ZTE GS217 GSM 850/1900 GPRS Digital Mobile Phone User Manual ZTE G S217
ZTE Corporation GSM 850/1900 GPRS Digital Mobile Phone ZTE G S217
ZTE >
User manual
ZTE-G S217
Mobile Phone
User Manual
LEGAL INFORMATION
Copyright © 2011 ZTE GROUP.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or
utilized in any form or by any means, electronic or mechanical, including
photocopying and microfilm, without the prior written permission of
ZTE GROUP.
The manual is published by ZTE GROUP. We reserve the right to make
modifications on print errors or update specifications without prior notice.
Version No.: R1.0
Edition Time: 2011226
User manual S217 ZTE
3
Table of Contents
SECURITY ................................ 5
SAFETY PRECAUTIONS ......... 5
LIMITATION OF LIABILITY ... 17
YOUR PHONE ........................ 19
LOCKING AND UNLOCKING
THE KEYPAD ......................... 21
INTERFACE ICONS ............... 21
BATTE RY ................................ 22
INSERTING THE SIM CARD .. 24
INSERTING THE MEMORY
CARD ...................................... 25
CHARGING THE BATTERY ... 26
POWERING YOUR PHONE
ON/OFF ................................... 28
TURNING THE TORCH ON/OFF
................................................ 28
WRITING TEXT ....................... 28
HOW TO ADD CONTACT TO
THE PHONEBOOK ................. 29
HOW TO MAKE AND RECEIVE
CALLS .................................... 30
HOW TO SEND MESSAGES . 31
HOW TO RECEIVE MESSAGES
................................................ 32
HOW TO SET USER PROFILES
................................................ 32
HOW TO VIEW CALL HISTORY
................................................ 32
4
HOW TO CONFIGURE CALL
SETTINGS .............................. 33
HOW TO SET YOUR PHONE 33
HOW TO SET YOUR ALARM 34
FILE MANAGER .................... 34
VIEWING IMAGE.................... 35
HOW TO PLAY MUSIC .......... 35
HOW TO USE FM RADIO ...... 36
USING SERVICES ................. 37
User manual S217 ZTE
5
Security
To protect your mobile phone from illegal use, take the security
measures as follows:
Set PIN codes of the SIM card.
Set handset lock code.
Set call restrictions.
Safety Precautions
This section includes some important information on safe and efficient
operation. Please read this information before using the phone.
Operational Precautions
Please use your phone properly. When making or receiving a call,
please hold your phone as holding a wireline telephone. Make sure
that the phone is at least one inch (about two point five centimeters)
from your body when transmitting.
User manual S217 ZTE
6
Do not touch the antenna when the phone is in use. Touching the
antenna area affects call quality and may cause the phone to operate
at a higher power level than needed.
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when watching television or playing
video games. If you have experienced seizures or blackouts, or if
you have a family history of such occurrences, please consult your
doctor before playing video games on your phone or enabling a flashing-
light feature on your phone. (The flashing-light feature is not available
on all products.)
Keep the phone out of the reach of small children. The phone may
cause injury if used as a toy.
Precautions While Driving
Please pay attention to the traffic safety. Check the laws and regulations
on the use of your phone in the area where you drive. Always obey
them.
User manual S217 ZTE
7
Use hands-free function of the phone, if available.
Pull off the road and park before making or answering a call if conditions
require.
Precautions for Medical Devices and Facilities
When using your phone near pacemakers, please always keep the
phone more than eight inches (about twenty centimeters) from the
pacemaker when the phone is switched on. Do not carry the phone in
the breast pocket. Use the ear opposite the pacemaker to minimize
the potential for interference. Switch off the phone immediately if
necessary.
Some phones may interfere with some hearing aids. In the event
of such interference, you may consult your hearing aids manufacturer
to discuss alternatives.
If you use any other personal medical device, please consult the
manufacturer of your device to determine if it is adequately shielded
from RF energy.
User manual S217 ZTE
8
In those facilities with special demand, such as hospital or health care
facilities, please pay attention to the restriction on the use of mobile
phone. Switch off your phone if required.
Mobile Phone
Please use original accessories or accessories approved by the
phone manufacturer. Using any unauthorized accessories may
affect your mobile phone’s performance, damage your phone or even
cause danger to your body and violate related local regulations about
telecom terminals.
