Zippy Technology ZMS3700RL 2.4G RF MOUSE User Manual
Zippy Technology Corp. 2.4G RF MOUSE
Users Manual
1
" 2.4GHz All Around Freedom , Infinite Possibilities "
Mini Transport, ZMS3700RL
User's Manual
System requirements
IBM or compatible PC
Windows Operating System
Pentium-equivalent processor or above
One available USB port
OS support
Windows XP/64Bit
Windows 2000/NT
Windows 7
Windows Vista
Introduction
Thank you for your patronage of purchasing our cordless Laser mouse. For your own
safety, please read this manual thoroughly before using this product. After you have read
this manual, please keep it in place for reference when necessary.
Contents in the package
The following items are included in the package. Please make sure all items are accounted
for as you open the package. If there was any item missing or damaged, please contact the
reseller where the product was purchased or our support center.
Wireless Laser Mouse x 1
USB 2.4GHz dongle receiver x 1
Manualx 1
Alkaline batteries x2 AAA
2
Warning
Any malfunction, damage or personal injury caused by the malfunctioning or damage of the
user’s personal computer or misuse of this product.
Any attempt to dismantle, change or modify this product in any manner.
Warning
Please do not use this product in ashy, wet, or oily environments. Failure to do so
may shorten the life of this product and may cause bodily harm.
Please keep this product as far away from Radio Frequency interruption areas as
possible.
This is not an outdoor product. Exposing this product to the elements may cause
damages to the product and bodily harm to its users.
Please do not use petroleum, benzene or thinner-based solution to clean this
product.
Laser Mouse
International standards and safety. This Laser device complies with International
Standard IEC 60825-1:2001-08, Class 1 Laser Product, and also complies with 21 CFR
1040.10 and 1040.11, except for deviations pursuant to Laser Notice No.50, dated July
26, 2001:1) Emission of a parallel beam of infrared user-invisible light: 2) Maximum
Power of 716 microwatts CW, wavelength range 832-865 nanometers; 3) Operating
temperature between 0℃ ( 32℉ ) to 40℃ ( 104℉ ). CAUTION: This Laser device has
no serviceable parts. Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radiation exposure. Safety
and Usage Guidelines. 1) Do not point infrared beam at eye. 2) In the absence of
proper operation and if customer-initiated troubleshooting is unsuccessful, switch off
device and call technical support. 3) Do not disassemble your product or expose it
to liquid, humidity, moisture, or temperatures outside the specified operating range of
0℃ ( 32℉ ) to 40℃ ( 104℉ ). 4) If you product is exposed to out-of-range temperatures,
Switch it off and allow the temperature to return to the normal operating range
Warranty Information
This product is backed by a One-Year Manufacturer’s Warranty, starting from the date of
purchase. The warranty covers for free repair in accordance with the contents stated herein
but does not cover wear and tear and any malfunction or damages as results of improper
usage as stated in this manual.
3
Specifications
Mouse
■ Dimensions: L95 x W58.4 x H37 mm
■ Weight: +/- 25g (with Battery)
■ Key Number: 7 Keys (Wheel button on middle button)
Next page; Back page; CPI + ; CPI -
■ Battery: 2 x AAA batteries
■ Battery Life: 1 Month (Base on average usage)
■ Channel: 78 Channels
■ ID: Unique ID for mouse
■ Radio Frequency: 2.4 GHz
Dongle Receiver
■ Dimensions: L19.15xW12xH2.35 mm
■ Weight: (實秤)g +/-5g
■ Interface: USB 1.1
Installation Procedure
Before installing this product please make sure you have one available USB port reserved
for the dongle receiver.
A. Setting up the Dongle Receiver
1. Plug the dongle receiver (FIG. 3) into an available USB port
2. Wait for Windows to install drivers for the dongle receiver and mouse
3. When the dongle receiver has been properly initialized, its LED light will stay alit.
B. Setting up the Mouse
1. Open the mouse’s battery compartment cover and insert the two pieces of AAA
Alkaline batteries. Make sure they are properly installed and Switch on the switch at the
bottom case.(FIG.1)
2. Replace the mouse battery compartment cover.
3. Usually the keyboard and mouse have bind in the factory, if the system cannot
recognize the keyboard and mouse, please follow step 6~8 to bind keyboard and
mouse.
6. Let Mouse right corner to close the Dongle to 0~15cm.
7. To press any button of mouse, the system will automatically recognize the mouse.
8. The LED indicator on the dongle receiver will show green light when the connecting
4
have been properly set and the mouse are working.
Battery Low
1. . Low-Battery is indicated by the illumination of the Mouse Scroll. Please replace the
battery when the LED lights up.
2. While the mouse is in sleep mode, please press any button or move the scroll wheel to
wake it up.
3. We recommend using alkaline batteries for the mouse.
4. You may need to reset the ID’s after replacing new batteries for the mouse.
Warning
Please be careful when resetting the ID’s for the mouse and dongle receiver. Objects with
sharp point may break and leave behind shards.
To remove batteries, please repeat steps 4 to 3 or 2 to 1 in reverse order..
Mouse
Receiver
RX19
ID button and mouse reset button is device make a pair; When does not search the RF device please
push any key after push ID or reset button to make a pair the RF device.
FCC Statement on CLASS B
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
5
-Connect the equipment into and outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio / TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that may
cause undesired operation
Mandatory repair charges are required for the following conditions, even within the
guarantee period:
(1) Malfunction or damage is due to misuse or improper alteration or repair.
(2) Malfunction or damage is caused by the movement or fall during installation after the
purchase.
(3) Malfunction or damage is caused by a fire, salt, gas, earthquake, lightning, wind, water
or other natural calamities, or abnormal voltage.
(4) The manual is not presented.
(5) Date of purchase, customer's name, name of the shop are not filled in or are altered.
(6) Malfunction or damage is caused by other devices connected to the product.
To get the repair service, please disconnect product from other devices connected.
Date Contents of service
Person in charge
Person in charge
This warranty is intended to provide free repair under the terns and period stated herein.
Accordingly, this warranty shall not limit the legal rights entitled to the Customer. For more
information concerning the repair after expiration of the guarantee period, please contact us
or our retailer where you purchased this product.
Names of other products mentioned in this Manual are the trademarks or registered
trademarks of their respective owners.
6
Warning
You are cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
All brand names, trademarks and logos are the properties of their respective owners.
