ZTE S610 GSM Dual-band GPRS digital mobile phone (850/1900) User Manual
ZTE Corporation GSM Dual-band GPRS digital mobile phone (850/1900)
ZTE >
User Manual
GSM Dual-Band GPRS
Digital Mobile Phone
User Manual
This manual is applicable for S610 Mobile Phone.
Copyright © 2009 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or
utilized in any form or by any means, electronic or mechanical, including
photocopying and microfilm, without the prior written permission of ZTE
Corporation.
ZTE Corporation reserves the right to make modifications on print errors or
update specifications in this manual without prior notice.
Version 1.0, Apr. 2009
Contents
Before Use ......................................... 1
Safety Instructions ......................... 1
Parts Definition ............................ 10
Insert and Remove SIM Card ...... 13
Insert and Remove Memory Card 14
Battery.......................................... 15
Install the battery ................. 15
Remove the battery ............. 15
Charge the battery ............... 16
Power On/Off ............................... 17
Enter the Menu ............................... 18
Menu Tree ........................................ 19
Function Descriptions ................... 20
Make and answer calls ................ 20
Make a call ........................... 20
Answer a call ....................... 21
Adjust the volume ................ 21
Hands-free ........................... 21
Call Options ......................... 22
Write message ............................. 22
View Message ............................. 23
Add New Entry ............................. 23
U-Disk .......................................... 24
Main Function List ......................... 25
Input Methods ................................. 35
Appendix ......................................... 36
Clearance and Maintenance ....... 36
Failure Analysis ........................... 38
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
1
Before Use
Thank you for choosing ZTE-G S610 digital mobile phone. (Shortly referred
to as “Mobile Phone”)
To guarantee your mobile phone always in its best condition, please read
this manual carefully and keep it for future use.
The pictures in this user manual are only used to demonstrate the mobile
phone’s functions, so they are maybe different from what you see on your
mobile phone. Please refer to your mobile phone if there are any differences.
Safety Instructions
If your mobile phone is lost or stolen, notify your network service provider
immediately to prevent unauthorized use.
To protect your mobile phone against abuse, take the following precautions:
- Set PIN code for SIM card and modify it from time to time.
- Take your mobile phone with yourself as much as possible.
2
Precautions for using the mobile phone
Traffic Security
z Pay attention to traffic security and follow all local relevant laws and
regulations while driving.
Interference
z Do not use your mobile phone near weak signal or high-precision
electronic devices. Radio wave interference may cause electronic
equipment to malfunction. Pay special attention when you use your
mobile phone near audio phone, pacemaker and/or other medical
electronic devices, fire detector, auto-door and/or other auto-control
equipments. For details on the influence caused by your mobile
phone on pacemaker or other medical electronic devices, please
consult the manufacturer or your local distributor.
z Do not use your mobile phone near TV set, radio or office automated
equipments to avoid mutual influence.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
3
On Airplane
z Turn off your mobile phone on airplane where it’s forbidden to use it.
The mobile phone may affect the normal operation of electronic
devices.
In Hospital
z Turn off your mobile phone in hospital where it’s forbidden to use it. The
mobile phone may affect the normal operation of medical apparatus.
In Gas Station
z Do not use your mobile phone in gas station. Turn off your mobile phone
near fuels or chemicals.
Waterproof
z Keep your mobile phone away from water. This may cause overheating,
electric leakage or failure if water or any other kind of liquid enters your
4
mobile phone.
Disassemble
z Do not disassemble or reassemble your mobile phone because this
might cause damage, electric leakage or circuit failure.
Antenna
z Do not use your mobile phone if your antenna is damaged because this
may cause body injury.
Away from Children
z Keep your mobile phone from children. It may cause body injury when
the mobile phone is used as a toy.
Original Accessories
z Use the original accessories or those authenticated by the
manufacturer. Using non-original accessories may affect the mobile
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
5
phone’s performance, violate the warranty provisions or relevant
national regulations about telecom terminals, or even cause body
injury.
Explosion Areas
z Please strictly follow relevant laws and regulations to turn off your
mobile phone in or near the explosion areas.
Emergency Calls
z Make sure your mobile phone is turned on and in the service area. Input
the emergency number and press “Send” key to dial.
