User Manual
1
Contents
Safety...............................................................................................................3
Environment....................................................................................................4
1 Getting Started.............................................................................................5
1.1 Getting to know your touch phone..................................................5
1.2 Installing the SIM card, battery, and storage card............................5
1.3 Charging the Battery.......................................................................6
1.4 Starting up the device......................................................................7
1.5 Status Icons.....................................................................................9
2 Using phone features..................................................................................11
2.1 Turning the phone function on and off..........................................11
2.2 Making a call................................................................................11
2.3 Answering and Ending a call.........................................................12
2.4 In-call options...............................................................................12
2.5 Using call history..........................................................................13
3 Setting on your device................................................................................13
4 ActiveSync...................................................................................................17
5 Contacts......................................................................................................20
6 Exchanging Messages.................................................................................23
7 Internet.......................................................................................................28
7.1 Ways of Connecting to the Internet...............................................28
7.2 Browser........................................................................................29
8 Google.........................................................................................................32
8.1 Google mail..................................................................................32
8.2 Google talk...................................................................................35
8.3 Google Maps................................................................................36
8.4 Google Calendar...........................................................................37
9 Experiencing Multimedia...........................................................................42
9.1 Camera & Picture.........................................................................42
2
9.2 Music............................................................................................45
9.3 FM Radio......................................................................................47
10 Android Market........................................................................................48
11 Other applications....................................................................................51
11.1 Alarm Clock................................................................................51
11.2 Calculator...................................................................................52
3
Safety
Never attempt to disassemble your phone. You alone are responsible for how
you use your phone and any consequences of its use.
As a general rule, always switch off your phone wherever the use of a phone is
prohibited. Use of your phone is subject to safety measures designed to protect
users and their environment.
Do not use your phone in damp areas (bathroom, swimming pool…). Protect it
from liquids and other moisture.
Do not expose your phone to extreme temperatures lower than - 10°C and
higher than + 55°C.
The physicochemical processes created by chargers impose temperature limits
when charging the battery. Your phone automatically protects the batteries in
extreme temperatures.
Do not leave your phone within the reach of small children (certain removable
parts may be accidentally ingested).
Electrical safety: Only use the chargers listed in the manufacturer’s catalogue.
Using any other charger may be dangerous; it would also invalidate your
warranty. Line voltage must be exactly the one indicated on the charger’s serial
plate.
Aircraft safety: When traveling by plane, you will need to switch your phone
off when so instructed by the cabin crew or the warning signs.
Using a mobile phone may be dangerous to the operation of the aircraft and may
disrupt the phone network.
Its use is illegal and you could be prosecuted or banned from using cellular
networks in the future if you do not abide by these regulations.
Explosive materials: Please comply with warning signs at petrol station asking
you to switch your phone off. You will need to comply with radio equipment
usage restrictions in places such as chemical plants, fuel depots and at any
location where blasting operations are under way.
Electronic equipment: To avoid the risk of demagnetization, do not let
electronic devices close to your phone for a long time.
Electronic medical equipment: Your phone is a radio transmitter which may
interfere with electronic medical equipment or implants, such as hearing aids,
pacemakers, insulin pumps, etc. It is recommended that a minimum separation
of 15 cm be maintained between the phone and an implant. Your doctor or the
4
manufacturers of such equipment will be able to give you any advice you may
need in this area.
Hospitals: Always make sure that your phone is switched off in hospitals when
so instructed by warning signs or by medical staff.
Road safety: Do not use your phone when driving. In order to give your full
attention to driving, stop and park safely before making a call. You must comply
with any current legislation.
Distance of operation: This phone model has been tested and meets
radiofrequency exposure guidelines when used as follows:
• Against the ear: Place or receive a phone call and hold the phone as you would
a wire line telephone.
• Body worn: When transmitting, place the phone in a carry accessory that
contains no metal and positions the phone a minimum of 2.5 cm form your body.
Use of other accessories may not ensure compliance with radiofrequency
exposure guidelines. If you do not use a body worn accessory and are not
holding the phone at the ear, position the phone a minimum of 2.5 cm from your
body,
• Data operation: When using a data feature, position the phone a minimum of
2.5 cm from your body for the whole duration of the data transmission.
Environment
Packaging: To facilitate the recycling of packaging materials, please obey the
sorting rules instituted locally for this type of waste.
Batteries: Spent batteries must be deposited at the designated collection points.
The product: The crossed-out waste bin mark affixed to the product means that
it belongs to the family of electrical and electronic equipment.
To promote the recycling and recovery of waste electrical and electronic
equipment (WEEE) and at the same time safeguard the environment, European
regulations require you to obey the sorting rules instituted locally for this type
of waste.
5
1 Getting Started
1.1 Getting to know your touch phone
1.2 Installing the SIM card, battery, and storage card
You need to remove the back cover before you can install the SIM card and
battery. Also, make sure to always turn off the power before installing or
replacing the SIM card and battery.
To remove the back cover
1. Make sure your device is turned off.
2. Firmly hold the device with both hands and the front panel facing down.
3. Push the back cover up with your thumbs until it disengages from the device
and then slide it up to remove.
To install the SIM card
The SIM card contains your phone number, service details, and phonebook/
message memory. Your device is supported both 1.8V and 3V SIM cards.
Note: 1. The phone can be supported the double SIM cards.
2. Some legacy SIM cards may not function with your device. You should
consult with your service provider for a replacement SIM card. There may be
fees for this service.
1. Remove the battery if it is installed.
2. Locate the SIM card slot, and then insert the SIM card with its gold contacts
facing down and its cut-off corner facing out the card slot.
3. Slide the SIM card completely into the slot.
To install the battery
Your device comes with a rechargeable Lithium-ion battery and is designed to
use only manufacturer-specified original batteries and accessories. Battery
performance depends on many factors, including network configuration, signal
strength, and usage patterns.
Warning: To reduce risk of fire or burns:
• Do not attempt to open, disassemble, or service the battery pack.
• Do not crush, puncture, short external contacts, or dispose of in fire or water.
• Do not expose to temperatures above 60°C (140°F).
6
• Replace only with the battery pack designated for this product.
• Recycle or dispose of used battery as stipulated by local regulations.
1. Align the battery’s exposed copper contacts with the battery connectors at the
bottom part of the battery compartment.
2. Insert the contacts side of the battery first and then gently push the battery
into place.
3. Replace the back cover.
To remove the battery
1. Make sure your device is turned off.
2. Remove the back cover.
3. The bottom of the phone has a notch. Lift the battery by the notch to remove
it.
To install a memory card
To have additional storage for your images, videos, music, and files, you can
purchase a memory card and install it into your device.
1. Make sure that your device is turned off, and then remove the back cover.
2. Locate the memory card slot on the upper part of the exposed right panel.
3. Insert the memory card into the slot with its gold contacts facing down until it
clicks into place.
Note: To remove the memory card, press it to eject it from the slot.
1.3 Charging the Battery
New batteries are shipped partially charged. Before you start using your device,
it is recommended that you install and charge the battery. Some batteries
perform best after several full charge/discharge cycles.
Note: Only the AC adapter and USB sync cable provided with your device must
be used to charge the device.
Connect the USB connector of the AC adapter to the sync connector on your
device, and then plug in the AC adapter to an electrical outlet to start charging
the battery.
As the battery is being charged while the device is on, a charging icon appears
in the title bar of the Home screen. After the battery has been fully charged, a
full battery icon appears in the title bar of the Home screen.
7
Warning: • Do not remove the battery from the device while you are charging it
using the AC or car adapter.
• As a safety precaution, the battery stops charging before it overheats.
1.4 Starting up the device
Power on/off
To power off your phone, press & hold POWER. On release, the Phone options
menu opens. Select ‘Power off’ and confirm.
To power on again, press & hold POWER.
Silent mode
To silence your phone quickly, press & hold the – volume button to zero volume.
Or on the Home screen, touch and select Settings > Audio profiles. Select
‘Silent’ check box.
Or on the lock screen, slide the ring icon leftward to switch the silent mode.
Screen sleep
After a period of inactivity, your screen will go to sleep (display will turn black).
In sleep, your phone uses less battery power. You can control this behavior:
Set screen timeout period
1. On the Home screen, touch and select Settings.
2. Select Display option.
3. Select Screen timeout. Select a time from the menu.
Prevent sleep while charging
1. On the Home screen, then touch and select Settings.
2. Select Applications, and then select Development.
3. Select ‘Stay awake’ check box.
Lock screen & put phone to sleep
Except when on a phone call, from any screen, press POWER (immediately).
While not on a call, to lock your control buttons and screen from accidental
touch activation, press POWER.
You can increase the security of your phone by setting a screen unlock pattern.
Once set, in order to unlock your screen, you’ll have to draw the correct unlock
pattern. You can set your screen unlock pattern as follows:
1. On the Home screen, touch and select Settings.
8
2. Select Location & security, and then scroll down to the Screen unlock pattern
section.
3. Set or change your unlock pattern by selecting either Set unlock pattern or
Change unlock pattern, as applicable.
4. Follow the prompts to define your pattern. Note: You must slide your finger
along the screen to create the pattern, not select individual dots. Connect at least
four dots.
When you unlock your screen, if you want your pattern to be hidden as you
draw it, clear ‘Use visible pattern’ check box.
Home screen
The Home screen is your starting point for using all the applications on your
phone. You can customize your Home screen to display applications, shortcuts,
and widgets as you like.
1. Touch the application tab ( ) with your fingertip to reveal the
application icons.
2. The Home screen actually extends beyond the screen width. On Home screen,
slide your fingertip left and right along the screen to reveal the full width of the
Home screen. This additional space gives you more room to customize Home
with applications, shortcuts, and widgets.
3. Create Home screen shortcuts and widgets:
• From the Home screen, press MENU to select ‘Add’, The Add to Home screen
menu opens.
