ZTE WP659+
GSM Wireless
Phone
User Guide
{tc " Know Your Phone" \f E}Know Your Phone
{tc " Key Instruction" \f E}Key Instruction
Key
Description
1.
MENU/OK
• Enter main menu.
• Performs the function indicated at the left bottom of
the screen.
2. Number
• Use these keys to enter numbers and characters.
3. # , *
• Perform different functions under different conditions.
4.Scrolling
• Press these keys to scroll cursor to the left, right, up
or down when inputting characters or selecting items.
• Default functions in standby mode are set in Settings
menu.
Key
Description
5.
NAMES/B
ACK
• To return to upper menu, or cancel
• Enter the Phonebook in Idle screen
6. EXIT
• To turn ON/OFF the unite
7. MUTE
•To mute the voice while communication
8.MESSAG
E
• This is the shortcut key to enter message menu in
standby mode.
9.
CALL/RED
IAL
• Make a call or answer an incoming call.
• In standby mode, press this key to enter Dialed calls
list.
10.HANDS
-FREE
• If you are using the handset to call and want to transfer
the call to the speakerphone, press this key and hang
up the handset to put conversation on the
speakerphone.
• Press this key to end a hands-free call.
Notes:
In this manual, “press” a key means to press the key once, “hold” a
key means to press the key for 2 or 3 seconds.
{tc " Interface Icons" \f E}Interface Icons
Ico
n
Descripti
on
Ico
n
Description
Signal
strength
New message
Silent
Power indicator
{tc " Installation" \f E}Installation
1.
{
tc "Handset" \f A}
{
tc "Handset" \f B}
{
tc " Handset" \f E}Handset
Connect phone and handset via the phone cord.
2.
{
tc "External power adapter" \f A}
{
tc "External power adapter" \f B}
{
tc
" External power adapter" \f E}External power adapter
Plug the external power adapter to the external AC socket.
3.
{
tc "SIM card" \f A}
{
tc "SIM card" \f B}
{
tc " SIM card" \f E}SIM card
Always switch the phone off before removing or inserting SIM card.
Open the bottom cover of the battery. Remove the battery, slide the SIM
card into the SIM card slot. Make sure that the contact area of the card is
facing down, and the beveled corner matches with the SIM card slot. Put in
the battery and install the bottom cover.
{tc " How to Power on/off" \f E}How to Power on/off
To power on the phone, connect phone and external power outlet with
the power adapter and then hold the EXIT key till the phone is powered on.
To power off the phone, at standby mode, hold the EXIT key till the
phone is powered off.
Notes:
It is strongly recommended to connect the phone to external power outlet,
and use internal battery to power your phone only when external power fails
or is not available. The phone will charge the internal battery automatically
when it is connected to external power outlet.
{tc " How to Make a Call" \f E}How to Make a Call
There are two methods for making a call.
The first method:
1. Pick up the handset or press the HANDS-FREE key.
2. Enter the phone number, press CALL/REDIAL key to make the call.
The second method:
Enter the number or select recipient’s number from Contacts, or press
CALL/REDIAL key to select a number from the Dialed calls list, then press
CALL/REDIAL key to make the call.
Notes:
Add the international prefix, country code and area code (without the leading
0) before the number when making an international call.
{tc " Message" \f E}Message
Select Messaging in Menu.
• Select Write message to write message, Press Options select Send to or
Save.
• Select Inbox to view messages received.
• Select Outbox to view the failure messages.
• Select Drafts to view the draft messages.
• Select Sent messages to view the successfully sent messages.
• Select SMS templates to View the template messages.
• Select SMS settings to make some necessary short message settings.
• Select Memory status under SMS settings to View the message of saved
entries and maximum number of entries capacity in phone and SIM.
{tc " Phone Code" \f E}Security setting
Security setting could prevent your phone from unauthorized use. The
default phone code is 1122. Change it to your own as soon as possible.
If you change the default phone code to a new one, remember it or place it
at secure place.
{TC " PIN1 Code and PUK Code" \f "E"}PIN Code and PUK Code
• PIN code: PIN code could prevent your SIM card from illegal use. When
PIN code is enabled, you should enter the PIN code when powering on the
phone again. Change the default PIN code to your own as soon as
possible.
• PUK code: The SIM card will be locked if you enter a wrong PIN code
consecutively for three times. To unlock, you need PUK code.
