User Manual
ZTE N285
Mobile Phone
User Manual
LEGAL INFORMATION
Copyright © 2011 by ZTE CORPORATION
All Rights Reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in
any form or by any means, electronic or mechanical, including photocopying and
microfilm, without the prior written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make
modifications on print errors or update specifications without prior notice.
Version No. : R1.0
Edition Time : 20110518
Manual No. : 079584503176
3
Table of Contents
SECURITY ..................................................4
SAFETY PRECAUTIONS ...........................4
LIMITATION OF LIABILITY ..................... 15
YOUR PHONE ......................................... 16
TURNING ON / OFF OR WAKING UP
YOUR PHONE ......................................... 17
LOCKING / UNLOCKING THE KEYPAD 17
USING THE TOUCHSCREEN ................. 18
STATUS BAR ICONS .............................. 18
ADJUSTING THE VOLUME .................... 19
BATTERY ................................................. 19
INSERTING THE SIM CARD................... 22
INSERTING THE MICROSD CARD ...... 24
WRITING TEXT ........................................ 24
PHONEBOOK .......................................... 26
MAKING AND RECEIVING CALLS ........ 27
CALL CENTER ........................................ 28
SENDING AND RECEIVING MESSAGES
.................................................................. 30
USER PROFILES .................................... 32
SETTINGS ................................................ 33
CONNECTIVITY ....................................... 35
ORGANIZER ............................................ 37
FILE MANAGER ...................................... 38
FUN&GAMES........................................... 38
CAMERA .................................................. 39
VIDEO RECORDER ................................. 39
MULTIMEDIA ........................................... 40
SERVICES ................................................ 42
4
Security
To protect your mobile phone from illegal usage, take the following security
measures:
Set the PIN codes of the SIM card.
Set the phone lock code.
Set call restrictions.
Safety Precautions
This section includes some important information on safe and efficient operation.
Please read this information before using the phone.
Operational Precautions
Please use your phone properly. When making or receiving a call, please
hold your phone as when holding a standard wireline telephone. Make
sure that the phone is at least one inch (about two point five centimeters)
from your body when transmitting.
Do not touch the antenna when the phone is in use. Touching the antenna
area affects call quality and may cause the phone to operate at a higher
power level than needed.
Some people may be susceptible to epileptic seizures or blackouts
when exposed to flashing lights, such as when watching television or
5
playing video games. If you have experienced seizures or blackouts, or if
you have a family history of such occurrences, please consult your doctor
before playing video games on your phone or enabling a flashing-light
feature on your phone. (The flashing-light feature is not available on all
products.)
Keep the phone out of reach of small children. The phone may cause injury
if used as a toy.
Precautions While Driving
Please pay attention to traffic safety. Check the laws and regulations on the
use of your phone in the area where you drive. Always obey them.
Use the hands-free function of the phone, if available.
Pull off the road and park before making or answering a call if required.
Precautions for Medical Devices and Facilities
When using your phone near pacemakers, please always keep the phone
more than eight inches (about twenty centimeters) from the pacemaker
when the phone is switched on. Do not carry the phone in the breast
pocket. Use the ear opposite the pacemaker to minimize the potential for
interference. Switch off the phone immediately if necessary.
Some phones may interfere with some hearing aids. In the event of such
interference, you may consult your hearing-aid manufacturer to discuss
6
alternatives.
If you use any other personal medical device, please consult the
manufacturer of your device to determine if it is adequately shielded from
RF(radio frequency) energy.
In areas with special requirements, such as hospitals or health care
facilities, please pay attention to the restrictions on the use of your mobile
phone. Switch off your phone if required.
Mobile Phone
Please use original accessories or accessories approved by the
phone manufacturer. Using any unauthorized accessories may affect
your mobile phone’s performance, damage your phone or even cause injury
and may violate related local regulations for telecom terminals.
Turn off your phone before you clean it. Use a damp or anti-static cloth
to clean the phone. Do not use a dry cloth or electrostatically charged cloth.
Do not use chemical or abrasive cleaners as these could damage the
phone.
As your mobile phone can produce an electromagnetic field, do not place
it near magnetic items such as computer disks.
