Zippy Technology BW7080 Bluetooth & Wired Combo Keyboard User Manual 01
Zippy Technology Corp. Bluetooth & Wired Combo Keyboard 01
User Manual
1
Bluetooth & Wired Combo Keyboard
Model No.: BW7080
Safety
Introduction
Before getting started, read these instructions and save
them for future reference.
Do not drop or hit your keyboard.
Do not use your keyboard in a location that is subject
to strong vibrations because vibration may damage
your keyboard.
Do not disassemble or modify the product in any way.
Disassembly or modification may void your warranty
and could damage your keyboard leading to a fire or
electric shock.
Do not use or store your keyboard in damp locations.
Liquid entering the product may cause damage or lead
to fires or electric shock.
Do not insert metal objects, such as coins or paper
clips, into your keyboard.
Your keyboard is for general device use. Do not use
your keyboard with a device that requires exceptional
reliability, especially if a breakdown or malfunction of
might jeopardize life or health, such as aerospace
equipment, atomic power control system, traffic-related
equipment, transportation equipment, industrial robotics,
Congratulations on your purchase of a high-quality product.
Your keyboard represents the state of the art in wireless
keyboard design and is designed for reliable and trouble-free
performance.
23
Keyboard Components
1. Devices Indicators
2. Bluetooth Function Keys
3. Media & iPad Hot Keys
4. NFC Detection Area
5. Bluetooth Pairing Button
6. Fn Key
7. Micro USB Slot
8. On/ OFF Switch
Features
combustion equipment, safety devices, and life-support
systems.
Batteries may explode or leak if they are improperly
recharged, inserted disposed of in fire, or mixed with
used batteries or different battery types. There is a risk
of explosion if a battery is replaced incorrectly.
Dispose of used batteries according to local regulations.
Keep the battery compartment cover and the batteries
out of the reach of small children.
Patented Wired USB and Bluetooth multi-link function
that memorizes up to five Bluetooth devices and one
USB device, and fast switch between each other.
6 LED Bluetooth device indicators inform the present
device is connected.
Multimedia function keys: Last Track, Play/ Pause, Next
Track, Calculator, Vol+, Vol-, Mute.
Specific iPad function key: Screen lock, Home, Search,
Picture frame mode, On-screen keyboard.
Assembled a separable 1.5-meter USB cable.
Bluetooth 3.0 technology and auto sleep mode extend
battery life.
Reliable Bluetooth connection ranges up to 33 feet
(10 meters).
Patented Scissor-Key Structure provides 10 million
service times, positive response and quiet typing.
A pair of rubber foot enhances user comfort.
1
2
3
4
5
ON OFF
9
6
87
4 5
Operating System Support
Specifications
Package Contents
Bluetooth and Wired Combo Keyboard
Micro USB Cable
AA Alkaline Batteries x2
User’s Manual
Windows XP
Windows Vista (32-bit / 64-bit)
Windows 7 (32-bit / 64-bit)
Windows 8 (32-bit / 64-bit)
Mac OS X v10.0 or later
iOS 6 or later
* Media and iOS hot keys may not support
at every OS and device.
Dimension: 451.3(L) x 152.3(W) x 26.0(H) mm
Weight: 600 ± 20g (w/o battery)
Interface: Bluetooth / USB
Operating Distance: 10 Meters
Key Number: 108 Keys (US) / 109 Keys (UK) /
112 Keys (JA) / 110 Keys (KO)
(Incl. 4 Hotkeys)
Battery: 2 x AA Alkaline Batteries
Battery Life: 4 Months (base on average usage)
Keyboard
Installing Batteries
2. Insert two AA alkaline batteries and make
sure the batteries are installed properly.
1. Open the battery cover.
3. Close the battery cover.
* You don’t necessarily need to install batteies if you
connect the keyboard with a powerd USB port by
USB cable.
7
6
Installation Proccedure
Set Up Keyboard - Pair with 1st Bluetooth Compatible
Device
2. Select a “Bluetooth” function key to assign 1st
device to connect with the keyboard.
1. Turn on the the keyboard.
3. Hold “Fn” key and “Bluetooth Pairing” key to activate
Bluetooth discovering.
* The indicators above the “Bluetooth” keys will BLINK.
4. Complete Bluetooth pairing on the device.
+
ON OFF
ON OFF
Set Up Keyboard - Connect with device by USB cable
1. Connect the keyboard with a computer by the Micro-USB
cable.
2. Select “USB” key to associate with device.
* The indicators above the USB keys will be ON.
ON OFF
89
Hotkey Functions
: Last Track
: Play/ Pause
: Next Track
: Mute
: Volume Down
: Volume Up
: On-Screen Keyboard (iOS Only)
: Search Mode
: Home Screen (iOS Only)
: Screen Lock (iOS Only)
Switch among Paired Devices
1. Press “Bluetooth and USB” function key to select a device to
use.
* The indicators above the “Bluetooth and USB” function keys
will be ON.
2. You can also hold “Fn” key and “Tab” to return to use
previous device.
+
10 11
Battery Low
Make sure that you have paired your keyboard with
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
You are cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void
your authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired operation
Low-battery is indicated by illumination on the top case of
keyboard. Please replace the batteries when the indicator
lights up.
Do not mix old and new batteries, or mix different types
of batteries. This can cause rupture or leakage, resulting
in presonal injury or property damage.
your device. For more information, see “Installation
Procedure” on page 6.
Make sure that your operating system is compatible
with your keyboard. For more information, see
“Operating System Support” on page 4.
Make sure that the anode(+) and cathode(–) symbols
on the batteries match the anode(+) and cathode(–)
symbols in the battery compartment.
Troubleshooting
