S202 GSM Mobile Phone
User Guide
ZTE CORPORATION
ZTE Plaza, Keji Road South,
Hi-Tech Industrial Park,
Nanshan District, Shenzhen,
P. R. China
518057
Tel: (86) 755 26779999
URL: http://www.zte.com.cn
E-mail: mobile@zte.com.cn
LEGAL INFORMATION
Copyright © 2010 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by
any means, electronic or mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications on print
errors or update specifications without prior notice.
Version No. : R1.0
Edition Time :
Manual No. :
Confidential and Proprietary Information of ZTE CORPORATION 1
C h a p t e r 1
User Guide
Security
• To protect your mobile phone from illegal use, take the security measures as follows:
Set PIN codes of the SIM card.
Set handset lock code.
Set call restrictions.
Safety Precautions
This section includes some important information on safe and efficient operation. Please read this
information before using the phone.
Operational Precautions
• Please use your phone properly. When making or receiving a call, please hold your phone as holding a
wireline telephone. Make sure that the phone is at least one inch (about two point five centimeters) from
your body when transmitting.
• Do not touch the antenna when the phone is in use. Touching the antenna area affects call quality and
may cause the phone to operate at a higher power level than needed.
• Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such
as when watching television or playing video games. If you have experienced seizures or blackouts, or if
you have a family history of such occurrences, please consult your doctor before playing video games
on your phone or enabling a flashing-light feature on your phone. (The flashing-light feature is not
available on all products.)
• Keep the phone out of the reach of small children. The phone may cause injury if used as a toy.
Precautions While Driving
• Please pay attention to the traffic safety. Check the laws and regulations on the use of your phone in the
area where you drive. Always obey them.
• Use hands-free function of the phone, if available.
• Pull off the road and park before making or answering a call if conditions require.
Precautions for Medical Devices and Facilities
• When using your phone near pacemakers, please always keep the phone more than eight inches (about
twenty centimeters) from the pacemaker when the phone is switched on. Do not carry the phone in the
breast pocket. Use the ear opposite the pacemaker to minimize the potential for interference. Switch off
the phone immediately if necessary.
• Some phones may interfere with some hearing aids. In the event of such interference, you may consult
your hearing aids manufacturer to discuss alternatives.
• If you use any other personal medical device, please consult the manufacturer of your device to
determine if it is adequately shielded from RF energy.
• In those facilities with special demand, such as hospital or health care facilities, please pay attention to
the restriction on the use of mobile phone. Switch off your phone if required.
S202 GSM Mobile Phone User Guide
2 Confidential and Proprietary Information of ZTE CORPORATION
Mobile Phone
• Please use original accessories or accessories approved by the phone manufacturer. Using any
unauthorized accessories may affect your mobile phone’s performance, damage your phone or even
cause danger to your body and violate related local regulations about telecom terminals.
• Turn off your phone before you clean it. Use a damp or anti-static cloth to clean the phone. Do not use a
dry cloth or electrostatically charged cloth. Do not use chemical or abrasive cleaners as these could
damage the phone.
• As your mobile phone can produce electromagnetic field, do not place it near magnetic items such as
computer disks.
• Using the phone near electrical appliances such as TV, telephone, radio and personal computer can cause
interference.
• Do not expose your mobile phone to direct sunlight or store it in hot areas. High temperatures can
shorten the life of electronic devices.
• Keep your phone dry. Any liquid may damage your phone.
• Do not drop, knock or harshly treat the phone. Rough handling can break internal circuit boards.
• Do not connect the phone with any incompatible enhancement.
• Do not attempt to disassemble the mobile phone or battery.
• Do not store the phone with flammable or explosive articles.
• Do not charge the mobile phone without battery.
Precautions for Potentially Explosive Atmospheres
• Switch off your phone prior to entering any area with potentially explosive atmospheres, such as fueling
areas, fuel or chemical transfer or storage facilities.
• Do not remove, install, or charge batteries in such areas. Spark in a potentially explosive atmosphere can
cause an explosion or fire resulting in bodily injury or even death.