• Select an Application shortcut, a Shortcut to some of your saved information
(such as a play list), a Widget (a clock or picture frame), Folders or Wallpapers
for your Home screen.
• The application, shortcut, folder, or widget appears on the screen. If you
selected Wallpaper, you’ll be asked to select a picture.
Tip: To create an application shortcut quickly, touch the application tab to reveal
all the application icons, then touch & hold an application icon. Its shortcut is
added to the Home screen; close the application tab to see it.
4. To remove a shortcut or widget from your Home screen, touch & hold the
item to enter “move mode”. The application tab turns into a Trash button. Drag
9
the item to the Trash button and release. You’ll know when your item is in the
Trash because the item and the tab will turn red.
5. Move objects on the Home screen
• To move an icon or other item on the Home screen, you must first touch &
hold it to enter move mode. The object will magnify when it’s ready to be
moved.
• Without lifting your finger (or you’ll drop out of move mode), drag the object
to the new position. To move an item to a section of the Home screen not in
view, move it to the edge of the screen and hold it there for a moment. The
screen view will shift; position the object and release.
1.5 Status Icons
Connection status icons
Along the top of your phone screen is the status bar. On the left side, icons will
appear, notifying you of a new message, upcoming calendar event, or something
else you should notice. On the right side of the status bar, you’ll see connection
status icons.
Note: The 1 or 2 number showed on the up of the icon is SIM1 card or SIM2
card.
New email
message Sign-in/sync error
New SMS or
MMS
GSM signal, roaming, no
signal
New voicemail
GPRS service connected,
data flowing
Song is
playing
Edge service connected,
data flowing Call
forwarding is on
Ringer is off
(Silent mode)
Wi-Fi service connected,
network available
10
Call in
progress
Battery charge indicators:
full, half-full, low, very
low!
Missed call Battery is charging
Call on hold Wireless services are off
(Airplane mode)
Speakerphone
is on
Bluetooth® is on,
Bluetooth device
connected
Phone on mute
No SIM card in phone
Connected
GPS Alarm is set
Connected the
PC
Read your notifications
When you see a notification in the status bar, touch the bar and slide your finger
down the screen to open the list of notifications displayed in the sliding window.
Ongoing notifications report activities such as call forwarding ON, current call
status, song playing.
Notifications report the arrival of new messages, calendar events, and alarms.
You can clear notifications list by selecting ‘Clear’ notifications at the top of the
notifications window.
To open the message, reminder, or other notification, you can touch the items.
To close the notifications window, slide your finger up the screen.
11
2 Using phone features
2.1 Turning the phone function on and off
To enable or disable Airplane Mode
In many countries, you are required by law to turn off the phone while on board
an aircraft. Another way to turn off the phone function is to switch your device
to Airplane Mode.
When you enable Airplane Mode, all wireless radios on your device are turned
off, including the phone function, Bluetooth, and Wi-Fi.
1. Touch -> Settings -> Wireless & networks -> Airplane mode.
2. Touch ‘Airplane mode’ to enable or disable.
When you disable Airplane mode, the phone function is turned back on and the
previous state of Bluetooth and Wi-Fi are restored.
Adjusting the volume
Press Volume button on the side of the phone to show the volume screen.
If the phone is in vibrating mode, the voice will be muted automatically and the
device will vibrate when there is an incoming call.
2.2 Making a call
On Home screen, touch -> Phone to enter the dial screen.
Touch the on-screen dial pad to enter a number, touch ‘Delete’ button to delete
numbers you’ve entered. Touch & hold to delete all the numbers in the field.
To dial a number, touch ‘CALL1’ button (Green icon) by the SIM1 card, touch
‘CALL2’ button (Blue icon) by the SIM2 card. To end a call, touch ‘END’
button (Red icon).
1. Call log tab: Select an entry listed in the log to call the number.
2. Contacts tab: Contacts with phone numbers are listed. Select a contact, and
then select the phone number to dial the call.
3. Favorites tab: Favorite contacts with phone numbers are listed. Select a
favorite, and then select the phone number to dial the call.
Calling voice mail
Number 1 is generally reserved for your voice mail. Tap and hold this button on
the Phone screen keypad to call voice mail and retrieve your voice mail
12
messages.
2.3 Answering and Ending a call
When you receive a phone call, the incoming voice call screen will appear,
allowing you to either answer or ignore the call.
1. To answer an incoming call, slide ‘ANSWER’ (Green icon) button rightward.
2. To reject a call, slide ‘REJECT’ button (Red icon) button leftward.
2.4 In-call options
While on a call, reveal the in-call options: Speaker, Mute, Hold, End and More.
Note that if Bluetooth services are on and you are connected to a hands-free
device, the more menu indicator will show Bluetooth on.
1. Speaker: To use the speaker, select ‘Speaker’ so it shows a green bar. To turn
it off, select it again so the bar is unfilled. The status bar will display this icon
when the speaker is on.
2. Mute: To mute your side of the conversation, select ‘Mute’ so it shows a
green bar. To turn it off, select it again so the bar is unfilled. The status bar will
display this icon when Mute is on.
3. Hold: To put an active call on hold, select ‘Hold’ so it shows a green bar. To
resume the call, or take the call off hold, select it again so the bar is unfilled. If
you take a call while already on a call, the first call will be placed on hold
automatically. The status bar will display this icon when a call is on hold.
4. Add call: If you need to enter numbers while on a call, touch ‘More’ tab and
select ‘Add call’.
5. Incoming call: During call in progress, if you are on a call (“call in progress”)
when another call comes in (“incoming call”), you have a few choices:
• Answer the incoming call and place the call in progress on hold. To switch
calls at any time, touch ‘More’ button to select ‘Swap calls’.
• If you don’t want to interrupt your call in progress, then slide ‘END’ leftward.
• If you have one call in progress and one caller on hold, to end both calls, touch
‘More’ button to select ‘End all’.
6. While on a call, you can conference up to six callers, counting yourself. Note
that you can also have an additional caller on hold during a conference call,
regardless of how many participants are on the conference.
13
Note: Whether the group call function can be used depends on whether the
network operator supports and provides such function as well as whether you
have applied for such function. Please contact network operator for details.
2.5 Using call history
1. The missed call icon appears in the title bar when you missed a call.
2. Use ‘Call log’ tab to check who the caller was, or view all your dialed
numbers, and received calls. To open ‘Call log’ tab, touch ‘Call log’ button in
the phone screen to enter the call history list.
3. Scroll to select the contact or number you want to dial, touch ‘Call’ button.
4. Tap and hold the selected contact you want to call, and then you can make to
do the following options of call, edit number before call, send text message, add
to contacts or remove from call log phone on the shortcut menu.
3 Setting on your device
Control phone-wide settings from the Home settings screen: touch and
select Settings.
3.1 Dual-SIM settings
You can select to activate or deactivate the SIM card you want to open.
3.2 Wireless controls
Wi-Fi on/off: Select this check box if you prefer to use Wi-Fi for your data
connection.
Wi-Fi settings: Open the Wi-Fi settings screen; select it from the network list.
Provide your username or password if required.
Bluetooth on/off: Use this check box to turn Bluetooth services on or off.
Bluetooth settings: With Bluetooth services on, you can open the Bluetooth
settings screen to:
• Rename your device.
• Select to be discoverable for up to 120 seconds, or not discoverable.
• Pair or unpair with one of the Bluetooth devices in range - You will be asked
to type a PIN before pairing. Refer to the manufacturer’s documentation for the
PIN code.
14
• Rescan for devices.
Airplane mode on/off: When airplane mode is selected, all wireless connectivity
is off. This icon will display in the status bar when airplane mode is
selected.
Mobile network
• Select data roaming capability.
• Select to connect only to 2G (slower) networks to save battery power.
• Select a wireless operator network - Scan for all available networks, or select a
network automatically.
• Add or edit network Access Point Names (APNs) - Do not change this setting
unless advised to do so by your wireless operator!
3.3 Call settings
Note that when you open ‘Call settings’ for SIM1 or SIM2, your current settings
are fetched, which can take a few moments.
Fixed Dialing Numbers: This feature allows you to restrict outgoing calls to a
fixed set of numbers. To enable this feature you must know the SIM PIN2 code
for your phone. You can get this number from your wireless operator, assuming
this feature is supported.
Voicemail service: Select to set a voicemail number that isn’t being read from
the SIM card.
Call forwarding: Select how you want busy, unanswered, and unreachable calls
to be handled. There is also an option to Always forward.
Call barring: Restrict to answer or dial the call in any situation. You need to
apply to the network operator for opening the international long-distance
function and get network restricting code for barring setups.
Additional settings: From this setting you can set your Caller ID preference and
turn on/off call waiting.
Cell broadcast (supported by the network): Set and activate receive of local
information broadcast from the network. Choose whether you want to receive
information broadcast from your network such as weather forecast, traffic
update, news, and taxi service info.
Please contact your local network operator for more details.
15
3.4 Basic phone settings
Audio profiles
Select one user profile and enter the following options:
Vibrate: Select to have your phone vibrate for incoming calls.
Volume: Select to open the volume control, and then slide your finger along the
volume bar to set an incoming call ring volume or alarm, playing back music,
videos.
Phone ring tone: Select to decide on a ring tone to use for incoming calls. Note
that you can override this setting for individual contacts in the Edit contact
details screens.
Notification ring tone: Select a ring tone to use for a notification (e.g., new
message). Note that you can override this setting for new Calendar event
notifications, text and multimedia message notifications. Go to the applications
settings screens to select specific ring tones.
Audible touch tones: Select to have a tone sound when you use the on-screen
Dialer.
Audible selection: Select to have a sound play when you select an item on the
screen either using touch.
Display settings
Brightness: Select to open the brightness control, and then slide your finger
along the brightness bar to set the level. In sunlight, increase the level.
Screen timeout: Select to decide how long your phone must be inactive before
the screen turns off.
