ZTE ZTEA110 LTE/WCDMA/GSM Multi-Mode Digital Mobile Phone User Manual

ZTE Corporation LTE/WCDMA/GSM Multi-Mode Digital Mobile Phone Users Manual

Contents

Users Manual

1
ZTE BLADE A110
Quick Start Guide
2
LEGAL INFORMATION
Copyright © 201
6 ZTE CORPORATION.
All rights reserved.
No part of this publication may be quoted,
reproduced, translated
or used in any form or by any means, electronic or mechanical,
including photocopying and microfilm, without the prior written
permission of ZTE Corporation.
ZTE Corporation reserves the right to make modifications on print
r update specifications in this guide without prior notice.
Trademarks
ZTE
and the ZTE logos are trademarks of ZTE Corporation.
Google and
Android are trademarks of Google, Inc.
The
Bluetooth® trademark and logos are owned by the Bluetooth
SIG, Inc.
and any use of such trademarks by ZTE Corporation is
under license.
microSDHC Logo is a trademark of SD-3C, LLC.
3
Other trademarks and trade names are the property of their
respective owners.
We offer self-service for our smart terminal device users. Please
visit the ZTE official website (at www.ztedevice.com) for more
information on self-service and supported product models.
Information on the website takes precedence.
Visit http://www.ztedevice.com to download the user manual. Just
click Service Support>user’s manual from the home page and
then select your location, product type, and name to search for
related support information.
Disclaimer
ZTE Corporation expressly disclaims any liability for faults and
damages caused by unauthorized modifications of the software.
Version No.: R1.0
Edition Time: 2016.1
4
Front Camera
Touch Screen
Back Key Menu Key
Home Key
Power Key
Volume Key
Sensor
Indicator
Getting to
Know Your Phone
Receiver
5
Volume Key
Power Key
Loud Speaker
Camera
Flash Lamp
Back Cover
Headset Jack
Charging/USB Jack
6
Power Key
·
Press and hold to power on, select phone modes, turn
on/off airplane mode, restart, or power off.
·
Press to wake up your phone.
Home Key
·
Touch to return to the Home Screen from any
application or screen.
·
Hold to see Google search.
Menu Key
Touch and hold to see recently used applications.
Back Key
Touch to go to the previous screen.
Volume
Key
Press or hold to turn the volume up or down.
7
Starting Up
Switch off your phone before installing or replacing the battery
or the SIM card. The microSDHC™ card is optional and can be
installed and removed while the phone is turned on. Unmount
the microSDHC card before removing it.
1. Place your finger in the slot at the bottom of the back cover to
lift and remove the cover.
2. Hold the SIM card with its cut corner oriented as shown and
slip it into the card holder.
8
3.
Hold your microSDHC card with the metal contacts facing
down and slide it into the microSDHC card slot.
micro-SIM card
microSDHC
card
9
4、Align the connectors on the phone and the battery and
slide the battery into the compartment. Then gently press
the battery down until it is secured.
5、Align the back cover with the back of the phone and press
the cover back into place. Make sure all the tabs are secure
and there are no gaps around the cover.
Charging the Battery
1. Connect the adapter to the charging jack. Ensure that the
adapter is inserted with the correct orientation. Do not force
the connector into the charging jack.
10
2.
Connect the charger to a standard AC power outlet.
3.
Disconnect the charger when the battery is fully charged.
Powering On/Off Your Phone
Make sure the battery is charged
before powering on.
·
Press and hold the Power Key to turn on your phone.
11
· To turn it off, press and hold the Power Key to open the
options menu. Touch Power off.
Product Safety Information
Do not use hand-held
while driving
Do not use while re-fuelling
For body-worn
operation maintain a
separation of 10 mm
This device may produce a
bright or flashing light
Small parts may cause
a choking hazard
Do not dispose of it in a fire
This device may
produce a loud sound
To prevent possible hearing
damage, do not listen at high
volume levels for long
periods.
Avoid contact with
magnetic media
Avoid Extreme Temperatures
12
Keep away from
pacemakers and other
personal medical
devices
Avoid any contact with liquid,
keep it dry
Switch off when
instructed in hospitals
and medical facilities
Do not attempt to
disassemble
Switch off when
instructed in aircrafts
and airports
Only use approved
accessories
Switch off in explosive
environments
Do not rely on this device for
emergency communications
13
§ 15.19 Labeling requirements.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
14
determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
-
Reorient or relocate the receiving antenna.
-
Increase the separation between the equipment and
receiver.
-
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-
Consult the dealer or an experienced radio/TV technician
for help.
Specific Absorption Rate (SAR) information:
Body Operation
This device was tested for typical body suppo
rt operations.
To comply with RF exposure requirements, a minimum
separation distance of
1.0 cm must be maintained between
the user’s body and the device, including the antenna.
Third
-party belt-clips, holsters, and similar accessories
used by this device
should not contain any metallic
components. Body accessories that do not meet these
15
requirements may not comply with RF exposure
requirements and should be avoided. Use only the
supplied or an approved antenna.
