ZTE ZTEA15 GSM DUAL-BAND DIGITAL MOBILE PHONE User Manual 661995
ZTE Corporation GSM DUAL-BAND DIGITAL MOBILE PHONE 661995
ZTE >
USERS MANUAL
1
ZTE A15
GSM Dual-band Digital Mobile Phone
User Manual
2
Copyright © 2006 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any
form or by any means, electronic or mechanical, including photocopying and microfilm,
without the prior written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications
on print errors or update specifications without prior notice.
SW VERSION: P103A1AXDV1.0.0B01
Edition: 1st edition, May, 2006
3
Contents
1 GENERAL INFORMATION........................................................1
1.1 WELCOME ................................................................................1
1.2 SECURITY .................................................................................1
1.3 SAFETY PRECAUTIONS..............................................................2
2 GETTING STARTED.................................................................. 11
2.1 KEY DEFINITION .....................................................................11
2.2 DISPLAY SYMBOLS .................................................................13
2.3 TECHNICAL PARAMETERS.......................................................14
2.4 BATTERY.................................................................................15
2.4.1 Removing & Installing the Battery.................................15
2.4.2 Charging the Battery......................................................16
2.5 CONNECTING TO THE NETWORK.............................................18
4
2.5.1 SIM Card ....................................................................... 18
2.5.2 Inserting & Removing SIM Card................................... 19
2.5.3 Power on/off Your Phone............................................... 20
2.5.4 Unlocking the SIM Card and Mobile Phone ................. 20
2.5.5 Connecting to the Network............................................ 21
3 BASIC OPERATIONS ............................................................... 23
3.1 MAKING A CALL .................................................................... 23
3.2 ANSWERING A CALL .............................................................. 25
3.3 CALL MENU ........................................................................... 25
4 FUNCTION MENU .................................................................... 28
4.1 USAGE AND STRUCTURE OF FUNCTION MENU ...................... 28
4.2 SHORT MESSAGE ................................................................... 29
4.3 PHONE MENUS....................................................................... 33
4.3.1 Call Logs....................................................................... 34
5
4.3.2 Diverts............................................................................35
4.3.3 Firewall..........................................................................37
4.4 PROFILES ................................................................................39
4.5 SETTINGS................................................................................41
4.5.1 Phone Settings................................................................41
4.5.2 Display Settings .............................................................42
4.5.3 Clock Settings.................................................................42
4.5.4 Call Settings...................................................................42
4.5.5 Network Settings ............................................................43
4.5.6 Security Settings.............................................................44
4.5.7 Factory Settings .............................................................47
4.6 TOOLKIT .................................................................................47
4.6.1 Alarm Clock ...................................................................48
4.6.2 Calculator ......................................................................49
4.6.3 Stopwatch .......................................................................49
4.6.4 World Clock....................................................................50
6
4.7 GAMES................................................................................... 50
4.8 NAMES................................................................................... 51
4.8.1 Searching....................................................................... 53
4.8.2 Editing........................................................................... 53
4.8.3 Deleting......................................................................... 53
4.8.4 Making an IP Call......................................................... 54
4.8.5 Adding New Name......................................................... 54
4.8.6 Settings .......................................................................... 55
4.8.7 Batch Operation............................................................ 55
5 TEXT INPUT .............................................................................. 56
5.1 OVERVIEW ............................................................................. 56
5.2 KEYBOARD DEFINITION......................................................... 56
5.3 CHARACTER CHART............................................................... 57
6 TROUBLESHOOTING ............................................................. 60
1
1 General Information
1.1 Welcome
Thank you for using A15 GSM digital mobile phone.
To guarantee the mobile phone always in its best condition, please read this manual
carefully and keep it for further use.
The pictures, symbols and contents in this manual are just for your reference. They might
not be completely identical with your cellular phone. Please subject to the material object.
ZTE operates a policy of continuous development. We reserve the right to update the
technical specifications in this document at any time without prior notice.
1.2 Security
If your mobile phone is lost or stolen, please report to your service provider or proxy
agencies to ban the use of your lost SIM card and phone, which will protect you
from economic losses resulted from unauthorized use. Note: This service needs
the network to support. You need to provide the IMEI number labeled on the back of
2
the phone to the service provider. You can see the IMEI number after removing the
battery. Please keep the IMEI number for further use.
To protect your mobile phone from illegal use, please take the security measures as
follows:
¾ Set PIN codes of the SIM card.
¾ Set handset lock code.
¾ Take it with you as you can.
1.3 Safety Precautions
This section includes some important information on safe and efficient operation. Please
read this information before using the phone.
Operational Precautions
Please use your phone properly. When making or receiving a call, please hold your
phone as holding a wireline telephone. Ensure the phone is at least 1 inch (2.5
centimeters) from your body when transmitting.
Do not touch the antenna area when the phone is in use. Touching the antenna area
3
affects call quality and may cause the phone to operate at a high power level than
needed.
Some people may be susceptible to epileptic seizures or blackouts when exposed to
flashing lights, such as when watching television or playing video games. If you have
experienced seizures or blackouts, or if you have a family history of such
occurrences, please consult with you doctor before playing video games on you
phone or enabling a flashing-lights feature on your phone. (The flashing-light feature
is not available on all products.)
