ZTE ZTEMF710 HSPA+ USB MODEM User Manual MF710 UserMan
ZTE Corporation HSPA+ USB MODEM MF710 UserMan
ZTE >
user manual
MF710
HSPA+ USB MODEM
Quick Guide
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
LEGAL INFORMATION
Copyright © 2013 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by
any means, electronic or mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications on print
errors or update specifications without prior notice.
Version No. : R1.0
Confidential and Proprietary Information of ZTE CORPORATION 1
Getting to know your device
Your device supports data and SMS services through the mobile phone network, enabling you to
communicate anytime and anywhere.
The following figure is only for your reference. The actual product may be different.
1. Modem Cap
2. Front Cover
3. Indicator
4. microSD Card Slot
5. SIM/USIM Card Slot
6. USB Connector
NOTE: microSD is a trademark of SD Card Association.
Installation Guide
Installing SIM/USIM Card
1. Slide the front cover and remover it.
2. Insert the SIM/USIM card into the SIM/USIM card slot as shown below.
IMPORTANT: Your device supports Micro/Nano SIM card. To avoid device damage, please use original
or authorized card holder while installing.
MF710 Quick Guide
2 Confidential and Proprietary Information of ZTE CORPORATION
3. Insert the microSD card into the microSD slot.
4. Put the front cover upon the body of the modem after directing it towards the locking catches, and then
push the front cover to lock it in place.
Connecting the Modem to Your PC
1. Plug the USB connector into the USB port and make sure it is tightly inserted.
2. The OS automatically detects and recognizes new hardware.
Installing Software
On different operating systems, the installation may be different. Follow the system prompts during the
process.
For Windows OS
Your system will start the software setup process automatically when you connect the modem to your
computer correctly. Follow the system prompts to complete the software installation.
MF710 Quick Guide
Confidential and Proprietary Information of ZTE CORPORATION 3
NOTE: If the system does not launch installation automatically, you can run the installation program in
path of My Computer > ZTEMODEM.
For Mac OS
The system will automatically display a CD-ROM icon on the desktop when you connect the modem to
your computer correctly. Double click the installation package in the CD-ROM, and follow the system
prompts to complete the software installation.
Warning and Notice
To the owner
• Some electronic devices are susceptible to electromagnetic interference sent by modem if inadequately
shielded, such as the electronic system of vehicles. Please consult the manufacturer of the device before
using the modem if necessary.
• Operating of laptop and desktop PCs and the modem may interfere with medical devices like hearing
aids and pacemakers. Please always keep them more than 20 centimeters away from such medical
devices when they are turned on. Turn the modem off if necessary. Consult a physician or the
manufacturer of the medical device before using the modem.
• Be aware of the usage limitation when using a modem at places such as oil warehouses or chemical
factories, where there are explosive gases or explosive products being processed. Turn off your modem
if required.
• The use of electronic transmitting devices is forbidden in aircrafts, at petrol stations and in hospitals.
Please observe and obey all warning signs and switch off your modem in these conditions.
• Do not touch the inner antenna area if not necessary. Otherwise it will affect your modem’s performance.
• Store the modem out of the reach of little children. The modem may cause injury if used as a toy.
• Do not touch the metallic parts of the modem so as to avoid a burn, when the modem is working.
Using your USB Modem
• Please use original accessories or accessories that are authorized. Using any unauthorized accessories
may affect your modem’s performance, and violate related national regulations about telecom terminals.
• Avoid using the modem near or inside metallic structures or establishments that can emit
electromagnetic waves. Otherwise it may influence signal reception.
• The modem is not waterproof. Please keep it dry and store in a shady and cool place.
• Do not use the modem immediately after a sudden temperature change. In such case, it will produce dew
inside and outside the modem, so don’t use it until it becomes dry.
• Handle the modem carefully. Do not drop, bend or strike it. Otherwise the modem will be damaged.
• No dismantling by non-professionals and only qualified technicians can undertake repair work.
• Operating temperature range of -10℃ ~ +55℃ and humidity range of 5% ~ 95% are recommended.
