ZTE TWC010 Wireless Charging User Manual

ZTE Corporation Wireless Charging

User Manual

User Manual
1 PRODUCT DESCRIPTION
This product adopts the theory of electromagnetic induction. Transfer electricity
from power supply to the device that will be charged by electromagnetic wave. It
uses advanced, distinguished and controlled technology, which can realize low power
standbycharge indicationautomatic suspending when charge finished. The charging
efficiency can reach up to 70%. Any device pass the Qi certification can be charged
on the board. This TWC010 has the following features.
WPC-certified transmitter
Transmitter mounting pad to provide correct receiver interface
Receiver output voltage of 5 V up to 1 A
Standard A11-type transmitter coil
LED indicates power transfer state.
Installation:
Please install the TWC9520R power receiver into ZTE N9520.
Use method:
1) Please connect the adapter and the compact transmitter, and then plug the other end of the
power cord into power supply socket. If the power-led turns blue, it means product initiates
normally.
2) Please put standby charging device on transmitter interface, where is magnetic. If LED blinks
blue, it means your device enters normal charging phrase.
3) Please make sure you had put your device on the exact location of transmitter, or LED will
blinks blue rapidly, which means there is error when charging. You need to re-aim.
2 LED indicators:
3. FCC WARNING
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
LED
STATE
INDICATION
Charging
indicator
Blinking blue
Normal charging
Blinking blue rapidly
Abnormal charging
Blue
Charging complete
