Users Manual
1
MF920V
Quick Start Guide
ZTE CORPORATION
NO. 55, Hi-tech Road South, Shenzhen, P.R.China
Postcode: 518057
2
Getting to Know Your Device
Appearance
The following figure is for your reference only.
1. *External antenna connectors (not all the devices support)
2. Charging/micro-USB jack
3. Indicator light
4. Power key
Press and hold for about 3 seconds to power on/off your
device.
Press and hold for about 10 seconds to restart your
device.
5. WPS key
Press and hold for 3 seconds to activate the WPS function.
6. micro-SIM card slot and reset hole
3
Getting to Know Your Device
Indicator lights
Indicator Status Description
Battery
Red solid /
blinking
The battery is low. Please
charge the battery.
Green
blinking
The battery is being
charged.
Green
solid
The battery level is middle
or high.
Light off Your device is not being
charged.
Wi-Fi
Blue solid Wi-Fi is active.
Blue
blinking
WPS is active.
Light off Wi-Fi is off.
SMS
Blue solid You have unread messages.
Blue
blinking
You have new messages.
Light off There is no unread
message or new message.
4
Network
Red Error status. Not registered
to the mobile network, no
micro-SIM card inserted or
no network service
available.
Green
solid
Registered to the 2G/3G
mobile network.
Green
blinking
Connected to the 2G/3G
mobile network and data is
being transferred.
Blue solid Registered to the 4G LTE
network.
Blue
blinking
Connected to the 4G LTE
network and data is being
transferred.
5
Getting to Know Your Device
Connection Scenarios
The device allows multiple clients to surf on the Internet at the
same time. The following figure is for your reference only.
A micro-SIM card can be used to access the Internet.
Installin
g
1. Open the mi
NOTE:
Do not remove
device.
2. Install a mic
r
WARNING
Your device do
other non-stan
device, do not
u
3. Close the
m
6
g
Your Devi
c
cro-SIM card cover.
the cover rudely, be
c
r
o-SIM card to the m
!
es not support SIM
c
dard micro-SIM car
d
u
se those cards or a
m
icro-SIM card cove
r
c
e
c
ause it is connecte
d
icro-SIM card slot.
c
ards, nano-SIM car
d
d
s. To avoid dama
g
ny card holders.
r
.
d
with the
d
s or any
g
e to the
Connec
t
Using Wi-
F
1. Power on y
o
2. Ensure tha
t
enabled Wi-
NOTE
: Re
further details
use a comput
e
address autom
3. Select the
Connect
.
4. Enter the W
i
NOTE
: Re
f
SSID and P
a
password.
5. Wait until t
successfully
Using a U
S
1. Connect a c
o
2. Power on
y
identifies n
e
software.
7
t
ing to Your
F
i
o
ur device.
t
your computer o
r
Fi, and search for a
v
fer to your Wi-Fi-en
a
on how to search f
o
e
r, you need to set y
o
atically.
Wi-Fi name (SSID
)
i
-Fi password if nec
e
f
er to the chapter
G
a
ssword
to get th
he client device is
.
S
B Cable
o
mputer to your dev
i
y
our device. The o
p
e
w hardware, and
Device
r
other client devic
v
ailable wireless net
w
a
bled client device m
a
o
r wireless networks
o
ur computer to obt
a
)
of your device,
a
e
ssary, and click OK.
G
etting to Know t
h
e default Wi-Fi S
S
connected to you
i
ce with a USB cabl
e
p
erating system det
e
automatically ins
t
es have
w
orks.
a
nual for
. If you
a
in an IP
a
nd click
h
e Wi-Fi
S
ID and
r device
e
.
e
cts and
t
alls the
NOTE:
If the system d
double-click t
h
install the soft
w
3. Wait until
successfully
Getting
t
Passwo
r
You can view
SSID and pas
s
Logging
Hotspot
1. Ensure that
client devic
e
2. Launch the
http:/
/
ufi.zt
e
3. Enter the
p
configuratio
n
NOTE: Th
e
8
oes not automaticall
y
h
e device installatio
n
w
are.
the computer is
.
t
o Know th
e
r
d
the label on the de
v
s
word.
in to t
h
Configurati
the connection be
e
is correct.
