Adobe Illustrator CC 2015 Scripting Reference (2017) Reference: Java Script Cc2017 Ref En

User Manual: adobe Illustrator - CC (2017) - Scripting Reference: JavaScript Free User Guide for Adobe Illustrator Software, Manual

Open the PDF directly: View PDF .
Page Count: 255 [warning: Documents this large are best viewed by clicking the View PDF Link!]

JavaScript Object Reference
Scripting Constants

ADOBE® ILLUSTRATOR® CC 2017

ADOBE ILLUSTRATOR CC 2017

SCRIPTING REFERENCE:

JAVASCRIPT

Adobe Illustrator CC 2017 Scripting Reference: JavaScript

If this guide is distributed with software that includes an end user agreement, this guide, as well as the software

described in it, is furnished under license and may be used or copied only in accordance with the terms of such license.

Except as permitted by any such license, no part of this guide may be reproduced, stored in a retrieval system, or

transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written

permission of Adobe Systems Incorporated. Please note that the content in this guide is protected under copyright law

even if it is not distributed with software that includes an end user license agreement.

The content of this guide is furnished for informational use only, is subject to change without notice, and should not be

construed as a commitment by Adobe Systems Incorporated. Adobe Systems Incorporated assumes no responsibility or

liability for any errors or inaccuracies that may appear in the informational content contained in this guide.

Please remember that existing artwork or images that you may want to include in your project may be protected under

the copyright owner. Please be sure to obtain any permission required from the copyright owner.

Any references to company names in sample templates are for demonstration purposes only and are not intended to

refer to any actual organization.

Adobe, the Adobe logo, Acrobat, Flash, Illustrator, Macromedia, and Photoshop are either registered trademarks or

trademarks of Adobe Systems Incorporated in the United States and/or other countries.

JavaScript and all Java-related marks are trademarks or registered trademarks of Sun Microsystems, Incorporated in the

United States and other countries.

All other trademarks are the property of their respective owners.

Adobe Systems Incorporated, 345 Park Avenue, San Jose, California 95110, USA. Notice to U.S. Government End Users.

The Software and Documentation are “Commercial Items,” as that term is defined at 48 C.F.R. §2.101, consisting of

“Commercial Computer Software” and “Commercial Computer Software Documentation,” as such terms are used in 48

C.F.R. §12.212 or 48 C.F.R. §227.7202, as applicable. Consistent with 48 C.F.R. §12.212 or 48 C.F.R. §§227.7202-1 through

227.7202-4, as applicable, the Commercial Computer Software and Commercial Computer Software Documentation are

being licensed to U.S. Government end users (a) only as Commercial Items and (b) with only those rights as are granted

to all other end users pursuant to the terms and conditions herein. Unpublished-rights reserved under the copyright

laws of the United States. Adobe Systems Incorporated, 345 Park Avenue, San Jose, CA 95110-2704, USA. For U.S.

Government End Users, Adobe agrees to comply with all applicable equal opportunity laws including, if appropriate, the

provisions of Executive Order 11246, as amended, Section 402 of the Vietnam Era Veterans Readjustment Assistance Act

of 1974 (38 USC 4212), and Section 503 of the Rehabilitation Act of 1973, as amended, and the regulations at 41 CFR

Parts 60-1 through 60-60, 60-250, and 60-741. The affirmative action clause and regulations contained in the preceding

sentence shall be incorporated by reference.

Contents

1 JavaScript Object Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Artboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Artboards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Brush . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Brushes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

CharacterAttributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

CharacterStyle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

CharacterStyles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

CMYKColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

CompoundPathItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

CompoundPathItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Dataset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Datasets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

DocumentPreset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

EPSSaveOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

ExportOptionsAutoCAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

ExportOptionsFlash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

ExportOptionsGIF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

ExportOptionsJPEG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

ExportOptionsPhotoshop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

ExportOptionsPNG8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

ExportOptionsPNG24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

ExportOptionsSVG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

ExportOptionsTIFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

FXGSaveOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Gradient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

GradientColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Gradients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

GradientStop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Contents 4

GradientStops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

GraphicStyle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

GraphicStyles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

GraphItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

GraphItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

GrayColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

GroupItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

GroupItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

IllustratorSaveOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

ImageCaptureOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Ink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

InkInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

InsertionPoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

InsertionPoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

LabColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Layer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Layers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

LegacyTextItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

LegacyTextItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

MeshItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

MeshItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

NoColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

NonNativeItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

NonNativeItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

OpenOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

OpenOptionsAutoCAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

OpenOptionsFreeHand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

OpenOptionsPhotoshop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

PageItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

PageItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

PaperInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

ParagraphAttributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Paragraphs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

ParagraphStyle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

ParagraphStyles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Contents 5

PathItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

PathItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

PathPoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

PathPoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

PatternColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

PDFFileOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

PDFSaveOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

PhotoshopFileOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

PlacedItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

PlacedItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

PluginItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

PluginItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

PPDFile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

PPDFileInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

PrintColorManagementOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

PrintColorSeparationOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

PrintCoordinateOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

PrinterInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

PrintFlattenerOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

PrintFontOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

PrintJobOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

PrintOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

PrintPageMarksOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

PrintPaperOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

PrintPostScriptOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

RasterEffectOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

RasterItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

RasterItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

RasterizeOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

RGBColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

ScreenInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

ScreenSpotFunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Spot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Contents 6

SpotColor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196

Spots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

Story . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

Stories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Swatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

Swatches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

SwatchGroup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

SwatchGroups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205

Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206

SymbolItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

SymbolItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210

Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211

TabStopInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

Tag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214

Tags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216

TextFont . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217

TextFonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218

TextFrameItem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220

TextFrameItems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

TextPath . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226

TextRange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228

TextRanges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

TracingObject . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231

TracingOptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233

Variable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235

Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236

View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237

Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238

Words . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

2 Scripting Constants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241

1JavaScript Object Reference

This section presents all of the object classes in the type library. Each class listing includes the following:

Properties of the class, including value type, read-only status, and an explanation.

Methods for the class. Constants and value types needed by the method are shown in bold face.

Required terms are shown in plain face. All items surrounded by brackets [ ] are optional.

Notes to explain special issues.

Sample code to help illustrate the syntax and typical workflow usage of the object class.

These examples are intended to be clear demonstrations of syntax, and do not show the best or most

efficient way to construct a JavaScript script. Error checking, for instance, is generally brief or missing.

However, the examples can be combined and expanded to make scripts with greater functionality.

CHAPTER 1: JavaScript Object Reference Application 8

Application

The Adobe® Illustrator® application object, referenced using the pre-defined global app object, which

contains all other Illustrator objects.

Application properties

Property Value type What it is

activeDocument Document The active (frontmost) document in Illustrator.

browserAvailable boolean Read-only. If true, a web browser is available.

buildNumber string Read-only. The application’s build number.

colorSettingsList object Read-only. The list of color-settings files currently

available for use.

coordinateSystem CoordinateSystem The coordinate system currently in use,

document or artboard.

defaultColorSettings File Read-only. The default color-settings file for the

current application locale.

documents Documents Read-only. The documents in the application.

flattenerPresetList object Read-only. The list of flattener style names

currently available for use.

freeMemory number (long) Read-only. The amount of unused memory (in

bytes) within the Illustrator partition.

locale string Read-only. The application’s locale.

name string Read-only. The application’s name (not related to

the filename of the application file).

pasteRememberLayers boolean Read-only. If true, the paste operation maintains

the layer structure.

path File Read-only. The file path to the application.

PDFPresetsList object Read-only. The list of preset PDF-options names

available for use.

PPDFileList object Read-only. The list of PPD files currently available

for use.

preferences Preferences Illustrator’s preference settings.

printerList array of Printer Read-only. The list of installed printers.

printPresetsList object Read-only. The list of preset printing-options

names available for use.

scriptingVersion string Read-only. The version of the Scripting plug-in.

CHAPTER 1: JavaScript Object Reference Application 9

Application methods

selection array of objects All currently selected objects in the active

(frontmost) document.

startupPresetsList object Read-only. The list of presets available for

creating a new document.

textFonts TextFonts Read-only. The installed fonts.

tracingPresetList array of string Read-only. The list of preset tracing-options

names available for use.

typename string Read-only. The class name of the referenced

object.

userInteractionLevel UserInteractionLevel What level of interaction with the user should be

allowed when handling script commands.

version string Read-only. The application’s version.

visible boolean Read-only. If true, the application is visible.

Property Value type What it is

Method Parameter type Returns What it does

beep

()

nothing Alerts the user.

concatenateMatrix

(matrix,

secondMatrix)

Matrix

Matrix Joins two matrices together.

concatenateRotationMatrix

(matrix,

angle)

Matrix

number (double)

Matrix Joins a rotation translation to a

transformation matrix.

concatenateScaleMatrix

(matrix

[,scaleX]

[,scaleY])

Matrix

number (double)

Matrix Concatenates a scale translation to

a transformation matrix.

concatenateTranslationMatrix

(matrix

[,deltaX]

[,deltaY])

Matrix

number (double)

Matrix Joins a translation to a

transformation matrix.

convertSampleColor

(sourceColorSpace,

sourceColor,

destColorSpace,

colorConvertPurpose

[,sourceHasAlpha]

[,destHasAlpha])

ImageColorSpace

ColorComponents

ImageColorSpace

ColorConvertPurpose

boolean

array of

ColorComponents

Converts a sample-component

color from one color space to

another.

copy

()

nothing Copies current selection to the

clipboard.

CHAPTER 1: JavaScript Object Reference Application 10

cut

()

nothing Cuts current selection to the

clipboard.

deleteWorkspace()

(workspaceName) string

Boolean Deletes an existing workspace.

getIdentityMatrix

()

Matrix Returns an identity matrix.

getIsFileOpen

(filePath) string

Boolean Returns if the specified filePath is

open

getPPDFileInfo

(name) string

PPDFileInfo Gets detailed file information for

specified PPD file.

getPresetFileOfType

(presetType) DocumentPresetType

File Returns the full path to the

application’s default document

profile for the specified preset

type.

getPresetSettings

(preset) string

DocumentPreset Retrieves the tracing-option

settings from the template with a

given preset name.

getRotationMatrix

([angle]) number (double)

Matrix Returns a transformation matrix

containing a single rotation.

NOTE: Requires a value in degrees.

For example, 30 rotates the object

30 degrees counterclockwise; -30

rotates the object 30 degrees

clockwise.

getScaleMatrix

([scaleX]

[, scaleY])

number (double)

Matrix Returns a transformation matrix

containing a single scale.

NOTE: Requires a value in

percentage. For example, 60 scales

the object to 60% of its original

size; 200 doubles the object’s

bounds.

getScriptableHelpGroup

()

variant Gets the scriptable help group

object that represents the search

widget in the app bar.

getTranslationMatrix

([deltaX]

[, deltaY])

number (double)

Matrix Returns a transformation matrix

containing a single translation.

NOTE: Requires a value in points.

For example, ({100,200} moves the

object 100 pt. to the right and 200

pt. up; a minus before each

number moves the object left and

down.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference Application 11

invertMatrix

(matrix) Matrix

Matrix Inverts a matrix.

isEqualMatrix

(matrix,

secondMatrix)

Matrix

boolean Checks whether the two matrices

are equal.

isSingularMatrix

(Matrix) Matrix

boolean Checks whether a matrix is singular

and cannot be inverted.

loadColorSettings

(fileSpec) File

nothing Loads color settings from specified

file, or, if file is empty, turns color

management off.

open

(file

[, documentColorSpace]

[, options])

File

DocumentColorSpace

anything

Document Opens the specified document file.

If you open a pre-Illustrator 9

document that contains both

RGB and CMYK colors and

documentColorSpace

is supplied,

all colors are converted to the

specified color space. If the

parameter is not supplied,

Illustrator opens a dialog so the

user can choose the color space.

paste() nothing Pastes current clipboard content

into the current document.

quit

()

nothing Quits Illustrator. Note that if the

clipboard contains data, Illustrator

may show a dialog prompting the

user to save the data for other

applications.

redo() nothing Redoes the most recently undone

transaction.

redraw

()

nothing Forces Illustrator to redraw all its

windows.

resetWorkspace()

()

Boolean Resets the current workspace.

saveWorkspace()

(workspaceName) string

Boolean Saves a new workspace.

sendScriptMessage

(pluginName,

messageSelector,

inputString)

string

string Sends a plug-in-defined command

message to a plug-in with given

input arguments, and returns the

plug-in-defined result string.

showPresets

(fileSpec) File

PrintPresetList Gets presets from the file.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference Application 12

Duplicating the active document

// Duplicates any selected items from

// the active document into a new document.

var newItem;

var docSelected = app.activeDocument.selection;

if ( docSelected.length > 0 ) {

// Create a new document and move the selected items to it.

var newDoc = app.documents.add();

if ( docSelected.length > 0 ) {

for ( i = 0; i < docSelected.length; i++ ) {

docSelected[i].selected = false;

newItem = docSelected[i].duplicate( newDoc,

ElementPlacement.PLACEATEND );

}

else {

docSelected.selected = false;

newItem = docSelected.parent.duplicate( newDoc,

ElementPlacement.PLACEATEND );

}

else {

alert( "Please select one or more art objects" );

}

switchWorkspace()

(workspaceName) string

Boolean Switches to the specified

workspace.

translatePlaceholderText

(text) string

string Translates the placeholder text to

regular text (a way to enter

Unicode points in hex values).

undo() nothing Undoes the most recent

transaction.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference Artboard 13

Artboard

An Artboard object represents a single artboard in a document. There can be between 1 to 100 artboards

in one document.

Artboard properties

Artboards methods

Property Value type What it is

artboardRect rect Size and position of the artboard.

name string The unique identifying name of the artboard.

parent Document Read-only. The parent of this object.

rulerOrigin Point Ruler origin of the artboard, relative to the top left corner of the

artboard.

rulerPAR number (double) Pixel aspect ratio, used in ruler visualization if the units are

pixels. Range: 0.1 to 10.0

showCenter boolean Show center mark.

showCrossHairs boolean Show cross hairs.

showSafeAreas boolean Show title and action safe areas (for video).

typename string Read-only. The class name of this object.

Method Parameter type Returns What it does

remove

()

Nothing Deletes this artboard object. You

cannot remove the last artboard in a

document.

CHAPTER 1: JavaScript Object Reference Artboards 14

Artboards

A collection of Artboard objects.

Artboards properties

Artboards methods

Property Value type What is it

length number Read-only. The number of datasets in the collection

parent Artboard Read-only. The name of the object that contains this dataset

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

(artboardRect) rect

Artboard Creates a new Artboard object.

getActiveArtboardIndex

()

number (long) Retrieves the index position of the

active artboard in the document's list.

Returns the 0-based index.

getByName

(name) string

Artboard Gets the first element in the

collection with the specified name.

insert

(artboardRect,

index)

rect

number (long)

Nothing Creates a new Artboard object and

inserts it at the given index in the list.

remove

(index)

number (long) Nothing Deletes an artboard object. You

cannot remove the last artboard in a

document.

setActiveArtboardIndex

(index)

number (long) Nothing Makes a specific artboard active and

makes it current in the iteration order.

CHAPTER 1: JavaScript Object Reference Brush 15

Brush

A brush in an Illustrator document. Brushes are contained in documents. Additional brushes may be

created by the user within Illustrator. You can access brushes within a script, but you cannot create them.

Brush properties

Brush methods

Applying a brush

// Duplicates and groups all items in the current selection,

// then applies the same brush to each item in the group

if ( app.documents.length > 0 ) {

docSelection = app.activeDocument.selection;

if ( docSelection.length > 0 ) {

newGroup = app.activeDocument.groupItems.add();

for ( i = 0; i < docSelection.length; i++ ) {

newItem = docSelection[i].duplicate();

newItem.moveToBeginning( newGroup );

}

brush4 = app.activeDocument.brushes[1];

brush4.applyTo( newGroup );

}

Property Value type What it is

name string The name of the brush.

parent Document Read-only. The document that contains this brush.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

applyTo

(artItem) PageItem

Nothing Applies the brush to a specific art item.

CHAPTER 1: JavaScript Object Reference Brushes 16

Brushes

A collection of brush objects in a document.

Brushes properties

Brushes methods

Counting brushes

// Counts all brushes in the active document

if ( app.documents.length > 0 ) {

numberOfBrushes = app.activeDocument.brushes.length;

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The document that contains this brushes collection.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

getByName

(name) string

Brush Gets the first element in the collection with the specified

name.

index

(itemKey) string, number

Brush Gets an element from the collection.

CHAPTER 1: JavaScript Object Reference CharacterAttributes 17

CharacterAttributes

Specifies the properties of a character contained in a text frame. A CharacterStyle object associates

these attributes with a specific text range through its characterAttributes property.

NOTE: Character attributes do not have default values, and are undefined until explicitly set.

CharacterAttributes properties

Property Value type What it is

akiLeft number (double) The amount of inter-character

spacing to be added to the left

side of the character, in

thousandths of an em (that

amount will not compress or

expand during full-justification).

akiRight number (double) The amount of inter-character

spacing to be added to the right

side of the character, in

thousandths of an em (that

amount will not compress or

expand during full-justification).

alignment StyleRunAlignmentType The character alignment type.

alternateGlyphs AlternateGlyphsForm The alternate glyphs form.

autoLeading boolean If true, the automatic leading

should be used.

baselineDirection BaselineDirectionType The Japanese text baseline

direction.

baselinePosition FontBaselineOption The baseline position of text.

baselineShift number (double) The amount of shift in points of

the text baseline.

capitalization FontCapsOption The case of text.

connectionForms boolean If true, the OpenType®

connection forms should be

used.

contextualLigature boolean If true, the contextual ligature

should be used.

discretionaryLigature boolean If true, the discretionary

ligature should be used.

figureStyle FigureStyleType The number style in an

OpenType font.

fillColor Color The color of the text fill.

CHAPTER 1: JavaScript Object Reference CharacterAttributes 18

fractions boolean If true, the OpenType fractions

should be used.

horizontalScale number (double) The character horizontal scaling

factor expressed as a

percentage (100 = 100%).

italics boolean If true, the Japanese OpenType

font supports italics.

kerningMethod AutoKernType The automatic kerning method

to use.

language LanguageType The language of text.

leading number (double) The amount of space between

two lines of text, in points.

ligature boolean If true, the ligature should be

used.

noBreak boolean If true, line breaks are not

allowed.

openTypePosition FontOpenTypePositionOption The OpenType baseline

position.

ordinals boolean If true, the OpenType ordinals

should be used.

ornaments boolean If true, the OpenType

ornaments should be used.

overprintFill boolean If true, the fill of the text should

be overprinted.

overprintStroke boolean If true, the stroke of the text

should be overprinted.

parent object Read-only. The object’s

container.

proportionalMetrics boolean If true, the Japanese OpenType

font supports proportional

glyphs.

rotation number (double) The character rotation angle in

degrees.

size number (double) Font size in points.

strikeThrough boolean If true, characters use

strike-through style.

strokeColor Color The color of the text stroke.

strokeWeight number (double) Line width of stroke.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference CharacterAttributes 19

stylisticAlternates boolean If true, the OpenType stylistic

alternates should be used.

swash boolean If true, the OpenType swash

should be used.

tateChuYokoHorizontal number (long) The Tate-Chu-Yoko horizontal

adjustment in points.

tateChuYokoVertical number (long) The Tate-Chu-Yoko vertical

adjustment in points.

textFont TextFont The text font.

titling boolean If true, the OpenType titling

alternates should be used.

tracking number (long) The tracking or range kerning

amount, in thousandths of an

em.

Tsume number (double) The percentage of space

reduction around a Japanese

character.

typename string Read-only. The class name of

the object.

underline boolean If true, characters are

underlined.

verticalScale number (double) Character vertical scaling factor

expressed as a percentage (100

= 100%).

wariChuCharactersAfterBreak number (long) Specifies how the characters in

Wari-Chu text (an inset note in

Japanese text) are divided into

two or more lines.

wariChuCharactersBeforeBreak number (long) Specifies how the characters in

Wari-Chu text (an inset note in

Japanese text) are divided into

two or more lines.

wariChuEnabled boolean If true, Wari-Chu is enabled.

wariChuJustification WariChuJustificationType The Wari-Chu justification.

wariChuLineGap number (long) The Wari-Chu line gap.

wariChuLines number (long) The number of Wari-Chu

(multiple text lines fit into a

space meant for one) lines.

wariChuScale number (double) The Wari-Chu scale.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference CharacterAttributes 20

Setting character attributes

// Creates a new document, adds a simple text item

// then incrementally increases the horizontal and

// vertical scale attributes of each character

var docRef = documents.add();

var textRef = docRef.textFrames.add();

textRef.contents = "I Love Scripting!";

textRef.top = 400;

textRef.left = 100;

// incrementally increase the scale of each character

var charCount = textRef.textRange.characters.length;

var size = 100;

for(i=0; i<charCount; i++, size *= 1.2) {

textRef.textRange.characters[i].characterAttributes.horizontalScale

= size;

textRef.textRange.characters[i].characterAttributes.verticalScale

= size;

}

CHAPTER 1: JavaScript Object Reference Characters 21

Characters

A collection of characters (TextRange objects of length 1). The elements are not named; you must access

them by index.

Characters properties

Characters methods

Counting characters

// Counts all characters in the active document,

// including whitespace, and stores in numChars

if ( app.documents.length > 0 ) {

var doc = app.activeDocument;

var numChars = 0;

for ( i = 0; i < doc.textFrames.length; i++ ) {

textArtRange = doc.textFrames[i].contents;

numChars += textArtRange.length;

}

Property Value type What it is

length number Read-only. The number of characters in the collection.

parent object Read-only. The text art item that contains this character.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

(contents

[,relativeObject]

[,insertionLocation])

string

TextFrameItem

ElementPlacement

TextRange Adds a new character with

specified text contents at the

specified location in the current

document. If a location is not

specified, adds the new character

to the containing text frame after

the current text selection or

insertion point.

addBefore

(contents) string

TextRange Adds a character before the

specified text selection.

index

(itemKey) number

TextRange Gets an element from the

collection.

removeAll

()

Nothing Deletes all elements in the

collection.

CHAPTER 1: JavaScript Object Reference CharacterStyle 22

CharacterStyle

Associates character attributes with characters. For an example, see CharacterStyles.

CharacterStyle properties

CharacterStyle methods

Property Value type What it is

characterAttributes CharacterAttributes Read-only. The character properties for the style.

name string The character style’s name.

parent object Read-only. The object’s container.

typename string Read-only. The class name of the object.

Method Parameter type Returns What it does

applyTo

(textItem

[,clearingOverrides])

object

boolean

Nothing Applies the character style to the text

object or objects.

remove

()

Nothing Deletes the object.

CHAPTER 1: JavaScript Object Reference CharacterStyles 23

CharacterStyles

A collection of CharacterStyle objects.

CharacterStyles properties

CharacterStyles methods

Using characters styles

// Creates 3 text frames in a new document then creates

// a character style and applies it to each text frame.

var docRef = documents.add();

var textRef1 = docRef.textFrames.add();

textRef1.contents = "Scripting is fun!";

textRef1.top = 700;

textRef1.left = 50;

var textRef2 = docRef.textFrames.add();

textRef2.contents = "Scripting is easy!";

textRef2.top = 625;

textRef2.left = 100;

var textRef3 = docRef.textFrames.add();

textRef3.contents = "Everyone should script!";

textRef3.top = 550;

textRef3.left = 150;

redraw();

// Create a new character style

var charStyle = docRef.characterStyles.add("BigRed");

Property Value type What it is

length number Read-only. Number of elements in the collection.

parent object Read-only. The object’s container.

typename string Read-only. The class name of the object.

Method Parameter type Returns What it does

add

(name) string

CharacterStyle Creates a named character style.

getByName

(name) string

CharacterStyle Gets the first element in the collection with the

provided name.

index

(itemKey) string, number

CharacterStyle Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference CharacterStyles 24

// set character attributes

var charAttr = charStyle.characterAttributes;

charAttr.size = 40;

charAttr.tracking = -50;

charAttr.capitalization = FontCapsOption.ALLCAPS;

var redColor = new RGBColor();

redColor.red = 255;

redColor.green = 0;

redColor.blue = 0;

charAttr.fillColor = redColor;

// apply to each textFrame in the document

charStyle.applyTo(textRef1.textRange);

charStyle.applyTo(textRef2.textRange);

charStyle.applyTo(textRef3.textRange);

CHAPTER 1: JavaScript Object Reference CMYKColor 25

CMYKColor

A CMYK color specification, used where a color object is required.

If the color space of a document is RGB and you specify the color value for a page item in that document

using CMYK, Illustrator will translate the CMYK color specification into an RGB color specification. The same

thing happens if the document’s color space is CMYK and you specify colors using RGB. Since this

translation can lose information, you should specify colors using the class that matches the document’s

actual color space.

CMYKColor properties

Setting a CMYK color

// Sets the fill color of the frontmost path item in

// the current document to a light purple CMYK color

if ( app.documents.length > 0 && app.activeDocument.pathItems.length > 0) {

frontPath = app.activeDocument.pathItems[0];

// Set color values for the CMYK object

newCMYKColor = new CMYKColor();

newCMYKColor.black = 0;

newCMYKColor.cyan = 30.4;

newCMYKColor.magenta = 32;

newCMYKColor.yellow = 0;

// Use the color object in the path item

frontPath.filled = true;

frontPath.fillColor = newCMYKColor;

}

Property Value type What it is

black number (double) The black color value. Range 0.0–100.0. Default: 0.0

cyan number (double) The cyan color value. Range 0.0–100.0. Default: 0.0

magenta number (double) The magenta color value. Range 0.0–100.0. Default: 0.0

typename string Read-only. The class name of the referenced object.

yellow number (double) The yellow color value. Range 0.0–100.0. Default: 0.0

CHAPTER 1: JavaScript Object Reference Color 26

Color

An abstract parent class for all color classes used in Illustrator. Subclasses are:

CMYKColor

GradientColor

GrayColor

LabColor

NoColor

PatternColor

RGBColor

SpotColor

CHAPTER 1: JavaScript Object Reference CompoundPathItem 27

CompoundPathItem

A compound path. These objects are composed of multiple intersecting paths, resulting in transparent

interior spaces where the component paths overlap. The pathItems property provides access to the paths

that make up the compound path.

Paths contained within a compound path or group in a document are returned as individual paths when a

script asks for the paths contained in the document. However, paths contained in a compound path or

group are not returned when a script asks for the paths in a layer that contains the compound path or

group.

All paths within a compound path share property values. Therefore, if you set the value of a property of

any one of the paths in the compound path, the properties of all other component paths are updated with

the new value.