Using the phone near electrical appliances such as TVs, telephones, radios
and personal computers can cause interference.
Do not expose your mobile phone to direct sunlight or store in hot places.
7
High temperatures can shorten the life of electronic devices.
Keep your phone dry. Any liquid may damage your phone.
Do not drop, knock or harshly treat the phone. Rough handling can damage
internal circuit boards.
Do not connect the phone with any incompatible accessory or
enhancement.
Do not attempt to disassemble the mobile phone or battery.
Do not store the phone with flammable or explosive articles.
Do not charge the mobile phone without the battery.
Some electronic devices are susceptible to electromagnetic interference
sent by phone if inadequately shielded. Please use phone at least 20 cm or
as far away as you can from TV set, radio and other automated office
equipment so as to avoid electromagnetic interference.
Operating phone may interfere with medical devices like hearing aides and
pacemakers, or other medical devices in hospital. Consult a physician or
the manufacturer of the medical device before using phone.
Be aware of the usage limitation when using phone at places such as oil
warehouses, or chemical factories, where there are explosive gases or
explosive products being processed, because even if your phone is in idle
state, it still transmits radio frequency (RF) energy. Therefore, power off
your phone if required.
8
Do not touch the antenna while calling. Otherwise it will affect the quality of
calling and waste battery energy. The damaged antenna will cause slight
burn while touching your skin.
Keep phone out of the reach of small children. Phone may cause injury if
used as a toy.
Do not put other things on the terminal to avoid overlaying radiator.
Keep the antenna free from obstructions and position the antenna straight
up. This will ensure best call quality.
Precautions for Potentially Explosive Atmospheres
Switch off your phone prior to entering any area with potentially
explosive environments, such as fueling areas, fuel or chemical transfer
or storage facilities.
Do not remove, install, or charge batteries in such areas. Sparks in
potentially explosive environments can cause explosions or fire, resulting in
bodily injury or even death.
To avoid possible interference with blasting operations, switch off your
phone when you are near electrical blasting caps, in a blasting area, or in
areas posted “Turn off electronic devices”. Obey all signs and instructions.
9
Precautions for Electronic Devices
Some electronic devices are susceptible to electromagnetic interference
sent by the mobile phone if inadequately shielded, such as the electronic
systems of vehicles. Please consult the manufacturer of the device before
using the phone if necessary.
Safety and General Use in Vehicles
Safety airbags, brakes, speed control systems and oil eject systems should
not be affected by wireless transmissions. If you do meet any of the above
problems, please contact your automobile provider. Do not place your
phone in the area over an airbag or in the airbag deployment area. Airbags
inflate with great force. If a phone is placed in the airbag deployment area
and the airbag inflates, the phone may be propelled with great force and
cause serious injury to occupants of the vehicle.
Please turn off your mobile phone at a refueling point, and in the locations
where the use of two-way radio is also prohibited.
Aircraft Safety
Please turn off your mobile phone before take off. In order to protect the
aeroplane’s communication system from interference, it is forbidden to
use mobile phones in flight. Safety regulations require you to have
permission from a crew member to use your phone while the plane is on
the ground.
10
If the mobile phone has the automatic timing power-on feature, please
check your alarm setting to make sure that your phone will not be
automatically turned on during the flight.
Battery Use
Do not short-circuit the battery, as this can cause the unit to overheat or
ignite.
Do not store the battery in hot areas or throw it into a fire. Otherwise, it may
cause an explosion.
Do not disassemble or refit the battery. Otherwise, it may cause liquid
leakage, overheating, explosions and ignition of the battery.
Please store the battery in a cool dry place if you do not use it for a long
period.
The battery can be recharged many times, but it will eventually wear out.
When the operating time (talk time and standby time) is noticeably shorter
than normal, it is time to replace it with a new one.
Please stop using the charger and battery when they are damaged or show
evidence of ageing.
Return the worn-out battery to the provider or dispose of it in accordance
with local environmental regulations. Do not dispose of it in household
rubbish.
Please use original batteries or batteries approved by the phone
11
manufacturer. Using unauthorized batteries may affect your handset
performance or may cause danger of explosion, etc.
