User_Manual
User Guide
目录
1. Preface ............................................................................................................................................................................. 39
2. Quick Start Guide ............................................................................................................................................................. 40
2.1 Insert SIM card and battery .............................................................................................................................................................. 40
2.2 Insert memory card ......................................................................................................................................................................... 40
2.3 Battery charging ............................................................................................................................................................................. 40
3. Call .................................................................................................................................................................................... 41
3.1 Dialpad .............................................................................................................................................................................................. 41
3.2 Making an overseas call. ....................................................................................................................................................................... 41
3.3 Dialing via Contacts............................................................................................................................................................................. 41
3.4 Calling an extension number ................................................................................................................................................................. 41
3.5 Making an emergency phone ................................................................................................................................................................. 41
3.6 Answer or reject incoming calls ............................................................................................................................................................. 41
3.7 Menu during a call ............................................................................................................................................................................... 42
4. Call Log ............................................................................................................................................................................ 43
5. Contacts ........................................................................................................................................................................... 44
5.1 Browsing contacts ........................................................................................................................................................................... 44
5.2 Quick search .................................................................................................................................................................................. 44
5.3 Creating contacts ............................................................................................................................................................................ 44
6. Message Service .............................................................................................................................................................. 45
6.1 SMS .............................................................................................................................................................................................. 45
6.2 MMS ............................................................................................................................................................................................ 45
7. Browser ............................................................................................................................................................................ 46
7.1 Open ............................................................................................................................................................................................. 46
7.2 Browser ......................................................................................................................................................................................... 46
8. Multimedia ........................................................................................................................................................................ 47
8.1 Audio Player .................................................................................................................................................................................. 47
8.2 Video Player ................................................................................................................................................................................... 47
8.3 Camera .......................................................................................................................................................................................... 47
8.4 FM Radio ...................................................................................................................................................................................... 47
9. Application ....................................................................................................................................................................... 48
9.1 Clock ............................................................................................................................................................................................ 48
9.2 Calendar ........................................................................................................................................................................................ 48
You can create new events prompt appears on the phone to remind. ................................................................................................................. 48
9.3 Calculator ...................................................................................................................................................................................... 48
9.4 Recorder ........................................................................................................................................................................................ 48
9.5 SIM Toolkit .................................................................................................................................................................................... 48
10. Setting .............................................................................................................................................................................. 49
10.1 Dual SIM settings ...................................................................................................................................................................... 49
10.2 Connection Management ............................................................................................................................................................. 49
10.3 Call settings .............................................................................................................................................................................. 49
10.4 Phone profile ............................................................................................................................................................................. 49
10.5 Display ..................................................................................................................................................................................... 49
10.6 Security .................................................................................................................................................................................... 50
11 Maintenance of Mobile Phone .................................................................................................................................................. 51
12Troubleshooting for Simple Troubles ....................................................................................................................................... 40
13 Safety Information ...................................................................................................................................................................... 1
14 FCC Warnings ............................................................................................................................................................................. 5
![](/img.php?id=4018372&img=bg2.png)
Maintenance of Mobile Phone
1. Preface
Thank you for choosing this Spreadtrum Platform Cellphone.
This device will offer you an unprecedented surprise for it can support two GSM cards with double
standby. Meanwhile, this cellphone is equipped with a 3 megapixel HD digital camera, a MP3
music player and a MP4 video player. Enjoy yourself!
Safety
Please go through, and comply with, the following considerations before using this cellphone.
Please take earphone if making or
answering a call while driving or after
you car is parked.
The cellphone may interfere with aircraft
telecommunication. So please turn off or
switch to flight mode during the flight.
Any cellphone may be susceptible to
interference, which could affect
performance.
Please turn off your cellphone near the
medical equipment or in the medical
facility where any cellphone must be out
of service.
Please use the original battery and
accessories in order to have optimal
performance and prevent phone
damage. Please don’t use unmatched
products.
Please turn off your cellphone in the gas
station or near fuel or chemicals to
prevent explosion.
To avoid interference with blasting
work, please turn off the cellphone on
the site or where two-way radio must
be switched off. Please observe the
local rules.
Burning or disposing of cellphone
battery as usual is prohibited, or it may
cause life risk or environmental
pollution. Please dispose of and recycle
it in compliance with the local
environmental regulations.
