RFID Printers
North America Price List
Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road, Suite 500
Lincolnshire, IL 60069 U.S.A.
Tel: +1 847 793 2600
+1 800 423 0442
Fax: +1 847 913 8766
www.zebra.com
Please note, not all printer part numbers on this price list are compliant with the Buy American Act (BAA) or the Trade Agreements
Act (TAA). Please refer to Zebra's BAA/TAA Printer price list for a select list of printer part numbers that are BAA/TAA compliant.
What’s Inside:
Product Information
RXi Series (UHF) 1
RXi Series (HF) 2
R110PAX4 3
RZ Series 4
RP4T& Accessories 5-6
RP4T Cables 7-8
R2844-Z Series 9
RFID Printer Acc. 10
RXi and RPAX Fonts 11-12
RZ Series Fonts 13
RFID Region Matrix 14
ZebraCare™ Service 15
Professional Services 16 - 18
Description
Base Printer Models (ZPL II Prog. Lang.) (choose one)
R 1 2 - 7 _ _ - _ _ _ _ _ - _ _ Zebra R110Xi Multi-Protocol RFID Reader - 200 dpi
R 1 3 - 7 _ _ - _ _ _ _ _ - _ _ Zebra R110Xi Multi-Protocol RFID Reader - 300 dpi
R 7 2 - 7 _ _ - _ _ _ _ _ - _ _ Zebra R170Xi Multi-Protocol RFID Reader - 200dpi
R 7 0 - 7 _ _ - _ _ _ _ _ - _ _ Zebra R170Xi Multi-Protocol Reader - 300 dpi
Communications Options (choose one) Reference Region Availability
Matrix for 802.11g options
_ _ _ - _ 0 _ - _ _ _ _ _ - _ _ RS-232 Serial, Parallel & USB 2.0 (Standard)
_ _ _ - _ 5 _ - _ _ _ _ _ - _ _ RS-232/RS-422/485 Serial, Parallel & USB 2.0 & Applicator Interface Port
_ _ _ - _ A _ - _ _ _ _ _ - _ _ Internal ZebraNet 10/100 PrintServer, RS-232, & USB 2.0
_ _ _ - _ B _ - _ _ _ _ _ - _ _
Internal ZebraNet 10/100 PrintServer , RS-232 Serial & USB 2.0 & Applicator
Interface Port
_ _ _ - _ E _ - _ _ _ _ _ - _ _ ZebraNet Wireless Plus (Radio card not included)
_ _ _ - _ F _ - _ _ _ _ _ - _ _
ZebraNet Wireless Plus & Internal ZebraNet 10/100 Printserver (Radio card
not included.)
_ _ _ - _ G _ - _ _ _ _ _ - _ _ ZebraNet Internal Wireless Plus (radio card included)
_ _ _ - _ H _ - _ _ _ _ _ - _ _
ZebraNet Internal Wireless Plus & Internal ZebraNet 10/100 PrintServer(radio
card included)
_ _ _ - _ J _ - _ _ _ _ _ - _ _ SEH PS102-Z Internal IPV6 Print Server
Regional Edition, A/C Power Configuration and Cord
_ _ _ - _ _ 1 - _ _ _ _ _ - _ _ North American Edition, 120 VAC Cord
_ _ _ - _ _ 2 - _ _ _ _ _ - _ _ No Cord
_ _ _ - _ _ 4 - _ _ _ _ _ - _ _ European Edition, 240 VAC Cords with European and UK Plug
_ _ _ - _ _ 5 - _ _ _ _ _ - _ _ Argentina Edition, 240 VAC Cord
_ _ _ - _ _ 6 - _ _ _ _ _ - _ _ Australian Edition, 240 VAC Cord
_ _ _ _ _ 7 _ _ _ _ _ _ _ Taiwan Edition, 120 VAC Cord
_ _ _ _ _ 9 _ _ _ _ _ _ _ Chinese Edition, 240 VAC Cord
Font Options (choose one)
_ _ _ - _ _ _ - 0 0 _ _ _ - _ _ Do not include this option
_ _ _ - _ _ _ - X X _ _ _ - _ _ To include this option see font list for selection and specifications
Media Options (choose one)
_ _ _ - _ _ _ - _ _ 0 _ _ - _ _ None (Standard)
_ _ _ - _ _ _ - _ _ 1 _ _ - _ _ Cutter with Catch Tray
_ _ _ - _ _ _ - _ _ 2 _ _ - _ _ Rewind with Peel
SDRAM Memory and Languages
_ _ _ - _ _ _ - _ _ _ 0 _ - _ _ 16MB SDRAM (Standard) with ZPLII and XML
_ _ _ - _ _ _ - _ _ _ 1 _ - _ _
64MB On-Board Linear Flash Memory w/ ZPLII and XML (Factory Installed
Only)
Other Factory Installed Options (choose one)
_ _ _ - _ _ _ - _ _ _ _ 0 - _ _ Clear Media Side Door & Media Hanger
_ _ _ - _ _ _ - _ _ _ _ 1 - _ _ Clear Media Side Door & 3-inch Media Supply Spindle
_ _ _ - _ _ _ - _ _ _ _ 3 - _ _ Clear Bi-fold Media Side Door & Media Hanger
_ _ _ - _ _ _ - _ _ _ _ 4 - _ _ Clear Bi-fold Media Side Door & Media Supply Spindle
Region/Country Configuration (choose one)
_ _ _ - _ _ _ - _ _ _ _ _ - _ _ RFID Configured for US, Canada, and Latin America (Leave Blank)
_ _ _ - _ _ _ - _ _ _ _ _ - R 2 RFID Configured for Operations in Australia & New Zealand
_ _ _ - _ _ _ - _ _ _ _ _ - R 6 RFID Configured for Operations in Taiwan
_ _ _ - _ _ _ - _ _ _ _ _ - R 9 RFID Configured for Operations in Brazil
_ _ _ - _ _ _ - _ _ _ _ _ - R A RFID Configured for Operations in China
_ _ _ - _ _ _ - _ _ _ _ _ - R B RFID Configured for Operation in Hong Kong, Singapore and Thailand
_ _ _ - _ _ _ - _ _ _ _ _ - R E RFID Configured for Operation in El Salvador
R 1 3 - 7 A 1 - 0 0 2 0 3 - _ _
Example: Zebra 110Xi IIIPlus - 300 dpi Printer including internal ZebraNet
10/100 PrintServer, 120 VAC cord with US plug, rewind, 16MB SDRAM
memory, and clear bi-fold media side door & media supply hanger, configured
for US
N/C
170
170
50
N/C
120
120
50
295
395
695
795
R170Xi
R110Xi
N/C
N/C
RXi ™ Series Price List (UHF)
North America, Latin America and South America
Prices are in U.S. Dollars. EXW Vernon Hills, IL, USA.
Minimum billing for orders is $50.00 per shipment per location.
RXi - Configurator (UHF) Reference Region Availability Matrix for Country availability. R Xi
printers include:RXi User's Guide, Ztools Utilities, ZPL II Programming Guide, Zebra Designer, Zebra Designer Pro, BAR-ONE for
R/3 (mySAP.com), Zebra's Universal Windows Printer Driver, ZebraNet WebView and Alert Utilities, Adobe Acrobat, Direct Zebra
Web Access, ZebraNet Connectivity CD for PSII, PS10/100 and Wireless Print Server, ZBI-Ready.