• To avoid possible interference with blasting operations, switch off your phone when you are near
electrical blasting caps, in a blasting area, or in areas posted “Turn off electronic devices.” Obey all
signs and instructions.
Precautions for Electronic Devices
• Some electronic devices are susceptible to electromagnetic interference sent by mobile phone if
inadequately shielded, such as electronic system of vehicles. Please consult the manufacturer of the
device before using the phone if necessary.
Safety and General Use in Vehicles
• Safety airbag, brake, speed control system and oil eject system shouldn’t be affected by wireless
transmission. If you do meet problems above, please contact your automobile provider. Do not place
your phone in the area over an airbag or in the airbag deployment area. Airbags inflate with great force.
If a phone is placed in the airbag deployment area and the airbag inflates, the phone may be propelled
with great force and cause serious injury to occupants of the vehicle.
• Please turn off your mobile phone at a refueling point, and the same to the place where the use of
two-way radio is prohibited.
Aircraft Safety
• Please turn off your mobile phone before the airplane takes off. In order to protect airplane’s
communication system from interference, it is forbidden to use mobile phone in flight. Safety
regulations require you to have permission from a crew member to use your phone while the plane is on
S202 GSM Mobile Phone User Guide
Confidential and Proprietary Information of ZTE CORPORATION 3
the ground.
• If the mobile phone has the function of automatic timing power-on, please check your alarm setting to
make sure that your phone will not be automatically turned on during flight.
Battery Use
• Do not short-circuit the battery, as this can cause the unit to overheat or ignite.
• Do not store battery in hot areas or throw it into fire. Otherwise, it will cause explosion.
• Do not disassemble or refit the battery. Otherwise, it will cause liquid leakage, overheating, explosion
and ignition of the battery.
• Please store the battery in a cool dry place if you don’t use it for a long period.
• The battery can be recharged for hundreds of times, but it will eventually wear out. When the operating
time (talk time and standby time) is noticeably shorter than normal, it is time to replace it with a new
one.
• Please stop using the charger and battery when they are damaged or show evidence of aging.
• Return the worn-out battery to the provider or dispose of it in accordance with environment regulations.
Do not dispose of it in household rubbish.
• Please use original batteries or batteries approved by the phone manufacturer. Using any unauthorized
battery may affect your handset performance or may cause danger of explosion, etc.
Warning:
If the battery is damaged, do not discharge it. If the leakage does come into contact with the eyes or skin,
wash thoroughly in clean water and consult a doctor.
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the condition
that this device does not cause harmful interference.
Caution: Changes or modifications not expressly approved by the manufacturer could void
the user’s authority to operate the equipment.
Health and safety information
Radio Frequency (RF) Energy
This model phone meets the government’s requirements for exposure to radio waves.
This phone is designed and manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of the U.S. Government:
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted
using standard operating positions accepted by the FCC with the phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is determined at the highest certified power
level, the actual SAR level of the phone while operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power levels so as to use only the poser required to
reach the network. In general, the closer you are to a wireless base station antenna, the lower the power
output.
S202 GSM Mobile Phone User Guide
4 Confidential and Proprietary Information of ZTE CORPORATION
The highest SAR value for the model phone as reported to the FCC when tested for use at the ear is
1.490W/kg and when worn on the body, as described in this user guide, is 0.684 W/kg (Body-worn
measurements differ among phone models, depending upon available enhancements and FCC
requirements.)
While there may be differences between the SAR levels of various phones and at various positions, they
all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on
FCC ID: Q78-GS202.
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for use
with an accessory that contains no metal and the positions the handset a minimum of 1.5 cm from the
body. Use of other enhancements may not ensure compliance with FCC RF exposure guidelines. If
you do no t use a body-worn accessory and are not holding the phone at the ear, position the handset a
minimum of 1.5 cm from your body when the phone is switched on.
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages
resulting from or arising out of or in connection with using this product, whether or not ZTE had been
advised, knew or should have known the possibility of such damages. The user should refer to the
enclosed warranty card for full warranty and service information.