Keep the phone out of the reach of small children. The phone may cause injury if
used as a toy.
Precautions While Driving
Please pay attention to the traffic safety. Check the laws and regulations on the use
of your phone in the area where you drive. Always obey them.
Use hands-free function of the phone, if available.
Pull off the road and park before making or answering a call if conditions so require.
4
Precautions for Medical Devices and Facilities
When using your phone near pacemakers, please: Always keep the phone more
than 8 inches (20 centimeters) from the pacemaker when the phone is switched on.
Not carry the phone in the breast pocket. Use the ear opposite the pacemaker to
minimize the potential for interference. Switch off the phone immediately if
necessary.
Some phones may interfere with some hearing aids. In the event of such
interference, you may want to consult your hearing aids manufacturer to discuss
alternatives.
If you use any other personal medical device, please consult the manufacturer of
your device to determine if it is adequately shielded from RF energy.
In those facilities with special demand, such as hospital or health care facilities,
please pay attention to the restriction on the use of mobile phone. Switch off your
phone if required.
Mobile phone
Please use original accessories or accessories approved by the phone
5
manufacturer. Using any unauthorized accessories may affect your mobile phone’s
performance, hurt your phone or even cause danger to your body and violate
related national regulations about telecom terminals.
Turn off your phone before you clean it. Use a damp or anti-static cloth to clean the
phone. Do not use a dry cloth or electrostatically charged cloth. Do not use
chemical or abrasive cleaners as these could damage the phone.
As your mobile phone can produce electromagnetic field, do not place it near
magnetic items such as computer disks.
Using the phone near electrical appliances such as TV, telephone, radio and
personal computer can cause interference.
Do not expose your mobile phone to direct sunlight or store it in hot areas. High
temperatures can shorten the life of electronic devices.
Prevent liquid from leaking into your phone.
Do not drop, knock or harshly treat the phone. Rough handling can break internal
circuit boards.
Do not connect the phone with any incompatible enhancement.
6
Do not attempt to disassemble the mobile phone and battery.
Do not store the phone with flammable and explosive articles.
Do not charge the mobile phone without battery.
Precautions for Potentially Explosive Atmospheres
Switch off your phone prior to entering any area with potentially explosive
atmospheres, such as fueling areas, fuel or chemical transfer or storage facilities.
Do not remove, install, or charge batteries in such areas. Sparks in a potentially
explosive atmosphere can cause an explosion or fire resulting in bodily injury or
even death.
To avoid possible interference with blasting operations, switch off your phone when
you are near electrical blasting caps, in a blasting area, or in areas posted “Turn off
electronic devices.” Obey all signs and instructions.
Precautions for Electronic Devices
Some electronic devices are susceptible to electromagnetic interference sent by
mobile phone if inadequately shielded, such as electronic system of vehicles.
Please consult the manufacturer of the device before using the phone if necessary.
7
Safety and General Use in Vehicles
Safety airbag, brake, speed control system and oil eject system shouldn’t be
affected by wireless transmitting. If you do meet problems above, please contact
your automobile provider. Do not place your phone in the area over an airbag or in
the airbag deployment area. Airbags inflate with great force. If a phone is placed in
the airbag deployment area and the airbag inflates, the phone may be propelled
with great force and cause serious injury to occupants of the vehicle.
Please turn off your mobile phone at a refueling point, and the same to the place
where the use of 2-way radio is prohibited.
Aircraft Safety
Please turn off your mobile phone before the airplane takes off. In order to protect
airplane’s communication system from interference, it is never allowed to use
mobile phone when it is in flight. Using mobile phone before the plane taking off
should get aircrew’s permission according to safety regulations.
If the mobile phone has the function of automatic timing power-on, please check
your alarm setting to ensure that your phone will not be automatically turned on
8
during flight.
Battery use
Do not short-circuit the battery, as this can cause overheating to bring about fire.
Do not store battery in hot areas or throw it into fire. Otherwise, it will cause
explosion.
Do not disassemble or refit the battery. Otherwise, it will cause liquid leakage,
overheating, explosion and ignition of the battery.
Please store the battery in a cool dry place if you don’t use it for a long period.
The battery can be recharged for hundreds of times, but it will eventually wear out.
When the operating time (talk time and standby time) is noticeably shorter than
normal, it is time to replace a new one.
Please stop using the charger and battery when they are damaged or show
evidence of aging.
Return the wear-out battery to the provider or dispose of it in accordance with
environment regulations. Do not dispose of it in household rubbish.
9
Exposure to radio frequency energy
Radio wave exposure and Specific Absorption Rate (SAR) information
The handset is designed to comply with safely, requirements for exposure to radio
waves. This requirement is based on scientific guidelines that include safety
margins designed to assure the safety of all persons, regardless of age and health.
The radio wave exposure guidelines employ a unit of measurement known as the
Specific Absorption Rate, or SAR. Tests for SAR are conducted using a
standardized method with the phone transmitting at its highest certified power level
in all used frequency bands.
While there may be differences between the SAR levels of various ZTE phone
models, they are all designed to meet the relevant guidelines for exposure to radio
waves.
The SAR limit recommended is 1.6W/kg averaged over one(1) gramme of tissue.