CompoundPathItem properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so, what

kind of knockout.

blendingMode BlendModes The mode used when compositing an object.

controlBounds array of

4numbers

Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this item is editable.

geometricBounds array of

4numbers

Read-only. The bounds of the object excluding stroke

width.

height number(double) The height of the compound path item excluding stroke

width.

hidden boolean If true, this compound path item is hidden.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this compound path item

belongs.

left number(double) The position of the left side of the item (in points,

measured from the left side of the page).

locked boolean If true, this compound path item is locked.

name string The name of this compound path item.

note string The note assigned to this item.

opacity number (double) The opacity of the object. Range: 0.0 to 100.0

parent Layer or

GroupItem

Read-only. The parent of this object.

pathItems PathItems Read-only. The path art items in this compound path.

CHAPTER 1: JavaScript Object Reference CompoundPathItem 28

position array of

2numbers

The position (in points) of the top left corner of the

compoundPathItem object in the format [x, y]. Does not

include stroke weight.

selected boolean If true, this compound path item is selected.

sliced boolean If true, the item is sliced. Default: false

tags Tags Read-only. The tags contained in this object.

top number (double) The position of the top of the item (in points, measured

from the bottom of the page).

typename string Read-only. Read-only. The class name of the referenced

object.

uRL string The value of the Adobe URL tag assigned to this

compound path item.

visibilityVariable Variant The visibility variable bound to the item.

visibleBounds array of

4numbers

Read-only. The visible bounds of the compound path item

including stroke width.

width number (double) The width of the compound path item excluding stroke

width.

wrapInside boolean If true, the text frame object should be wrapped inside

this object.

wrapOffset number (double) The offset to use when wrapping text around this object.

wrapped boolean If true, wrap text frame objects around this object (text

frame must be above the object).

zOrderPosition number (long) Read-only. The position of this art item within the stacking

order of the group or layer (Parent) that contains the art

item.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference CompoundPathItem 29

CompoundPathItem methods

Method Parameter type Returns What it does

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

CompoundPath

Item

Creates a duplicate of the

selected object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

Nothing Moves the object.

remove

()

Nothing Deletes this object.

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item where

scaleX is the horizontal

scaling factor and scaleY

is the vertical scaling

factor. 100.0 = 100%.

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item

relative to the current

rotation. The object is

rotated

counter-clockwise if the

angle value is positive,

clockwise if the value is

negative.

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art item

by applying a

transformation matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art item

relative to the current

position, where deltaX is

the horizontal offset and

deltaY is the vertical

offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the stacking

order of the group or

layer (parent) of this

object.

CHAPTER 1: JavaScript Object Reference CompoundPathItem 30

Selecting paths in a document

// Selects all paths not part of a compound path

if ( app.documents.length > 0 ) {

doc = app.activeDocument;

count = 0;

if ( doc.pathItems.length > 0 ) {

thePaths = doc.pathItems;

numPaths = thePaths.length;

for ( i = 0; i < doc.pathItems.length; i++ ) {

pathArt = doc.pathItems[i];

if ( pathArt.parent.typename != "CompoundPathItem" ) {

pathArt.selected = true;

count++;

}

Creating and modifying a compound path item

// Creates a new compound path item containing 3 path

// items, then sets the width and the color of the stroke

// to all items in the compound path

if ( app.documents.length > 0 ) {

doc = app.activeDocument;

newCompoundPath = doc.activeLayer.compoundPathItems.add();

// Create the path items

newPath = newCompoundPath.pathItems.add();

newPath.setEntirePath( Array( Array(30, 50), Array(30, 100) ) );

newPath = newCompoundPath.pathItems.add();

newPath.setEntirePath( Array( Array(40, 100), Array(100, 100) ) );

newPath = newCompoundPath.pathItems.add();

newPath.setEntirePath( Array( Array(100, 110), Array(100, 300) ) );

// Set stroke and width properties of the compound path

newPath.stroked = true;

newPath.strokeWidth = 3.5;

newPath.strokeColor = app.activeDocument.swatches[3].color;

}

CHAPTER 1: JavaScript Object Reference CompoundPathItems 31

CompoundPathItems

A collection of CompoundPathItem objects.

CompoundPathItem methods

Counting compound paths

// Counts all compound path items in layer 1 of the current document

if ( app.documents.length > 0 ) {

doc = app.activeDocument;

numCompoundPaths = doc.layers[0].compoundPathItems.length;

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this collection (either a Layer or a GroupItem).

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

CompoundPathItem Creates a new CompoundPathItem.

getByName

(name) string

CompoundPathItem Gets the first element in the collection with

the specified name.

index

(itemKey) string, number

CompoundPathItem Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference Dataset 32

Dataset

A set of data used for dynamic publishing. A dataset allows you to collect a number of variables and their

dynamic data into one object. You must have at least one variable bound to an art item in order to create a

dataset. See the class Variable.

Dataset properties

Dataset methods

Using variables and datasets

// Creates two variables, 1 visibility and 1 text,

// creates two datasets each with different values

// for the variables, then displays both datasets

var docRef = documents.add();

// Create visibility variable

var itemRef = docRef.pathItems.rectangle(600, 200, 150, 150);

var colorRef = new RGBColor;

colorRef.red = 255;

itemRef.fillColor = colorRef;

var visibilityVar = docRef.variables.add();

visibilityVar.kind = VariableKind.VISIBILITY;

itemRef.visibilityVariable = visibilityVar;

// Create text variable

var textRef = docRef.textFrames.add();

textRef.contents = "Text Variable, dataset 1";

textRef.top = 400;

textRef.left = 200;

var textVar = docRef.variables.add();

textVar.kind = VariableKind.TEXTUAL;

Property Value type What is it

name string Then name of the dataset.

parent Document Read-only. The name of the object that contains this dataset.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

display

()

Nothing Displays the dataset.

remove

()

Nothing Deletes this object.

update

()

Nothing Updates the dataset.

CHAPTER 1: JavaScript Object Reference Dataset 33

textRef.contentVariable = textVar;

redraw();

// Create dataset 1

var ds1 = docRef.dataSets.add();

// Change variable values and create dataset 2

itemRef.hidden = true;

textRef.contents = "Text Variable, dataset 2";

redraw();

var ds2 = docRef.dataSets.add();

// display each dataset

ds1.display();

redraw();

ds2.display();

redraw();

CHAPTER 1: JavaScript Object Reference Datasets 34

Datasets

A collection of Dataset objects.

Datasets properties

Datasets methods

Property Value type What is it

length number Read-only. The number of datasets in the collection

parent Document Read-only. The name of the object that contains this dataset

typename string Read-only. Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

Dataset Creates a new dataset object.

getByName

(name) string

Dataset Gets the first element in the collection with the

specified name.

index

(itemKey) string, number

Dataset Gets an element from the collection.

removeAll

()

Nothing Removes all elements in the collection.

CHAPTER 1: JavaScript Object Reference Document 35

Document

An Illustrator document. Documents are contained in the Application object.

The default document settings—those properties starting with the word “default”—are global settings

that affect the current document. Be sure to modify these default properties only when a document is

open. Note that if you set default properties to desired values before creating new objects, you can

streamline your scripts, eliminating the need to specify specific properties such as fillColor and

stroked that have default properties.

A document’s color space, height, and width can only be set when the document is created. You cannot

modify these properties in an existing document. See Application.open for more information on how

document color spaces are handled.

Document properties

Property Value type What it is

activeDataset Dataset The currently opened dataset.

activeLayer Layer The active layer in the document.

activeView View Read-only. The document’s current view.

artboards Artboards Read-only. All artboards in the document.

brushes Brushes Read-only. The brushes contained in the

document.

characterStyles CharacterStyles Read-only. The list of character styles in this

document.

compoundPathItems CompoundPathItems Read-only. The compound path items

contained in the document.

cropBox array of 4 numbers The boundary of the document’s cropping box

for output, or null if no value has been set.

cropStyle CropOptions The style of the document’s cropping box.

dataSets Datasets Read-only. The datasets contained in the

document.

defaultFillColor Color The color to use to fill new paths if

defaultFilled is true.

defaultFilled boolean If true, a new path should be filled.

defaultFillOverprint boolean If true, the art beneath a filled object should

be overprinted by default.

defaultStrokeCap StrokeCap Default type of line capping for paths created.

defaultStrokeColor Color The stroke color for new paths if default

stroked is true.

defaultStroked boolean If true, a new path should be stroked.

CHAPTER 1: JavaScript Object Reference Document 36

defaultStrokeDashes object Default lengths for dashes and gaps in dashed

lines, starting with the first dash length,

followed by the first gap length, and so on. Set

to an empty object, {}, for solid line.

defaultStrokeDashOffset number (double) The default distance into the dash pattern at

which the pattern should be started for new

paths.

defaultStrokeJoin StrokeJoin Default type of joints in new paths.

defaultStrokeMiterLimit number (double) When a default stroke join is set to mitered,

this property specifies when the join will be

converted to beveled (squared-off) by default.

The default miter limit of 4 means that when

the length of the point reaches four times the

stroke weight, the join switches from a miter

join to a bevel join. Range: 1 to 500; a value of 1

specifies a bevel join.

defaultStrokeOverprint boolean If true, the art beneath a stroked object should

be overprinted by default.

defaultStrokeWidth number (double) Default width of stroke for new paths.

documentColorSpace DocumentColorSpace Read-only. The color specification system to

use for this document’s color space.

fullName File Read-only. The file associated with the

document, which includes the complete path

to the file.

geometricBounds array of 4 numbers Read-only. The bounds of the illustration

excluding the stroke width of any objects in the

document.

gradients Gradients Read-only. The gradients contained in the

document.

graphicStyles GraphicStyles Read-only. The graphic styles defined in this

document.

graphItems GraphItems Read-only. The graph art items in this

document.

groupItems GroupItems Read-only. The group items contained in the

document.

height number (double) Read-only. The height of the document.

inkList object Read-only. The list of inks in this document.

kinsokuSet object Read-only. The Kinsoku set of characters that

cannot begin or end a line of Japanese text.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference Document 37

layers Layers Read-only. The layers contained in the

document.

legacyTextItems LegacyTextItems Read-only. The legacy text items in the

document.

meshItems MeshItems Read-only. The mesh art items contained in the

document.

mojikumiSet object Read-only. A list of names of predefined

Mojikumi sets which specify the spacing for the

layout and composition of Japanese text.

name string Read-only. The document’s name (not the

complete file path to the document).

nonNativeItems NonNativeItems Read-only. The non-native art items in this

document.

outputResolution number (double) Read-only. The current output resolution for

the document in dots per inch (dpi).

pageItems PageItems Read-only. The page items (all art item classes)

contained in the document.

pageOrigin array of 2 numbers The zero-point of the page in the document

without margins, relative to the overall height

and width.

paragraphStyles ParagraphStyles Read-only. The list of paragraph styles in this

document.

parent Application Read-only. The application that contains this

document.

path File Read-only. The file associated with the

document, which includes the complete path

to the file.

pathItems PathItems Read-only. The path items contained in this

document.

patterns Patterns Read-only. The patterns contained in this

document.

placedItems PlacedItems Read-only. The placed items contained in this

document.

pluginItems PluginItems Read-only. The plug-in items contained in this

document.

printTiles boolean Read-only. If true, this document should be

printed as tiled output.

rasterEffectSettings RasterEffectOptions The document’s raster effect settings.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference Document 38

rasterItems RasterItems Read-only. The raster items contained in this

document.

rulerOrigin array of 2 numbers The zero-point of the rulers in the document

relative to the bottom left of the document.

rulerUnits RulerUnits Read-only. The default measurement units for

the rulers in the document.

saved boolean If true, the document has not been changed

since last time it was saved.

selection array of objects References to the objects in this document’s

current selection, or null when nothing is

selected.

A reference to an insertion point is returned

when there is an active insertion point in the

contents of a selected text art item. Similarly, a

reference to a range of text is returned when

characters are selected in the contents of a text

art item.

showPlacedImages boolean Read-only. If true, placed images should be

displayed in the document.

splitLongPaths boolean Read-only. If true, long paths should be split

when printing.

spots Spots Read-only. The spot colors contained in this

document.

stationery boolean Read-only. If true, the file is a stationery file.

stories Stories Read-only. The story items in this document.

swatches Swatches Read-only. The swatches in this document.

swatchGroups SwatchGroups Read-only. The swatch groups in this

document.

symbolItems SymbolItems Read-only. The art items in the document

linked to symbols.

symbols Symbols Read-only. The symbols in this document.

tags Tags Read-only. The tags in this document.

textFrames TextFrameItems Read-only. The text frames in this document.

tileFullPages boolean Read-only. If true, full pages should be tiled

when printing this document.

typename string Read-only. Read-only. The class name of the

referenced object.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference Document 39

Document methods

useDefaultScreen boolean Read-only. If true, the printer’s default screen

should be used when printing this document.

variables Variables Read-only. The variables defined in this

document.

variablesLocked boolean If true, the variables are locked.

views Views Read-only. The views contained in this

document.

visibleBounds array of 4 numbers Read-only. The visible bounds of the

document, including stroke width of any

objects in the illustration.

width number (double) Read-only. The width of this document.

XMPString string The XMP metadata packet associated with this

document.

Property Value type What it is

Method Parameter type Returns What it does

activate

()

Nothing Brings the first window

associated with the

document to the front.

arrange

([layoutStyle]) DocumentLayoutStyle

Boolean Arranges multiple

documents in the given

layout style.

([saveOptions]) SaveOptions

Nothing Closes a document using

specified save options.

When you close a document,

you should set your

document reference to null

to prevent your script from

accidentally trying to access

closed documents.

closeNoUI

()

Nothing Closes the specified non-UI

document.

convertCoordinate

(coordinate,

source,

destination)

Point

CoordinateSystem

Point Converts the given point

between artboard and

document coordinate

systems. Returns the

converted point coordinates.

CHAPTER 1: JavaScript Object Reference Document 40

exportFile

(exportFile,

exportFormat

[,options])

File

ExportType

variant

Nothing Exports the document to the

specified file using one of the

predefined export file

formats. The appropriate file

extension is automatically

appended to the file name,

except for Photoshop®

documents. For these, you

must include the file

extension (PSD) in the file

specification.

exportPDFPreset

(file) File

Nothing Exports the current PDF

preset values to the file.

exportPerspectiveGridPreset

(file) File

Nothing Exports the current

perspective grid preset

values to the file.

exportPrintPreset

(file) File

Nothing Exports the current print

preset values to the file.

exportVariables

(fileSpec) File

Nothing Saves datasets into an XML

library. The datasets contain

variables and their associated

dynamic data.

fitArtboardToSelectedArt

([index]) number (long)

boolean Resizes the artboard at the

given index to fit currently

selected art. Index default is

0. Returns true on success.

getPerspectiveActivePlane

()

Perspective

GridPlaneTy

Retrieves the active plane of

the active perspective grid of

the document.

hidePerspectiveGrid

()

boolean Hides the current active grid

for the document. If no grid is

visible, does nothing. Returns

true if a grid is hidden.

imageCapture

(imageFile,

[clipBounds],

[options])

File

Rect

ImageCaptureOptions

Nothing Captures the artwork content

within the clipping

boundaries in this document

as a raster image, and writes

the image data to a specified

file.

If the bounds parameter is

omitted, captures the entire

artwork.

importCharacterStyles

(fileSpec) File

Nothing Loads the character styles

from the Illustrator file.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference Document 41

importParagraphStyles

(fileSpec) File

Nothing Loads the paragraph styles

from the Illustrator file.

importPDFPreset

(fileSpec

[, replacingPreset])

File

boolean

Nothing Loads all PDF presets from a

file.

importPerspectiveGridPreset

(fileSpec

[, perspectivePreset])

File

String

Nothing Loads a specified perspective

grid preset, or, if preset not

specified, all presets from a

file.

importPrintPreset

(printPreset,

fileSpec)

string

File

Nothing Loads the named print preset

from the file.

importVariables

(fileSpec) File

Nothing Imports a library containing

datasets, variables, and their

associated dynamic data.

Importing variables

overwrites existing variables

and datasets.

([options]) PrintOptions

Nothing Prints the document.

rasterize

(sourceArt

[, clipBounds]

[, options])

variant

Rect

RasterizeOptions

RasterItem Rasterizes the source art(s)

within the specified clip

bounds. The source art(s) is

disposed of as a result of the

rasterization.

rearrangeArboards

([artboardLayout,

artboardRowsOrCols,

artboardSpacing,

artboardMoveArtwork])

DocumentArtboardLayout

integer

Number

boolean

boolean Rearranges artboards in the

document. All arguments are

optional. Default layout style

is DocumentArtboard

Layout.GridByRow.

The second argument

specifies the number of rows

or columns, as appropriate

for the chosen layout style, in

the range

[1..docNumArtboards-1],

or 1 (the default) for single

row/column layouts.

Spacing is a number of pixels,

default 20.

When last argument is true

(the default), artwork is

moved with the artboards.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference Document 42

Deselecting all objects in the current document

The frontmost document can be referred to as either activeDocument or documents[0].

var docRef = activeDocument;

docRef.selection = null;

Closing a document

// Closes the active document without saving changes

if ( app.documents.length > 0 ) {

aiDocument = app.activeDocument;

aiDocument.close( SaveOptions.DONOTSAVECHANGES );

aiDocument = null;

}

save

()

Nothing Saves the document in it

current location.

saveAs

(saveIn

[, options])

File

SaveOptions

Nothing Saves the document in the

specified file as an Illustrator,

EPS, or PDF file.

saveNoUI

(saveIn)

File Nothing Saves the non-UI document

at the specified path

selectObjectsOnActiveArtboard

()

boolean Selects the objects on the

currently active artboard.

Returns true on success.

setActivePlane

(gridPlane) PerspectiveGridPlaneType

boolean Sets the active plane of the

active perspective grid of the

document. Returns true on

success.

selectPerspectivePreset

(gridType,

presetName)

PerspectiveGridType

string

boolean Selects a predefined preset to

define grid for the current

document. Returns true on

success.

showPerspectiveGrid

()

boolean Shows the current active grid

for the document, or if no

grid is active, shows the

default grid. Returns true on

success.

windowCapture

(imageFile,

windowSize)

File

array of 2 numbers

Nothing Captures the current

document window to the

target TIFF image file.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference Document 43

Creating a document with defaults

// Creates a new document if none exists

// then sets fill and stroke defaults to true

if ( app.documents.length == 0 ) {

doc = app.documents.add();

}

else {

doc = app.activeDocument;

}

doc.defaultFilled = true;

doc.defaultStroked = true;

CHAPTER 1: JavaScript Object Reference DocumentPreset 44

DocumentPreset

A preset document template to use when creating a new document. See Documents.addDocument().

DocumentPreset properties

Property Value type What it is

artboardLayout DocumentArtboardLayout The layout of artboards in the new

document. Default: GridByRow

artboardRowsOrCols number (long) The number of rows (for rows layout) or

columns (for column layout) of artboards.

Range: 1 to (numArtboards - 1) or 1 for

single row or column layouts. Default: 1

artboardSpacing number (double) The spacing between artboards in the new

document. Default: 20.0

colorMode DocumentColorSpace The color space for the new document.

documentBleedLink Boolean The document link for bleed values.

documentBleedOffsetR

ect

rectangle The document bleed offset rectangle.

height number (double) The height in document points.

Default: 792.0

numArtboards number (long) The number of artboards for the new

document. Range: 1 to 100. Default: 1

previewMode DocumentPreviewMode The preview mode for the new document.

rasterResolution DocumentRasterResolution The raster resolution for the new document.

title string The document title.

transparencyGrid DocumentTransparencyGrid The transparency grid color for the new

document.

typename string Read-only. The class name of the referenced

object.

units RulerUnits The ruler units for the new document.

width number (double) The width in document points.

Default: 612.0

CHAPTER 1: JavaScript Object Reference Documents 45

Documents

A collection of Document objects.

Documents properties

Documents methods

Creating a new document

// Creates a new document with an RGB color space

app.documents.add( DocumentColorSpace.RGB );

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

([documentColorSpace]

[, width]

[, height]

[, numArtBoards]

[, artboardLayout]

[, artboardSpacing]

[, artboardRowsOrCols])

DocumentColorSpace

number (double)

number (long)

DocumentArtboardLayout

number (double)

number (long)

Document Creates a new document

using optional

parameters and returns a

reference to the new

document.

addDocument

(startupPreset

[, presetSettings]

[, showOptionsDialog])

string

DocumentPreset

boolean

Document Creates a document

from the preset,

replacing any provided

setting values, and

returns a reference to the

new document.

addDocumentNoUI

(startupPreset)

string Document Creates a document

without showing in UI

getByName

(name) string

Document Gets the first element in

the collection with the

specified name.

index

(itemKey) string, number

Document Gets an element from

the collection.

CHAPTER 1: JavaScript Object Reference EPSSaveOptions 46

EPSSaveOptions

Options for saving a document as an Illustrator EPS file, used with the saveAs method. All properties are

optional.

EPSSaveOptions properties

Property Value type What it is

artboardRange string If saveMultipleArtboards is true, this

is considered for multi-asset extraction,

which specifies the artboard range. An

empty string extracts all the artboards.

Default: empty string

cmykPostScript boolean If true, use CMYK PostScript.

compatibility Compatibility Specifies the version of the EPS file

format to save. Default:

Compatibility.ILLUSTRATOR1719

compatibleGradientPrinting boolean If true, create a raster item of the

gradient or gradient mesh so that

PostScript Level 2 printers can print the

object. Default: false

embedAllFonts boolean If true, all fonts used by the document

should be embedded in the saved file

(version 7 or later). Default: false

embedLinkedFiles boolean If true, linked image files are to be

included in the saved document.

flattenOuput OutputFlattening How should transparency be flattened

for file formats older than Illustrator 9.

includeDocumentThumbnails boolean If true, thumbnail image of the EPS

artwork should be included.

overprint PDFOverprint Whether to preserve, discard, or

simulate the overprint. Default:

PDFOverprint.PRESERVEPDFOVERPRINT

postScript EPSPostScriptLevelEnum PostScript Language Level to use

(Level 1 valid for file format version 8 or

older). Default:

EPSPostScriptLevelEnum.LEVEL2

preview EPSPreview The format for the EPS preview image.

saveMultipleArtboards boolean If true, all artboards or range of

artboards are saved. Default: false

typename string Read-only. The class name of the

referenced object.

CHAPTER 1: JavaScript Object Reference EPSSaveOptions 47

Exporting to EPS format

// Exports current document to destFile as an EPS file with specified

// options, destFile contains the full path including the file name

function exportFileAsEPS (destFile) {

var newFile = new File(destFile);

var saveDoc;

if ( app.documents.length == 0 )

saveDoc = app.documents.add();

else

saveDoc = app.activeDocument;

var saveOpts = new EPSSaveOptions();

saveOpts.cmykPostScript = true;

saveOpts.embedAllFonts = true;

saveDoc.saveAs( newFile, saveOpts );

}

CHAPTER 1: JavaScript Object Reference ExportOptionsAutoCAD 48

ExportOptionsAutoCAD

Options for exporting a document as an AutoCAD file, used with the exportFile method. All properties are

optional.

When you export a document, a file extension is appended automatically. You should not include any file

extension in the file specification. To override the default AutoCAD export format (DWG), use the

exportFileFormat property.

ExportOptionsAutoCAD properties

Property Value type What it is

alterPathsForAppearance boolean If true, paths are altered if needed to

maintain appearance. Default: false

colors AutoCADColors The colors exported into the

AutoCAD file.

convertTextToOutlines boolean If true, text is converted to vector

paths; preserves the visual

appearance of type. Default: false

exportFileFormat AutoCADExportFileFormat The format to which the file is

exported. Default:

AutoCADExportFileFormat.DWG

exportOption AutoCADExportOption Specifies whether to preserve

appearance or editability during

export. Default:

AutoCADExportOption.

MaximizeEditability

exportSelectedArtOnly boolean If true, only selected artwork is

exported. Default: false

rasterFormat AutoCADRasterFormat The format in which raster art is

exported.

scaleLineweights boolean If true, line weights are scaled by the

same scaling factor as the rest of the

drawing. Default: false

typename string Read-only. The class name of the

referenced object.

unit AutoCADUnit The measurement units from which

to map.

CHAPTER 1: JavaScript Object Reference ExportOptionsAutoCAD 49

unitScaleRatio number (double) The ratio (as a percentage) by which

output is scaled. Range: 0 to 1000

version AutoCADCompatibility The release of AutoCAD to which the

file is exported. Default:

AutoCADCompatibility.AutoCADRe

lease24

Property Value type What it is

CHAPTER 1: JavaScript Object Reference ExportOptionsFlash 50

ExportOptionsFlash

Options for exporting a document as a Macromedia® Flash® (SWF) file, used with the exportFile method.

All properties are optional.

When you export a document, the appropriate file extension is appended automatically. You should not

include any file extension in the file specification.

ExportOptionsFlash properties

Property Value type What it is

artClipping ArtClippingOption How the art should be clipped during output.

Default: ArtClippingOption.OUTPUTARTBOUNDS

artboardRange string If saveMultipleArtboards is true, this is

considered for multi-asset extraction, which

specifies the artboard range. An empty string

extracts all the artboards. Default: empty string

backgroundColor RGBColor The background color of the exported Flash

frames.

backgroundLayers array of Layer A list of layers to be included as the static

background of the exported Flash frames.

blendAnimation BlendAnimationType The animation type for blended objects. Default:

BlendAnimationType.NOBLENDANIMATION

compressed boolean If true, the exported file should be exported

compressed. Default: false

convertTextToOutlines boolean If true, all text is converted to vector paths;

preserves the visual appearance of type in all

Flash players. Default: false

curveQuality number (long) The amount of curve information that should be

presented. Default: 7

exportAllSymbols boolean If true, export all symbols defined in the palette.

Default: false

exportStyle FlashExportStyle The style in which the exported data should be

created in Flash.

Default: FlashExportStyle.ASFLASHFILE

exportVersion FlashExportVersion The version of the exported SWF file.

Default: FlashExportVersion.FlashVersion9.

frameRate number (double) The display rate in frames per second.

Range: 0.01–120.0. Default: 12.0

ignoreTextKerning boolean If true, ignore kerning information in text

objects. Default: false

CHAPTER 1: JavaScript Object Reference ExportOptionsFlash 51

Exporting to Flash format

// Exports current document to destFile as a flash file with specified

// options, destFile contains the full path including the file name

function exportToFlashFile(destFile) {

if ( app.documents.length > 0 ) {

var exportOptions = new ExportOptionsFlash();

var type = ExportType.FLASH;

var fileSpec = new File(destFile);

exportOptions.resolution = 150;

app.activeDocument.exportFile( fileSpec, type, exportOptions );

}

imageFormat FlashImageFormat How should the image in the exported Flash file

be compressed.

