Zebra Technologies 3678 Industrial Scanner Cradle User Manual STB3678

Zebra Technologies Corporation Industrial Scanner Cradle STB3678

Contents

User Manual STB3678

Service Information
If you have a problem using the equipment, contact your facility’s Technical or
Systems Support. If there is a problem with the equipment, they will contact Zebra
Support at: http://www.zebra.com/support.
For the latest version of this guide go to: http://www.zebra.com/support.
Warranty
For the complete Zebra hardware product warranty statement, go to:
http://www.zebra.com/warranty.
For Australia Only:
This warranty is given by Zebra Technologies Asia Pacific Pte. Ltd., 71 Robinson Road,
#05-02/03, Singapore 068895, Singapore. Our goods come with guarantees that cannot
be excluded under the Australia Consumer Law. You are entitled to a replacement or
refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be
of acceptable quality and the failure does not amount to a major failure.
Zebra Technologies Corporation Australia's limited warranty above is in addition to any
rights and remedies you may have under the Australian Consumer Law. If you have any
queries, please call Zebra Technologies Corporation at +65 6858 0722. You may also visit
our website: http://www.zebra.com for the most updated warranty terms.
Zebra Technologies Corporation
Lincolnshire, IL U.S.A.
http://www.zebra.com
Zebra and the stylized Zebra head are trademarks of ZIH Corp., registered in many
jurisdictions worldwide. All other trademarks are the property of their respective owners.
©2015 ZIH Corp and/or its affiliates. All rights reserved.
MN002334A01 Revision Draft 3 - December 2015
© 2015 Symbol Technologies, Inc.
Zebra reserves the right to make changes to any software or product to improve
reliability, function, or design.
Zebra does not assume any product liability arising out of, or in connection with, the
application or use of any product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under
any Zebra Technologies Corporation, intellectual property rights. An implied license
exists only for equipment, circuits, and subsystems contained in Zebra products.
Zebra and the stylized Zebra head are trademarks of ZIH Corp., registered in many
jurisdictions worldwide. All other trademarks are the property of their respective owners.
©2015 ZIH Corp and/or its affiliates. All rights reserved.
Zebra Technologies Corporation
Lincolnshire, IL USA
http://www.zebra.com
Health and Safety RecommendationsErgonomic
Recommendations
Caution: In order to avoid or minimize the potential risk of ergonomic injury follow the
recommendations below. Consult with your local Health & Safety Manager to ensure that you
are adhering to your company’s safety programs to prevent employee injury.
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
Vehicle Installation
RF signals may affect improperly installed or inadequately shielded electronic systems in motor
vehicles (including safety systems). Check with the manufacturer or its representative regarding
your vehicle. You should also consult the manufacturer about any equipment that has been
added to your vehicle.
Regulatory Information
This device is approved under Zebra Technologies Corporation.
This guide applies to the following Model Number: STB3678
All Zebra devices are designed to be compliant with the rules and regulations in the locations
they are sold and will be labeled as required.
Local language translations are available at the following website: http://www.zebra.com/doc.
Any changes or modifications to Zebra equipment not expressly approved by Zebra could void
the user's authority to operate the equipment.
CAUTION
Only use Zebra approved and UL Listed accessories, battery packs and
battery chargers.
Do NOT attempt to charge damp/wet batteries. All components must be dry
before connecting to an external power source.
Declared maximum operating temperature: 50oC.
Statement of Compliance
Zebra hereby, declares that this device is in compliance with the essential requirements and
other relevant provisions of Directive 1995/5/EC and 2011/65/EU. A Declaration of Conformity
may be obtained from http://www.zebra.com/doc.
Bluetooth® Wireless Technology
This is an approved Bluetooth product. For more information or to view End Product Listing,
please visit https://www.bluetooth.org/tpg/listings.cfm.
Wireless Device Country Approvals
Regulatory markings, subject to certification, are applied to the device signifying the radio(s) is/
are approved for use in the following countries: United States, Canada, Japan, China, South
Korea, Australia, and Europe.