The highest SAR value for this model phone tested by MORLAB for use at the head
is 0.566 W/kg(1g)
The highest SAR value for this model phone tested by MORLAB for use at the body
is 0.683W/kg(1g)
SAR compliance for body-worn operations is restricted to belt-clips, holsters, or
similar accessories that have no metallic component in the assembly and which
provide at least 1.5 cm separation between the device, including its antenna, and
10
the users body
Warning: If the battery is damaged, keep away from the discharge. If the leakage does
come into contact the eyes or skin, please wash thoroughly in clean water and consult
with a doctor.
11
2 Getting Started
2.1 Key Definition
Left Soft Key
Execute functions of the indicator as showed in the lower left corner of the screen,
or execute select/confirm function.
Right Soft Key
Execute functions of the indicator as showed in the lower right corner of the screen,
or execute exit/clear function.
Send Key
Make and answer calls. Bring out call logs in standby mode.
12
End Key
Finish or reject a call. Power on/off. Return to idle screen or the previous screen in
the menu interface.
Left/Right/Up/Down Key
Up/Down Key: Scroll through the phone number list or setting options. Roll the
cursor up and down when editing. Direction keys in games.
Left/Right Key: Roll the cursor left and right when editing.
OK key: Confirm actions/make selections.
~ 0~9 Number Key
Enter numbers and characters. One-touch dials. Quickly select options when
entering menu. Direction keys in games.
13
* Key, # Key
They are used for various purposes in different functions.
Note: In this manual pressing a key means you press a key and then release it while
holding a key means you press a key and hold on for 2 seconds or more.
2.2 Display Symbols
: Indicate signal strength.
: Displayed when the function to divert all calls unconditionally is enabled.
: Displayed when the Key Lock function is enabled.
: Displayed when roaming within your subscription country.
: Displayed when there are unread messages in the Inbox. Blink when no
14
space for messages.
: Displayed when the mute function is enabled.
: Displayed when an alarm clock has been set.
: Indicate the battery level.
2.3 Technical Parameters
Handset
Type A15
DimensionsW×L×H 44mm×105mm×18mm
Weight Approx. 77g (with standard battery)
Battery 800mAh
Continuous standby time Approx. 60 hours ~ 120 hours (subject to network
status)
Continuous talk time Approx. 2 hours ~ 4 hours(subject to network status)
For other parameters about battery and charger, please refer to the real objects.
15
2.4 Battery
The accessory lithium battery of the handset can be immediately used after unpacking. A
new battery performs best after full charge/discharge cycles for the first three times.
2.4.1 Removing & Installing the Battery
Remove: Push the spring buckle up; Lift the battery and remove it.
Install: Insert the bottom hook of the battery into the back of the phone; Push the
cell until you hear “kaka”.
16
2.4.2 Charging the Battery
17
Plug the travel charger connector into your phone with the arrow facing up. Then
plug the other end of the travel charger into the appropriate electrical outlet.
If the battery is charged in power-on condition, the charging animated indicator bar
starts scrolling at the top right of the screen. If the battery is charged in power-off
condition, the screen will display a charging indicator that indicates the phone is
charging. If the phone is not used for a long time or the battery is completely flat, it
may take a few minutes before this indicator appears.
When the battery level indictor changes from charging symbol to full level indicator,
it means charging has been finished. Generally the whole charge process needs
2~3 hours (Please charge the battery for 6~8 hours for the first three times). During
the charge process, your phone, battery and charger may become hot, and this is a
normal phenomenon.
Please disconnect the charger with the phone and the power outlet when charging
finished.
Warning:
18
Please put the phone at the ventilated place with temperature between 5~40
. Please use charger approved by the phone manufacturer. Using unauthorized
charger may cause danger and violate the authorization and warranty rules
applying to the phone.
Please charge the battery in time when your phone is automatically switched off or
displays a warning “battery is low”.
The phone’s talking time and standby time are based on ideal working
environments. In practice, the battery work time varies with different network
conditions, work environments and modes.
2.5 Connecting to the Network
2.5.1 SIM Card
Please insert a valid SIM card (user identification card) into the phone before using it.
Everything about setting connection to the network and your call logs is initialized and
saved in the SIM card, together with information in your Names stored in the SIM card.
This SIM card can be used by any GSM mobile phone (A new phone can read the SIM
19
card automatically).
Don’t touch the metal surface of the SIM card in case that information in the card may be
lost or destroyed. Keep the card away from electricity and magnetism.
Warning: Please power off your phone before changing the SIM card. Inserting or
removing the SIM card is forbidden when it is connected to the outer power source.
2.5.2 Inserting & Removing SIM Card
Power off your phone, disconnect the outer power source and remove the battery.
20
Slide the SIM card into the SIM card slot.
Please power off your phone before you remove your SIM card.
2.5.3 Power on/off Your Phone
Hold End Key to power on/off the phone.
The mobile phone will automatically test whether the SIM card is plugged in and valid
after power on, then the screen will display the following messages in turn
Enter PIN ——if SIM card password has been set.
Unlock-Enter Lock Code ——if handset lock code has been set.
Searching ——search for the network.
2.5.4 Unlocking the SIM Card and Mobile Phone
By setting PIN (personal identification number) code of SIM card and handset lock code,
you can protect your SIM card and phone from illegal use.
Method to unlock the SIM card: Enter PIN code and end with OK.
