ZTE MOVISTARONDA GSM Dual-Band Digital Mobile Phone User Manual
ZTE Corporation GSM Dual-Band Digital Mobile Phone Users Manual
ZTE >
user manual
Movistar Onda
Mobile Phone
User Manual
LEGAL INFORMATION
Copyright © 2011 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in
any form or by any means, electronic or mechanical, including photocopying and
microfilm, without the prior written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make
modifications on print errors or update specifications without prior notice.
Version No. :
Edition Time :
Manual No. :
3
Table of Contents
SECURITY ........................................ 4
SAFETY PRECAUTIONS ................. 4
FCC COMPLIANCE ........................ 11
HEALTH AND SAFETY
INFORMATION ............................... 12
LIMITATION OF LIABILITY ........... 15
KEY FUNCTIONS ........................... 16
LOCKING AND UNLOCKING THE
KEYPAD .......................................... 18
INTERFACE ICONS ....................... 18
BATTERY ........................................ 18
INSERTING THE SIM CARD .......... 20
INSERTING THE MEMORY CARD 22
CHARGING THE BATTERY ........... 23
POWERING YOUR PHONE ON/OFF
........................................................ 24
TURN THE TORCH ON/OFF .......... 24
WRITING TEXT .............................. 24
HOW TO ADD PEOPLE TO THE
PHONEBOOK ................................ 25
HOW TO MAKE AND RECEIVE
CALLS ............................................ 26
HOW TO SEND MESSAGES ......... 26
HOW TO RECEIVE A MESSAGE .. 27
HOW TO SET PROFILES .............. 27
HOW TO VIEW CALL HISTORY .... 28
HOW TO CONFIGURE CALL
SETTINGS ...................................... 28
HOW TO SET YOUR PHONE ........ 28
ORGANIZER .................................. 29
FILE MANAGER ............................. 30
HOW TO PLAY MUSIC .................. 30
HOW TO USE SERVICES .............. 31
QUESTIONS & ANSWERS ............ 32
4
Security
To protect your mobile phone from illegal use, take the security measures
as follows:
Set PIN codes of the SIM card.
Set handset password.
Set call restrictions.
Safety Precautions
This section includes some important information on safe and efficient operation.
Please read this information before using the phone.
Operational Precautions
Please use your phone properly. When making or receiving a call,
please hold your phone as holding a wireline telephone. Make sure that
the phone is at least one inch (about two point five centimeters) from
your body when transmitting.
Do not touch the antenna when the phone is in use. Touching the antenna
area affects call quality and may cause the phone to operate at a higher
power level than needed.
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when watching television or playing
5
video games. If you have experienced seizures or blackouts, or if you
have a family history of such occurrences, please consult your doctor
before playing video games on your phone or enabling a flashing-light feature
on your phone. (The flashing-light feature is not available on all products.)
Keep the phone out of the reach of small children. The phone may cause
injury if used as a toy.
The device of temperature range is -10°C ~ +55°C
Precautions While Driving
Please pay attention to the traffic safety. Check the laws and regulations
on the use of your phone in the area where you drive. Always obey them.
Use hands-free function of the phone, if available.
Pull off the road and park before making or answering a call if conditions
require.
Precautions for Medical Devices and Facilities
When using your phone near pacemakers, please always keep the phone
more than eight inches (about twenty centimeters) from the pacemaker
when the phone is switched on. Do not carry the phone in the breast pocket.
Use the ear opposite the pacemaker to minimize the potential for
interference. Switch off the phone immediately if necessary.
Some phones may interfere with some hearing aids. In the event of
6
such interference, you may consult your hearing aids manufacturer to
discuss alternatives.
If you use any other personal medical device, please consult the
manufacturer of your device to determine if it is adequately shielded from
RF(radio frequency) energy.
In those facilities with special demand, such as hospital or health care
facilities, please pay attention to the restriction on the use of mobile phone.
Switch off your phone if required.
Mobile Phone
Please use original accessories or accessories approved by the
phone manufacturer. Using any unauthorized accessories may affect
your mobile phone’s performance, damage your phone or even cause
danger to your body and violate related local regulations about telecom
terminals.
Turn off your phone before you clean it. Use a damp or anti-static cloth
to clean the phone. Do not use a dry cloth or electrostatically charged
cloth. Do not use chemical or abrasive cleaners as these could damage
the phone.
As your mobile phone can produce electromagnetic field, do not place it
near magnetic items such as computer disks.
Using the phone near electrical appliances such as TV, telephone, radio
7
and personal computer can cause interference.
Do not expose your mobile phone to direct sunlight or store it in hot areas.