Warning: If the battery is damaged, do not discharge it. If leakage does come
into contact with eyes or skin, wash the affected areas thoroughly in clean water
and consult a doctor.
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Caution: Changes or modifications not expressly approved by the manufacturer
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
12
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
Health and safety information
Radio Frequency (RF) Energy
This model phone meets the government’s requirements for exposure to radio
waves.
This phone is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government:
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR limit set
by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating
positions accepted by the FCC with the phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is determined at
the highest certified power level, the actual SAR level of the phone while
13
operating can be well below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only the poser required
to reach the network. In general, the closer you are to a wireless base station
antenna, the lower the power output.
The highest SAR value for the model phone as reported to the FCC when tested
for use at the ear is 1.450W/kg and when worn on the body, as described in this
user guide, is0.960W/kg (Body-worn measurements differ among phone models,
depending upon available enhancements and FCC requirements.)
While there may be differences between the SAR levels of various phones and at
various positions, they all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone with all
reported SAR levels evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone is on file with the FCC and
can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after
searching on
FCC ID: Q78-N285
For body worn operation, this phone has been tested and meets the FCC RF
exposure guidelines for use with an accessory that contains no metal and the
positions the handset a minimum of 1.5 cm from the body. Use of other
enhancements may not ensure compliance with FCC RF exposure guidelines.
If you do no t use a body-worn accessory and are not holding the phone at the
ear, position the handset a minimum of 1.5 cm from your body when the phone is
14
switched on.
15
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or
consequential damages resulting from or arising out of or in connection with using
this product, whether or not ZTE had been advised, knew or should have
known the possibility of such damages. The user should refer to the enclosed
warranty card for full warranty and service information.
Note: The pictures and icons shown in the manual are just schematic drawings
for demonstration of functions. If they are inconsistent with your handset, please
take your handset as the standard. If the inconsistency exits in the manual
because the handset function has been updated, please refer to the follow-up
public information from ZTE.
16
Your phone
End key
Send key
Touch screen
Status bar
Receiver
Power key
Volume keys
USB /charger
connector
Headset jack
17
Turning On / Off or waking up your phone
Hold the Power key to turn your phone on or off.
In Settings→Phone settings→LCD Backlight, set the LCD backlight brightness and
time. If the phone is not operated within this time, the screen will turn black.
Press the Power key, Volume keys to wake up your phone.
Locking / unlocking the keypad
In Settings→Security settings→Auto keypad lock, set the auto keypad lock
time. If the phone is not operated within this time in the standby mode, the keypad
will be locked. You can press the Power key to lock the keypad directly in the
standby mode.You can also press End key in the standby mode, then select Yes
to lock the keypad.
To unlock the keypad, drag the key icon in the bottom left corner from left to right
until the key icon get to the lock icon.
Note: In this User Manual, “press a key” means to press the key and release it
immediately, while “hold a key” means to press the key for at least two
seconds and then release it. Locking the keypad can prevent unintentional
operations on it. You can answer an incoming call with the regular operation
when the keypad is locked.
18
Using the touchscreen
Your phone supports touch screen functionality.
Tap any application to open it.
Drag up or down to scroll.
Status bar icons
Indicator
What it means
Indicator
What it means
Signal strength
New SMS, blinking when
message box is full
GPRS
New MMS
Roaming
Missed call
Bluetooth
Call forward
General
Alarm clock set
Outdoor
Keypad unlocked
Meeting
Battery status
19
Adjusting the volume
When you’re on the phone or listening to songs, watching movies, or using
other media, you can use the Volume keys on the right side of your phone to
adjust the audio volume. Otherwise, the keys control the volume for the ringer,
and other sound effects.
Battery
The lithium ion battery of the mobile phone can be immediately used after unpacking.
Installing the Battery
1. Pull the battery cover from the notch on the bottom and remove the cover.
2. Insert the battery by aligning the gold-coloured contacts with the contacts in
the battery slot.
