Users Manual
Zebra Technologies Corporation
Zebra Confidential Restricted
1. Regulatory Information
This device is approved under Zebra Technologies Corporation.
This guide applies to Model Number: CDR2G
All Zebra devices are designed to be compliant with the rules and regulations in the locations they are sold and will be labeled as
required.
Local language translations are available at the following website: www.zebra.com/support.
Any changes or modifications to Zebra equipment not expressly approved by Zebra could void the user’s authority to operate the
equipment.
Zebra devices are professionally installed — the Radio Frequency Output Power will not exceed the maximum allowable limit for
the country of operation.
Antennas: Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments
could cause damage and may violate regulations.
This device is only to be used with a Zebra Wireless Switch.
For use only with Zebra approved and UL Listed mobile computers, Zebra approved, and UL Listed/Recognized battery packs.
2. Wireless Device Country Approvals
Note: This section is only applicable to WW/WR/EU configurations.
Regulatory markings subject to certification are applied to the device signifying the radio(s) is/are approved for use in the following
countries and continents: United States, Canada, Japan, China, South Korea, Australia, and Europe.
Please refer to the Declaration of Conformity (DoC) for details of other country markings. This is available at:
http://www.zebra.com/doc.
Note: Europe includes Austria, Belgium, Bulgaria, Croatia, Czech Republic, Cyprus, Denmark, Estonia, Finland, France, Germany,
Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland,
Portugal, Romania, Slovak Republic, Slovenia, Spain, Sweden, Switzerland, and the United Kingdom.
Caution: Operation of the device without regulatory approval is illegal.
Country Selection
Select only the country in which the device will be used. Any other selection will make the operation of this device illegal.
Country Roaming
This device incorporates the International Roaming feature (IEEE802.11d), which will ensure the product operates on the correct
channels for the particular country of use.
Frequency of Operation – IC
2.4 GHz Only:
The available channels for 802.11 b/g operation in the US are Channels 1 to 11. The range of channels is limited by firmware.
Warnings for Use of Wireless Devices
Regulatory Guide (RG) Rev. A
Zebra Technologies Corporation Page 2 of 9
Zebra Confidential Restricted
Caution: Please observe all
warning notices with regard to the usage of wireless devices.
Potentially Hazardous Atmospheres – Fixed Installations
You are reminded of the need to observe restrictions on the use of radio devices in fuel depots, chemical plants etc. and areas
where the air contains chemicals or particles such as grain, dust, or metal powders.
Safety in Aircraft
Switch off your wireless device whenever you are instructed to do so by airport or airline staff. If your device offers a ‘flight mode’
or similar feature, consult airline staff as to its use in flight.
Safety in Hospitals
Wireless devices transmit radio frequency energy and may affect medical electrical equipement.
Wireless devices should be switched off wherever you are requested to do so in hospitals, clinics, or healthcare facilitlies. These
requests are designed to prevent possible interference with sensitive medical equipement.
Wireless devices transmit radio frequency energy and may affect medical electrical equipment. When installed adjacent to other
equipment, it is advised to verify that the adjacent equipment is not adversely affected.
Pacemakers
Pacemaker manufacturers recommended that a minimum of 15cm (6 inches) be maintained between a handheld wireless device
and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with independent
research and recommendations by Wireless Technology Research.
Persons with Pacemakers:
• Should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker when turned ON.
• Should not carry the device in a breast pocket.
• Should use the ear furthest from the pacemaker to minimise the potential for interference.
• If you have any reason to suspect that interference is taking place, turn OFF your device.
Other Medical Devices
Please consult your physician or the manufacturer of the medical device to determine if the operation of your wireless product
may interfere with the medical device.
RF Exposure Guidelines
Safety Information
• Reducing RF Exposure – Use Properly
Only operate the device in accordance with the instructions supplied.
• International
Regulatory Guide (RG) Rev. A
Zebra Technologies Corporation Page 3 of 9
Zebra Confidential Restricted
The device complies with internationally recognized standards covering human exposure to electromagnetic fields from
radio devices. For information on ’International‘ human exposure to electromagnet fields, refer to the Zebra Declaration
of Conformity (DoC) at http://www.zebra.com/doc
For further information on the safety of RF energy from wireless devices, see
.
http://responsibility.zebra.com/index.php/downloads/, which is located under Wireless Communications and Health.