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
1
SPECIFICATIONS AND PRICES SUBJECT TO
CHANGE WITHOUT NOTICE
Description
Base Printer Models (ZPL II Prog. Lang.) (choose one)
H 1 2 - 7 _ _ - _ _ _ _ _ Zebra R110Xi High Frequency RFID Reader- 200 dpi
H 1 3 - 7 _ _ - _ _ _ _ _ Zebra R110Xi High Frequency RFID Reader- 300 dpi
Communications Options (choose one) Reference Region Availability
Matrix for 802.11g options
_ _ _ - _ 0 _ - _ _ _ _ _ RS-232 Serial, Parallel & USB 2.0 (Standard)
_ _ _ - _ 5 _ - _ _ _ _ _ RS-232/RS-422/485 Serial, Parallel & USB 2.0 & Applicator Interface Port
_ _ _ - _ A _ - _ _ _ _ _ Internal ZebraNet 10/100 PrintServer, RS-232, & USB 2.0
_ _ _ - _ B _ - _ _ _ _ _
Internal ZebraNet 10/100 PrintServer , RS-232 Serial & USB 2.0 &
Applicator Interface Port
_ _ _ - _ E _ - _ _ _ _ _ ZebraNet Wireless Plus PrintServer (does not include radio card)
_ _ _ - _ F _ - _ _ _ _ _ ZebraNet Wireless PrintServer & Internal ZebraNet 10/100 Printserver
_ _ _ - _ G _ - _ _ _ _ _ ZebraNet Internal Wireless Plus (radio card included)
_ _ _ - _ H _ - _ _ _ _ _
ZebraNet Internal Wireless Plus & Internal ZebraNet 10/100
PrintServer(radio card included)
_ _ _ - _ J _ - _ _ _ _ _ SEH PS102-Z Internal IPV6 Print Server
Regional Edition, A/C Power Configuration and Cord (choose one)
_ _ _ - _ _ 1 - _ _ _ _ _ North American Edition, 120 VAC Cord
_ _ _ - _ _ 2 - _ _ _ _ _ No Cord
_ _ _ - _ _ 9 - _ _ _ _ _ Chinese Edition, 240 VAC Cord
Font Options (choose one)
_ _ _ - _ _ _ - 0 0 _ _ _ Do not include this option
_ _ _ - _ _ _ - X X _ _ _ To include this option see font list for selection and specifications
Media Options (choose one)
_ _ _ - _ _ _ - _ _ 0 _ _ None (Standard) N/C
_ _ _ - _ _ _ - _ _ 1 _ _ Cutter with Catch Tray 695
_ _ _ - _ _ _ - _ _ 2 _ _ Rewind Option with Peel 295
SDRAM Memory and Languages
_ _ _ - _ _ _ - _ _ _ 0 _ 16MB Memory with ZPL II and XML (Standard)
_ _ _ - _ _ _ - _ _ _ 1 _
64 MB On-Board Linear Flash Memory ZPL II and XML (61 MB user
available)
Other Factory Installed Options (choose one)
_ _ _ - _ _ _ - _ _ _ _ 0 Clear Media Side Door & Media Hanger N/C
_ _ _ - _ _ _ - _ _ _ _ 1 Clear Media Side Door & 3-inch Media Supply Spindle 50
_ _ _ - _ _ _ - _ _ _ _ 3 Clear Bi-fold Media Side Door & Media Hanger 120
_ _ _ - _ _ _ - _ _ _ _ 4 Clear Bi-fold Media Side Door & 3-inch Media Supply Spindle 170
H 1 3 - 7 A 1 - 0 0 2 0 3
Example: Zebra R110Xi - 300 dpi Printer with High Frequency RFID
Reader, including internal ZebraNet 10/100 PrintServer, 120 VAC cord with
US plug, rewind, 16MB SDRAM memory, and clear bi-fold media side door
& media supply hanger.
Cost
$4610
150
N/C
N/C
see pages 12-13
N/C
N/C
195
N/C
N/C
249
3995
4195
299
499
499
N/C
499
499
RXi ™ Series Price List (HF)
North America, Latin America and South America
Prices are in U.S. Dollars. EXW Vernon Hills, IL, USA.
Minimum billing for orders is $50.00 per shipment per location.
RXi Series - Configurator (HF -13.56MHz)
Reference RFID Region Availability Matrix
RXi printers include: RXi printers include: RXi User's Guide, Ztools Utilities, ZPL II Programming Guide, Zebra Designer, Zebra Designer Pro, BAR-ONE
for R/3 (mySAP.com), Zebra's Universal Windows Printer Driver, ZebraNet WebView and Alert Utilities, Adobe Acrobat, Direct Zebra Web Access,
ZebraNet Connectivity CD for PSII, PS10/100 and Wireless Print Server, ZBI-Ready.
List Price
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
2
SPECIFICATIONS AND PRICES SUBJECT TO
CHANGE WITHOUT NOTICE
Description
Base Print Engine Models (choose one)
R 1 2 E R _ _ - _ _ _ _ _ Zebra R110PAX4 (203dpi, 12 ips, right-hand)
R 1 2 E L _ _ - _ _ _ _ _ Zebra R110PAX4 (203dpi, 12 ips, left-hand)
R 1 3 E R _ _ - _ _ _ _ _ Zebra R110PAX4 (300dpi, 8 ips, right-hand)
R 1 3 E L _ _ - _ _ _ _ _ Zebra R110PAX4 (300dpi, 8 ips, left-hand)
Communications Options (choose one)
_ _ _ _ _ 0 _ - _ _ _ _ _ High Speed Serial (RS-232) and Parallel (IEEE-1284)
_ _ _ _ _ 3 _ - _ _ _ _ _ Internal ZebraNet® PrintServer 10/100 (in lieu of Parallel)
Regional Edition, A/C Power Configuration and Cord (choose one)
_ _ _ _ _ _ 1 - _ _ _ _ _ North American Edition, 120 VAC Cord
_ _ _ _ _ _ 2 - _ _ _ _ _ No Cord
Font Options (choose one)
_ _ _ _ _ _ _ - 0 0 _ _ _ Do not include an optional font
_ _ _ _ _ _ _ - X X _ _ _ To include this option see font list for selection and specifications
PC Card (PCMCIA) Option -Reference Region Availability Matrix for 802.11g options
_ _ _ _ _ _ _ - _ _ 0 _ _ Memory Socket board for PC Card (PCMCIA) and Compact Flash Memory Cards*
_ _ _ _ _ _ _ - _ _ 6 _ _ ZebraNet Internal Wireless Plus (radio card included)
Flash Memory Options
_ _ _ _ _ _ _ - _ _ _ 0 _ Standard ZPL & 4MB Flash (2MB User Available)
Applicator Interface Options
_ _ _ _ _ _ _ - _ _ _ _ 0 5V I/O Applicator Interface Card
_ _ _ _ _ _ _ - _ _ _ _ 2 24V - 28V I/O Applicator Interface Card
R 1 2 E R 0 1 - 0 0 5 0 2
Example Option Pricing: Zebra R110PAX4 (203 dpi, right hand) including Serial & Parallel Ports
with US Cord, ZebraNet Internal Wireless Print Server, 2MB Flash and 24V-28V I/O Applicator
Interface Card
N/C
N/C
N/C
Sample Configuration
contract price + 499
499
N/C
see pages 12-13
N/C
By contract
R110PAX 4™ Series Price List
Zebra North America Only
Prices are in U.S. Dollars. EXW Vernon Hills, IL, USA.
Minimum billing for orders is $50.00 per shipment per location.