3. Push down the upper section of the battery until it clicks into place.
4. Replace the battery cover and close it gently until you hear a click.
20
Remove the battery cover Push down the battery
Replace the battery cover
21
Removing the Battery
1. Make sure that your mobile phone is switched off.
2. Remove the battery cover.
3. Pull the battery up and remove it from the mobile phone.
Remove the battery cover Pull up the battery
Charging the Battery
Your phone is powered by a rechargeable battery. For maximum battery
performance, it is recommended that you first use up the battery power and then
charge it completely. A new battery’s full performance is achieved only after three
complete charge and discharge cycles.
1. Connect your travel adapter to the left side of your mobile phone as shown in
the diagram.
22
2. Connect the other end of the travel adapter to the mains socket.
3. When you charge the battery, the battery charging indicator appears.
4. When the battery is fully charged, disconnect the charger.
Inserting the SIM Card
You want a mobile phone that is sophisticated yet easy to use and here it is in
your hands! Naturally you are eager to start using it, but first you need to insert
the SIM card.
Insert the SIM card as follows:
Make sure that the phone is switched off and the charger is disconnected from
the phone.
Turn the phone over and remove the battery cover.
23
Remove the battery if it is already installed.
Hold your SIM card with the cut corner oriented as shown and then slide it into
the card holder. You can follow the diagrams below.
Replace the battery first.
Replace the battery cover.
Every mobile phone has a SIM card (Subscriber Identity Module). This is a
micro-chip that holds your personal information such as names and phone numbers.
Your phone won’t work without it. If you already have contacts on your SIM card,
they can be transferred in most cases.
24
Inserting the microSD card
You can use a microSD card to expand the storage of the phone. You can store
or copy files such as videos, photos, music, and so on.
Do not take out the card or switch off the phone while transmitting or storing data,
which may cause data loss or damage to the phone or the card.
microSD Logo is a trademark.
You can follow the diagram below to insert the microSD card.
Note: microSD is a trademark of SD Card Association.
Writing text
25
Your phone provides two sets of on-screen keyboards. Tap a text field, such as in
a note or new contact, to bring up the keyboard.
Using the Full Keyboard
Notes:
You cannot use predictive word input with the full keyboard.
Tap to select input method.
Tap to change to Condensed Keyboard.
Tap to select symbols and digits.
Tap to delete text.
Tap to change to capital letter mode.
Tap to input space.
Tap to start a new paragraph.
Using the Condensed Keyboard
You can enter letters, words, numbers, symbols and emoticons with the
condensed keyboard.
Tap to select input method.
26
Tap to change to Full Keyboard.
Tap to select symbols.
Tap to delete text.
Tap to change to capital letter mode and to select digits.
Tap to input space.
Phonebook
There are some numbers that you may want to call again and again, so it makes
sense to add these numbers to your Phonebook. You can then access these
numbers quickly and easily.
Add new contact
Go to Phonebook→Add new contact.
Edit the information and save it.
Save number to Phonebook
You can also save a number right after you’ve made or received a phone call
or a message from someone who is not yet in your Phonebook list.
Quick search
27
To quickly search for the contacts, tap the input box, and then enter the first
letter of your desired contact on the screen.
Delete one record
To delete someone from your Phonebook list, first select the name, then
select Options→Delete.
Copy or move records
You can copy or move the records to SIM or to phone. Select Options→Copy
or Move.
Set preferred storage
Select Options→ Phonebook settings→Preferred storage and then
select SIM, Phone or All.
View memory status
Select Options→Phonebook settings→Memory status to check the
memory status of both phone and SIM.
Making and receiving calls
Basic way to make a call
In the standby mode select Dialer icon. Tap the numeric buttons to input the
number and press the Send key to dial.
Dial from the Phonebook
28
Go to Menu→Phonebook. Find the name of the person you want to call,
and press the Send key.
Make an emergency call
You can make emergency calls without the SIM card inserted so long as you
are in an area with network coverage.
Answer a call
Press the Send key.
End a call
Press the End key.
Use call options
During a call, you can unlock the screen then select Options to enter the call
options.
You can use the speakerphone by tapping the H-free button.
You can put a call on hold, make a conference call, and use applications such
as Messaging & Phonebook while you’re on a call.