Default: FlashImageFormat.LOSSLESS

includeMetadata boolean If true, include minimal XMP metadata in the

SWF file. Default: false

jpegMethod FlashJPEGMethod Specifies the JPEG method to use.

Default: FlashJPEGMethod.Standard

jpegQuality number (long) Level of compression to use. Range 1 to 10.

Default: 3

layerOrder LayerOrderType The order in which layers are exported to Flash

frames. Default: LayerOrderType.BOTTOMUP

looping boolean If true, the Flash file is set to loop when run.

Default: false

playbackAccess FlashPlaybackSecurity The access level for the exported SWF file.

Default:

FlashPlaybackSecurity.PlaybackLocal

preserveAppearance boolean If true, preserve appearance. If false, preserve

editability. Default: false

readOnly boolean If true, export as read-only file. Default: false

replacing SaveOptions If a file with the same name already exists, should

it be replaced.

Default: SaveOptions.PROMPTTOSAVECHANGES

resolution number (double) The resolution in pixels per inch. Range: 72–2400.

Default: 72

saveMultipleArtboards boolean If true, all artboards or range of artboards are

saved. Default: false

typename string Read-only. The class name of the referenced

object.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference ExportOptionsGIF 52

ExportOptionsGIF

Options for exporting a document as a GIF file, used with the exportFile method. All properties are

optional.

When you export a document, the appropriate file extension is appended automatically. You should not

include any file extension in the file specification.

ExportOptionsGIF properties

Property Value type What it is

antiAliasing boolean If true, the exported image should be anti-aliased.

Default: true

artBoardClipping boolean If true, the exported image should be clipped to the

art board. Default: false

colorCount number (long) The number of colors in the exported image’s color

table. Range: 2 to 256. Default: 128

colorDither ColorDitherMethod The method used to dither colors in the exported

image. Default: ColorDitherMethod.DIFFUSION

colorReduction ColorReductionMethod The method used to reduce the number of colors in

the exported image.

Default: ColorReductionMethod.SELECTIVE

ditherPercent number (long) How much should the colors of the exported image be

dithered, where 100.0 is 100%.

horizontalScale number (double) The horizontal scaling factor to apply to the exported

image, where 100.0 is 100%. Default: 100.0

infoLossPercent number (long) The level of information loss allowed during

compression, where 100.0 is 100%.

interlaced boolean If true, the exported image should be interlaced.

Default: false

matte boolean If true, the art board should be matted with a color.

Default: true

matteColor RGBColor The color to use when matting the art board.

Default: WHITE

saveAsHTML boolean If true, the exported image should be saved with an

accompanying HTML file. Default: false

transparency boolean If true, the exported image should use transparency.

Default: true

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference ExportOptionsGIF 53

Exporting to GIF format

// Exports current document to dest as a GIF file with specified

// options, dest contains the full path including the file name

function exportToGIFFile(dest) {

if ( app.documents.length > 0 ) {

var exportOptions = new ExportOptionsGIF();

var type = ExportType.GIF;

var fileSpec = new File(dest);

exportOptions.antiAliasing = false;

exportOptions.colorCount = 64;

exportOptions.colorDither = ColorDitherMethod.DIFFUSION;

app.activeDocument.exportFile( fileSpec, type, exportOptions );

}

verticalScale number (double) The vertical scaling factor to apply to the exported

image, where 100.0 is 100%. Default: 100.0

webSnap number (long) How much should the color table be changed to match

the web palette, where 100 is maximum. Default: 0

Property Value type What it is

CHAPTER 1: JavaScript Object Reference ExportOptionsJPEG 54

ExportOptionsJPEG

Options for exporting a document as a JPEG file, used with the exportFile method. All properties are

optional.

When you export a document, the appropriate file extension is appended automatically. You should not

include any file extension in the file specification.

ExportOptionsJPEG properties

Property Value type What it is

antiAliasing boolean If true, the exported image should be anti-aliased.

Default: true

artBoardClipping boolean If true, the exported image should be clipped to the art

board.

blurAmount number (double) The amount of blur to apply to the exported image.

Range: 0.0 to 2.0. Default: 0.0

horizontalScale number (double) The horizontal scaling factor to apply to the exported

image, where 100.0 is 100%. Default: 100.0

matte boolean If true, the art board should be matted with a color.

Default: true

matteColor RGBColor The color to use when matting the art board.

Default: white

optimization boolean If true, the exported image should be optimized for web

viewing. Default: true

qualitySetting number (long) The quality of the exported image. Range: 0 to 100.

Default: 30

saveAsHTML boolean If true, the exported image should be saved with an

accompanying HTML file. Default: false

typename string Read-only. The class name of the referenced object.

verticalScale number (double) The vertical scaling factor to apply to the exported image.

Range: 0.0 to 776.19. Default: 100.0

CHAPTER 1: JavaScript Object Reference ExportOptionsJPEG 55

Exporting to JPEG format

// Exports current document to dest as a JPEG file with specified

// options, dest contains the full path including the file name

function exportFileToJPEG (dest) {

if ( app.documents.length > 0 ) {

var exportOptions = new ExportOptionsJPEG();

var type = ExportType.JPEG;

var fileSpec = new File(dest);

exportOptions.antiAliasing = false;

exportOptions.qualitySetting = 70;

app.activeDocument.exportFile( fileSpec, type, exportOptions );

}

CHAPTER 1: JavaScript Object Reference ExportOptionsPhotoshop 56

ExportOptionsPhotoshop

Options for exporting a document as a Photoshop file, used with the exportFile method. All properties are

optional.

When you export a document, the appropriate file extension is appended automatically. You should not

include any file extension in the file specification.

ExportOptionsPhotoshop properties

Property Value type What it is

antiAliasing boolean If true, the exported image should be anti-aliased.

Default: true

artboardRange string If saveMultipleArtboards is true, this is considered

for multi-asset extraction, which specifies the

artboard range. An empty string extracts all the

artboards. Default: empty string

editableText boolean If true, text objects should be exported as editable

text layers. Default: true

embedICCProfile boolean If true, an ICC profile should be embedded in the

exported file. Default: false

imageColorSpace ImageColorSpace The color space of the exported file.

Default: ImageColorSpace.RGB

maximumEditability boolean Preserve as much of the original document’s structure

as possible when exporting. Default: true

resolution number (double) Resolution of the exported file in dots per inch (dpi).

Range: 72.0 to 2400.0. Default: 150.0

saveMultipleArtboards boolean If true, all artboards or range of artboards are saved.

Default: false

typename string Read-only. The class name of the referenced object.

warnings boolean If true, a warning dialog should be displayed in case

of conflicts in the export settings. Default: true

writeLayers boolean If true, the document layers should be presented in

the exported document. Default: true

CHAPTER 1: JavaScript Object Reference ExportOptionsPhotoshop 57

Exporting to Photoshop format

// Exports current document to dest as a PSD file with specified

// options, dest contains the full path including the file name

function exportFileToPSD (dest) {

if ( app.documents.length > 0 ) {

var exportOptions = new ExportOptionsPhotoshop();

var type = ExportType.PHOTOSHOP;

var fileSpec = new File(dest);

exportOptions.resolution = 150;

app.activeDocument.exportFile( fileSpec, type, exportOptions );

}

CHAPTER 1: JavaScript Object Reference ExportOptionsPNG8 58

ExportOptionsPNG8

Options for exporting a document as an 8-bit PNG file, used with the exportFile method. All properties are

optional.

When you export a document, the appropriate file extension is appended automatically. You should not

include any file extension in the file specification.

ExportOptionsPNG8 properties

Property Value type What it is

antiAliasing boolean If true, the exported image should be anti-aliased.

Default: true

artBoardClipping boolean If true, the exported image should be clipped to the

art board. Default: false

colorCount number (long) The number of colors in the exported image’s color

table. Range: 2 to 256. Default: 128

colorDither ColorDitherMethod The method used to dither colors in the exported

image. Default: ColorDitherMethod.Diffusion

colorReduction ColorReductionMethod The method used to reduce the number of colors in

the exported image.

Default: ColorReductionMethod.SELECTIVE

ditherPercent number (long) The amount (as a percentage) that the colors of the

exported image are dithered, where 100.0 is 100%.

Range: 0 to 100. Default: 88

horizontalScale number (double) The horizontal scaling factor to apply to the exported

image, where 100.0 is 100%. Default: 100.0

interlaced boolean If true, the exported image should be interlaced.

Default: false

matte boolean If true, the art board should be matted with a color.

Default: true

matteColor RGBColor The color to use when matting the art board.

Default: white

saveAsHTML boolean If true, the exported image be saved with an

accompanying HTML file. Default: false

transparency boolean If true, the exported image use transparency.

Default: true

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference ExportOptionsPNG8 59

Exporting to PNG8 format

// Exports current document to dest as a PNG8 file with specified

// options, dest contains the full path including the file name

function exportFileToPNG8 (dest) {

if ( app.documents.length > 0 ) {

var exportOptions = new ExportOptionsPNG8();

var type = ExportType.PNG8;

var fileSpec = new File(dest);

exportOptions.colorCount = 8;

exportOptions.transparency = false;

app.activeDocument.exportFile( fileSpec, type, exportOptions );

}

verticalScale number (double) The vertical scaling factor to apply to the exported

image, where 100.0 is 100. Default: 100.0

webSnap number (long) Specifies how much the color table should be

changed to match the web palette, where 100 is

maximum. Default: 0

Property Value type What it is

CHAPTER 1: JavaScript Object Reference ExportOptionsPNG24 60

ExportOptionsPNG24

Options for exporting a document as a 24-bit PNG file, used with the exportFile method. All properties are

optional.

When you export a document, the appropriate file extension is appended automatically. You should not

include any file extension in the file specification.

ExportOptionsPNG24 properties

Exporting to PNG24 format

// Exports current document to dest as a PNG24 file with specified

// options, dest contains the full path including the file name, saveAsHTML

// option creates an HTML version with the PNG file in an images folder

function exportFileToPNG24 (dest) {

if ( app.documents.length > 0 ) {

var exportOptions = new ExportOptionsPNG24();

var type = ExportType.PNG24;

var fileSpec = new File(dest);

exportOptions.antiAliasing = false;

exportOptions.transparency = false;

exportOptions.saveAsHTML = true;

app.activeDocument.exportFile( fileSpec, type, exportOptions );

}

Property Value type What it is

antiAliasing boolean If true, the exported image be anti-aliased. Default: true

artBoardClipping boolean If true, the exported image be clipped to the art board.

Default: false

horizontalScale number (double) The horizontal scaling factor to apply to the exported

image, where 100.0 is 100%. Default: 100.0

matte boolean If true, the art board be matted with a color.

Default: true

matteColor RGBColor The color to use when matting the art board.

Default: white

saveAsHTML boolean If true, the exported image be saved with an

accompanying HTML file. Default: false

transparency boolean If true, the exported image use transparency.

Default: true

typename string Read-only. The class name of the referenced object.

verticalScale number (double) The vertical scaling factor to apply to the exported

image, where 100.0 is 100. Default: 100.0

CHAPTER 1: JavaScript Object Reference ExportOptionsSVG 61

ExportOptionsSVG

Options for exporting a document as a SVG file, used with the exportFile method. All properties are

optional.

When you export a document, the appropriate file extension is appended automatically. You should not

include any file extension in the file specification.

ExportOptionsSVG properties

Property Value type What it is

artboardRange string A range of artboards to save, if

saveMultipleArtboards is true. A

comma-delimited list of artboard

names., or the empty string to save all

artboards. Default: empty string

compressed boolean If true, the exported file should be

compressed. Default: false

coordinatePrecision number (long) The decimal precision for element

coordinate values. Range: 1 to 7.

Default: 3

cssProperties SVGCSSPropertyLocation How the CSS properties of the

document should be included in the

exported file. Default:

SVGCSSPropertyLocation.

STYLEATTRIBUTES

documentEncoding SVGDocumentEncoding How the text in the document should

be encoded. Default:

SVGDocumentEncoding.ASCII

DTD SVGDTDVersion The SVG version to which the file

should conform. Default:

SVGDTDVersion.SVG1_1

embedRasterImages boolean If true, the raster images contained in

the document should be embedded

in the exported file. Default: false

fontSubsetting SVGFontSubsetting Which font glyphs should be included

in the exported file. Default:

SVGFontSubsetting.ALLGLYPHS

fontType SVGFontType The type of font to included in the

exported file.

Default: SVGFontType.CEFFONT

includeFileInfo boolean If true, file information should be

saved in the exported file.

Default: false

CHAPTER 1: JavaScript Object Reference ExportOptionsSVG 62

Exporting to SVG format

// Exports current document to dest as an SVG file with specified

// options, dest contains the full path including the file name

function exportFileToSVG (dest) {

if ( app.documents.length > 0 ) {

var exportOptions = new ExportOptionsSVG();

var type = ExportType.SVG;

var fileSpec = new File(dest);

exportOptions.embedRasterImages = true;

exportOptions.embedAllFonts = false;

exportOptions.fontSubsetting = SVGFontSubsetting.GLYPHSUSED;

app.activeDocument.exportFile( fileSpec, type, exportOptions );

}

includeUnusedStyles boolean If true, save unused styles in the

exported file. Default: false

includeVariablesAndDatasets boolean If true, variables and datasets should

be saved in the exported file.

Default: false

optimizeForSVGViewer boolean If true, the exported file should be

optimized for the SVG Viewer.

Default: false

preserveEditability boolean If true, Illustrator editing capabilities

should be preserved when exporting

the document. Default: false

saveMultipleArtboards boolean If true, save the artboards specified

by artboardRange in the exported

file. Default: false

slices boolean If true, slice data should be exported

with the file. Default: false

sVGAutoKerning boolean If true, SVG automatic kerning is

allowed in the file. Default: false

sVGTextOnPath boolean If true, the SVG text-on-path

construct is allowed in the file.

Default: false

typename string Read-only. The class name of the

referenced object.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference ExportOptionsTIFF 63

ExportOptionsTIFF

Options for exporting a document as a TIFF file, used with the exportFile method. All properties are

optional.

When you export a document, the appropriate file extension is appended automatically. You should not

include any file extension in the file specification.

ExportOptionsTIFF properties

Exporting to TIFF format

// Exports current document to dest as a TIFF file with specified

// options, dest contains the full path including the file name

function exportFileToPSD (dest) {

if ( app.documents.length > 0 ) {

var exportOptions = new ExportOptionsTIFF();

var type = ExportType.TIFF;

var fileSpec = new File(dest);

exportOptions.resolution = 150;

exportOptions.byteOrder = TIFFByteOrder.IBMPC;

exportOptions.IZWCompression = false;

app.activeDocument.exportFile( fileSpec, type, exportOptions );

}

Property Value type What it is

antiAliasing boolean If true, the exported image should be anti-aliased.

Default: true

artboardRange string If saveMultipleArtboards is true, this is considered

for multi-asset extraction, which specifies the

artboard range. An empty string extracts all the

artboards. Default: empty string

byteOrder TIFFByteOrder The byte order to use in the new file.

imageColorSpace ImageColorSpace The color space of the exported file.

Default: ImageColorSpace.RGB

IZWCompression boolean If true, use IZW compression in the new file.

resolution number (double) Resolution of the exported file in dots per inch (dpi).

Range: 72.0 to 2400.0. Default: 150.0

saveMultipleArtboards boolean If true, all artboards or range of artboards are saved.

Default: false

CHAPTER 1: JavaScript Object Reference FXGSaveOptions 64

FXGSaveOptions

Specifies options which may be supplied when saving a document as an FXG file. All properties are

optional.

FXGSaveOptions properties

Property Value type What it is

artboardRange string If saveMultipleArtboards is true,

this is considered for multi-asset

extraction, which specifies the

artboard range. An empty string

extracts all the artboards.

Default: empty string

blendsPolicy BlendsExpandPolicy The policy used by FXG to expand

blends. Default:

BlendsExpandPolicy.AUTOMATICA

LLYCONVERTBLENDS

downsampleLinkedImages boolean If true, linked images are

downsampled (at 72 dpi).

Default: false

filtersPolicy FiltersPreservePolicy The policy used by FXG to preserve

filters. Default:

FiltersPreservePolicy.

KEEPFILTERSEDITABLE

gradientsPolicy GradientsPreservePolicy The policy used by FXG to preserve

gradients. Default:

GradientsPreservePolicy.

AUTOMATICALLYCONVERTGRADIENTS

includeUnusedSymbols boolean If true, unused symbols are

included. Default: false

preserveEditingCapabilities boolean If true, the editing capabilities of

FXG are preserved. Default: true

saveMultipleArtboards boolean If true, all artboards or range of

artboards are saved. Default: false

textPolicy TextPreservePolicy The policy used by FXG to preserve

text. Default: TextPreservePolicy.

AUTOMATICALLYCONVERTTEXT

version FXGVersion The version of the FXG file format to

create. Default

FXGVersion.VERSION2PT0

CHAPTER 1: JavaScript Object Reference Gradient 65

Gradient

A gradient definition contained in a document. Scripts can create new gradients.

Gradient properties

Gradient methods

Creating and applying a gradient

// Creates a new gradient in current document then

// applies the gradient to the frontmost path item

if ( app.documents.length > 0 ) {

// Create a color for both ends of the gradient

var startColor = new RGBColor();

var endColor = new RGBColor();

startColor.red = 0;

startColor.green = 100;

startColor.blue = 255;

endColor.red = 220;

endColor.green = 0;

endColor.blue = 100;

// Create a new gradient

// A new gradient always has 2 stops

var newGradient = app.activeDocument.gradients.add();

newGradient.name = "NewGradient";

newGradient.type = GradientType.LINEAR;

// Modify the first gradient stop

newGradient.gradientStops[0].rampPoint = 30;

newGradient.gradientStops[0].midPoint = 60;

newGradient.gradientStops[0].color = startColor;

Property Value type What it is

gradientStops GradientStops Read-only. The gradient stops contained in this gradient.

name string The gradient’s name.

parent Document Read-only. The document that contains this gradient.

type GradientType The kind of the gradient, either radial or linear.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

remove

()

Nothing Removes the referenced object from the document.

CHAPTER 1: JavaScript Object Reference Gradient 66

// Modify the last gradient stop

newGradient.gradientStops[1].rampPoint = 80;

newGradient.gradientStops[1].color = endColor;

// construct an Illustrator.GradientColor object referring to the

// newly created gradient

var colorOfGradient = new GradientColor();

colorOfGradient.gradient = newGradient;

// get first path item, apply new gradient as its fill

var topPath = app.activeDocument.pathItems[0];

topPath.filled = true;

topPath.fillColor = colorOfGradient;

}

CHAPTER 1: JavaScript Object Reference GradientColor 67

GradientColor

A gradient color specification in a Gradient object. A script can create a new gradient color using a

reference to an existing gradient in the document. If no existing gradient object is referenced, a default

gradient is supplied.

GradientColor properties

Changing a gradient stop color

// Creates a new RGB document, then changes the color

// of the first gradient stop of an indexed gradient

app.documents.add(DocumentColorSpace.RGB);

// Get a reference to the gradient that you want to change

var gradientRef = app.activeDocument.gradients[1];

// Create the new color

var startColor = new RGBColor();

startColor.red = 255;

startColor.green = 238;

startColor.blue = 98;

// apply new color to the first gradient stop

gradientRef.gradientStops[0].color = startColor;

Property Value type What it is

angle number (double) The gradient vector angle in degrees. Default: 0.0

gradient Gradient Reference to the object defining the gradient.

hiliteAngle number (double) The gradient highlight vector angle in degrees.

hiliteLength number (double) The gradient highlight vector length.

length number (double) The gradient vector length.

matrix Matrix An additional transformation matrix to manipulate the

gradient path.

origin array of 2 numbers The gradient vector origin, the center point of the gradient in

this color.

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference Gradients 68

Gradients

A collection of Gradient objects in a document.

Gradients properties

Gradients methods

Removing a gradient

// Deletes the first gradient from the current document

if ( app.documents.length > 0 ) {

app.activeDocument.gradients[0].remove();

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

Gradient Creates a new Gradient object.

getByName

(name) string

Gradient Gets the first element in the collection with the

specified name.

index

(itemKey) string, number

Gradient Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference GradientStop 69

GradientStop

A gradient stop definition that represents a point on a specific gradient defined in the document. Each

gradient stop specifies a color change in the containing gradient. See Changing a gradient stop color for

an example.

GradientStop properties

GradientStop methods

Property Value type What it is

color Color The color linked to this gradient stop.

midPoint number (double) The midpoint key value, specified as a percentage from 13.0 to

87.0.

opacity number (double) The opacity value for the gradient stop. Range: 0.0 to100.0

parent Gradient Read-only. The gradient that contains this gradient stop.

rampPoint number (double) The location of the color in the blend in a range from 0.0 to 100.0,

where 100.0 is 100%.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

remove

()

Nothing Deletes this object.

CHAPTER 1: JavaScript Object Reference GradientStops 70

GradientStops

A collection of GradientStop objects in a specific gradient. The elements are not named; you must access

them by index.

GradientStops properties

GradientStops methods

Adding a new gradient stop

// Adds a new gradient stop to a gradient, color of new stop is 70% gray

if ( app.documents.length > 0 && app.activeDocument.gradients.length > 0 ) {

// Get a reference to the gradient to change

var changeGradient = app.activeDocument.gradients[0];

// Get a reference to the last gradient stop

var origCount = changeGradient.gradientStops.length;

var lastStop = changeGradient.gradientStops[origCount-1];

// add the new gradient stop

var newStop = changeGradient.gradientStops.add();

// Set the values of the new gradient stop.

// Move the original last gradient stop a bit to the left and

// insert the new gradient stop at the old position

newStop.rampPoint = lastStop.rampPoint;

lastStop.rampPoint = lastStop.rampPoint - 10;

// Create a new color to apply to the newly created gradient stop

// --a Gray tint value of 70%

var newStopColor = new GrayColor();

newStopColor.gray = 70.0;

newStop.color = newStopColor;

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

GradientStop Creates a new object.

getByName

(name) string

GradientStop Gets the first element in the collection

with the specified name.

index

(itemKey) number

GradientStop Gets an element from the collection.

removeAll

()

Nothing Deletes all objects in this collection.

CHAPTER 1: JavaScript Object Reference GradientStops 71

}

CHAPTER 1: JavaScript Object Reference GraphicStyle 72

GraphicStyle

A graphic style. Each graphic style defines a set of appearance attributes that you can apply

non-destructively to page items. Graphic styles are contained in documents. Scripts cannot create new

graphic styles.

GraphicStyle properties

GraphicStyle methods

Applying a graphic style

// Duplicates each path item in the selection, places the duplicate into a

// new group, then applies a graphic style to the new groups items

if ( app.documents.length > 0 ) {

var doc = app.activeDocument;

var selected = doc.selection;

var newGroup = doc.groupItems.add();

newGroup.name = "NewGroup";

newGroup.move( doc, ElementPlacement.PLACEATEND );

var endIndex = selected.length;

for ( i = 0; i < endIndex; i++ ) {

if ( selected[i].typename == "PathItem" )

selected[i].duplicate( newGroup, ElementPlacement.PLACEATEND );

}

for ( i = 0; i < newGroup.pageItems.length; i++ ) {

doc.graphicStyles[1].applyTo( newGroup.pageItems[i] );

}

Property Value type What it is

name string The graphic style name.

parent Document Read-only. The document that contains this graphic style.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

applyTo

(artItem) PageItem

Nothing Applies this art style to a specified art item.

mergeTo

(artItem) PageItem

Nothing Merges this art style into the current styles of a specified

art item.

remove

()

Nothing Deletes this object.

CHAPTER 1: JavaScript Object Reference GraphicStyles 73

GraphicStyles

A collection of GraphicStyle objects in a document.

GraphicStyles properties

GraphicStyles methods

Counting graphics styles

//Counts the number of graphic styles in the active document

// and stores result in numberOfStyles

if ( app.documents.length > 0 ) {

var numberOfStyles = app.activeDocument.graphicStyles.length;

}

Property Value type What it is

length number Read-only. The number of graphic styles in the document.

parent object Read-only. The document that contains this graphic styles collection.

typename string Read-only. The class name of the referenced object.

Method Parameter type: Returns What it does

getByName

(name) string

GroupItem Gets the first element in the collection with the

specified name.

index

(itemKey) string, number

GroupItem Gets an element from the collection.

removeAll

()

Nothing Removes all elements in the referenced collection.

CHAPTER 1: JavaScript Object Reference GraphItem 74

GraphItem

Any graph artwork object. See example Rotating graph items below.

GraphItem properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so, what

kind of knockout. You cannot set this value to

KnockoutState.Unknown

blendingMode BlendModes The mode used when compositing an object.

contentVariable Variable The content variable bound to the graph item.

It is not necessary to set the type of the

contentVariable before binding. Illustrator

automatically set the type to GRAPH.

controlBounds array of 4 numbers Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this graph item is editable.

geometricBounds array of 4 numbers Read-only. The bounds of the object excluding stroke

width.

height number (double) The height of the graph item.

hidden boolean If true, this graph item is hidden.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this graph item belongs.

left number The offset (in points) of the left side of the graph item

from the left side of the page.

locked boolean If true, this graph item is locked.

name string The name of this graph item.

note string The note assigned to this item.

opacity number(double) The opacity of the object; the value is between 0.0

and 100.0.

parent Layer or

GroupItem

Read-only. The parent of this object.

position array of 2 numbers The position (in points) of the top left corner of the

graphItem object in the format [x, y]. Does not

include stroke weight.

selected boolean If true, this object is selected.

sliced boolean If true, the graph item is sliced. Default: false

CHAPTER 1: JavaScript Object Reference GraphItem 75

GraphItem methods

tags Tags Read-only. The tags contained in this graph item.

top number (double) The offset (in points) of the top of the graph item from

the bottom of the page.

typename string Read-only. The type of the graph item.

uRL string The value of the Adobe URL tag assigned to this graph

item.

visibilityVariable Variable The visibility variable bound to the graph item.

It is not necessary to set the type of the

visibilityVariable before binding. Illustrator

automatically set the type to VISIBILITY.

visibleBounds array of 4 numbers Read-only. The visible bounds of the graph item

including stroke width.

width number (double) The width of the graph item. Range: 0.0 to 16348.0

wrapInside boolean If true, the text frame object should be wrapped

inside this object.

wrapOffset number (double) The offset to use when wrapping text around this

object.

wrapped boolean If true, wrap text frame objects around this object.

(Text frame must be above the object.)

zOrderPosition number (long) Read-only. The position of this art item within the

stacking order of the group or layer (parent) that

contains the art item.