Notes:
The pictures and icons shown in the manual are just schematic drawings for function demonstration. If
they are inconsistent with your handset, please take your handset as the standard. If the inconsistency exits
in the manual because of the handset function updating, please refer to the follow-up public information
from ZTE CORPORATION.
Before use
Put in / take out battery
Put in battery
1. Remove the battery cover.
2. Insert the battery carefully with the contacts located against the gold springs. The battery will only fit
one way.
3. Put on battery cover. Make sure that cover is completely matched and the cover matching sound could
be heard.
S202 GSM Mobile Phone User Guide
Confidential and Proprietary Information of ZTE CORPORATION 5
Take battery out
1. Remove the battery cover.
2. Press the battery side and lift it up to take it out from battery slot.
3. Put on battery cover. Make sure that cover is completely matched and the cover matching sound could
be heard.
Notes:
Shut down all devices and cut the connection with charger when removing battery. Please use battery
which is matched with this phone only.
Charge battery
Phone could be charged when phone is power off or power on. Make sure that the battery is inserted in
phone before charging.
1. Plug in the charger.
2. Plug out the charger from power jack first after it is fully charged. Then unplug charger from the phone.
S202 GSM Mobile Phone User Guide
6 Confidential and Proprietary Information of ZTE CORPORATION
Notes:
Battery indication will be displayed after several minutes if battery is over-discharged.
Battery level indication bar
Charging
Charged
Not enough battery alert
Phone will give alert when battery is not enough and display a message of low battery on screen. Please
charge battery when you receive the alert of low battery during calling in order to keep the calling.
Insert / take out SIM card
1. Insert SIM card: Remove battery cover, insert and slide the SIM card with the metal part facing
downward by following arrow direction at battery slot until SIM card is completely inserted in right
position.
2. Take out SIM card: Hold the notch of SIM card and lift it slightly up by the other hand to take card out.
S202 GSM Mobile Phone User Guide
Confidential and Proprietary Information of ZTE CORPORATION 7
Power on / off the phone
Long press the Red key to power on.
Long press the Red key to power off the phone at standby mode.
Your phone
Standby mode
When the phone is ready to use but no operation on phone, then phone is under standby mode.
* key
# key
Numeric keys
Send key
(Green key)
End key
(Red key)
Up key
Down key
S202 GSM Mobile Phone User Guide
8 Confidential and Proprietary Information of ZTE CORPORATION
Main Display
1. Network signal
2. Status bar
3. Battery level
4. Service provider name
5. Time
6. Date
SOS key
Torch key
Keypad lock key
Volume keys
Charging slot
FM key
Torch light
Headset jack
S202 GSM Mobile Phone User Guide
Confidential and Proprietary Information of ZTE CORPORATION 9
Icon indication
Battery level
Network signal
New SMS
（blinking）
SMS full
Missed call
Keypad locked
Headset
inserted
New SMS when
keypad is
locked
Missed call
when keypad is
locked
New SMS and
Missed call
when keypad is
locked
Key functions
Function
Description
Send key (Green key)
Press to call out.
Press to pick up phone when there is an incoming call.
In standby mode, press to enter call list.
When operating, press to confirm the function you choose
End key (Red key)
Long press to power on or off.
When operating, press to go back to previous menu, long
press to go back to standby mode.
In standby mode, press to enter quick search.
S202 GSM Mobile Phone User Guide
10 Confidential and Proprietary Information of ZTE CORPORATION
Function
Description
Up key
In standby mode, press to enter organiser.
When operating, press to move cursor up.
Down key
In standby mode, press to enter main menu.
When operating, press to move cursor down.
# key
In standby mode, press to input “#”.
In SMS editing status, press to switch input mode.
* key
In standby mode, press to input “*”, “+”, “p” or “w”.
In SMS editing status, press to use common symbols.
Numeric keys
Enter characters 0-9 and the alphabets from A-Z.
