Congratulations on purchasing your new amps&watts BeatBlock
Please take a moment to read this manual.
The BeatBlock will turn your mobile device (smartphone, tablet, pc, mac) into the only
Hi-Fi system you will ever need!
Please read these instructions
thoroughly before use
Do not use the BeatBlock near water
Clean only with a dry cloth
Do not block any ventilation openings: Install in accordance with the manufacturer's
instructions
Do not install your BeatBlock near any heat sources such as radiators, heat registers, stove,
or other apparatus (Including amplifier) that produce heat
Do not defeat the safety purpose of the polarized or grounded-type plug
A polarized plug has two blades with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade or the third prong is provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet
Protect the power cord from being walked on or pinched particularly at the point where it
exits from the BeatBlock and the point where it is plugged into the electricity outlet
Only use attachments & accessories specified by the manufacturer
Unplug the BeatBlock during lightning storms or when unused for a long period of time
Service your BeatBlock only at qualified service personnel. Servicing is required when the
BeatBlock has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the BeatBlock, the BeatBlock has been
exposed to rain or moisture, does not operate normally, or has been dropped
The BeatBlock must be connected to a MAIN socket outlet with a protective earthing
connection
Batteries or battery packs must not be exposed to excessive heat such as sunshine, fire or
similar
Safety Instructions
3
BeatBlock
TM
amps atts
vv
Information
Unpacking
Recommended Speaker Setup
Speaker Conditioning and Break-in
Speaker Conditioning
Your BeatBlock was carefully tested and inspected during production, packaging and
shipping. After unpacking please check for any damage. It is rare that your BeatBlock is
damaged during shipping, but if this does happen, please contact your retailer immediately.
We recommend that you keep the original carton and packing material for future shipping.
Correct speaker placement has a huge impact on sound quality. There are many different
theories, but all rooms and tastes are different so it's impossible to specify a correct
placement. We do suggest you experiment with a few different locations to see what is best
for you.
For the best bass response, we recommend that you keep a minimum distance of 20-25 cm
between the speakers and the rear wall. Align the speakers with the tweeters at eye-level
according to your most common listening position.
Although a break-in period is not required, we recommend that you play between 24 to 48
hours of music through the speakers of your BeatBlock before doing any critical listening or
speaker placement.
We don't recommend using any solvents or cleaners on cabinets or speaker units.
Just wipe down with a soft cloth.
4
BeatBlock
TM
amps atts
vv
Great features of your BeatBlock
Play and enjoy your music wirelessly
Charge your smartphone, tablet & mobile devices
Amazing, Impressive Hi-Fi POWER sound
Unique, high end timeless fashion design
Remote control with unique bass & treble enhancement feature
Your BeatBlock comes with a built in Bluetooth feature which allows you to connect your
Bluetooth enabled devices wirelessly and to play and enjoy your music with wireless
freedom. Imagine coming home and diving into your couch and with a touch of a button
being able to play all your music from your smartphone/PC/MAC/mobile device wirelessly
without even moving and inch. Say goodbye to connection cables, hi-fi systems, selecting
and changing CD's, getting up to select and control your music and docking! Your
smartphone/tablet/PC/MAC will become the only Hi-Fi system you will ever need!
Your BeatBlock comes with a unique charging feature on the rear panel you will find 2 USB
charging outputs which charge your tablets, smartphones and other mobile devices. Say
goodbye to all those chargers and cables!
With a Class AB amplifier, high quality components and 2 x 30Watts RMS you will enjoy
unbelievable Hi-Fi power sound from such a small form factor. It is truly SOUND BEYOND
SIZE!
Enjoy the high end timeless fashion design of your BeatBlock which will look really great in
your room, lounge, office or living/working area!
Most Smartphones, Tablets and mobile devices do not allow you to adjust the treble and
bass when playing downloaded music or music from Youtube, Pandora, Spotify and other
internet sites resulting in poor sound quality and a bad music experience. Your BeatBlock
comes with a clever little remote control that allows you to adjust the treble and bass of the
music that you are playing from your mobile device thus allowing you to truly enhance your
music and listening experience!