Please refer to the Declaration of Conformity (DoC) for details of other country markings. This
is available at: http://www.zebra.com/doc.
Note: Europe includes, Austria, Belgium, Bulgaria, Croatia,Czech Republic, Cyprus, Denmark,
Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein,
Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovak Republic,
Slovenia, Spain, Sweden, Switzerland and the United Kingdom.
Power Supply
Use ONLY a Zebra approved UL LISTED ITE (IEC/EN 60950-1, LPS/SELV) power supply with
electrical ratings: Output 12Vdc, min 4.16A, with a maximum ambient temperature of at least 50
degrees C. Use of alternative power supply will invalidate any approvals given to this unit and may be
dangerous.
CAUTION Operation of the device without regulatory approval is illegal.
STB3678 CRADLE
Industrial Scanner Cradle
Quick Reference Guide
RF Exposure Guidelines
Reducing RF Exposure – Use Properly
Only operate the device in accordance with the instructions supplied. The device complies with
internationally recognized standards covering human exposure to electromagnetic fields from radio
devices. For information on “International” human exposure to electromagnetic fields refer to the Zebra
Declaration of Conformity (DoC) at http:www.zebra.com/doc.
For further information on the safety of RF energy from wireless devices, see
http://responsibility.zebra.com/index.php/downloads/, which is located under Wireless Communications
and Health.
Europe
Remote and Standalone Antenna Configurations - To comply with EU RF exposure requirements,
antennas that are mounted externally at remote locations or operating near users at stand-alone
desktop of similar configurations must operate with a minimum separation distance of 20 cm from all
persons.
US and Canada
To comply with FCC RF exposure compliance requirement, the antenna used for this transmitter must
not be co-located or operating in conjunction with any other transmitter/antenna except those already
approved in this filling.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator and
your body.
NOTE IMPORTANTE: (Pour l'utilisation de dispositifs mobiles)
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de
distance entre la source de rayonnement et votre corps.
Remote and Standalone Antenna Configurations
To comply with FCC RF exposure requirements, antennas that are mounted externally at remote
locations or operating near users at stand-alone desktop of similar configurations must operate with a
minimum separation distance of 20 cm from all persons.
Radio Frequency Interference Requirements-FCC
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment in an outlet on a circuit different from the receiver is connection
• Consult the dealer or an experienced radio/TV technician for help
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Radio Frequency Interference Requirements-Canada
CAN ICES-3 (B)/NMB-3(B)
Radio Transmitters - This device complies with Industry Canada's license-exempt RSS's. Operation is
subject to the following two conditions: (1) This device may not cause interference; and (2) This device
must accept any interference, including interference that may cause undesired operation of the device.
Cet appareil est conforme exempts de licence le flux RSS de Industrie Canada. Son fonctionnement est
soumis aux deux conditions suivantes:
(1) Ce dispositif ne peut causer des interférences; et (2) Cet appareil doit accepter toute interférence,
y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil.
Radio Frequency Interference Requirements-Brazil
For more information consult the website www.anatel.gov.br
Declarações Regulamentares para STB/FLB3678 - Brazil
Nota: A marca de certificação se aplica ao Transceptor, modelo STB/FLB3678. Este equipamento
opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo
de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.
Para maiores informações sobre ANATEL consulte o site: www.anatel.gov.br
Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência
prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando
em caráter primário.
Este produto está homologado pela Anatel, de acordo com os procedimentos regulamentados pela
Resolução n°242/2000 e atende aos requisitos técnicos aplicados, incluindo os limites de exposição da
Taxa de Absorção Específica referente a campos elétricos, magnéticos e eletromagnéticos de
radiofrequência, de acordo com as Resoluções n° 303/2002 e 533/2009.
Este dispositivo está em conformidade com as diretrizes de exposição à radiofrequência quando
posicionado pelo menos 20 centímetros de distância do corpo. Para maiores informações, consulte o
site da Anatel.
