ZTE K4607-ZR HSPA+ USB MODEM User Manual

ZTE Corporation HSPA+ USB MODEM

User Manual

K4607-Zr
HSPA+USB MODEM
Quick Start Guide
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: +86-755-26779999
URL: http://www.ztedevice.com
E-mail: mobile@zte.com.cn
LEGAL INFORMATION
Copyright © 2015 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form
or by any means, electronic or mechanical, including photocopying and microfilm, without
the prior written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications
on print errors or update specifications without prior notice.
Version No. : R1.0
Confidential and Proprietary Information of ZTE CORPORATION 1
Getting to Know Your Modem
Your modem supports data and SMS services through the mobile phone network,
enabling you to communicate anytime and anywhere.
The following figure is only for your reference. The actual product may be different.
1. USB Connector
2. SIM/USIM card slot
3. microSDHC™ card slot
4. Front cover
5. Modem cap
NOTE:
microSDHC logo is a trademark of SD-3C, LLC.
Installing the (U)SIM Card and microSDHC Card
1. Press and push the front cover and remove it.
NOTE:
Do not open the front cover rudely so as to avoid the damage of the front cover.
2. Insert the (U)SIM card into the (U)SIM card slot.
WARNING!
Your modem does not support micro-SIM cards, nano-SIM cards or any other non-standard
SIM cards. To avoid damage to the modem, do not use those cards or any card holders.
2 Confidential and Proprietary Information of ZTE CORPORATION
3. Insert the microSDHC card into the microSDHC card slot.
NOTE:
This modem only supports microSDHC card.
4. Slide the front cover gently back into place.
Connecting the Modem to Your PC
Insert the modem into your computer’s USB port securely. The operating system
automatically detects and identifies your modem and starts the installation wizard.
Confidential and Proprietary Information of ZTE CORPORATION 3
Installing Software
On different operating systems, the installation procedures may be different. Follow the system
prompts during operation.
For Windows OS
Follow the system prompts to complete the software installation.
NOTE:
If the system does not launch installation automatically, you can run the installation program in
path of My Computer > ZTEMODEM.
For Mac OS
The system will automatically display a CD-ROM icon on the desktop when you connect the
modem to your computer correctly. Double click the installation software package in this
CD-ROM, and follow the system prompts to complete the software installation.
Using Your Modem
Various icons are presented to enable quick operation of the following functions.
Connect Connect to the Internet.
Menu Unfold or fold the main window of
your software.
Data Show the connection information.
SMS Send or read your SMS.
Contacts Manage contacts information.
Settings Set the USB modem.
4 Confidential and Proprietary Information of ZTE CORPORATION
Warning and Notice
To the Owner
Some electronic devices are susceptible to electromagnetic interference sent by
modem if inadequately shielded, such as the electronic system of vehicles. Please
consult the manufacturer of the device before using the modem if necessary.
Operating the modem may interfere with medical devices like hearing aids and
pacemakers. Please always keep them more than 20 centimeters away from such
medical devices when they are turned on. Turn the modem off if necessary. Consult a
physician or the manufacturer of the medical device before using the modem.
Be aware of the usage limitation when using a modem at places such as oil
warehouses or chemical factories, where there are explosive gases or explosive
products being processed. Turn off your modem if required.
• The use of electronic transmitting devices is forbidden in aircrafts, at petrol stations and
in hospitals. Please observe and obey all warning signs and switch off your modem in
these conditions.
Do not touch the inner antenna area if not necessary. Otherwise it will affect your
modem’s performance.
• Store the modem out of the reach of little children. The modem may cause injury if used
as a toy.
• Do not touch the metallic parts of the modem so as to avoid a burn, when the modem is
working.
Use Your USB Modem
Please use original accessories or accessories that are authorized. Using any
unauthorized accessories may affect your modem’s performance, and violate related
national regulations about telecom terminals.
Avoid using the modem near or inside metallic structures or establishments that can
emit electromagnetic waves. Otherwise it may influence signal reception.
• The modem is not waterproof. Please keep it dry and store in a shady and cool place.
Do not use the modem immediately after a sudden temperature change. In such case, it
will produce dew inside and outside the modem, so don’t use it until it becomes dry.
Confidential and Proprietary Information of ZTE CORPORATION 5
Handle the modem carefully. Do not drop, bend or strike it. Otherwise the modem will
be damaged.
No dismantling by non-professionals and only qualified technicians can undertake
repair work.
• Operating temperature range of -10 ~ +50 and humidity range of 5% ~ 95% are
recommended.
• The product shall only be connected to a USB interface of version USB2.0
• Data operation: When using a data feature, position the device a minimum of 0.5 cm from your
body for the whole duration of the data transmission.
Limited Warranty
This warranty does not apply to defects or errors in the Product caused by:
i. Reasonable abrasion.
ii. End User’s failure to follow ZTE’s installation, operation or maintenance instructions
or procedures.
iii. End User’s mishandling, misuse, negligence, or improper installation, disassembly,
storage, servicing or operation of the Product.
iv. Modifications or repairs not made by ZTE or a ZTE-certified individual.
v. Power failures, surges, fire, flood, accidents, actions of third parties or other events
outside ZTE’s reasonable control.
vi. Usage of third-party products, or usage in conjunction with third-party products
provided that such defects are due to the combined usage.
vii. Any other cause beyond the range of normal usage intended for the Product.
End User shall have no right to reject or return the Product, or receive a refund for the
Product from ZTE under the above-mentioned situations.
This warranty is End User’s sole remedy and ZTE’s sole liability for defective or
nonconforming items, and is in lieu of all other warranties, expressed, implied or
statutory, including but not limited to the implied warranties of merchantability and
fitness for a particular purpose, unless otherwise required under the mandatory
provisions of the law.
6 Confidential and Proprietary Information of ZTE CORPORATION
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or
consequential damages resulting from or arising out of or in connection with using of this
product, whether or not ZTE had been advised, knew or should have known of the
possibility of such damages, including, but not limited to lost profits, interruption of
business, cost of capital, cost of substitute facilities or product, or any downtime cost.
Regulatory Conformance Hereby, ZTE Corporation declares that this device
is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. CE0700
FCC Caution
§ 15.19 Labeling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
Confidential and Proprietary Information of ZTE CORPORATION 7
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help
Body support Operation
This device was tested for typical body support operations. To comply with RF exposure
requirements, a minimum separation distance of 0.5cm must be maintained between the
user’s body and the device, including the antenna. Third-party accessories used by this
device should not contain any metallic components. Accessories that do not meet these
requirements may not comply with RF exposure requirements and should be avoided.
Use only the supplied or an approved antenna.
Getting More Help
You can get help by:
• Sending an email to mobile@zte.com.cn
• Visiting http://www.ztedevice.com
• Calling Service Hotline: +86-755-26779999
