Zebra Technologies MD-FXLAN11AC Wireless 802.11ac + Bluetooth Module User Manual
Zebra Technologies Corporation Wireless 802.11ac + Bluetooth Module
User Manual
Installation Guide
AC Radio Module
802.11ac/a/b/g/n + BT + BLE combo module
Compliance and Regulatory Statements
FCC Compliance Statement (USA)
This device complies with Part 15 rules. Operation is subject to the following two conditions:
1.
This device may not cause harmful interference, and
2.
This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for Class B Digital
Devices,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection
against harmful interference when the equipment is operated in a residential
environment. This
equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used
in accordance with the product manuals, may cause harmful interference
to radio
communications. However, there is no guarantee that interference will not occur in a
particular
installation. If this equipment does cause harmful interference to radio or television reception, the
user is encouraged to do one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced RF service technician for help.
The end product must be labeled, in a visible area, with the following:
Modification Warning
The user is cautioned that any changes or modifications not expressly approved by Zebra
Technologies could void the user’s authority to operate the equipment. To ensure compliance, this
printer must be used with fully shielded communication cables.
RF Exposure Statement
This transmitter complies with FCC radiation exposure limits set forth for an uncontrolled
environment. The antenna(s) used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter, except in accordance with FCC multi-
transmitter product procedures.
Contains FCC ID: I28MD-FXLAN11AC
Canadian DOC Compliance Statement
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada. This Class B digital apparatus complies with Canadian ICES-003.
Industry Canada (IC) Warning
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1)
l’appareil
ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter
tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le
fonctionnement.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: 1) This device may not cause interference., 2)
This device must accept any interference, including interference that may cause undesired
operation of the device.
Approved Antenna information
The end product must be labeled, in a visible area, with the following:
Contains IC: 3798B-FXLAN11AC
Only Zebra approved antennas are allowed and cannot be user replaceable.
Antenna Type:
Patch: Gain: 3.66dBi (2.4G); 3.19dBi (5G)
Omnidirectional: Gain 3dBi (2.4G); 5dBi (5G)
General
Installation Instructions for Zebra printers
The 802.11ac radio module is not intended for OEM Integrators or end users. it can only be installed at
the grantee manufacturing facility.
The802.11ac radio module hasbeencertifiedasaFullModular.Additionalevaluationis
requiredforuseinallhostdevices.Thefollowingdescribestheinstallationproceduresforthevarious
hostsinwhichthemodulehasbeenevaluated.