If your cellphone needs to be
connected with other device, please
read the User Guide of the latter.
Some small components (e.g. memory
card, etc.) shall be out of children’s
reach; otherwise it may be swallowed or
cause other hazards.
Please copy or keep a written copy of
the vital information stored in your
cellphone.
SOS
Ensure the cellphone is turned on and
within the service area. Enter the
emergency number, press the talking key
to tell your location. Please don’t end the
call without permission.
![](/img.php?id=4018372&img=bg3.png)
2. Quick Start Guide
2.1 Insert SIM card and battery
Press turn it off;
Slide the cover downwards and remove it;
Remove the battery. Insert SIM Card 1 (per the mark “SIM1” on the card slot. The contactor shall
face down (note the notch on the SIM card is in line with the slot). Push the SIM card inwards from
the card slot until it absolutely fits the slot. Insert SIM Card 2 in the same manner.
Insert the battery with metallic contact aligned to the cellphone battery contact and replace the
cover.
2.2 Insert memory card
This cellphone supports the T-Flash memory card. After it is inserted, you can browse or copy, etc.
the files stored in the memory card. Also, the memory space of this device can be expanded.
Remove the cover and battery and turn over the cover of the memory card in the direction as
shown thereon;
Let the side of the memory card bearing metallic contact face down, insert the narrower end
into the card slot until absolutely fitted by it, and replace the back cover.
2.3 Battery charging
The cellphone battery may be charged with travel charger.
Insert the battery in the device correctly;
Let the charger arrow towards the screen, insert the charger plug into the interface, and
connect the charger to the standard power supply socket.
After charging is over, cut off the connection between the charger and the standard power
supply socket.
![](/img.php?id=4018372&img=bg4.png)
3. Call
3.1 Dialpad
Press the physical keyboard to enter the dialpad
Press “Call”, escape the SIM card select screen. Select SIM1 to dial with SIM1; select SIM2 to dial with SIM2
Press “IP” button to carry out IP dial;
3.2 Making an overseas call.
Enter the country code (in this case, “+” shall be entered by pressing * twice continuously);
Enter the area code (without “0” prefixed to that as usual) and the phone number;
Press “Call”, escape the SIM card option screen. Select SIM1 to dial with SIM1; select SIM2 to dial with SIM2
3.3 Dialing via Contacts
Enter the Contacts and search for the phone number you need;
Press Record for a long time to select Call in the option menu.
3.4 Calling an extension number
Enter the switchboard number;
Press [Add call] and then input the extension number;
Press “call”, escape the SIM card select screen. Select SIM1 to dial with SIM1; select SIM2 to dial with SIM2
3.5 Making an emergency phone
Enter the emergency phone number;
Press “Call”, escape the SIM card select screen. Select SIM1 to dial with SIM1; select SIM2 to dial with SIM2
3.6 Answer or reject incoming calls
If there is an incoming call, press “Answer” to answer it;
If there is an incoming call, press “Reject” to reject it;
![](/img.php?id=4018372&img=bg5.png)
3.7 Menu during a call
During a call, you can:
Hold: Press [Hold] to hold current call.
Contacts:Enter into the interface of contact list.
Keypad:Enter into the dial interface.
Record: Record the call details, and the document will be kept in the file manager automatically.
Note:
It is illegal to record any call in some countries. So please do so with the speaker’s prior consent.
Mute: Turn off the microphone during the call. In the mute mode, you can hear the speaker but the speaker can’t
hear you.
Hands-free: Start or cancel a handsfree call.
Adjust volume: You can volume the receiver by down key during a call
End a call: Press “Hang up” to end a call.
![](/img.php?id=4018372&img=bg6.png)
4. Call Log
Roll to any number and press the dial button reply the call, and can press [Menu] to select other operations.
Commonly Used Functions:
Press the single record for a long time, and open the option menu.
Call: call again.
Edit number before call: Edit the current number before call
Write message: Send message to the current number.
Add to blacklist:Set the phone number as a rejected call
Add to contacts : Store the number to this phone.
Remove from call log: Remove the current number.
.
![](/img.php?id=4018372&img=bg7.png)
5. Contacts
5.1 Browsing contacts
When this device standby, select [Contacts] and open the namelist.