6
Precautions for using the battery
z Put the battery in a cool and ventilated place where there is no direct
sunshine.
z The battery life is usually limited, and it becomes shorter and shorter
after the battery is charged over and over again. If the charging fails
several times, this indicates that the battery is worn out and the
replacement is advised.
z Dispose the worn-out batteries in designated places according to
specified regulations rather than throw them into residential garbage.
z Do not throw the worn-out batteries into fire because this might cause
fire or explosion.
z Do not press with great force when installing the battery because this
may result in leakage, overheating, explosion or fire.
z Do not disassemble or reassemble the battery because this may result
in leakage, overheating, explosion or fire.
z If the battery becomes hot, changes in color or gets deformed during the
course of use, charging or storage, please immediately stop using and
replace it.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
7
z Keep the battery away from dampness to prevent overheating,
smoldering or erosion.
z Do not leave the battery in direct sunshine, around a car or
high-temperature place because this might result in leakage or
overheating. This might affect the battery’s performance and shorten its
life.
z Do not keep charging the battery continuously over 24 hours.
Note:
If the battery is damaged, please avoid contacting the materials in
it. If your skin has contacted those materials, flush your skin
with lots of water and seek for help from doctors if necessary.
8
Precautions for using the charger
z Use the power voltage between 110VAC and 220VAC. Using the
voltage beyond the range may cause leakage, fire or damage to the
phone and charger.
z Do not short-circuit the charger because this might cause electric
shock, smoldering or damage.
z Do not charge the battery in direct sunshine, near dampness, dust,
vibration, TV set, or radio (may affect the image, sound), etc.
z Do not use the charger if the power cable is damaged because this
might cause fire or electric shock.
z Do not place water containers near the charger to avoid water
splashing. If water or any other kind of liquid splashes on the charger,
immediately remove the charger from the power socket to avoid
overheating, fire, electric shock or failure.
z Do not disassemble or reassemble the charger because this might
cause body injury, electric shock, fire or damage.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
9
z Do not touch any charger, power cable or power socket with wet
hands to avoid electric shock.
z Do not place heavy objects onto power cables or refit power cable
because this might cause electric shock or fire.
z Remove power plug from the socket before cleaning and
maintenance.
z Hold the charger rather than pull the power cable while removing the
plug from the socket because this might cause damage, electric
shock or fire.
10
Parts Definition
Receiver
End key
LCD
Send ke
y
Make or answer a call;
Press it to enter recent calls in
idle mode. Alphanumeric keys
* key
Under text input mode, press * key
to display the list of symbols.
# key
Left/Right soft ke
y
Execute the operations of the
words at left/right corner;
Navigation key and O
K
key
In idle mode
Up key: Music
Down key: Profiles
Left key: Messages
Right key: Inbox
OK key: main menu
In idle screen, hold # key to quickly switch
between Meeting and other mode; press # key
to switch the input method when editing the
text.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
11
Note:
In this user manual, “press” means pressing the key and then
releasing; “hold” means pressing and holding the key for about
2 seconds or more.
USB Interface
Camera
head
Side keys
Memory card slo
t
Adjust the volume
12
Descriptions of icons on the status bar
Icons Descriptions Icons Descriptions
Network signal strength Battery capacity indication
Unread SMS Unread MMS
Calling and in a conversation Hands-free
Outdoor mode Meeting mode
Flight mode Mute mode
Self-defined mode Alarm on
Stopwatch on Bluetooth on
MP3 playing FM radio on
GPRS icon Call forwarding set
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
13
Insert and Remove SIM Card
Insert a valid SIM card into your mobile phone before use.
All information regarding network connection and SIM
contacts is saved in SIM card. In order to avoid the loss
and damage of information saved in SIM card, please
don’t touch the metal surface and put SIM card far away
from electricity or magnetism.
1. Turn off your mobile phone, remove the battery and disconnect the
external power.
2. Insert SIM card into the socket.
Turn off your mobile phone and remove the battery before taking out SIM
card.
14
Insert and Remove Memory Card
Note:
The mobile phone supports T-FLASH only. Please consult your
manufacturer or supplier for the information on the compatibility
of T-FLASH card.
Do not take out the memory card when executing the operation of
browsing the card. Otherwise, it might not only damage the card &
the phone, but destroy the data saved in the card.
1. Open the cover and insert the memory card into the slot;
2. Push until the card is in right position and close the cover;
Open the cover, slightly press the memory card until it’s unlocked and take
out the memory card.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
15
Battery
Install the battery
1. Align the battery's contact
points in the direction of the
arrow as shown, and Insert
the battery into the slot;
2. Put on the battery cover, and
push forward in the direction
of the arrow as shown until
it’s locked.