High temperatures can shorten the life of electronic devices.
Keep your phone dry. Any liquid may damage your phone.
Do not drop, knock or harshly treat the phone. Rough handling can
break internal circuit boards.
Do not connect the phone with any incompatible enhancement.
Do not attempt to disassemble the mobile phone or battery.
Do not store the phone with flammable or explosive articles.
Do not charge the mobile phone without battery.
Precautions for Potentially Explosive Atmospheres
Switch off your phone prior to entering any area with potentially
explosive atmospheres, such as fueling areas, fuel or chemical transfer or
storage facilities.
Do not remove, install, or charge batteries in such areas. Spark in a
potentially explosive atmosphere can cause an explosion or fire resulting in
bodily injury or even death.
To avoid possible interference with blasting operations, switch off your
phone when you are near electrical blasting caps, in a blasting area, or
in areas posted “Turn off electronic devices.” Obey all signs and
8
instructions.
Precautions for Electronic Devices
Some electronic devices are susceptible to electromagnetic interference
sent by mobile phone if inadequately shielded, such as electronic system of
vehicles. Please consult the manufacturer of the device before using the phone
if necessary.
Safety and General Use in Vehicles
Safety airbag, brake, speed control system and oil eject system shouldn’t
be affected by wireless transmission. If you do meet problems above,
please contact your automobile provider. Do not place your phone in the
area over an airbag or in the airbag deployment area. Airbags inflate with
great force. If a phone is placed in the airbag deployment area and the
airbag inflates, the phone may be propelled with great force and cause
serious injury to occupants of the vehicle.
Please turn off your mobile phone at a refueling point, and the same to
the place where the use of two-way radio is prohibited.
Aircraft Safety
Please turn off your mobile phone before the airplane takes off. In order
to protect airplane’s communication system from interference, it is
9
forbidden to use mobile phone in flight. Safety regulations require you to
have permission from a crew member to use your phone while the plane is
on the ground.
If the mobile phone has the function of automatic timing power-on,
please check your alarm setting to make sure that your phone will not be
automatically turned on during flight.
10
Battery Use
Do not short-circuit the battery, as this can cause the unit to overheat or
ignite.
Do not store battery in hot areas or throw it into fire. Otherwise, it will
cause explosion.
Do not disassemble or refit the battery. Otherwise, it will cause liquid
leakage, overheating, explosion and ignition of the battery.
Please store the battery in a cool dry place if you don’t use it for a long
period.
The battery can be recharged for hundreds of times, but it will eventually
wear out. When the operating time (talk time and standby time) is noticeably
shorter than normal, it is time to replace it with a new one.
Please stop using the charger and battery when they are damaged or
show evidence of aging.
Return the worn-out battery to the provider or dispose of it in accordance
with environment regulations. Do not dispose of it in household rubbish.
Please use original batteries or batteries approved by the phone
manufacturer. Using any unauthorized battery may affect your handset
performance or may cause danger of explosion, etc.
Warning: If the battery is damaged, do not discharge it. If the leakage does come
into contact with the eyes or skin, wash thoroughly in clean water and consult a
11
doctor.
FCC Compliance
This mobile phone complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This mobile phone has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiated radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
12
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Health and safety information
Radio Frequency (RF) Energy
This model phone meets the government’s requirements for exposure to radio
waves.
This phone is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government:
The exposure standard for wireless mobile phones employs a unit of
13
measurement known as the Specific Absorption Rate, or SAR. The SAR limit
set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard
operating positions accepted by the FCC with the phone transmitting at its
highest certified power level in all tested frequency bands. Although the SAR
is determined at the highest certified power level, the actual SAR level of the
phone while operating can be well below the maximum value. This is because
the phone is designed to operate at multiple power levels so as to use only the
poser required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output.
The highest SAR value for the model phone as reported to the FCC when tested
for use at the ear is 1.24W/kg and when worn on the body, as described in
this user guide, is 0.766 W/kg (Body-worn measurements differ among phone
models, depending upon available enhancements and FCC requirements.)
While there may be differences between the SAR levels of various phones and at
various positions, they all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone with all
reported SAR levels evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone is on file with the FCC and
can be found under the Display Grant section of http://www.fcc.gov/oet/fccid
after searching on
FCC ID: Q78-MOVISTARONDA
For body worn operation, this phone has been tested and meets the FCC RF
14
exposure guidelines for use with an accessory that contains no metal and the
positions the handset a minimum of 1.5 cm from the body. Use of other
enhancements may not ensure compliance with FCC RF exposure guidelines.