Chile
Este equipo cumple con la Resolución No 403 de 2008, de la Subsecretaria de telecomunicaciones,
relativa a radiaciones electromagnéticas.
Ukraine
Japan (VCCI) - Voluntary Control Council for Interference
Class B ITE
Taiwan
South Korea
Korean Warning Statement for Class B ITE
China
Thailand
Marking and European Economic Area (EEA)
Bluetooth® Wireless Technology for use through the EEA have the following restrictions:
Maximum radiated transmit power of 100mW EIRP in the freq. range 2.400 -2.4835 GHz
Warnings for Use of Wireless Devices
Caution: Please observe all warning notices with regard to the usage of wireless devices.
Potentially Hazardous Atmospheres - Vehicles Use
You are reminded of the need to observe restrictions on the use of radio devices in fuel depots, chemical
plants, etc. and areas where the air contains chemicals or particles such as grain, dust, or metal
powders and any other area where you would normally be advised to turn off your vehicle engine.
Safety in Hospitals
Wireless devices transmit radio frequency energy and may affect medical electrical equipment.
Wireless devices should be switched off wherever you are requested to do so in hospitals, clinics or
healthcare facilities. These requests are designed to prevent possible interference with sensitive
medical equipment.
Pacemakers
Pacemaker manufacturers recommended that a minimum of 15cm (6 inches) be maintained between
a hand-held wireless device and a pacemaker to avoid potential interference with the pacemaker. These
recommendations are consistent with independent research and recommendations by Wireless
Technology Research.
• Should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker when turned ON.
• Should not carry the device in a breast pocket.
• Should use the ear furthest from the pacemaker to minimize the potential for interference.
• If you have any reason to suspect that interference is taking place, turn OFF your device.
Other Medical Devices
Please consult your physician or the manufacturer of the medical device, to determine if the operation
of your wireless product may interfere with the medical device.
Waste Electrical and Electronic Equipment (WEEE)
Bulgarish: За клиенти от ЕС: След края на полезния им живот всички продукти трябва да се връщат на Zebra
за рециклиране. За информация относно връщането на продукти, моля отидете на адрес:http://
www.zebra.com/weee.
Čeština: Pro zákazníky z EU: Všechny produkty je nutné po skonèení jejich životnosti vrátit spoleènosti Zebra
k recyklaci. Informace o zpùsobu vrácení produktu najdete na webové stránce:
http://www.zebra.com/weee.
Dansk: Til kunder i EU: Alle produkter skal returneres til Zebra til recirkulering, når de er udtjent. Læs oplysningerne
om returnering af produkter på: http://www.zebra.com/weee.
Deutsch: Für Kunden innerhalb der EU: Alle Produkte müssen am Ende ihrer Lebensdauer zum Recycling an
Zebra zurückgesandt werden. Informationen zur Rücksendung von Produkten finden Sie unter http://
www.zebra.com/weee.
Ελληνικά: Για πελάτες στην Ε.Ε.: Όλα τα προϊόντα, στο τέλος της διάρκειας ζωής τους, πρέπει να επιστρέφονται
στην Zebra για ανακύκλωση. Για περισσότερες πληροφορίες σχετικά με την επιστροφή ενός προϊόντος,
επισκεφθείτε τη διεύθυνση http://www.zebra.com/weee στο ∆ιαδίκτυο.
Eesti: EL klientidele: kõik tooted tuleb nende eluea lõppedes tagastada taaskasutamise eesmärgil Zebra'ile.
Lisainformatsiooni saamiseks toote tagastamise kohta külastage palun aadressi: http://www.zebra.com/weee.
English: For EU Customers: All products at the end of their life must be returned to Zebra for recycling. For
information on how to return product, please go to: http://www.zebra.com/weee.
Español: Para clientes en la Unión Europea: todos los productos deberán entregarse a Zebra al final de su ciclo
de vida para que sean reciclados. Si desea más información sobre cómo devolver un producto, visite:
http://www.zebra.com/weee.