Remove the battery
1. Turn off the mobile phone;
2. Open battery cover in the
direction of the arrow.
3. Pull the battery in the direction
of the arrow and take it out.
16
Charge the battery
The accompanying Li battery can be used after being unpacked. To make
the battery always in its best condition, please exhaust the capacity of the
battery and then fully recharge it for the first three times.
1. Connect the charger with the mobile phone through the
charging interface, and insert the charger to 110V/220V
power socket.
2. When the phone is turned on, the capacity indicator on up-right corner
of the screen keeps scrolling during charging; when the phone is turned
off, there’ll be charging indication on the screen during charging. If the
phone is used excessively without enough capability, the charging
indication will not immediately appear on the screen of the phone when
charging starts, and the phone might not be powered on within a few
minutes.
3. When the phone is on, the battery is fully charged as the capacity
indication on the up-right corner of the screen is full and doesn’t flicker
any longer. When the phone is off, there should be a prompt as the
battery is fully charged. During the charging, the phone and charger
may normally become hot.
4. Please disconnect the charger from your mobile phone and the socket
when the charging is completed.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
17
Power On/Off
Hold End key until the power-on/off animation appears.
After your turn on your mobile phone, it will automatically check whether or
not SIM card is inserted or usable, and shows the following information on
the screen in turn:
Enter Phone Lock Code: if you’ve set lock code.
Enter PIN Code: if you’ve set PIN code for SIM card
Note:
SIM card will be locked if you enter wrong PIN code three times.
Then you need PUK code to unlock SIM card. The PIN code
may be provided to you together with SIM card. If not, contact
your network service provider. The default PIN code is normally
1234. Please replace it with your own PIN code as soon as
possible.
Search: The mobile phone will search for the available network.
18
Enter the Menu
In idle mode, press left soft key to enter the main menu, press left/right key
to switch among the three main interfaces, press up/down key to select the
relevant submenu, and press Ok key to enter the submenu. Press End key
to return to idle screen.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
19
Menu Tree
Messages
SMS
MMS
Voice Mail
Server
Broadcast
Message
Contacts
Quick Search
Search Entry
Add New Entry
Caller Group
Copy All
Delete All
Preferred
Storage
Information
Call History
Missed Calls
Dialed calls
Received calls
Delete Call Log
Call Time
Bluetooth
Power
Inquire Audio
Device
My Device
Active Device
Settings
About
Music
Audio Player
FM Radio
Sound Recorder
Games
UFO
Game center
Game Setting
Video
Camera
Video Player
Album
Video Recorder
Connect
STK service
WAP
Data Account
ZTE Fairyland
Mobile QQ
Settings
User Profiles
Phone Setup
Call Setup
Network Setup
Security Setup
Restore Factory
Settings
File Manager
Phone
DRM Rights
Memory Card
Organizer
Calendar
Alarm
Calculator
Phone number
location
Stopwatch
E-book Reader
Converter
World Clock
ZTE Services
20
Function Descriptions
Make and answer calls
Make a call
Direct dial: In idle mode, press the numeric keys to input the
telephone number and press Send key to dial.
Dial from Contacts: In idle mode, press right soft key to enter the list
of contacts, select the contact and press Send
key to dial.
Dial from call history: In idle mode, press Send key to enter the list of
“Call Logs”, select the call record and press Send
key to dial.
Dial extension: Sometimes you can not dial the extension directly.
Dial the direct line firstly, press * key to switch
continuously until “P” appears on the screen,
and then dial the extension number.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
21
Dial international calls: To dial an international call, press * key to
switch continuously until “+” appears on the screen,
and then dial the country or region code, city code
and phone number.
Answer a call
Press Send key to answer the call.
Adjust the volume
Press Side keys to adjust the key volume in idle mode, and press Side
keys to adjust the voice volume during the conversation.
Hands-free
During the conversation, press “H-Free” key to enter the hands-free status,
and press “H-Held” to return to normal status.
22
Call Options
During the conversation, press “Options” to enter “Contacts”, “Messages”,
etc.
Write message
1. In idle mode, press “Menu” to select “Messages” “SMS” “Write
Message” to edit the message text.
Press “Options” and then select “Insert” to insert Use Template, PHB
Number, PHB Name, Bookmark, Object, etc.