If you do not use a body-worn accessory and are not holding the phone at the
ear, position the handset a minimum of 1.5 cm from your body when the phone
is switched on.
15
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or
consequential damages resulting from or arising out of or in connection with
using this product, whether or not ZTE had been advised, knew or should have
known the possibility of such damages. The user should refer to the enclosed
warranty card for full warranty and service information.
Note: The pictures and icons shown in the manual are just schematic drawings
for function demonstration. If they are inconsistent with your handset, please take
your handset as the standard. If the inconsistency exits in the manual because of
the handset function updating, please refer to the follow-up public information
from ZTE CORPORATION.
16
Key Functions
End/Power key
Left/Right soft key
Send key
4-Way Navigation
keys and Center key
* key # key
Earpiece
A
lpha numeric keys
Charger /headset interface
Torch
17
Function Description
Left soft key Performs the function indicated at the left bottom of the screen.
Right soft key Performs the function indicated at the right bottom of the screen.
Center key Press to confirm actions and make selections.
4-Way
Navigation keys
These keys (UP, DOWN, LEFT and RIGHT) allow for navigation
through menu options and quick accessing to some function
menus.
Send key Press to dial a phone number or answer a call, or view the call
history in the standby mode.
End/Power key Press to exit to the standby mode.
Hold to switch on/off the phone.
* key and # key They have different functions in different modes or function
menus.
Alpha numeric keys Press to enter digits 0-9 and the alphabets from a-z or A-Z.
Note: In this User Manual, “press a key” means to press the key and release it
immediately, while “hold a key” means to press the key for at least two seconds and
then release it.
18
Locking and Unlocking the Keypad
In the standby mode, press the Left soft key and then press the * key within two
seconds to lock the keypad. The unlock method is the same.
Locking the keypad can prevent unintentional operations on it. You can answer
an incoming call with the regular operation when the keypad is locked.
Interface Icons
Signal strength New SMS
Silent New MMS
Keypad locked Call diverting
Battery status General
Alarm clock set Headset
Missed call
Battery
The lithium ion battery of the mobile phone can be immediately used after unpacking.
19
Installing the battery
1. Pull the battery cover from the notch on the top edge and remove the cover.
2. Insert the battery by aligning the gold-coloured contacts with the contacts in
the battery slot.
3. Push down the upper section of the battery until it clicks into place.
4. Fix the battery cover till you hear the click sound.
Remove the battery cover Push down the battery
Fix the battery cover till you hear the click sound
20
Removing the battery
1. Make sure that your mobile phone is switched off.
2. Remove the battery cover.
3. Pull the battery up and remove it from the mobile phone.
Remove the battery cover Pull up the battery from here
Inserting the SIM Card
Insert the SIM card as follows:
1. Make sure that the phone is switched off and the charger is disconnected
from the phone.
2. Turn the phone over and remove the battery cover.
3. Remove the battery if it is already installed.
4. Hold your SIM card with the cut corner oriented as shown and then slide it
21
into the card holder with the gold-coloured contacts facing downwards.
5. Install your battery.
6. Fix the battery cover till you hear the click sound.
Insert the SIM card
SIM (Subscriber Identity Module) card is a micro chip from a network provider
that keeps the carrier details and customers information such as names and
phone numbers. Your phone won’t work without it. If you already have contacts
on your SIM card, they can be transferred in most cases.
22
Inserting the Memory Card
You can use a memory card to expand the storage of the phone. You can
store or copy files such as music and so on.
Do not take out the card or switch off the phone while transmitting or storing data,
which may cause data loss or damage to the phone or the card.
Insert the memory card as follows:
The memory card slot is beside the SIM card holder. You can insert the memory
card as shown in the diagram below. Open the battery cover. Insert the card with
the metal contacts facing downwards until it clicks to the right position.
Insert the Memory card
23
Charging the Battery
Your phone is powered by a rechargeable battery. For maximum battery performance,
it is recommended that you first use up the battery power and then charge it
completely. A new battery’s full performance is achieved only after three complete
charge and discharge cycles.
1. Connect your travel adapter to the right side of your mobile phone as
shown in the diagram.
2. Connect the other end of the travel adapter to the mains socket.
3. When you charge the battery, the battery charging indicator appears.
4. When the battery is fully charged, disconnect the charger.
24
Powering your Phone On/Off
Make sure that your SIM card is in your mobile phone and that the battery is
charged.
Hold the End/Power key to power on/off the phone. The phone will
automatically search for the network.
Turn the Torch On/Off
In the standby mode, hold the 0 key to turn on or off the torch. The torch is at
the bottom of the phone.