Security & location
My Location: Select a source for determining your location: Wireless networks,
or GPS satellites. Typically GPS will be more accurate (to street level) but it
consumes more battery power.
Screen unlock pattern: Create a pattern you will be asked to draw before your
screen will unlock. You can select to make the pattern visible or invisible as you
draw it.
SIM card lock settings: Lock your SIM card for extra security. You can also
change your SIM card PIN from this screen. If you don’t know your SIM PIN,
16
you can obtain it from your wireless operator.
Visible passwords: Select to have your password display as you type it.
Applications
Unknown sources: Select this check box if you want the ability to download
applications from the Web. With this check box not selected, you will only be
able to download applications from Android Market. To ensure your personal
data and phone remain secure; it is recommended you not select this check box.
Manage applications: View all the applications stored on your phone and how
much space they occupy. If you’ve downloaded an application from Android
Market, you can uninstall it from this screen. Select a specific application to:
1. Clear your user data (if you have any associated with a particular
application).
2. Disassociate the application with any actions.
3. Uninstall - If you’ve downloaded an application from Android Market, you
will be able to uninstall it from this screen by selecting Uninstall.
Development: If you are an application developer, you may be interested in
these settings: 1. USB debugging: If you want be able to communicate with
your phone directly via USB, select ‘USB debugging’ check box. 2. Stay awake:
To prevent your phone from sleeping while charging (via power adapter or
USB), select ‘Stay awake’ check box.
Accounts & sync
Read more in “Data synchronization” on page 17.
Turn on/off synchronization for all services.
Privacy
You can select to reset your phone to factory settings. This will erase all your
data from the phone and require you to sign in and go through the setup screens
to use any of the applications.
SD card& phone storage
View and manage the data storage on your phone.
Memory card: Monitor and manage the use of your Memory card from this
screen: 1. View how much space you are using on your memory card. 2. Select
to use your memory card as USB mass storage when your phone is connected to
17
your computer (selected by default) 3. Unmount/eject your memory card from
your phone. Note that when your phone is connected to your computer via USB,
you cannot view pictures or play any media stored on the card from your phone.
Internal phone storage: Reports how much internal storage is free.
Date & time
Set time, time zone, and date: Use Automatic unless you need to override the
network values.
Time format: Select from 12 or 24 hour formats.
Date format: Select from a variety of formats.
About phone
View your phone Status: This screen lists a variety of information, including
your phone number, the network you are currently using, the type of network,
signal strength, whether you are roaming or not, any Wi-Fi addresses you’re
connected to, and more.
View the model number and version information for your phone.
4 ActiveSync
4.1 Data synchronization
Some Google applications on your phone (Gmail, Calendar, and Contacts) give
you access to the same personal information that you can add, view, and edit on
your computer using Google Web applications. This means that when you add,
change, or delete your information in any of these applications on the Web, the
updated information also appears on your phone, and vice versa. Also, if you
lose your phone or if your phone is destroyed, your personal information is not
lost and will appear, as before, on a replacement phone.
This mirroring of information happens through over-the-air data
synchronization, or data “syncing”. Data syncing occurs in the background and
shouldn’t ever get in your way. You’ll know your data is being synchronized
when you see this icon in the status bar:
Because sending large amounts of data back and forth over the air can take time
and require considerable bandwidth, there are some settings on the phone that
18
allow you to control data sync.
Sync by application
To control synchronization for Gmail, Calendar, and Contacts, you can do the
following:
1. On the Home screen, then touch and select Settings.
2. Select Accounts & sync. When any of the applications are synchronizing, you
will see the “sync” icon . You will also see the last time your data was
synchronized.
3. By default, the personal information in Gmail, Calendar, and Contacts will
sync whenever you make a change or receive a new message. You can change
this behavior:
Auto-sync: When selected, Auto-sync will sync Gmail, Calendar, and Contacts
automatically, as you make changes or receive new messages. When OFF,
information will not be synced automatically, although you can force sync by
using the individual application check boxes described below.
Gmail: Clear this check box to exclude Gmail from auto-sync.
Calendar: Clear this check box to exclude Calendar from auto-sync.
Contacts: Clear this check box to exclude Contacts from auto-sync.
4. Sync problems:
If you see this icon to the left of the sync check box, then there was a
temporary problem with the data synchronization. Check your data connection
and try again later.
4.2 Bluetooth
Your phone is equipped with Bluetooth® wireless technology Specification 2.0.
You can use Bluetooth to send and receive calls using a headset or hands-free
car kit.
Turn on Bluetooth services
1. On the Home screen, then touch and select Settings.
2. Select Wireless & networks, and then select ‘Bluetooth’ check box to turn on
Bluetooth services.
3. When on, the Bluetooth icon appears in the status bar.
Discoverability
19
By default, your phone is not “discoverable”. This means other Bluetooth
devices will not see your phone in their scans for Bluetooth devices. If you
make your phone discoverable, it will be visible to other Bluetooth devices for
up to 120 seconds.
To make your phone discoverable:
1. Make sure you have turned Bluetooth on.
2. Select Settings > Wireless & networks> Bluetooth settings.
3. Select ‘Discoverable’ check box to make your phone visible to other
Bluetooth devices for 120 seconds. You must stay on the Bluetooth settings
screen to remain discoverable.
4. Select ‘Discoverable’ again during the 120 seconds, or leave the Bluetooth
settings screen, to make your phone undiscoverable.
Name your Bluetooth device
1. Make sure you have turned Bluetooth on.
2. Select Settings > Wireless & networks> Bluetooth settings > Device name.
3. Type the name for your device in the dialog box, and then select ‘OK’.
4. Your new device name appears on the Bluetooth settings screen.
Pair & connect with Bluetooth devices
Before your phone can communicate with a Bluetooth headset or hands-free car
kit, the devices must “pair”, then “connect”:
1. Make sure you have turned Bluetooth on.
2. Select Settings > Wireless & networks> Bluetooth settings.
3. Your phone starts scanning for Bluetooth devices within range. As they are
found, the devices appear in the list of Bluetooth devices.
4. To pair with a device in the list, select it.
5. Type the device’s PIN, and then select ‘OK’. (Read the manufacturer’s
documentation if you don’t know the PIN.)
6. Once paired, select the device name to connect. You can also touch & hold
the name to open the context menu, and then select Connect.
7. Pairing and connection status appear under the device name.
8. Once the other Bluetooth device shows “connected” status, you can start
using it to make and receive phone calls.
20
9. To disconnect or unpair with a device, touch & hold the device to open the
context menu. Select Disconnect or Unpair, as appropriate. If you select
‘Unpair’ when connected, you will be disconnected as well.
Notes: The phone supports only the headset and hands-free Bluetooth profiles,
so if you try to connect to a device that is not a headset or hands-free car kit,
then you will receive an “unable to connect” message.
If you pair with a second headset while connected to the first, the first headset
will remain connected. To switch connection to the second headset you must
manually select that headset again after pairing.
Rescan for Bluetooth devices
If you want to update the list of Bluetooth devices, press MENU and select
‘Scan for devices’.
5 Contacts
The contacts on your phone are synced with your account contacts stored on the
Web.
To view the contacts on your phone, touch and select Contacts.
Contacts belonging to a specific group (you can choose which group) are listed
in the Contacts tab. Only those contacts you star as “favorites” are listed in the
Favorites tab. Browse through your contacts by sliding your fingertip up and
down on the screen. Another way to find a contact quickly is to use “SEARCH”
button. As soon as you press “SEARCH” button, the quick search tab appears
on the top of the screen, input the first letter of the name you’re looking for and
touch search icon, the matching contacts are appeared on the screen.
From the Contacts tab, you can:
1. Take action on a contact: Touch & hold the contact’s name to open the
context menu. From the menu you can select to view the Contact details screen,
call the contact’s number, send a text message, add or remove a star, edit the
contact details, or delete the contact.
2. Go to Contact details: Select the contact’s name to open the Contact details
screen, where all screen the information you’ve saved for this contact is
21
displayed.
Add a contact
1. On the Home screen, then touch and select Contacts. Your contact list
appears.
2. Press MENU and select ‘New contact’.
3. Add all the information you want to store for this contact in the appropriate
fields. You must add some information to save a contact. To change a default
label, select the label name to open the label menu. Select a different label or
create a custom label. To add more fields, select + More info.
4. Assuming you have memory card inserted with pictures on it, you can assign
a Caller ID icon to your contact by touching Caller ID icon. The Pictures
application opens. Navigate to a picture and select it, size the cropper with your
fingertips. When finished, select ‘Save’. The picture is associated with your
contact. If you do not assign an icon, a default android icon will be assigned.
5. To save your contact, press BACK, or touch ‘Done’.
Assign favorites
Use Favorites as a way to display only those contacts you contact most
frequently. To add a contact to Favorites:
1 From Contacts, touch & hold the contact you want to add to Favorites. The
context menu opens.
2. Select ‘Add to favorites’.
3. Now your contact will be listed in Favorites. Their details screen will also
display the colored star.
Edit contact details
You can always make changes to the information you’ve stored for a contact:
1. From Contacts, touch & hold the contact whose information you want to edit.
The context menu opens.
2. Select ‘Edit contact’. The Edit contact screen appears.
3. Make your edits, then press ‘Done’.
Communicate with a contact
From Contacts you can quickly call or text a contact’s default number, as
displayed below their name on the screen. However, to view all the information
22
you’ve stored for a contact, and to initiate other types of communication with
that contact, open the Contact details screen. To open a contact’s details screen,
simply select their name from Contacts.
1. Call a contact: From the contact list, touch & hold the contact you want to
call. Select ‘Call contact’ to dial that contact’s primary number (first in the list
on their details screen).
2. To dial a different number for the contact, select the contact’s name, and then
select the number on their details screen and then touch ‘CALL’ icon.