Property Value type What it is

Method Parameter type Returns What it does

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

GraphItem Creates a duplicate of the

selected object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

GraphItem Moves the object.

remove

()

Nothing Deletes this object.

CHAPTER 1: JavaScript Object Reference GraphItem 76

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item where

scaleX is the horizontal

scaling factor and scaleY is

the vertical scaling factor.

100.0 = 100%.

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item relative

to the current rotation. The

object is rotated

counter-clockwise if the

angle value is positive,

clockwise if the value is

negative.

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art item by

applying a transformation

matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art item

relative to the current

position, where deltaX is the

horizontal offset and deltaY

is the vertical offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the stacking order

of the group or layer (parent)

of this object.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference GraphItems 77

GraphItems

A collection GraphItems objects, which gives you access to all the graph art items in an Illustrator

document.

GraphItems properties

GraphItems methods

Rotating graph items

// Rotates each graph item in the current document 90 degrees.

// Verify a document with a graph item is open

var ok = false;

if (documents.length > 0) {

var docRef = activeDocument

var iCount = docRef.graphItems.length

if( iCount > 0) {

ok = true;

for (var i=0; i<iCount; i++) {

var graphRef = docRef.graphItems[i];

graphRef.selected = true;

graphRef.rotate(90); //rotate clockwise 90 degrees

}

redraw();

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

getByName

(name) string

GraphItems Gets the first element in the collection with the

specified name.

index

(itemKey) string, number

GraphItems Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in the collection.

CHAPTER 1: JavaScript Object Reference GrayColor 78

GrayColor

A grayscale color specification, used where a color object is required.

GrayColor properties

Changing a color to gray

// Sets the color of the first word in the active document

// to a shade of gray

if ( app.documents.length > 0

&& app.activeDocument.textFrames.length > 0 ) {

var text = app.activeDocument.textFrames[0].textRange;

var firstWord = text.words[0];

// Create the new color

var textColor = new GrayColor();

textColor.gray = 45;

firstWord.filled = true;

firstWord.fillColor = textColor;

}

Property Value type What it is

gray number (double) The tint of the gray. Range: 0.0 to 100.0, where 0.0 is black and 100.0

is white.

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference GroupItem 79

GroupItem

A grouped set of art items. Group items can contain all of the same page items that a layer can contain,

including other nested groups.

Paths contained in a group or compound path in a document are returned as individual paths when a

script asks for the paths contained in the document. However, paths contained in a group or compound

path are not returned when a script asks for the paths in a layer which contains the group or compound

path.

GroupItem properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so,

what kind of knockout.

blendingMode BlendModes The blend mode used when compositing an object.

clipped boolean If true, the group is clipped to the clipping mask.

compoundPathItems CompoundPathItems Read-only. The compound path items contained in

this group.

controlBounds array of 4 numbers Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this item is editable.

geometricBounds array of 4 numbers Read-only. The bounds of the object excluding stroke

width.

graphItems GraphItems Read-only. The graph items contained in this group.

groupItems GroupItems Read-only. The group items contained in this group.

height number (double) The height of the group item.

hidden boolean If true, this group item is hidden.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this group item

belongs.

left number (double) The position of the left side of the item (in points,

measured from the left side of the page).

legacyTextItems LegacyTextItems Read-only. The legacy text items in the group.

locked boolean If true, this group item is locked.

meshItems MeshItems Read-only. The mesh items contained in this group.

name string The name of this group item.

nonNativeItems NonNativeItems Read-only. The non-native art items in this group.

CHAPTER 1: JavaScript Object Reference GroupItem 80

note string The note assigned to this item.

opacity number (double) The opacity of the object. Range: 0.0 to 100.0

pageItems PageItems Read-only. The page items (all art item classes)

contained in this group.

parent Layer or GroupItem Read-only. The parent of this object.

pathItems PathItems Read-only. The path items contained in this group.

placedItems PlacedItems Read-only. The placed items contained in this group.

pluginItems PluginItems Read-only. The plug-in items contained in this group.

position array of 2 numbers The position (in points) of the top left corner of the

groupItem object in the format [x, y]. Does not

include stroke weight.

rasterItems RasterItems Read-only. The raster items contained in this group.

selected boolean If true, this group item is selected.

sliced boolean If true, the item sliced. Default: false

symbolItems SymbolItems Read-only. The symbol item objects in this group.

tags Tags Read-only. The tags contained in this group.

textFrames TextFrameItems Read-only. The text art items contained in this group.

top number (double) The position of the top of the item (in points,

measured from the bottom of the page).

typename string Read-only. The class name of the referenced object.

uRL string The value of the Adobe URL tag assigned to this

group item.

visibilityVariable Variable The visibility variable bound to the item.

visibleBounds array of 4 numbers Read-only. The visible bounds of the group item

including stroke width.

width number (double) The width of the group item.

wrapInside boolean If true, the text frame object should be wrapped

inside this object.

wrapOffset number (double) The offset to use when wrapping text around this

object.

wrapped boolean If true, wrap text frame objects around this object

(text frame must be above the object).

zOrderPosition number (long) Read-only. The position of this group object within

the stacking order of the group or layer (parent) that

contains the group object.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference GroupItem 81

GroupItem methods

Method Parameter type Returns What it does

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

GroupItem Creates a duplicate of the

selected object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

GroupItem Moves the object.

remove

()

Nothing Deletes this object.

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item where

scaleX is the horizontal

scaling factor and scaleY

is the vertical scaling factor.

100.0 = 100%.

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item relative

to the current rotation. The

object is rotated

counter-clockwise if the

angle value is positive,

clockwise if the value is

negative.

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art item by

applying a transformation

matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art item

relative to the current

position, where deltaX is

the horizontal offset and

deltaY is the vertical

offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the stacking

order of the group or layer

(parent) of this object.

CHAPTER 1: JavaScript Object Reference GroupItem 82

Modifying all objects in a group

It is easy to modify all of the objects contained in a group. This example demonstrates how to simplify your

operations on multiple objects by creating group to contain them.

// Creates a new group item, adds a new path item, of triangle shape, to the group, then

// adds a new text item to the group and sets the fill color of the text to red

if ( app.documents.length > 0 ) {

var triangleGroup = app.activeDocument.groupItems.add();

// Create a triangle and add text, the new art is created inside the group

var trianglePath = triangleGroup.pathItems.add();

trianglePath.setEntirePath( Array( Array(100, 100), Array(300, 100),

Array(200, Math.tan(1.0471975) * 100 + 100) ) );

trianglePath.closed = true;

trianglePath.stroked = true;

trianglePath.filled = false;

trianglePath.strokeWidth = 3;

var captionText = triangleGroup.textFrames.add();

captionText.position = Array(100, 150);

captionText.textRange.size = 48;

captionText.contents = "A triangle";

var fillColor = new RGBColor;

fillColor.red = 255;

fillColor.green = 0;

fillColor.blue = 0;

captionText.characters.fillColor = fillColor;

}

CHAPTER 1: JavaScript Object Reference GroupItems 83

GroupItems

The collection of grouped art items in a document.

GroupItems properties

GroupItems methods

Importing a PDF as a group item

The following script shows how you can import a PDF document using the createFromFile function.

Before running this script you must create a one page PDF file and put it in the location

/temp/testfile1.pdf.

// Embeds a new group item in to the current

// document from a file specified by dest

// dest should contain the full path and file name

function embedPDF(dest) {

var embedDoc = new File(dest);

if ( app.documents.length > 0 && embedDoc.exists ) {

var doc = app.activeDocument;

var placed = doc.groupItems.createFromFile( embedDoc );

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

GroupItem Creates a new object.

createFromFile

(imageFile) File

GroupItem Places an external vector art file as a group

item in the document.

getByName

(name) string

GroupItem Gets the first element in the collection with

the specified name.

index

(itemKey) string, number

GroupItem Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference IllustratorSaveOptions 84

IllustratorSaveOptions

Options for saving a document as an Illustrator file, used with the saveAs method. All properties are

optional.

IllustratorSaveOptions properties

Property Value type What it is

artboardRange string If saveMultipleArtboards is true (which is valid

only for Illustrator 13 or earlier), the document is

considered for multi-asset extraction, which specifies

an artboard range. An empty string extracts all

artboards. Default: empty string

compatibility Compatibility Specifies the version of Illustrator file format to create.

Default: Compatibility.ILLUSTRATOR19

compressed boolean (Illustrator version 10 or later.) If true, the saved file is

compressed. Default: true

embedICCProfile boolean (Illustrator version 9 or later.) If true, the document’s

ICC profile is embedded in the saved file.

Default: false

embedLinkedFiles boolean (Illustrator version 7 or later.) If true, the linked image

files is embedded in the saved file. Default: false

flattenOutput OutputFlattening (Versions before Illustrator 9.) How transparency

should be flattened for older file format versions.

Default: OutputFlattening.PRESERVEAPPEARANCE

fontSubsetThreshold number (double) (Illustrator version 9 or later.) Include a subset of fonts

when less than this percentage of characters is used in

the document. Range: 0.0 to 100.0. Default: 100.0

pdfCompatible boolean (Illustrator version 10 or later.) If true, the file is saved

as a PDF compatible file. Default: true

saveMultipleArtboards boolean If true, all artboards or range of the artboards are

saved. Valid for Illustrator 13 or earlier.

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference IllustratorSaveOptions 85

Saving with options

// Saves the current document to dest as an AI file with specified options,

// dest specifies the full path and file name of the new file

function exportFileToAI (dest) {

if ( app.documents.length > 0 ) {

var saveOptions = new IllustratorSaveOptions();

var ai8Doc = new File(dest);

saveOptions.compatibility = Compatibility.ILLUSTRATOR8;

saveOptions.flattenOutput = OutputFlattening.PRESERVEAPPEARANCE;

app.activeDocument.saveAs( ai8Doc, saveOptions );

}

CHAPTER 1: JavaScript Object Reference ImageCaptureOptions 86

ImageCaptureOptions

Options for image capture, used with the imageCapture method. All properties are optional.

ImageCaptureOptions properties

Property Value type What it is

antiAliasing boolean If true, the image result is anti-aliased. Default: false

matte boolean If true, the artboard is matted with a color. Default: false

matteColor RGBColor The color to use for the artboard matte. Default: white

resolution number (double) The resolution of the captured image file in points-per-inch

(PPI), in the range [72.0 ... 2400.0]. Default: 150

transparency boolean If true, the image result is transparent. Default: false

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference Ink 87

Ink

Associates a document ink name with ink information.

Ink properties

Property Value type What it is

inkInfo InkInfo The ink information

name string The ink’s name

typename string Read-only. The class name of the object

CHAPTER 1: JavaScript Object Reference InkInfo 88

InkInfo

Ink information for printing a document.

InkInfo properties

Getting ink information

// Displays the current documents inks in a text frame

var docRef = documents.add();

var textRef = docRef.textFrames.add();

// assemble a string of the inks in this document

var sInks = "";

var iLength = activeDocument.inkList.length;

for(var i=0; i<iLength; i++) {

sInks += docRef.inkList[i].name;

sInks += "\r\t";

sInks += "Frequency = " + docRef.inkList[i].inkInfo.frequency;

sInks += "\r\t";

sInks += "Density = " + docRef.inkList[i].inkInfo.density;

sInks += "\r";

}

textRef.contents = sInks;

textRef.top = 600;

textRef.left = 200;

redraw();

Property Value type What it is

angle number (double) The ink’s screen angle in degrees. Range: -360 to 360

customColor Color The color of the custom ink.

density number (double) The neutral density. Minimum: 0.0

dotShape string The dot shape name.

frequency number (double) The ink’s frequency. Range: 0.0 to 1000.0

kind InkType The ink type.

printingStatus InkPrintStatus The ink printing status.

trapping TrappingType The trapping type.

trappingOrder number (long) The order of trapping for the ink. Range: 1 to 4 for CMYK

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference InsertionPoint 89

InsertionPoint

A location between characters that is used to insert new text objects. An insertion point is contained in an

InsertionPoints collection.

InsertionPoint properties

Property Value type What it is

characters Characters Read-only. All the characters in this text range.

lines Lines Read-only. All the lines in this text range.

paragraphs Paragraphs Read-only. All the paragraphs in this text range.

parent TextRange Read-only. The object’s container.

story Story Read-only. The story to which the text range

belongs.

textRanges TextRanges Read-only. All of the text in this text range.

typename string Read-only. The class name o f the object.

words Words Read-only. All the words contained in this text

range.

CHAPTER 1: JavaScript Object Reference InsertionPoints 90

InsertionPoints

A collection of InsertionPoint objects.

InsertionPoints properties

InsertionPoints methods

Using insertion points to add spaces

// Creates a new document, adds text then inserts a

// space between each character using insertion points

var docRef = documents.add();

var textRef = docRef.textFrames.add();

textRef.contents = "Wouldn't you rather be scripting?";

textRef.top = 400;

textRef.left = 100;

textRef.textRange.characterAttributes.size = 20;

redraw();

// Add a space between each character using insertion points.

var ip;

for(var i=0; i<(textRef.insertionPoints.length); i+=2) {

ip = textRef.insertionPoints[i];

ip.characters.add(" ");

}

Property Value type What it is

length number Read-only. Number of elements in the collection.

parent object Read-only. The object’s container.

typename string Read-only. The class name of the object.

Method Parameter type Returns What it does

index

(itemKey) string, number

InsertionPoint Gets an element from the collection.

CHAPTER 1: JavaScript Object Reference LabColor 91

LabColor

A color specification in the CIE Lab color space, used where a color object is required.

LabColor properties

Property Value type What it is

anumber (double) The a (red-green) color value. Range -128.0–128.0. Default: 0.0

bnumber (double) The b (yellow-blue) color value. Range -128.0–128.0. Default: 0.0

lnumber (double) The l (lightness) color value. Range -128.0–128.0. Default: 0.0

CHAPTER 1: JavaScript Object Reference Layer 92

Layer

A layer in an Illustrator document. Layers may contain nested layers, which are called sublayers in the user

interface.

The layer object contains all of the page items in the specific layer as elements. Your script can access

page items as elements of either the Layer object or as elements of the Document object. When accessing

page items as elements of a layer, only objects in that layer can be accessed. To access page items

throughout the entire document, be sure to refer to them as contained by the document.

Layer properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so, what

kind of knockout. You cannot set this value to

KnockoutState.Unknown.

blendingMode BlendModes The mode used when compositing an object.

color RGBColor The layer’s selection mark color.

compoundPathItems CompoundPathItems Read-only. The compound path items contained in this

layer.

dimPlacedImages boolean If true, placed images should be rendered as dimmed in

this layer.

graphItems GraphItems Read-only. The graph items contained in this layer.

groupItems GroupItems Read-only. The group items contained in this layer.

hasSelectedArtwork boolean If true, an object in this layer has been selected; set to

false to deselect all objects in the layer.

isIsolated boolean If true, this object is isolated.

layers Layers Read-only. The layers contained in this layer.

legacyTextItems LegacyTextItems Read-only. The legacy text items in this layer.

locked boolean If true, this layer is editable; set to false to lock the

layer.

meshItems MeshItems Read-only. The mesh items contained in this layer.

name string The name of this layer.

nonNativeItems NonNativeItems The non-native art items in this layer.

opacity number (double) The opacity of the layer. Range: 0.0 to 100.0

pageItems PageItems Read-only. The page items (all art item classes)

contained in this layer.

parent Document or Layer Read-only. The document or layer that contains this

layer.

CHAPTER 1: JavaScript Object Reference Layer 93

Layer methods

pathItems PathItems Read-only. The path items contained in this layer.

placedItems PlacedItems Read-only. The placed items contained in this layer.

pluginItems PluginItems Read-only. The plug-in items contained in this layer.

preview boolean If true, this layer should be displayed using preview

mode.

printable boolean If true, this layer should be printed when printing the

document.

rasterItems RasterItems Read-only. The raster items contained in this layer.

sliced boolean If true, the layer item is sliced. Default: false

symbolItems SymbolItems Read-only. The symbol items contained in the layer.

textFrames TextFrameItems Read-only. The text art items contained in this layer.

typename string Read-only. The class name of the referenced object.

visible boolean If true, this layer is visible.

zOrderPosition number (long) Read-only. The position of this layer within the stacking

order of layers in the document.

Property Value type What it is

Method Parameter type Returns What does it do

move

(relativeObject,

insertionLocation)

object

ElementPlacement

Layer Moves the object.

remove

()

Nothing Deletes this object.

zOrder

(ZOrderCmd) ZOrderMethod

Nothing Arranges the layer’s position in the

stacking order of the containing layer or

document (parent) of this object

CHAPTER 1: JavaScript Object Reference Layer 94

Bringing a layer to the front

// Moves the bottom layer to become the topmost layer

if (documents.length > 0) {

countOfLayers = activeDocument.layers.length;

if (countOfLayers > 1) {

bottomLayer = activeDocument.layers[countOfLayers-1];

bottomLayer.zOrder(ZOrderMethod.BRINGTOFRONT);

}

else {

alert("The active document only has only 1 layer")

}

CHAPTER 1: JavaScript Object Reference Layers 95

Layers

The collection of layers in the document.

Layers properties

Layers methods

Finding and deleting layers

// Deletes all layers whose name begins with "Temp" in all open documents

// loop through all open documents

var layersDeleted = 0;

for ( i = 0; i < app.documents.length; i++ ) {

var targetDocument = app.documents[i];

var layerCount = targetDocument.layers.length;

// Loop through layers from the back, to preserve index

// of remaining layers when we remove one

for (var ii = layerCount - 1; ii >= 0; ii-- ) {

targetLayer = targetDocument.layers[ii];

var layerName = new String( targetLayer.name );

if ( layerName.indexOf("Temp") == 0 ) {

targetDocument.layers[ii].remove();

layersDeleted++;

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

Layer Creates a new layer in the document.

getByName

(name) string

Layer Gets the first element in the collection with the specified

name.

index

(itemKey) string, number

Layer Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference LegacyTextItem 96

LegacyTextItem

A text object created in Illustrator CS (version 10) or earlier, which is uneditable until converted. To convert

legacy text, see convertToNative.

You can view, move, and print legacy text, but you cant edit it. Legacy text has an “x” through its bounding

box when selected.

LegacyTextItem properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so, what

kind of knockout.

blendingMode BlendModes The blend mode used when compositing an object.

controlBounds array of 4 numbers Read-only. The bounds of the object including stroke

width and controls.

converted boolean Read-only. If true, the legacy text item has been

updated to a native text frame item.

editable boolean Read-only. If true, this item is editable.

geometricBounds array of 4 numbers Read-only. The bounds of the object excluding stroke

width.

height number (double) The height of the group item.

hidden boolean If true, this item is hidden.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this item belongs.

left number (double) The position of the left side of the item (in points,

measured from the left side of the page).

locked boolean If true, this item is locked.

name string The name of this item.

note string The note assigned to this item.

opacity number (double) The opacity of the object. Range: 0.0 to 100.0

parent Layer or GroupItem Read-only. The parent of this object.

position array of 2 numbers The position (in points) of the top left corner of the

legacyTextItem object in the format [x, y]. Does not

include stroke weight.

selected boolean If true, this item is selected.

sliced boolean If true, the item sliced. Default: false

tags Tags Read-only. The tags contained in this item.

CHAPTER 1: JavaScript Object Reference LegacyTextItem 97

LegacyTextItem methods

top number (double) The position of the top of the item (in points,

measured from the bottom of the page).

typename string Read-only. The class name of the referenced object.

uRL string The value of the Adobe URL tag assigned to this item.

visibilityVariable Variable The visibility variable bound to the item.

visibleBounds array of 4 numbers Read-only. The visible bounds of the item including

stroke width.

width number (double) The width of the item.

wrapInside boolean If true, the text frame object should be wrapped

inside this object.

wrapOffset number (double) The offset to use when wrapping text around this

object.

wrapped boolean If true, wrap text frame objects around this object

(text frame must be above the object).

zOrderPosition number (long) Read-only. The position of this item within the stacking

order of the group or layer (parent) that contains the

item.

Property Value type What it is

Method Parameter type Returns What it does

convertToNative

()

GroupItem Converts the legacy

text item to a text

frame and deletes the

original legacy text.

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

LegacyTextItem Creates a duplicate of

the selected object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

LegacyTextItem Moves the object.

remove

()

Nothing Deletes this object.

CHAPTER 1: JavaScript Object Reference LegacyTextItem 98

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item

where scaleX is the

horizontal scaling

factor and scaleY is

the vertical scaling

factor. 100.0 = 100%.

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item

relative to the current

rotation. The object is

rotated

counter-clockwise if

the angle value is

positive, clockwise if

the value is negative.

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art

item by applying a

transformation matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art

item relative to the

current position,

where deltaX is the

horizontal offset and

deltaY is the vertical

offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the

stacking order of the

group or layer (parent)

of this object.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference LegacyTextItems 99

LegacyTextItems

A collection of LegacyTextItem objects.

LegacyTextItems properties

LegacyTextItems methods

Property Value type What it is

length number Read-only. Number of elements in the collection.

parent object Read-only. The object’s container.

typename string Read-only. The class name of the object.

Method Parameter type Returns What it does

convertToNative

()

boolean Creates text frames from all legacy text

items; the original legacy text items are

deleted. Returns true on success.

getByName

(name) string

LegacyTextItem Get the first element in the collection

with the specified name.

index

(itemKey) string, number

LegacyTextItem Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference Lines 100

Lines

A collection of TextRange objects representing lines of text in a text frame. The elements are not named;

you must access them by index.

Lines properties

Lines methods

Property Value type What it is

length number Read-only. Number of elements in the collection.

parent object Read-only. The object’s container.

typename string Read-only. The class name of the object.

Method Parameter type Returns What it does

index

(itemKey) number

TextRange Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference Matrix 101

Matrix

A transformation matrix specification, used to transform the geometry of objects. Use it to specify and

retrieve matrix information from an Illustrator document or from page items in a document.

Matrices are used in conjunction with the transform method and as a property of a number of objects. A

matrix specifies how to transform the geometry of an object. You can generate an original matrix using the

Application object methods getTranslationMatrix, getScaleMatrix, or getRotationMatrix.

A Matrix is a record containing the matrix values, not a reference to a matrix object. The matrix

commands operate on the values of a matrix record. If a command modifies a matrix, a modified matrix

record is returned as the result of the command. The original matrix record passed to the command is not

modified.

Matrix properties

Combining matrices to apply multiple transformations

To apply multiple transformations to objects, it is more efficient to use the matrix suite than to apply the

transformations one at a time. The following script demonstrates how to combine multiple matrices.

// Tranforms all art in a document using translation and rotation matrices,

// moves art half an inch to the right and 1.5 inches up on the page

if ( app.documents.length > 0 ) {

var moveMatrix = app.getTranslationMatrix( 0.5, 1.5 );

// Add a rotation to the translation, 10 degrees counter clockwise

var totalMatrix = concatenateRotationMatrix( moveMatrix, 10 );

// apply the transformation to all art in the document

var doc = app.activeDocument;

for ( i = 0; i < doc.pageItems.length; i++ ) {

doc.pageItems[i].transform( totalMatrix );

}

Property Value type What it is

mValueA number (double) Matrix property a.

mValueB number (double) Matrix property b.

mValueC number (double) Matrix property c.

mValueD number (double) Matrix property d.

mValueTX number (double) Matrix property tx.

mValueTY number (double) Matrix property ty.

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference MeshItem 102

MeshItem

A gradient mesh art item. You cannot create mesh items from a script. However, you can copy an existing

mesh item with the duplicate method, then use the one of the move methods to place the copy at the

proper location.

MeshItem properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so, what

kind of knockout.

blendingMode BlendModes The blend mode used when compositing an object.

controlBounds array of 4 numbers Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this item is editable.

geometricBounds array of 4 numbers Read-only. The bounds of the object excluding stroke

width.

height number (double) The height of the group item.

hidden boolean If true, this item is hidden.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this item belongs.

left number (double) The position of the left side of the item (in points,

measured from the left side of the page).

locked boolean If true, this item is locked.

name string The name of this item.

note string The note assigned to this item.

opacity number (double) The opacity of the object. Range: 0.0 to 100.0

parent Layer or

GroupItem

Read-only. The parent of this object.

position array of 2 numbers The position (in points) of the top left corner of the

meshItem object in the format [x, y]. Does not include

stroke weight.

selected boolean If true, this item is selected.

sliced boolean If true, the item sliced. Default: false

tags Tags Read-only. The tags contained in this item.

top number (double) The position of the top of the item (in points, measured

from the bottom of the page).

CHAPTER 1: JavaScript Object Reference MeshItem 103

MeshItem methods

typename string Read-only. The class name of the referenced object.

uRL string The value of the Adobe URL tag assigned to this item.

visibilityVariable Variable The visibility variable bound to the item.

visibleBounds array of 4 numbers Read-only. The visible bounds of the item including

stroke width.

width number (double) The width of the item.

wrapInside boolean If true, the text frame object should be wrapped inside

this object.

wrapOffset number (double) The offset to use when wrapping text around this object.

wrapped boolean If true, wrap text frame objects around this object (text

frame must be above the object).

zOrderPosition number (long) Read-only. The position of this item within the stacking

order of the group or layer (parent) that contains the

item.

Property Value type What it is

Method Parameter type Returns What it does

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

MeshItem Creates a duplicate of the

selected object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

MeshItem Moves the object.

remove

()

Nothing Deletes this object.

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item where

scaleX is the horizontal

scaling factor and scaleY is

the vertical scaling factor.

100.0 = 100%.

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item relative

to the current rotation. The

object is rotated

counter-clockwise if the

angle value is positive,

clockwise if the value is

negative.

CHAPTER 1: JavaScript Object Reference MeshItem 104

Finding and locking mesh items

// Locks all mesh items in the current document

if ( app.documents.length > 0 ) {

doc = app.activeDocument;

for ( i = 0; i < doc.meshItems.length; i++ ) {

doc.meshItems[i].locked = true;

}

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art item by

applying a transformation

matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art item

relative to the current

position, where deltaX is the

horizontal offset and deltaY

is the vertical offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the stacking order

of the group or layer (parent)

of this object.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference MeshItems 105

MeshItems

A collection of MeshItem objects.

MeshItems properties

MeshItems methods

Copying mesh items to another document

To run this script, have two open documents. One document should contain at least one mesh item, the

other document can be empty. Make the empty document the frontmost before running the script.