US and Canada
o Co-located statement
To comply with FCC RF exposure compliance requirement, the antenna used for this transmitter must not be co-located
or operating in conjunction with any other transmitter/antenna except those already approved in this filling.
To satisfy US and Canadian RF exposure requirements, a transmitting device must operate with a
minimum separation distance of 40 cm or more from a person’s body.
Pour satisfaire aux exigences Américaines et Canadiennes d'exposition aux radio fréquences, un
dispositif de transmission doit fonctionner avec une distance de séparation minimale de 40 cm ou plus
de corps d'une personne.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 40 cm between the radiator and your body.
NOTE IMPORTANTE: (Pour l'utilisation de dispositifs mobiles)
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 40 cm de distance entre la source de
rayonnement et votre corps.
o Remote and Standalone Antenna Configurations
To comply with FCC RF exposure requirements, antennas that are mounted externally at remote locations or
operating near users at stand-alone desktop of similar configurations must operate with a minimum separation
distance of 40 cm from all persons.
To comply with FCC Antenna requirements, the Antenna must be adjust such that the RF emission lobes are
below 30 degrees elevation.
Regulatory Guide (RG) Rev. A
Zebra Technologies Corporation Page 4 of 9
Zebra Confidential Restricted
3. Radio Frequency Interference Requirements- FCC
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received including interference that may cause
undesired operation.
IMPORTANT NOTE:
This module is intended for OEM integrator. The OEM integrator is responsible for the compliance to all the rules that apply to the
product into which this certified RF module is integrated. Additional testing and certification may be necessary when multiple
modules are used.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 40 cm separation with the antenna while
this end product is installed and operated. The end user has to be informed that the FCC radio-frequency exposure guidelines for
an uncontrolled environment can be satisfied. The end user has to also be informed that any changes or modifications not
expressly approved by the manufacturer could void the user's authority to operate this equipment. If the size of the end product is
smaller than 8x10cm, then additional FCC part 15.19 statement is required to be available in the users manual: This device
complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received, including interference that may cause undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains TX FCC ID: UZ7CDR2G ". If the size of the
end product is larger than 8x10cm, then the following FCC part 15.19 statement has to also be available on the label: This
device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference and (2) this device must accept any interference received, including interference that may cause undesired
operation.
Regulatory Guide (RG) Rev. A
Zebra Technologies Corporation Page 5 of 9
Zebra Confidential Restricted
4. Radio Frequency Interference Requirements- Canada
CAN ICES-3 (B)/NMB-3(B)
Radio Transmitters
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radio électrique subi même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Label Marking: The Term ‘IC:’ before the radio certification only signifies that Industry Canada technical specifications were met.
In accordance with the regulations of Industry Canada, this radio transmitter can operate with an antenna of a type
and a maximum gain (or lower) approved for the transmitter by Industry Canada. With the aim of reducing the risk of
radio interference to other users, the chosen antenna type and it gain should be selected so that the equivalent
isotropically radiated power (e.i.r.p.) does not exceed the intensity necessary for the establishment of a satisfactory
connection.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne
d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les
risques de brouillage radio électrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de
sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement
d'une communication satisfaisante.
This radio transmitter (CDR2G) has been approved by Industry Canada to operate with the antenna types listed below
and having a maximum gain allowable and the impedance required for each type of antenna. The antenna types not
included in this list, or whose gain is higher than the maximum gain indicates, are strictly prohibited for the operation of
the transmitter.
Regulatory Guide (RG) Rev. A
Zebra Technologies Corporation Page 6 of 9
Zebra Confidential Restricted
The antenna list and types are included in the following table:
Part Number Antenna
Type
2.4
GHZ
Gain
(dBi) Impedance
(Ohms)
ML-2452-HPAG4A6-01 Dipole 4 50
ML-2452-APAG2A1-01 Dipole 2.7 50
ML-2452-HPA6-01 Dipole 5.3 50
ML-2452-APA2-01 Dipole 3.17 50
ML-2452-PNA5-01R Panel 5.5 50
ML-2452-SEC5M4-N36 Polarized
Panel 6.92 50
ML-2452-PTA4M4-036 Patch 5 50
ML-2499-HPA6H-01 Polarized
Dipole 5.4 50
ML-2452-HPAG4A6-01 Polarized
Dipole 4 50
CEDAR-INT-ANT Mono
pole
5.2 N/A
Le présent émetteur radio (CDR2G) a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne
énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les
types d'antenne non inclus dans cette liste ou dont le gain est supérieur au gain maximal indiqué, sont strictement
interdits pour l'exploitation de l'émetteur.