If you enter an incorrect PIN code three times in a row, your SIM card will be locked by the
network and the phone will ask for PUK code.
21
Note: Your network service provider will set a standard PIN code (4-8 digits) for your SIM
card; please change it with your private password as soon as possible.
Method to unlock the phone: Enter handset lock code and end with OK.
Note: If you forget your handset lock code, please connect with your distributor or the
authorized local customer service center.
Please refer to Section “Security Settings” for details.
2.5.5 Connecting to the Network
After the SIM card and the phone are unlocked, the mobile phone will automatically
search for the network. (The screen displays “Searching for network”.)
After a few seconds, you will be registered on the network. Now your phone is in standby
22
mode. Besides receiving and sending calls, you can do the following things:
Press Right Soft Key to enter the Names.
Press Left Soft Key to enter the function menu, please refer to Chapter 4 “Function
Menu”.
You can customize the fastkey settings of Up/Down/Left/Right Key for standby
mode.
Note: If “Emergency only” or “SOS” is shown on your screen, you can only send
emergency calls.
Note: In standby mode, press # Key and then press * Key within 2 seconds to lock
the keypad of the phone. The steps are the same as when unlocking the keypad.
This feature is used to prevent the keys being accidentally pressed. When the
keypad is locked, you can also answer calls normally.
23
3 Basic Operations
3.1 Making a Call
You can make or answer calls in standby mode. The information bar in the upper left
corner of the screen shows the network signal strength.
Making DDD: Enter telephone number by Number Keys (add area code when
making a long distance call), and then press Send Key to send a call. Hang up the
phone by End Key if the call is over.
Dialing extension number:
Method 1: Dial the telephone exchange and then the extension number according to
24
prompt.
Method 2: Enter the telephone exchange number, hold # Key to enter pause character
“P”, enter the extension number, and then press Send Key. Then your phone will dial the
extension automatically after getting through the exchange. Like this:
Area code Exchange number P Extension number Send Key
Making IDD: Hold * Key until your screen displays the character “+” (replaces the
international access code), then enter the country code and complete phone
number and then press Send Key.
Dialing the number in the List: Generally, all calls you have made or received are
saved in a list of the phone. All numbers are grouped as Dialled Calls, Received
Calls and Missed Calls. Your mobile phone lists all the numbers so that you can
view all the call logs. When the list is full, old numbers will be deleted automatically.
You can check the list by the following operations:
¾ View All Calls by Send Key.
¾ To vi e w Received Calls or Missed Calls depends on the fastkey settings.
¾ Directly dial all the numbers in the list by Send Key.
25
¾ When there is a list of phone numbers, you can press Options to enter the
numbers list submenu.
Note: Up/Down Key shortcuts can be customized in Settings-Phone Settings-Fastkey
Setting.
3.2 Answering a Call
Generally, press Send Key or Left Soft Key to answer an incoming call. If Anykey
Answer is set On, you can press any key (except End Key /Right Soft Key) to answer a
call.
3.3 Call Menu
During a call, you can enter the call menu by pressing Menu. The operation methods are
the same as those in function menu. Call menu can be seen only in the process of
communication and those functions such as Call waiting, Call keeping, Multiparty need
the network to support. If you need those services, please contact your network service
provider.
If you couldn’t answer a call, press Busy to send busy tone to the caller.
26
You can do the following operations in the call menu:
Hold/ Retrieve Keep the current call/Resume the kept call.
Swap Switch between the current call and the kept call.
Names Display information in the Names.
Speaker Volume Adjust earpiece volume.
Mute Don’t send local voice.
DTMF On/Off Enable or disable sending DTMF tone.
Multiparty
¾ Join All Calls Add the current call to Multiparty.
¾ Hold All Calls Hang on all calls.
¾ Private Converse with one side privately and keep the session with the other
one.
¾ Exclude Keep one call from Multiparty.
¾ End All Calls End up the current call and the hang-on calls.
Note: Some menu items can only appear in special cases. Menu items such as Swap will
27
appear only when the ongoing call and the hang-on call coexist at the same time.
28
4 Function Menu
4.1 Usage and Structure of Function Menu
Scrolling search function: Enter the Function main menu by pressing Menu in
standby mode. Enter the call menu by pressing Menu in call state. Pressing
Up/Down Key to select in menu interface.
In function menu, you can select or quit some menu by pressing Left Soft Key or
Right Soft Key according to the prompt displayed on the screen.
Function menu includes items as follows: Short Message, Phone Menus, Profiles,
Settings, Toolkit, Games. In standby mode, press Names to enter the Names interface.
Please look for details in this chapter.
29
4.2 Short Message
If the network supports and you have subscribed this service, you can send and receive
text short messages freely. And you also can subscribe a voice mailbox to receive
voicemail. Please contact your service provider for details.
In standby mode, press Menu, select Short Message then press OK Key to access the
Short Message menu interface.
Short Message submenu includes: New Msg, Inbox, Outbox, Msg Settings, Voice
Mail and Cell Info.
When a new message comes, your phone will ring to notify you. The number of
messages your phone can save is subject to the SIM card capacity and the handset
capacity.
Creating Messages
30
Please ensure message service center number has been set before writing messages.
¾ In message interface, select New Msg and press Select to access message
input interface to enter the message. (Please refer to Chapter “Text Input”.)