Internet browser an
d
e
device.com in the
a
p
assword to log in
n
page.
e
default password i
s
y
launch installation,
n
icon in My Com
c
onnected to you
r
e
Wi-Fi SSI
D
v
ice to get the defa
h
e 4G M
on Page
tween your device
d
enter http://192.1
6
a
ddress bar.
to the 4G Mobile
s
admin.
you can
puter to
r
device
D
and
ult Wi-Fi
obile
and the
6
8.0.1 or
Hotspot
9
Changing the Wi-Fi SSID or
Password
1. Log in to the 4G Mobile Hotspot configuration page.
2. Select Wi-Fi Settings.
3. Change the Network Name (SSID) or the Password in the
Main SSID area.
4. Click Apply.
Accessing the Internet
After a client device is successfully connected to your device,
you can access the Internet in Automatic or Manual mode. The
default mode is Automatic.
Mode Operation
Automatic Your device is automatically connected to the
Internet, and you can surf on the Internet
through the client.
Manual 1. Log in to the 4G Mobile Hotspot
configuration page.
2. In My router section, select LTE (or other
network type) Settings > Connection
Mode > Manual, and then click Apply.
10
3. Click to return to the home page,
and then click or .
NOTE:
• To change current connection setting, please disconnect
from network.
• To modify the parameters of your device, log in to the 4G
Mobile Hotspot configuration page.
Configuring Your PC
The following procedure describes how to configure the Internet
Protocol in Windows 7 for your Wi-Fi connection.
1. Right-click Network and select Properties.
2. Select Change adapter settings.
3. Right-click Wireless Network Connection and select
Properties.
4. Select Internet Protocol Version 4 (TCP/IPv4), and click
Properties.
5. Select Obtain an IP address automatically and Obtain
DNS server address automatically, and click OK.
11
Warning and Notice
To the Users
• If inadequately shielded, some electronic devices, for example, the
electronic system of vehicles, may be affected by the
electromagnetic interference caused by the device. Consult the
manufacturers of such devices before using the device if
necessary.
• Operating the device may interfere with medical instruments such
as hearing aids and pacemakers. Always keep the device more
than 20 centimeters away from such medical instruments when
your device is powered on. Power off the device if necessary.
Consult a physician or the manufacturers of medical instruments
before using the device if necessary.
• Be aware of the usage limitation when using the device at places
such as oil warehouses or chemical factories, where there are
explosive gases or explosive products being processed. Power off
the device if necessary.
• Do not use electronic transmission devices in aircrafts, at petrol
stations or in hospitals. Observe and obey all warning signs, and
power off the device in these conditions.
• Do not touch the inner antenna area unless necessary. Otherwise
the performance of the device may be affected.
• Do not use the device in an enclosed environment or where heat
dissipation is poor. Prolonged work in such space may cause
excessive heat and raise ambient temperature, which may lead to
automatic shutdown of the device for your safety. In the case of
such event, cool the device in a well-ventilated place before turning
on for normal use.
• Keep the device out of the reach of small children. The device may
cause an injury if used as a toy.
12
• When the device is operating, do not touch the metallic parts.
Failing to do so may cause burns.
• Use original accessories or accessories that are authorized. Using
any unauthorized accessories may affect the performance of the
device and violate the related national regulations about telecom
terminals.
• Avoid using the device near or inside metallic constructions or
establishments that can emit electromagnetic waves, because
signal reception may be affected.
• The device is not waterproof. Keep the device dry and store it in a
shady and cool place.
• Do not use the device immediately after a sudden temperature
change, because dew may be generated inside and outside the
device. Do not use it until it becomes dry.
• Handle the device carefully. Do not drop, bend or strike it.
Otherwise the device may be damaged.
• Only qualified personnel can dismantle and repair the device.
• An operating temperature between -10°C and +60°C and humidity
between 5% and 95% are recommended.
Using Battery
Do not change the built-in rechargeable battery in your device by
yourself. The battery can only be changed by ZTE or ZTE authorized
service provider.
Limited Warranty
This warranty does not apply to defects or errors in the product
caused by:
i. Reasonable abrasion.
ii. End users’ failure to follow ZTE’s installation, operation or
maintenance instructions or procedures.
13
iii. End users’ mishandling, misuse, negligence, or improper
installation, disassembly, storage, servicing or operation of the
product.
iv. Modifications or repairs not provided by ZTE or a ZTE-certified
individual.
v. Power failures, surges, fire, flood, accidents, and actions of third
parties or other events outside ZTE’s reasonable control.
vi. Usage of third-party products or usage in conjunction with
third-party products if such defects are due to the combined
usage.
vii. Any other cause beyond the range of normal usage intended for
the product.