Writing Text
Change input mode: Press the # key to change the input mode
(input modes: ABC, abc,123).
Input letters: In ABC/abc mode, constantly press the corresponding
letter key till the letter appears.
Input digits: In 123 mode, press digit key once to input a digit. In
ABC/abc mode, constantly press the digit key until the number appears.
Input symbol: Press the * key to enter the symbol mode, select the
required symbol (common symbols) by pressing the Navigation keys and then
press the Left soft key or Center key to confirm it. In ABC/abc mode,
constantly press the 1 key until the required symbol (common symbols)
25
appears.
Input space: Press the 0 key to input space. It does not work in 123
mode.
Delete character: Press the Right soft key to clear a character. Hold
the Right soft key to delete all characters and clear the display.
Move cursor to left or right: Among the text, press the Left/Right
navigation keys to move the cursor to left or right.
How to Add People to the Phonebook
There are some numbers that you may want to call again and again, so it makes
sense to add these numbers to your Phonebook. You can then access these
numbers quickly and easily.
Go to Menu→Phonebook→Preferred storage to set the storage position.
Go to Menu→Phonebook→Add new contact.
Edit the information and save it.
You can also save a number right after you’ve made or received a
phone call or a message from someone who is not yet in your Phonebook list.
To delete someone from your Phonebook list, go to
Phonebook→Contacts, first select the name, then select Options→Delete.
26
How to Make and Receive Calls
The most basic way to make a call is to input the number in the standby mode
and press the Send key. You can also make a call from the Contact list.
To call someone: Go to Menu→Phonebook→Contacts. Use the
Up/Down Navigation keys to find the name of the person you want to call. You
can also type in the first letter of the name of the person you want to call to find
the right name, and press the Send key.
To receive a call, press the Left soft key or the Send key.
To end a call, press the End/Power key.
To reject a call, press the End/Power key.
Make sure that you are in an area with sufficient coverage to make calls. The
strength of the network signal is indicated on the Status Bar of the screen.
How to Send Messages
You can use your mobile phone to send and receive messages.
1. Go to Menu→Messages→Write message.
2. Write your message. For more information on input method, see section
‘Writing Text’. When you write an SMS, press Options→Send, and edit the
recipient.
3. When you finish writing an SMS, select Options to send the message.
27
How to Receive a Message
Upon receiving a message, the mobile phone will alert you with a ringtone, prompt,
or a new message icon. Message full when the message icon blinking.
1. Press Read to open the new message. You can also go to Inbox to read the
message.
2. Use the Up/Down Navigation keys to view the message.
3. While the message is open, use Options to reply, delete, or forward the
message. You can go to Use number to save the sender’s number.
You can also receive broadcast messages by using this mobile phone.
Go to Menu→Messages→Voice mail,you can call the voicemail or edit the
voicemail.
How to Set Profiles
Go to Menu→Settings→Profiles. You can select Options→Activate to
activate a profile. Or you can select Options→Customize to edit a profile.
Note: The Silent mode can be only set Activate or not. And the Headset mode
can only be activated with the headset connected.
28
How to View Call history
Go to Menu→Call logs.
Dialed calls, Received calls and Missed calls are saved in Call logs. If the
records are full, the earliest saved records will be deleted automatically.
Also, you can view call timers, call cost in Call logs.(Call cost need network
support.)
How to Configure Call Settings
Go to Menu→Settings→Call settings.
You can set call waiting, call divert and call barring and so on.
How to Set Your Phone
You can adjust various settings of your phone. Go to Menu→Settings.
Phone settings: Set time and date and schedule power on/off, select
language, set writing language, display, greeting text and LCD backlight, etc.
Network settings: Set to automatically or manually select network. Set
29
preferred networks.
Security settings: Set security features to protect your phone and SIM
card from unauthorized use.
Connectivity: View connection activities and set data account.
Restore factory settings: Enter the phone password to restore to the
factory settings. Some personal information might be lost if you use this function,
so be careful.
Note: You may be required to input the phone password in some of the security
setting interfaces. The default password is 1122. Go to Security settings→Phone
security→Change password to change the phone password.
Organizer
Go to Menu→Organizer.
Calendar
Enter Calendar, the calendar of the current month will be displayed on the screen
and the current date will be marked by a background box in a special colour. In the
Calendar interface.
Tasks
Select Add to add tasks.
Alarm
30
You can view, and edit the alarm clock settings. You can also enable or disable
the alarms. By pressing Edit, you can set the corresponding features of the
alarm according to instructions.
World clock
You can view the time in different cities.