3. Send a text or multimedia: To send a text or multimedia message to a contact,
you must have a message to a contact mobile number stored for them in contact
details. From the Contact details screen, select a phone number and click
‘Message’ icon, A Compose screen opens for your new message. Complete your
message and select ‘Send’.
4. Send email to a contact: To send an email message to a contact, you must
have an email address stored for them in their contact details.
• Select the contact you want to email. Their Contact details screen opens.
• In the Send email section, select the email address. If you are fetching POP3 or
IMAP email accounts to your phone, then select the account you wish to use to
send. A Compose screen opens for your new message.
• Complete your message, select ‘Send’.
SIM contacts importer
If you have stored names and phone numbers on your SIM card, you can add
these to the Contacts stored on your phone by selecting this settings option.
From the contact list, press MENU to select ‘Import/Export’, you can select to
import from SIM card or memory card, once the list of names and numbers
appears you can:
Import all names/numbers in the list - Press MENU and select ‘Import all’.
Import only certain names/numbers in the list - Select the name/number you
want to import, then repeat for others as you wish. (As soon as you select the
name/number, it is imported.)
23
6 Exchanging Messages
6.1 SMS and MMS messaging
To open the SMS & MMS Messaging application, on the Home screen, then
touch and select the Messaging icon.
About text and multimedia messages
SMS messages are also know as “text” messages and can each be around 160
characters. If you continue to type after the limit is reached, your message will
be delivered as one, but count as more than one message. These are called
“concatenated” messages.
MMS messages are also known as “multimedia” or “picture” messages and can
contain text, picture, audio, and video files.
When you compose a message, the phone will automatically convert a text
message into a multimedia message as soon as you add a subject or an
attachment, or if you address the message using an email address rather than a
phone number.
View the message from the message list
Select a message thread in the list to open it for reading. When open, the
individual messages appear stacked on the screen, much like with instant
messaging conversations (or chats).
Note that messages you send are also listed in the Read view.
1. Reading multimedia messages
If you have selected to auto-retrieve your multimedia messages, then both the
message header and body will download.
If you are downloading only the headers, then you must first select the
Download button to retrieve the message body. If you are concerned about the
size of your data downloads, you can check the message size before you
download.
Once the message has downloaded, select the “play” button to view the
message.
From a message read view, you can do the following:
1. To view details about a particular message, in the Read view, touch & hold
24
the message to open the context menu. Select View message details.
2. Reply to a message: Simply start typing your message in the text box at the
bottom of the screen to reply to a message. You can always press MENU and
select to add a subject or an attachment to convert it to a multimedia message.
Select ‘Send’ when ready.
3. Links in messages: If a message contains a link to a Web page, it will be
selectable. To view the Web page in the Browser, simply select it.
4. Delete messages: Your messages will be saved until you explicitly delete
them.
Delete one message in a thread - With the message thread open in Read view,
touch & hold the individual message you want to delete to open the context
menu. Delete all messages in a thread - With the message thread open in Read
view, press MENU > Delete threads. You can also delete an entire thread from
the message list by pressing & holding the thread to open the context menu,
then select ‘Delete’.
Delete all message threads - From the message list, press MENU and select
Delete threads.
Compose text and multimedia messages
1. Press MENU and select ‘Compose’. The Compose screen opens.
2. Add recipients by typing a name, phone number, or email address in the ‘To’
field. Matching contacts will appear. Select the recipient or continue typing.
Add as many recipients as you wish. If you send the message to an email
address, the message will automatically convert from a text to a multimedia
message.
3. To add a subject, press MENU and select ‘Add subject’. If you add a subject,
the message will convert to a multimedia message.
4. To add an attachment, press MENU and select ‘Attach’. Adding an
attachment will always convert the message to a multimedia message. Select
from audio or picture files. You can select to take a new picture if you want, or
record an audio file. Any recordings you make will be stored automatically in
the Music application in a play list named “My recordings”. To remove an
attachment, select the attachment’s ‘Remove’ button.
25
5. Type your message. As you type, you’ll be able to track how many
characters/messages you’re creating. Remember that text messages have a limit
around 160 characters. Once you go over that limit, a new message is actually
created but automatically joined into one when received.
6. Select ‘Send’ when ready. You can also save a draft.
7. As your message sends, progress displays in the title bar. If you see this icon
to the right of the message, it means your message is still being delivered.
Save message as draft
While composing, press BACK, your message automatically saves as a draft.
Text and multimedia message settings
To set text and multimedia message preferences, from the message list, press
MENU and select ‘Settings’. You can set the following from this screen:
1. Notification settings
You can receive a notification each time you receive a new message.
Select ‘Notifications’ check box to receive a notification in the status bar when a
new message arrives. If you want your phone to ring when a new message
arrives, select that check box as well. Select Ring tone to open the ring tone
menu and select a ring tone specific to new text and multimedia message
notifications. Note that when you check a ring tone, it plays briefly.
If you want your phone to vibrate when you receive a new message, select
‘Vibrate’ check box.
2. Text message settings
Delivery reports: To receive a report on the delivery status of your message,
select this check box.
Manage SIM card messages: Text messages can also be stored on your SIM card.
The exact SIM card number depends on your card, but it is usually around
25-50. To view messages on your SIM card, delete them, and copy them to your
phone memory, select this setting.
3. Multimedia message settings
Delivery reports: To receive a report on the delivery status of your message,
select this check box.
Read reports: To receive a report on whether each recipient has read or deleted
26
the message without reading it, select this check box.
Auto-retrieve: To retrieve all your MMS messages automatically (the header
plus the message will download to your phone), select this check box. If you
clear this check box, then only the message headers will be retrieved and
display in your message list. You can retrieve the full message by selecting the
Download button that displays in the header. Once the message has downloaded,
select the “play” button to expand the message.
Roaming auto-retrieve: If you are concerned about data traffic and just want the
message headers to download while roaming, clear the Roaming auto-retrieve
check box. Otherwise, you can select this check box to have your messages
download even while roaming.
6.2 POP3 and IMAP email accounts
Add an email account
You can fetch messages from up to five POP3 or IMAP accounts. Follow these
steps:
1. Press Home, then select the Email application.
2. The Set up new account screen appears.
3. Type your account email address and password.
4. If you want, select the Send email from this account by default check box.
This setting only applies if you have more than one POP3 or IMAP account set
up.
5. Select ‘Next’.
If you have a popular email account, the application will set everything up for
you! Before you go to your Inbox, you can name the account (if you don’t, your
email address will be used). You are also asked to type your name as you want it
to display on outgoing messages. You must complete this field before you can
select ‘Next’ and go to your Inbox.
For less popular accounts, follow the prompts to type the email server, protocol,
and other account information yourself. After your account settings have been
verified, select ‘Next’ to go to your Inbox.
6. To add more accounts (up to five), from an Inbox or your Accounts screen,
press MENU and select ‘Add account’.
27
Use your POP3 and IMAP email account
Once you’ve set up an account, you can do the following:
1. Refresh Inbox: From the Inbox, press MENU and then select ‘Refresh’ to
update your Inbox with any previously-unfetched email.
2. Read email: You can display or collapse the messages in your Inbox by
selecting Inbox. Unread messages display with a colored band. (Each account
you add will use a different color.)
3. Forward, Reply, Reply all: You can forward, reply, or reply all to an email
message from the Inbox. From the Inbox, touch & hold the message to open its
context menu. Select the action you want to take.
4. Compose new
From the Inbox: 1. Press MENU and select ‘Compose’. 2. Add recipients by
typing a name or address in the ‘To’ field. Matching contacts will appear. Select
the recipient or continue typing the address. Add as many as you wish. 3. Type a
subject and message. 4. Select ‘Send’, ‘Save as draft’, or ‘Discard’. Pressing
BACK will also save as draft unless you have not typed anything.
5. Delete message
From the Inbox: 1. Expand the Inbox to display the messages. 2. Touch & hold
the message you want to delete. 3. Select ‘Delete’. 4. Your message is moved to
the Trash.
6. Empty Trash: Once you’ve moved a message to the Trash, to empty messages
in the Trash you must delete each message individually. Press MENU and select
‘Folders’ to enter the Trash.
Note that the message is only deleted from your phone, not from the account
server.
7. Remove an email account: You can always remove a POP3 or IMAP email
account from your phone. Go to your Inbox, press MENU and select ‘Accounts’.
Your Accounts screen opens. Touch & hold the account you want to remove to
open the context menu. Select ‘Remove account’. You will be asked to confirm
before the account is removed.
Edit account settings
To open your Account settings screen, do the following:
28
1. From your account Inbox, press MENU and select ‘Account settings’.
2. The Account settings screen appears. You can do the following from this
screen:
Account name: Select to change the name of your account as it appears on your
Accounts screen.
Your name: Select to change your name as it appears in outgoing email.
Email check frequency: Select this pop-up menu to set how frequently your
email account is checked for new messages. Note that whenever you open a
folder, email is refreshed, regardless of this setting.
Default account: If you have more than one POP3 or IMAP email account set up
on your phone and want to use this account by default when selecting Compose
from the Accounts screen, select this check box.
Email notifications: If you want an icon to appear in the status bar when a new
message arrives, select this check box.
Incoming server settings: Select Incoming settings if you need to edit the
username/ password, server, port, or option to delete email from server.
Outgoing server settings: Select Outgoing settings if you need to edit the SMTP
server, port, security type, option to require sign-in, or username/password.
Add another POP3 or IMAP
To add another account (you can add up to five), go to your Inbox, press MENU
and select ‘Accounts’. Your Accounts screen opens.
Press MENU and select ‘Add account’ another account.
7 Internet
7.1 Ways of Connecting to the Internet
Your device’s networking capabilities allow you to access the Internet or your
corporate network through Wi-Fi, GPRS or EDGE (if available).
You can also add and set up a VPN or proxy connection.