SOS key
Push down to turn on the SOS alert and dial the emergency
calls.
Volume keys
Adjusts the volume.
Torch key
Push to turn on or off the torch.
FM key
In the standby mode, press to turn on the FM radio.
Keypad lock key
Push to lock and unlock keypad.
Voice call
Dial emergency call
Go to Organiser > SOS > SOS Switch to set emergency call function on or off.
Volume: Set the type of volume or you can turn off the alerting sound.
Set emergency call: go to Organiser > SOS > SOS Number to set five emergency numbers.
Set emergency SMS: go to Organiser > SOS > SOS SMS to edit an emergency SMS.
If you have already set emergency numbers and enabled this function, when you push down the SOS
key, the phone will send emergency SMS to the set numbers first, and then dial these numbers one by
one. If one number can not get through, it will call the next number. There will be two calling cycles.
The phone will send out alerting sound when it is sending message. After the message is sent out, then
it will call set emergency numbers.
If any call can get through, the phone will be in emergency alert status after the call ends, and send out
alerting sound.
In any status, push up the SOS key, the phone will go back to standby mode. If the keypad is locked,
the phone will still activate emergency mode when you push down the SOS key.
Dial call
Input the area code and phone number and press the Green key to dial out. Use the Red key to delete
if there is wrong input. Long press the Red key to clear all characters.
Voice assist dial: go to Settings > User Profiles > Personalise > Tone Setup > Keypad Tone. Select
“Spoken Tone” for Keypad Tone. When you input the phone number, your phone will read the number
S202 GSM Mobile Phone User Guide
Confidential and Proprietary Information of ZTE CORPORATION 11
you dial at the same time.
Aid Volume: go to Settings > User Profiles > Personalise > Volume > In Call Volume. Select a
number (1 to 7) and press the Green key. In a call, hold the “0” number and the volume will turn to the
size of the number you set.
Press the * key twice to input “+”. Press the * key for three times to input p symbol.
Press the Green key to answer an incoming call, and press the Red key to end the call or reject a call.
Dial a number in Phone Book: go to Phone Book > Quick Search or press Red key to enter quick
search in standby mode. Then press the Up/Down Key to select the number you want to dial and press
the Green key to select “Dial”.
If you have set the speed dial number, in the standby mode, long press the numeric keys (2 to 9) to dial
the corresponding speed dial number.
Press the Volume keys to adjust volume during the call.
Messages
on screen means there is a new message and it blinking means mail box is full.
Select Messages > Write Message to type a new message, then press the Green key to send it only,
save and send it, save it or exit.
Press the # key to switch input method.
When a message is received, press the Green key to read message directly. Press the Red key to exit if
you want to read it later.
Inbox shows all received messages, Outbox shows all sent out messages if you saved, Drafts shows all
your messages saved, Voice Mail is a kind of network service, and Broadcast Message shows all the
received broadcast message.
You can delete message by selecting Option > Delete when viewing a message.
Call History
Press the Green key to check call history under standby state. Dialed Call shows all your calls out,
Received Call shows all your incoming calls and Missed call shows all your missed incoming calls.
Delete Call Log: You can delete call logs of Dialed Call, Received Call and Missed call or you can
delete all call logs.
Call Time: You can check the time of Last Call Time, Total Dialed and Total Received, you can also
reset all time.
Phone Book
You can save the name and phone number of contact to the phone memory and SIM card.
Select Phone Book > Add New Entry to add new contact, and select to save to SIM or phone.
Select Phone Book > Quick Search to view the phone book. Input the first letters of the name, the
phone will list the corresponding records.
Select Phone Book > Delete All to delete all contacts from the phone or SIM. Or you can select
Option > Delete in phone book list to delete the contacts one by one.
Select Phone Book > Copy All to copy all records from SIM to phone or from Phone to SIM.
Select Phone Book > Memory Status to view the memory status of the SIM card and the phone.
S202 GSM Mobile Phone User Guide
12 Confidential and Proprietary Information of ZTE CORPORATION
Settings
Select Settings > User Profiles > Silent to select On or Off for Silent.