R110PAX4 Series - Configurator
Reference RFID Region Availability Matrix
List Price
N/C
N/C
N/C
N/C
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
3
SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
Description
RZ400 - 8 dot/mm (203 dpi), ZPL II & XML, 16MB SDRAM, Power Cord w/US plug - 120
VAC, Serial, Parallel, USB, RFID Configured for US & Canada
RZ400 - 8 dot/mm (203 dpi), ZPL II & XML, 16MB SDRAM, Power Cord w/US plug - 120
VAC, Internal ZebraNet 10/100 PrintServer, RFID Configured for US & Canada
RZ400 - 12 dot/mm (300 dpi), ZPL II & XML, 16MB SDRAM, Power Cord w/US plug - 120
VAC, Serial, Parallel, USB, RFID Configured for US & Canada
RZ400 - 12 dot/mm (300 dpi), ZPL II & XML, 16MB SDRAM, Power Cord w/US plug - 120
VAC, Internal ZebraNet 10/100 PrintServer, RFID Configured for US & Canada
RZ600 - 8 dot/mm (203 dpi), ZPL II & XML, 16MB SDRAM, Power Cord w/US plug - 120
VAC, Serial, Parallel, USB, RFID Configured for US & Canada
RZ600 - 8 dot/mm (203 dpi), ZPL II & XML, 16MB SDRAM, Power Cord w/US plug - 120
VAC, Internal ZebraNet 10/100 PrintServer, RFID Configured for US & Canada
Description
Base Printer Model and Resolution
R Z 4 0 0 - 2 _ _ _ - _ _ _ _ _ RZ400 - 8 dot/mm (203 dpi)
R Z 4 0 0 - 3 _ _ _ - _ _ _ _ _ RZ400 - 12 dot/mm (300 dpi)
R Z 6 0 0 - 2 _ _ _ - _ _ _ _ _ RZ600 - 8 dot/mm (203 dpi)
R Z 6 0 0 - 3 _ _ _ - _ _ _ _ _ RZ600 - 12 dot/mm (300 dpi)
Programming Language
_ _ _ _ _ - _ 0 _ _ - _ _ _ _ _ ZPL II and XML
Flash Memory
_ _ _ _ _ - _ _ 0 _ - _ _ _ _ _ 16MB SDRAM (Standard)
_ _ _ _ _ - _ _ 1 _ - _ _ _ _ _ 64MB On Board Linear Flash Memory (Factory Installed Only)
Power Cords
_ _ _ _ _ - _ _ _ 0 - _ _ _ _ _ No Power Cord
_ _ _ _ _ - _ _ _ 1 - _ _ _ _ _ Power Cord with US plug; 120VAC
_ _ _ _ _ - _ _ _ 4 - _ _ _ _ _ Power Cord with European and UK plug; 240VAC
_ _ _ _ _ - _ _ _ 5 - _ _ _ _ _ Power Cord with Argentinean plug; 240VAC
_ _ _ _ _ - _ _ _ 6 - _ _ _ _ _ Power Cord with Australian plug;240VAC
_ _ _ _ _ - _ _ _ 7 - _ _ _ _ _ Power Cord with Taiwan additions;240VAC
_ _ _ _ _ - _ _ _ 9 - _ _ _ _ _ Chinese Edition, 240 VAC Cord
Media Handling Options
_ _ _ _ _ - _ _ _ _ 0 _ _ _ _ Standard version
_ _ _ _ _ - _ _ _ _ - 1 _ _ _ _ Cutter
_ _ _ _ _ - _ _ _ _ - 3 _ _ _ _ Passive Peel (No Liner Takeup Spindle)
_ _ _ _ _ - _ _ _ _ - 4 _ _ _ _ Peel with full roll liner take-up (RZ400 only)
_ _ _ _ _ - _ _ _ _ - 5 _ _ _ _ Peel with full roll rewind
Communication Options - Reference RFID Region Availability Matrix for 802.11g
_ _ _ _ _ - _ _ _ _ _ 0 _ _ _ Serial, Parallel, USB (Standard)
_ _ _ _ _ - _ _ _ _ - _ 1 _ _ _ Internal ZebraNet Printserver 10/100, Serial, Parallel, USB
_ _ _ _ _ - _ _ _ _ - _ 4 _ _ _ ZebraNet Internal Wireless Plus (card included), Serial, Parallel, USB
_ _ _ _ _ - _ _ _ _ - _ 5 _ _ _ ZebraNet Internal Wireless Plus & Internal ZebraNet 10/100 Print Server (radio card not included), Serial, Parallel, USB
Fonts
_ _ _ _ _ - _ _ _ _ - _ _ 0 _ _ Standard
_ _ _ _ _ - _ _ _ _ - _ _ X _ _ See Font Page for Options
Region/Country Configuration (choose one) - Reference RFID Region List for Model Availabilty
_ _ _ _ _ - _ _ _ _ - _ _ _ R 0 RFID Configured for US, Canada, and Latin America
_ _ _ _ _ - _ _ _ _ - _ _ _ R 2 RFID Configured for Operation in Australia and New Zealand
_ _ _ _ _ - _ _ _ _ - _ _ _ R 6 RFID Configured for Operation in Taiwan
_ _ _ _ _ - _ _ _ _ - _ _ _ R A RFID Configured for Operation in China
_ _ _ _ - _ _ _ _ - _ _ _ R B RFID Configured for Operation in Hong Kong, Singapore, Malaysia, and Thailand
_ _ _ _ - _ _ _ _ - _ _ _ R D RFID Configured for Operation in India
_ _ _ _ _ - _ _ _ _ - _ _ _ R H RFID Configured for Operations in Korea
Example
R Z 4 0 0 - 2 0 0 1 - 0 4 0 R 0
Description: Zebra RZ400 UHF RFID Thermal Transfer Printer, 203 dpi, Internal ZebraNet Wireless Plus,
16MB SDRAM, US Power Cord, RFID Configured for US/Can
Zebra RZ Series™ Price List
North America, Latin America & Asia Pacific
Prices are in U.S. Dollars. EXW Vernon Hills, IL, USA.
Minimum billing for orders is $50.00 per shipment per location.
RZ400/RZ600 - Common Configuration Price List
Reference RFID Region Availability Matrix
The following part numbers are classified as common configurations, which means they are the most popular configurations and are
readily available from Zebra and our authorized Distribution partners.
List Price
5294
RZ600-2001-010R0
3595
RZ400-2001-000R0
RZ400-2001-010R0
RZ400-3001-010R0
3894
RZ400-3001-000R0
4294
3995
4995
RZ600-2001-000R0
List Price
3595
RZ400/RZ600 - Configurator
Reference RFID Region Availability Matrix
Unique printer configurations which combine specific options and features are also available, using thepart number configurator below.
Longer lead times may apply to unique configurations.
NC
Choose a single number for each column
4995
3995
5395
6"
4"
N/C
N/C
200
N/C
N/C
N/C
N/C
N/C
N/C
N/C
175
250
N/C
299
495
895
N/C
725
N/A
695
375
N/C
See page 14
N/C
N/C
595
N/C
499
N/C
4094
N/C
N/C
N/C
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
4SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
Description
List
Price
Base Printer Model (CPCL Programming Language with ZPL/EPL/XML support)
P 4 D - _ _ _ _ _ _ _ _ - _ _ RP4T (4 inch, 32-bit processor, USB, 8MB FLASH/ 16MB RAM, CPCL/EPL/ZPL/XML ) 3195
RFID - Please check certification table in Appendix B for product availability by country.