Wi-Fi
Wi-Fi provides wireless Internet access over distances of up to 100 meters (300
feet). To use Wi-Fi on your device, you need access to a wireless access point or
29
“hotspot”. Note: The availability and range of your device’s Wi-Fi signal
depends on the number, infrastructure, and other objects through which the
signal passes.
7.2 Browser
To open the Browser, touch and select the Browser icon.
The Browser always opens to the last Web page you were viewing. The first
time you enter the Browser after powering on, your home page will display.
You can change your home page by pressing MENU and selecting More >
Settings > Set home page.
Zoom and navigation in Web pages
While viewing a Web page, you can press MENU and select More > Settings >
Default zoom to set the zoom controls.
Slide your fingertip in any direction to shift your page view.
The Browse screen
From the Browse screen you can do the following:
1. Go to a Web page: Make sure the focus is not on a text box and then start
typing the URL.
2. Add a bookmark: Bookmark the Web page you are currently viewing:
• Press MENU and select ‘Bookmarks’.
• From the Bookmarks screen, select ‘Add’.
• Confirm the URL and name, and then select ‘OK’.
To view all your bookmarks, press MENU and select Bookmarks.
3. Refresh a Web page: To refresh the contents of the current page, press MENU
and select ‘Refresh’.
Open pages in separate windows
You can keep more than one Web page open by using multiple windows to
display the pages. You can open up to eight windows.
Open a new window: From a Web page, press MENU and select ‘Windows’.
The Current windows screen opens, showing the Web page you started from,
plus a “new window”. Select ‘New window’. Your home page opens in a new
window. To return to one of the other windows, press MENU and select
‘Windows’. Select the page you want to view.
30
Manage bookmarks
You can store as many bookmarks as you want on your phone.
Press MENU and select ‘Bookmarks’. The Bookmarks screen opens.
1. Bookmark any page: Select ‘Add’. Type a name and location (URL) in the
dialog box. Select ‘OK’.
2. Send bookmarked page’s URL: Touch & hold the bookmark you want to
open. The context menu opens. Select ‘Share link’. An email Compose screen
opens with the URL as the message. Address your message and finish
composing and select ‘Send’.
3. View bookmarked page: Touch & hold the bookmark you want to open. The
context menu opens. Select View page or Open in new window.
4. Edit bookmark: Touch & hold the bookmark you want to e open. The context
menu opens. Select ‘Edit bookmark’. The edit bookmark dialog box opens.
Type your change and select ‘OK’.
5. Delete a bookmark: Touch & hold the bookmark you want to open. The
context menu opens. Select ‘Delete bookmark’. You will be asked to confirm.
6. Bookmark current page: Go to a Web page you want to bookmark. Press
MENU and select ‘Bookmarks’. The Bookmarks screen opens. Press MENU
and select Bookmark last-viewed page. The Bookmark link dialog box opens.
Confirm or edit the information, then select ‘OK’.
Set your home page
You set your home page from the Settings screen:
1. Press MENU and select More > Settings. The Settings screen opens.
2. In the Page content section, select ‘Set home page’ to open the dialog box.
3. Type the URL of the page you want to set as home, and then select ‘OK’.
Download Web files and applications
Before you download any files or applications using the Browser, note the
following:
1. Before you can download Web applications, you must explicitly “allow”
downloading from the Home > Settings screen:
On the Home screen, then press and select Settings. Select ‘Applications’,
then on the Application settings screen, select ‘Unknown sources’ check box.
31
2. All items downloaded form the Web are stored on your memory card, so be
sure you have a card installed in your phone before you download from the
Browser.
3. The Browser will only allow you to download items that are supported by an
application installed on the phone.
Warning! Applications downloaded from the Web can be from unknown sources.
To protect your phone and personal data, only download applications from
sources you trust, such as Android Market.
View your downloads
To see which files or applications you’ve downloaded:
1. From the Browse screen, press MENU and select More > View downloads.
2. The Download history screen appears with the list of downloads. If you have
no downloads, nothing will be shown on this screen.
Browser settings
To set Browser preferences from the Browser screen, press MENU and select
More > Settings.
1. Page content settings
Text size: Select to open the Text size menu. Default setting is Normal, but you
can increase the size to Larger or Largest, or decrease to Smaller or Smallest.
Note that this text size setting only affects pages you view through the Browser.
Block pop-up windows: Select this check box if you want pop-up windows to
be blocked.
Load images: Select this check box if you want images on Web pages to load.
For faster page loading, clear this check box.
Auto-fit pages: Select to size pages to the screen automatically.
Open in background: Select if you want links to new pages to open in a new
window in the background.
Set home page: Your currently-set home page is shown on the Settings screen.
To change your home, select Set home page, type the URL for your home page,
then select OK.
2. Privacy settings
Select one of the privacy settings to clear the following:
32
Browser cache: Browser page-visited history stored cookie data saved form data
Accept cookies: Select this check box if you want the Browser to save cookies.
Some Web sites might not work properly with cookies disabled.
Remember form data: Select this check box if you want the Browser to
remember text you have typed in forms, so that you can select the same text
later rather than retyping it.
3. Security settings
Remember passwords: Select this check box to save usernames and passwords
to various Web sites.
Clear passwords: Select Clear passwords to clear all your saved passwords.
Show security warnings: Select this check box if you want a warning to be
displayed when you are going to an insecure Web site.
8 Google
8.1 Google mail
To open Gmail™ webmail service, touch and select Gmail icon.
With Gmail, each message you send is grouped with all the responses you
receive. This “conversation view” continues to grow as new replies arrive, so
you can always see your messages in context. Conversations are also referred to
as “message threads” or simply “threads”. A new message or a change to the
subject of a current message will begin a new conversation.
Inbox conversation list
All the Gmail that you fetch to your phone is delivered to your inbox, and the
Inbox is your default Gmail view. The total number of unread messages displays
in the title bar and individual unread messages display in bold. If you have
labeled a message, its label appears in a colored rectangle to the left of the date.
Conversation labels
Organize your email by labeling your conversations. You can filter the
conversation list to show only those with a specific label. You can apply as
many labels to a conversation as you wish.
Use stars to mark important conversations, or any way that you wish. Other
system labels include: Inbox, Sent, Outbox, Drafts, and All Mail.
33
Here are some specific instructions on using labels, from a conversation list,
touch & hold a conversation to open the context menu.
1. Label a conversation: Select ‘Change labels’. The Labels menu appears.
Select the label to either apply it or remove it from the conversation, then select
‘OK’ to return to the conversation list.
2. Star a conversation: Select ‘Add star’. If the conversation already is starred
and you want to remove it, select ‘Remove star’.
3. Filter conversations by label: From a conversation list, press MENU and
select ‘View labels’. Select the label of the conversations you want to view,
including system labels.
4. A list appears, showing just the conversations marked with the label you
selected. To return to the Inbox, press MENU and select ‘Back to Inbox’, or
press BACK.
5. Select labels to sync: You can select to synchronize specific labels: From a
conversation list, press MENU and select ‘Settings’, and then select Labels. All
your labels appear in a list. Select the labels you want synchronized on a regular
basis.
6. Refresh: From a conversation list, press MENU and select Refresh. Your
email is synchronized per settings.
Read email
When you open a conversation for reading, the subject will appear in a box at
the top of the screen and the latest message will appear at the bottom of the
conversation.
Here are some actions you can take on individual messages and conversation:
1. Open/collapse messages: All read messages are collapsed. Once the read
messages are expanded, their individual headers display. Touch the header to
open/collapse the message body.
2. Scroll through messages: Slide your finger up or down on the screen; quickly
brush your finger up or down to scroll faster.
3. Mark conversation as spam: From a conversation list, touch & hold the
conversation to open the context menu. Select ‘Report spam’.
From the read view, press MENU and select More > Report spam.
34
4. Mark conversation as read/ unread: From a conversation list, touch & hold
the conversation to open unread the context menu. Select ‘Mark read’/’Mark
unread’ as appropriate.
5. Archive conversation: From a conversation list, touch & hold the
conversation to open the context menu. Select ‘Archive’. To view your archived
messages, from the list of labels, select ‘All mail’.
Compose email
1. From a conversation list, press MENU and select ‘Compose’.
2. Add recipients by typing a name or address in the ‘To’ field. Matching
contacts will appear. Select the recipient or continue typing the address. Add as
many as you wish.
3. Type a subject and message.
4. To add a picture attachment, press MENU and select ‘Attach’. Select a
picture. To remove an attachment, select the attachment’s ‘Remove’ button.
5. Select ‘Send’ or ‘Save as draft’ when ready. Pressing BACK will also save as
draft.
6. Reply, Reply all, Forward: With a conversation highlighted or open for
reading, scroll to the end of the conversation. Select Reply, Reply all, or
Forward. Tip: Always double-check that you’ve made the right selection!
Compose your message and Send or Save as draft when ready. Pressing BACK
will also save as draft.
Search for messages
In Gmail, you can search for a specific message by sender, word in subject, or
label:
1. From a conversation list, press MENU and select ‘Search’. You can also press
SEARCH button.
2. Type your search string into the box, and then select ‘Search’.
Add signature to messages
You can append a signature to every message you send.
1. From a conversation list, press MENU and select ‘Settings’.
2. Select ‘Signature’.
3. Type your signature in the box. Your signature can be multiple lines, as long
35
as you like. When finished, touch ‘OK’.
Select labels to synchronize
You can choose to synchronize messages based on the labels you’ve assigned to
them. Limiting the amount of email that is regularly synchronized will cut down
on network data exchange.
1. From a conversation list, press MENU and select ‘Settings’.
2. Select ‘Labels’ to open the Labels screen. In addition to the labels you’ve
created, all the “system labels” (Inbox, Starred, Chats, Sent, Spam, and Trash)
are listed.