Français: Clients de l'Union Européenne : Tous les produits en fin de cycle de vie doivent être retournés à Zebra
pour recyclage. Pour de plus amples informations sur le retour de produits, consultez : http://www.zebra.com/weee.
Italiano: per i clienti dell'UE: tutti i prodotti che sono giunti al termine del rispettivo ciclo di vita devono essere
restituiti a Zebra al fine di consentirne il riciclaggio. Per informazioni sulle modalità di restituzione, visitare il
seguente sito Web: http://www.zebra.com/weee.
Latviešu: ES klientiem: visi produkti pēc to kalpošanas mūža beigām ir jānogādā atpakaļ Zebra otrreizējai
pārstrādei. Lai iegūtu informāciju par produktu nogādāšanu Zebra, lūdzu, skatiet: http://www.zebra.com/weee.
Lietuvių: ES vartotojams: visi gaminiai, pasibaigus jų eksploatacijos laikui, turi būti grąžinti utilizuoti į kompaniją
„Zebra“. Daugiau informacijos, kaip grąžinti gaminį, rasite: http://www.zebra.com/weee.
Magyar: Az EU-ban vásárlóknak: Minden tönkrement terméket a Zebra vállalathoz kell eljuttatni újrahasznosítás
céljából. A termék visszajuttatásának módjával kapcsolatos tudnivalókért látogasson el a
http://www.zebra.com/weee weboldalra.
Malti: Għal klijenti fl-UE: il-prodotti kollha li jkunu waslu fl-aħħar tal-ħajja ta' l-użu tagħhom, iridu jiġu rritornati għand
Zebra għar-riċiklaġġ. Għal aktar tagħrif dwar kif għandek tirritorna l-prodott, jekk jogħġbok żur:
http://www.zebra.com/weee.
Nederlands: Voor klanten in de EU: alle producten dienen aan het einde van hun levensduur naar Zebra te worden
teruggezonden voor recycling. Raadpleeg
http://www.zebra.com/weee voor meer informatie over het terugzenden van producten.
Polski: Klienci z obszaru Unii Europejskiej: Produkty wycofane z eksploatacji nale¿y zwróciæ do firmy Zebra w celu
ich utylizacji. Informacje na temat zwrotu produktów znajduj¹ siê na stronie internetowej
http://www.zebra.com/weee.
Português: Para clientes da UE: todos os produtos no fim de vida devem ser devolvidos à Zebra para reciclagem.
Para obter informações sobre como devolver o produto, visite: http://www.zebra.com/weee.
Românesc: Pentru clienţii din UE: Toate produsele, la sfârşitul duratei lor de funcţionare, trebuie returnate la Zebra
pentru reciclare. Pentru informaţii despre returnarea produsului, accesaţi: http://www.zebra.com/weee.
Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku življenjske dobe vrniti podjetju Zebra za reciklažo. Za
informacije o vračilu izdelka obiščite: http://www.zebra.com/weee.
Slovenčina: Pre zákazníkov z krajín EU: Všetky výrobky musia byť po uplynutí doby ich životnosti vrátené
spoločnosti Zebra na recykláciu. Bližšie informácie o vrátení výrobkov nájdete na:http://www.zebra.com/weee.
Suomi: Asiakkaat Euroopan unionin alueella: Kaikki tuotteet on palautettava kierrätettäväksi Zebra-yhtiöön, kun
tuotetta ei enää käytetä. Lisätietoja tuotteen palauttamisesta on osoitteessa http://www.zebra.com/weee.
Svenska: För kunder inom EU: Alla produkter som uppnått sin livslängd måste returneras till Zebra för återvinning.
Information om hur du returnerar produkten finns på http://www.zebra.com/weee.
Türkçe: AB Müşterileri için: Kullanım süresi dolan tüm ürünler geri dönüştürme için Zebra'ya iade edilmelidir.
Ürünlerin nasıl iade edileceği hakkında bilgi için lütfen şu adresi ziyaret edin: http://www.zebra.com/weee.