_ _ _ - U _ _ _ _ _ _ _ - _ _ US, Canada, and Latin America N/C
_ _ _ - 1 _ _ _ _ _ _ _ - _ _ EU/EFTA (Does not include Croatia), Turkey, and UAE N/C
_ _ _ - 2 _ _ _ _ _ _ _ - _ _ Australia/New Zealand N/C
_ _ _ 6 _ _ _ _ _ _ _ - _ _ Taiwan N/C
_ _ _ A _ _ _ _ _ _ _ - _ _ China N/C
_ _ _ B _ _ _ _ _ _ _ - _ _ Malaysia, Singapore, Thailand N/C
_ _ _ C _ _ _ _ _ _ _ - _ _ Philippines N/C
_ _ _ H _ _ _ _ _ _ _ - _ _ South Korea N/C
Character Set (choose one) *for Hebrew or Arabic select “U” for part number selection
_ _ _ - _ D _ _ _ _ _ _ - _ _ Chinese 16 x 16 (traditional) N/C
_ _ _ - _ H _ _ _ _ _ _ - _ _ Chinese 16 x 16 (Simplified) N/C
_ _ _ - _ I _ _ _ _ _ _ - _ _ Chinese 24 x 24 (Simplified) N/C
_ _ _ - _ U _ _ _ _ _ _ - _ _ *US/Canadian English/Latin 1 & 5 (Incl. Turkish) N/C
Connectivity (choose one) Please check certification table in Appendix B for product availability by
country.
_ _ _ - _ _ 1 _ _ _ _ _ - _ _ None (serial and USB cable ready) N/C
_ _ _ - _ _ B _ _ _ _ _ - _ _ Bluetooth 150
_ _ _ - _ _ K _ _ _ _ _ - _ _ Zebra Value Radio, 802.11b/g 350
Media Handling (choose one)
_ _ _ - _ _ _ 0 _ _ _ _ - _ _ Internal media only N/C
_ _ _ - _ _ _ 1 _ _ _ _ - _ _ Add slot for external fanfold media N/C
Regional Grouping Codes- **Please check certification table in Appendix B for product availability by
country.
_ _ _ - _ _ _ _ 0 0 _ _ - _ _ Grouping "0": (US/Canada/Mexico/Australia/New Zealand) N/C
_ _ _ - _ _ _ _ A 0 _ _ - _ _ Grouping "A": (Taiwan, South Korea) N/C
_ _ _ - _ _ _ _ B 0 _ _ - _ _ Grouping "B": (China/Singapore/Thailand/Philippines) N/C
_ _ _ - _ _ _ _ E 0 _ _ - _ _
Grouping "E" (RoHS-compliant): EMEA/EU/India/Russia:
(Austria/Belgium/Cypress/Czech/Denmark/Estonia/Finland/France/Germany/Greece/Hungry/Iceland/Ireland/It
aly/Latvia/Liechtenstein/Lithuania/Luxembourg/Malta/Netherlands/Norway/Poland/Portugal/Slovakia/
Slovenia/Spain/Sweden/Switzerland/Turkey/UK)
N/C
Customer Options
_ _ _ - _ _ _ _ _ _ 0 1 - 0 0 Default: 19.2 Baud; DTR Pwr-Off Enable; Handshake HW (CTS/RTS); CPCL/EPL/ZPL N/C
P 4 D - U U K 0 0 0 0 1 - 0 0
Example: RP4T printer with US/Canadian/ English/Latin character set, RFID and 802.11g for use in US and
Canada
3545
Zebra RP4T Price List
North America, Latin America & Asia Pacific
Prices are in U.S. Dollars. EXW Vernon Hills, IL, USA.
Minimum billing for orders is $50.00 per shipment per location.
RP4T - 203 dpi Thermal Transfer RFID Printer
Part Number
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
5SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
Description
List
Price
Handling Options:
RP4T Soft Case 85
Mobile Mount: Select one mobile mount option and one power supply option
Handi-Mount (compact, flexible RAM arm) with Base Plate 300
Handi-Mount (compact, flexible RAM arm) without Base Plate 225
QL 420 Plus/P4T Heavy Duty Forklift Mount Kit (with U-Arm bracket and fanfold bin) 475
Fanfold Bin (includes media spacer and mounting hardware) 70
Li-Ion DC/DC 15 - 60 VDC adapter (for use with forklifts without RP4T Vehicle Cradle) 95
12-15 VDC Cable Lighter Adapter (for use without RP4T Vehicle Cradle) 135
12-15 VDC Cable Unterminated Wires (for use without RP4T Vehicle Cradle) 135
RP4T Vehicle Cradle with Lighter Adapter - English, Spanish, French Manual 225
RP4T Vehicle Cradle Open-Ended Terminals - English, Spanish, French Manual 225
Li-Ion DC/DC 15 - 60 VDC adapter (ONLY for use with the P4T vehicle cradle and forklifts) 95
RAM Mount 99
Power System Options:
Spare Batteries:
Smart Li-Ion Battery for the RP4T 160
AC Adpater (for charging single battery inside printer)
AC Adapter, US AC cable 95
AC Adapter, UK AC cable 95
AC Adapter, European AC cable 95
AC Adapter, China AC cable 95
AC Adapter, Australia/New Zealand AC cable 95
AC Adapter, Argentina AC cable 95
AC Adaptor, Japan AC cable 95
AC Adaptor, Brazil AC cable 95
AC Adaptor, Singapore AC cable 95
Li-Ion Single Chargers (for charging single battery outside printer) Li72:
US 115
UK 115
Europe 115
Australia 115
For use in countries with an unsupported AC plug. Use with locally sourced AC cable with IEC 60320 type
C7 Connector.
115
Li-Ion Quad Charger (charges up to 4 QL/QL Plus/RW/RP4T batteries)
US 550
UK 550
Europe 550
Australia 550
Operational Options:
XML Support Utility CD: Applications and documentation files 10
Cleaning Supplies:12 printhead cleaning pens 40
Printer Cable Pricing
Cables:
Unterminated: 6' Straight locking 25
USB-A to RJ45 via USB; Strain relief locking AP DTR 23
Zebra RP4T Price List
North America, Latin America & Asia Pacific
Prices are in U.S. Dollars. EXW Vernon Hills, IL, USA.
Minimum billing for orders is $50.00 per shipment per location.
Lithium ion batteries have a limited life, and Zebra recommends a regular replacement cycle. To learn about Zebra's Battery Refresh Program, visit the 'Service
and Support' section of AccessZebra or www.zebra.com/batteries."