This module is intended for OEM integrator. The OEM integrator is still responsible for the IC compliance requirement
of the end product, which integrates this module.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 40 cm separation with the
antenna while this end product is installed and operated. The end user has to be informed that the IC radio-frequency
exposure guidelines for an uncontrolled environment can be satisfied. The end user has to also be informed that any
changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this
equipment. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may cause undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains IC: 109AN-CDR2G ".
The Host Model Number (HMN) must be indicated at any location on the exterior of the end product or product
packaging or product literature which shall be available with the end product or online.
Regulatory Guide (RG) Rev. A
Zebra Technologies Corporation Page 7 of 9
Zebra Confidential Restricted
5. CE Marking and European Economic Area (EEA)
WARNING: This is a Class B product. In a domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.
:
The use of 2.4GHz RLAN’s, for use through the EEA, have the following restrictions:
• Maximum radiated transmit power of 100mW EIRP in the frequency range 2.400 -2.4835 GHz.
Zebra hereby declares that this device is in compliance with the essential requirements and other relevant provisions of Directive
1999/5/EC and 2011/65/EU. A Declaration of Conformity may be obtained from
Statement of Compliance
http://www.zebra.com/doc.
6. Waste Electrical and Electronic Equipment (WEEE)
English: For EU Customers: All products at the end of their life must be returned to Zebra for recycling. For
information on how to return product, please go to: www.zebra.com/weee.
Français: Clients de l'Union Européenne: Tous les produits en fin de cycle de vie doivent être retournés à
Zebra pour recyclage. Pour de plus amples informations sur le retour de produits, consultez :
www.zebra.com/weee.
Español: Para clientes en la Unión Europea: todos los productos deberán entregarse a Zebra al final de su
ciclo de vida para que sean reciclados. Si desea más información sobre cómo devolver un producto, visite:
www.zebra.com/weee.
Български: За клиенти от ЕС: След края на полезния им живот всички продукти трябва да се връщат на
Zebra за рециклиране. За информация относно връщането на продукти, моля отидете на адрес:
www.zebra.com/weee.
Deutsch: Für Kunden innerhalb der EU: Alle Produkte müssen am Ende ihrer Lebensdauer zum Recycling an
Zebra zurückgesandt werden. Informationen zur Rücksendung von Produkten finden Sie unter
www.zebra.com/weee.
Italiano: per i clienti dell'UE: tutti i prodotti che sono giunti al termine del rispettivo ciclo di vita devono essere
restituiti a Zebra al fine di consentirne il riciclaggio. Per informazioni sulle modalità di restituzione, visitare il
seguente sito Web: www.zebra.com/weee.
Português: Para clientes da UE: todos os produtos no fim de vida devem ser devolvidos à Zebra para
reciclagem. Para obter informações sobre como devolver o produto, visite: www.zebra.com/weee.
Nederlands: Voor klanten in de EU: alle producten dienen aan het einde van hun levensduur naar Zebra te
worden teruggezonden voor recycling. Raadpleeg www.zebra.com/weee voor meer informatie over het
terugzenden van producten.
Polski: Klienci z obszaru Unii Europejskiej: Produkty wycofane z eksploatacji nale¿y zwróciæ do firmy Zebra w
celu ich utylizacji. Informacje na temat zwrotu produktów znajduj¹ siê na stronie internetowej
www.zebra.com/weee.
Čeština: Pro zákazníky z EU: Všechny produkty je nutné po skonèení jejich životnosti vrátit spoleènosti Zebra
k recyklaci. Informace o zpùsobu vrácení produktu najdete na webové stránce: www.zebra.com/weee.
Eesti: EL klientidele: kõik tooted tuleb nende eluea lõppedes tagastada taaskasutamise eesmärgil Zebra'ile.
Lisainformatsiooni saamiseks toote tagastamise kohta külastage palun aadressi: www.zebra.com/weee.
Magyar: Az EU-ban vásárlóknak: Minden tönkrement terméket a Zebra vállalathoz kell eljuttatni
újrahasznosítás céljából. A termék visszajuttatásának módjával kapcsolatos tudnivalókért látogasson el a
www.zebra.com/weee weboldalra.