Press “Options” to select “Text Format” to edit Text Style, Alignment,
New Paragraph, etc.
2. After the message text is finished, press “Options” to select:
Send Only: press “Options” “Send Now” to send the message
after entering the recipient’s number (press “Options”
“Contacts” to select the phone number from Contacts).
Send By Group: send the message to all the members in a group.
Save and Send: See the same operation of “Send Only”. The sent
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
23
messages will be saved in “Outbox”.
Save as Draft: save the messages in “Draft”.
View Message
In idle mode, your mobile phone will prompt you upon the receiving of a
new message. Press “Read” to directly view the message. You could also
go to “Inbox” to check the message.
1. In idle mode, press “Menu” and select “Messages” “SMS” “Inbox”.
2. The list of received messages is displayed on the screen. Press
Up/Down key to select the message, and press “Options” “View” to
view the message text.
3. Press “Options” to select “Reply”, “Delete”, “Forward”, etc.
Add New Entry
1. In idle mode, press “Menu” to select “Contacts” “Add New Entry”.
2. Select “To SIM” or “To Phone”.
24
If you want to add new entry to SIM, you need input “Name” and
“Number” only.
If you want to add new entry to Phone, you need edit “Name”,
“Mobile Number”, “Home Number”, “Office Number”, “Other
Number”, “Email Address”, “Caller Group”, “Associate Picture”,
“Associate Sound” and “Memo”.
3. Press “Save” after finishing the edit.
U-Disk
z When the phone is powered off, you could use your mobile phone as
U-disk simply by connecting it and PC through a data cable
z When the phone is powered on, you will be prompted to select “U-disk”
by connecting your mobile phone and PC if the memory card is inserted
into the phone.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
25
Main Function List
The functions marked with “*” need the support from network operators.
Functions Descriptions Operations
Send SMS Send short messages to
others.
Menu Messages SMS
Write Message
View SMS View received, sent and
saved messages
Menu Messages SMS
Inbox/ Outbox/Draft
Insert Template Insert the template into the
message text and sent it out.
Menu Messages SMS
Template
Delete
Messages
Delete the messages in
inbox/outbox/draft or delete all
messages.
Menu Messages SMS
Delete Messages
Check memory
status
Check the memory status of
SIM card or phone.
Menu Messages SMS
Settings Memory
Status
Send MMS Send MMS to others Menu Messages MMS
Write Message
26
Functions Descriptions Operations
View MMS View received, sent and
saved messages
Menu Messages MMS
Inbox/Outbox/Draft
Insert
Templates
Insert the template into the
message text and sent it out.
Menu Messages MMS
Template
Check memory
status
Check the memory status of
SIM card or phone.
Menu Messages MMS
Message Settings
Memory Status
Voice mail* The dialing party leaves the
message through voice mail
and you could listen to it.
Menu Messages Voice
Mail Server
In idle mode, hold “1” key to
call the voice mail number
Broadcast* Receive the public information
from network operator.
Menu Messages
Broadcast Message
View contacts Browse all contacts, input the
first letter of contact’s name to
quickly search for the contact
Menu Contacts Quick
Search
Search Entry Search by name Menu Contacts Search
Entry
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
27
Functions Descriptions Operations
Add New Entry Save the telephone number
and name
Menu Contacts Add
New Entry
Edit contacts Edit the information of existing
contacts
Menu Contacts Select
any contact Options
Details Edit
Copy All Copy all contacts from SIM to
phone or from phone to SIM.
Menu Contacts Copy
All
Delete All Delete all contacts in SIM or
phone
Menu Contacts
Delete All
Caller Group Divide the contacts into
different groups
Menu Contacts
Caller group
Memory status Check the memory status of
SIM card or phone
Menu Contacts
Information Memory
Status
Preferred
Storage
Set the preferred storage
location for the contact
Menu Contacts
Preferred Storage
View call View the recent missed dialed Menu Call History
28
Functions Descriptions Operations
history and received calls. Missed calls / Dialed
Calls /Received Calls
Delete Call Log Delete missed calls, dialed
Calls, received Calls or all.
Menu Call History
Delete Call Log
View call time Check the last call time and
total sent/received call time.
Menu Call History Call
Time
Bluetooth Short distance wireless
transmission.
Menu Bluetooth
Audio player Play the audio file Menu Music Audio
Player
FM radio Listen to FM radio Menu Music FM radio
Sound recorder Record audio files Menu Music Sound
Recorder
Games Provides built-in games. See
the detailed operation
instruction in the menu.