3. Select a label name to cycle through the sync options: Sync 4 days, Sync all,
or Sync none (no sync option displays). Note: You cannot turn off sync for
Inbox except through the Home > Settings > Account & sync options.
Set new email notifications
You can receive a notification each time you receive a new email message:
1. From a conversation list, press MENU and select ‘Settings’.
2. Select ‘Email notifications’ check box to see an icon in the status bar when a
new message arrives.
3. If you want a sound to play when a new message arrives, select ‘Select
ringtone’. From the ringtone menu, select a ringtone that will play for new email
notifications. Note that when you select a ringtone, it plays briefly. If you don’t
want a ringtone to play when you receive a new message, select ‘Silent’. The
ringtone marked ‘Default ringtone’ is defined in the Home > Settings > Sound
& display > Notification ringtone menu.
4. If you want your phone to vibrate when you receive a new message, select
‘Vibrate’ check box.
8.2 Google talk
You can use Google Talk™ instant messaging service to send instant messages
to your friends. All you need is Gmail account and you’re set up. To open
Google Talk, touch and select Talk icon.
The IM accounts screen opens. The number of open chats displays opposite the
account name. You can have as many open chats as you wish.
36
8.3 Google Maps
To open Google Maps™ mapping service, touch and select Maps icon.
Find your location
1. Make sure you have enabled a “location source” in global Settings by doing
the following: touch , and then select Settings.
Select Security & location. Select either Wireless networks or GPS satellites, or
both.
2. From the main Map screen, press MENU and select ‘My Location’.
3. Your location is shown on the map as a blue blinking dot surrounded. Touch
the screen of zoom icon controls to zoom in or zoon out the map.
Find any location
1. From the main Map screen, press MENU and select ‘Search’.
2. You can use a variety of search criteria in the search box:
• Type an address.
• Type a type of business and city (e.g., sushi seattle).
• Select an address you’ve visited before in Maps from the drop-down menu
(stored in History).
3. Select ‘Search’ when ready. Your search results display.
4. Select to see the highlighted result on a map.
5. Touch the result balloon to open the location’s details.
In addition to seeing details about the location, from this screen you can:
• Zoom in to address
• Get directions to address to another location
• Get directions from this address to another location
• Add to Contacts
• Go to associated Web site, if available
Get directions
To get detailed directions to a location, do the following:
1. From the main Map screen, press MENU and select ‘Directions’.
2. Enter the starting point in the first box. You can type an address, or select to
open the location source menu. Select from:
• My current location - Remember to have a location selected.
37
• Contacts - Opens a list of the contacts you’ve stored with a physical address.
• Point on map- Opens a menu of places you’ve visited.
3. Enter your destination in the second box. You can type an address or select to
select from the location source menu.
4. Select Route. You can choose to view your directions in a list, or you can
select Show map, to view the same directions overlaid on a map.
5. When finished reading or following the directions, press MENU and select
‘More > Clear map’. Your destination is saved in History.
Select map mode
Whenever you are viewing a map, you can switch your view. Press MENU and
select ‘Layer’ to select from Satellite, Traffic, Terrain or Latitude View.
Satellite view: Satellite images are not real-time. Google Maps acquires the best
imagery available, most of which is approximately one to three years old.
Traffic view: If available in your area, real-time traffic conditions are displayed
over the highway as color-coded lines.
8.4 Google Calendar
To open Google Calendar™ calendaring service, press HOME and select the
Calendar icon. The Calendar on your phone stays in sync with your Google
Calendar events on the Web.
Calendar views
You can view multiple calendars on your phone, so each calendar event is coded
with a color.
Note: To create new calendars, you must go to Google Calendar on the Web.
You can view your calendar in a variety of ways. Press MENU to select from
Month, Agenda, Week, or Day.
1. Month view
Days are shown in a month grid. Busy time slots are shown as vertical bars in
the corresponding part of the day. An all-day event is shown as a small vertical
bar at the top of the slot (it does not fill the entire slot).
View event details - Select a day to view all the events in that day. This will take
you to either the Agenda or Day view, depending on which you last visited.
Select the event to view its details.
38
Edit an event - First select a day to go to either the Day or Agenda view. From
there, select the event to view its details. Assuming you have write privileges on
an event, press MENU and select ‘Edit event’ to open the event for editing.
Navigate months - Slide your fingertip up/down, through the days and past the
beginning/end of the month to move to the previous/next month.
Create new event- Touch & hold a day to open the context menu. Select ‘New
event’. You can also press MENU and select ‘New event’.
Jump to current day - Press MENU and select ‘Today’.
2. Agenda view
Events in the current month are shown vertically in a list, one event after the
other. Days with no events are not displayed.
Repeating events - Marked with icon following the time or date.
View event details - Select the event to view its details.
Edit an event - First, select the event to view its details. Assuming you have
write privileges on an event, press MENU and select ‘Edit event’ to open the
event for editing.
Navigate within the current month - Slide your fingertip up/down.
Jump to current agenda - Press MENU and select ‘Today’.
3. Week view
Days are shown vertically within the Week view. Time slots are defined
horizontally in rows. Events are shown as blocks.
View event details - Highlight an event to open a small popup window in the
lower part of the screen that provides more event information. This window will
stay open for three seconds. (Note that highlighted events are outlined in
orange.) To view the full event details, touch the pop-up window while it’s open,
or select the event itself. You can also touch & hold the event to open the
context menu, then select ‘View event’.
Edit an event - Assuming you have write privileges on an event, touch and hold
the event to open the context menu, then select ‘Edit event’.
Navigate within the current week -Slide your fingertip up/down.
Navigate to a past or future week - Slide your fingertip left/right.
Jump to current day - Press MENU and select ‘Today’. The current time is
39
highlighted.
4. Day view
Days are divided into hour time slots. Events are shown tiled and span the time
they last. All-day events are displayed at the top of the day list.
View event details - Highlight an event to open a small popup window in the
lower part of the screen that provides more event information. This window will
stay open for three seconds. (Note that highlighted events are outlined in
orange.) To view the full event details, touch the pop-up window while the
pop-up window is open, or select the event itself. You can also touch & hold the
event to open the context menu, then select View event.
Edit an event - Assuming you have write privileges on an event, touch and hold
the event to open the context menu, then select Edit event.
Navigate within the current day - Slide your fingertip up/down.
Navigate to a past or future day - Slide your fingertip left/right.
Jump to current day - Press MENU and select ‘Today’. The current time is
highlighted.
Create new event - Touch an empty time slot to open the new Event details
screen.
Create an event
From any of the views, press MENU and select ‘New event’ to open the new
Event details screen.
• Type the information in the fields.
• Select date & time. You can type directly in the date fields if you don’t want to
step through using the + and – buttons.
• Name that appears in Day view.
• Description can be as long as you like.
• Select a calendar if you display more than one.
• Set a default reminder time.
Press MENU to select ‘Show extra options’ to set presence and privacy:
• Set online presence: available or busy.
• Select calendar privacy from Default (as defined when calendar was created),
Private, or Public.
40
When finished, select ‘Done’. Pressing BACK also saves the event.
Tip: Create an event quickly in the Day or Week view by selecting an empty
time slot. A new Event details screen appears. The ‘From’ field contains the
selected time slot.
The View event screen
In the Day and Week views, when you highlight an event, a pop-up window
with more details opens (the window stays open for three seconds). To see even
more details, open the View event screen by touching the pop-up window.
From the Agenda view, simply select an event to open the View event screen.
From the Month view, first select the day of the event to go to either the Agenda
or and Day view, then select the event (Agenda view) or pop-up window (Day
view).
From the View event screen, you can do the following:
View details: All the information you’ve entered about the event is displayed on
the View event screen.
Reset reminder: Select the Reminders pop-up menu to select a new reminder
time.
Add reminder: Press MENU and select ‘Add reminder’ to create another
reminder for the event. This will not replace existing reminders. You can have
up to five reminders per event.
Delete reminder: Either select the x to the right of a reminder, or press MENU
and select ‘Delete event’ to remove the event from your calendar. If this is a
repeating event, you will be asked if you want to delete just this one instance,
this & future events, or all events.
Edit event: Press MENU and select ‘Edit event’ to open the event for editing. If
this is a repeating event, you will be asked if you want to change just this one
instance, this & future events, or all events.
Event reminders
If you have set at least one reminder for an event (you can set up to five), the
upcoming event icon will appear in the left side of the status bar to remind you.
To view, dismiss, or snooze the reminder, do the following:
1. Touch the status bar and slide your finger down the screen to open the
41
notifications list. The upcoming event name is displayed. If you have only one
reminder, the place is also displayed.
2. To read more details about the event, select the reminder. If you have other
reminders pending, they will be listed on this screen as well. You can Snooze or
Dismiss the reminder(s), or press BACK to keep the reminder(s) pending in the
notifications bar. The snooze time is five minutes.
Edit an event
To edit an event, you must have the View event screen open and you must have
created, or have write privileges, for the event.
1. Navigate to the View event screen.
2. Press MENU and select ‘Edit event’. If Edit event isn’t an option, then you
cannot make any changes to that particular event.
Note: If your event repeats, you will be asked to choose which events you want
changed (only the current one you’re editing, all events in the series, or the
current event plus future events).
3. Once you have finished your edits, select ‘Done’.
4. To delete the event, from the View event screen, press MENU and select
‘Delete event’.
Go to today
From any view, to jump to the screen that shows “today”, press MENU and
select ‘Today’. If you are in the Day or Week view, the current time will be
highlighted.
View multiple calendars
If you’ve created more than one Google Calendar on the Web client, you can
change which calendars are displayed and synced to your phone:
1. From any of the calendar views, press MENU and select More > My
calendars.
2. All your synced calendars are shown in a list. The checked calendars are
displayed on your phone.
3. To hide a calendar from display on your phone, clear that calendar’s check
box.
