the battery first.
6. Replace the battery cover.
For dual SIM version:
For single SIM version:
21
SIM card (Subscriber Identity Module) is a micro-chip that holds your personal
information such as names and phone numbers. Your phone won’t work without it.
If you already have contacts on your SIM card, they can be transferred in most
cases.
Inserting the Memory Card
You can use memory card to expand the storage of the phone. You can store
or copy files such as videos, photos, music, and so on.
Do not take out the card or switch off the phone while transmitting or storing data,
which may cause data loss or damage to the phone or the card.
Insert the memory card as follows:
1. Open the battery cover and remove the battery.
2. Follow the OPEN arrow to push the metal slot, and flip it up.
22
3. Insert the card into the metal solt with the metal contacts facing down until it
clicks to the right position.
4. Flip the metal slot back and follow the LOCK arrow to lock it.
Push the metal slot Flip up the metal slot
23
Insert the memory card Flip the metal slot back
Charging the battery
Your phone is powered by a rechargeable battery. For maximum battery performance,
it is recommended that you first use up the battery power and then charge it
completely. A new battery’s full performance is achieved only after three complete
charge and discharge cycles.
1. Connect your travel adapter to the bottom of your mobile phone as shown in
the diagram.
Note: The side with arrow should be upright while connecting.
2. Connect the other end of the travel adapter to the mains socket.
3. When you charge the battery, the battery charging indicator appears.
4. When the battery is fully charged, disconnect the charger.
24
25
Powering your phone on/off
Make sure that your SIM card is in your mobile phone and that the battery is
charged.
Hold the End/Power key to power on/off the phone. The phone will
automatically search for the network.
Turn the torch on/off
In the standby mode, hold the * key to turn on or off the torch.
Writing text
• Change input mode: Press the # key to change the input mode (input
modes: eZi ABC, eZi abc, ABC, abc and 123).
• Input Letters: In ABC/abc mode, press the corresponding letter key
till the letter appears.
• Input Words: In eZi ABC/eZi abc mode, input any letter with a single key
press. Press each key only once for every letter. The word changes after each
key stroke. Predictive text input is based on a built-in dictionary. When you
have finished writing the word and it is correct, confirm it by pressing the 0 key
or the Centre key. If the word is incorrect, press the Left/Right keys to view other
matching words found in the dictionary.
• Input Digits: In 123 mode, press digit key once to input a digit. In eZi
26
ABC/eZi abc mode, press the digit key, and select the number by pressing the
Navigation keys. You cannot input 0 in eZi ABC/eZi abc mode. In ABC/abc mode,
constantly press the digit key until the number appears.
• Input Symbol: Press the * key to enter a symbol. In eZi ABC/eZi abc
mode, press the 1 key, and select the required symbol (common symbols) by
pressing the Navigation keys. In ABC/abc mode, constantly press the 1 key
until the required symbol (common symbols) appears.
• Input Space: Press the 0 key to input space. It does not work in 123
mode.
• Delete Character: Press the Right soft key to clear a character. Hold the
Right soft key to delete all characters and clear the display.
• Move Cursor to Left or Right: Among the text, press the Left/Right
navigation keys to move the cursor to left or right.
How to add people to the Phonebook
There are some numbers that you may want to call again and again, so it makes
sense to add these numbers to your Phonebook. You can then access these
numbers quickly and easily.
1. Go to Menu→Phonebook→Options→Add new contact.
2. Select to save the number to SIM or phone.
3. Edit the information and confirm by selecting Done.
27
• You can also save a number right after you’ve made or received a
phone call or a text message from someone who is not yet in your Phonebook
list.
• To delete someone from your Phonebook list, first select the name,
then select Options→Delete.
• To view the memory status and so on, select Phonebook settings.
How to make and receive calls
The most basic way to make a call is to input the number in the standby mode
and press the Send key. You can also make a call from the Phonebook list.
• To call someone: Go to Menu→Phonebook. Use the Up/Down
keys to find the name of the person you want to call. You can also type in the
first letter of the name of the person you want to call to find the right name, and
press the Send key.
• To receive a call, press the Send key.
• To end a call, press the End/Power key.
• To reject a call, press the End/Power key.
Make sure that you are in an area with sufficient coverage to make calls. The
strength of the network signal is indicated on the Status Bar of the screen.
How to send messages
28
You can use your mobile phone to send and receive messages.
1. Go to Menu→Messages→SMS/MMS→Write message.
2. Write your message. For more information on input method, see section
‘Writing text’. When you write an SMS, press Options→Send to, and edit the
recipient. When you write an MMS, you can edit To, Cc, Bcc, Subject and
content. In content field, you can select Options and then select to add
picture, audio, bookmark, attachment and slide.
3. When you finish writing an SMS, select Options to send or save the
message. When you finish writing an MMS, press Done, and select to send
or save.
How to receive a message
Upon receiving a message, the mobile phone will alert you with a ringtone, prompt,
or a new message icon.
1. Press Read to open the new message. You can also go to Inbox to read the
message.
