Application Diagram

4-Port MDIX Switch

The prestige 324 features a 4-port 10/100Mbps switch for

local network connections. The MDIX feature

automatically and transparently detects wired cables,

making network installation easy and manageable.

SUA/NAT Technology

ZyNOS, ZyXEL’s proprietary networking software allows

multiple users to share a single ISP account.

DHCP Client/Server

The Prestige 324 behaves as a DHCP client to obtain an

IP address from ISP servers when the link is up. It also

serves as a DHCP server on the LAN to provide IP

addresses to local computers.

Secured Firewall Protection

Based on Stateful Packet Inspection, Denial of Service

(DoS) and Attack Alert, the Prestige 324 provides the first

line of defense against hackers, network intruders, and

other hazardous threats.

Traffic Redirect and Dial Backup for Broadband

Backup Connections

The Prestige 324 offers users increased reliability by

supporting Fail-Over and Fail-Back technology. Fail-Over

and Fail-Back technology forward WAN port traffic to

backup ISDN or Analog modems in the event of WAN

port connection failure. Once WAN port connections are

reestablished, traffic automatically returns. An additional

gateway may also be connected to the Prestige 324 to

ensure High-Availability of the Internet. Prestige 324

backup features increase reliability while decreasing

device maintenance, IT consulting costs, and daily

operation losses.

Benefits

ZyXEL’s Prestige 324 is an intelligent broadband sharing

gateway with integrated firewall protection. This high

performing security router can reach throughput rates of

28Mbps, while simultaneously offering features such as

Stateful Packet Inspection (SPI), Denial of Service (DoS)

and Access Control with scheduling. Additional value-

added features include Dial Backup and Traffic Redirect,

both of which enhance data transmission efficiency, and

minimize costs associated with operation and

maintenance. Security management is simplified with an

intuitive Web management interface and easy-to-use

administration wizard. A rich feature set combined into

one compact unit makes the Prestige 324 the best and

most affordable choice for residential and SOHO users.

Prestige 324

Intelligent Broadband

Sharing Gateway

Home Office LAN

10/100M Ethernet

10/100M 4-port Switch

Prestige 324

INTERNET

ADSL/Cable Modem

ADSL/Cable

ISDN TA /Analog Modem

Features

Specifications

Rear Panel

65-100-032401

Prestige 324

Intellient Broadband Sharing Gateway

Copyright© 2003 ZyXEL Communications Corporation. All rights reserved. ZyXEL, the ZyXEL logo, ZyNOS are registered trademarks of ZyXEL Communications Co. Other trademarks and service names referenced

are properties of their respective holders. All specifications are subject to change without notice.

Corporate Headquarters

ZyXEL Communications Co.

Tel: +886-3-578-3942

Fax:+886-3-578-2439

Email: sales@zyxel.com.tw

http://www.zyxel.com

http://www.zyxel.com.tw

North America

ZyXEL Communications Inc.

Tel: +1-714-632-0882

Fax:+1-714-632-0858

Email: sales@zyxel.com

http://www.zyxel.com

Germany

ZyXEL Deutschland GmbH.

Tel: +49 2405 6909 0

Fax:+49 2405 6909 99

Email: sales@zyxel.de

http://www.zyxel.de

Denmark

ZyXEL Communications A/S

Tel: +45 39 55 07 00

Fax:+45 39 55 07 07

Email: sales@zyxel.dk

http://www.zyxel.dk

Norway

ZyXEL Communications A/S

Tel: +47 22 80 61 80

Fax:+47 22 80 61 81

Email: sales@zyxel.no

http://www.zyxel.no

Sweden

ZyXEL Communications A/S

Tel: +46 (0) 31 744 3810

Fax:+46 (0) 31 744 3811

Email: sales@zyxel.se

http://www.zyxel.se

Security

•Packet Filter

•Stateful Packet Inspection

•Denial of Service

•Attack Alert an logs

•Access Control

Routing Support

•IP Routing : UDP, TCP, ICMP, ARP, RIP V1 and RIP V2

•Programmable Static Route

•IP Alias

•IP Multicast

IP Management

•DHCP client/server

•Multi-NAT/SUA

Content Filtering

•Java/ActiveX/Cookie/Proxy Blocking

•URL Blocking

Hardware Specification

•Power: 9VAC

•LAN: 10/100Mbps Ethernet

•Reset Button

•WAN: 10/100Mbps Ethernet

•CON/AUX Switch

•RS-232 DB9F: Console/Dial Back-up

Operating Environment

•Operating Temperature: 0 ~ 40˚C

•Operating Humidity: 5 ~ 90% (non-condensing)

Physical Specification

•Dimensions: 181mm(L) x 128mm(D) x 36mm(H)

•Weight: 330g

ISP Authentication

•RR Manager

•PPPoE

•PPTP

Network Management

•Web-based configurator

•Telnet remote access support

•TFTP/FTP for firmware upgrade/backup

•SNMP support

Application

•DNS proxy

•Internet Time Calibration

•Dynamic DNS

•Telnet Client

•Built-in Diagnostic Tool

•Call Scheduling

•Budget Management

•UPnP

•Dial Backup