TURKISH WEEE Statement of Compliance
기 종 별 사 용 자 안 내 문
B급 기기
( 가정용 방송통신기기 )
이 기기는 가정용 (B 급 ) 으로 전자파적합등록을
한 기기로서 주로 가정에서 사용하는 것을 목적
으로 하며 , 모든 지역에서 사용할 수 있습니다 .
Draft 3 Reg Submission
Dimension tolerance = ± 0.01 inch (± 0.25 mm)
2.26"
[57.28mm]
1.13"
[28.64mm]
5.05"
[128.27mm]
Introduction
The STB3678 cordless scanner cradle acts as charger and radio communication
interface for the XX3678 cordless scanner. It can sit on a desktop or be mounted on a
wall.
The STB3678 cradle receives data from the scanner via a Bluetooth radio, and sends
that data to the host through an attached cable. The cradle also charges the scanner’s
internal battery pack when the scanner is inserted. The scanner can be charged from an
external power supply or a powered host cable.
This document provides basic instructions on setting up and using the cradle. Any
discussion of transmission of information refers specifically to the STB3678 cradle.
CAUTION LS3578 and DS3578 cordless scanners are incompatible with
STB3678 cradles.
Equipment Supplied
The cradle package includes:
•Cradle
• Four rubber feet (for desk mounting).
Accessories
The following equipment may be needed:
• Three 1.5" #8 Philips head screws (for wall mounting, if applicable, not available
from Zebra).
• Power supply for desk/wall mounting configuration.
Save the shipping container for storing or shipping. Inspect all equipment for damage. If
anything is damaged or missing, call an authorized Zebra Support Center immediately.
Related Documentation
LI3678 Product Reference Guide, p/n MN001740Axx.
LI3678 Quick Start Guide, p/n MN002323Axx.
FLB3678 Quick Reference Guide, p/n MN002336Axx.
This documentation is available at: www.zebra.com/support.
Cradle Parts
Charging/
Communications
Contacts
Pairing
Bar Code
Mounting
Screw Hole
Foot Latch
LED
Mounting
Screw Hole
PAIR
Drain Hole
Canopy Latch
Mounting
Screw Hole
Page Button
Drain Hole
Rubber Feet
Host Cable Latch
Host Cable (Under Latch)
Rubber Feet
Host Cable
Guide
Foot Latch
Release
Mounting
Screw Hole
Mounting
Screw Hole
Top View
Bottom View
Cradle Connections
1. Connect the appropriate cable to the
power supply and an AC power source, if
necessary. This will ensure detection of the
host and prevent inadvertently back
powering the cradle from improper
detection of the host.
2. Insert the interface cable into the host port.
3. Lift the latch and connect the interface
cable into the cradle’s host port, then close
the latch.
4. If applicable, thread the interface cable
over the cable support hook and run the
host and power cables into their respective
cable grooves.
5. Pair the scanner to the cradle either by
inserting it in the cradle (if Pair on Contacts
is enabled) or by scanning the pairing bar
code.
6. If necessary, scan the appropriate host bar
code (for non-autodetected interfaces). Refer to the Product Reference Guide.
Changing the Host Interface
To connect to a different host, or to the same host through a different cable:
1. Unplug the interface cable from the host.
2. Unplug the power supply from the cradle.
3. Connect the interface cable to the new host, or the new interface cable to the
existing host.
4. Reconnect the power supply, if required.
5. If necessary, scan the appropriate host bar code (for non-autodetected interfaces).
Refer to the Product Reference Guide.
Using a Host Interface to Supply Power
Some hosts can provide power to the cradle via the host interface, instead of an external
power supply.
IMPORTANT Connect the interface cable and power supply (if necessary) in
the following order to ensure proper operation of the scanner
and cradle.
CAUTION Always disconnect the DC power supply BEFORE disconnecting the
cable to the host end or the cradle may not recognize the new host.
Latch Host Port
(Under Latch)
Mounting the Cradle
Horizontal Mount
1. Ensure the desk/wall mount
converter knob is in the correct
position, shown at right.
