ZTE ZTEV10VITA Mobile Phone (BT/WIFI/GSM/WCDMA/LTE) User Manual Quick Start Guide V1

ZTE Corporation Mobile Phone (BT/WIFI/GSM/WCDMA/LTE) Quick Start Guide V1

Contents

Quick Start Guide V1

1
ZTE Blade V10 Vita
Quick Start Guide
2
LEGAL INFORMATION
Copyright © 2019 ZTE CORPORATION.
All rights reserved.
No part of this publication may be quoted, reproduced,
translated or used in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without the
prior written permission of ZTE Corporation.
Notice
ZTE Corporation reserves the right to make modifications on
print errors or update specifications in this guide without prior
notice.
We offer self-service for our smart terminal device users.
Please visit the ZTE official website (at
www.ztedevices.com) for more information on self-service
and supported product models. Information on the website
takes precedence.
Disclaimer
ZTE Corporation expressly disclaims any liability for faults
and damages caused by unauthorized modifications of the
software.
Images and screenshots used in this guide may differ from
the actual product. Content in this guide may differ from the
3
actual product or software.
Trademarks
ZTE and the ZTE logos are trademarks of ZTE Corporation.
Android™ is a trademark of Google LLC.
The Bluetooth
®
word mark and logos are registered
trademarks owned by the Bluetooth SIG, Inc. and any use of
such marks by ZTE Corporation is under license.
microSDXC Logo is a trademark of SD-3C, LLC.
Other trademarks and trade names are those of their
respective owners.
Version No.: R1.0
Edition Time : December 05, 2018
4
Getting to Know Your Phone
Front camera
Touch screen
Earpiece Proximit
y
sensor
Volume up key
Power key
Flash
Charging/
micro-USB
j
ack
Headset
j
ack
Dual-lens
camera
Speake
r
Indicator light
Main
microphone
Light senso
r
Volume down key
Fingerprint
senso
r
nano-SIM /
nano-UIM /
microSDXC
card tray
Auxiliary
microphone
5
Installing the nano-SIM Card and the
microSDXC™ Card (Optional)
The nano-SIM card can be installed or removed while the
phone is turned on.
WARNING!
To avoid damage to the phone, do not use any other kind of
SIM cards, or any non-standard nano-SIM card cut from a
SIM card. You can get a standard nano-SIM card from your
service provider.
1. Insert the tip of the tray eject tool into the hole next to the
card tray.
2. Pull out the card tray and place the nano-SIM card and
the microSDXC card on the tray, as shown. Carefully
slide the tray back into place.
6
Charging the Phone
Your phone’s battery should have enough power for the
phone to turn on, find a signal, and make a few calls. You
should fully charge the battery as soon as possible.
WARNING!
Use only ZTE-approved chargers and USB cables. The use
of unapproved accessories could damage your phone or
invalidate your warranty.
WARNING!
Do not remove the back cover. The battery is not
removable. Removal may cause fire or explosion.
NOTE:
If the battery charge is low you may be unable to power on
the phone. Leave on charge for at least 20 minutes and try
again. Contact the customer service if you still cannot power
on the phone after prolonged charging.
NOTE:
If the screen freezes or takes too long to respond, press and
hold the Power key for 10 seconds to restart the phone.
FM Radio
Scanning for Channels
1. Plug in a wired headset, and swipe all the way up from
the bottom of the screen and touch FM Radio.
7
2. Touch . Your phone scans for all available channels
and save them to the radio station list. You can touch
> Refresh to scan again if necessary.
Listening to FM Radio
1. Open FM Radio while the headset is connected.
2. Touch and select a channel.
You can also touch or to switch to other channels.
Touch or to adjust the channel frequency.
NOTES:
• Touch to add the channel to favorites.
• Touch to listen to the radio through the phone
speaker.
• The FM radio feature does not require an Internet
connection.
Product Safety Information
Don’t make or receive phone calls while driving.
Never text while driving.
Keep your phone at least 10 mm away from your
body while making calls.
Small parts may cause choking.
Your phone can produce a loud sound.
Do not listen at high volume levels for long periods.
Exercise caution when holding your phone near
y
our ear while the loudspeaker is in use.
Avoid contact with anything magnetic.
Keep away from pacemakers and other electronic
medical devices.
Turn off when asked to in hospitals and medical
facilities.
Turn off when told to on aircraft and at airport.
Turn off when near explosive materials or liquids.
8
Don’t use at gas stations.
Your phone may produce a bright or flashing light.
Don’t dispose of your phone in fire.
Avoid extreme temperatures.
Avoid contact with liquids. Keep your phone dry.
Do not attempt to disassemble your phone.
Only use approved accessories.
Don’t rely on your phone as a primary device for
emergency communications.
FCC RF Exposure Information (SAR)
This phone is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy
set by the Federal Communications Commission of the
United States.
During SAR testing, this device was set to transmit at its
highest certified power level in all tested frequency bands,
and placed in positions that simulate RF exposure in usage
against the head with no separation, and near the body with
the separation of 10 mm. Although the SAR is determined at
the highest certified power level, the actual SAR level of the
device while operating can be well below the maximum value.
This is because the phone is designed to operate at multiple
power levels so as to use only the power required to reach
the network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
The exposure standard for wireless devices employing a unit
of measurement is known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC is 1.6 W/kg.
This device is complied with SAR for general
9
population/uncontrolled exposure limits in ANSI/IEEE C95.1-
1992 and had been tested in accordance with the
measurement methods and procedures specified in
IEEE1528.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and
can be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on FCC ID: SRQ-
ZTEV10VITA. The FCC ID also can be found on the device
when you open Settings > System > About phone.
For this device, the highest reported SAR value for usage
against the head is 0.270 W/kg, and for usage near the body
is 1.452 W/kg.
While there may be differences between the SAR levels of
various phones and at various positions, they all meet the
government requirements.
SAR compliance for body-worn operation is based on a
separation distance of 10 mm between the unit and the
human body. Carry this device at least 10 mm away from your
body to ensure RF exposure level compliant or lower to the
reported level. To support body-worn operation, choose the
belt clips or holsters, which do not contain metallic
components, to maintain a separation of 10 mm between this
device and your body.
RF exposure compliance with any body-worn accessory,
which contains metal, was not tested and certified, and using
such body-worn accessory should be avoided.
FCC Regulations
This mobile phone complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
10
This mobile phone has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
CAUTION:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