¾ When you finish entering the message, press Options, and then use Up/Down
Key to select Send to One, Send to Many or Save.
¾ Select Save to save messages to the SIM card. When saving, you can directly
input the destination number according to prompts on the screen, or press Names
to select a number in the Names. Select Send to One, you can directly enter the
receiver’s number, or press Names to select a number in the Names. Select Send
to Many, enter the group list, select one group and then select the receivers’
numbers. There will be prompt information on the screen after the message is sent
successfully.
Note: The SMS centers of some cities and regions do not support messages longer than
160 English characters.
Viewing Received messages and Saved messages
¾ Select Inbox to check received short messages; select Outbox to check short
31
messages saved in the Outbox, and use Up/Down Key to select in the message
list.
¾ In the message list, press Read to view the message details; press Options to
do the following operations:
z Text Reply: Reply messages to the sender. (The menu appears only when
reading messages in the Inbox.)
z Delete: Delete the current message.
z Forward: Transfer messages to others.
z Voice Reply: Call the sender. (The menu appears only when reading
messages in the Inbox.)
z Extract No.: Extract numbers from the message text and the sender’s
number, and then list them on the screen. If you select one, the number will be
displayed on the dialing interface for editing or dialing.
¾ Delete all: Delete all the received or saved messages.
Message Settings
You must set up necessary SMS information before using message functions. Access
32
Msg Settings submenu:
¾ Templates: When editing messages, set idioms can be brought out by holding *
Key. In this menu, you can edit or change these phrases.
¾ Select Msg Centre, input the short message service center number (You must
obtain this number from your service provider.), and then press Save to store the
number.
¾ Msg Validity: In the period of validity, the message center will repeat to deliver a
message till it is received. Press Up/Down Key to select a valid time and then
press Select to confirm. Note: This function needs the network to support.
¾ Status Report: If the Status Report is set On, a message report will be sent to
inform you after the sent message has reached the destination. Note: This function
needs the network to support. There is no status report when you select Send to
Many option.
¾ Used Space: Check the total amount of messages that has already been stored
and can be stored at most in the SIM card and the handset.
Voice Mail
33
Select and access Voice Mail submenu:
¾ Select Get Voicemail to check the voicemail box and listen to the voice
message.
¾ Voicemail No.: Set the voice mailbox number.
Cell Information
¾ Select Settings to access, and then select language and subjects you are
interested. In the subjects interface, select Current List option to set or select
Create Subject to define a new subject.
¾ When cell information comes, you can view them one by one by Read Info
Message option in the menu.
4.3 Phone Menus
34
In standby mode, press Menu, select Phone Menus and then press OK Key to access
the Phone Menus interface.
4.3.1 Call Logs
View calls list
¾ Select All Calls to view all calls list.
¾ Select Missed Calls to view the calls that you received but did not answer.
¾ Select Received Calls to view the calls that you answered.
¾ Select Dialled Calls to view calls that you made.
In the calls list interface, press Options to access the detailed submenus:
¾ Send Message: Send short messages to the number. The operation is the
same as when creating messages.
¾ IP Dial: Press IP Dial to prefix the IP code to the number you want to dial if IP
code has been set before.
¾ Detail: Check the details of the number.
¾ Save: Save the number to the SIM card or the handset.
35
¾ Add to Blacklist: Add the number to the black list.
Call Duration: Check the last call duration and the total call duration. And you can
reset the timer.
Call Costs: Select Last Call/All Call Info check the last call cost and the total call
costs. Select Clear Logs to clear all the costs information. Select Cost Units to
read or set cost unit. Select Max Cost to read or set the limitation of call charge.
Note: This function needs the network to support.
4.3.2 Diverts
This service enables you to divert some incoming calls to other preset numbers. Please
contact your service provider for details.
Set Diverts: Set diverts in different conditions.
¾ All Calls: Divert all incoming calls unconditionally.
¾ When Busy: Divert incoming calls when the line is busy.
¾ No Answer: Divert incoming calls when there is no answer.
¾ Unreachable: Divert incoming calls when the handset is turned off or out of the
36
network service area.
After choosing one of the above 4 options, select By Service and then select one of the
following options, you can set to divert which service to the preset number:
¾ All Services: Divert incoming calls, voice calls and short messages.
¾ Voice Calls: Only divert voice calls.
¾ Data: Only divert data.
¾ Fax: Only divert faxes.
¾ Messages: Only divert short messages.
¾ All Except Msgs: Diverts all services except messages.
When you have set conditions and types of divert services, the following can be chosen:
¾ On: Only registered services are functional.
¾ Off: Delete the divert service.
¾ Status Check: Query if the service is active.
Cancel all diverts
Enter the divert interface, use Scroll Key to select Cancel All to cancel all diverts
services.
37
4.3.3 Firewall
4.3.3.1 Incoming Calls Bar
Friend List: Press Select to access.
¾ If you have not added anything, the screen displays “List empty”. Press Add to
enter the adding interface, add the friend number and then press OK to save.
¾ If you have added something, you can directly enter the friend list. Press
Options to select such options: Add, Edit or Delete.
Black List: Press Select to access.
¾ If you have not added anything, the screen displays “List empty”. Press Add to
enter the adding interface, add a number and then press OK to save.