Menu Games
Camera Take digital photos Menu Video Camera
Video player Play the video file Menu Video Video
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
29
Functions Descriptions Operations
Player
Album View the captured photos Menu Video Album
Video recorder Record video files Menu Video Video
Recorder
WAP Get access to WAP service,
such as news, weather
forecast, airline flights, etc.
Menu Services WAP
Mobile QQ* Log onto QQ Menu Connect Mobile
QQ
User Profiles Perform personalized settings
on ringtone, volume, ringer
type, etc. according to
different events and
occasions.
Menu Settings User
Profiles any
mode Options Activate
In idle mode, hold “#” key to
activate or deactivate
“Meeting”.
Time & Date Set the date and time
displayed on the phone
Menu Settings Phone
Setup Time & Date
Schedule Perform the action of power Menu Settings Phone
30
Functions Descriptions Operations
power on/off on/off according to the setting
time
Setup Schedule Power
On/Off
Language Select the language for the
menu
Menu Settings Phone
Setup Language
Wallpaper Set the standby wallpaper on
the screen
Menu Settings Phone
Setup Display
Characteristic Wallpaper
Motion Sensor Set Call Silence, Alarm
Silence, Rock Change Music,
Change Wallpaper, Change
Menu, View SMS, etc
Menu Settings Phone
Setup Motion Sensor
Keypad lock The keypad lock would
prevent the inadvertent
operation caused by key
press.
Menu Settings Phone
Setup Auto Keypad
Lock.
In idle mode, hold Left soft
key to quickly lock the
keypad.
Unlock: press left soft key
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
31
Functions Descriptions Operations
and # key to unlock the
keypad
Voice Function Set Voice Dial, Voice Song
and Voice Menu.
You could check Help menu
for details.
Menu Settings Phone
Setup Voice Func
Speed Dial Edit 8 speed dial numbers
using numeric keys from 2-9.
In idle mode, hold the numeric
key to quickly dial the
corresponding phone number.
Menu Settings Call
Setup Speed Dial
Call Waiting * You will be prompted by the
network upon a received call if
this function is activated.
Menu Settings Call
Setup Call Waiting
Call Divert * Forward the received call to
designed number on a
specific occasion
Menu Settings Call
Setup Call Divert
IP dial After editing IP access Menu Settings Call
32
Functions Descriptions Operations
number and selecting
“Activate”, you could select IP
dial when making a call.
Setup IP Dial
Any key to
answer
Press any key to answer the
call.
Menu Settings Call
Setup Set Answer Key
Any Key
SIM lock Activate PIN code to prevent
SIM card from abuse.
SIM card will be locked if you
enter wrong PIN code three
times. Then you need PUK
code to unlock SIM card. The
PIN code and PUK code may
be provided to you together
with SIM card. If not, contact
your network service provider.
The default PIN code is
normally 1234. Please replace
it with your own PIN code as
soon as
p
ossible.
Menu Settings Security
Setup SIM Lock
The default code is 0000.
Phone lock Activate phone lock to prevent
the phone from abuse
Menu Settings Security
Setup Phone Lock
Call Barring* Set the dialed call barring or Menu Settings Call
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
33
Functions Descriptions Operations
received call barring Setup Call Barring
Fixed dial * After this function is activated,
you could only dial the
number in fixed dial list.
Menu Settings Security
Setup Fixed Dial
Network
settings
Select the network and set
GPRS connection
Menu Settings
Network Setup
Restore factory
settings
Restore the relevant
parameters to factory settings.
Menu Settings Restore
Factory Settings
File manager View the files saved in phone
and memory card.
Menu File Manager
Calendar Check the calendar and
schedule
Menu Organizer Calend
ar
Alarm Set multiple alarms, and
support power-off alarm
Menu Organizer
Alarm
Calculator Simple calculation, such as
add, subtract, multiply, divide;
Menu Organizer
Calculator
Phone number
location
Input the phone number or
region code to inquire the
Menu Organizer
Phone Number Location
34
Functions Descriptions Operations
location.
Stopwatch Measure the time Menu Organizer
Stopwatch
E-book Browse TXT file. Menu Organizer
E-book Reader
Converter Provide basic functions of
currency conversion and unit
conversion.
Menu Organizer
Converter
World Clock Press left/right key to browse
the current time of different
cities around the world.
