ZTE ZTEWP850 CDMA 1X Wireless Phone User Manual Q78 ZTEWP850
ZTE Corporation CDMA 1X Wireless Phone Q78 ZTEWP850
ZTE >
User Manual
ZTE WP850
CDMA Wireless Phone
User Guide
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: (86) 755 26779999
URL: http://www.zte.com.cn
E-mail: mobile@zte.com.cn
LEGAL INFORMATION
Copyright © 2012 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by
any means, electronic or mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications on print
errors or update specifications without prior notice.
Version No. : R1.2
Edition Time : 2012.05.25
Confidential and Proprietary Information of ZTE CORPORATION 1
C h a p t e r 1
Know Your Phone
There are two ZTE WP850 models. One needs UIM card inserted in, the other does not need.
Section or function marked with “★” is only available to the model with UIM card. Otherwise, it is
available to both models.
2
LCD Screen
4
7
9
3 8
1
Earpiece
10
5
6 11
Confidential and Proprietary Information of ZTE CORPORATION 2
C h a p t e r 2
Key Instruction
Key Description
1, 3, 8: Scrolling keys
(Up/Down/Left/Right key)
Press these keys to scroll cursor to the left, right, up or down
when inputting characters or selecting items.
2: Left select key Enter main menu.
Select or confirm options in menu.
Enter the left-bottom menu.
4: CALL/REDIAL key Make a call or answer an incoming call.
In standby mode, press this key to enter recent calls list.
5: Number keys Input numbers and characters.
6, 11: * key, # key Perform different functions under different conditions.
7: Right select key Enter righ
t
-
b
ottom submenu on the screen.
Erase character(s) while editing text.
Return to the previous page during menu navigation.
9: End key End an active call or reject a call.
Hold this key to Power on/Power off the phone.
Exit from any interface to standby mode.
10: OK key Confirm the commands and options selected.
Confirm the characters inputting.
Notes:
In this guide, “press” a key means to press the key once, “hold” a key means to press the key for 2 or 3
seconds.
Confidential and Proprietary Information of ZTE CORPORATION 3
C h a p t e r 3
Interface Icons
Icon Description Icon Description
Signal strength New message
Silent Roaming
Power indicator Alarm clock
Confidential and Proprietary Information of ZTE CORPORATION 4
C h a p t e r 4
Installation
1. Charge the battery
z Connect the desk charger and external AC socket via power adapter.
z Put the phone on the desk charger. The charge spring of the desk charger should be inserted in
the apertures at the bottom of the phone.
z Meanwhile, power indicator in the upper-right corner of the display blinks, indicating the
charging is in progress. While charging in power-off mode, the display only shows the charge
indicator. If the battery is completely flat, it may take a while before the charge indicator appears
on the display.
z When the power indicator on the screen stops blinking, the charging is completed. The normal
charging time is 4 hours. In the process of charging, it is a normal phenomenon that the battery,
phone and charger get hot.
z After the completion of charging, disconnect the charger from the phone and AC socket.
Note：
When charging the battery, place the phone in an environment with good ventilation and
temperature between 0℃～＋45℃. Make sure to use the charger offered by the phone
manufacturer. Using unauthorized charger may cause danger and violate the guarantee articles.
When the phone is automatically switched off or indicates power shortage, charge the battery in
time.
The standby time and the talk time of the phone are based on ideal working environment. In
practice, the working time of battery varies with network condition, working environment and
application methods.
2.
★
UIM Card
z Power off the phone and remove other external power.
z Take off the back cover and remove the battery of the phone.
z Insert UIM card into UIM card slot in the phone or pull out UIM card out of slot.
z Direct the back cover towards the locking catches on the both sides of the phone and push the
back cover of the phone upward to lock the cover into its place.
Confidential and Proprietary Information of ZTE CORPORATION 5
C h a p t e r 5
How to Power On/Off
Hold the End key to power on the phone.
When the phone is powered on, hold the End key to power off the phone.
Confidential and Proprietary Information of ZTE CORPORATION 6
C h a p t e r 6
How to Make a Call
1. Enter the telephone number.
Add the international prefix, country code and area code (without the leading 0) before the number when
making an international call.
2. Press the CALL/REDIAL key to make the call.
Note: If required, hold the 0 key for the international prefix “+”, or input international prefix e.g. “00”
directly.
Confidential and Proprietary Information of ZTE CORPORATION 7
C h a p t e r 7
Message
Select Menu→Messages.
• Select New Message to create new message: key in receiver’s phone number or press OK key to select
from Contacts list, press Down key to input message text, Press OK key to send the message.
• Select Inbox to view messages received.
• Select Drafts to view draft you saved.
• Select Outbox to view the stored messages.
• Select Sent to view the sent messages.
• Select Message Settings to set the message configuration.
• Select Message Template to view or edit the default text.
• Select Delete Message to erase certain messages.
• Select Memory Status to view the memory information of message box.
Confidential and Proprietary Information of ZTE CORPORATION 8
C h a p t e r 8
Phone Code
Phone code could prevent your phone from illegal using. The default handset password is 0000. Change it
to your own phone password as soon as possible.