Turn off your phone before you clean it. Use a damp or anti-static cloth
to clean the phone. Do not use a dry cloth or electrostatically charged
cloth. Do not use chemical or abrasive cleaners as these could damage
the phone.
As your mobile phone can produce electromagnetic field, do not place
it near magnetic items such as computer disks.
Using the phone near electrical appliances such as TV, telephone,
radio and personal computer can cause interference.
User manual S217 ZTE
9
Do not expose your mobile phone to direct sunlight or store it in hot
areas. High temperatures can shorten the life of electronic devices.
Keep your phone dry. Any liquid may damage your phone.
Do not drop, knock or harshly treat the phone. Rough handling can
break internal circuit boards.
Do not connect the phone with any incompatible enhancement.
Do not attempt to disassemble the mobile phone or battery.
Do not store the phone with flammable or explosive articles.
Do not charge the mobile phone without battery.
Some electronic devices are susceptible to electromagnetic interference
sent by phone if inadequately shielded. Please use phone at least 20
cm or as far away as you can from TV set, radio and other automated
office equipment so as to avoid electromagnetic interference.
Operating phone may interfere with medical devices like hearing aides
and pacemakers, or other medical devices in hospital. Consult a
physician or the manufacturer of the medical device before using phone.
User manual S217 ZTE
10
Be aware of the usage limitation when using phone at places such as
oil warehouses, or chemical factories, where there are explosive
gases or explosive products being processed, because even if your
phone is in idle state, it still transmits radio frequency (RF) energy.
Therefore, power off your phone if required.
Do not touch the antenna while calling. Otherwise it will affect the
quality of calling and waste battery energy. The damaged antenna
will cause slight burn while touching your skin.
Keep phone out of the reach of small children. Phone may cause
injury if used as a toy.
Do not put other things on the terminal to avoid overlaying radiator.
Keep the antenna free from obstructions and position the antenna
straight up. This will ensure best call quality.
Precautions for Potentially Explosive Atmospheres
Switch off your phone prior to entering any area with potentially explosive
atmospheres, such as fueling areas, fuel or chemical transfer or
User manual S217 ZTE
11
storage facilities.
Do not remove, install, or charge batteries in such areas. Spark in a
potentially explosive atmosphere can cause an explosion or fire
resulting in bodily injury or even death.
To avoid possible interference with blasting operations, switch off
your phone when you are near electrical blasting caps, in a blasting
area, or in areas posted “Turn off electronic devices.” Obey all signs
and instructions.
Precautions for Electronic Devices
Some electronic devices are susceptible to electromagnetic interference
sent by mobile phone if inadequately shielded, such as electronic
system of vehicles. Please consult the manufacturer of the device before
using the phone if necessary.
User manual S217 ZTE
12
Safety and General Use in Vehicles
Safety airbag, brake, speed control system and oil eject system
shouldn’t be affected by wireless transmission. If you do meet problems
above, please contact your automobile provider. Do not place your
phone in the area over an airbag or in the airbag deployment area.
Airbags inflate with great force. If a phone is placed in the airbag
deployment area and the airbag inflates, the phone may be propelled
with great force and cause serious injury to occupants of the vehicle.
Please turn off your mobile phone at a refueling point, and the same
to the place where the use of two-way radio is prohibited.
Aircraft Safety
Please turn off your mobile phone before the airplane takes off. In
order to protect airplane’s communication system from interference,
it is forbidden to use mobile phone in flight. Safety regulations require
you to have permission from a crew member to use your phone while
the plane is on the ground.
User manual S217 ZTE
13
If the mobile phone has the function of automatic timing power-on,
please check your alarm setting to make sure that your phone will not
be automatically turned on during flight.
Battery Use
Do not short-circuit the battery, as this can cause the unit to overheat
or ignite.
Do not store battery in hot areas or throw it into fire. Otherwise, it
will cause explosion.
Do not disassemble or refit the battery. Otherwise, it will cause liquid
leakage, overheating, explosion and ignition of the battery.
Please store the battery in a cool dry place if you don’t use it for a long
period.
The battery can be recharged for hundreds of times, but it will eventually
wear out. When the operating time (talk time and standby time) is
noticeably shorter than normal, it is time to replace it with a new one.
Please stop using the charger and battery when they are damaged
or show evidence of aging.
User manual S217 ZTE
14
Return the worn-out battery to the provider or dispose of it in accordance
with environment regulations. Do not dispose of it in household rubbish.