// Copies all mesh items from one document to a new document

if ( app.documents.length > 0 ) {

var srcDoc = documents[0];

var locationOffset = 0;

var targetDoc = documents.add();

for ( i = 0; i < srcDoc.meshItems.length; i++) {

srcItem = srcDoc.meshItems[i];

var dupItem = srcDoc.meshItems[i].duplicate( targetDoc,

ElementPlacement.PLACEATEND );

// offset the copied items' position on the y axis

dupItem.position = Array( 100, 50 + locationOffset );

locationOffset += 50;

}

Property Value type What it is

length number Read-only. The number of objects in the collection

parent object Read-only. The parent of this object

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

getByName

(name) string

MeshItem Gets the first element in the collection with the

specified name.

index

(itemKey) string, number

MeshItem Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference NoColor 106

NoColor

Represents the “none” color. Assigning a NoColor object to the fill or stroke color of an art item is

equivalent to setting the filled or stroked property to false.

NoColor properties

Using NoColor to remove a fill color

// Creates 2 overlapping objects with different fill colors.

// Assign the top object a fill color of "NoColor"

// allowing the bottom object to become visible.

// create 2 overlapping objects one blue, one red;

var docRef = documents.add();

var itemRef1 = docRef.pathItems.rectangle(500, 200, 200, 100);

var itemRef2 = docRef.pathItems.rectangle(550, 150, 200, 200);

var rgbColor = new RGBColor();

rgbColor.red = 255;

itemRef2.fillColor = rgbColor;

rgbColor.blue = 255;

rgbColor.red = 0;

itemRef1.fillColor = rgbColor;

redraw();

// create a nocolor and assign it to the top object

var noColor = new NoColor();

itemRef2.fillColor = noColor;

redraw();

Property Value type What it is

typename string Read-only. The class name of the object

CHAPTER 1: JavaScript Object Reference NonNativeItem 107

NonNativeItem

A non-native artwork item.

NonNativeItem properties

These classes inherit all properties from the page item class.

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so, what

kind of knockout.

blendingMode BlendModes The blend mode used when compositing an object.

controlBounds array of 4 numbers Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this item is editable.

geometricBounds array of 4 numbers Read-only. The bounds of the object excluding stroke

width.

height number (double) The height of the group item.

hidden boolean If true, this item is hidden.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this item belongs.

left number (double) The position of the left side of the item (in points,

measured from the left side of the page).

locked boolean If true, this item is locked.

name string The name of this item.

note string The note assigned to this item.

opacity number (double) The opacity of the object. Range: 0.0 to 100.0

parent Document, Layer, or

GroupItem

Read-only. The parent of this object.

position array of 2 numbers The position (in points) of the top left corner of the

NonNativeItem object in the format [x, y]. Does not

include stroke weight.

selected boolean If true, this item is selected.

sliced boolean If true, the item sliced. Default: false

tags Tags Read-only. The tags contained in this item.

top number (double) The position of the top of the item (in points, measured

from the bottom of the page).

CHAPTER 1: JavaScript Object Reference NonNativeItem 108

NonNativeItem methods

typename string Read-only. The class name of the referenced object.

uRL string The value of the Adobe URL tag assigned to this item.

visibilityVariable Variable The visibility variable bound to the item.

visibleBounds array of 4 numbers Read-only. The visible bounds of the item including

stroke width.

width number (double) The width of the item.

wrapInside boolean If true, the non-native-item object should be wrapped

inside this object.

wrapOffset number (double) The offset to use when wrapping text around this

object.

wrapped boolean If true, wrap non-native-item objects around this

object (non-native-item object must be above the

object).

zOrderPosition number Read-only. The position of this item within the stacking

order of the group or layer (parent) that contains the

item.

Property Value type What it is

Method Parameter type Returns What it does

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

NonNativeItem Creates a duplicate of

the selected object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

NonNativeItem Moves the object.

remove

()

Nothing Deletes this object.

removeAll

()

Nothing Deletes all elements in

this collection.

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item

where scaleX is the

horizontal scaling factor

and scaleY is the

vertical scaling factor.

100.0 = 100%.

CHAPTER 1: JavaScript Object Reference NonNativeItem 109

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item

relative to the current

rotation. The object is

rotated

counter-clockwise if the

angle value is positive,

clockwise if the value is

negative.

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art item

by applying a

transformation matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art item

relative to the current

position, where deltaX

is the horizontal offset

and deltaY is the

vertical offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the stacking

order of the group or

layer (parent) of this

object.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference NonNativeItems 110

NonNativeItems

A collection of NonNativeItem objects.

NonNativeItems properties

NonNativeItems methods

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

getByName

(name) string

NonNativeItem,

SymbolItem

Gets the first element in the collection with the

specified name.

CHAPTER 1: JavaScript Object Reference OpenOptions 111

OpenOptions

Options for opening a document, used with the open method.

OpenOptions properties

Automatically updating legacy text on open

// Opens a file with legacy text (AI 10 or older), using

// OpenOptions to automatically update the legacy text.

var fileRef = filePath;

if (fileRef != null) {

var optRef = new OpenOptions();

optRef.updateLegacyText = true;

var docRef = open(fileRef, DocumentColorSpace.RGB, optRef);

}

Property Value type What it is

convertCropAreaToArboard boolean Optional. Convert crop areas to artboards when

opening a legacy document in Illustrator CS4 or later.

When false, crop areas are discarded. Default: true.

convertTilesToArboard boolean Optional. Convert print tiles to artboards when opening

a legacy document in Illustrator CS4 or later. Default:

false.

createArtboardWithArtwor

kBoundingBox

boolean Optional. Create an artboard with the dimensions of the

bounding box of the artwork when opening a legacy

document in Illustrator CS4 or later. Default: false.

openAs LibraryType Optional. Open the file as an Illustrator library of this

type. Default: LibraryType.IllustratorArtwork.

preserveLegacyArtboard boolean Optional. Preserve legacy artboards when opening a

legacy document in Illustrator CS4 or later. Default: true.

updateLegacyGradientMesh boolean If true, preserves the spot colors in the gradient mesh

objects for legacy documents (pre-Illustrator CS4).

Default: true

updateLegacyText boolean Optional. If true, update all legacy text items (from

previous versions of Illustrator). Default: false

CHAPTER 1: JavaScript Object Reference OpenOptionsAutoCAD 112

OpenOptionsAutoCAD

Options for opening an AutoCAD drawing, used with the open method.

OpenOptionsAutoCAD properties

Property Value type What it is

centerArtwork boolean If true, the artwork is centered on the

artboard. Default: true

globalScaleOption AutoCADGlobalScaleOption How to scale the drawing on import. Default:

AutoCADGlobalScaleOption.FitArtboard

globalScalePercent double The value when globalScaleOption is

AutoCADGlobalScaleOption.ScaleByValue

expressed as a percentage. Range: 0.0 to

100.0. Default is 100.0

mergeLayers boolean If true, the layers of the artwork are merged.

Default: false

parent object Read-only. The object’s container.

scaleLineweights boolean If true, line weights are scaled by the same

factor as the rest of the drawing.

Default: false

selectedLayoutName string The name of the layout in the drawing to

import.

typename string Read-only. The class name of the object.

unit AutoCADUnit The unit to map to.

Default: AutoCADUnit.Millimeters

unitScaleRatio double The ratio by which to scale while mapping

units. Default: 1.0

CHAPTER 1: JavaScript Object Reference OpenOptionsFreeHand 113

OpenOptionsFreeHand

Options for opening a FreeHand file.

OpenOptionsFreeHand properties

Property Value type What it is

convertTextToOutlines boolean If true, all text is converted to vector paths; preserves the

visual appearance of type. Default: false

importSinglePage boolean If true, imports only the page specified in the pageToOpen

property. Default: true

pageToOpen long The number of the page to import when opening a

multipage document. Valid only when importSinglePage is

true.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference OpenOptionsPhotoshop 114

OpenOptionsPhotoshop

Options for opening a Photoshop document, used with the open method.

OpenOptionsPhotoshop properties

Property Value type What it is

layerComp string The name of the layer comp to use when the document is

converted.

preserveHiddenLayers boolean If true, preserve hidden layers when the document is

converted. Default: false.

preserveImageMaps boolean If true, preserve image maps when the document is converted.

Default: true.

preserveLayers boolean If true, preserve layers when the document is converted.

Default: true.

preserveSlices boolean If true, preserve slices when the document is converted.

Default: true.

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PageItem 115

PageItem

Any art item. Every art item and group in a document is a page item. You may refer to a page item as an

element of a document, layer, or group item.

The PageItem class gives you complete access to every art item contained in an Illustrator document. The

PageItem class is the superclass of all artwork objects in a document. The CompoundPathItem, GroupItem,

MeshItem, PathItem, PlacedItem, PluginItem, RasterItem, and TextFrame classes each inherit a set of

properties from the PageItem class.

You cannot create a PageItem directly, you must create one of the specific PageItem subclasses, such as

PathItem.

PageItem properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout.

blendingMode BlendModes The mode to use when compositing this object. An object

is considered composited when its opacity is set to less

than 100.0 (100%).

controlBounds rect Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this page item is editable.

geometricBounds rect Read-only. The object’s bounds excluding the stroke

width.

height real The height of the page item, calculated from the

geometric bounds. Range: 0.0 to 16348.0

hidden boolean If true, this page item is hidden.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this page item belongs.

left number (double) The left position of the art item.

locked boolean If true, this page item is locked.

name string The name of this page item.

note string The note assigned to this item.

opacity real The opacity of this object, where 100.0 is completely

opaque and 0.0 is completely transparent.

parent object Read-only. The parent of this object.

pixelAligned boolean True if this item is aligned to the pixel grid.

position point The position (in points) of the top left corner of the item in

the format {x, y}. Does not include stroke weight.

CHAPTER 1: JavaScript Object Reference PageItem 116

PageItem methods

selected boolean If true, this object is selected.

sliced boolean If true, preserve slices.

tags Tags The collection of tags associated with this page item.

top number (double) The top position of the art item.

typename string Read-only. The class name of the object.

URL string The value of the Adobe URL tag assigned to this page item.

visibilityVariable anything The visibility variable to which this page item path is

bound.

visibleBounds rect Read-only. The object’s visible bounds, including stroke

width of any objects in the illustration.

width real The width of the page item, calculated from the geometric

bounds. Range: 0.0 to 16348.0

wrapInside boolean If true, the text frame object should be wrapped inside

this object.

wrapOffset number (double) The offset to use when wrapping text around this object.

wrapped boolean If true, wrap text frame objects around this object (text

frame must be above the object).

zOrderPosition number (long) Read-only. The drawing order of the art within its group or

layer.

Property Value type What it is

Method Parameter type Returns What it does

bringInPerspective

(posX,

posY,

perspectiveGridPlane)

number

PerspectiveGrid

PlaneType

Nothing Places art object(s) in a

perspective grid at a specified

position and grid plane.

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales art object(s).

CHAPTER 1: JavaScript Object Reference PageItem 117

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates art object(s).

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidth]

[,transformAbout])

matrix

boolean

number (double)

Transformation

Nothing Transforms art object(s) using a

transformation matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradents]

[,transformStrokePattern])

number (double)

boolean

Nothing Repositions art object(s).

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art relative to other

art in the group or layer.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference PageItems 118

PageItems

A collection of page item objects. Provides complete access to all the art items in an Illustrator document

in the following classes:

CompoundPathItem

GraphItem

GroupItem

LegacyTextItem

MeshItem

NonNativeItem

PathItem

PlacedItem

PluginItem

RasterItem

SymbolItem

TextFrameItem

You can reference page items through the PageItems property in a Document, Layer, or Group. When you

access an individual item in one of these collections, the reference is a page item of one of a particular

type. For example, if you use PageItems to reference a graph item, the typename value of that object is

GraphItem.

PageItems properties

PageItems methods

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

getByName

(name) string

PageItem Gets the first element in the collection with the

specified name.

index

(itemKey) string, number

PageItem Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference PageItems 119

Getting references to external files in page items

Before running this script, open a document that contains one or more linked images.

// Gets all file-references in the current document using the pageItems object,

// then displays them in a new document

if ( app.documents.length > 0 ) {

var fileReferences = new Array();

var sourceDoc = app.activeDocument;

var sourceName =sourceDoc.name;

for ( i = 0; i < sourceDoc.pageItems.length; i++ ) {

artItem = sourceDoc.pageItems[i];

switch ( artItem.typename ) {

case "PlacedItem":

fileReferences.push( artItem.file.fsName );

break;

case "RasterItem":

if ( ! artItem.embedded ) {

fileReferences.push( artItem.file.fsName );

}

break;

}

// Write the file references to a new document

var reportDoc = documents.add();

var areaTextPath = reportDoc.pathItems.rectangle( reportDoc.height,0,

reportDoc.width, reportDoc.height );

var fileNameText = reportDoc.textFrames.areaText( areaTextPath );

fileNameText.textRange.size = 24;

var paragraphCount = 3;

var text = "File references in \'" + sourceName + "\':\r\r";

for ( i = 0; i < fileReferences.length; i++ ) {

text += ( fileReferences[i] + "\r" );

paragraphCount++;

}

fileNameText.contents = text;

}

CHAPTER 1: JavaScript Object Reference Paper 120

Paper

Associates paper information with a paper name. Paper objects are used by Printer objects.

Paper properties

Property Value type What it is

name string The paper name.

paperInfo PaperInfo The paper information.

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PaperInfo 121

PaperInfo

Paper information for use in printing documents.

PaperInfo properties

Finding paper information

// Displays the papers and paper sizes available for the 2nd printer in a text frame

var docRef = documents.add();

var itemRef = docRef.pathItems.rectangle(600, 300, 200, 100);

var textRef = docRef.textFrames.add();

textRef.top = 600;

textRef.left = 50;

// get paper objects for 2nd printer

var printerRef = printerList[1];

textRef.contents = printerRef.name;

textRef.contents += " paper list:\r";

var paragraphCount = 2;

// get details of each paper

var iCount = printerRef.printerInfo.paperSizes.length;

for( var i=0; i<iCount; i++ ) {

var paperRef = printerRef.printerInfo.paperSizes[i];

var paperInfoRef = paperRef.paperInfo;

textRef.contents += paperRef.name;

textRef.contents += "\t";

textRef.contents += paperInfoRef.height;

textRef.contents += " x ";

textRef.contents += paperInfoRef.width;

textRef.contents += "\r";

paragraphCount++;

}

redraw();

Property Value type What it is

customPaper boolean If true, it is a custom paper.

height number (double) The paper’s height in points.

imageableArea array of 4 numbers The imageable area.

typename string Read-only. The class name of the object.

width number (double) The paper’s width in points.

CHAPTER 1: JavaScript Object Reference ParagraphAttributes 122

ParagraphAttributes

Specifies the properties and attributes of a paragraph contained in a text frame.

Note: Paragraph attributes do not have default values, and are undefined until explicitly set.

ParagraphAttributes properties

Property Value type What it is

autoLeadingAmount number (double) Auto leading amount expressed as a

percentage.

bunriKinshi boolean If true, BunriKinshi is enabled.

burasagariType BurasagariTypeEnum The Burasagari type.

desiredGlyphScaling number (double) Desired glyph scaling, expressed as a

percentage of the default character width.

Range: 50.0 to 200.0. At 100.0, the width of

characters is not changed.

desiredLetterSpacing number (double) Desired letter, spacing expressed as a

percentage of the default kerning or

tracking Range: -100.0 to 500.0. At 0, no

space is added between letters. At 100.0,

an entire space width is added between

letters.

desiredWordSpacing number (double) Desired word spacing, expressed as a

percentage of the default space for the

font. Range: 0.0 to 1000.0; at 100.00. No

space is added between words.

everyLineComposer boolean If true, the Every-line Composer is

enabled. If false, the Single-line

Composer is enabled.

firstLineIndent number (double) First line left indent in points.

hyphenateCapitalizedWords boolean If true, hyphenation is enabled for

capitalized words.

hyphenation boolean If true, hyphenation is enabled for the

paragraph.

hyphenationPreference number (double) Hyphenation preference scale for better

spacing (0) or fewer hyphens (1).

Range: 0.0 to 1.0

CHAPTER 1: JavaScript Object Reference ParagraphAttributes 123

hyphenationZone number (double) The distance (in points) from the right

edge of the paragraph that marks the part

of the line where hyphenation is not

allowed.

NOTE: 0 allows all hyphenation. Valid only

when everyLineComposer is false.

justification Justification Paragraph justification.

kinsoku string The Kinsoku Shori name.

kinsokuOrder KinsokuOrderEnum The preferred Kinsoku order.

kurikaeshiMojiShori boolean If true, KurikaeshiMojiShori is enabled.

leadingType AutoLeadingType Auto leading type.

leftIndent number (double) The left indent of margin in points.

maximumConsecutiveHyphens number (long) Maximum number of consecutive

hyphenated lines.

maximumGlyphScaling number (double) Maximum glyph scaling, expressed as a

percentage of the default character width.

Range: 50.0 to 200.0; at 100.0. The width of

characters is not changed.

NOTE: Valid only for justified paragraphs.

maximumLetterSpacing number (double) Maximum letter spacing, expressed as a

percentage of the default kerning or

tracking Range: -100.0 to 500.0; at 0. No

space is added between letters. At 100.0,

an entire space width is added between

letters.

NOTE: Valid only for justified paragraphs.

maximumWordSpacing number (double) Maximum word spacing, expressed as a

percentage of the default space for the

font. Range: 0.0 to 1000.0; at 100.00. No

space is added between words.

NOTE: Valid only for justified paragraphs.

minimumAfterHyphen number (long) Minimum number of characters after a

hyphen.

minimumBeforeHyphen number (long) Minimum number of characters before a

hyphen.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference ParagraphAttributes 124

minimumGlyphScaling number (double) Minimum glyph scaling, expressed as a

percentage of the default character width.

Range: 50.0 to 200.0. At 100.0, the width of

characters is not changed.

NOTE: Valid only for justified paragraphs.

minimumHyphenatedWordSize number (long) Minimum number of characters for a word

to be hyphenated.

minimumLetterSpacing number (double) Minimum letter spacing, expressed as a

percentage of the default kerning or

tracking Range: -100.0 to 500.0; at 0. No

space is added between letters. At 100.0,

an entire space width is added between

letters.

NOTE: Valid only for justified paragraphs.

minimumWordSpacing number (double) Minimum word spacing, expressed as a

percentage of the default space for the

font. Range: 0.0 to 1000.0; at 100.00. No

space is added between words.

NOTE: Valid only for justified paragraphs.

mojikumi string The Mojikumi name.

parent object Read-only. The object’s container.

rightIndent number (double) Right indent of margin in points.

romanHanging boolean If true, Roman hanging punctuation is

enabled.

singleWordJustification Justification Single word justification.

spaceAfter number (double) Spacing after paragraph in points.

spaceBefore number (double) Spacing before paragraph in points.

tabStops TabStopInfo Tab stop settings.

typename string Read-only. The class name of the object.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference ParagraphAttributes 125

Changing justification in paragraphs

// Creates a new document with 1 text frame and 3 paragraphs

// then gives each paragraph a different justification

var docRef = documents.add();

var pathRef = docRef.pathItems.rectangle(600, 200, 200, 400);

var textRef = docRef.textFrames.areaText(pathRef);

textRef.paragraphs.add("Left justified paragraph.");

textRef.paragraphs.add("Center justified paragraph.");

textRef.paragraphs.add("Right justified paragraph.");

textRef.textRange.characterAttributes.size = 28;

// change the justification of each paragraph

// using the paragraph attributes object

var paraAttr_0 = textRef.paragraphs[0].paragraphAttributes;

paraAttr_0.justification = Justification.RIGHT;

var paraAttr_1 = textRef.paragraphs[1].paragraphAttributes;

paraAttr_1.justification = Justification.CENTER;

var paraAttr_2 = textRef.paragraphs[2].paragraphAttributes;

paraAttr_2.justification = Justification.LEFT;

CHAPTER 1: JavaScript Object Reference Paragraphs 126

Paragraphs

A collection of TextRange objects, with each TextRange representing a paragraph. The elements are not

named; you must access them by index.

Paragraphs properties

Paragraphs methods

Counting paragraphs

// Counts all paragraphs in current doc and stores result in paragraphCount

if ( app.documents.length > 0 ) {

doc = app.activeDocument;

paragraphCount = 0;

for ( i = 0; i < doc.textFrames.length; i++ ) {

paragraphCount += doc.textFrames[i].paragraphs.length;

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

(contents

[,relativeObject]

[,insertionLocation])

string

TextFrameItem

ElementPlacement

TextRange Adds a new paragraph with

specified text contents at the

specified location in the current

document. If location is not

specified, adds the new paragraph

to the containing text frame after

the current text selection or

insertion point.

addBefore

(contents) string

TextRange Adds a new paragraph with

specified text contents before the

current text selection or insertion

point.

index

(itemKey) number

TextRange Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this

collection.

CHAPTER 1: JavaScript Object Reference ParagraphStyle 127

ParagraphStyle

Associates character and paragraph attributes with a style name. The style object can be used to apply

those attributes to the text in a TextFrame object. See Creating and applying a paragraph style below.

ParagraphStyle properties

ParagraphStyle methods

Property Value type What it is

characterAttributes CharacterAttributes Read-only. The character properties for the text

range.

name string The paragraph style’s name.

paragraphAttributes ParagraphAttributes Read-only. The paragraph properties for the text

range.

parent object Read-only. The object’s container.

typename string Read-only. The class name of the object.

Method Parameter type Returns What it does

applyTo

(textItem

[,clearingOverrides])

object

boolean

Nothing Applies this paragraph style to the

specified text item.

remove

()

Nothing Deletes the object.

CHAPTER 1: JavaScript Object Reference ParagraphStyles 128

ParagraphStyles

A collection of ParagraphStyle objects.

ParagraphStyles properties

ParagraphStyles methods

Property Value type What it is

length number Read-only. Number of elements in the collection.

parent object Read-only. The object’s container.

typename string Read-only. The class name of the object.

Method Parameter type Returns What it does

add

(name) string

ParagraphStyle Creates a named paragraph style.

getByName

(name) string

ParagraphStyle Get the first element in the collection with the

provided name.

index

(itemKey) string, number

ParagraphStyle Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in the collection.

CHAPTER 1: JavaScript Object Reference ParagraphStyles 129

Creating and applying a paragraph style

// Creates a new document with 1 text frame and 3 paragraphs

// gives each paragraph a different justification, then creates

// a paragraph style and applies it to all paragraphs

var docRef = documents.add();

var pathRef = docRef.pathItems.rectangle(600, 200, 200, 400);

var textRef = docRef.textFrames.areaText(pathRef);

textRef.paragraphs.add("Left justified paragraph.");

textRef.paragraphs.add("Center justified paragraph.");

textRef.paragraphs.add("Right justified paragraph.");

textRef.textRange.characterAttributes.size = 28;

// change the justification of each paragraph

// using the paragraph attributes object

var paraAttr_0 = textRef.paragraphs[0].paragraphAttributes;

paraAttr_0.justification = Justification.RIGHT;

var paraAttr_1 = textRef.paragraphs[1].paragraphAttributes;

paraAttr_1.justification = Justification.CENTER;

var paraAttr_2 = textRef.paragraphs[2].paragraphAttributes;

paraAttr_2.justification = Justification.LEFT;

// create a new paragraph style

var paraStyle = docRef.paragraphStyles.add("LeftIndent");

// add some paragraph attributes

var paraAttr = paraStyle.paragraphAttributes;

paraAttr.justification = Justification.LEFT;

paraAttr.firstLineIndent = 10;

// apply the style to each item in the document

var iCount = textRef.paragraphs.length;

for(var i=0; i<iCount; i++) {

paraStyle.applyTo(textRef.paragraphs[i], true);

}

redraw();

CHAPTER 1: JavaScript Object Reference PathItem 130

PathItem

Specifies a path item, which contains PathPoint objects that define its geometry. The PathItem class

gives you complete access to paths in Illustrator. The setEntirePath method provides an extremely

efficient way to create paths comprised of straight lines.

PathItem properties

Property Value type What it is

area number (double) Read-only. The area of this path in square points. If

the area is negative, the path is wound

counterclockwise. Self-intersecting paths can

contain sub-areas that cancel each other out, which

makes this value zero even though the path has

apparent area.

artworkKnockout KnockoutState Is this object used to create a knockout, and if so,

what kind of knockout.

blendingMode BlendModes The blend mode used when compositing an object.

clipping boolean If true, this path should be used as a clipping path.

closed boolean If true, this path is closed.

controlBounds array of 4 numbers Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this item is editable.

evenodd boolean If true, the even-odd rule should be used to

determine “insideness.”

fillColor Color The fill color of the path.

filled boolean If true, the path be filled.

fillOverprint boolean If true, the art beneath a filled object should be

overprinted.

geometricBounds array of 4 numbers Read-only. The bounds of the object excluding

stroke width.

guides boolean If true, this path is a guide object.

height number (double) The height of the group item.

hidden boolean If true, this item is hidden.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this item belongs.

left number (double) The position of the left side of the item (in points,

measured from the left side of the page).

CHAPTER 1: JavaScript Object Reference PathItem 131

length number (double) The length of this path in points.

locked boolean If true, this item is locked.

name string The name of this item.

note string The note text assigned to the path.

opacity number (double) The opacity of the object. Range: 0.0 to 100.0

parent Layer or GroupItem Read-only. The parent of this object.

pathPoints PathPoints Read-only. The path points contained in this path

item.

pixelAligned boolean True if this item is aligned to the pixel grid.

polarity PolarityValues The polarity of the path.

position array of 2 numbers The position (in points) of the top left corner of the

pathItem object in the format [x, y]. Does not

include stroke weight.

resolution number (double) The resolution of the path in dots per inch (dpi).

selected boolean If true, this item is selected.

selectedPathPoints PathPoints Read-only. All of the selected path points in the path.

sliced boolean If true, the item sliced. Default: false

strokeCap StrokeCap The type of line capping.

strokeColor Color The stroke color for the path.

stroked boolean If true, the path should be stroked.

strokeDashes object Dash lengths. Set to an empty object, {}, for a solid

line.

strokeDashOffset number (double) The default distance into the dash pattern at which

the pattern should be started.

strokeJoin StrokeJoin Type of joints for the path.

strokeMiterLimit number (double) When a default stroke join is set to mitered, this

property specifies when the join will be converted to

beveled (squared-off ) by default. The default miter

limit of 4 means that when the length of the point

reaches four times the stroke weight, the join

switches from a miter join to a bevel join. A value of 1

specifies a bevel join. Range: 1 to 500. Default: 4

strokeOverprint boolean If true, the art beneath a stroked object should be

overprinted.

strokeWidth number (double) The width of the stroke (in points).

Property Value type What it is

CHAPTER 1: JavaScript Object Reference PathItem 132

PathItem methods

tags Tags Read-only. The tags contained in this item.

top number (double) The position of the top of the item (in points,

measured from the bottom of the page).

typename string Read-only. The class name of the referenced object.

uRL string The value of the Adobe URL tag assigned to this

item.

visibilityVariable Variable The visibility variable bound to the item.

visibleBounds array of 4 numbers Read-only. The visible bounds of the item including

stroke width.

width number (double) The width of the item.

wrapInside boolean If true, the text frame object should be wrapped

inside this object.

wrapOffset number (double) The offset to use when wrapping text around this

object.

wrapped boolean If true, wrap text frame objects around this object

(text frame must be above the object).

zOrderPosition number (long) Read-only. The position of this item within the

stacking order of the group or layer (parent) that

contains the item.

