Zoom Telephonics 3GM1085 3G+ Freedom Modem User Manual WM67 Quick start

Zoom Telephonics Inc 3G+ Freedom Modem WM67 Quick start

Contents

Users Manual 2

WIRELESS USB MODEM is a kind of online device which designed for the user who may use
mobile internet to get online, and the user may access to the internet at anywhere and anytime.
（Please close the antivirus and security software,Before Installation.）
To Insert (U)SIM Card
1). Push away protecting cover of the product;
2). nsert the (U)SIM card into the socket (the golden contact side is downward ) according to
the direction indicated in the sketch, and confirm the (U)SIM card is inserted completely.
To Insert Micro SD Card
1). Push away protecting cover of the product;
2). Insert the Micro SD card into the socket according to the indicated direction and confirm
the Micro SD card is inserted completely.
Connect the Computer and the WIRELESS USB MODEM
1). Rotate USB;
2). Insert MODEM device into the USB socket of the computer;
3). After correctly inserted, the installation procedure will automatically operate; if installation
procedure can not pop up automatically, please open My Computer--- MODEM Disk and
then double click Modem_installation.exe to start installation. Moreover, in the course of
installation, please do not disconnect the device;
4). After installation, restart the computer and click Run Icon to operate the procedure.
1. About WIRELESS USB MODEM
2. Installation
115mm
85mm 85mm
3G USB MODEM
HSPA/UMTS/EDGE/GPRS/GSM
Set Up Connection
1).
Click the button of under the main window to access the network, and then the button
of will turn into the button of ;
2).
Pop-up connection information window, indicating the success of network connection.
If connection fails, please check APN setting. (Reference help file of customize the
Internet Connection Configuration section).
Disconnection
Click the button of in main window to disconnect the network.
4.Indicator light
1). If SMS sending fails, please confirm whether the number of SMS Center is correct or not.
2). If do not receive the SMS, please check whether the storage space of (U)SIM card is full
or not.
3). The device will be brought about normal heat phenomena if used under the long-time
working environment, weak signal or higher room temperature conditions, however, it does
not affect the use and life of the device.
4). Please avoid contacting with the skin directly for a long time.
5). Please keep the device a minimum physical distance: 20cm.
6). USB port 2.0 version or higher．
For MAC OS or more detailed information of the product, please click <Help> file of the
Setting Menu under the main window.
3.Connect to the Internet
5. Notes
6. Remark
Status of Indicating Light
Colour Flashing Cycle
Red Slow Flashing
Luminous continuously
Green
Blue
Purple
Yellow
Description
Searching Network
Abnormal of (U)SIM card or no network
Data transmission
HSPA
UMTS
EDGE
GPRS
12
12
12