Call center
Go to Call center.
Call history
29
Missed calls, Dialled calls and Received calls are saved in Call history. If the
records are full, the earliest saved records will be deleted automatically.
Also, you can view call timers, text msg. counter and GPRS counter in Call
history.
Call settings
Caller ID: You can select to Set by network, Hide ID or Send ID.
Call waiting: After this function is activated, the system will inform you if
there is another incoming call when you are in call. Please contact your
network provider for details.
Call divert: The call divert service enables you to divert an incoming call
from a service to a specified telephone number in preset conditions. You
can contact the network provider to activate this service. You can set the
call divert service so that voice calls and data calls are diverted to a preset
number under different conditions.
Call barring: You can bar outgoing and incoming calls.
Line switching: Switch the call line.
Advance settings: You can set auto redial, call time display and call time
reminder.
30
Sending and receiving messages
Write a new message
You can use your mobile phone to send and receive messages.
1. Go to Messaging→Write message.
2. Write your message. For more information on input method, see section
“Writing text”. The default message type is SMS.
3. If you want to change to MMS, you can press Options and choose Switch
to MMS; or you can press Options and choose Add picture, Add sound,
Add video or Add subject to directly insert multimedia contents to the
message and it will be switched to MMS automatically.
4. You can select Options→Slide options to select to add a new slide. And
you can select Options→Advanced to insert an attachment, contact
number, contact name or bookmark.
5. When you finish writing, press Options→Send to to enter recipient or add
from Phonebook. If you are writing an MMS, after adding recipients, then
you can select Options→Change to Cc or Change to Bcc to change the
current contact to Cc or Bcc.
6. Select Options→Send to send the message out. If you want to save the
message as a draft, select Options→Save to Drafts.
View messages
31
Upon receiving a message, the mobile phone will alert you with a ringtone,
prompt, or a new message icon.
1. Press View to view the message.
2. While the message is open, use Options to reply, delete, or forward the
message. You can also call back the sender.
You can view the message boxes in the Messaging interface.
Select Inbox to view received messages.
Select Drafts to view unsent messages.
Select Outbox to view messages that failed to send.
Select Sent messages to view messages been successfully sent and
saved.
Select Archive to view archive messages.
Select Broadcast message to view broadcast messages.
In Voicemail server you can edit your voicemail server and call
voicemail.
Message settings
Go to Messaging→Message settings→Text message.
Profile settings: This is automatically set by the service provider, but
please contact us if this is not available.
Common settings: You can set Delivery report and Reply path on or off.
32
You can select to save sent messages or not.
Memory status: View the SIM and phone memory status.
Preferred storage: Set the preferred storage to SIM or Phone.
Go to Messaging→Message settings→Multimedia message.
Profiles: You can activate a profile or add new ones.
Common settings: In Compose, you can set Slide time, Creation mode,
Picture resizing, Auto signature and Signature. In Sending, you can
set Validity period, Delivery report, Read report, Priority, Delivery time,
and Send and save. In Retrieval, you can set Home network, Roaming,
Filters, Read report and Delivery report. In Preferred storage, you can
set the preferred storage to Phone or microSD card. In Memory status,
you can view memory status.
User profiles
Go to User profiles. You can select your preferred profile in this menu. The
profile options are: General, Meeting, Outdoor, Indoor, Silent, Headset and
Bluetooth. The default settings for each individual profile are preset at the factory.
You can change them in the Options→Customize menu.
Tone settings: Set the tone for various conditions.
Volume: Set the Ringtone and Key tone.
Alert type: Choose among four modes based on ring and vibration.
33
Ring type: Choose among Single, Repeat and Ascending.
Extra tone: Let the phone alert when Warning, Error, Camp on or Connect.
Note: The Headset mode can only be activated with the headset connected. And
the Bluetooth mode can only be activated when the Bluetooth headset is
connected.
Settings
You can adjust various settings of your phone. Go to Settings.
Dual SIM settings
In this menu, you can select Dual SIM open, Only SIM1 open,Only SIM2 open,
Flight mode. If you select Dual SIM open, the phone will remind you of choosing
SIM1 or SIM2 card in some interfaces.