Notes:
Remember the handset password, otherwise some service expense may happen.
Confidential and Proprietary Information of ZTE CORPORATION 9
C h a p t e r 9
★ PIN Code and PUK Code
Notes:
PIN code and PUK code may be offered together with the UIM card. If not, please contact with network
operator. Change default PIN code to your own as soon as possible.
PIN code: PIN code could prevent your phone from illegal use. You should input the PIN code
when entering some menus.
PUK code: The UIM card will be locked if you enter a wrong PIN code consecutively for three times.
You need PUK code to unlock it.
Confidential and Proprietary Information of ZTE CORPORATION 10
C h a p t e r 10
Text Input
Operation Method
Input Letters Multitap Input — “Abc/abc/ABC” press corresponding letter key till the
letter appears.
Input Words eZiText Input — “eZi”, press any key once to key in any word.
Input Digits Numbers Input — “123”, press digital key once.
Input Symbol Symbols Input — Press * key to enter the symbols mode and press
corresponding digital key.
Or press “1” key till the symbol (common symbols) appears except for
numbers input mode.
Input Space Press “0” key, except for the numbers input mode.
Erase Character Press Right select key.
Move cursor Press Scrolling keys.
Change input mode Press # key to select another text mode.
Confidential and Proprietary Information of ZTE CORPORATION 11
C h a p t e r 11
Menu Function
The contents in the following table briefly describe the functions of the phone.
Function Selection Description
Add Contact Menu→Contacts→Add Contact Add a new contact to the phone or the UIM
card（★）.
All List Menu→Contacts→All List View all the contacts in the phone or UIM
card（★）.
Groups Menu→Contacts→Groups View the Group’s name and change some
related settings about the group.
Speed Dial Menu→Contacts→Speed Dial Call a contact by holding a number key for a
few seconds.
Memory
Status
Menu→Contacts→Memory
Status
Check the storage information about the
phone or UIM card（★）.
Call History Menu→Call History→Call
History
View the call history.
Call Duration Menu→Call History→Call
Duration
View the dialed/answered/all calls’ time, and
you can also clear the call time.
Profile Menu→Profile Select and modify the phone profile.
Display
Settings
Menu→Settings→Display
Settings
You can change the settings of screen, banner
or keypad light.
Phone
Settings
Menu→Settings→Phone Settings Set the phone or view the version information
of the phone.
Call Settings Menu→Settings→Call Settings Make the call settings.
Time & Date
Settings
Menu→Settings→Time & Date
Settings
Set the time and date format.
Security
Settings
Menu→Settings→Security
Settings
Change the settings about the phone code or
PIN code（★）, restore factory settings and
clear user data.
Alarm Menu→Alarm Set reminder time.
Calendar Menu→Calendar
View the date, and check/create a task that
relates with the date.
ZTE WP850 User Guide
12 Confidential and Proprietary Information of ZTE CORPORATION
Function Selection Description
Magic Box Menu→Magic Box Use the tools in magic box.
Confidential and Proprietary Information of ZTE CORPORATION 13
C h a p t e r 12
To the Owner
Some electronic devices are susceptible to electromagnetic interference sent by phone if inadequately
shielded. Use phone at least 20 cm or as far away as you can from TV sets, radio and other automated
office equipment so as to avoid electromagnetic interference.
Operating phone may interfere with medical devices like hearing aids and pacemakers, or other
medical devices in hospital. Consult a physician or the manufacturer of the medical device before
using phone.
Be aware of the usage limitation when using phone at places such as oil warehouses, or chemical
factories, where there are explosive gases or explosive products being processed, because even if your
phone is in idle state, it still transmits radio frequency (RF) energy. Therefore, power off your phone
if required.
Keep out of the reach of small children. Phone may cause injury if used as a toy.
Do not put other things on the terminal to avoid overlaying radiator.
Phone Use
Please use original accessories or accessories that are authorized by the manufacturer. Using any
unauthorized accessories may affect your phone’s performance, and violate related national
regulations about telecom terminals, or even endanger your body.
Do not connect the phone with other unauthorized peripheral equipments.
As your phone can produce electromagnetic field, do not place it near magnetic items such as
computer disks.
Using the phone near electrical appliances such as TV, telephone, radio and personal computer can
cause interference, which affects the function of the phone.
Do not expose your phone to direct sunlight or store it in hot areas. High temperatures can shorten the
life of electronic devices.
Prevent liquid from leaking into your phone.
Disconnect external power supply and do not use your phone during thunderstorm.
Unplug the external power adapter or remove battery when your phone is not in use, esp. for a long
period of time.
It is highly recommended to charge the battery before initial use. The battery might have been
discharged during storage and delivery.
Do not unplug the connector of the data cable from phone, and not install or remove battery, when the
power is on.
Keep phone power on and in service area when make emergency call. Enter emergency call number in
status of standby, and then press Call key to send.
Do not attempt to disassemble the phone by yourself. Non-expert handling of the devices may damage
them.
Battery Use
Do not short-circuit the battery, as this can cause excessive heat and fire.
Do not store battery in hot areas or dispose of it in a fire to avoid explosion.