Calculator
You can perform simple calculations. Press digit key to enter the number. Press
Navigation keys to select the operational character. Press OK or Center key to
get the result. Press Clear to delete the number.
Note: This calculator has limited accuracy and rounding errors may occur
especially in long division.
Stopwatch
Use it to record the time.
File manager
Go to Menu→File manager. You can check all the folders in the phone or memory
card, create new ones or rename, delete, or sort, etc. The files you download from
the internet will be stored in these folders.
How to Play Music
Go to Menu→Fun&Games→Audio player. You can play the audio in your
31
memory card.
In List→Options, you can refresh your list and make personal settings.
Audio player supports: AMR-NB, WAV, MP3, iMelody, MIDI.
Go to Menu→Fun&Games→Games to play games.
In Games,you can choose your favorite game to play. In Games→Game
settings, you can set the games.
How to Use Services
Go to Menu→Services. Services allows you to view internet content. In
Services you can use the STK and WAP.
STK
SIM card Toolkit (STK) services are value-added services provided by your
network provider.
Your mobile phone supports STK service, but if your SIM card and network
provider do not support the service, these functions can’t be used.
32
Questions & Answers
If you encounter problems while using the phone, or if it performs abnormally,
you can refer to the chart below. If your particular problem cannot be resolved
using the information in the chart, contact the dealer where you purchased the
phone.
Problem Possible causes Possible solution
Poor reception The network signal is
too weak at your current
location, for example, in
a basement or near a
tall building, because
wireless transmissions
Move to a location
where the network
signal can be properly
received.
33
Problem Possible causes Possible solution
can not effectively reach
it.
The network is busy at
the current time (for
example, during peak
times, there may be too
much network traffic to
handle additional calls).
Avoid using the phone
at such times, or try
again after waiting a
short time.
You are too far away
from a base station for
your service provider.
You can request a
service area map from
your service provider.
Echo or noise Poor network trunk
quality on the part of
your service provider.
Press End key and dial
again. You may be
switched to a better-
quality network trunk or
phone line.
Poor local telephone line
quality.
Press End key and dial
again. You may be
switched to a better-
quality network trunk or
phone line.
34
Problem Possible causes Possible solution
Unable to select certain
features
Your service provider
does not support these
features, or you have not
applied for services that
provide these features.
Contact your service
provider.
Battery not charge The battery or battery
charger is damaged.
Contact the dealer.
The phone’s
temperature is below
0°C or higher than 45 °C.
Adjust the battery
charging environment to
avoid extremes of
temperature.
Poor contact between
the battery and charger.
Check all connectors to
make sure all
connections have been
properly made.
Shortened standby time The standby time is
related to your service
provider system
configuration. The same
phone used with different
service providers’
If you are located in an
area where signaling is
weak, temporarily power
off the phone.
35
Problem Possible causes Possible solution
systems will not provide
exactly the same length
of standby time.
The battery is depleted.
In high-temperature
environments, battery
life will be shortened.
Use a new battery.
If you are not able to
connect to the network,
the phone will continue
to send out signals as it
attempts to locate a
base station. Doing so
consumes battery power
and will consequently
shorten standby time.
Change your location to
one where the network
is accessible, or
temporarily turn off your
phone.
Cannot switch your
phone on
Battery power has been
depleted.
Recharge the phone’s
battery.
USIM card error USIM card malfunction
or damage.
Take the USIM card to
your service provider for
36
Problem Possible causes Possible solution
testing.
USIM card inserted
improperly.
Insert the USIM card
properly.
Debris on the USIM card
contacts.
Use a soft, dry cloth to
clean the USIM card
contacts.
Unable to connect to the
network
USIM card invalid. Contact your service
provider.
You are not within the
network’s service area.
Check the service area
with your service
provider.
Poor signal. Move to an open space,
or if you are inside a
building, move closer to
a window.
Cannot answer
incoming calls
You have activated the
Call barring feature.
Go to Settings > Call
settings > Call barring,
and then select Cancel
all.
37
Problem Possible causes Possible solution
You cannot make
outgoing calls.
You have activated the
Call barring feature.
Go to Settings > Call
settings > Call barring,
and then select Cancel
all.
You have activated the
Fixed dial feature.
Go to Settings >
Security settings > SIM
security > Fixed dial >
Mode and select Off.
PIN Code blocked You have entered an
incorrect PIN code three
consecutive times.
Contact your service
provider. If the service
provider provides the
USIM card’s PUK code,
use the PUK code to
unlock the USIM card.
Unable to enter
information into the
Phonebook
The Phonebook’s
memory is already full.
Delete unnecessary
data from the contacts.