Please use original batteries or batteries approved by the phone
manufacturer. Using any unauthorized battery may affect your handset
performance or may cause danger of explosion, etc.
Warning: If the battery is damaged, do not discharge it. If the leakage
does come into contact with the eyes or skin, wash thoroughly in clean
water and consult a doctor.
FCC Compliance:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate he equipment.
User manual S217 ZTE
15
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/ TV technician for help.
User manual S217 ZTE
16
Health and safety informationRadio Frequency (RF) Energy
This model phone meets the government's requirements for exposure to
radio waves.
This phone is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government:
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using
standard operating positions accepted by the FCC with the phone
transmitting at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest certified power
level, the actual SAR level of the phone while operating can be well
below the maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the poser required to
reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
The highest SAR value for the model phone as reported to the FCC
User manual S217 ZTE
17
when tested for use towards ground is 1.34 mW/g. While there may be
differences between the SAR levels of various phones and at various
positions, they all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this model phone is on file with
the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID: Q78-GS217
For body worn operation, this phone has been tested and meets the
FCC RF exposure guidelines for use with an accessory that contains no
metal and the positions for the handset a minimum of 1.5 cm from the
body. Use of other enhancements may not ensure compliance with FCC
RF exposure guidelines. If you do not use a body-worn accessory and
are not holding the phone at the ear, position the handset a minimum of
1.5 cm from your body when the phone is switched on.
User manual S217 ZTE
18
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special,
incidental or consequential damages resulting from or arising out of or in
connection with using this product, whether or not ZTE had been
advised, knew or should have known the possibility of such damages.
The user should refer to the enclosed warranty card for full warranty and
service information.
Note: The pictures and icons shown in the manual are just schematic
drawings for function demonstration. If they are inconsistent with your
handset, please take your handset as the standard. If the inconsistency
exits in the manual because of the handset function updating, please
refer to the follow-up public information from ZTE GROUP.
User manual S217 ZTE
19
Your phone
Torch
4-Way Navigation
keys and Center key
End/Power key
Alpha numeric keys
Earpiece
Left/Right soft key
Send key
* key # key
USB/earphone jack
User manual S217 ZTE
20
Function Description
Left soft key Performs the function indicated at the left bottom of the
screen.
Right soft key Performs the function indicated at the right bottom of the
screen.
Center key Press to confirm actions and make selections.
4-Way
Navigation keys
These keys (UP, DOWN, LEFT and RIGHT) allow for
navigation through menu options and quick access to
some function menus.
Send key Press to dial a phone number or answer a call, or view
the call history.
End/Power key Press to exit to the standby mode.
Hold to switch on/off the phone.
Alpha numeric keys Press to enter characters 0-9 and the alphabets from a-z.
User manual S217 ZTE
21
Note: In this User Manual, “press a key” means to press the key and
release it, while “hold a key” means to press the key for at least two
seconds and then release it.
Locking and Unlocking the Keypad
In the standby mode, press the Left soft key and then press the * key
within two seconds to lock the keypad. The unlock method is the same.
Locking the keypad can prevent unintentional operations on it. You can
answer an incoming call with the regular operation when the keypad is
locked.
Interface icons
SIM1_Signal strength SIM2_Signal strength
SIM1_New SMS SIM2_New SMS
User manual S217 ZTE
22
Keypad locked Battery status
Alarm clock set Headset
Silent General
Outdoor Meeting
Battery
The lithium ion battery of the mobile phone can be immediately used
after unpacking.
Installing the battery
1. Pull the battery cover downward and remove it.
2. Insert the battery by aligning the metal contacts with the contacts in
the battery slot.
3. Push down the upper section of the battery until it clicks into place.
4. Replace the battery cover and close it gently until you hear a click.
User manual S217 ZTE
23
Remove the battery cover Push down the battery
Replace the battery cover
Removing the battery
1. Make sure that your mobile phone is switched off.
2. Remove the battery cover.
User manual S217 ZTE
24
3. Pull the battery up and remove it from the mobile phone.
Remove the battery cover Pull up the battery from here
Inserting the SIM card
Insert the SIM card as follows:
1. Make sure that the phone is switched off and the charger is
disconnected from the phone.
2. Turn the phone over and remove the battery cover.
3. Hold your SIM card with the cut corner oriented as shown and then
slide it into the card holder with the metal contacts facing downward.