4. To remove a calendar and all its events from your phone, press MENU and
42
select ‘Remove calendars’. On the menu that appears, select the calendar that
you want to remove. Note: Hiding or removing calendars on your phone does
not affect the display of calendars on the Web.
Calendar settings
From any of the calendar views, press MENU and select More > Settings.
1. Calendar view setting
Hide declined events: Select this check box if you want all the events you
decline to be hidden from all calendar views.
2. Reminder settings
Set alerts & notifications: Select to set the type of event reminder you want:
• Alert - A dialog box will appear to remind you of the event.
• Status bar notification - An icon appears on the left side of the status bar.
• Off - You will receive no reminder.
Select ring tone: Select Ring tone to open the ring tone menu and select a ring
tone specific to new event notifications. Note that when you check a ring tone, it
plays briefly.
Vibrate: Select this check box to have your phone vibrate when you are
reminded of an event.
Default reminder time: Select to open the default reminder menu. The time you
select will appear by default in the Reminder section when you create a new
event.
9 Experiencing Multimedia
9.1 Camera & Picture
All the pictures you can capture or view on your phone are stored on memory
card, which must be installed in your phone. Before you can use the Camera or
view pictures in Pictures, make sure you have a card installed.
Load pictures onto your memory card
Read the instructions below to add pictures to your Memory card.
1. Mount your memory card to your computer by doing one of the following:
Remove the memory card and insert it into a card reader attached to your
43
computer; or attach your phone to your computer using a USB cable that came
in the box. If you use this method, make sure Home > Settings > SD card&
phone storage > Use for USB storage check box is selected. It is selected by
default.
2. On your computer, find the mounted USB drive and open it.
3. Create a folder at the top-level called “Pictures” or some other descriptive
name and open it.
4. Copy .jpg or other image files into this folder. To organize pictures into
albums that will display in the Pictures application, create a folder and copy
pictures there for each album you want to display.
5. When finished, close the USB drive window and unmount or eject the drive
as required by your computer's operating system. You can also go to Home >
Settings > SD card& phone storage, and clear the Use for USB storage check
box. Remove the USB cable from your phone and computer.
Take a picture
Captured pictures are saved to the “DCIM” folder on your memory card.
Tip: Before you take a picture, wipe the sensor window (on the back cover) to
remove any small amounts of oil.
1. To open the Camera, on the Home screen, touch and select the Camera
icon.
2. The Camera opens in capture mode. Frame your picture within the screen and
hold the phone steady. Press the OK button to capture. Continue to hold the
camera steady for a second after you hear the shutter sound.
3. Immediately after capture, you can select to Save, Set as (contact icon or
wallpaper), Share (via a compatible application), or Delete your picture.
4. If you select to save, set as, or share, your picture is saved to the Pictures
application.
View your pictures
To view the pictures you’ve captured, as well as any you’ve stored on your
memory card, go to the Gallery application:
1. To open Pictures, on the Home screen, touch and select Gallery icon.
2. Depending on how many pictures you’ve stored, they may take a few minutes
44
to load.
3. If you’ve stored your pictures in folders on your Memory card, then the
folders will display as separate “albums”. The top left album always contains all
the pictures in all the albums.
4. The individual pictures display in a grid in thumbnail format. You can select
to display smaller or large thumbnails in Settings.
5. To open a picture in full-screen view, touch the picture. Once in full-screen,
select the arrows to scroll through the pictures within that album. If the arrows
disappear, touch the picture again to reveal the arrows and zoom controls.
Picture options
You can do the following while in Pictures. Note: In all the instructions below,
you can touch & hold a picture to open the context menu to access all actions,
rather than open the picture in full-screen view.
1. View full-screen: Select a picture to open it in full-screen view.
2. Share a picture: In full-screen view, press MENU and select Share. Select to
share your picture via Messaging (MMS), or another application (if you have
another application installed on your phone that supports sharing).
3. Set as wallpaper: In full-screen view, press MENU and select Set as. From
the menu that opens select Wallpaper. Touch & hold an edge of the cropper to
reveal the sizing arrows, then drag the edge in or out to size. Touch & drag the
center of the cropper to move it within the picture. When you’re happy with the
cropped area, select ‘Save’.
4. Set as contact picture: In full-screen view, press MENU and select Set as.
From the menu that opens, select Contact icon. Your contact list opens. Select
the contact you want to associate with the picture. Touch & hold an edge of the
cropper to reveal the sizing arrows, then drag the edge in or out to size. Touch &
drag the center of the cropper to move it within the picture.
When you’re happy with the cropped area, select ‘Save’. The picture will now
appear in the Contact details screen, as well as on any incoming call
notifications.
7. Crop picture: In full-screen view, press MENU and select More > Crop.
Touch & hold an edge of the cropper to reveal the sizing arrows, then drag the
45
edge in or out to size. Touch & drag the center of the cropper to move it within
the picture. 3 When you are happy with the cropped area, select ‘Save’. Select
Discard to cancel the crop. The cropped picture is saved to Pictures as a copy.
Your original is not touched.
8. Rotate picture: In full-screen view, press MENU and select Rotate. Select
from Rotate left (counter-clockwise) or Rotate right (clockwise). Your picture
rotates and is saved automatically.
9. Delete picture: In full-screen view, press MENU and select Delete.
The picture will be removed from the Memory card after you confirm.
10. View picture details: In full-screen view, press MENU and select More >
Details. The picture details window opens. You can see the title, resolution, file
size, and date of the picture.
9.2 Music
To open your music Library, on the Home screen, touch and select the
Music icon. Your music is organized into four categories: Artists, Albums,
Songs, and Playlists. Select a category to view the lists within each. Once in a
category, keep selecting until you reach the music you want to play.
For example, if you select the Artists category, you will see a list of artists in
A-Z order. If you select an artist, the list opens to display that artist’s albums.
Select an album, and the album’s song list displays.
Load music onto your Memory card
All the music you can listen to on your phone is stored on memory card. Read
the instructions below to add music to your memory card.
1. Mount your memory card to your computer by doing one of the following:
Remove the memory card and insert it into a card reader attached to your
computer; or, attach your phone to your computer using a USB cable that came
in the box. If you use this method, make sure the Home > Settings > Data > SD
card & phone storage > Use for USB storage check box is selected. It is by
default.
2. On your computer, find the mounted USB drive and open it.
3. Although your phone will find all music files on your memory card, it’s
advisable to keep the number of files or folders at the root level to a minimum.
46
So, if you wish, create a folder at the top-level called “music” (or whatever you
want) to store your files.
4. Open this folder and copy music files into it. If you want, create folders
within “music” to organize your music further. If you want to use certain music
files as phone, notification, or alarm ring tones.
Note: If you do not want a ringtone to appear in your music Library but you do
want it to be available as a ringtone, and then create the “ringtones”,
“notifications”, or “alarms” folder outside your “music” folder.
5. When finished copying, close the USB drive window and unmount or eject
the drive as required by your computer's operating system. Remove the USB
cable from your phone and computer.
Play back music
At any level in your Library, touch & hold a listing (a song, artist, album, or
playlist) to open the context menu. Select Play to begin play and go to the
Playback screen. You can do the following using the Playback screen:
1. Shuffle songs: Shuffle plays songs in random order. Touch to toggle shuffle
on and off. When the con is grey, shuffle is off.
2. Repeat mode: Touch to step through repeat modes: repeat all songs, repeat
current song, don’t repeat (grey icon).
3. Go to any point in song: Slide fingertip in progress bar to desired point in a
song.
4. Playback control: from left to right icons: Go to beginning song, Pause/
resume play and Go to next of song.
If a song is playing while you are on the Library screen, you can switch to the
Playback screen quickly by selecting the lower song bar.
Playlists
You can create as many playlists as you wish. Note that the “Recently added”
playlist is a system playlist and cannot be deleted or renamed. Also, if you make
any voice recordings as part of a MMS message, they will be stored
automatically in a playlist called “My recordings”.
Create a playlist on your phone
1. From the Library, select a category. From the list that appears, navigate to the
47
artist, album, or song that you want on a playlist.
2. Touch & hold the artist, album, or song to open the context menu.
3. Select Add to playlist.
4. In the Add to playlist menu that opens, select New to create a new playlist, or
one of the existing playlists.
5. The song(s) are added.
Manage your playlists
Go to the Library screen and select ‘Playlists’. All your playlists appear.
Touch & hold the playlist to open the context menu. You can do the following
from this screen: Play, Edit (rearrange songs), Delete and Rename.
Create ringtones from songs
You can set any of your songs as a phone ringtone:
1. From the Library, navigate to a song you want to use as a phone ringtone.
2. Touch & hold the song in the list to open the context menu.
3. Select Use as phone ringtone. The ringtone is set as your default incoming
call ringtone.
4. Now, when you go to Home > Settings > Audio profiles, and select a phone
ringtone, your song will be listed as an option.
Delete music from memory card
All the music you play on your phone is stored on the inserted memory card.
From your phone, you can delete music stored on the card:
1. From the Library screen, select the Artists, Albums, or Songs category.
2. Go to the screen that shows the artist, album, or song that you want to delete.
3. Touch & hold the item to open the context menu.
4. Select ‘Delete’. You will be asked to confirm that you want to delete the item
from your memory card.
9.3 FM Radio
This device provides radio function.
Note: Within doors or shielded environment, the receiving effect of radio may
be affected. You can improve the effect in the following ways: Near window,
adjust the position of earphone cable or adopt manual adjustment.
48
10 Android Market
Android Market™ provides you with direct access to software developers
throughout the world. It is the place to go to find fun games and cool
applications that have been rated by your fellow Androids. To open the Market,
on the Home screen, touch and select the Market icon
If you ever need help or have questions about Android Market, press MENU
and select ‘Help’. The Browser will take you to the Android Market “help &
info” Web page.
Browse items to install
When you first enter Android Market, you will see featured items, a list of item
categories, a link to search, and a link to ‘Downloads’.