Batteries
Vehicle
RP4T Accessories
Personal
P/N
AK18924-1
AK18926-1
AK18831-1
AK18926-2
AK18926-3
AN16618-1
AK18831-2
P1005317-001
AK18913-015
AK18913-003
Other
AK18666-1
AL17594-812
AN11209-1
AK18388-001
AC18177-1
AC18177-2
Charging
AT17696-3
AC18177-3
AT17696-1
AT17696-4
AT17696-6
AT17696-2
AC18177-5
AK18913-009
AK18913-011
AK18913-010
P1005317-002
AK18913-012
AK18914-014
AK18913-007
AK18913-006
P1010338
AK18913-002
AK18913-001
AK18913-013
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
6SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
Model Connector Type
RW & RP4T
Part #
RW & RP4T
Part $
Cable Type
CK30, CK31 JAE-26M AK17594-119 $85.00 8' Coiled AP DTR
CK60
DB-9M using I-mec #225-
690-002
BL17205-1 $40.00 6' Straight locking AP DTR
CN2
DB-9M using Intermec
#074247
BL17205-1 $40.00 6' Straight locking AP DTR
CT60, CV60, CV30 DB-9M BL17205-1 $40.00 6' Straight locking AP DTR
700 Hirose, 16F Pin AK18246-1 $80.00 6' coiled
241X AMP Pocket Phone
243x
DB-9M with Serial Connector
Module #071775
BL17205-1 $40.00 6' Straight locking AP DTR
246X DM-9M BL17205-1 $40.00 6' Straight locking AP DTR
248X DB-9M COM1 BL17205-1 $40.00 6' Straight locking AP DTR
502X
Intermec L5020 Adapter
DB-9
BL17205-1 $40.00 6' Straight locking AP DTR
6110 DB-9M Using the Serial Pod BL17205-1 $40.00 6' Straight locking AP DTR
6640, 665X DB-9M BL17205-1 $40.00 6' Straight locking AP DTR
Model Connector Type
RW & RP4T
Part #
RW & RP4T
Part $
Cable Type
MC50
Micro DB-15 using ADP5000-
00 Pod
AK17594-341 $39.00 8' coiled AP DTR
MC70
Avial. from
Motorola
MC1000 Clip-On AK17594-347 $85.00 8' coiled AP DTR
Clip-On AK17594-345 $85.00 8' coiled AP DTR
MC9000-G Series
DB-15 using ADP 9000-100
pod
AK17594-343 $39.00 8' coiled AP DTR
MK1100, MK2000 MOD 10 AK17594-337 $39.00 8' coiled AP DTR
AK17594-813 $39.00 8' Coiled AP +5v
AK17594-335 $39.00 8' coiled APDTR
PDT 8000 Clip-On AK17463-010 $125.00 6' coiled
PPT 8800
Micro DB-15 using
UCC8800-00 Pod
AK17594-341 $39.00 8' coiled APDTR
PTC 1124, 2124 DB-9M Using Serial Pod BL17205-1 $40.00 6' Straight locking AP DTR
PTC 1194 DB-9M BL17205-1 $40.00 6' Straight locking AP DTR
VC5090
Avial. from
Motorola
VRC 4000 DB-9M BL17205-1 $40.00 6' Straight locking AP DTR
VRC 5000 DB-9M BL17205-1 $40.00 6' Straight locking AP DTR
6' Straight locking AP DTR
FMT 1000, 3000
DB-9M
MC3000
PDT 3100, 3200, 3500, 6100
MOD-10
$40.00
DB-9M
RP4T Printer Cable Pricing
BL17205-1
6400
$40.00
6' Straight locking AP DTR
$40.00
DB-9M w/optical link adapter
#064021
242X
6' Straight locking AP DTR
6' Straight locking AP DTR
RFID Printers Price List
6' Straight locking AP DTR
7500, 7506
$40.00
BL17205-1
6' Straight locking AP DTR
RP4T Printer Cable Pricing
2020
DB-9M
BL17205-1
Intermec / Norand
Motorola/Symbol / Telxon
$40.00
DB-9M
5055
BL17205-1
BL17205-1
$40.00
BL17205-1
DB-9M
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
7
SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
Model Connector Type
RW & RP4T
Part #
RW & RP4T
Part $
Cable Type
Powerscan RJ-45 MOD 8 AK18218-1 $45.00 4' Coiled
Tek
7530, 7535 and 8530
RJ45 AK17594-400 $125.00 8' Spiral
AK17594-812 $25.00 6' Straight Locking
AK17594-817 $25.00 8' Coiled Locking
1/4" Phone Jack/ DEX AK17594-810 $36.00 1' Straight Locking
USB-A to RJ45 via USB AK18666-2 $23.00 Strain relief daily use
USB-A AT17010-1 $23.00 to Mini USB setup only
BL17205-1
PC
All
Other
BL17205-1
BL17205-1
DB-9M
DB-9M
Unitech
PT-805
PT-815
All
DB-9M
Unterminated
DB-9M
BL17205-1
6' Straight locking AP DTR
$40.00
6' Straight locking AP DTR
6' Straight locking AP DTR
$40.00
$40.00
PT-700
DB-9M
PT-500
BL17205-1
6' Straight locking AP DTR
$40.00
6' Straight locking AP DTR
$40.00
6' Straight locking AP DTR
$40.00
Falcon 310, 315, 320, 325
MOD-10
Falcon 510, 515, 625, 665
DB-9M
BL17205-1
DB-9M
1380, 1390, 1590
6' Straight locking AP DTR
BL17205-1
$39.00
6' Straight locking AP DTR
$40.00
$40.00
8' Coiled AP +5v
MX1, MX3
RFID Printers Price List
$40.00
RP4T Printer Cable Pricing
DB-9M
6' Straight locking AP DTR
BL17205-1
PSC
LXE
VX1, VX2, VX4
BL17205-1
AK17594-813
DB-9M
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
8
SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
R2844-Z Series - Custom Configurations
(choose one item from each section to form a complete part number)
Part Number Description
Suggested
List Price
Base Printer
R284 - 1 _ _ _ _ - _ _ _ _ R2844 with Thermal Transfer Print Technology and ZPL Command Language 1,695
Interface
____ - _ 0 3 _ _ - _ _ _ _ Parallel, RS232 Serial and USB N/C
____ - _ 0 4 _ _ - _ _ _ _ RS232 Serial, USB and Optional Internal ZebraNet Print Server II 249
Power
____ - _ _ _ 0 _ - _ _ _ _ 100-240V A.C. USA and European N/C
____ - _ _ _ 3 _ - _ _ _ _ 240V A.C. U.K. N/C
____ - _ _ _ 4 _ - _ _ _ _ 240V A.C. Australian N/C
____ - _ _ _ 7 _ - _ _ _ _ 220V A.C. Chinese Agency Certified N/C
____ - _ _ _ 9 _ - _ _ _ _ 110-220V A.C. Japan, European, USA N/C
Media Options
____ - _ _ _ _ 0 - _ _ _ _ No Options (standard) N/C
____ - _ _ _ _ 1 - _ _ _ _ Dispenser 35
Printer Font Set
____ - _ _ _ _ _ - 0 0 _ _ USA and European N/C
Memory
____ - _ _ _ _ _ - _ _ 0 _ Standard Flash, Standard SDRAM, No Real Time Clock N/C
User Documentation
____ - _ _ _ _ _ - _ _ _ 1 English N/C
Example:
R284 - 1 0 3 0 1 - 0 0 0 1
R2844-Z with Thermal Transfer Print Technology and ZPL Command Language
Parallel, RS232 Serial & USB Interface, USA and European Power, Dispenser,
USA and European Font Set Standard Flash, Standard SDRAM, No Real Time Clock,
English/European/Latin America Documentation
1,730
Description
Suggested
List Price
ZebraDesigner Pro 250
ZebraNet Bridge Enterprise (1 to 50 printers) 595
Japanese Monotype Mincho™ Smooth Scalable Font (code page 932)** 50
Japanese HGP Gothic B™ Smooth Scalable Font (code page 942)** 50
Korean HY Gothic Hangul™ Smooth Scalable Font (code page 947)** 50
Traditional Chinese Monotype Kai™ Smooth Scalable Font (code page 950)** 50
Simplified Chinese Monotype Sung™ Smooth Scalable Font (GB2312-80)** 50
Thai Angsana™ Smooth Scalable Font (code page 847)** 50
Over 20 Smooth Scalable Fonts (code page 850)** 50
Five Asian Bitmap Flash Font Pack (pt.Sizes 6, 12, 18, & 24, code page 850)** 50
Media Adaptor Plates (for media cores from 1.5" to 3" ID) 83
77848
77843
R2844-Z Series - Accessories
Part Number
13831-001
48733-100
77846
77847
77844
105810-002
77840
77842
77845
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
9
SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
Memory List Price
Rxi
(UHF & HF)
RPAX RZ
G46999-0008 8MB Linear PCMCIA Flash Card (blank) (A) 315 x x