2. If mounting the cradle horizontally
where no fastening is necessary,
peel the protective paper from the
back of the rubber feet included
with the cradle packaging, and
attach the feet to the cradle at the
indentations in the plastic. These
feet provide traction and prevent
surface damage.
Vertical Mount
To mount the cradle on a vertical surface:
1. Use a Philips screwdriver to turn the desk/wall mount converter knob to the position
shown below. The front latches protract to engage the depressions at the base of the
scanner’s handle.
2. Attach the interface and power
cables (see Cradle Connections).
3. Press the cables into the cable
grooves.
4. Position the cradle on the
mounting surface, or use the
template included in this guide.
5. Mark the surface through the
three holes on the bottom of the
cradle, or use the mounting
template to determine the location
of the screw holes.
6. Pre-drill holes to accommodate
three 1.5" #8 Philips head screws.
7. Attach the cradle securely to the
surface.
8. Place the scanner in the cradle.
NOTE Do not use the rubber feet when mounting in a vertical orientation.
Converter Knob
Horizontal Position
Converter Knob
Vertical Position
Inserting the Scanner in the Cradle
To insert the scanner in the cradle:
• Insert the scanner top first. Push the handle until it clicks into place, engaging the
contacts in the cradle and scanner.
Sending Data to the Host Computer
The cradle receives data from the scanner via a wireless radio connection and transmits it
to the host computer via the host cable. The scanner and cradle must be paired for
successful wireless communication.
Pairing
Pairing registers a scanner to the cradle such that the scanner and cradle can exchange
information. The STB3678 operates in two modes: Point-to-Point and Multipoint-to-Point.
In Point-to-Point mode, pair the scanner to the cradle either by inserting it in the cradle (if
pair on contacts is enabled), or by scanning the pairing bar code. In Multipoint-to-Point
mode, you can pair up to seven scanners to one cradle.
To pair the scanner with the cradle, scan a pairing bar code. A high-low-high-low beep
sequence followed by a low-high beep sequence indicates successful pairing and
connection to the remote device. A long low, long high beep sequence indicates
unsuccessful pairing.
Lost Connection to Host
If scanned data does not transmit to the cradle’s host, ensure that all cables are firmly
inserted and the power supply is connected to an appropriate AC outlet, if applicable. If
scanned data still does not transmit to the host, reestablish a connection with the host:
1. Disconnect the power supply from the cradle.
2. Disconnect the host interface cable from the cradle.
3. Wait three seconds.
4. Reconnect the host interface cable to the cradle.
5. Reconnect the power supply to the cradle, if required.
6. Reestablish pairing with the cradle by scanning the pairing bar code.
CAUTION Do not pour, spray, or spill any liquid on the cradle.
NOTE The pairing bar code that connects the scanner to a cradle is unique to
each cradle.
Do not scan data or parameters until pairing completes.
Charging the Scanner Battery in the Cradle
When using a new battery in the scanner, the battery requires a charge to be enabled.
Insert the battery in the scanner and place the scanner in the STB3678 cradle (see
Inserting the Scanner in the Cradle). The battery begins charging when the scanner LED
indicator starts flashing amber. The battery is fully charged when the cradle LED is solid
green. A complete charge of a fully discharged battery can take up to three hours using
external power and up to ten hours using the USB interface cable.
Cradle LED Indicators
Troubleshooting
If the cradle does not work after following the previous procedures:
• Check the system power.
• Check for loose cable connections.
• Check that the scanner is inserted properly in the cradle.
• Check that the host settings are correct and the cradle is connected to the appropriate
port on the host.
LED Indication
Green Power on
Green flashing Bluetooth connection established
Blue Page button
Amber (fast fast slow) Scanner page issued
Battery Indications
Amber Blinking Charging
Amber fast blinking Charging error
Green Fully
charged
Wall Mount Template
Pending Template Replacement
Draft 3 Reg Submission

Navigation menu