The contacts are listed in the order of unnamed, special symbol, digit and English letter respectively (for Chinese
names, the English letter corresponding to their pinyin prevails).
5.2 Quick search
When this device stands by, select [Contacts] and open the namelist.
Press the [Arrow keys] to move to the [Search box]. You may search via the physical keyboard
0~9 keys on the lower part of the screen or the keys on the keyboard (vague search is allowed).
5.3 Creating contacts
SIM1: The input is added to SIM1 with only one number stored under a name.
SIM2: The input is added to SIM2 with only one number stored under a name.
Phnone: All records other than in SIM1 and SIM2 are stored in the memory of this device. Can be
added to the group:Famoly、Friends、Business、Classmates.
Note: Name may be empty, but phone number shall not be so for any new record.
On the contacts list interface, press one record for a long time to operate the following functions:
View contact: View the contact.
Call: ring the contact.
Send message: send one message to the contacts.
Delete contat: Delete the person information.
Edit contact: Edit the contact.
Send contact: send the contact in vCard.
![](/img.php?id=4018372&img=bg8.png)
6. Message Service
Message service is actually a network service. This menu works soundly depending on the type of
your SIM card and the service provided by the network operator. Therefore, please check it before
applying such function.
Messaging
Please have the service center number from the network operator before applying this function. The
storage capacity of SIM card depends on its type.
6.1 SMS
This device supports multi-messaging. Five common messages are editable at most with each
containing 268 Chinese characters or 612 English ones.
When this device stands by, open the function menu, select [Message→New Messag] to open the
editing screen and write a message.
6.2 MMS
Short for multi-media service, MMS is just a multi-media message, which supports GIF, JPEG,
WBMP or BMP display.
Select [Message→New Messag] to open the edit screen and edit a message.
![](/img.php?id=4018372&img=bg9.png)
7. Browser
Internet is an application platform integrating wireless communication and Internet technology,
which makes it possible for you to access to rich Internet information source and e-commerce
application etc.
7.1 Open
Input webpage address you are to browse or link to the pre-set or default main page.
The largest free wireless portal website makes it possible for you to have access to global
information without even stepping out of your house.
7.2 Browser
Open the starting page of the brower, users can enter into input URL, search, bookmarks, history and stored pages
through the interfaces.
Current Page:
New window: Open the new page of the brower.
Bookmarks: Open the list of the stored bookmark.
Refresh: Refresh current WAP page.
Send connection: Send this link to a text message
More: Find on page, Select text, Page info, Settings,Exit
![](/img.php?id=4018372&img=bga.png)
8. Multimedia
8.1 Audio Player
The cellphone is able to play music files saved in cellphone and the downloaded music and support
background play of MP3 file.
Background Play of Audio File
In audio player mode, press key to exit the audio player mode and enter background play
mode, at the same time, the idle mode will display name of the playing music.
8.2 Video Player
The video player supports 3gp and mp4 documents.
8.3 Camera
Enter main menu, select [Camera] to enter Capture / record video pre-view mode.
8.4 FM Radio
In idle mode, select [FM Radio]. To listen to broadcasting program, connect your compatible
headset to the radio, and open it. Select the medium volume to listen to music.
![](/img.php?id=4018372&img=bgb.png)
9. Application
9.1 Clock
You can use the Clock app’s Alarms screen to set up one or more wake-up alarms.
9.2 Calendar
You can create new events prompt appears on the phone to remind.
9.3 Calculator
Enter the function list and select [Calculator].
Input the data by physical keyboard and you can choose add, subtract, multiply and divide.
9.4 Recorder
Don’t just think out loud. Use Voice Recorder to quickly capture your thoughts. You can also record
your voice and set it as a ringtone.
9.5 SIM Toolkit
In standby mode, press middle key to enter the function list and select [SIM Toolkit].
Entering the STK sub-menu, you can use the value added service offered by network operator.
This mobile supports STK function but this service is offered by network operator. If your SIM card
and network operator don’t support this service then you cannot use it. Please contact your network
operator for more information.