Never use any charger or battery damaged or worn out.
Return the wear-out battery to the provider or put it in the appointed recycle place. Do not put it in
familial rubbish.
Warning: If the battery is broken, keep away from substance inside. If it taints your skin, wash your skin
with abundant fresh water and ask doctor for help if necessary.
Safety and General Use in Vehicles
Before making or answering a call, you should pay attention to the local laws about using wireless
mobile phones and take them into account in practical use.
Safety airbag, brake, speed control system and oil eject system shouldn’t be affected by wireless
transmitting. If you do meet problems above, contact your automobile provider.
Power off your mobile phone when refueling your automobile, and so do the place where duplex
ZTE WP850 User Guide
14 Confidential and Proprietary Information of ZTE CORPORATION
wireless equipments are banned. Don’t put your phone together with flammable or explosive items,
inner spark may cause fire.
Cleaning and Maintenance
The phone is non-waterproof, keep it dry and store in shaded and cool place.
If you want to clean your phone, use clean fabric that is a bit wet or anti-static. Do not use harsh
chemical cleaning solvents or strong detergents to clean your phone such as alcohol, dilution agent
and benzene. Power-off your phone before you clean it.
Use phone within a temperature range of -10°C~+55°C and the humidity less than 95%.
Confidential and Proprietary Information of ZTE CORPORATION 15
C h a p t e r 13
Limited Warranty
The warranty does not apply to defects or errors in the product caused by:
(a) Reasonable abrasion.
(b) Misuse including mishandling, physical damage, improper installation, unauthorized disassembly of
the product.
(c) Water or any other liquid damage.
(d) Any unauthorized repair or modification.
(e) Power surges, lightning damage, fire, flood or other events outside ZTE’s reasonable control.
(f) Use of the product with any unauthorized third party products such as generic chargers.
(g) Any other cause beyond the range of normal usage for products.
End User shall have no right to reject, return, or receive a refund for any product from ZTE under the
above-mentioned situations.
This warranty is end user’s sole remedy and ZTE’s sole liability for defective or nonconforming items,
and is in lieu of all other warranties, expressed, implied or statutory, including but not limited to the
implied warranties of merchantability and fitness for a particular purpose, unless otherwise required under
the mandatory provisions of the law.
Confidential and Proprietary Information of ZTE CORPORATION 16
C h a p t e r 14
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages
resulting from or arising out of or in connection with using of this product, whether or not ZTE had been
advised, knew or should have known of the possibility of such damages, including, but not limited to lost
profits, interruption of business, cost of capital, cost of substitute facilities or product, or any downtime
cost.
ZTE WP850 User Guide
Confidential and Proprietary Information of ZTE CORPORATION 17
C h a p t e r 15
FCC Compliance
• This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Caution: Changes or modifications not expressly approved by the manufacturer could void the user’s
authority to operate the equipment.
• This device has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
f Reorient or relocate the receiving antenna.
f Increase the separation between the equipment and receiver.
f Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
f Consult the dealer or an experienced radio/TV technician for help.
f Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
• The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Radio Frequency (RF) Energy
This model phone meets the government’s requirements for exposure to radio waves.
This phone is designed and manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of the U.S. Government:
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating
positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone
while operating can be well below the maximum value. This is because the phone is designed to operate at
multiple power levels so as to use only the poser required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output.
The highest SAR value for the model phone as reported to the FCC when tested for use at the ear is
1.370W/kg and when worn on the body, as described in this user guide, is 0.617W/kg (Body-worn
measurements differ among phone models, depending upon available enhancements and FCC
requirements.)
ZTE WP850 User Guide
18 Confidential and Proprietary Information of ZTE CORPORATION
While there may be differences between the SAR levels of various phones and at various positions, they
all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/ea/fccid/ after searching on
FCC ID: Q78-ZTEWP850.
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for use
with an accessory that contains no metal and the positions the handset a minimum of 1.5 cm from the
body. Use of other enhancements may not ensure compliance with FCC RF exposure guidelines. If you do
no t use a body-worn accessory and are not holding the phone at the ear, position the handset a minimum
of 1.5 cm from your body when the phone is switched on.
Confidential and Proprietary Information of ZTE CORPORATION 19
C h a p t e r 16
Troubleshooting
If your phone appears following phenomenon in the process of operation, please read following relative
information at first. If the problems still can not be solved, please contact the distributor or service
provider.
Problem Check Point
When switching on the phone, it prompts “Enter
phone password”.
Enter phone code you set already to unlock the
phone.
Incorrect display of system time. Check whether the system signal is too weak.
No corresponding response when press the phone
keys (after several attempts).
Restart the phone.
No display on screen when disconnect external
power supply.
Check whether the battery has electricity or it is
damaged, or restart the phone.
There is incoming call, but no prompt ring tone. Check the silent mode and the volume of ring
tone.
There is no prompt tone when the alarm clock
has reached the time.
Check whether the alarm clock is enabled or not.
Cannot send short message. Check the network condition.
Other abnormal phenomenon. Please first refer to user guide, then check
whether the power is connected correctly or not,
if there is no problem, please restart the phone.