Thank Yo u for your purchase of your BeatBlock!
We look forward to you enjoying it for many many years to come!
The amps&watts Team
5
Serial Number:
BeatBlock
TM
amps atts
vv
2
1
3
4
5
6
7
810
12 13 14 15
119
1．Remote receiver
2．Red LED indicator light
(standby)
3．Green LED indicator light
(Normal)
4．Blue LED indicator light
(Bluetooth mode)
5．Input mode selector
6．Previous
7．Volume Control
8．Play/pause
9．Next
10. Power On/Off
11. Power supply input
12. Mobile device charge sockets
2100mAh for iPad & other tablets
1000mAh for smartphones & other
mobile devices
13. Aux in
For right/left RCA stereo plugs, from
CD/DVD/Home Theatre player
14.AUDIO INPUT
For 3.5mm jack from iPod,iPhone,iPad,
PC, mobile phone etc
15.Optical audio in
Front and rear panel
DC 16V IN
Power consumption 90W
Active with Bluetooth OPTICAL IN
RL
AUX1 IN AUX2 IN
USB charge
USB 1(iPAD/TABLET)
5V/2100mA
USB 2
5V/1000mA
BeatBlockMODEL:
TM
amps atts
vv
FCC ID:
6
TM
amps atts
vv
BeatBlock
TM
amps atts
vv
6
7
8
9
10
11
13
14
12
Remote control
1.STANDBY BUTTON
Press to enter standby mode.
2.PREV TRACK
3.BLUETOOTH INPUT
4.OPTICAL INPUT SELECT
5.BASS BUTTON
Press"-", then bass will decrease;
Press"+", then bass will increase;
6.MUTE BUTTON
7.NEXT TRACK
8.PLAY/PAUSE
9. AUX2 INPUT SELECT
10.AUX1 INPUT SELECT
11.LOUD
Enhances the treble and bass effects
at low volume
12.RESET
Default Volume, Reset bass and treble.
13.TREBLE BUTTON
Press"-", then treble will decrease;
Press"+", then treble will increase;
14.VOLUME BUTTON
Press"-", then volume will decrease;
Press"+", then volume will increase;
7
BeatBlock
TM
amps atts
vv
Connection via Bluetooth
Operating Bluetooth function
Pairing your smartphone/mac/pc/mobile device with your amps&watts BeatBlock: If you
have a Bluetooth enabled audio device, such as smarthphone, music player, computer,
tablet and you are connecting it with your BeatBlock for the first time, you should pair as
follows:
1.Power on your BeatBlock and wait for 3 seconds.
2.Press “BLUETOOTH” on remote control and switch to Bluetooth input mode. (You can
also choose Bluetooth input mode by pressing the Input mode selector button on the
front panel of your BeatBlock). Once you have done so, the green indicator will start
flashing. If not, please check whether there is any other Bluetooth device connected
with your BeatBlock and turn off such other Bluetooth device.
3.Select the Bluetooth function on your smartphone/mobile device and then search for new
Bluetooth devices until the name “BeatBlock” appears on your screen. Select “BeatBlock”
to pair with your smartphone/mobile device. If your smartphone/mobile device asks for a
pairing code please enter “0000”.
4.If pairing is successful and the BeatBlock is connected to your smartphone/ mobile
device, the green indicator will stay on and will stop flashing. Pairing is now complete.
5.Once paired all you have to do to pair again is to select the BeatBlock on your list of
Bluetooth devices specified on your smartphone/mobile device and the BeatBlock will
automatically connect to your smartphone/mobile device.
1.Select the Bluetooth Input mode on your BeatBlock by pressing the “BLUETOOTH”
button on the remote control or by pressing “the input mode selector button” on the front
panel of your BeatBlock.
2.If you have already paired your smartphone/mobile device to your BeatBlock, select the
Bluetooth setting on your smartphone/mobile device and select “BeatBlock” which
appears on your list of Bluetooth devices. Your BeatBlock will automatically connect to
your smartphone/mobile device.
3.If your Bluetooth audio device supports the AVRCP agreement, you can use your remote
control to select “PREV /PLAY/PAUSE /NEXT ” on your smartphone/ mobile
device.