End users have no right to reject or return the product, or receive a
refund for the product from ZTE under the above-mentioned
situations.
This warranty is end users’ sole remedy and ZTE’s sole liability for
defective or nonconforming items, and is in lieu of all other warranties,
expressed, implied or statutory, including but not limited to the implied
warranties of merchantability and fitness for a particular purpose,
unless otherwise required under the mandatory provisions of the law.
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special,
incidental or consequential damages resulting from or arising out of or
in connection with using of this product, no matter whether or not ZTE
had been advised, knew or should have known of the possibility of
such damages, including, but not limited to lost profits, interruption of
business, cost of capital, cost of substitute facilities or product, or any
downtime cost.
14
LEGAL INFORMATION
Copyright © 2016 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated
or utilized in any form or by any means, electronic or mechanical,
including photocopying and microfilm, without the prior written
permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to
make modifications on print errors or update specifications without
prior notice.
Version No.: R1.0
Edition Time: April 12, 2016
15
Troubleshooting
Problem Recommended Action
The
connection
between your
device and a
PC through a
USB cable
cannot be
established.
Install the software, and run the
installation program in the path of My
Computer.
If the driver of your device is
abnormal, reinstall the software. You
need to uninstall the software first.
The
connection
between your
device and a
client through
Wi-Fi cannot
be
established.
Ensure that the Wi-Fi function is
enabled.
Refresh the network list and select
the correct SSID.
Check the IP address, and ensure
that your client can automatically
obtain an IP address.
Enter the correct network key (Wi-Fi
password) when you connect the
client to your device.
Trouble
s
Problem
The clie
n
connected
t
the devi
c
cannot acce
s
the Internet.
The 4
G
Mobile
Hotspot
configuration
page cann
o
be visited.
Getting
M
You can get h
e
Sending
a
Visiting
w
Calling t
h
16
s
hooting
Recommend
e
n
t
t
o
c
e
s
s
Ensure th
available.
Change t
h
with good
Check th
connectio
n
Contact
y
confirm y
o
G
o
t
Enter th
e
default a
d
or http://u
f
Use only
your PC.
Do not us
e
M
ore Help
e
lp by:
a
n email to mobile
@
w
ww.ztedevice.com
h
e service hotline: +
8
e
d Action
at your micro-SIM
c
h
e location and find
a
signal.
e settings of the
n
mode.
y
our service provid
e
o
ur APN settings.
e
correct address
d
dress is http://192.1
f
i.ztedevice.com.
one network ada
p
e
any proxy server.
@
zte.com.cn
8
6-755-26779999
c
ard is
a
place
WAN
e
r and
. The
68.0.1
p
ter in
17
FCC RF Exposure Information (SAR)
This device is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the United States.
During SAR testing, this device was set to transmit at its highest
certified power level in all tested frequency bands, and placed in
positions that simulate RF exposure in usage near the body with the
separation of 10 mm. Although the SAR is determined at the highest
certified power level, the actual SAR level of the device while
operating can be well below the maximum value. This is because the
device is designed to operate at multiple power levels so as to use
only the power required to reach the network. In general, the closer
you are to a wireless base station antenna, the lower the power
output.
The exposure standard for wireless devices employing a unit of
measurement is known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6W/kg. This device is complied with
SAR for general population /uncontrolled exposure limits in
ANSI/IEEE C95.1-1992 and had been tested in accordance with the
measurement methods and procedures specified in IEEE1528.
The FCC has granted an Equipment Authorization for this model
device with all reported SAR levels evaluated as in compliance with
the FCC RF exposure guidelines.
For this device, the highest reported SAR value for usage near the
body is 1.441 W/kg.
While there may be differences between the SAR levels of various
positions, they all meet the government requirements.
SAR compliance for body-worn operation is based on a separation
18
distance of 10 mm between the unit and the human body. Carry this
device at least 10 mm away from your body to ensure RF exposure
level compliant or lower to the reported level. To support bodyworn
operation, choose the belt clips or holsters, which do not contain
metallic components, to maintain a separation of 10 mm between this
device and your body.
RF exposure compliance with any body-worn accessory, which
contains metal, was not tested and certified, and use such body-worn
accessory should be avoided.
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
19
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
CAUTION: Changes or modifications not expressly approved
by the party responsible for compliance could void the user’s authority
to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