Note: In Flight mode ,you can only use local program in your phone and all the
wireless functions will be turned off.
Pen calibration
If you feel that the contact point of your touch screen is not accurately positioned,
you can fix it by this function.
Complete the calibration operation according to the system prompts. Tap the
centre of the cross until the calibration is completed.
34
Phone settings
Time and date: You can set home city, time/date and format.
Schedule power on/off: Set auto power on and off time.
Language: You can set the language.
Display: You can set Wallpaper in this menu.
LCD Backlight: You can set the LCD backlight brightness and time.
Network settings
In this menu, you can set Network selection to be Automatic/Manual to select
the network service provider according to requests. If you have selected a
service provider manually, you have to manually select again or return to the
Automatic option to select the service provider when you switch to the SIM
card of another network.
Security settings
SIM lock: If SIM Lock is currently set Off, select On, then input a PIN
code to turn it on. You need to input the correct PIN code to unlock your
SIM card when you turn on your mobile phone next time.
Note: The PUK code is required to unlock the SIM card if you have incorrectly
input the PIN code for three consecutive times. The PIN code and the PUK
code may be supplied along with the SIM card. If not, contact the network
provider.
Phone lock: Phone lock can prevent your mobile phone from unauthorized
35
use. Select On/Off to enable or disable the handset lock protection.
Auto keypad lock: Select a time for auto keypad lock, and the phone will
automatically lock the keypad in the standby mode to prevent unintended
touch.
Change password: You can change the phone password here.
Note: You may be required to input the phone lock code in some of the security
setting interfaces. The default lock code is 1234.
Restore factory settings
You need to input the correct phone lock password to restore to the factory
settings.
Connectivity
Go to Connectivity.
Bluetooth: The Bluetooth devices must be paired before the communication
is performed.
Turn on or off the Bluetooth on your phone
Go to Power, you can turn on or off Bluetooth.
Make your phone visible
Go to Bluetooth→Visibility, you can choose to be visible or not.
When your phone is visible, and the Bluetooth is turned on, all other
Bluetooth-enabled devices within range can detect your phone.
36
Create a Bluetooth partnership
1. Go to Bluetooth→My Device→Search new device to search other
Bluetooth-enabled devices and list them.
2. Select the desired device name in the list and press Pair.
3. Enter a passcode (1 up to 16 characters), and then press OK. When
the opposite party enters the same passcode, the connection will be
established. Sometimes the devices can be paired automatically
without entering password.
Beam information using Bluetooth
After the Bluetooth partnership is established, you can beam information,
such as calendar items, as well as files from your phone to another
Bluetooth-enabled device.
For example, if you want to send a calendar item to the opposite party, find
that item, press Options→Send vCalendar→Via Bluetooth, and then
select the device name. If you want to send a multimedia file, find the file
from the media folder and then press Options→Send→Via Bluetooth,
and then select the device name.
Connect a Bluetooth hands-free or stereo headset
For hands-free phone conversations or to listen to music, you can use a
Bluetooth hands-free or stereo headset.
Go to Bluetooth→Search audio device to search for the Bluetooth
37
hands-free or stereo headset.
Data account: You can add and view your GSM and GPRS data account.
Organizer
Go to Organizer.
Calendar
Enter Calendar, the calendar of the current month will be displayed on the
screen and the current date will be marked by a background box in a special
colour.
You can click the dates, browse the dates, and click the direction arrows on the
screen to switch the year and month; the information on the screen will also
change consequently.
Tasks
You can add tasks.
Alarm
You can view, and edit the alarm clock settings. You can also enable or disable
the alarms. By taping Edit, you can set the corresponding features of the
alarm according to instructions.
World clock
You can view the time in different cities.
38
Calculator
You can perform simple calculations. Tap digit key to enter the number. Tap
operational character key to select operational character. Tap “=” to get the
result.
Note: This calculator has limited accuracy and rounding errors may occur
especially in long division.
File manager
Go to File manager. You can check all the folders in the phone or microSD card,
create new ones or rename, delete, or sort, etc. The files you download from the
internet will be stored in these folders.