8
Serial Number:
DC 16V IN
Power consumption 90W
Active with Bluetooth OPTICAL IN
RL
AUX1 IN AUX2 IN
USB charge
USB 1(iPAD/TABLET)
5V/2100mA
USB 2
5V/1000mA
BeatBlockMODEL:
TM
amps atts
vv
FCC ID:
DC 16V IN
Power consumption 90W
Active with Bluetooth OPTICAL IN
RL
AUX1 IN AUX2 IN
USB charge
USB 1(iPAD/TABLET)
5V/2100mA
USB 2
5V/1000mA
BeatBlockMODEL:
TM
amps atts
vv
FCC ID:
DC 16V IN
Power consumption 90W
Active with Bluetooth OPTICAL IN
RL
AUX1 IN AUX2 IN
USB charge
USB 1(iPAD/TABLET)
5V/2100mA
USB 2
5V/1000mA
BeatBlockMODEL:
TM
amps atts
vv
FCC ID:
BeatBlock
TM
amps atts
vv
A
B
Use with iPod-iPhone-iPad/ Smartphone-PC-Mac-
Tablet-MP3 player
If your device has Optical digital audio output (usually located on the rear connection panel),
use the included Optical or RCA cable (just use one channel of the Stereo RCA cable) to
connect your device's digital audio output to the Optical digital audio input on the rear of
your BeatBlock.
Connection with Optical Devices
Optical OUT
9
Serial Number:
Serial Number:
BeatBlock
TM
amps atts
vv
CONFIGURATION A
CONFIGURATION B
(iPod-iPhone-iPad):
For playing music without Bluetooth connectivity connect
1.a 3.5mm to Left Right RCA audio jack to the headphone jack of your iPod-iPhone-iPad
and then to the AUX IN RCA jacks on the rear panel of your BeatBlock, OR
2.a 3.5mm to 3.5mm audio jack to the headphone jack of your iPod-iPhone-iPad and then
to the AUDIO INPUT jack on the rear panel of your BeatBlock.
For charging your iPod-iPhone-iPad, connect the 30-pin/lightning cable from the
iPod/iPhone/iPad to the USB jack on the rear panel of your BeatBlock. Note that for charging
an iPad you must connect to the USB jack marked as “USB 1 (IPAD/TABLET)”. For charging
your iPod or iPhone connect to the USB jack marked as “USB 2”.
(Smartphone-PC-Mac-Tablet-MP3 player- all products with a 3.5mm
audio jack output):
For playing music without Bluetooth connectivity connect
1.a 3.5mm to Left Right RCA audio jack to the headphone jack of your Smartphone-PC-
Mac-Tablet-MP3 player and then to the AUX IN RCA jacks on the rear panel of your
BeatBlock, OR
2.a 3.5mm to 3.5mm audio jack to the headphone jack of your Smartphone-PC-Mac-Tablet-
MP3 player and then to the AUDIO INPUT jack on the rear panel of your BeatBlock.
For charging your Smartphone-MP3-Tablet, connect the charging cable to the USB jack on
the rear panel of your BeatBlock. Note that for charging a Tablet you must connect to the
USB jack marked as “USB 1 (IPAD/TABLET)”. For charging your Smartphone-MP3 connect
to the USB jack marked as “USB 2”.
Attention: When connecting audio cables the power switch of your BeatBlock must be turned
OFF. After connecting all cables the power switch can be turned ON and the system will be
ready to use.
10
Serial Number:
Serial Number:
DC 16V IN
Power consumption 90W
Active with Bluetooth OPTICAL IN
RL
AUX1 IN AUX2 IN
USB charge
USB 1(iPAD/TABLET)
5V/2100mA
USB 2
5V/1000mA
BeatBlockMODEL:
TM
amps atts
vv
FCC ID:
DC 16V IN
Power consumption 90W
Active with Bluetooth OPTICAL IN
RL
AUX1 IN AUX2 IN
USB charge
USB 1(iPAD/TABLET)
5V/2100mA
USB 2
5V/1000mA
BeatBlockMODEL:
TM
amps atts
vv
FCC ID:
BeatBlock
TM
amps atts
vv
A
AUDIO
RL
PC AUDIO
OUT IN
B
Connect TV, DVD, console, PC
CONFIGURATION A
CONFIGURATION B
(TV,DVD,CD-RCA stereo plugs):
For playing music without Bluetooth connectivity connect the RCA L/R jacks to your TV,DVD,
CD and the other RCA L/R jacks to the AUX IN on the rear panel of your BeatBlock.