¾ If you have added something, you can directly enter the black list. Press
Options to select such options: Add, Edit or Delete.
Current Settings: Press Select to access and the following options are displayed:
Bar All, Bar Blacklist, Friend Only and Cancel All.
38
4.3.3.2 Outgoing Calls Bar
Before entering the function, you need to enter handset lock code first. Please refer to
Section “Security Settings” for the password. The default lock code is 1234.
Current Settings:
¾ Bar All: Bar all outgoing calls except emergency calls.
¾ Bar List: Bar all numbers in the barred list and all the numbers beginning with
any number in the barred list.
¾ Cancel All: Cancel the restriction on outgoing calls.
Barred List: Directly enter the list, press Options to select Add/Edit/Delete, and
you can select Clear prefix option in the end of the list to delete all the logs. If you
have not added anything, the screen displays “List empty”. Press Add to add phone
number and then press OK to save.
39
4.4 Profiles
In standby mode, press Menu, select Profiles and then press OK Key to access the
profiles interface.
You can select the profile you need in this submenu. The profile options are: Normal,
Outdoor, and Silent. These profiles have been set before leaving factory. You can
change them in the Personalise submenu.
Access the Personalise submenu, change the detailed settings of the selected profile,
including: Alert Type, Ringing Tone, Ringing Volume, Speaker Volume, Key Tone, Warn
Tone, Missed Alert, Message Alert and Power on/off Ring.
Alert Type: This option determines the notification mode. You can select from Ring
and Silent.
Ringing Tone: Many polyphonic ring tones for selection.
40
Ringing Volume: Adjust the volume of the ring tone by Left/Right Key and press
OK Key to save the change.
Speaker Volume: Adjust the volume of the earpiece by Left/Right Key and press
OK Key to save the change.
Key Tone: Select to turn on/off key tone.
Warn Tone: Select On to set the phone to sound tones, for example, when the
battery is running out of power, or turn off the tone.
Missed Alert: Select On to set the phone to sound tones when there is a missed
call, or turn off the tone.
Message Alert: Select the alert tone type when a new message is coming or select
to turn off the alert tone.
Power on/off Ring: Select to turn on/off the tone ringing when the phone is
switched on/off.
41
4.5 Settings
In standby mode, press Menu, select Settings and then press OK Key to access the
settings interface.
4.5.1 Phone Settings
Select and enter the Phone Settings submenu.
Language: Press Select to change the current language for the displayed texts
according to your needs.
Own Number: Edit/view your own phone number.
Fastkey Setting: Set the shortcut menu content corresponding to
Up/Down/Left/Right Key in standby mode.
Auto Lock: If you select On, the keypad is automatically locked after a certain
42
length of time in standby mode. You can unlock the keypad according to the prompt
on the screen. Select Off to disable this function.
4.5.2 Display Settings
Backlight: Select to turn on/off the backlights of the screen and the keypad.
4.5.3 Clock Settings
You can set date and clock.
Date & Time: Use Scroll Key to switch between year, month, day and time. Date
can be set from January 1, 2005 to December 31, 2055. Time can be set from 00:00
to 23:59. After correctly inputting the date and clock settings, press OK to confirm
and exit.
Date Format: Set the date displayed format.
4.5.4 Call Settings
Access Call Settings menu.
Anykey Answer: If “On” is selected, you can answer the call by pressing any key
except End Key and Right Soft Key.
43
Minute Minder: Select to sound an alert notification 5 or 10 seconds ahead of
every 1 minute after call connection, or select Off.
Connected Minder: Select to turn on/off alert tone when the dialed call is
connected.
DTMF Tones: Select to turn on/off DTMF Tones.
Call Waiting: Select On/Off to enable/disable this function; select Status to query
the current status of this function. When enabled, the network will notify you of a
new incoming call while you have a call in progress. Please contact the network
service provider for details.
IP Setting: You can set an IP code. In this case, you can use the IP function in the
Names, and the IP code will be automatically added before the phone number that
you want to dial.
4.5.5 Network Settings
In this menu, you can select Automatic/Manual to select the network service provider
according to needs.
44
If you have selected a service provider manually, you have to manually select again or
return to the Automatic option to select the service provider when you switch to the SIM
card of another network.
4.5.6 Security Settings
Security features protect you from illegal use of your phone and SIM card.
Note: You need to input handset lock code to enter security settings interface. The default
handset lock code is 1234. Please change it with your own private password as soon as
possible.
SIM Password: SIM password (PIN code) can prevent your SIM card from illegal
use. Select On/Off to enable or disable SIM password protection; select Change
PIN to set a new PIN code.
Note: Three consecutive times of wrong PIN code inputting will lock the SIM card. Then,
the PUK code is needed to unlock the SIM card. The PIN code and the PUK code may be
provided to you together with the SIM card. If not, please contact with your network
service provider. The default PIN code is 1234. Please change it with your own private
45
password as soon as possible.
Handset Lock: Handset Lock can prevent your mobile phone from unauthorized
use. Select On/Off to enable or disable the handset lock protection; select Change
Code to set a new handset lock code.
Note: The default handset lock code is 1234.
Network Call Bar: You can set any combination of the following call restriction
options to improve security level. Please contact with the network service provider
for details. The network service provider provides a 4-digit network password to
enable your call restrictions.