G46999-0032 32MB Linear PCMCIA Flash Card (blank) (A) 995 x x
G33193-128 128MB Compact Flash (CF) Card Accessory (blank) (A) 226 x x
G33193-256 256MB Compact Flash (CF) Card Accessory (blank) (A) 363 x x
G33194-128 128MB ATA PCMCIA Flash Card Accessory (blank) (A) 250 x x
G33194-256 256MB ATA PCMCIA Flash Card Accessory (blank) (A) 456 x x
Print Server Connectivity -Reference RFID Region Availability Matrix for
802.11g
Internal ZebraNet PrintServer 10/100 (B) 349 G47480 G57546 79823
External ZebraNet PrintServer 10/100 Accessory Kit (B) 249 G47490 G47490 G47490
ZebraNet Wireless Plus (does not include radio card) 499 29651-002M 29651-004M 29651-006M
ZebraNet Internal Wireless Plus Print Server (Includes radio card) 550 29652-002M 29652-004M 29652-006M
SEH PS105-Z External IPv6 Print Server for RXi & RZ 411 P1000219 P1000219
SEH PS102-Z Internal IPv6 Print Server for RXi & RZ 462 P1000220 P1000220
Connectivity
37608 RS-485 Y-Connection Cable for Printer-to-Printer 64 xx
37996 USB Cable, 15 Feet Long 23 xx
G33114M Serial Port Converter: RS232 to RS422/RS485 adapter 61 x x x
G33109M Serial Port Converter: RS232 DB9 to DB25 adapter 44 x x x
Maintenance
47362 Preventive Maintenance Kit 13 x x x
RXI Field Installable Upgrades
P/N
List Price P/N List Price
Cutter, Self-Sharpening Rotary Blade with Catch Tray G41353 927 G46353 1076
Cutter and Rewind with Cutter Catch Tray N/A G46154 1725
Media rewind Spindle Kit (enables rewind and peel-off option) G41355 479 G46355 541
Media Supply Spindle, 3" ID Core G41253M 145 G46253M 176
Media Supply Spindle, 40mm ID Core G41254M 173
Media Door Panel, with Window 46937 77
Bi-fold Media Door Panel, with Window G47077M 210
Applicator Interface Port 49872-009M 120
RZ Series Field Installable Upgrades
P/N List Price P/N List Price
203 to 300 dpi printhead conversion kit 79806 560 79808 825
300 to 203 dpi printhead conversion kit 79805 480 79809 530
Cutter with Catch Tray 79841 757 79842 973
Liner Take-up Spindle Only 79868M 394
Kit Combination Media Rewnd & Peel 79835 613 79836 716
Kit Peel Unit Only 79831M 193 79832M 276
Documentation List Price RXi (UHF) RXi (HF) RPAX RZ
ZPL II Programming Guide Vol. 2 The X.10 Environment (Bound hard copy;
Electronic copy included with Printer on CD-ROM)
25 45542L 45542L 45542L 45542L
110XiIIIPlus Maintenance Manual -Hard Copy 83 13185L-002
XiII, Xi III and Xi IIIPlus Maintenance Manual on CD-ROM (110XilllPlus not included) 54 48560-001
110PAX4 Quick Reference Guide (Included with International Units) 75 57515L-001
110PAX 4 Maintenance Manual 75 57515L-001
RZx00 Maintenance Manual on CD-ROM 54 77960-001
Software List Price
RXi-UHF &
HF
RPAX4 RZ
48766-001 ZBI 2.0 Enablement Kit for 1 Printer 99 xx x
48767-001 ZBI 2.0 Enablement Kit for 5 Printers 495 xx x
48768-001
ZBI 2.0 Enablement Kit for 25 Printers 2475 xx x
13831-002ZebraDesigner Pro 275 xx x
13832-002ZebraDesigner for mySAP Business Suite 495 xx x
13833-002ZebraDesigner for XML 495 xx x
48733-120
ZebraNet Bridge Enterprise for 1-50 Printers 595 xx x
48734-120
ZebraNet Bridge Enterprise for 1-100 Printers 795 xx x
48735-120 ZebraNet Bridge Enterprise for 100+ Printers 995 x x x
48735-120 ZebraNet Bridge Enterprise for 100+ Printers 995 x x x
P1006469 ZebraLink Enterprise Connector for Oracle BI Publisher 9600 x x x
A - ZebraNet Wireless Plus does not support CF/PCMCIA Memory B - Ethernet disables parallel port on XilllPlus
RZ600
R170Xi (200, 300dpi)
RFID ™ Price List
Available in North America, Latin America, South America & Asia Pacific
Prices are in U.S. Dollars. EXW Vernon Hills, IL, USA.
Minimum billing for orders is $50.00 per shipment per location.
RZ400
RFID - Accessories
R110Xi (UFH & HF) (200,
300dpi)
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
10
SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
Language Description
Code
Page
Xi-Series
RPAX
G46999-0401 English CG Times™ (standard, bold, italic and bold italic) 850 x x
G46999-0501 English Univers® (standard, bold, italic and bold italic) 850 x x
G46999-0801 Cyrillic CG Times, Univers (CG Times standard, Univers bold) 866 x x
G46999-0901 East European CG Times, Univers (CG Times standard, Univers medium) 852 x x
G46999-1504 Japanese Gothic Kanji (standard) 932 x x
G46999-1608 Japanese Mincho & Gothic (standard) 932 x x
G46999-1804 Japanese HGP Gothic B™ (standard) 932 x x
G46999-1904 Korean HY Gothic Hangul™ (standard) 947 x x
G46999-2008 Traditional Chinese Monotype Kai™ (standard) 950 x x
G46999-2104 Simplified Chinese Monotype Sung™ (standard) GB2312-80 x x
G48303 Unicode Andale Mono Japanese Unicode x x
G48304
Unicode Andale Mono Korean Unicode x x
G48305
Unicode Andale Mono Simplified Chinese Unicode x x
G48306 Unicode Andale Mono Traditional Chinese Unicode x x
77842
CG Triumvirate™, CG Times™, CG Century Schoolbook™, CG
Univers®, CG Triumvirate™ Condensed, CG Futura®, CG
Palacio™, Arabic Font, Greek Font, Cyrillic Font, Turkish Font,
Icelandic Font, East European font (standard)
850, 866
x x
77840 Asian Bitmap Font Pack Chinese, Japanese, Korean (203 dpi) 932 x x
77841 Asian Bitmap Font Pack Chinese, Japanese, Korean (300 dpi) 932 x x
77845 Thai Scaleable Font Angsana™ 847 x x
77848 Japanese Scaleable Font
HGP Gothic B (requires 64MB Flash option or 8MB linear PCMCIA
card)
932 x x
77844 Korean Scaleable Font
HY Gothic Hangul (requires 64MB Flash or 8MB linear PCMCIA
card)
947 x x
77847 Chinese Scaleable Font
Monotype Kai (requires 64MB Flash option or 8MB linear PCMCIA
card)
950 x x
77846
Simplified Chinese
Scaleable Font
Monotype Sung (requires 64MB Flash option or 8MB linear PCMCIA
card)
GB2312-80 x x
56050-001
Korean Kit, Font, Andale Korean Unicode x
56068-001 Japanese Kit, Font, Andale Japanese Unicode x
56080-001 Simplified Chinese Kit, Font, Andale Simplified Chinese Unicode x
56095-001 Traditional Chinese Kit, Font, Andale Traditional Chinese Unicode x
50
50
200
50
200
200
Font Packs - Field Installable/Downloadable (requires 64MB Flash option or 32MB linear PCMCIA card)
200
Font Packs - Field Installable/Downloadable
R110Xi (R12), R110Xi (H12), R170Xi (R72) use the 203 dpi fonts; R110Xi (R13), R170Xi (R70), R110Xi (H13) use the 300 dpi fonts.
50
50
50
50
50
1025
355
355
1025
Scaleable Fonts on 32 MB PCMCIA (linear) Flash Memory Cards (needs to support PCMCIA Memory Cards)
1025
1025
355
355
355
355
355
355
355
355
RFID Price List _RXI (UHF & HF)
Zebra North America, Latin America & Asia Pacific
Prices are in U.S. Dollars. EXW Vernon Hills, IL USA.
Minimum billing for orders is $50.00 per shipment per location.