![](/img.php?id=4018372&img=bgc.png)
10. Setting
10.1 Dual SIM settings
Data connection Setting
Standby SIM card Setting
Standby SIM card Setting: When setting the SIM card (in standby) mode, you can
choose either one SIM card card or two SIM card cards SIM cardultaneously to be in
standby. You can customize Flight mode as the standby mode (Flight mode can not be
switched continuously and 10 seconds is needed to turn off it after it is activated) and
customize Power-on options.
10.2 Connection Management
The items are :
Data connection settings: Select to connect as needed or all the time.
Network selection: Select to automatically or manually connect.
10.3 Call settings
Set up call services such as call divert, call barring, call waiting, hide ID and Others.
10.4 Phone profile
The preset modes are General mode, Mute mode, Conference mode, Indoor mode, Outdoor
mode, Headset mode. It support custom profiles, define at most 5 profiles, and users can set the
parameters of the profiles.
Instruction: The preset profiles do not support delete, while the custom profiles support delete.
10.5 Display
Set up display settings such as automatic screen orientation, brightness, screen timeout, and more.
![](/img.php?id=4018372&img=bgd.png)
10.6 Security
Including:
PIN code: Start and close of PIN code and the modification of PIN.
Warning
Please use this function cautiously. If you forget the PUK code, please get it from the service provider. Ten
consective incorrect PUK code entries will make the SIM card card unserviceable.
Modify PIN2 code: Modification of PIN2 code.
Warning:
Be cautious to use this function, if wrong PUK2 code is entered for 10 times, SIM card can not be used.
Phone Lock:Open or close the phone lock.
Change Phone Password:Change the phone password.
Privacy Protection: Set the privacy protection
![](/img.php?id=4018372&img=bge.png)
11 Maintenance of Mobile Phone
Mobile phone is a high-precision electronic product, so please take good care of it. The following suggestions can
help you preserve it and lengthen its useful life:
Put mobile phone and its accessories to the place where children are out of reach.
Keep mobile phone dry. Rain, moisture or water may erode circuit board. If mobile phone falls into water
carelessly, take battery out in time and send it to local authorized service center immediately.
Please do not put mobile phone at dust-covered place or its normal usage will be affected.
Liquid crystal display is an easily vulnerable part of mobile phone, try to prevent it from falling down or
violently shaken; it is forbidden to use sharp item to touch the screen.
Please do not put mobile phone on the place where temperature is too high. High temperature will shorten the
life of electric equipment, damage the battery, deform or melt its plastic cover.
Please do not put mobile phone on the place where temperature is too low, or moisture will come out when
its temperature increases to normal temperature, it will damage the circuit board of mobile phone.
Please do not throw, knock or forcefully shake mobile phone to avoid its inner circuit board and precise
structure are damaged.
Please do not clean mobile or with chemical agent, cleaning solvent or powerful detergent, instead, clean it
lightly with soft cloth with soap water.
Please do not draw mobile phone with painting material to prevent its removable parts from being stuck,
which will affect its normal operation.
Please use cleaning soft cloth to clean lens, such as camera’s lens.
When antenna is replaced, use only supporting or designated antenna. Using unauthorized antenna,
accessories or reshaping mobile phone may damage it or violated relevant wireless electric equipments.
![](/img.php?id=4018372&img=bgf.png)
Troubleshooting for Simple Troubles
12Troubleshooting for Simple Troubles
In the course of using mobile phone, if abnormal condition comes out, please refer to following
instruction to rule out malfunctions. If it can’t work, please contact designated maintenance center.
Mobile phone can’t be turned on
Possible causes of trouble
Troubleshooting
The time pressing end key is too short.
Please keep pressing hanging mobile phone for
more than three seconds.
Electricity of battery is exhausted.
Please charge the battery.
Battery is misinstalled.
Please install battery correctly.
Mobile phone can’t be turned on because
of illegal usage.
Please input correct anti-robbery password.
Mobile phone turns off automatically
Possible causes of trouble
Troubleshooting
If the function of turning off mobile
phone at set time is on
If you don’t need the function of turning off
mobile phone at set time, please cancel it.
The electricity of battery isn’t sufficient.
Please charge the battery.
The battery is loose.
Please install battery correctly according to
installation method of battery on the instruction
book.
Mobile phone is turned off automatically
because of illegal usage.
Please input correct anti-robbery password.
PIN/PUK code lock
Possible causes of trouble
Troubleshooting
Wrong PIN number (Personal
Identification Number) / PUK number
(Personal Unlock Key number) is
imputed.
