Zanussi 285742 Brochure ELECTRIC RANGE
SCFE700 to the manual 24c7b7df-27ae-4778-8247-13cd44d08d18
2015-01-05
: Zanussi Zanussi-285742-Brochure-206928 zanussi-285742-brochure-206928 zanussi pdf
Open the PDF directly: View PDF
.
Page Count: 2
ZANUSSI
P R O F E S S I O N A L
ELECTRIC RANGE
SNACK 600
SCFE 700
front plates 2,2
back plates 2,2
oven 2,5
Power - kW
height 420
depth 325
width 460
Oven cavity - mm
height adjustment 50
External dimensions - mm
Supply voltage 400 V, 3N, 50/60
Net weight - kg. 56
installed-electric 10.5
Power - kW
height 850
depth 600
width 700
External dimensions - mm
Power supply Electric
SCFE700
285742
CHARACTERISTICS MODELS
TECHNICAL DATA
RANGE
COMPOSITION
Ideal for smaller sized catering
establishments: bars, pubs, fast food
outlets, pizzerias and small hotels;
the Snack 600 range of modular
cooking appliances consists of a
series of appliances each with a
depth of 600 mm - in gas and
electric - featuring high power for
fast service whether in table top
situations, where space is a
premium, or in a complete cooking
installation, using the base units that
can include doors, drawers or
runners for gastronorm containers.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
� Constructed completely in 18/10,
304 AISI stainless steel to guarantee
a hard-wearing performance.
� Hygiene guaranteed by rounded
edges, flush fit between units, side
upstands and sealing joints,
completely smooth and easy to
clean surfaces and rear splashback.
� The top is pressed and perfectly
sealed to prevent food infiltration.
� Cast-iron hot plates each with 2
kW power to ensure a rapid-heat up,
sealed to the top. Temperature
limiter to reduce energy consumption.
� Temperature control with 7
settings to suit all types of cooking.
ELECTRIC OVEN
� Electric fan assisted oven, oven
chamber in stove enamelled sheet
steel, internal lighting, removable
self-cleaning panelling,
thermostatically controlled
temperature to 275°C. Timer.
� Grid and enamelled shelf supplied
as standard.
� All models comply with the
standards required by the main
international approval bodies and
are H marked.
BAAB1 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L
GULLEY WITH JOINING PANEL FOR 600 LINE 285798
SCFE700
285742
ACCESSORIES MODELS
OPTIONAL ACCESSORIES
I - Electrical connection 400 V, 3N, 50/60
SCFE700
285742
LEGEND
285742
700 600
ITC-SCFE700
960
850
I
65 I
205