Property Value type What it is

Method Parameter type Returns What it does

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

PathItem Creates a duplicate of the

selected object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

PathItem Moves the object.

remove

()

Nothing Deletes this object.

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item where

scaleX is the horizontal

scaling factor and scaleY is

the vertical scaling factor.

100.0 = 100%.

CHAPTER 1: JavaScript Object Reference PathItem 133

Setting colors in a path

// Sets the stroke and fill of a path item to colors of a randomly selected swatch

if ( app.documents.length > 0 && app.activeDocument.pathItems.length > 0 ) {

doc = app.activeDocument;

for (var i = 0; i < doc.pathItems.length; i++ ) {

pathRef = doc.pathItems[i];

pathRef.filled = true;

pathRef.stroked = true;

swatchIndex = Math.round( Math.random() * ( doc.swatches.length - 1 ) );

pathRef.fillColor = doc.swatches[ swatchIndex ].color;

pathRef.strokeColor = doc.swatches[ swatchIndex ].color;

}

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item relative

to the current rotation. The

object is rotated

counter-clockwise if the

angle value is positive,

clockwise if the value is

negative.

setEntirePath

(pathPoints) array of[x, y]

coordinate pairs

Nothing Sets the path using an array

of points specified as [x, y]

coordinate pairs.

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art item by

applying a transformation

matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art item

relative to the current

position, where deltaX is

the horizontal offset and

deltaY is the vertical offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the stacking

order of the group or layer

(parent) of this object.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference PathItem 134

Creating a path from straight lines

This script illustrates the use of the setEntirePath method.

// Creates a new open path consisting of 10 straight lines

if ( app.documents.length > 0 ) {

var lineList = new Array(10);

for ( i = 0; i < lineList.length; i++ ) {

lineList[i] = new Array( i * 10 + 50, ((i - 5) ^ 2) * 5 +50);

}

app.defaultStroked = true;

newPath = app.activeDocument.pathItems.add();

newPath.setEntirePath(lineList);

}

CHAPTER 1: JavaScript Object Reference PathItems 135

PathItems

A collection of PathItem objects. The methods ellipse, polygon, rectangle, roundedRectangle, and

star allow you to create complex path items using straightforward parameters. If you do not provide any

parameters when calling these methods, default values are used.

PathItems properties

PathItems methods

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

PathItem Creates a new object.

ellipse

([top]

[,left]

[,width]

[,height]

[,reversed]

[,inscribed])

number (double)

boolean

PathItem Creates a new pathItem in the shape of

an ellipse using the supplied parameters.

Defaults: top: 100 pt.; left: 100 pt.;

width: 50 pt.; height: 100 pt.;

reversed:false

getByName

(name) string

PathItem Gets the first element in the collection

with the specified name.

index

(itemKey) string, number

PathItem Gets an element from the collection.

polygon

([centerX]

[,centerY]

[,radius]

[,sides]

[,reversed])

number (double)

number (long)

boolean

PathItem Creates a new pathItem in the shape of

an polygon using the supplied

parameters. Defaults: centerX: 200 pt.;

centerY: 300 pt.; radius: 50 pt.;

sides:8; reversed: false

rectangle

(top,

left,

width,

height

[,reversed])

number (double)

boolean

PathItem Creates a new pathItem in the shape of

an polygon using the supplied

parameters.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference PathItems 136

Creating shapes

// Creates 5 shapes in layer 1 of document 1

// and applies a random graphic style to each

var doc = app.documents.add();

var artLayer = doc.layers[0];

app.defaultStroked = true;

app.defaultFilled = true;

var rect = artLayer.pathItems.rectangle( 762.5, 87.5, 425.0, 75.0 );

var rndRect = artLayer.pathItems.roundedRectangle(

637.5, 87.5, 425.0, 75.0, 20.0, 10.0 );

// Create ellipse, 'reversed' is false, 'inscribed' is true

var ellipse = artLayer.pathItems.ellipse(

512.5, 87.5, 425.0, 75.0, false, true );

// Create octagon, and 8-sided polygon

var octagon = artLayer.pathItems.polygon( 300.0, 325.0, 75.0, 8 );

// Create a 4 pointed star

var star = artLayer.pathItems.star( 300.0, 125.0, 100.0, 20.0, 4 );

for ( i = 0; i < artLayer.pathItems.length; i++ ) {

styleIndex = Math.round(

Math.random() * ( doc.graphicStyles.length - 1 ) );

doc.graphicStyles[styleIndex].applyTo( artLayer.pathItems[i] );

}

roundedRectangle

(top,

left,

width,

height

[,horizontalRadius]

[,verticalRadius]

[,reversed])

number (double)

boolean

PathItem Creates a new pathItem in the shape of a

rectangle with rounded corners using

the supplied parameters. Defaults:

horizontalRadius: 15 pt.;

verticalRadius: 20 pt.;

reversed:false

star

([centerX]

[,centerY]

[,radius]

[,innerRadius]

[,points]

[,reversed])

number (double)

number (long)

boolean

PathItem Creates a new path item in the shape of a

star using the supplied parameters.

Defaults: centerX: 200 pt.;

centerY: 300 pt.; radius: 50 pt.;

innerRadius: 20 pt.; points: 5;

reversed: false

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference PathPoint 137

PathPoint

A point on a specific path. Each path point is made up of an anchor point (anchor) and a pair of handles

(leftDirection and rightDirection).

PathPoint properties

PathPoint methods

Property Value type What it is

anchor array of 2 numbers The position of this point’s anchor point.

leftDirection array of 2 numbers The position of this path point’s in control point.

parent PathItem Read-only. The path item that contains this path point.

pointType PointType The type of path point, either a curve or a corner. Any

point can considered a corner point. Setting the type to a

corner forces the left and right direction points to be on a

straight line when the user attempts to modify them in

the user interface.

rightDirection array of 2 numbers The position of this path point’s out control point.

selected PathPointSelection Are points of this path point selected, and if so, which

ones.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

remove

()

Nothing Removes the referenced point from the path.

CHAPTER 1: JavaScript Object Reference PathPoints 138

PathPoints

A collection of PathPoint objects in a specific path. The elements are not named; you must access them

by index.

PathPoints properties

PathPoints methods

Adding a path point to a path

// Appends a new PathPoint to an existing path

// and initializes its anchor and handle points.

if ( app.documents.length > 0 ) {

var doc = app.activeDocument;

var line = doc.pathItems.add();

line.stroked = true;

line.setEntirePath( Array( Array(220, 475), Array(375, 300) ) );

// Append another point to the line

var newPoint = doc.pathItems[0].pathPoints.add();

newPoint.anchor = Array(220, 300);

newPoint.leftDirection = newPoint.anchor;

newPoint.rightDirection = newPoint.anchor;

newPoint.pointType = PointType.CORNER;

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

PathPoint Creates a new PathPoint object.

index

(itemKey) number

PathPoint Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference Pattern 139

Pattern

An Illustrator pattern definition contained in a document. Patterns are shown in the Swatches palette.

Each pattern is referenced by a PatternColor object, which defines the pattern’s appearance.

Pattern properties

Pattern methods

Property Value type What it is

name string The pattern name.

parent Document Read-only. The document that contains this pattern.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

remove

()

Nothing Removes the referenced pattern from the document.

toString

()

string Returns the object type of a referenced object. If the

object has a name, also returns the name.

CHAPTER 1: JavaScript Object Reference PatternColor 140

PatternColor

A pattern color specification. You can create a new pattern color by modifying an existing pattern in the

document. Any modification you make to a pattern affects that pattern in the Palette.

PatternColor objects can be used in any property that takes a color object, such as fillColor or

strokeColor.

PatternColor properties

Property Value type What it is

matrix Matrix Additional transformation arising from manipulating the

path.

pattern Pattern A reference to the pattern object that defines the pattern to

use in this color definition.

reflect boolean If true, the prototype should be reflected before filling.

Default: false

reflectAngle number (double) The axis around which to reflect, in points. Default: 0.0

rotation number (double) The angle in radians to rotate the prototype pattern before

filling. Default: 0.0

scaleFactor array of

2numbers

The fraction to which to scale the prototype pattern before

filling, represented as a point containing horizontal and

vertical scaling percentages.

shearAngle number (double) The angle in radians by which to slant the shear. Default: 0.0

shearAxis number (double) The axis to shear with respect to, in points. Default: 0.0

shiftAngle number (double) The angle in radians to which to translate the unscaled

prototype pattern before filling. Default: 0.0

shiftDistance number (double) The distance in points to which to translate the unscaled

prototype pattern before filling. Default: 0.0

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference PatternColor 141

Modifying and applying pattern colors

// Rotates the color of each pattern in the current document,

// then applies the last pattern to the first path item

if ( app.documents.length > 0 && app.activeDocument.pathItems.length > 0 ) {

doc = app.activeDocument;

swatchIndex = 0;

for ( i = 0; i < doc.swatches.length; i++ ) {

// Get the generic color object of the swatch

currentSwatch = doc.swatches[i];

swatchColor = currentSwatch.color;

// Only operate on patterns

if ( currentSwatch.color.typename == "PatternColor" ) {

// Change a pattern property

currentSwatch.color.rotation = 10;

swatchIndex = i;

}

// Apply the last pattern color swatch to the frontmost path

firstPath = app.activeDocument.pathItems[0];

firstPath.filled = true;

firstPath.fillColor = doc.swatches[swatchIndex].color;

}

CHAPTER 1: JavaScript Object Reference Patterns 142

Patterns

A collection of Pattern objects in a document.

Patterns properties

Patterns methods

Removing a pattern

// Deletes the last pattern from the current document.

if ( app.documents.length > 0 ) {

var lastIndex = app.activeDocument.patterns.length - 1;

var patternToRemove = app.activeDocument.patterns[lastIndex];

var patternName = patternToRemove.name;

patternToRemove.remove();

// Note after removing Illustrator objects, set the variable that

// referenced the removed object to null, since it is now invalid.

patternToRemove = null;

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

Pattern Creates a new object.

getByName

(name) string

Pattern Gets the first element in the collection with the provided

name.

index

(itemKey) string, number

Pattern Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference PDFFileOptions 143

PDFFileOptions

Options for opening a PDF file, used with the open method. All properties are optional.

PDFFileOptions properties

Opening a PDF with options

// Opens a PDF file with specified options

var pdfOptions = app.preferences.PDFFileOptions;

pdfOptions.pDFCropToBox = PDFBoxType.PDFBOUNDINGBOX;

pdfOptions.pageToOpen = 2;

// Open a file using these preferences

var fileRef = filePath;

if (fileRef != null) {

var docRef = open(fileRef, DocumentColorSpace.RGB);

}

Property Value type What it is

pageToOpen number (long) What page should be used when opening a multipage document.

Default: 1

parent object Read-only. The object’s container.

pDFCropToBox PDFBoxType Which box should be used when placing a multipage document.

Default: PDFBoxType.PDFMediaBox

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PDFSaveOptions 144

PDFSaveOptions

Options for saving a document as an Adobe PDF file, used with the saveAs method. All properties are

optional.

PDFSaveOptions properties

Property Value type What it is

acrobatLayers boolean Optional. Create Acrobat®

layers from top-level layers.

Acrobat 6 only. Default:

false

artboardRange string Optional. This is considered

for multi-asset extraction,

which specifies the artboard

range. An empty string

extracts all the artboards.

Default: empty string

bleedLink boolean Optional. Link 4 bleed

values. Default: true

bleedOffsetRect array of 4 numbers The bleed offset rectangle.

colorBars boolean Optional. Draw color bars.

Default: false

colorCompression CompressionQuality Optional. The type of color

bitmap compression used.

Default:

CompressionQuality.

None

colorConversionID ColorConversion Optional. The PDF color

conversion policy. Default:

ColorConversion.None

colorDestinationID ColorDestination Optional. The conversion

target for color conversion.

Default:

ColorDestination.None

colorDownsampling number (double) Optional. The color

downsampling resolution in

dots per inch (dpi). If 0, no

downsampling is

performed. Default: 150.0

colorDownsamplingImageThreshold number (double) Optional. Downsample if the

image’s resolution is above

this value. Default: 225.0

CHAPTER 1: JavaScript Object Reference PDFSaveOptions 145

colorDownsamplingMethod DownsampleMethod Optional. How color bitmap

images should be

resampled. Default:

DownsampleMethod.

NODOWNSAMPLE

colorProfileID ColorProfile Optional. The color profile to

include. Default:

ColorProfile.None

colorTileSize number (long) Optional. Tile size when

compressing with

JPEG2000. Default: 256

compatibility PDFCompatibility Optional. The version of the

Acrobat file format to create.

Default:

PDFCompatibility.

Acrobat5

compressArt boolean Optional. If true, the line art

and text should be

compressed.

Default: true

documentPassword string Optional. A password string

to open the document.

Default: no string

enableAccess boolean Optional. If true, enable

accessing 128-bit.

Default: true

enableCopy boolean Optional. If true, enable

copying of text 128-bit.

Default: true

enableCopyAccess boolean Optional. If true, enable

copying and accessing

40-bit. Default: true

enablePlainText boolean Optional. If true, enable

plaintext metadata 128-bit.

Available only for Acrobat 6.

Default: false

flattenerOptions PrintFlattenerOptions Optional. The printing

flattener options.

flattenerPreset stringOptional. Optional. The transparency

flattener preset name.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference PDFSaveOptions 146

fontSubsetThreshold number (double) Optional. Include a subset of

fonts when less than this

percentage of characters is

used in the document. Valid

for Illustrator 9 file format.

Range: 0.0 to 100.0.

Default: 100.0

generateThumbnails boolean Optional. If true, thumbnail

images are generated with

the saved file. Default: true

grayscaleCompression CompressionQuality Optional. Quality of

grayscale bitmap

compression. Default: None

grayscaleDownsampling number (double) Optional. Downsampling

resolution in dots per inch

(dpi). If 0, no downsampling

is performed. Default: 150.0

grayscaleDownsamplingImageThreshold number (double) Optional. Downsample if the

image’s resolution is above

this value. Default: 225.0

grayscaleDownsamplingMethod DownsampleMethod Optional. How grayscale

bitmap images should be

resampled Default:

DownSampleMethod.

NODOWNSAMPLE

grayscaleTileSize number (long) Optional. Tile size when

compressing with

JPEG2000. Default: 256

monochromeCompression MonochromeCompression Optional. Type of

monochrome bitmap

compression used. Default:

MonochromeCompression.

None

monochromeDownsampling number (double) Optional. Downsampling

resolution in dots per inch

(dpi). If 0, no downsampling

is performed. Default: 300

monochromeDownsamplingImageThreshold number (double) Optional. Downsample if the

image’s resolution is above

this value. Default: 450.0

Property Value type What it is

CHAPTER 1: JavaScript Object Reference PDFSaveOptions 147

monochromeDownsamplingMethod DownsampleMethod Optional. How monochrome

bitmap images should be

resampled. Default:

DownSampleMethod.

NODOWNSAMPLE

offset number (double) Optional. Custom offset in

points for using the custom

paper. Default: 0.0

optimization boolean Optional. If true, the PDF

document should be

optimized for fast web

viewing. Default: false

outputCondition string Optional. An optional

comment to add to the PDF

file, describing the intended

printing condition.

Default: not included

outputConditionID string Optional. The name of a

registered printing

condition.

Default: not included

pageInformation boolean Optional. If true, raw page

information. Default: false

pageMarksType PageMarksTypes Optional. The page marks

style. Default:

PageMarksType.Roman

pDFAllowPrinting PDFPrintAllowedEnum Optional. PDF security

printing permission. Default:

PDFPrintAllowedEnum.

PRINT128HIGHRESOLUTION

pDFChangesAllowed PDFChangesAllowedEnum Optional. Security changes

allowed. Default:

PDFChangeAllowedEnum.

CHANGE128ANYCHANGES

pDFPreset string Optional. Name of PDF

preset to use.

pDFXStandard PDFXStandard Optional. The PDF standard

with which this document

complies. Default:

PDFXStandard.PDFXNONE

pDFXStandardDescription string Optional. A description of

the PDF standard from the

selected preset.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference PDFSaveOptions 148

permissionPassword string Optional. A password string

to restrict editing security

settings. Default: no string

preserveEditability boolean Optional. If true, Illustrator

editing capabilities should

be preserved when saving

the document. Default: true

printerResolution number (double) Optional. Flattening printer

resolution. Default: 800.0

registrationMarks boolean Optional. If true, draw

registration marks.

Default: false

requireDocumentPassword boolean Optional. Require a

password to open the

document. Default: false

requirePermissionPassword boolean Optional. Use a password to

restrict editing security

settings. Default: false

trapped boolean Optional. If true, manual

trapping has been prepared

for the document.

Default: false

trimMarks boolean Optional. Draw trim marks.

Default: false

trimMarkWeight PDFTrimMarkWeight Optional. The trim mark

weight. Default:

PDFTrimMarkWeight.

TRIMMARKWEIGHT0125

typename string Optional. Read-only. The

class name of the referenced

object.

viewAfterSaving boolean Optional. View PDF after

saving. Default: false

Property Value type What it is

CHAPTER 1: JavaScript Object Reference PDFSaveOptions 149

Saving to PDF format

// Saves the current document as PDF to dest with specified options

// dest contains the full path and file name to save to

function saveFileToPDF (dest) {

var doc = app.activeDocument;

if ( app.documents.length > 0 ) {

var saveName = new File ( dest );

saveOpts = new PDFSaveOptions();

saveOpts.compatibility = PDFCompatibility.ACROBAT5;

saveOpts.generateThumbnails = true;

saveOpts.preserveEditability = true;

doc.saveAs( saveName, saveOpts );

}

CHAPTER 1: JavaScript Object Reference PhotoshopFileOptions 150

PhotoshopFileOptions

Options for opening a Photoshop file, used with the open method. All properties are optional.

PhotoshopFileOptions properties

Opening a Photoshop file

// Opens a Photoshop file containing layers with

// preferences set to preserve layers

var psdOptions = preferences.photoshopFileOptions;

psdOptions.preserveLayers = true;

psdOptions.pixelAspectRatioCorrection = false;

// open a file using these prefs

var fileRef = File( psdFilePath);

if (fileRef != null) {

var docRef = open(fileRef, DocumentColorSpace.RGB);

}

Property Value type What it is

parent object Read-only. The parent of this object.

pixelAspectRatioCorrection boolean If true, imported images that have a non-square

pixel aspect ratio should be adjusted.

preserveImageMaps boolean If true, image maps should be preserved when

document is converted. Default: true

preserveLayers boolean If true, layers should be preserved when document

is converted. Default: true

preserveSlices boolean If true, slices should be preserved when document

is converted. Default: true

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference PlacedItem 151

PlacedItem

An artwork item placed in a document as a linked file. For example, an artwork object created using the

File > Place command in Illustrator or using the add() method of the placedItems collection object is a

placed item. For information, see “PlacedItems” on page 155.

PlacedItem properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so, what

kind of knockout.

blendingMode BlendModes The blend mode used when compositing an object.

boundingBox array of 4 numbers Read-only. The dimensions of the placed art item

regardless of transformations.

contentVariable Variable The content variable bound to the item.

controlBounds array of 4 numbers Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this item is editable.

file File The file containing the artwork.

geometricBounds array of 4 numbers Read-only. The bounds of the object excluding stroke

width.

height number (double) The height of the group item.

hidden boolean If true, this item is hidden.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this item belongs.

left number (double) The position of the left side of the item (in points,

measured from the left side of the page).

locked boolean If true, this item is locked.

matrix Matrix The transformation matrix of the placed artwork.

name string The name of this item.

note string The note assigned to this item.

opacity number (double) The opacity of the object. Range: 0.0 to 100.0

parent Layer or GroupItem Read-only. The parent of this object.

position array of 2 numbers The position (in points) of the top left corner of the

placedItem object in the format [x, y]. Does not include

stroke weight.

selected boolean If true, this item is selected.

CHAPTER 1: JavaScript Object Reference PlacedItem 152

PlacedItem methods

sliced boolean If true, the item sliced. Default: false

tags Tags Read-only. The tags contained in this item.

top number (double) The position of the top of the item (in points, measured

from the bottom of the page).

typename string Read-only. The class name of the referenced object.

uRL string The value of the Adobe URL tag assigned to this item.

visibilityVariable Variable The visibility variable bound to the item.

visibleBounds array of 4 numbers Read-only. The visible bounds of the item including

stroke width.

width number (double) The width of the item.

wrapInside boolean If true, the text frame object should be wrapped inside

this object.

wrapOffset number (double) The offset to use when wrapping text around this

object.

wrapped boolean If true, wrap text frame objects around this object (text

frame must be above the object).

zOrderPosition number (long) Read-only. The position of this item within the stacking

order of the group or layer (parent) that contains the

item.

Property Value type What it is

Method Parameter type Returns What it does

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

PlacedItem Creates a duplicate of the

selected object.

embed

()

Nothing Embeds this art in the

document. Converts the art

to art item objects as

needed and deletes this

object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

PlacedItem Moves the object.

relink

(linkFile) File object

Nothing Relinks the art object with

the file that defines its

content.

remove

()

Nothing Deletes this object.

CHAPTER 1: JavaScript Object Reference PlacedItem 153

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item where

scaleX is the horizontal

scaling factor and scaleY

is the vertical scaling factor.

100.0 = 100%.

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item relative

to the current rotation. The

object is rotated

counter-clockwise if the

angle value is positive,

clockwise if the value is

negative.

trace

()

PluginItem Converts the raster art for

this object to vector art,

using default options.

Reorders the placed art

into the source art of a

plug-in group, and

converts it into a group of

filled and/or stroked paths

that resemble the original

image.

Creates and returns a

pluginItem object that

references a

tracingObject object.

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art item by

applying a transformation

matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art item

relative to the current

position, where deltaX is

the horizontal offset and

deltaY is the vertical

offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the stacking

order of the group or layer

(parent) of this object.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference PlacedItem 154

Changing the selection state of placed items

// Toggles the selection state of all placed items.

if ( app.documents.length > 0 ) {

for ( i = 0; i < app.activeDocument.placedItems.length; i++ ) {

placedArt = app.activeDocument.placedItems[i];

placedArt.selected = !(placedArt.selected);

}

CHAPTER 1: JavaScript Object Reference PlacedItems 155

PlacedItems

A collection of PlacedItem objects in the document.

PlacedItems properties

PlacedItems methods

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

none PlacedItem Creates a new object. Use to place new art in a

document. Use the file property of the resulting

placedItem object to link the file containing the

artwork. See “PlacedItem” on page 151.

getByName

(name) string

PlacedItem Gets the first element in the collection with the

specified name.

index

(itemKey) string, number

PlacedItem Gets an element from the collection.

removeAll

()

none Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference PluginItem 156

PluginItem

An art item created by an Illustrator plug-in. Scripts can create a plug-in item using PlacedItem.trace or

RasterItem.trace, and can copy existing plug-in items using the duplicate method, but cannot create

PluginItem objects directly.

PluginItem properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so, what

kind of knockout.

blendingMode BlendModes The blend mode used when compositing an object.

controlBounds array of 4 numbers Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this item is editable.

geometricBounds array of 4 numbers Read-only. The bounds of the object excluding stroke

width.

height number (double) The height of the group item.

hidden boolean If true, this item is hidden.

isIsolated boolean If true, this object is isolated.

isTracing boolean If true, this plug-in group represents a vector art item

created by tracing a raster art item. The tracing

property contains the tracing object associated with the

options used to create it.

layer Layer Read-only. The layer to which this item belongs.

left number (double) The position of the left side of the item (in points,

measured from the left side of the page).

locked boolean If true, this item is locked.

name string The name of this item.

note string The note assigned to this item.

opacity number (double) The opacity of the object. Range: 0.0 to 100.0

parent Layer or GroupItem Read-only. The parent of this object.

position array of 2 numbers The position (in points) of the top left corner of the

plugInItem object in the format [x, y]. Does not include

stroke weight.

selected boolean If true, this item is selected.

sliced boolean If true, the item sliced. Default: false

CHAPTER 1: JavaScript Object Reference PluginItem 157

PluginItem methods

tags Tags Read-only. The tags contained in this item.

top number (double) The position of the top of the item (in points, measured

from the bottom of the page).

tracing TracingObject When this plug-in group was created by tracing

(isTracing is true), the tracing object associated with

the options used to create it.

typename string Read-only. The class name of the referenced object.

uRL string The value of the Adobe URL tag assigned to this item.

visibilityVariable Variable The visibility variable bound to the item.

visibleBounds array of 4 numbers Read-only. The visible bounds of the item including

stroke width.

width number (double) The width of the item.

wrapInside boolean If true, the text frame object should be wrapped inside

this object.

wrapOffset number (double) The offset to use when wrapping text around this

object.

wrapped boolean If true, wrap text frame objects around this object (text

frame must be above the object).

zOrderPosition number Read-only. The position of this item within the stacking

order of the group or layer (parent) that contains the

item.

Property Value type What it is

Method Parameter type Returns What it does

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

PluginItem Creates a duplicate of

the selected object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

PluginItem Moves the object.

remove

()

Nothing Deletes this object.

CHAPTER 1: JavaScript Object Reference PluginItem 158

Copying a plug-in item

// Creates new plug-in art by copying an existing plug-in art item

if ( app.documents.length > 0 && app.activeDocument.pluginItems.length > 0 ) {

doc = app.activeDocument;

pluginArt = doc.pluginItems[0];

pluginArt.duplicate( pluginArt.parent,

ElementPlacement.PLACEATBEGINNING );

}

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item

where scaleX is the

horizontal scaling factor

and scaleY is the

vertical scaling factor.

100.0 = 100%.

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item

relative to the current

rotation. The object is

rotated

counter-clockwise if the

angle value is positive,

clockwise if the value is

negative.

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art item

by applying a

transformation matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art item

relative to the current

position, where deltaX

is the horizontal offset

and deltaY is the

vertical offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the stacking

order of the group or

layer (parent) of this

object.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference PluginItems 159

PluginItems

A collection of PluginItem objects in a document. See Copying a plug-in item.

PluginItems properties

PluginItems methods

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

getByName

(name) string

PluginItem Gets the first element in the collection

with the specified name.

index

(itemKey) string, number

PluginItem Gets an element from the collection.

removeAll

()

Nothing Deletes all objects in this collection.