2. Use the Up/Down keys to view the message.
3. While the message is open, use Options to reply, delete, or forward the
message. You can also call back the sender or save the sender’s number.
How to set User profiles
29
Go to Menu→User profiles. You can select Options→Activate to activate a
profile. Or you can select Options→Customize to edit a profile.
How to view Call history
Go to Menu→Call center→Call history.
Dialed calls, Received calls and Missed calls are saved in Call History. If the
records are full, the earliest saved records will be deleted.
Also, you can view call timers, call cost, SMS counter, and GPRS counter in
Call history.
How to configure Call settings
Go to Menu→Call center→Call settings.
You can set call waiting, call divert and call barring.
In Advance settings, you can set blacklist, auto redial, call time display, call time
reminder, auto quick end.
How to set your phone
You can adjust various settings of your phone. Go to Menu→Settings.
• Dual SIM settings: Select dual SIM open, only SIM1/SIM2 open or
flight mode. This is only available for dual SIM version.
30
• Phone settings: Select language, set time and date and schedule power
on/off, set prefered input method, display, greeting text and LCD backlight, etc.
• Network settings: Set to automatically or manually select network, and
set the preferred networks.
• Security settings: Set security features to protect you from
unauthorized use of your phone and SIM card.
• Connectivity: View connection activities and set data accout.
• Restore factory settings: Enter the phone lock code to restore to the
factory settings. Some personal information might be lost if you use this function,
so be careful.
Note: You may be required to input the phone lock code in some of the security
settings interfaces. The default lock code is 1234. Go to Security settings→Change
password→Phone password to change the phone lock code.
How to set your alarm
Go to Menu→Organizer→Alarm. You can view, and edit the alarm clocks settings.
You can also enable or disable the alarms. By pressing Edit, you can set the
corresponding features of the alarm according to instructions: repeat type, time,
snooze, alert type, etc.
File manager
31
Go to Menu→File manager. You can check all the folders in the phone or memory
card, create new ones or rename, delete, or sort, etc. The files you download from
the internet will be stored in these folders.
Note: When you select Format, the data will be lost, so please be careful with this
function.
Camera
Go to Menu→Multimedia→Camera.
• Take a Photo
Go to Camera to take a photo.
Aim the camera at the subject and then press the Centre key to take the shot.
• Configure your camera
Go to Camera. Press the icon on the bottom left corner to configure your
camera:
♦ Photos: Enter Image viewer to view the photos you’ve just taken.
♦ Camera settings: Set Anti-flicker and Delay timer.
♦ Image settings: Set Image size and Image quality.
♦ White balance: Select Auto, Daylight, Fluorescent or Incandescent.
♦ Scene mode: Select Auto or Night.
♦ Storage: Select Phone or Memory card.
32
♦ Restore default: Restore to factory default settings.
View image
Go to Menu→Multimedia→Image viewer.
The images you want to view in Image viewer must be put in the ..\ Photos folder in
the phone or memory card, and in Options→Storage, the storage must be set
to phone or card correspondingly.
You can select an image and view it.
Image viewer supports: jpeg, jpg, bmp, gif, png.
How to play music
Go to Menu→Multimedia→Audio player. You can play the audio in your phone
or the memory card.
In List, you can refresh your playlist, set storage, or make personal settings.
Audio player supports: AMR-WB, WAV, MP3, iMelody, MIDI.
How to listen to FM
Go to Menu→Multimedia→FM radio.
With the radio, you can search for radio channels, listen to them, and save
them on your device. Note that the quality of the radio broadcast depends on the
33
coverage of the radio station in that particular area. In the FM radio interface,
you can press the Up/Down keys to adjust volume, press the Left/Right keys
to tune the frequency, and press the Centre key to pause. Select Options to
enter the submenu.
• Channel list: Edit the channel list.
• Manual input: Manually input a channel.
• Auto search: Automatically searches for channels.
• Settings: You can turn on Background play, and you can turn on
Loudspeaker when headset is inserted.
How to use Services
Go to Menu→Services. Services allows you to view internet content. In
Services you can use the STK and WAP.
In WAP, select Homepage to go into your homepage.
Select Bookmarks to view the list of saved pages.
Select Recent pages to view the list of pages you recently visited.
Select Input address to go to a page by directly inputting the address.
Go to Service inbox to view the service messages.
Go to Settings→Select SIM to select a SIM card which you wish to use to connect
GPRS. This is only available for dual SIM version.
34
Go to Settings→Profiles to select a profile or add a new one.
Go to Settings→Browser options. Select Timeout to set timeout. If the timeout
period elapsed prior to completion of the operation or the server is not responding,
it will show “Connection Failed”. During the timeout period, it will keep trying to
connect until expired. Select Show images to set whether or not to show the
images. Select whether or not to enable Cache and Cookies.
Go to Settings→Service message settings to set the service message
receiving.
Go to Settings→Clear cache to clear cache.
Go to Settings→Clear cookies to clear cookies.