Please input correct password.
![](/img.php?id=4018372&img=bg10.png)
Troubleshooting for Simple Troubles
Note:
1. If PIN number is inputed wrong for 3 times successively, many functions of SIM card and mobile phone are
locked, please read details in “ safety settings” in P59.
2. Correct PIN number and PUK number can’t be guaranteed, please contact operator or retailer.
Poor quality of conversation
Possible causes of trouble
Troubleshooting
Current signal strength changes sharply.
Maybe you are in a status of moving at high speed (in a
train or motor, ect.), judge by signal strength indicator
and choose a place with strong signal strength to
communicate in order to assure conversation quality.
You are in the location where signal is
badly received
Please go to the open place
Inability to answer mobile phone
Possible causes of trouble
Troubleshooting
Call forwarding is set.
Please cancel call forwarding according to your demand.
Call barred is set.
Please cancel relevant barred function of Call barred
according to your demand.
Inability to dial mobile phone
Possible causes of trouble
Troubleshooting
Mobile phone is power off.
Please turn on your mobile phone.
Mobile phone is out of network service
area
Please confirm network is in normal service status.
Proper SIM card isn’t correctly
inserted.
Please confirm if your SIM card can be normally used.
Call barred is set.
Please cancel relevant barred function of Call
barredaccording to your demand.
Keyboard is locked automatically.
Please select left soft key+# key, unlock keyboard
![](/img.php?id=4018372&img=bg11.png)
Troubleshooting for Simple Troubles
Low conversation volume
Possible causes of trouble
Troubleshooting
The conversation volume is set too low.
Please increase conversation volume.
The counterpart can’t hear you
Possible causes of trouble
Troubleshooting
Your microphone is too far away from
voice.
Put the microphone close to your mouth.
No ringtone for incoming call
Possible causes of trouble
Troubleshooting
The alerting signal of incoming call is
set in mute mode.
Please reset alerting signal of incoming call in ringtone
The volume of ringtone is set too low.
Please increase volume.
Call forwarding is set.
Please cancel Call divert
Battery can’t be charged
Possible causes of trouble
Troubleshooting
The battery is exhausted and placed for
too long.
Please charge battery in time after mobile phone
signalizes insufficient power.
Battery is in bad contact with mobile
phone.
Please make sure battery is correctly placed.
Charger is in bad contact with mobile
phone.
Please link well charger and port of mobile phone, now
the screen displays charging indicator
Battery or charger is damaged.
Please contact maintenance station designated by the
company
The surrounding temperature is too low
or too high.
Please charge mobile phone under normal temperature.
![](/img.php?id=4018372&img=bg12.png)
Troubleshooting for Simple Troubles
No network displayed
Possible causes of trouble
Troubleshooting
SIM card is wrongly placed.
Please place SIM card correctly according to its
installation method on the instruction book.
There are impurities between SIM card
and contacts of mobile phone.
Please keep clean between SIM card and the contacts
of mobile phone.
SIM card is ineffective.
Please check if SIM card is expired.
Network environment is in weak field
strength area.
Please move to the place with good signal strength of
network for using mobile phone.
Memory card can’t be found in mobile phone
Possible causes of trouble
Troubleshooting
Memory card is wrongly inserted.
Please use memory card correctly according to its
inserting method on instruction book.
Memory card is damaged.
Please change memory card.
Insufficient space
Possible causes of trouble
Troubleshooting
MMS or SMS have occupied too much
storing space.
Please Clear unnecessary MMS or SMS to free up
space.
History recording saved in browser has
occupied too much storing space.
Please select Communication→Browser→WAP
settings→Browser settings→Clear cache] to free up
space.
Menu options what PC Camera of mobile phone can’t realize
Possible causes of error
Troubleshooting
After mobile phone is linked to computer,
no menu of “PC Camera”is displayed on
mobile phone.
1. Please check if USB port of computer is complete.
2. Please check if you have correctly used linking line
provided by retailer.
![](/img.php?id=4018372&img=bg13.png)
Troubleshooting for Simple Troubles
13 Safety Information
Usage Environment
To assure you use mobile phone reasonably and avoid its affect on you and environment, please keep in mind
relevant regulations and provisions which shall be complied with at any place when you use mobile phone.