Notes:
PIN code and PUK code may be offered together with the SIM card. If not,
contact your service provider.
{tc " Text Input" \f E}Text Input
Operation
Method
Input
digits
“123”, press the Number keys to input the digits you want
directly.
Input
letters
“Abc”, “abc”, “ABC”, press corresponding letter key till
the letter appears.
Input
words
“=ABC”, “=abc”, press the Number keys to input the
characters of the word. Then press MENU/SELECT key to
confirm.
Input
symbol
Press * key, and then select corresponding symbol by
using Scrolling keys.
Input
space
Apart from Numbers input mode, press “0” key to add
space.
Erase
character
Press NAMES/BACK key. Hold NAMES/BACK key until the
cursor before the character be erased.
Move the
cursor
Press Scrolling keys.
Change
input
mode
Press # key to change text input mode.
{tc " Menu Function" \f E}Menu Function
Hereinafter are brief instructions for menu functions of the phone.
Description
Selection
Create message and send
to others.
Menu→ Messaging→
Write message
Read message in Inbox,
Outbox, Drafts, Sentbox.
Menu→ Messaging→
Inbox/Outbox/Drafts/Sen
t messages
Make some necessary
short message settings.
Menu→ Message→ SMS
settings
View or dial all recent
calls.
Menu→ Call history→
Missed calls/Dialed
calls/Received
calls/Delete call logs
Check the Last call,
Received calls, Dialed
calls or Call history
duration.
Menu→ Call history→
Missed calls/Dialed
calls/Received calls→
Options(Scrolling to view)
View contacts
Menu→ Phonebook
Save phone number.
Menu→ Phonebook→
Options→ Select
Set and view speed dial
list.
Menu→ Phonebook→
Options→ Phonebook
settings→ Speed dial
Specify the conditions
under which the call types
should be diverted to
another number.
Menu→ Settings→ Call
settings→ Call divert
Put the current call on
hold to answer the other
incoming call.
Menu→ Settings→ Call
settings→ Call waiting
Description
Selection
Restrict the dialing or
receiving of certain calls.
Menu→ Settings→ Call
settings→ Call barred
Other setting items of Call
setting
Menu→ Settings→ Call
settings → Advanced
setting→ Black list/Call
time reminder/Answer
mode/Delay dial
Set the date and the time,
and the date and time
format.
Menu→ Settings→
Phone settings→ Time &
date
Set the display language
Menu→ Settings→
Phone settings →
Language
Set the scrolling key as
shortcut of some menu.
Menu→ Settings→
Phone settings→
Dedicated keys
Lock the keypad
automatically. Press #
key, then * key to unlock.
Menu→ Settings→
Phone settings→ Screen
auto lock
Set the backlight time,
when using the phone.
Menu→ Settings→
Phone settings →LCD
backlight
Set or change the PIN
code
Menu → Settings →
Security settings → SIM
security → Change PIN
Set or change the phone
lock code.
Menu→ Settings→
Security settings→
Phone security→ Change
password
Switch to the factory
default settings. The
phone will clew input
Menu→ Settings→
Restore factory settings
Description
Selection
password, the
password default 1122.
Set profiles of your phone.
Menu→ Profiles
Set the way of searching
network.
Menu→ Settings→
Network selection
Execute basic math
calculation.
Menu→ Organizer→
Calculator
Set alarm clock.
Menu→ Organizer→
Alarm
Listen to FM radio.
Menu→ FM radio.
{tc " Warning and Maintenance" \f 549}Warning and Maintenance
• Some electronic devices are susceptible to electromagnetic interference
sent by the phone if inadequately shielded. Keep using the phone at least
20 cm or as far away as you can from TV sets, radio and other automated
office equipment so as to avoid electromagnetic interference.
• Operating the phone may interfere with medical devices like hearing aides
and pacemakers, or other medical devices in hospital. Consult a
physician or the manufacturer of the medical device before using the
phone.
• Be aware of the usage limitation when using the phone at places such as
oil warehouses, or chemical factories, where there are explosive gases or
explosive products being processed, because even if your phone is in idle
state, it still transmits radio frequency (RF) energy. Therefore, power off
your phone if required.
• Do not touch the antenna while calling. Otherwise it will affect the quality
of calling and waste battery energy. The damaged antenna will cause
slight burn while touching your skin.
