Zebra Technologies Corporation Active 13.56MHz NFC Module Installation Guide
Installation Guide
![](/img.php?id=2501872&img=bg1.png)
Installation Guide
1356NFC-ZQ500
![](/img.php?id=2501872&img=bg2.png)
Compliance and Statements
FCC Compliance Statement (USA)
This device complies with Part 15 rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for Class B Digital Devices,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a residential environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the product manuals, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, the
user is encouraged to do one or more of the following measures:
•
•
•
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced RF service technician for help.
•
The end product must be labeled, in a visible area, with the following:
Contains FCC ID: I28MD-1356NFC
Modification Warning
The user is cautioned that any changes or modifications not expressly approved by Zebra
Technologies could void the user s authority to operate the equipment. To ensure compliance, this
printer must be used with fully shielded communication cables.
RF Exposure Statement
This transmitter complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter, except in accordance with FCC multi- transmitter product procedures.
![](/img.php?id=2501872&img=bg3.png)
Canadian DOC Compliance Statement
Cet appareil numerique de la classe B est conforme a la norme NMB-003 du
Canada. This Class B digital apparatus complies with Canadian ICES-003.
Industry Canada (IC) Warning
Le present appareil est conforme aux CNR d Industrie Canada applicables aux appareils
radio exempts de licence. L exploitation est autorisee aux deux conditions suivantes : (1)
appareil ne doit pas produire de brouillage, et (2) l utilisateur de l appareil doit accepter
tout brouillage radioelectrique subi, meme si le brouillage est susceptible n
compromettre le fonctionnement.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: 1) This device may not cause interference., 2)
This device must accept any interference, including interference that may cause undesired
operation of the device.
The end product must be labeled, in a visible area, with the following:
Contains IC: 3798B-1356NFC
Approved Antenna information
Only Zebra approved antennas are allowed and cannot be user replaceable.
Antenna PN: P1027365-01
Type: Mag coupler Coil-PCB
![](/img.php?id=2501872&img=bg4.png)
General
The 1356NFC-ZQ500 NFC module has been certified as a Limited Single Modular. Additional
evaluation is
required for use in all host devices. The following describes the installation procedures
for the various hosts in which the module has been evaluated.
Installation Instructions for ZQ510 and ZQ520
The 1356NFC-ZQ500 is not intended for OEM integrators or end users. It can only be installed in the
ZQ510 and ZQ520
printers at the grantee manufacturing facility.