CHAPTER 1: JavaScript Object Reference PPDFile 160

PPDFile

Associates file information with a PostScript Printer Description (PPD) file.

PPDFile properties

Property Value type What it is

name string The PPD model name.

PPDInfo PPDFileInfo The PPD file information.

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PPDFileInfo 161

PPDFileInfo

Information about a PostScript Printer Description (PPD) file.

PPDFileInfo properties

Displaying PPD file properties

// Displays postscript level and path for each PPD file found in a new text frame

var sPPD = "";

var docRef = documents.add();

var x = 30;

var y = (docRef.height - 30);

var iLength = PPDFileList.length;

if (iLength > 20)

iLength = 20;

for(var i=0; i<iLength; i++) {

var ppdRef = PPDFileList[i];

sPPD = ppdRef.name;

sPPD += "\r\tPS Level ";

var ppdInfoRef = ppdRef.PPDInfo;

sPPD += ppdInfoRef.languageLevel;

sPPD += "\r\tPath: ";

sPPD += ppdInfoRef.PPDFilePath;

var textRef = docRef.textFrames.add();

textRef.textRange.characterAttributes.size = 8;

textRef.contents = sPPD;

textRef.top = (y);

textRef.left = x;

redraw();

if( (y-=(textRef.height)) <= 30 ) {

y = (docRef.height - 30);

x += 150;

}

Property Value type What it is

languageLevel string The PostScript language level.

PPDFilePath File Path specification for the PPD file.

screenList array of Screen List of color separation screens.

screenSpotFunctionList array of

ScreenSpotFunction

List of color separation screen spot functions.

CHAPTER 1: JavaScript Object Reference PPDFileInfo 162

PPDFileInfo and related screen information

// Displays in a new text frame, the postscript level, file paths, screens, and

// screen spot information for first 10 PPD files found

var sPPD = "";

var docRef = documents.add();

var x = 30;

var y = (docRef.height - 30);

var iLength = PPDFileList.length;

if (iLength > 10)

iLength = 10;

for(var i=0; i<iLength; i++) {

var ppdRef = PPDFileList[i];

sPPD = ppdRef.name;

sPPD += "\r\tPS Level ";

var ppdInfoRef = ppdRef.PPDInfo;

sPPD += ppdInfoRef.languageLevel;

sPPD += "\r\tPath: ";

sPPD += ppdInfoRef.PPDFilePath;

sPPD += "\r\tScreens:\r";

var iScreens = ppdInfoRef.screenList.length;

for(var c=0; c<iScreens; c++) {

var screenRef = ppdInfoRef.screenList[c];

sPPD += "\t\t";

sPPD += screenRef.name;

var screenInfoRef = screenRef.screenInfo;

sPPD += ", Angle = ";

sPPD += screenInfoRef.angle;

sPPD += ", Frequency = ";

sPPD += screenInfoRef.frequency;

sPPD += "\r";

}

sPPD += "\r\tScreenSpots:\r";

var iScreenSpots = ppdInfoRef.screenSpotFunctionList.length;

for(var n=0; n<iScreenSpots; n++) {

var screenSpotRef = ppdInfoRef.screenSpotFunctionList[n];

sPPD += "\t\t";

sPPD += screenSpotRef.name;

sPPD += ", spotFunction: ";

sPPD += screenSpotRef.spotFunction;

sPPD += "\r";

}

var textRef = docRef.textFrames.add();

textRef.textRange.characterAttributes.size = 8;

textRef.contents = sPPD;

textRef.top = (y);

textRef.left = x;

redraw();

y-=(textRef.height);

}

CHAPTER 1: JavaScript Object Reference Preferences 163

Preferences

Specifies the preferred options for AutoCAD, FreeHand, PDF, and Photoshop files.

Preferences properties

Preferences methods

Property Value type What it is

AutoCADFileOptions OpenOptionsAutoCAD Read-only. Options to use when opening or

placing an AutoCAD file.

FreeHandFileOptions OpenOptionsFreeHand Read-only. Options to use when opening or

placing a FreeHand file.

parent object Read-only. The parent of this object.

PDFFileOptions PDFFileOptions Read-only. Options to use when opening or

placing a PDF file.

PhotoshopFileOptions PhotoshopFileOptions Read-only. Options to use when opening or

placing a Photoshop file.

typename string Read-only. The class name of the referenced

object.

Method Parameter type Returns What it does

getBooleanPreference

(key) string

boolean Gets the boolean value of a given

application preference.

getIntegerPreference

(key) string

integer Gets the integer value of a given

application preference.

getRealPreference

(key) string

double Gets the real-number value of a given

application preference.

getStringPreference

(key) string

string Gets the string value of a given

application preference.

removePreference

(key) string

Nothing Deletes a given application preference.

setBooleanPreference

(key,

value)

string

boolean

Nothing Sets the boolean value of a given

application preference.

setIntegerPreference

(key,

value)

string

integer

Nothing Sets the integer value of a given

application preference.

CHAPTER 1: JavaScript Object Reference Preferences 164

setRealPreference

(key,

value)

string

double

Nothing Sets the real-number value of a given

application preference.

setStringPreference

(key,

value)

string

Nothing Sets the string value of a given

application preference.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference PrintColorManagementOptions 165

PrintColorManagementOptions

Information used for color management of the document.

PrintColorManagementOptions properties

Managing colors for printing

// Creates a new document, adds symbols, then creates a

// PrintColorManagementOptions object and assigns it

// to a PrintOptions object, then prints with each color intent

// Add some symbol items to a new document

var docRef = documents.add();

var y = docRef.height - 30;

for(var i=0; i<(docRef.symbols.length); i++) {

symbolRef = docRef.symbols[i];

symbolItemRef1 = docRef.symbolItems.add(symbolRef);

symbolItemRef1.top = y;

symbolItemRef1.left = 100;

y -= (symbolItemRef1.height + 10);

}

redraw();

var colorOptions = new PrintColorManagementOptions();

var options = new PrintOptions();

options.colorManagementOptions = colorOptions;

colorOptions.name = "ColorMatch RGB";

// Print the current document once for each color intent.

colorOptions.intent = PrintColorIntent.ABSOLUTECOLORIMETRIC;

docRef.print(options);

colorOptions.intent = PrintColorIntent.PERCEPTUALINTENT;

docRef.print(options);

colorOptions.intent = PrintColorIntent.RELATIVECOLORIMETRIC;

docRef.print(options);

colorOptions.intent = PrintColorIntent.SATURATIONINTENT;

docRef.print(options);

Property Value type What it is

colorProfileMode PrintColorProfile The color management profile mode.

Default: PrintColorProfile.SOURCEPROFILE

intent PrintColorIntent The color management intent type.

Default: PrintColorIntent.RELATIVECOLORIMETRIC

name string The color management profile name.

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PrintColorSeparationOptions 166

PrintColorSeparationOptions

Information about the color separations to be used in printing the document.

PrintColorSeparationOptions properties

Managing color separations for printing

// Creates a new document with symbol items

// and prints document with each separation option

// Add some symbol items to a new document

var docRef = documents.add();

var y = docRef.height - 30;

for(var i=0; i<(docRef.symbols.length); i++) {

symbolRef = docRef.symbols[i];

symbolItemRef1 = docRef.symbolItems.add(symbolRef);

symbolItemRef1.top = y;

symbolItemRef1.left = 100;

y -= (symbolItemRef1.height + 10);

}

// Print with various separation options

var sepOptions = new PrintColorSeparationOptions();

var options = new PrintOptions();

options.colorSeparationOptions = sepOptions;

sepOptions.convertSpotColors = true;

sepOptions.overPrintBlack = true;

sepOptions.colorSeparationMode = PrintColorSeparationMode.COMPOSITE;

docRef.print(options);

sepOptions.colorSeparationMode = PrintColorSeparationMode.INRIPSEPARATION;

docRef.print(options);

sepOptions.convertSpotColors = false;

sepOptions.overPrintBlack = false;

sepOptions.colorSeparationMode = PrintColorSeparationMode.HOSTBASEDSEPARATION;

docRef.print(options);

Property Value type What it is

colorSeparationMode PrintColorSeparationMode The color separation type. Default:

PrintColorSeparationMode.COMPOSITE

convertSpotColors boolean If true, all spot colors should be converted

to process colors. Default: false

inkList array of Ink The list of inks for color separation.

overPrintBlack boolean If true, overprint in black. Default: false

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PrintCoordinateOptions 167

PrintCoordinateOptions

Information about the media and associated printing parameters.

PrintCoordinateOptions properties

Managing print coordinates

???// Creates a new document with symbol items that extend

// off the page then print with each print orientation

var docRef = documents.add();

var y = 500;

var x = -70

if(docRef.symbols.length > 0){

for(var i=0; i<5; i++) {

symbolRef = docRef.symbols[0];

symbolItemRef1 = docRef.symbolItems.add(symbolRef);

symbolItemRef1.top = y;

symbolItemRef1.left = x;

x += 30;

}

redraw();

// Print it with various Coordinate Options

var coordinateOptions = new PrintCoordinateOptions();

var options = new PrintOptions();

options.coordinateOptions = coordinateOptions;

coordinateOptions.emulsion = true; // reverse from right to left

coordinateOptions.fitToPage = true; // fit artwork to page size

coordinateOptions.orientation = PrintOrientation.LANDSCAPE;

Property Value type What it is

emulsion boolean If true, flip artwork horizontally. Default: false

fitToPage boolean If true, proportionally scale the artwork to fit on media.

Default: false

horizontalScale number (double) The horizontal scaling factor expressed as a percentage

(100 = 100%). Range: 1.0 to 10000.0. Default: 100.0

orientation PrintOrientation The artwork orientation.

Default: PrintOrientation.PORTRAIT

position PrintPosition The artwork position on media.

Default: PrintPosition.TRANSLATECENTER

tiling PrintTiling The page tiling mode.

Default: PrintTiling.TILESINGLEFULLPAGE

typename string Read-only. The class name of the object.

verticalScale number (double) The vertical scaling factor expressed as a percentage

(100 = 100%) Range: 1.0 to 10000.0. Default: 100.0

CHAPTER 1: JavaScript Object Reference PrintCoordinateOptions 168

docRef.print(options);

coordinateOptions.emulsion = false;

coordinateOptions.fitToPage = false;

coordinateOptions.orientation = PrintOrientation.PORTRAIT;

coordinateOptions.horizontalScale = 50;

coordinateOptions.verticalScale = 50;

docRef.print(options);

}

CHAPTER 1: JavaScript Object Reference Printer 169

Printer

Associates an available printer with printer information. To request a list of printers, you must first have a

document open or an error is returned.

Printer properties

Property Value type What it is

name string The printer name.

printerInfo PrinterInfo The printer information.

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PrinterInfo 170

PrinterInfo

Configuration information about a printer.

PrinterInfo properties

Property Value type What it is

binaryPrintingSupport boolean If true, the printer supports

binary printing.

colorSupport PrinterColorMode The printer color capability.

customPaperSupport boolean If true, the printer supports

custom paper size.

customPaperTransverseSupport boolean If true, the printer supports

custom paper transverse.

deviceResolution number (double) The printer default resolution.

inRIPSeparationSupport boolean If true, the printer supports

InRIP color separation.

maxDeviceResolution number (double) The printer maximum device

resolution.

maxPaperHeight number (double) Custom paper’s maximum

height.

maxPaperHeightOffset number (double) Custom paper’s maximum

height offset.

maxPaperWidth number (double) Custom paper’s maximum

width.

maxPaperWidthOffset number (double) Custom paper’s maximum

width offset.

minPaperHeight number (double) Custom paper’s minimum

height.

minPaperHeightOffset number (double) Custom paper’s minimum

height offset.

minPaperWidth number (double) Custom paper’s minimum

width.

minPaperWidthOffset number (double) Custom paper’s minimum

width offset.

paperSizes array of Paper The list of supported paper

sizes.

postScriptLevel PrinterPostScriptLevelEnum The PostScript Language level.

CHAPTER 1: JavaScript Object Reference PrinterInfo 171

Finding available printers

// Displays a list of available printers in a new text frame

var docRef = documents.add();

var textRef = docRef.textFrames.add();

var iCount = printerList.length;

textRef.contents += "Printers...\r";

for( var i=0; i<iCount; i++ ) {

textRef.contents += printerList[i].name;

textRef.contents += "\r\t";

}

textRef.top = 600;

textRef.left = 200;

redraw();

printerType PrinterTypeEnum The printer type.

typename string Read-only. The class name of

the object.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference PrintFlattenerOptions 172

PrintFlattenerOptions

Contains flattening options for use when Illustrator outputs artwork that contains transparency into a

non-native format.

PrintFlattenerOptions properties

Property Value type What it is

clipComplexRegions boolean If true, complex regions should be clipped.

Default: false

convertStrokesToOutlines boolean If true, convert all strokes to outlines.

Default: false

convertTextToOutlines boolean If true, all text is converted to vector paths;

preserves the visual appearance of type.

Default: false

flatteningBalance number (long) The flattening balance. Range: 0.0 to 100.0.

Default: 100.0

gradientResolution number (double) The gradient resolution in dots per inch (dpi).

Range: 1.0 to 9600.0. Default: 300.0

overprint PDFOverprint Whether to preserve, discard, or simulate

overprinting.

Default: PDFOverprint.PRESERVEPDFOVERPRINT

rasterizationResolution number (double) The rasterization resolution in dots per inch (dpi).

Range: 1.0 to 9600.0. Default: 300.0

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PrintFlattenerOptions 173

Setting print flattening

// Creates a new document, adds symbols to the document

// then prints with a range of flattener balance settings

var docRef = documents.add();

var y = docRef.height - 30;

for(var i=0; i<(docRef.symbols.length); i++) {

symbolRef = docRef.symbols[i];

symbolItemRef1 = docRef.symbolItems.add(symbolRef);

symbolItemRef1.top = y;

symbolItemRef1.left = 100;

y -= (symbolItemRef1.height + 10);

}

redraw();

// Create PrintFlattenerOptions object and assign to a PrintOptions object

var flatOpts = new PrintFlattenerOptions();

var printOpts = new PrintOptions();

printOpts.flattenerOptions = flatOpts;

// Set other print options

printOpts.ClipComplexRegions = true;

printOpts.GradientResoultion = 360;

printOpts.RasterizatonResotion = 360;

// Print the current document with flattening balance increments of 20

var i;

for(i=0; i<=100; i+=20) {

flatOpts.flatteningBalance = i;

activeDocument.print(printOpts);

}

CHAPTER 1: JavaScript Object Reference PrintFontOptions 174

PrintFontOptions

Contains information about font downloading and substitution for the fonts used for printing the

document.

PrintFontOptions properties

Printing with font options

// Creates a new document, adds text then prints with specified font options.

var docRef = documents.add();

var pathRef = docRef.pathItems.rectangle(500,300,400,400);

var textRef = docRef.textFrames.areaText(pathRef);

textRef.contents = "Text example";

//Create PrintFontOptions object and assign to a PrintOptions object

var fontOpts = new PrintFontOptions();

var printOpts = new PrintOptions();

printOpts.fontOptions = fontOpts;

//Set some font options

fontOpts.downloadFonts = PrintFontDownloadMode.DOWNLOADNONE;

fontOpts.fontSubstitution = FontSubstitutionPolicy.SUBSTITUTEDEVICE;

// print it

activeDocument.print(printOpts);

Property Value type What it is

downloadFonts PrintFontDownloadMode The font download mode. Default:

PrintFontDownloadMode.DOWNLOADSUBSET

fontSubstitution FontSubstitutionPolicy The font substitution policy. Default:

FontSubstitutionPolicy.SUBSTITUTEOBLIQUE

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PrintJobOptions 175

PrintJobOptions

Contains information about how the job is to be printed.

PrintJobOptions properties

Property Value type What it is

artboardRange string The artboard range to be printed if

printAllArtboards is false. Default: 1-

bitmapResolution number (double) The bitmap resolution. Minimum: 0.0.

Default: 0.0

collate boolean If true, collate print pages. Default: false

copies number (long) The number of copies to print. Minimum: 1.

Default: 1

designation PrintArtworkDesignation The layers/objects to be printed.

Default: PrintArtworkDesignation.

VISIBLEPRINTABLELAYERS

file File The file to which to print.

name string The print job name.

printAllArtboards boolean Indicates whether to print all artboards.

Default: true

printArea PrintingBounds The printing bounds.

Default: PrintingBounds.ARTBOARDBOUNDS

printAsBitmap boolean If true, print as bitmap. Default: false

reversePages boolean If true, print pages in reverse order.

Default: false

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PrintJobOptions 176

Printing with job options

// Creates a new document with layers containing visible, printable,

// non visible and non printable items then prints with each designation

// to view effects of using different job options

var docRef = documents.add();

var textRef_0 = docRef.layers[0].textFrames.add();

textRef_0.contents = "Visible and Printable";

textRef_0.top = 600;

textRef_0.left = 200;

var layerRef_1 = docRef.layers.add();

var textRef_1 = layerRef_1.textFrames.add();

textRef_1.contents = "Visible and Non-Printable";

textRef_1.top = 500;

textRef_1.left = 250;

layerRef_1.printable = false;

var layerRef_2 = docRef.layers.add();

var textRef_2 = layerRef_2.textFrames.add();

textRef_2.contents = "Non-Visible";

textRef_2.top = 400;

textRef_2.left = 300;

layerRef_2.visible = false;

redraw();

// Print with various job options

var printJobOptions= new PrintJobOptions();

var options = new PrintOptions();

options.jobOptions = printJobOptions;

printJobOptions.designation = PrintArtworkDesignation.ALLLAYERS;

printJobOptions.reverse = true;

docRef.print(options);

printJobOptions.collate = false;

printJobOptions.designation = PrintArtworkDesignation.VISIBLELAYERS;

printJobOptions.reverse = false;

docRef.print(options);

printJobOptions.designation = PrintArtworkDesignation.VISIBLEPRINTABLELAYERS;

var docPath = new File("~/printJobTest1.ps");

printJobOptions.file = docPath;

docRef.print(options);

CHAPTER 1: JavaScript Object Reference PrintOptions 177

PrintOptions

Contains information about all printing options including flattening, color management, coordinates,

fonts, and paper.

PrintOptions properties

Property Value type What it is

colorManagementOptions PrintColorManagementOptions The printing color management

options.

colorSeparationOptions PrintColorSeparationOptions The printing color separation options.

coordinateOptions PrintCoordinateOptions The printing coordinate options.

flattenerOptions PrintFlattenerOptions The printing flattener options.

flattenerPreset string The transparency flattener preset

name.

fontOptions PrintFontOptions The printing font options.

jobOptions PrintJobOptions The printing job options.

pageMarksOptions PrintPageMarksOptions The printing page marks options.

paperOptions PrintPaperOptions The paper options.

postScriptOptions PrintPostScriptOptions The printing PostScript options.

PPDName string The PPD name.

printerName string The printer name.

printPreset string The print style.

CHAPTER 1: JavaScript Object Reference PrintOptions 178

Setting print options

// Creates a new document, adds symbols, specifies a variety of print options,

// assigns each print option to a PrintOptions object,

// then prints with those options

// Create a new document and add some symbol items

var docRef = documents.add();

var y = docRef.height - 30;

for(var i=0; i<(docRef.symbols.length); i++) {

symbolRef = docRef.symbols[i];

symbolItemRef1 = docRef.symbolItems.add(symbolRef);

symbolItemRef1.top = y;

symbolItemRef1.left = 100;

y -= (symbolItemRef1.height + 10);

}

redraw();

// Create multiple options and assign to PrintOptions

var options = new PrintOptions();

var colorOptions = new PrintColorManagementOptions();

colorOptions.name = "ColorMatch RGB";

colorOptions.intent = PrintColorIntent.SATURATIONINTENT;

options.colorManagementOptions = colorOptions;

var printJobOptions= new PrintJobOptions();

printJobOptions.designation = PrintArtworkDesignation.ALLLAYERS;

printJobOptions.reverse = true;

options.jobOptions = printJobOptions;

var coordinateOptions = new PrintCoordinateOptions();

coordinateOptions.fitToPage = true;

options.coordinateOptions = coordinateOptions;

var flatOpts = new PrintFlattenerOptions();

flatOpts .ClipComplexRegions = true;

flatOpts .GradientResoultion = 60;

flatOpts .RasterizatonResotion = 60;

options.flattenerOptions = flatOpts;

// Print with options

docRef.print(options);

CHAPTER 1: JavaScript Object Reference PrintPageMarksOptions 179

PrintPageMarksOptions

The options for printing page marks.

PrintPageMarksOptions properties

Setting page mark printing options

// Creates a PrintPageMarksOptions object, assigns it

// to a PrintOptions object, then prints the current document.

var docRef = activeDocument;

var pageMarkOptions= new PrintPageMarksOptions();

var options = new PrintOptions();

options.pageMarksOptions = pageMarkOptions;

pageMarkOptions.colorBars = true;

pageMarkOptions.pageInfoMarks = true;

pageMarkOptions.registrationMarks = true;

pageMarkOptions.trimMarks = true;

docRef.print(options);

Property Value type What it is

bleedOffsetRect array of 4 numbers The bleed offset rectangle.

colorBars boolean If true, enable printing of color bars. Default: false

marksOffsetRect array of 4 numbers The page marks offset rectangle.

pageInfoMarks boolean If true, page info marks printing is enabled.

Default: false

pageMarksType PageMarksTypes The page marks style. Default: PageMarksType.Roman

registrationMarks boolean If true, registration marks should be printed.

Default: false

trimMarks boolean If true, trim marks should be printed. Default: false

trimMarksWeight number (double) Stroke weight of trim marks. Minimum: 0.0.

Default: 0.125

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference PrintPaperOptions 180

PrintPaperOptions

Information about the paper to be used in the print job.

PrintPaperOptions properties

Setting print paper options

// Creates a new document, adds a path item, applies a graphic style

// then prints with specified paper options

var docRef = documents.add();

var pathRef = docRef.pathItems.rectangle(600, 200, 200, 200);

docRef.graphicStyles[1].applyTo(pathRef);

var paperOpts = new PrintPaperOptions;

var printOpts = new PrintOptions;

printOpts.paperOptions = paperOpts;

var printerCount = printerList.length;

if (printerCount > 0){

// Print with the 1st paper from the 1st printer

for (var i = 0; i < printerList.length; i++)

if (printerList[i].printerInfo.paperSizes.length > 0)

var printerRef = printerList[i];

var paperRef = printerRef.printerInfo.paperSizes[0];

if (printerRef.printerInfo.paperSizes.length > 0){

paperOpts.name = paperRef.name;

printOpts.printerName = printerRef.name;

docRef.print(printOpts);

}

Property Value type What it is

height number (double) The custom height (in points) for using the custom paper.

Default: 0.0

name string The paper’s name.

offset number (double) Custom offset (in points) for using the custom paper. Default: 0.0

transverse boolean If true, transverse the artwork (rotate 90 degrees) on the custom

paper. Default: false

typename string Read-only. The class name of the object.

width number (double) The custom width (in points) for using the custom paper.

Default: 0.0

CHAPTER 1: JavaScript Object Reference PrintPostScriptOptions 181

PrintPostScriptOptions

Options for printing to a PostScript printer.

PrintPostScriptOptions properties

Setting PostScript printing options

// Prints current document with various postscript levels

// Create new postscript options object, assign to print options

var psOpts = new PrintPostScriptOptions();

var printOpts = new PrintOptions();

printOpts.postScriptOptions = psOpts;

// Assign PS level, print

psOpts.postScriptLevel = PrinterPostScriptLevelEnum.PSLEVEL2;

activeDocument.print(printOpts);

psOpts.postScriptLevel = PrinterPostScriptLevelEnum.PSLEVEL3;

activeDocument.print(printOpts);

Property Value type What it is

binaryPrinting boolean If true, printing should be in binary

mode. Default: false

compatibleShading boolean If true, use PostScript

Level 1-compatible gradient and

gradient mesh printing.

Default: false

forceContinuousTone boolean If true, force continuous tone.

Default: false

imageCompression PostScriptImageCompressionType The image compression type. Default:

ostScriptImageCompressionType.

IMAGECOMPRESSIONNONE

negativePrinting boolean If true, print in negative mode.

Default: false

postScriptLevel PrinterPostScriptLevelEnum The PostScript language level.

Default:

PrinterPostScriptLevelEnum.LEVEL2

shadingResolution number (double) The shading resolution. Range: 1.0 to

9600.0 Default: 300.0

typename string Read-only. The class name of the

object.

CHAPTER 1: JavaScript Object Reference RasterEffectOptions 182

RasterEffectOptions

Specifies raster effects settings for the document. All properties are optional.

RasterEffectOptions properties

Property Value type What it is

antiAliasing boolean If true, the image should be antialiased.

Default: false

clippingMask boolean If true, a clipping mask is created for the image.

Default: false

colorModel RasterizationColorModel The color model for the rasterization. Default:

RasterizationColorModel.DEFAULTCOLORMODEL

convertSpotColors boolean If true, all spot colors are converted to process

colors for the image. Default: false

padding number (double) The amount of white space (in points) to be added

around the object during rasterization. Default: .0

resolution number (double) The rasterization resolution in dots per inch (dpi).

Range: 72.0 to 2400.0. Default: 300.0

transparency boolean If true, the image should use transparency.

Default: false

CHAPTER 1: JavaScript Object Reference RasterItem 183

RasterItem

A bitmap art item in a document. A script can create a raster item from an external file, or by copying an

existing raster item with the duplicate method.

RasterItem properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so, what

kind of knockout.

bitsPerChannel number (long) Read-only. The number of bits per channel.

blendingMode BlendModes The blend mode used when compositing an object.

boundingBox array of

4numbers

The dimensions of the placed art item regardless of

transformations.

channels number (long) Read-only. The number of channels.

colorants array of string Read-only. The colorants used in the raster art.

colorizedGrayscale boolean Read-only. If true, the raster art is a colorized grayscale

image.

contentVariable Variable The content variable bound to the item.

controlBounds array of

4numbers

Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this item is editable.

embedded boolean If true, the raster art item is embedded in the illustration.

file File Read-only. The file containing the artwork.

geometricBounds array of

4numbers

Read-only. The bounds of the object excluding stroke

width.

height number (double) The height of the group item.

hidden boolean If true, this item is hidden.

imageColorSpace ImageColorSpace Read-only. The color space of the raster image.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this item belongs.

left number (double) The position of the left side of the item (in points,

measured from the left side of the page).

locked boolean If true, this item is locked.

matrix Matrix The transformation matrix of the placed artwork.

name string The name of this item.