¾ International Call: Bar all international calls.
¾ All Except Home: Bar international calls except local calls.
¾ Incoming Calls: Bar all incoming calls.
¾ Incoming If Abroad: Bar all incoming calls when roaming abroad.
¾ Outgoing Calls: Bar all outgoing calls.
After choosing one of the above options, select Select to restrict any of the following
services:
46
z All Services: Restrict incoming calls, voice calls and short messages.
z Voice Calls: Only restrict voice calls.
z Data: Only restrict data.
z Fax: Only restrict faxes.
z Messages: Only restrict short messages.
z All Except Msgs: Restrict other services except short messages.
When you have set types of restriction services, the following can be chosen:
z On: The restriction is functional.
z Off: Delete the restriction.
z Status: Query if the restriction is set.
¾ Cancel All: Select Cancel All to cancel all set call restrictions.
Note: You need to input network password to set or cancel network restrictions. Three
consecutive times of wrong network password inputting will lock the call restrictions
service. Please contact the network service provider to unlock it.
47
4.5.7 Factory Settings
In this menu, you can select to restore the related settings of the phone to factory settings.
4.6 Toolkit
In standby mode, press Menu, select Toolkit and then press Ok Key to access the
Toolkit interface.
Alarm Clock: The phone provides Power On/Power Off/Normal alarm clock
services.
Calculator: The phone provides simple calculating functions, such as addition,
subtraction, multiplication and division.
Stopwatch: The phone provides a stopwatch function.
World Clock: The phone allows you to check time information on major cities
48
worldwide.
4.6.1 Alarm Clock
Your phone can set up to 5 alarm clocks at the same time.
Set alarm: Select Set Alarm submenu, you can set the following options according
to instructions: alarm type (Normal/Daily/Weekly/Workday Alarm), date, time,
power-on/power-off/normal, and alert tone.
View alarms list: Select List Alarms submenu, use Up/Down Key to select the
desired alarm clock, press Options to enter the submenu list, and then select Edit
to view/edit the alarm clock settings, or select Delete to delete it, or select
Enable/Disable to enable/disable it.
Clear All: Select Clear All to clear all the alarm settings.
Define Rest Day: Select Define Rest Day to set or change the settled days off in a
week. The preset Workday Alarm will not sound at the defined rest day. Press
Up/Down Key to select and then press Right Key to set or cancel the rest day
setting.
49
Note: The Normal Alarm service is available only when the phone is switched on. When
the phone is switched off, the Normal Alarm service doesn’t work. The function of Power
on means to set the phone to switch itself on at the desired time, and the function of
Power off means to set the phone to switch itself off at the desired time.
4.6.2 Calculator
Press 0~9 Number Keys to enter numbers, press # Key to enter decimal point.
Press Left Soft Key to switch among +, –, ×, ÷.
Press Clear to clear the last digit or results. Press End Key to exit the calculator.
Press Equal to get results.
Note: This calculator has limited accuracy and rounding errors may occur, especially in
long division.
4.6.3 Stopwatch
Select Stopwatch to access the timing interface, press Start to start to measure, and
then press Stop to stop the timing and view the measured duration of time. Press Reset
to resume the stopwatch.
50
4.6.4 World Clock
Enter World Clock, you can view the time of desired city by using Scroll Keys. Press
Save to save the selected city time as local display and press End Key or Exit to quit.
4.7 Games
In standby mode, select Menu-Games, and then press OK Key to access the Games
interface.
Tetris: The options are as follows:
¾ New Game: Start a new game.
¾ Set Lines: Select the original lines of the game.
¾ Help: Check the rules and instructions for the game.
Push Box: The options are as follows:
51
¾ New Game: Start a new game.
¾ Load Game: Read the saved game records.
¾ Help: Check the rules and instructions for the game.
4.8 Names
In standby mode, access the Names interface by pressing Right Soft Key.
It shows List empty when there is no record in the Names, you can add records by
pressing Options-Add New Name. You can select the save position: SIM card or
Handset. The saved records will be ordered by the name. In that case, press # Key to
switch between the sort modes.
Press Up/Down Key to check the records. In the viewing interface, press Send
Key to dial the number.
In the Names list interface, press Right Key to check the details of the record. In
the detailed information interface, press Options to access the menu interface of
the selected record. The menu options are as follows:
¾ Send Message: Access the creating message interface.
52
¾ Edit: Edit the record.
¾ Delete: Select whether to delete the record.
¾ IP Dial: If IP code has been set in advanced, the phone will automatically prefix
IP code to the number you want to dial while you select IP Dial option.
¾ Add to Speed: You can assign the phone number to a speed-dialling key. Scroll
to the desired key and press Select to assign. Then, you can hold the selected
number key to directly dial the number in standby mode. In the speed dialling keys
list, press Delete to delete the assignment.
¾ Copy to SIM/MS: Copy the record to the SIM card or the handset.
¾ Move to SIM/MS: Move the record to the SIM card or the handset.
¾ Add to Blacklist: Add the record to the blacklist.
¾ Add to Friendlist: Add the record to the friend list.
Whether saved in the SIM card or the handset, one name only can correspond to one
number. Records saved in the SIM card are sorted into an independent group. If the user
doesn’t appoint the record to any group, the record will be sorted into the No Group.