Menu Tools World
Clock
ZTE Services Dial ZTE customer hotline Menu ZTE Services
Note:
When copying files from PC to memory card, please put the
files into relevant folder, e.g., put audio files into My Music,
electronic books into Ebook, video files into Video, etc.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
35
Input Methods
The mobile phone supports ABC/ abc input method, eZiABC/ eZiabc
input method, 123 input method and symbol input method.
Switch input
method
Press # key
Input space Press 0 key under any method except for 123 input method.
Delete inputs Press “Clear” to delete the input before the cursor and hold
“Clear” to delete all inputs.
ABC/ abc input
method Each key is used to input multiple letters. Quickly repeat the
key until your desired letter appears.
eZiABC/ eZiabc
input method 1. Press the corresponding number key to input;
2. If the word is not what you want, press up/down key to view
other matches, and press Select to input.
123 input method Press the numeric keys to input the corresponding numbers.
Symbol input
method Under text input mode, press * key to display the symbol box,
press navigation key to select the symbol and press OK key to
confirm.
36
Appendix
Clearance and Maintenance
Please carefully maintain your mobile phone because it is a delicately
designed and manufactured product. The following advice might help you
use your mobile phone correctly and prolong the mobile phone’s life.
z Clean the phone, battery and charger with a soft dry cloth.
z Do not clean the phone with the liquor such as alcohol, dilution agent or
benzene.
z Clean the socket from time to time because a dusty socket might cause
disconnection, power failure, or even charging failure.
z Do not press the keys with needles, pen points or other sharp objects to
avoid damage or malfunction.
z Do not touch the mobile phone with wet hands because this might
cause electric shock, which would hurt people or damage the phone.
z Do not use or put your mobile phone in a dusty or dirty place because it
may damage the components of the phone.
z Do not put your mobile phone in a place at too high/low temperature.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
37
z Do not put your mobile phone in or on the heating devices (microwave,
oven or heat sink). The mobile phone might cause explode if it gets too
hot.
z The color of the waterproof label in the phone will be changed if the
phone or battery gets wet. In this case, the warranty provisions will
become void even if the warranty period doesn’t expire.
z If there is anything wrong with the mobile phone, battery, charger or
any phone accessory, please send them to your nearest service center
for inspection. The working staff in our service center will help you.
38
Failure Analysis
Symptoms Possible Causes Solutions
Unable to turn
on the phone
Inadequate battery
capacity Charge the battery
Poor contact Reinstall the battery
Automatic
power-off
Seriously poor battery
capacity Recharge the battery
Inadequate
standby time
Deceasing of battery
performance Replace the battery
Poor network signal Turn off the phone as the
signal is poor.
Unable to
connect the
network
Poor network signal Move to other places
Out of the service
area
Make sure your phone is in
network service area
Call drop Poor network signal Move to other places
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
39
Cannot hear the
ringtone Silent profile was set
Enter User Profiles to
change Silent to other
mode, or check the setting
of ring volume.
Prompt to input
PUK
SIM card locked due
to the continuous
entering of wrong PIN
code for three times.
Contact your network
operator.
40
FCC Regulations:
zThis mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
zThis mobile phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to
operate the equipment.
zThe antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
錯誤! 使用 [常用] 索引標籤將 标题 1 套用到您想要在此處顯示的文字。
41
4RF Exposure Information (SAR)
This mobile phone meets the government’s requirements for exposure to radio waves.
This phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S. Government.
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating positions accepted by
the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the
maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the poser required
to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.
The highest SAR value for the model phone as reported to the FCC when tested for use at the ear is 1.52 W/kg and when worn
on the body, as described in this user guide, is 1.31 W/kg (Body-worn measurements differ among phone models, depending
upon available enhancements and FCC requirements.)
While there may be differences between the SAR levels of various phones and at various positions, they all meet the
government requirement.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance
with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the
Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID: Q78-S610.
This device is compliance with SAR for general population /uncontrolled exposure limits in ANSI/IEEE C95.1-1999 and had been
tested in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C.
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for use with an accessory that
contains no metal and the positions the handset a minimum of 2.5 cm from the body. Use of other enhancements may not
ensure compliance with FCC RF exposure guidelines. If you do no t use a body-worn accessory and are not holding the phone
at the ear, position the handset a minimum of 2.5 cm from your body when the phone is switched on.