In the places which may give rise to bomb such as gas station, fuel reservoir, chemical factory, or bombing
work, please turn off your mobile phone and abide by all safety marks and instruction there. Any violation
against relevant regulations may give rise to bomb and cause casualty.
Using mobile phone in plane may disturb plane’s operation and give rise to danger. Therefore, please do turn
off your mobile phone before boarding and make sure it is power off in the whole course of flight.
When your drive, please place mobile phone on a special stand, do not place it on seat or any place where it
may slide when it comes to collision or sudden braking. In the course of driving, please do not use mobile
phone to assure a safe drive and avoid traffic accident. If you must use mobile phone, please stop first before
using it.
Please keep your mobile phone away from high-temperature environment to avoid bomb rising from increased
temperature of battery.
Medical Equipments
It is expressly stipulated in writing that you shall turn off mobile phone nearby electric medical equipments
(like cardiac pacer maker and hearing aids). Most medical equipments have function of blocking
radio-frequency signal given off by mobile phone, but some electronic equipment don’t. if you have any doubt
or uncertainty about if medical equipment have function of blocking radio-frequency signal, please consult
doctors or manufacturer of medial equipments.
Pace Maker
Manufacturer of pace maker suggests you keep a distance of about 6 foot (15.3 cm) at least between your
mobile phone and pace maker, in order to prevent mobile phone from causing disturbance to pace maker.
Staff wearing pace maker:
When your mobile phone is power on, make sure the distance between your mobile phone and pace maker is
about 6 foot (15.3 cm) at least.
Please do not put mobile phone into the pocket in front of chest.
Please receive the call with the ear at the side different from pace maker.
Note:
If you suspect any disturbance, please turn off mobile at once and consult medical staff in time.
Hearing Aids
Mobile phone may disturb some hearing aids, if disturbance is made, please contact
![](/img.php?id=4018372&img=bg14.png)
Troubleshooting for Simple Troubles
manufacturer of hearing aids at once.
Emergency Call
The same as other mobile phones, this kind of mobile phone uses radio signal, wireless and ground
communication network and personal setting function, it can’t guarantee it can get linked successfully under
any situations. Please don’t reply on only mobile phone for sending important communication (such as medical
emergency)
Dial emergerncy call
If your mobile phone is power off, please turn it on and check if network signal is strong enough.
Input correct local emergency number (like 120 emergency center), the number differs from one district to
another.
Please call by pressing talking key.
Note:
In case of emergency call, please try to provide all important informtions. The mobile phone may be at the
accident site. It is the only conversation tool, please do not end conversation without approval.
Password Access
The mobile phone and SIM card can be protected by password to prevent them from illegal usage.
Power-on Password
To prevent your mobile phone from being used by others without your approval, you can set password when
you use the function for the first time. After you use mobile phone, please change power-on password as soon
as possible and keep it secret.
PIN Code
It is personal identification number to protect SIM card from being used by others without your approval.
Usually PIN code and SIM card are provided together. When you use using power-on PIN code, every time
when you turn on mobile phone, you have to input password before starting the normal phone function.
Note:
If PIN code is imputed wrong for three times successively, SIM card will be locked. You need to input PUK
code to unlock it. (If no PUK code is available, please contact your network operator or SIM card retailer
asking for PUK code. Please don’t input any character.)
PIN2 Code
PIN2 is password to realize special function of SIM card. If the network operation company provides this z
Unlock Key PIN code. Usually PUK code and SIM card are provided together. If you don’t have, please
contact your network operator or SIM card retailer. If you imput wrong PUK code for ten times successively,
![](/img.php?id=4018372&img=bg15.png)
Troubleshooting for Simple Troubles
SIM card can’t be used any more. Then please apply to your network operator for a new card. Do not change
PUK code.
PUK2 Code
Unlock PIN2 code. Usually PUK2 code and SIM card are provided together, PUK2 code can alter locked
PIN2code. If PUK2 number is imputed wrong for ten times successively, some functions can’t be used any
more. Then please apply to your network operator for a new card. Do not change PUK2 code. If it is lost,
please contact service provider.
Attentions on Charging of Battery
This kind of mobile phone provides energy by lithium ion battery, system environment, mobile phone settings
and others will affect waiting and conversation time of mobile phone.