Note: When you select Format, the data will be lost, so please be careful with this
function.
Fun&Games
Go to Fun&Games.
Java MIDlets are Java™-based applications that can run on your phones. Java
allows you to download Java-based applications, such as games and tools that
are specifically designed for mobile phones. Java gives you the flexibility of installing
and managing additional Java applications from the Internet.
39
Camera
Go to Camera→Camera.
Take a Photo
Aim the camera at the object and then tap the icon in the middle of the bottom
on the screen to take the shot.
Before capturing a photo, adjust brightness and zoom to the right size.
Configure your camera
Press the icon on the bottom left corner to configure your camera:
Photos: Enter Image viewer to view the photos you’ve just taken.
Camera settings: Set Shutter sound, EV, Night mode, Contrast,
Anti-flicker, Delay timer and Cont. shot.
Image settings: Set Image size and Image quality.
White balance: Select Auto, Daylight, Tungsten, etc.
Scene mode: Select Auto or Night.
Effect settings: Select Normal, Grayscale, Sepia, etc.
Storage: Select Phone or microSD card.
Restore default: Restore to factory default settings.
Video recorder
40
Before using the video recorder function, you must insert the microSD card,
otherwise video recorder function can’t be used.
1. Take a video
Tap the icon in the middle of the bottom on the screen to start shooting. You can
tap this icon to pause or restart shooting. Tap the icon on the bottom right corner
to finish recording.
Before recording a video, adjust brightness and zoom to the right size.
2. Configure your video recorder
Press the icon on the bottom left corner to configure your video recorder:
Camcorder settings: Set EV, Night mode and Anti-flicker.
Video settings: Set Video quality.
White balance: Select Auto, Daylight, Tungsten, etc.
Effect settings: Select Normal, Grayscale, Sepia, etc.
Restore default: Restore to default factory settings.
Multimedia
Go to Multimedia.
Image viewer
The images you want to view in Image viewer must be put in the ..\Fotos folder in
the phone or microSD card, and in Options→Storage, the storage must be
set to phone or microSD card correspondingly.
41
You can select an image and view it.
Image viewer supports: jpeg, jpg, bmp, gif, png.
Media player
You can play the audio and videos in your phone or the microSD card. To
create a playlist, in My playlists, select Options→New, and then set the list
name. select Options→Open→Options→Add, and select the file, then the
file will be added into the playlist.
Media player supports: AMR, WAV, MP3, MIDI, Mpeg4, 3GP.
FM radio
With the radio, you can search for radio channels and listen to them. When
you receive an incoming call while listening to the radio, the radio will pause.
After you finish the call, the radio will start working again. In the FM radio
interface, press the icon on the bottom left corner to enter the submenu.
Channel list: Edit and save radio channels.
Manual input: Manually input a channel.
Auto search: Automatically searches for channels.
Settings: You can turn on Loudspeaker and set Channel effect.
Note: The quality of the radio broadcast depends on the coverage of the radio
station in that particular area. The wired headset works as an antenna, so
always connect the headset when using the radio.
42
Services
Go to Services.
Services allows you to view internet content. In Services, you can use the STK
and Internet service, and you can select Licence manager to manage the
licences.
STK
SIM card Toolkit (STK) services are value-added services provided by your
network provider.
Your mobile phone supports STK service, but if your SIM card and network
provider do not support the service, these functions can’t be used.
Internet service
Your phone supports Wireless Application Protocol (WAP). You can get
access to this service through your network provider. Internet service lets
you get information about news, weather forecasts and more.
Go to Services→Internet service. You can perform the following operations:
Homepage: Homepage is a WAP site you set in Settings→Profiles.
Bookmarks: Access your phone’s preset websites. Select a bookmark
and press Options→Go to to load the website.
Input address: Input a URL and press Options→Done to visit the site.
Recent pages: Display the pages you’ve visited recently. Select an
43
item and choose Options→Go to to visit the page again.
Settings: You can set Profiles, Browser options, Preferences or
Security settings.
Licence manager
Licence list: Display the list of Licences.
Status: Check the version and time.
Advance: Select Sweep to remove useless licences and reboot your
phone.