RXi Series & RPAX - Field Installable Fonts
List Price
Scaleable Fonts on 8 MB PCMCIA (linear) Flash Memory Cards (needs to support PCMCIA Memory Cards)
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
11
SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
Language Description
Code
Page
Order Form
No.
List Price
Xi Series
RPAX
English CG Times (standard, bold, italic and bold italic) 850 04 125 x x
English Univers (standard, bold, italic and bold italic) 850 05 125 x x
Cyrillic CG Times, Univers (CG Times standard, Univers bold) 866 08 125 x x
East European CG Times, Univers (CG Times standard, Univers medium) 852 09 125 x x
WGLA / Pan European Swiss 721 (automatically included in “E” power cord configuration) Unicode 0E N/C x x
Unicode Andale Mono Japanese Unicode 0L 200 x
Unicode Andale Mono Korean Unicode 0M 200 x
Unicode Andale Mono Simplified Chinese Unicode 0N 200 x
Unicode Andale Mono Traditional Chinese Unicode 0P 200 x
Simplified Chinese SimSun GB 18030 0Q 200 x
Japanese HGP Gothic B™ (standard, 203 dpi) 932 18 50 x x
Korean HY Gothic Hangul™ (standard, 203 dpi) 947 19 50 x x
Traditional Chinese Monotype Kai™ (standard, 203 dpi) 950 20 50 x x
Simplified Chinese Monotype Sung™ (standard, 203 dpi) GB2312-80 21 50 x x
Japanese HGP Gothic B (standard, 300dpi) 932 24 50 x x
Korean HY Gothic Hangul (standard, 300dpi) 947 25 50 x x
Traditional Chinese Monotype Kai (standard, 300 dpi) 950 26 50 x x
Simplified Chinese Monotype Sung (standard, 300dpi) GB2312-80 27 50 x x
Scaleable Fonts
RXi ™ Series & RPAX Price List (UHF & HF)
Zebra North America, Latin America & Asia Pacific
Prices are in U.S. Dollars. EXW Vernon Hills, IL USA.
Minimum billing for orders is $50.00 per shipment per location.
Zebra®, ZPL II® and BAR-ONE® are Registered Trademarks of Zebra Technologies Corporation. XiIIIPlus™,110XiIIIPlus™, 140XiIIIPlus™, 170XiIIIPlus™,
220XiIIIPlus™, 105SL™, Z4Mplus™, Z4Mplus™, S4M™, Platinum™, ProPlus™, and ZebraNet™ are Trademarks of Zebra Technologies Corporation. IBM® is a
Registered Trademark of International Business Machines Corporation. Centronics® is a Registered Trademark of Genicom Corporation. Windows™ is a
Trademark of Microsoft Corporation. CG Triumvirate™, CG Palacio™, CG Times™, CG Century Schoolbook™ are Trademarks of Agfa Division, Miles Inc. CG
Futura™ is a Trademark of Fundicion Tipografica Neufville, S.A. Univers® is a Registered Trademark of Linotype AG. Monotype Times New Roman™, Monotype
Mincho™, Monotype Kai™, Monotype Sung™, are Trademarks of Monotype Typography, Ltd. HGP Gothic B™ is a Trademark of Ricoh Company, Ltd. HY Gothic
Hangul™ is a Trademark of Hanyang Systems Inc.
RXi Series & RPAX Factory Installed Fonts in Flash Memory
Bitmapped Fonts
R110Xi (R12), R110Xi (H12), R170Xi (R72) use the 203 dpi fonts; R110Xi (R13), R170Xi (R70), R110Xi (H13)
use the 300 dpi fonts
Scaleable Fonts only available with On-Board 64MB Flash Memory
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
12
SPECIFICATIONS AND PRICES SUBJECT TO CHANGE WITHOUT NOTICE
Japanese HGP Gothic B 932 150
Korean HY Gothic Hangul 947 250
Traditional Chinese Monotype Kai 950 350
Simplified Chinese Monotype Sung GB2312-80 4 50
Japanese HGP Gothic B 932 550
Korean HY Gothic Hangul 947 650
Traditional Chinese Monotype Kai 950 750
Simplified Chinese Monotype Sung GB2312-80 8 50
Japanese HGP Gothic B (requires 64MB Flash option) 932 F50
Korean HY Gothic Hangul (requires 64MB Flash option) 947 G50
Traditional Chinese Monotype Kai (requires 64MB Flash option) 950 H50
Simplified Chinese Monotype Sung (requires 64MB Flash option) GB2312-80 J 50
Thai Angsana™ 874 K50
Unicode Andale Mono Japanese (requires 64MB Flash option) Unicode L 200
Unicode Andale Mono Korean (requires 64MB Flash option) Unicode M 200
Unicode Andale Simplified Chinese (requires 64MB Flash option) Unicode N 200
Unicode Andale Mono Traditional Chinese (requires 64MB Flash option) Unicode P 200
List Price
WGL4/ Pan-European
Swiss 721 (included in "E" power cord configurations automatically)
Unicode
E
N/C
Language
Description
Code
Page
Order Form No.
List Price
Scalable Fonts
Language
Description
Code
Page
Order Form No.
List Price
Bitmap Fonts - 300 dpi
Language
Description
Code
Page
Order Form No.
Zebra RZ Series™ Price List
North America, Latin America & Asia Pacific
Prices are in U.S. Dollars. EXW Vernon Hills, IL, USA.
Minimum billing for orders is $50.00 per shipment per location.
RZx00 ZPL Factory Installed Fonts in Flash Memory
Bitmap Fonts - 203 dpi
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
13
SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
USA Can.
EU &
EFTA
Turkey UAE Aust. China
Hong
Kong
Japan S. Korea Malaysia
New
Zealand
Philip. Singap. Taiwan Thail. India Agent. Brazil Chile
Costa
Rica
Dom.
Rep.
El
Salvad.
Mex Nicar. Peru
Puerto
Rico
Urug. Venez.
Region Codes R0 R0 R1 R1 R1 R2 RA RB RG RH RB R2 RC RB R6 RB RD R0 R9 R0 R0 R0 RE R0 R0 R0 R0 R0 R0
RP4T
RP4T Y Y Y Y Y Y Y N N Y Y Y Y Y Y Y N N N N N N N N N N N N N
RP4T 802.11G Y Y Y Y Y Y Y N N Y Y Y Y Y Y Y N N N N N N N N N N N N N
RP4T Blue Tooth Y Y Y Y Y Y Y N N Y Y Y Y Y Y Y N N N N N N N N N N N N N
RZ400/RZ600
RZ400 Y Y Y Y Y Y Y Y N Y Y Y N Y Y N Y Y N N N N N Y N N Y N N
RZ400 with
WLAN
Y Y Y Y Y Y N Y N N N Y N Y Y N Y Y N N N N N Y N N Y N N
RZ600 Y Y Y Y N Y N N N N N Y N Y N N N Y N N N N N Y N N Y N N
RZ 600 with
WLAN
Y Y Y Y N Y N N N N N Y N Y N N N Y N N N N N Y N N Y N N
R110Xi
R110Xi UHF 900
MHz
Y Y N N N Y Y Y N N N N Y Y Y Y N Y Y Y Y Y Y Y Y Y Y Y N
R110Xi UHF 900
MHz WLAN
Y Y N N N Y N Y N N N N Y Y Y Y N N N N N N N Y N N Y N N
R110Xi HF Y Y Y N N Y Y Y Y Y N N N Y N N N N N N N N N Y N N N N N
R110Xi HF
WLAN
Y Y Y N N Y N Y Y N N N N Y N N N N N N N N N Y N N N N N
R170Xi
R170XIi 900 MHz Y Y N N N Y N Y N N N Y Y Y Y Y N N N Y Y Y Y Y Y Y N Y N
R170XIi 900 MHz
WLAN
Y Y N N N N N N N N N Y N Y N Y N N N N N N N Y N N N N N
R110 PAX4
R110 PAX4 900
MHz
Y Y N N N N N N N N N N N N N N N N N N N N N Y N N Y N N
R110 PAX4 900
MHz WLAN
Y Y N N N N N N N N N N N N N N N N N N N N N Y N N Y N N
R110 PAX4 800
MHz
N N Y Y N N N N N N N N N N N N N N N N N N N N N N N N N
R110 PAX4 800
MHz WLAN
N N Y Y N N N N N N N N N N N N N N N N N N N N N N N N N
RFID Printer Price List
RFID Printer Country Listings- Availability for Sale Status
Product
N. America
APAC
LATAM
EMEA
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
14
SPECIFICATIONS AND PRICES SUBJECT TO CHANGE WITHOUT NOTICE
RFID Products Price List
ZebraCare
ZebraCare ™ Depot Service Agreements
for Mobile Printers
ZebraCare™ Depot Extended Warranty Plans
Standard - Coverage on all parts and labor, 5 day turn, return shipping via ground
Advantage - Standard Coverage PLUS 2-business day turnaround time and no charge firmware upgrades
(on request)
Advantage Overnight - Advantage Coverage PLUS next day return shipping
Advantage Plus - Managed spares pool (up to 6%), same day overnight shipment of exchange pool
product, and monthly activity reports
Please download the ZebraCare™ Configurator via AccessZebra for Mobile Depot service agreement
pricing to create your ZebraCare quote.