Please use the standard battery and charger provided by the company, or the company isn’t responsible for
damage caused by battery or charger unauthorized by the company.
When the mobile phone is power on, the batty starts to roll on the battery indicator on the screen.
Note:
1. If the battery doesn’t have power at all, the battery indicator will show up after it is charged for 2 to 3
minutes. Generally according to current status of mobile phone (if it is power on, with conversation, etc), the
charging time is 2 to 5 hours.
2. To make new battery reach perfect performance, please finish two to three charging and discharging
cycles. A new battery shall be charged continuously for above 10 hours for the first time.
In the course of charging mobile phone, please do not contact its battery or charger with wet hand in order to
avoid danger.
When mobile phone is charged, please do not to use it as possible as you can.
After the battery is charged full, the electricity indicator stops rolling, then take mobile phone out from the port
of its adaptor.
Attentions on Use of Battery
The usage of battery is determined by network, settings of mobile phone, usage of mobile phone, take lithium
ion battery with capacity of 1200 MA, for example, its conversation time is about 6 to 8 hours and standby
time is 150 to 240 hours.
Please do not use damaged charged battery.
When mobile phone is used nearby network base, battery consumes little electricity. Therefore, conversation
and standby time, to great extent, are affected by signal strength of cellular network and parameter set by
network operator.
Time of charging battery depends on residual capacity, type of battery and electronic equipment type. When
usage time of battery is obviously shortened, you have better change battery to guarantee the performance of
![](/img.php?id=4018372&img=bg16.png)
Troubleshooting for Simple Troubles
mobile phone.
Please use standard battery and charger provided by Amoi Company, or it may give rise to bomb. When you
don’t need charger, please cut off electricity source. Do not keep battery linked with charger for over one week,
overcharge will shorten useful life of battery.
Please do not place battery by mistaking its cathode and anode.
Please do not place battery at place where it is too high or too low, or it will decrease battery’s capacity and life.
Please use battery at domestic temperature as possible as you can.
Do not make battery short-circuit, or it will damage battery core or protective circuit inside battery. When you
put unused battery in pocket or bag, medal items (coin, pin or pen, etc.) may link two ends of battery
immediately and make battery short-circuit, so please place battery singly and safety.
Please do not burn battery of mobile phone or do with it as common rubbish. To avoid potential life hazards
and harm to environment, please comply with environment-friendly policy stipulated by local government,
treat and recycle battery in time.
If your mobile phone, battery or other charging equipment fall into water carelessly, please do not dry it in any
heating equipment (such as drier, microwaver) . Mobile phone or other products may give rise to malfunction,
and mobile phone, battery or other charger may burn, expand bomb.
Please do with abandoned used battery according to relevant stipulation.
Amoi Company isn’t responsible for any direct or indirect loss caused by above-mentioned wrong operation.
Attention on Use of Accessories
Please put all accessories (such as SIM card, memory card, battery) in the place where children are out of
reach, to avoid danger.
Before taking out battery of mobile phone, please make sure mobile phone is power off and cut off linkage
between mobile phone and charger.
Accessories of mobile phone don’t have waterproof performance, please keep all accessories dry.
When cutting off electricity from any accessory, take out plug correctly, do not draw power cable.
If mobile phone, battery and charger don’t function normally, please contact the nearest and qualifying
maintenance department.
Other Safety Information
When mobile phone is not used, you’d better turn off mobile phone and take out battery in order to save energy
and eliminate radiation of mobile phone.
When mobile phone is used, please do not adjust its volume too high or it will do harm to hearing
Non-professional shall not take out terminal and battery of mobile phone by himself or herself.
You’d better not use leather case with magnetic button as possible as you can to avoid magnet what may cause
disturbance to signal of powering on or off the mobile phone, and its hard iron button may damage fluid crystal
![](/img.php?id=4018372&img=bg17.png)
Troubleshooting for Simple Troubles
display; plastic case may cause unsmooth evaporation to steam, eroding components inside mobile phone and
oxidizing and discoloring its cover.
14 FCC Warnings
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
“This compliance to FCC radiation exposure limits for an uncontrolled environment, and minimum of 15mm
separation between antenna and body.”
“Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment”
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.”