CHAPTER 1: JavaScript Object Reference RasterItem 184

note string The note assigned to this item.

opacity number (double) The opacity of the object. Range: 0.0 to 100.0

overprint boolean If true, the raster art overprints.

parent Layer or

GroupItem

Read-only. The parent of this object.

position array of

2numbers

The position (in points) of the top left corner of the

rasterItem object in the format [x, y]. Does not include

stroke weight.

selected boolean If true, this item is selected.

sliced boolean If true, the item sliced. Default: false

status RasterLinkState Status of the linked image.

tags Tags Read-only. The tags contained in this item.

top number (double) The position of the top of the item (in points, measured

from the bottom of the page).

transparent boolean Read-only. If true, the raster art is transparent.

typename string Read-only. The class name of the referenced object.

uRL string The value of the Adobe URL tag assigned to this item.

visibilityVariable Variable The visibility variable bound to the item.

visibleBounds array of

4numbers

Read-only. The visible bounds of the item including stroke

width.

width number (double) The width of the item.

wrapInside boolean If true, the text frame object should be wrapped inside

this object.

wrapOffset number (double) The offset to use when wrapping text around this object.

wrapped boolean If true, wrap text frame objects around this object (text

frame must be above the object).

zOrderPosition number Read-only. The position of this item within the stacking

order of the group or layer (parent) that contains the

item.

Property Value type What it is

CHAPTER 1: JavaScript Object Reference RasterItem 185

RasterItem methods

Method Parameter type Returns What it does

colorize

(rasterColor)

Color Nothing Colorizes the raster item

with a CMYK or RGB Color.

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

RasterItem Creates a duplicate of the

selected object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

RasterItem Moves the object.

remove

()

Nothing Deletes this object.

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item where

scaleX is the horizontal

scaling factor and scaleY

is the vertical scaling

factor. 100.0 = 100%.

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item

relative to the current

rotation. The object is

rotated counter-clockwise

if the angle value is

positive, clockwise if the

value is negative.

trace

()

PluginItem Converts the raster art for

this object to vector art,

using default options.

Reorders the raster art into

the source art of a plug-in

group, and converts it into

a group of filled and/or

stroked paths that

resemble the original

image.

Creates and returns a

pluginItem object that

references a

tracingObject object.

CHAPTER 1: JavaScript Object Reference RasterItem 186

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art item by

applying a transformation

matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art item

relative to the current

position, where deltaX is

the horizontal offset and

deltaY is the vertical

offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the stacking

order of the group or layer

(parent) of this object.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference RasterItems 187

RasterItems

A collection of RasterItem objects.

RasterItems properties

RasterItems methods

Creating a raster item

// Creates a new raster item in a new document from a raster file

// jpgFilePath contains the full path and file name of a jpg file

function createRasterItem(jpgFilePath) {

var rasterFile = File(jpgFilePath);

var myDoc = app.documents.add();

var myPlacedItem = myDoc.placedItems.add();

myPlacedItem.file = rasterFile;

myPlacedItem.position = Array( 0, myDoc.height );

myPlacedItem.embed();

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

getByName

(name) string

RasterItem Gets the first element in the collection with the

specified name.

index

(itemKey) string, number

RasterItem Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference RasterItems 188

Finding and examining a raster item

// Examines the color space of the first raster item in the document and displays

// result in ESTK console

if ( app.documents.length > 0 && app.activeDocument.rasterItems.length > 0 ) {

var rasterArt = app.activeDocument.rasterItems[0];

switch ( rasterArt.imageColorSpace ) {

case ImageColorSpace.CMYK:

$.writeln("The color space of the first raster item is CMYK");

break;

case ImageColorSpace.RGB:

$.writeln("The color space of the first raster item is RGB");

break;

case ImageColorSpace.GRAYSCALE:

$.writeln("The color space of the first raster item is GRAYSCALE");

break;

}

CHAPTER 1: JavaScript Object Reference RasterizeOptions 189

RasterizeOptions

Specifies options that may be supplied when rasterizing artwork. All properties are optional.

RasterizeOptions properties

Property Value type What it is

antiAliasingMethod AntiAliasingMethod The type of antialiasing method. Default:

AntiAliasingMethod.ARTOPTIMIZED

backgroundBlack boolean If true, the rasterization is done against a

black background (instead of white).

Default: false

clippingMask boolean If true, a clipping mask should be created for

the image. Default: false

colorModel RasterizationColorModel The color model for the rasterization. Default:

RasterizationColorModel.DEFAULTCOLOR

MODEL

convertSpotColors boolean If true, spot colors should be converted to

process colors for the image. Default: false

convertTextToOutlines boolean If true, all text is converted to outlines before

rasterization. Default: false

includeLayers boolean If true, the resulting image incorporates

layer attributes (like opacity and blend

mode). Default: false

padding number (double) The amount of white space (in points) to be

added around the object during

rasterization. Default: .0

resolution number (double) The rasterization resolution in dots per inch

(dpi). Range: 72.0 to 2400.0. Default: 300.0

transparency boolean If true, the image should use transparency.

Default: false

CHAPTER 1: JavaScript Object Reference RGBColor 190

RGBColor

An RGB color specification, used to apply an RGB color to a layer or art item.

If the color space of a document is RGB and you specify the color value for a page item in that document

using CMYK, Illustrator will translate the CMYK color specification into an RGB color specification. The same

thing happens if the document’s color space is CMYK and you specify colors using RGB. Since this

translation can lose information, you should specify colors using the class that matches the document’s

actual color space.

RGBColor properties

Setting an RGB color

// Sets the default fill color in the current document to yellow.

if ( app.documents.length > 0 ) {

// Define the new color

var newRGBColor = new RGBColor();

newRGBColor.red = 255;

newRGBColor.green = 255;

newRGBColor.blue = 0;

app.activeDocument.defaultFillColor = newRGBColor;

}

Property Value type What it is

blue number (double) The blue color value. Range: 0.0 to 255.0

green number (double) The green color value. Range: 0.0 to 255.0

red number (double) The red color value. Range: 0.0 to 255.0

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference Screen 191

Screen

Associates a color separation screen with information to be used for printing.

Screen properties

Property Value type What it is

name string The color separation screen name.

screenInfo ScreenInfo The color separation screen information.

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference ScreenInfo 192

ScreenInfo

Contains information about the angle and frequency of the color separation screen to be used for printing.

ScreenInfo properties

Getting screen information

// Displays in a new text frame, the name, angle and frequency

// of each screen list item

var sInfo = "";

var docRef = documents.add();

if(PPDFileList.length == 0){

var sInfo = "\r\t\tEmpty PPDFileList"

}

else{

var ppdRef = PPDFileList[0];

var ppdInfoRef = ppdRef.PPDInfo;

sInfo += "\r\t\tScreen Objects for 1st PPD File:\r";

sInfo += "\t\t" + ppdRef.name;

var iScreens = ppdInfoRef.screenList.length;

if(iScreens > 0){

for(var c=0; c<iScreens; c++) {

var screenRef = ppdInfoRef.screenList[c];

sInfo += "\r\t\t";

sInfo += screenRef.name;

var screenInfoRef = screenRef.screenInfo;

sInfo += ", Angle = ";

sInfo += screenInfoRef.angle;

sInfo += ", Frequency = ";

sInfo += screenInfoRef.frequency;

sInfo += "\r";

}

else{

sInfo += "\r\t\tEmpty ScreenList";

}

var textRef = docRef.textFrames.add();

textRef.textRange.characterAttributes.size = 12;

textRef.contents = sInfo;

textRef.top = 600;

textRef.left = 30;

redraw();

Property Value type What it is

angle number (double) The screen’s angle in degrees.

defaultScreen boolean If true, it is the default screen.

frequency number (double) The screen’s frequency.

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference ScreenSpotFunction 193

ScreenSpotFunction

Contains information about a color separation screen spot function, including its definition in PostScript

language code.

ScreenSpotFunction properties

Finding screen spot functions

// Displays in a new text frame, the screen spot functions for the 1st PPD file.

var docRef = documents.add();

if(PPDFileList.length == 0){

var sInfo = "\r\t\tEmpty PPDFileList"

}

else{

var ppdRef = PPDFileList[0];

var ppdInfoRef = ppdRef.PPDInfo;

var sInfo = "\r\t\tScreenSpotFunctions for 1st PPD File:\r";

sInfo += "\t\t" + ppdRef.name + "\r";

var iScreenSpots = ppdInfoRef.screenSpotFunctionList.length;

if(iScreenSpots > 0 ){

for(var n=0; n<iScreenSpots; n++) {

var screenSpotRef = ppdInfoRef.screenSpotFunctionList[n];

sInfo += "\t\t";

sInfo += screenSpotRef.name;

sInfo += ", spotFunction: ";

sInfo += screenSpotRef.spotFunction;

sInfo += "\r";

}

else{

sInfo += "\t\tEmpty ScreenSpotFunctionList";

}

var textRef = docRef.textFrames.add();

textRef.textRange.characterAttributes.size = 12;

textRef.contents = sInfo;

textRef.top = 600;

textRef.left = 30;

redraw();

Property Value type What it is

name string The color separation screen spot function name.

spotFunction string The spot function expressed in PostScript commands.

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference Spot 194

Spot

A custom color definition contained in a SpotColor object.

If no properties are specified when creating a spot, default values are provided. However, if specifying the

color, you must use the same color space as the document, either CMYK or RGB. Otherwise, an error

results. The new spot is added to the end of the swatches list in the Swatches palette.

Spot properties

Spot methods

Property Value type What it is

color Color The color information for this spot color.

colorType ColorModel The color model for this custom color.

name string The spot color’s name.

parent Document Read-only. The document that contains this spot color.

spotKind SpotColorKind Read-only. The kind of spot color (RGB, CMYK or LAB). This is the name of

the color kind contained in the spot object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

getInternalColor

()

Color components Gets the internal color of a spot.

remove

()

Nothing Deletes this object.

CHAPTER 1: JavaScript Object Reference Spot 195

Creating a new spot color

// Creates a new spot color in the current document, then applies an 80% tint to the

color

if ( app.documents.length > 0 ){

var doc = app.activeDocument;

// Create the new spot

var newSpot = doc.spots.add();

// Define the new color value

var newColor = new CMYKColor();

newColor.cyan = 35;

newColor.magenta = 0;

newColor.yellow = 50;

newColor.black = 0;

// Define a new SpotColor with an 80% tint

// of the new Spot's color. The spot color can then

// be applied to an art item like any other color.

newSpot.name = "Pea-Green";

newSpot.colorType = ColorModel.SPOT;

newSpot.color = newColor;

var newSpotColor = new SpotColor();

newSpotColor.spot = newSpot;

newSpotColor.tint = 80;

}

CHAPTER 1: JavaScript Object Reference SpotColor 196

SpotColor

Color class used to apply the color value of a spot at a specified tint value. Can be used in any property that

takes a color object.

SpotColor properties

Property Value type What it is

spot Spot A reference to the spot color object that defines the color.

tint number (double) The tint of the color. Range: 0.0 to 100.0

typename string Read-only. The class name of the referenced object.

CHAPTER 1: JavaScript Object Reference Spots 197

Spots

A collection of SpotColor objects in a document.

Spots properties

Spots methods

Removing spot colors

// Deletes all spots colors from the current document

if ( app.documents.length > 0 ) {

var spotCount = app.activeDocument.spots.length;

if (spotCount > 0) {

app.activeDocument.spots.removeAll();

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

Spot Creates a new object.

getByName

(name) string

Spot Gets the first element in the collection with the specified

name.

index

(itemKey) string, number

Spot Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference Spots 198

Creating and applying spot colors

// Defines and applies a new spot color in the current document then applies the color

// the first path item

if ( app.documents.length > 0 && app.activeDocument.pathItems.length > 0 ) {

// Define the new color value

newRGBColor = new RGBColor();

newRGBColor.red = 255;

newRGBColor.green = 0;

newRGBColor.blue = 0;

// Create the new spot

var newSpot = app.activeDocument.spots.add();

// Define the new SpotColor as 80% of the RGB color

newSpot.name = "Scripted Red spot";

newSpot.tint = 80;

newSpot.color = newRGBColor;

// Apply a 50% tint of the new spot color to the frontmost path item.

// Create a spotcolor object, set the tint value,

var newSpotColor = new SpotColor();

newSpotColor.spot = newSpot;

newSpotColor.tint = 50;

// Use the spot color to set the fill color

var frontPath = app.activeDocument.pathItems[0];

frontPath.filled = true;

frontPath.fillColor = newSpotColor;

}

CHAPTER 1: JavaScript Object Reference Story 199

Story

A contiguous block of text as specified by a text range. A story can contain one or more text frames; if there

is more than one, the multiple text frames are linked together to form a single story.

Story properties

Property Value type What it is

characters Characters Read-only. All the characters in this story.

insertionPoints InsertionPoints Read-only. All the insertion points in this story.

length number (long) Read-only. The number of characters in the story.

lines Lines Read-only. All the lines in this story.

paragraphs Paragraphs Read-only. All the paragraphs in this story.

parent object Read-only. The object’s container.

textFrames TextFrameItems Read-only. The text frame items in this story.

textRange TextRange Read-only. The text range of the story.

textRanges TextRanges Read-only. All the text ranges in the story.

textSelection array of TextRange Read-only. The selected text ranges in the story.

typename string Read-only. The class name of the object.

words Words Read-only. All the words in the story.

CHAPTER 1: JavaScript Object Reference Story 200

Threading text frames into stories

// Creates 1 story that flows through 2 text frames and another story that

// is displayed in a 3rd text frame

// Create a new document and add 2 area TextFrames

var docRef = documents.add();

var itemRef1 = docRef.pathItems.rectangle(600, 200, 50, 30);

var textRef1 = docRef.textFrames.areaText(itemRef1);

textRef1.selected = true;

// create 2nd text frame and link it the first

var itemRef2 = docRef.pathItems.rectangle(550, 300, 50, 200);

var textRef2 = docRef.textFrames.areaText(itemRef2, TextOrientation.HORIZONTAL,

textRef1);

textRef2.selected = true;

// Add enough text to the 1st TextFrame to

// cause it to flow to the 2nd TextFrame.

textRef1.contents = "This is two text frames linked together as one story";

redraw();

// Create a 3rd text frame and count the stories

var textRef3 = docRef.textFrames.add();

textRef3.contents = "Each unlinked textFrame adds a new story."

textRef3.top = 650;

textRef3.left = 200;

redraw();

CHAPTER 1: JavaScript Object Reference Stories 201

Stories

A collection of Story objects in a document.

Stories properties

Stories methods

Property Value type What it is

length number Read-only. Number of elements in the collection.

parent object Read-only. The object’s container.

typename string Read-only. The class name of the object.

Method Parameter type Returns What it does

index

(itemKey) string, number

Story Gets an element from the collection.

CHAPTER 1: JavaScript Object Reference Swatch 202

Swatch

A color swatch definition contained in a document. The swatches correspond to the swatch palette in the

Illustrator user interface. A script can create a new swatch. The swatch can hold all types of color data, such

as pattern, gradient, CMYK, RGB, gray, and spot.

Swatch properties

Swatch methods

Modifying a swatch

// Changes the name of the last swatch

if ( app.documents.length > 0 && app.activeDocument.swatches.length > 0 ) {

var lastIndex = app.activeDocument.swatches.length - 1;

var lastSwatch = app.activeDocument.swatches[lastIndex];

lastSwatch.name = "TheLastSwatch";

}

Property Value type What it is

color Color The color information for this swatch.

name string The swatch’s name.

parent Document Read-only. The document that contains this swatch.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

remove

()

Nothing Deletes this object.

CHAPTER 1: JavaScript Object Reference Swatches 203

Swatches

A collection of Swatch objects in a document.

Swatches properties

Swatches methods

Finding and deleting a swatch

// Deletes swatch 4 from the current document

if ( app.documents.length > 0 ) {

if (app.activeDocument.swatches.length > 4)

{

swatchToDelete = app.activeDocument.swatches[3];

swatchToDelete.remove();

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

()

Swatch Creates a new Swatch object.

getByName

(name) string

Swatch Gets the first element in the collection with the specified

name.

getSelected

()

List of

Swatch

Gets selected swatches in the document.

index

(itemKey) string, number

Swatch Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in this collection.

CHAPTER 1: JavaScript Object Reference SwatchGroup 204

SwatchGroup

A group of Swatch objects.

SwatchGroup properties

SwatchGroup methods

Property Value type What it is

name string The name of the swatch group.

parent object Read-only. The object that contains the symbol object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

addSpot

(spot) Spot

Nothing Adds a spot swatch to the swatch group.

addSwatch

(swatch) Swatch

Nothing Adds a swatch to the swatch group.

getAllSwatches

()

List of

Swatch

Gets a list of all swatches in the swatch group.

remove

()

Nothing Deletes this object.

removeAll

()

Nothing Deletes all elements in the collection.

CHAPTER 1: JavaScript Object Reference SwatchGroups 205

SwatchGroups

A collection of SwatchGroup objects.

SwatchGroups properties

SwatchGroups methods

Property Value type What it is

length number Read-only. The number of objects in the collection

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add SwatchGroup Creates a swatch group.

getByName

(name) string

SwatchGroup Gets the first element in the collection with the

specified name.

removeAll

()

Nothing Deletes all elements in the collection.

CHAPTER 1: JavaScript Object Reference Symbol 206

Symbol

An art item that is stored in the Symbols palette, and can be reused one or more times in the document

without duplicating the art data. Symbols are contained in documents. Instances of Symbol in a document

are associated with SymbolItem objects, which store the art object properties.

Symbol properties

Symbol methods

Property Value type What it is

name string The symbol’s name.

parent object Read-only. The object that contains the symbol object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

duplicate

()

Symbol Create a duplicate of this object.

remove

()

Nothing Deletes this object.

CHAPTER 1: JavaScript Object Reference SymbolItem 207

SymbolItem

An art item made reusable by adding it to the Symbols palette. A SymbolItem is linked to the Symbol from

which it was created and changes if you modify the associated Symbol object.

SymbolItem properties

Property Value type What it is

artworkKnockout KnockoutState Is this object used to create a knockout, and if so, what

kind of knockout.

blendingMode BlendModes The blend mode used when compositing an object.

controlBounds array of 4 numbers Read-only. The bounds of the object including stroke

width and controls.

editable boolean Read-only. If true, this item is editable.

geometricBounds array of 4 numbers Read-only. The bounds of the object excluding stroke

width.

height number (double) The height of the group item.

hidden boolean If true, this item is hidden.

isIsolated boolean If true, this object is isolated.

layer Layer Read-only. The layer to which this item belongs.

left number (double) The position of the left side of the item (in points,

measured from the left side of the page).

locked boolean If true, this item is locked.

name string The name of this item.

note string The note assigned to this item.

opacity number (double) The opacity of the object. Range: 0.0 to 100.0

parent Layer or

GroupItem

Read-only. The parent of this object.

position array of 2 numbers The position (in points) of the top left corner of the

symbolItem object in the format [x, y]. Does not

include stroke weight.

selected boolean If true, this item is selected.

sliced boolean If true, the item sliced. Default: false

symbol Symbol The symbol that was used to create this symbolItem.

tags Tags Read-only. The tags contained in this item.

top number (double) The position of the top of the item (in points,

measured from the bottom of the page).

CHAPTER 1: JavaScript Object Reference SymbolItem 208

SymbolItem methods

typename string Read-only. The class name of the referenced object.

uRL string The value of the Adobe URL tag assigned to this item.

visibilityVariable Variable The visibility variable bound to the item.

visibleBounds array of 4 numbers Read-only. The visible bounds of the item including

stroke width.

width number (double) The width of the item.

wrapInside boolean If true, the text frame object should be wrapped

inside this object.

wrapOffset number (double) The offset to use when wrapping text around this

object.

wrapped boolean If true, wrap text frame objects around this object

(text frame must be above the object).

zOrderPosition number Read-only. The position of this item within the stacking

order of the group or layer (parent) that contains the

item.

Property Value type What it is

Method Parameter type Returns What it does

duplicate

([relativeObject]

[,insertionLocation])

object

ElementPlacement

SymbolItem Creates a duplicate of the

selected object.

move

(relativeObject,

insertionLocation)

object

ElementPlacement

SymbolItem Moves the object.

remove

()

Nothing Deletes this object.

resize

(scaleX,

scaleY

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,scaleAbout])

number (double)

boolean

number (double)

Transformation

Nothing Scales the art item where

scaleX is the horizontal

scaling factor and scaleY is

the vertical scaling factor.

100.0 = 100%.

CHAPTER 1: JavaScript Object Reference SymbolItem 209

rotate

(angle

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,rotateAbout])

number (double)

boolean

Transformation

Nothing Rotates the art item relative

to the current rotation. The

object is rotated

counter-clockwise if the

angle value is positive,

clockwise if the value is

negative.

transform

(transformationMatrix

[,changePositions]

[,changeFillPatterns]

[,changeFillGradients]

[,changeStrokePattern]

[,changeLineWidths]

[,transformAbout])

Matrix

boolean

number (double)

Transformation

Nothing Transforms the art item by

applying a transformation

matrix.

translate

([deltaX]

[,deltaY]

[,transformObjects]

[,transformFillPatterns]

[,transformFillGradients]

[,transformStrokePatterns])

number (double)

boolean

Nothing Repositions the art item

relative to the current

position, where deltaX is

the horizontal offset and

deltaY is the vertical offset.

zOrder

(zOrderCmd) ZOrderMethod

Nothing Arranges the art item’s

position in the stacking

order of the group or layer

(parent) of this object.

Method Parameter type Returns What it does

CHAPTER 1: JavaScript Object Reference SymbolItems 210

SymbolItems

A collection of SymbolItem objects in the document.

SymbolItems properties

SymbolItems methods

Creating symbol items

// Creates a new document then adds each of

// the documents symbols to the document

var docRef = documents.add();

var y = 750;

var x = 25;

var iCount = docRef.symbols.length;

for(var i=0; i<iCount; i++) {

symbolRef = docRef.symbols[i];

symbolItemRef1 = docRef.symbolItems.add(symbolRef);

symbolItemRef1.top = y;

symbolItemRef1.left = x;

y-=(symbolItemRef1.height + 20);

if( (y) <= 60 ) {

y = 750;

x+= 190;

}

Property Value type What it is

length number Read-only. The number of objects in the collection.

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

(symbol) Symbol

SymbolItem Creates an instance of the specified symbol.

getByName

(name) string

SymbolItem Gets the first element in the collection with the

specified name.

index

(itemKey) string, number

SymbolItem Gets an element from the collection.

removeAll

()

Nothing Deletes all elements in the collection.

CHAPTER 1: JavaScript Object Reference Symbols 211

Symbols

The collection of Symbol objects in the document.

Symbols properties

Symbols methods

Property Value type What it is

length number Read-only. The number of objects in the collection

parent object Read-only. The parent of this object.

typename string Read-only. The class name of the referenced object.

Method Parameter type Returns What it does

add

(sourceArt,

[registrationPoint])

PageItem

SymbolRegistrationPoint

Symbol Returns a symbol object

created from the source art

item, any of the following:

CompoundPathItems

GroupItems

MeshItems

NonNativeItems

PageItems

PathItems

RasterItems

SymbolItems

TextFrameItems

The default registration

point is

SymbolCenterPoint.

index

(itemKey) string, number

Symbol Gets an element from the

collection.

getByName

(name) string

Symbol Gets the first element in the

collection with the specified

name.

removeAll

()

Nothing Deletes all elements in the

collection.

CHAPTER 1: JavaScript Object Reference Symbols 212

Creating a symbol

// Creates a path item from each graphic style

// then adds each item as a new symbol

var docRef = documents.add();

var y = 750;

var x =25;

var iCount = docRef.graphicStyles.length;

for(var i=0; i<iCount; i++) {

var pathRef = docRef.pathItems.rectangle( y, x, 20, 20 );

docRef.graphicStyles[i].applyTo(pathRef);

// are we at bottom?

if( (y-=60) <= 60 ) {

y = 750; // go back to the top.

x+= 200

}

redraw();

docRef.symbols.add(pathRef);

}

CHAPTER 1: JavaScript Object Reference TabStopInfo 213

TabStopInfo

Information about the alignment, position, and other details for a tab stop in a ParagraphAttributes

object.

TabStopInfo properties

Displaying tab stop information

// Displays tab stop information found in each text frame

// of current document, if any.

docRef = app.activeDocument;

var tabRef;

var sData = "Tab Stops Found \rTabStop Leader\t\tTabStop Position\r";

var textRef = docRef.textFrames;

for( var i=0 ; i < textRef.length; i++ ) {

// Get all paragraphs in the textFrames

paraRef = textRef[i].paragraphs;

for ( p=0 ; p < paraRef.length ; p++ ) {

// Get para attributes for all textRanges in paragraph

attrRef = paraRef[p].paragraphAttributes;

tabRef = attrRef.tabStops;

if ( tabRef.length > 0 ) {

for(var t=0; t<tabRef.length; t++){

sData += "\t" + tabRef[t].leader + "\t\t";

sData += "\t\t" + tabRef[t].position + "\r";

} // end for

} // end if

} // end for

var newTF = docRef.textFrames.add();

newTF.contents = sData;

newTF.top = 400;

newTF.left = 100;

redraw();

Property Value type What it is

alignment TabStopAlignment The alignment of the tab stop. Default: Left

decimalCharacter string The character used for decimal tab stops. Default: .

leader string The leader dot character.

position number (double) The position of the tab stop expressed in points.

Default: 0.0

typename string Read-only. The class name of the object.

CHAPTER 1: JavaScript Object Reference Tag 214

Tag

A label associated with a specific piece of artwork. Tags allows you to assign an unlimited number of

key-value pairs to any page item in a document.

Tag properties

Tag methods

Using tags

// Finds the tags associated with the selected art item,

// show names and values in a separate document

if ( app.documents.length > 0 ) {

doc = app.activeDocument;

if ( doc.selection.length > 0 ) {

for ( i = 0; i < selection.length; i++ ) {

selectedArt = selection[0];

tagList = selectedArt.tags;

if (tagList.length == 0) {

var tempTag = tagList.add();

tempTag.name = "OneWord";

tempTag.value = "anything you want";

}

// Create a document and add a line of text per tag

reportDocument = app.documents.add();

top_offset = 400;

for ( i = 0; i < tagList.length; i++ ) {

tagText = tagList[i].value;

newItem = reportDocument.textFrames.add();

newItem.contents = "Tag: (" + tagList[i].name +

" , " + tagText + ")";

newItem.position = Array(100, top_offset);

newItem.textRange.size = 24;

top_offset = top_offset - 20;

}

Property Value type What it is

name string The tag’s name.

parent object Read-only. The object that contains this tag.

typename string Read-only. The class name of the referenced object.

value string The data stored in this tag.

Method Parameter type Returns What it does

remove

()

Nothing Deletes this object.

CHAPTER 1: JavaScript Object Reference Tag 215

}

CHAPTER 1: JavaScript Object Reference Tags 216
