Zhejiang Hanshow Technology STELLARMF Electronic shelf label User Manual
Zhejiang Hanshow Technology Co., Ltd. Electronic shelf label
User Manual
Zhejiang Hanshow Technology Co., Ltd.
Website: www.hanshows.com
1
Stellar MF/M3F Specification
General Description
Hanshow Electronic Shelf Labels are custom made for all kinds of retailers such as malls,
hypermarkets, 3C stores, convenience stores and pharmacies. It is different from the
traditional paper price labels;ESL can be remotely controlled and updated anytime and
anywhere via RF technology. TheESL system also synchronizes retailers’ existing database,
which ensures the consistency between labels and counters. This is the key to successful O2O
(Online to Offline) business.
Hanshow Brings You
Direct & Accurate“Sales”Information
Smart “Pricing Management”
Simple “Pricing Update” Process
Convenience Stores
Supermarkets
3C Stores
Pharmacies
Malls
Hypermarkets
G-MALL
Zhejiang Hanshow Technology Co., Ltd.
Website: www.hanshows.com
2
System Map
Pricing Management Process
Branch
Store 1
Headquarters
Price Update
Server
Branch
Store 2
Branch
Store ..
Zhejiang Hanshow Technology Co., Ltd.
Website: www.hanshows.com
3
Benefits
1. Dot-matrix e-paper screen - high readability and high contrast rate.
2. Diverse content – text, digits, pictures, barcode and RQ code.
3. Color screen.
4. Multiple sizes.
5. Supports multiple languages. Currently it supports Chinese and English, other languages
can be custom made.
6. Real time price update. 10,000 updates per hour, 99.99% successful.
7. 360 degree signal transmission. Anti-interference.
8. Simple installation with antitheft function.
9. Product life span is 5 years.
Fastprice update enables more frequent promotion activities, which increases
retailers’ profit margin.
Pricing history in database is fundamental for data analysis, which provides
references for future pricing strategies.
Smarter pricing planning and shelf management.
Big label delivers strong messages to consumers.
Save labor and operation costs.
Zhejiang Hanshow Technology Co., Ltd.
Website: www.hanshows.com
4
Product List
Stellar-MF
Stellar-M3F
Product Specification
Stellar-MF/M3F
Technical Parameters
Model
Stellar-MF\M3F
Battery
1*EF702338
Dimension (H*W*T mm)
70.5*35.2*12.6
Replaceable Battery
NO
Display (H*W mm)
48.55*23.8
Battery Life
5 years
Weight
33g
Low Power Warning
Yes
RF Parameters
Data Rate
500Kbps
Modulation
GFSK
Quantity of Channels
79
Channel Separation
1MHz
Display Parameters
Display
E-Paper
/
Dot-Matrix
Screen Size (H*W mm)
48.55*23.8
Color Screen
Customized
Multiple Pages
Customized
“Sales” Sign
Yes
Other Specification
Antitheft Installation
Holder
Yes
Transmission
2.4G Wireless
Antitheft Technology
Custom
Updating Speed
10,000 Messages
Per Hour
Two-way Communication
Yes
Update Stability
Error Rate is less
than 0.0000001
Environment
Storage Temperature
0-40 degree
Operating
Temperature
0-40 degree
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