Svenska: För kunder inom EU: Alla produkter som uppnått sin livslängd måste returneras till Zebra för
återvinning. Information om hur du returnerar produkten finns på www.zebra.com/weee.
Regulatory Guide (RG) Rev. A
Zebra Technologies Corporation Page 8 of 9
Zebra Confidential Restricted
Suomi: Asiakkaat Euroopan unionin alueella: Kaikki tuotteet on palautettava kierrätettäväksi Zebra-yhtiöön, kun
tuotetta ei enää käytetä. Lisätietoja tuotteen palauttamisesta on osoitteessa www.zebra.com/weee.
Dansk: Til kunder i EU: Alle produkter skal returneres til Zebra til recirkulering, når de er udtjent. Læs
oplysningerne om returnering af produkter på: www.zebra.com/weee.
Ελληνικά: Για πελάτες στην Ε.Ε.: Όλα τα προϊόντα, στο τέλος της διάρκειας ζωής τους, πρέπει να
επιστρέφονται στην Zebra για ανακύκλωση. Για περισσότερες πληροφορίες σχετικά με την επιστροφή ενός
προϊόντος, επισκεφθείτε τη διεύθυνση www.zebra.com/weee στο Διαδίκτυο.
Malti: Għal klijenti fl-UE: il-prodotti kollha li jkunu waslu fl-aħħar tal-ħajja ta' l-użu tagħhom, iridu jiġu rritornati
għand Zebra għar-riċiklaġġ. Għal aktar tagħrif dwar kif għandek tirritorna l-prodott, jekk jogħġbok żur:
www.zebra.com/weee.
Românesc: Pentru clienţii din UE: Toate produsele, la sfârşitul duratei lor de funcţionare, trebuie returnate la
Zebra pentru reciclare. Pentru informaţii despre returnarea produsului, accesaţi: www.zebra.com/weee.
Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku življenjske dobe vrniti podjetju Zebra za reciklažo.
Za informacije o vračilu izdelka obiščite: www.zebra.com/weee.
Slovenčina: Pre zákazníkov z krajín EU: Všetky výrobky musia byť po uplynutí doby ich životnosti vrátené
spoločnosti Zebra na recykláciu. Bližšie informácie o vrátení výrobkov nájdete na: www.zebra.com/weee.
Lietuvių: ES vartotojams: visi gaminiai, pasibaigus jų eksploatacijos laikui, turi būti grąžinti utilizuoti į kompaniją
„Zebra“. Daugiau informacijos, kaip grąžinti gaminį, rasite: www.zebra.com/weee.
Latviešu: ES klientiem: visi produkti pēc to kalpošanas mūža beigām ir jānogādā atpakaļ Zebra otrreizējai
pārstrādei. Lai iegūtu informāciju par produktu nogādāšanu Zebra, lūdzu, skatiet: www.zebra.com/weee.
Türkçe: AB Müşterileri için: Kullanım süresi dolan tüm ürünler geri dönüştürme için Zebra'ya iade edilmelidir.
Ürünlerin nasıl iade edileceği hakkında bilgi için lütfen şu adresi ziyaret edin: www.zebra.com/weee.
기 종 별
Korea Warning Statement for Class B ITE
사 용 자 안 내 문
B급 기기
(가정용 방송통신기자재)
이 기기는 가정용(B급) 전자파적합기기로서 주로
가정에서 사용하는 것을 목적으로 하며, 모든
지역에서 사용할 수 있습니다.
For a radio equipment using 2400~2483.5MHz or 5725~5825MHz, the following two expression should be displayed;
South Korea
해당 무선설비는 운용 중 전파혼신 가능성이 있음
해당 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없습니다
Regulatory Guide (RG) Rev. A
Zebra Technologies Corporation Page 9 of 9
Zebra Confidential Restricted
Taiwan
臺灣
低功率電波輻射性電機管理辦法
第十二條
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功
能。
第十四條
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使
用。
前項合法通信，指依電信規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
無線接入點 (專業安裝)
• 本公司於說明書中提供所有必要資訊以指導使用者/安裝者正確的安裝及操作」警語。
並於該中文使用說明書及器材上標示
• 本器材須經專業工程人員安裝及設定，始得設置使用，且不得直接販售給一般消費者」
警語。
電磁波曝露量MPE標準值1mW/cm²本產品使用時建議應距離人體 40 cm