4. Replace the battery cover.
User manual S217 ZTE
25
Note:Insert the SIM2 card with the same way.
SIM card (Subscriber Identity Module) is a micro-chip that holds your
personal information such as names and phone numbers. Your phone
won’t work without it. If you already have contacts on your SIM card,
they can be transferred in most cases.
Inserting the Memory Card
You can use a memory card to expand the storage of the phone. You
can store or copy files such as videos, photos, music, and so on.
User manual S217 ZTE
26
Do not take out the card or switch off the phone while transmitting or
saving data, which may cause data loss or damage to the phone or the
card.
Insert the memory card as follows:
1. Open the battery cover and remove the battery.
2. Insert the card into the metal slot with the metal contacts facing down
until it clicks to the right position.
Charging the battery
Your phone is powered by a rechargeable battery. For optimum battery
User manual S217 ZTE
27
performance, it is recommended that you first use up the battery power
and then charge it completely. A new battery’s full performance is achieved
only after three complete charge and discharge cycles.
1. Connect your travel adapter to the left of your mobile phone as shown
in the diagram.
2. Connect the other end of the travel adapter to the mains socket.
3. When the battery is fully charged, disconnect the charger.
User manual S217 ZTE
28
Powering your phone on/off
Make sure that your SIM card is in your mobile phone and that the battery
is charged.
Hold the End/Power key to power on/off the phone. The phone will
automatically search for the network.
Turning the torch on/off
In the standby mode, hold the * key can turn on or off the torch.
Writing text
Change input mode: Press the # key to change the input mode.
Input letters: In alphabet (ABC/abc) mode, press the corresponding
letter key till the letter appears.
Input digits: In numeric (123) mode, press digit key once to input a
digit.
User manual S217 ZTE
29
Input symbol: Press the * key to enter symbol mode, select the
required symbol (common symbols) by pressing the Navigation keys
and then press the Left soft key or Center key to confirm it. In
alphabet (ABC/abc) mode, constantly press the 1 key until the
required symbol (common symbols) appears.
Input space: Press the 0 key to input space. It does not work in 123
mode.
Delete character: Press the Right soft key to clear a character. Hold
the Right soft key to delete all characters and clear the display.
Move cursor to left or right: Among the text, press the Left/Right
navigation keys to move the cursor to left or right.
How to add contact to the Phonebook
There are some numbers that you may want to call again and again, so
it makes sense to add these numbers to your Phonebook. You can
then access these numbers quickly and easily.
1. Go to Menu>Phonebook>Add new contact.
User manual S217 ZTE
30
2. Edit the information and save it.
You can also save a number right after you’ve made or received a
phone call or a text message from someone who is not yet in your
Phonebook list.
To delete someone from your Phonebook list, first select the name,
and then select Options>Delete.
How to make and receive calls
The most basic way to make a call is to input the number in the standby
mode and press the Send key. You can also make a call from the
Phonebook list.
To call someone: Go to Menu>Phonebook. Use the Up/Down
keys to find the name of the person you want to call. You can also
type in the first letter of the name of the person you want to call to
find the right name, and press the Send key.
To receive a call, press the Send key.
To end a call, press the End/Power key.
User manual S217 ZTE
31
To reject a call, press the End/Power key.
Make sure that you are in an area with sufficient coverage to make calls.
The strength of the network signal is indicated on the Status Bar of the
screen.
How to send messages
You can use your mobile phone to send and receive messages.
1. Go to Menu>Messaging>Write message>Text
message/Multimedia message.
2. Write your message. For more information on input method, see
section ‘Writing text’. When you write an SMS, press Options>Send to,
and edit the recipient. When you write an MMS, you can edit To, Cc,
Bcc, Subject and content. In content field, you can select Options and
then select to add pictures, sound, subject, attachment and slides.
3. When you finish writing an SMS/MMS, select Options to send or
save the message.
User manual S217 ZTE
32
How to receive messages
Upon receiving a message, the mobile phone will alert you with a ringtone,
prompt, or a new message icon.
1. Press View to open the new message. You can also go to Inbox to
read the message.
2. Use the Up/Down keys to view the message.
3. While the message is open, use Options to reply, delete, or forward the
message. You can also call back the sender.
How to set User profiles
Go to Menu>Settings>User profiles. You can select Options>
Activate to activate a profile. Or you can select Options>Customize to
edit a profile.