Limited Warranty
• This warranty does not apply to defects or errors in the Product caused by:
i. Reasonable abrasion.
ii. End User’s failure to follow ZTE’s installation, operation or maintenance instructions or procedures.
iii. End User’s mishandling, misuse, negligence, or improper installation, disassembly, storage,
servicing or operation of the Product.
MF710 Quick Guide
4 Confidential and Proprietary Information of ZTE CORPORATION
iv. Modifications or repairs not made by ZTE or a ZTE-certified individual.
v. Power failures, surges, fire, flood, accidents, actions of third parties or other events outside ZTE’s
reasonable control.
vi. Usage of third-party products, or usage in conjunction with third-party products provided that such
defects are due to the combined usage.
vii. Any other cause beyond the range of normal usage intended for the Product.
End User shall have no right to reject or return the Product, or receive a refund for the Product from
ZTE under the above-mentioned situations.
• This warranty is End User’s sole remedy and ZTE’s sole liability for defective or nonconforming items,
and is in lieu of all other warranties, expressed, implied or statutory, including but not limited to the
implied warranties of merchantability and fitness for a particular purpose, unless otherwise required
under the mandatory provisions of the law.
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages
resulting from or arising out of or in connection with using of this product, whether or not ZTE had been
advised, knew or should have known of the possibility of such damages, including, but not limited to lost
profits, interruption of business, cost of capital, cost of substitute facilities or product, or any downtime
cost.
Radio Frequency (RF) Energy
This device meets the government’s requirements for exposure to radio waves. This device is designed
and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the
Federal Communications Commission of the U.S. Government. The exposure standard for wireless device
employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the
FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating positions accepted by the FCC
with the device transmitting at its highest certified power level in all tested frequency bands. Although the
SAR is determined at the highest certified power level, the actual SAR level of the device while operating
can be well below the maximum value. This is because the device is designed to operate at multiple power
levels so as to use only the poser required to reach the network. In general, the closer you are to a wireless
base station antenna, the lower the power output. SAR compliance has been established in the host
product(s) (laptop computers), tested at 5mm separation distance to the human body, and tested with USB
slot configurations including Horizontal-UP, Horizontal-Down, Vertical-Front, Vertical-Back. This device
can be used in host product(s) with substantially similar physical dimensions, construction, and electrical
and RF characteristics. The highest SAR value, tested per FCC RF exposure guidelines for USB dongle,
as described in this user guide, is 1.18 W/kg. The FCC has granted an Equipment Authorization for this
device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines.
SAR information on this device is on file with the FCC and can be found under the Display Grant section
of www.fcc.gov/oet/ea/fccid after searching on FCC ID: Q78-ZTEMF710.
FCC Compliance
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiated radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation If this equipment does cause harmful interference to radio or television reception, which can
MF710 Quick Guide
Confidential and Proprietary Information of ZTE CORPORATION 5
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
For CE
It is hereby declared that following designated product:
Product Type: HSPA+ USB MODEM
Model No: MF710
Complies with the essential protection requirements of the Radio and Telecommunication Terminal
Equipment Directive (EC Directive 1999/5/EC).
This declaration applies to all specimens manufactured identical to the samples submitted for
testing/evaluation.
Assessment of compliance of the product with the requirements relating to the Radio and Telecommunication
Terminal Equipment Directive (EC Directive 1999/5/EC) was performed by ATCB (Notified Body
No.1588), based on the following standards:
Safety EN 60950-1:2006+A11:2009+A1:2010+A12:2011;
EMC EN301489-1V1.9.2
/
ETSI EN 301 489-7 V1.3.1
/
ETSI EN 301 489-24 V1.5.1;
Radio EN301908-1/-2 V5.2.1;
EN 301511 V9.0.2
Health EN 62311:2008; EN 62209-2:2010
This declaration is the responsibility of the manufacturer:
ZTE CORPORATION
ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park,
Nanshan District,Shenzhen, Guangdong, 518057, P.R.China
MF710 Quick Guide
6 Confidential and Proprietary Information of ZTE CORPORATION
How to get help
You can get Help by:
• Send E-mail to mobile@zte.com.cn
• Visit http://www.zte.com.cn
• Call Service Hotline: +86–755–26779999