• Keep the antenna free from obstructions and position the antenna
straight up. This will ensure best call quality.
• Keep the phone out of the reach of small children. The phone may cause
injury if used as a toy.
• Do not put other things on the terminal to avoid overlaying radiator.
• Use original accessories or accessories that are authorized by the
manufacturer. Using any unauthorized accessories may affect your
phone ’s performance, and violate related national regulations about
telecom terminals, or even endanger your body.
• As your phone can produce electromagnetic field, do not place it near
magnetic items such as computer disks.
• Do not expose your phone to direct sunlight or store it in hot areas. High
temperature can shorten the life of electronic devices.
• Prevent liquid from leaking into your phone.
• Disconnect external power supply and do not use your phone during
thunderstorm.
• Unplug the external power adapter or remove battery when your phone is
not in use, esp. for a long period of time.
• It is highly recommended to charge the battery before initial use. The
battery might have been discharged during storage and delivery.
• Do not unplug the connector of the data cable from the phone, and not
install or remove battery, when the power is on.
• Do not attempt to disassemble the phone by yourself. Non-expert
handling of the devices may damage them.
• The phone is non-waterproof, keep it dry and store in shady and cool
place.
• If you want to clean your phone, please use clean fabric that is a bit wet
or anti-static. Do not use harsh chemical cleaning solvents or strong
detergents to clean your phone, such as alcohol, dilution agent and
benzene. Power off your phone before you clean it.
{tc " Limited Warranty" \f E}Limited Warranty
• This warranty does not apply to defects or errors in the Product caused
by:
i. Reasonable Router Appearance Disfiguration.
ii. End User ’s failure to follow ZTE ’s installation, operation or
maintenance instructions or procedures.
iii. End User’s mishandling, misuse, negligence, or improper installation,
disassemble, storage, servicing or operation of the Product.
iv. Modifications or repairs not made by ZTE or a ZTE-certified individual.
v. Power failures, surges, fire, flood, accident, actions of third parties or
other events outside ZTE’s reasonable control.
vi. Usage of products of third Parties, or usage in conjunction with third
party products provided that such defects is due to the combined usage.
vii. Any other cause beyond the range of normal usage for Products.
End User shall have no right to reject, return, or receive a refund for any
product from ZTE under the above-mentioned situations.
• This warranty is end user’s sole remedy and ZTE’s sole liability for
defective or nonconforming items, and is in lieu of all other warranties,
expressed, implied or statutory, including but not limited to the implied
warranties of merchantability and fitness for a particular purpose, unless
otherwise required under the mandatory provisions of the law.
{tc " Limitation of Liability" \f 549}Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental
or consequential damages resulting from or arising out of or in connection
with using of this product, whether or not ZTE had been advised, knew or
should have known of the possibility of such damages, including, but not
limited to lost profits, interruption of business, cost of capital, cost of
substitute facilities or product, or any downtime cost.
{tc " Troubleshooting" \f E}Troubleshooting
If your phone appears following phenomenon in the process of application,
read following relative information at first. If the problems still can not be
solved, please contact with the distributor or service provider.
Problem
Check Point
When switching on the phone, it
prompts enter “PIN”.
Input your PIN code which offered
with SIM card together. If you have
changed PIN code, input the new
PIN code.
When switching on the phone, it
prompts “Emergency”.
Check whether valid SIM card is
inserted or not.
When switching on the phone, it
prompts enter “password”.
Enter lock code you set already to
unlock the phone.
No ring tone prompt for a
incoming call.
Check volume setting of ring ton
e.
And check whether "mute" is set
in Profiles.
No display on screen when
disconnect external power
supply.
Check whether the battery has
electricity, or it is damaged; or
power on the phone again.
Press CALL/REDIAL key, but no
number is sent.
Check whether you have set call
barring.
Certain call cannot be received.
Check whether the number is
Problem
Check Point
restricted.
Cannot send short messages.
Check the network condition, or
message center setting.
Other abnormal phenomenon.
First refer to the user manual, and
then check whether the power is
connected correctly or not. If there
is no problem, restart the phone.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
The interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
This device may not cause harmful interference, and This device must accept any interference
received, including interference that may cause undesired operation.
Note: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. such modifications could void the user’s authority
to operate this equipment.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.

Navigation menu