Besides, there are six groups for selection: Family, Friend, Colleague, Schoolmate,
53
Society and VIP.
4.8.1 Searching
In the Names list interface, press Options, select Search and then enter the name
you want to search.
Quick-search: In the Names list interface, you can press Number Keys to go to the
record of the name with similar initials.
¾ Switch method: Press # Key to switch between searching modes.
¾ Sort principle: Sort by ASCII Code in English mode.
¾ Match principle: If match, go to the character; if not, go to the next.
4.8.2 Editing
In the Names list interface, press Options and select Edit. You can edit the current
record including the name, the number and the group.
4.8.3 Deleting
In the Names list interface, press Options and select Delete, you can delete all the
information of the current record.
54
4.8.4 Making an IP Call
In the Names list interface, press Options and select IP Dial. If IP code has been set in
advanced, the phone will automatically prefix IP code to the number you want to dial after
you select IP Dial option. If not, there will be a prompt on the screen: Please set IP. Please
refer to Section 4.5.4 for IP setting.
4.8.5 Adding New Name
In the Names list interface, press Options and select Add New Name. You can decide to
save new number into SIM card or Handset, then press Ok to confirm.
If SIM card is selected to save new number, you need:
Enter the phone number you want to add.
Enter the name you want to add.
If Handset is selected to save new number, you need:
Enter the phone number and then press Ok.
Enter the name you want to add and then press Ok.
Select the group.
55
4.8.6 Settings
Ringing Tone: Set different alert tones for different groups to distinguish.
Save No. to: Select SIM card/Choice/Phone memory to save numbers.
Used Space: Check the total amount of phone numbers that has already been
stored and can be stored at most in the SIM card and the handset.
Speed Dial List: Check the set speed-dialling keys list.
4.8.7 Batch Operation
Copy SIM to mem., Copy mem. To SIM, Move SIM to mem., Move mem. to SIM: This
function provides you to batch copy or move all the numbers saved in the SIM card or the
handset. When copying or moving, there will be a prompt on the screen if the destination
space is full.
Delete All In SIM, Delete All In Phone: Delete all the records in the SIM card or the
handset. Note: The number is once deleted and will never be retrieved. Please be careful
to use this function.
56
5 Text Input
5.1 Overview
Your mobile phone provides the following input methods: upper and lower case input,
numeric input and punctuation mark or special characters input.
Entries where characters can be entered are as follows:
Entering/Editing short messages.
Entering/Editing Names.
Searching for phone numbers in the Names.
Editing preset idioms.
5.2 Keyboard Definition
The general keyboard is defined as follows
Left Soft Key: Usually means Select or Ok.
Right Soft Key: Usually means Delete, Exit or Cancel.
Scroll Keys: Usually used for moving cursor and paging selected word up/down.
57
# Key is used to switch among different input modes.
* Key: In input mode, press * Key to bring out symbol entering. When inputting
short messages, hold * Key to bring out preset idioms.
Entering Idioms: In the original screen when creating messages, press Idiom to
enter the idioms selecting interface.
5.3 Character Chart
Use this character as a guide for entering spaces, numbers, letters, symbols, and other
characters.
Key Corresponding Characters Notes
1 1 and some common symbols
2 ABCabc2
3 DEFdef3
4 GHIghi4
5 JKLjkl5
6 MNOmno6
58
7 PQRSpqrs7
8 TUVtuv8
9 WXYZwxyz9
0 Space 0
* Key Press * Key to bring out symbol entering.
# Key Switch among input methods.
Up/Down Key Roll the cursor up/down.
Left/Right Key Roll the cursor left/right.
Left Soft Key Select or confirm the option.
Right Soft Key Exit, delete or cancel the last inputting.
End Key Exit
Using Alphabet input by the following steps:
Each key corresponds to multiple letters. Press the key until the letters appear.
When the cursor moves, enter the next letter.
Use # Key to switch among input methods.
59
In other input modes except numeric input mode, press 0 Key once to enter space.
In numeric input mode, space cannot be entered.
Use Clear to clear errors.
60
6 Troubleshooting
Is it a malfunction? If you have a problem with your phone, first refer to this
Troubleshooting Guide as you check with your phone. If you can’t solve, please contact
your dealer.
1. “Enter PIN” is shown when the phone is switched on.
Input the PIN1 code or input the new PIN if you have changed the code. The code can be
set “Off” if you do not want to input. (Please refer to Section “Security Settings”.)
2. “Insert SIM card” is shown when the phone is switched on.
Turn off your phone and make sure that you have inserted a valid SIM card.
3. “Unlock” is shown when the phone is switched on.
Press Unlock, enter the handset lock code or the new code if you have changed it, and
then press Ok.
4. No key tone when pressing keys.
Check the key tone setting in the profile.
61
5. No incoming ring tone.
Check the ringing tone and ringing volume settings in the profile.
6. No alarm tone when the reminder time reaches.
Check the profile setting and the alarm ring setting.
7. A phone number cannot be dialed.
Check whether call restriction is set to the number. Please refer to Section “Outgoing
Calls Bar”.
8. A phone call cannot be answered.
Check the “Black List” in the Firewall menu. Please refer to Section “Incoming Calls Bar”.
9. Short message cannot be sent.
Check the Msg Centre setting in the Message-Msg Settings menu.