Scroll horizontally through the featured items or select a category to browse its
contents, and then select a subcategory. Within each subcategory you can select
to view items sorted by popularity or by date. Note that all items in a
subcategory are listed in each tab; those in the by popularity tab are sorted most
popular to least popular, and those in the by date tab are sorted newest to oldest.
Install an item
1. Navigate to an item you want to install and select it.
2. The Item details screen appears. Read more about the item on this screen,
including its overall rating and comments by users. If you scroll down to the
about the developer section, you can view more applications by this developer
or send the developer an email message.
3. More info about item: User comments about item, Scroll down to view more
of this developer’s applications or to email the developer.
Press MENU and select ‘Security’ (permissions) to view the functions and data
this item can access on your phone.
4. To install the item, select either Install (item is free) or Buy, whichever
appears. Important! If an application you are downloading requires either access
to any of your data or control of any functions on your phone, before you
proceed, you’ll see a screen that tells you what the application can access so you
can give your permission. Be sure to read this carefully! Be especially cautious
if an application has access to many functions or a significant amount of your
49
data. Once you select ‘OK’ on this screen, you will be responsible for the results
of using this item on your phone.
• After selecting ‘Install’, the item will start downloading immediately.
• After selecting ‘Buy’, you may be asked to sign in to an additional Google
account. Sign in and select Purchase now if you want to proceed. Step through
the purchase screens.
5. You can see the download progress of the item by opening the notifications
window. Download progress appears in the “ongoing” section of the
notifications window. Once downloaded and installed, a notification appears.
Manage your downloads
From the Android Market Home screen, select ‘Downloads’ to view your
downloaded items. From any of the Android Market screens, you can press
MENU and select ‘Downloads’ to go to the screen.
You can take the following actions from the Downloads screen:
View downloads in progress
1. From the Android Market home screen, press MENU and select ‘Downloads’.
2. If you are in the process of downloading and installing an item, the progress
will display at the top of the screen.
Review a downloaded item
You can rate and post comments on any item you’ve downloaded from Android
Market. Note that you must first rate an item to post a comment.
Uninstall a downloaded item
1. From the Android Market Home screen, press MENU and select ‘Downloads’.
2. Select the item you want to uninstall. The Item details screen appears.
3. Select ‘Uninstall’ button at the bottom of the screen.
Open downloaded item
1. From the Android Market Home screen, press MENU and select ‘Downloads’.
2. Select the item you want to open. The Item details screen appears.
3. Select ‘Open’ button at the bottom of the screen.
Read security permissions for this item
Items you download and install on your phone typically have access to
functionality. You can view what an item has access to on your phone:
50
1. From the Android Market Home screen, press MENU and select ‘Downloads’.
2. Select the item you want to read about. The Item details screen appears.
3. Press MENU and select ‘Security’.
4. All areas of your phone that this item has access to are listed.
5. Dismiss the screen by selecting ‘OK’.
Flag content
If you have a concern about an item, you can “flag” it for further investigation.
You can further manage your Android Market applications from the Home >
Settings > Applications > Manage applications screen.
Review your downloaded items Rate a downloaded item
If you’d like to rate one of the items you’ve downloaded from Android Market,
follow these steps:
1. From the Android Market Home screen, press MENU and select ‘Downloads’.
2. Select the item you want to rate to open its Item details screen.
3. Select ‘My rating’ section to open the Rate it! dialog box. Touch the number
of stars you want to give the item...more stars is better!
When ready, select ‘OK’ to submit your rating.
Write a comment
Once you’ve rated a downloaded item, you can post a comment:
1. From the Android Market Home screen, press MENU and select ‘Downloads’.
Select the item you want to comment on to open its details screen.
2. Select the Post a comment section to open ‘Post comment’ dialog box. If you
don’t see the Post a comment section, first rate the item.
3. Type your comment, and then select ‘OK’ to post it.
Remove rating and/or comment
Once you’ve rated or commented on an item, you can always remove this
review:
1. From the Android Market Home screen, press MENU and select ‘Downloads’.
Select the item to open its details screen.
2. Press MENU and select ‘Clear my review’.
3. Your rating and comments are removed.
51
11 Other applications
11.1 Alarm Clock
To open Alarm Clock, on the Home screen, then touch and select Clock
icon. The Alarm clock offers as many alarms as you want.
Set an alarm
Three alarms are set up for you, ready to customize. All three alarms are turned
off by default. Select the check box to turn on the alarm. If no day shows under
the set time, the alarm will go off once when the set time is reached.
This alarm will go off at 9:00 am every Tuesday and Friday.
To begin, select one of the default alarms to open Alarm settings.
Set the following options:
Alarm: Select the check box to turn alarm on (checked) or off (cleared). This is
the same check box that appears on the main Alarm Clock screen.
Time: The time the alarm will go off is shown. To change this time, select Time
to open the time selector. Tap the + or – buttons and the AM/PM button to set
the time you want, and then select Set.
Tip: Touch & hold the + or – buttons to move through the numbers quickly.
Ring tone: The current ring tone selection is shown. Select Ring tone to pick
another ring tone that will play when the alarm rings. (When you select a ring
tone, it plays briefly.) Note that when your alarm goes off, the ring tone will
play a maximum of five minutes.
Vibrate: Select this check box to have your phone vibrate when it goes off.
Repeat: The current repeat selection is shown. To change the setting, select
Repeat and make a selection from the menu. To have your alarm will only go
off once at the set time, don’t select any of the options. A one-time alarm is
shown on the Alarm Clock screen without any days under the set time.
Delete alarm: To delete the alarm, press MENU and select Delete alarm.
Once your alarm goes off, you will receive an alert with the options to Snooze
(for 10 minutes) or Dismiss.
Add more alarms
To add more than three alarms, from the main Alarm Clock screen, press
52
MENU and select ‘Add alarm’.
Change clock display
You can change the appearance of the clock displayed on the main Alarm Clock
screen:
1. Go to the main Alarm Clock screen.
2. Touch the clock with your fingertip to open the Clock selection screen.
3. Slide your fingertip horizontally along the bottom clock face row and touch
the face you want to display.
Change date & time display
You can change the format of the time displayed in your alarms from the global
Settings screen:
1. Go to the main Alarm Clock screen. On the Home screen, then touch
and then press MENU and select Settings. Scroll down and select ‘Date & time’.
The Date & time settings screen appears.
2. Use the network-provided values by selecting ‘Automatic’ check box.
3. Select ‘Use 24 hour format’ check box if you wish to use that rather than 12
hour format.
4. Select t ‘Select date format’ option to open the menu of various date formats.
11.2 Calculator
To open Calculator, on the Home screen, then touch and select the
Calculator icon.
The Calculator offers two panels: basic and advanced. Switch back and forth
between panels by pressing MENU and selecting ‘Advanced panel’ or ‘Basic
panel’, as you wish.
Calculator panels
Two calculator’s panels are available: basic and advanced. Use the Basic panel
to enter numbers and perform basic addition, subtraction, multiplication, and
division. Use the Advanced panel to insert advanced operators or delimiters,
such as sine, cosine, tangent, square root, parentheses, etc.
Switch back and forth between calculator panels by pressing MENU and
selecting ‘Advanced panel’ or ‘Basic panel’, as you wish. As soon as you select
an advanced operator, the panel switches back to Basic, where your operator
53
appears. When you touch a key on the screen, the key flashes red to let you
know the selection was made. Make sure you see the red flash before entering
your next number or completing the operation.
To delete numbers, one at a time, touch CLEAR on the screen.
To clear your operation history, press MENU and select ‘Clear history’.
54
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference. (2) This device must accept any interference received, including
interference that may cause undesired operation.
NOTE: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
---Reorient or relocate the receiving antenna.
---Increase the separation between the equipment and receiver.
---Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
---Consult the dealer or an experienced radio/TV technician for help.
Body-worn Operation
This device was tested for typical body-worn operations. To comply With
RF exposure requirements, a minimum separation distance of 1.5cm must be
maintained between the user’s body and the handset, including the antenna.
Third-party belt-clips, holsters, and similar including the antenna. Third-party
belt-clips, holsters, and similar accessories used by this device should not
contain any metallic components. Body-worn accessories that do not meet these
requirements may not comply with RF exposure requirements and should be
avoided.
55
Specific Absorption Rate (SAR)
This Model wireless phone meets the government’s requirements for
exposure to radio waves.
Your mobile device is a radio transmitter and receiver. It is designed and
manufactured to not exceed limits for exposure to radio frequency (RF) energy
set by the Federal Communications Commission (FCC) of the U.S. government
and by the Canadian regulatory authorities. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for the
general population. The guidelines are based on standards that were developed
by independent scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a substantial safety
margin designed for the safety of all persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR, The SAR limit
set by the FCC is 1.6 W/Kg. Tests for SAR are conducted using standard
operating positions accepted by the FCC with the phone transmitting at its
highest certified power level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR level of the
phone while operating can be well below the maximum value. This is because
the phone is designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a wireless
base station, the lower the power output. Before a phone model is available for
sale to the public in the U.S, it must be tested and certified to the FCC that it
does not exceed the limit establish for safe exposure. The tests are performed in
positions and locations (e.g, at the ear and worn on the body) reported to the
FCC.
Before a phone model is available for sale to the public in the U.S, it must
be tested and certified to the FCC that it does not exceed the limit establish for
safe exposure. The tests are performed in positions and locations (e.g, at the ear
and worn on the body) reported to the FCC. While there may be differences
between the SAR levels of various phones and at various positions, they all
meet the governmental requirements for safe exposure. Please note that
improvements to this product model could cause differences in the SAR value
for later products, in all cases, products are designed to be within the guidelines.
Additional information on Specific Absorption Rates (SAR) can be found on the
Cellular Telecommunications & Internet Association (CTIA) Web site:
http://www.phonefacts.net