Select Settings > User Profiles > Personalise to set Tone Setup, Volume and Alert Type.
Select Settings > Phone Setup > Set Time to set time and date.
Select Settings > Phone Setup > Set Home City to set the city you are in.
Select Settings > Phone Setup > Schedule Power On/Off to set automatic power on/off time.
Select Settings > Phone Setup > Language to set language.
Select Settings > Phone Setup > LCD Backlight to set LCD backlight time.
Select Settings > Call Setup > Call Time Reminder to set call time reminder.
Select Settings > Call Setup > Speed Dial to set speed dial number for 2 to 9 key.
Select Settings > Network Selection > New Search to search network single.
Select Settings > Network Selection > Select Network to reselect network.
Select Settings > Network Selection > Selection Mode to select Automatic or Manual for Selection
Mode.
Organiser
Tips
Select Tips> Birthdays. Select Add to edit a name, time and date, and the phone will remind you at
that time every year.
Select Tips> Important Dates. Select Add to edit a name, time and date, and the phone will remind
you at that time every year.
Select Tips> Medication Reminder. Select Add to edit a name and time, and the phone will remind
you at that time every day.
Select Tips> Getting Up. Select Add to edit a name and time, and the phone will remind you at that
time every day.
Select Tips> Entertainment. Select Add to edit a name and time, and the phone will remind you at
that time every day.
Select Tips> Others. Select Add to edit a name, time, date and repeat type, and the phone will remind
you as is set.
Select Tips> Count Down. Select Add to edit a name and time, and the phone will start to
count down.
Calendar
Select Calendar to view the calendar.
Calculator
Select Calculator. Press Up/Down keys to choose the operation symbols like +, -, *, /, = and press the
Green key to confirm it.
Press the Red key to clear all input information during using calculator and to exit calculator while 0
shows in the display.
SOS
See the Chapter of “Dial emergency call”.
S202 GSM Mobile Phone User Guide
Confidential and Proprietary Information of ZTE CORPORATION 13
Radio
Push the FM key to turn radio on or off under standby mode. Press the Green key to start to enjoy
radio and press the Red key to stop it and press again to continue.
Press Up/Down keys to turn up/down the channel number or input channel number directly to set the
channel, and then press the Green key to confirm the channel.
Press Volume keys to adjust the volume.
Select Option > Channel List > Option > Play to play the selected channel. Select Option > Channel
List > Option > Edit to edit the selected channel.
Select Option > Manual Input to manually input a channel. Confirm to play the channel.
Select Option > Volume to set the FM volume.
Select Option > Preset Auto Search to reset the playlist.
Select Option > Loud Speaker to turn on or off the loudspeaker.
Input method
1. Change input mode: Press the # key to change the input mode (input modes: Multitap abc, Multitap
ABC, Smart abc and Numeric 123).
2. Input Letters: In Multitap ABC and Multitap abc mode, press the corresponding letter key till the letter
appears.
3. Input Words: In Smart abc mode, input any letter with a single key press. Press each key only once for
every letter. The word changes after each key stroke. Predictive text input is based on a built-in
dictionary. When you have finished writing the word and it is correct, confirm it by pressing the Green
key. If the word is incorrect, press the Up/Down key to view other matching words found in the
dictionary.
4. Input Digits: In Numeric 123 mode, press digit key once to input a digit. In Multitap ABC and Multitap
abc mode, constantly press the digit key until the number appears.
5. Input Symbol: Press the * key to open the symbol list. Press the Up/Down keys to select a symbol and
press the Green key to confirm it. In Multitap ABC and Multitap abc mode, constantly press the 1 key
till the required symbol (common symbols) appears.
6. Input Space: Press the 0 key to input space. It does not work in Numeric 123 mode.
7. Delete Character: Press the Red key to clear a character. Hold the Red key to delete all characters and
clear the display.
8. Move Cursor to left or right: Press the Up/Down keys to move the cursor to left or right.