How to view Call history
Go to Menu>Call center>Call history.
User manual S217 ZTE
33
Dialed calls, Received calls and Missed calls are saved in Call history.
If the records are full, the earliest saved records will be deleted.
Also, you can view call timers, and delete call logs.
How to configure Call settings
Go to Menu>Call center>Call settings.
You can set call waiting, call diverting and call barring and so on.
How to set your phone
You can adjust various settings of your phone. Go to Menu>Settings.
Phone settings: Set time and date and schedule power on/off, select
language, set pref. input methods, display, flight mode and LCD
backlight, etc.
Network settings: Set to automatically or manually select network,
and set the preferred networks.
Security settings: Set security features to protect you from unauthorized
User manual S217 ZTE
34
use of your phone and SIM card.
Connectivity: View and set data account.
Restore factory settings: Enter the phone lock code to restore to the
factory settings. Some personal information might be lost if you use
this function, so be careful.
Note: You may be required to input the phone lock code in some of the
security settings interfaces. The default lock code is 1122.
How to set your alarm
Go to Menu>Organizer>Alarm. You can view, and edit the alarm clock
settings. You can also enable or disable the alarms. By pressing Edit,
you can set the corresponding features of the alarm according to
instructions.
File manager
Go to Menu>File manager. You can check all the folders in the phone
User manual S217 ZTE
35
or memory card, create new ones or rename, delete the folders, etc.
Viewing image
Go to Menu>Multimedia>Image viewer.
You can select an image and view it.
How to play music
Go to Menu>Multimedia>Audio player. You can play the audio in your
phone or the memory card.
In List, you can refresh your playlist or make personal settings.
Warning:
User manual S217 ZTE
36
Warning label
How to use FM radio
Go to Menu>Multimedia>FM radio.
With the radio, you can search for radio channels, listen to them, and
save them on your device. Note that the quality of the radio broadcast
depends on the coverage of the radio station in that particular area. In
the FM radio interface, you can press the */# keys to adjust volume, press
the Left/Right keys to tune the frequency, and press the Center key to
User manual S217 ZTE
37
pause. Select Options to enter the submenu.
Using Services
Go to Menu> Services. Services is a Web Browser, you must insert the
SIM card if you want to use it.
Go to Menu>Services>Internet service, select Homepage to go into
your homepage.
Select Bookmarks to view the list of saved pages.
Select Recent pages to view the list of pages you recently visited.
Select Settings>Preferences. Select Timeout to set timeout. If the
timeout period elapsed prior to completion of the operation or the server
is not responding, your phone will show “Connection Failed”. During
the timeout period, it will keep trying to connect until expired. Select Show
pictures to set whether or not to show the images. Select whether or
not to enable Cache and Cookies.
User manual S217 ZTE
38
EC Declaration of Conformity
It is hereby declared that following designated product:
Product Type: GSM（GPRS）Digital Mobile Phone
Model No: ZTE-G S217
Complies with the essential protection requirements of the Radio and Telecommunication Terminal
Equipment Directive (EC Directive 1999/5/EC) and the Electromagnetic Compatibility
Directive(2004/108/EC).
This declaration applies to all specimens manufactured identical to the samples submitted for
testing/evaluation.
Assessment of compliance of the product with the requirements relating to the Radio and Telecommunication
Terminal Equipment Directive (EC Directive 1999/5/EC) was performed by American TCB(Notified Body
No.1588), based on the following standards:
Safety EN 60950-1:2006/A11:2009/
EMC
EN 301 489-1 V1.8.1;
EN 301 489-7 V1.3.1;
EN 55013:20011/A2:2006;
EN 55020:2007;
Radio EN 301 511 V9.0.2;
3GPP TS51.010-1 V9.4.0
User manual S217 ZTE
39
Health
EN 50360:2001; EN 62209-1:2006;
EN 62209-2:2010;
IEC 62209-2 Edition1.0(2010-03);
EN 50332-1:2000;
EN 50332-2:2003
This declaration is the responsibility of the manufacturer:
ZTE Corporation
ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park,
Nanshan District, Shenzhen, Guangdong, 518057, P.R.China
Authorised person signing for the company:
Xu feng Quality Director Of ZTE Corporation
Name in block letters & position in the company
Shenzhen, 15th Feb 2011
Place & date