For more details and to download the Configurator please visit
(https://private.zebra.com/reseller/current_pricing_nalaap.php) to review the “Installation Instructions”
and to access the new configurator download file.
DEPOT REPAIR LOCATIONS
USA: Vernon Hills, Illinois
CANADA: Toronto
LATIN AMERICA: Mexico
*PLEASE NOTE*: It is extremely important to review the “Installation Instructions” presentation before
performing the download. This presentation outlines the required steps needed to ensure a successful
download. Failure to follow these instructions may result in possible computer issues that your in-house
IT team will have to resolve. Please contact your company’s IT team if you experience any issues.
For more details on Mobile ZebraCare Depot Service Agreements, please contact your customer
service representative.
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
15
PRICES AND SPECIFICATIONS SUBJECT
TO CHANGE WITHOUT NOTICE
Development Services:
Printer Customization
Enterprise Printing Services
Software Solutions
• ZebraLink™ Multiplatform SDK
• Driver Customization
• Alternate Programming Languages
• ZBI Development
• Custom Software Applications
Implementation and Deployment
• Font Kit Creation
• Wireless Mark-Up Language (WML) - Custom display content
• Mirror - Auto-updating printers
Description List Price
Development Services - Hourly Rate
295
For additional information on Zebra's Professional Services capabilities, please visit AccessZebra site at
https://private.zebra.com/reseller/services/professional_services.php
RFID Products Price List
Professional Services
Note: Development Services require a custom quote based on requirements.
Part Number
Custom
Zebra Professional Services
Have you ever found an opportunity that requires modifications to a Zebra® printer or software product?
If so, look to Zebra Development Services for solutions that will enable your business. Whether complementing
your core capabilities or extending your core capabilities or extending your project bandwidth, Zebra Development
Services offers competitive fee-based assistance.
Zebra’s printer customization service provides access to manufacturer-level product customization such as
hardware, firmware, electrical and kit creation. Depending on the nature of your solution, you can purchase and
modify standard configurations or have Zebra provide fee-based customized configurations.
Zebra offers Enterprise Printing Services, which plan and integrate the printer into enterprise solutions such as
applications from Oracle, SAP, and IBM.
All capabilities not available on all Zebra printers. Check with your Zebra account representative for more details.
NOTE:
Zebra provides many software solutions to integrate the printer into your customer’s environment. Consider one of
the following customized software solutions:
Development Services will also implement and deploy tools such as:
To inquire about a Development Services opportunity or to get a quote, please contact your Zebra account
representative.
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
16
SPECIFICATIONS AND PRICES SUBJECT TO
CHANGE WITHOUT NOTICE
Field Services:
• Wireless Site Surveys
• Wireless & Hardware Installations
• Wireless Troubleshooting
• Staging
• Integration
• Rollouts
Description List Price
Wireless Site Survey (Per Day)
Custom
Wireless & Hardware Installations (Per Day)
Custom
Wireless Troubleshooting (Per Day)
Custom
Staging
Custom
Integration
Custom
Rollouts
Custom
To inquire about a Field Services opportunity or to get a quote, please contact your Zebra account representative.
For additional information on Zebra's Professional Services capabilities, please visit AccessZebra site at
https://private.zebra.com/reseller/services/professional_services.php
Custom Part #
Custom Part #
Custom Part #
Custom Part #
Custom Part #
Note: Field Services require a custom quote based on the State of Work for each service.
Part Number
Custom Part #
RFID Product Price List
Professional Services
Zebra Professional Services - Continued
Have you ever been asked to assist in installing a wireless network? Have customers asked you to perform a site
survey or asked for technical assistance to fix a wireless network issue? If you don’t have this expertise, then Zebra's
Field Services can help. Zebra has a number of Field Services offerings to meet your customers’ needs:
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
17
SPECIFICATIONS AND PRICES
SUBJECT TO CHANGE WITHOUT NOTICE
Technical Services:
Technical Support Agreements
Our Technical support group consists of a team of technical professionals that are trained and certified to
provide exceptional technical support on the Zebra Enterprise Connector solution. By working with Zebra
Technical Support you get personalize Enterprise Connector support from professionals who are trained
and certified to provide support for your unique solution.
Description List Price
Enterprise Connector – 1 YR. Technical Support Agreement – 24x7
3360
Enterprise Connector – 1 YR. Technical Support Agreement – 24x5
2880
Enterprise Connector – 1 YR. Technical Support Agreement – 8x5
2400
Each Technical Support Agreement includes support on:
- Enterprise Connector - The server based solution that can be deployed to any J2EE container. Data is
handled as CVS or ZPL input and allows for easy implementation of custom designs and ZPL delivery
to any Zebra printer.
- Zebra Designer for XML - The ability to create ZPL label formats in GUI environment.
- ZebraNet Bridge Enterprise - Zebra printer management tools for setting alerts, audits and configurations.
- 2 hours setup assistance
- 2 hours remote training
- 1 free label conversion
Technical / Repair Training
For additional information on Zebra's Professional Services capabilities, please visit AccessZebra site at
https://private.zebra.com/reseller/services/professional_services.php
RFID Products Price List
Professional Services
ZEC-SUP2-100
Zebra Professional Services - Continued
ZEC-SUP3-100
Technical Support Agreements - Enterprise Connector
(Offered only on ZPL printer models)
Part Number
ZEC-SUP1-100
To inquire about a Technical Services opportunity or to get a quote, please contact your Zebra account
representative.
Are you looking for assistance with your Enterprise Connector solution? Then purchase one of our technical support
agreements to receive specialized technical assistance.
http://www.zebra.com/id/zebra/na/en/index/service_support/options/technical_training.html
Are you looking for technical training? Take advantage of Zebra’s experience in operations, applications,
maintenance, and technical support with a comprehensive Zebra training program. Zebra can deliver training at either
a Zebra office or on your own premises.
If you are interested in learning more, please visit the web link below for a detailed class curriculum.
Rev 8 - Effective July 1, 2010
Zebra Technologies International, LLC
475 Half Day Road
Lincolnshire, IL 60069
18
SPECIFICATIONS AND PRICES SUBJECT TO
CHANGE WITHOUT NOTICE

Navigation menu