(PC-MAC):
For playing music without Bluetooth connectivity connect
1. a 3.5mm to Left Right RCA audio jack to the headphone jack of your PC-MAC and then
to the AUX IN RCA jacks on the rear panel of your BeatBlock, OR
2. a 3.5mm to 3.5mm audio jack to the headphone jack of your PC-MAC and then to the
AUDIO INPUT jack on the rear panel of your BeatBlock.
11
DC 16V IN
Power consumption 90W
Active with Bluetooth OPTICAL IN
RL
AUX1 IN AUX2 IN
USB charge
USB 1(iPAD/TABLET)
5V/2100mA
USB 2
5V/1000mA
BeatBlockMODEL:
TM
amps atts
vv
FCC ID:
DC 16V IN
Power consumption 90W
Active with Bluetooth OPTICAL IN
RL
AUX1 IN AUX2 IN
USB charge
USB 1(iPAD/TABLET)
5V/2100mA
USB 2
5V/1000mA
BeatBlockMODEL:
TM
amps atts
vv
FCC ID:
BeatBlock
TM
amps atts
vv
Use with docking station
CONFIGURATION A
CONFIGURATION B
(For use with iPod/iPhone/iPad/Universal Docking station):
Place the docking station next to your BeatBlock. Connect the 3.5 mm audio jack cable from
the dock to AUDIO IN jack on the rear panel of your BeatBlock.
(For use with iPod/iPhone/iPad/Universal Docking station):
Place the docking station next to your BeatBlock. Connect the RCA Left Right audio jack
cable from the dock to AUDIO IN jack on the rear panel of your BeatBlock.
Insert your iPod/iPhone/iPad/Smartphone/Tablet in the dock, set the volume and
enjoy.
12
Serial Number:
Serial Number:
BeatBlock
TM
amps atts
vv
Limited Warranty
Dear Customer,
This product has been designed and
manufactured to the highest quality
standards, however should you encounter
any problems with this product please
contact your local dealer or your country
distributor.
This limited warranty is valid for the original
owner for a period of 12 months from the
date of purchase, it is not transferable.
The limited warranty covers all production
and material defects of the product, except
for the damages stated below.
Damages caused by packing and transport.
Defects caused by accidents, misuse,
normal wear and tear, wrong maintenance,
voltage variation and overloading.
Damages caused by incorrect installation or
operation.
Damages caused by modification or repair
by a non-authorized service centre and use
of non-original spare parts.
Other damages due to conditions beyond
the supplier's control such as fire, rain,
What is covered by the limited warranty:
What is not covered by the limited
warranty:
Dealer name and stamp: Date of purchase:
strode of lightning, war and other force
majeure events.
To have your product serviced under
warranty, you must contact the dealer from
where you bought the product or please
visit www.ampsandwatts.com and send an
email for warranty support.
You will need to produce this warranty
booklet completed and stamped by your
dealer on the date of purchase.
Alternatively, you will need the original sales
invoice or other proof of ownership and date
of purchase.
The supplier is liable only to repair or
replace defective parts of products and the
supplier is not responsible for indirect
losses or damages arising from the use of
the product.
Transportation costs for servicing are not
covered by the warranty.
A service repair or replacement cannot
exceed the value of the product under
warranty; in no event shall the supplier be
responsible or liable for special, incidental,
consequential or indirect damages.
How to claim parts or repair under
warranty:
13
BeatBlock
BeatBlock
TM
amps atts
vv
MODEL
Description
Tweeters
Woofers
Amplifier
Frequency Response
Inputs
USB Charge
Dimensions(WDH)
Outer casing
Specifications
Battery Safety Warnings
1. Never dispose of the batteries found in the remote control of your BeatBlock in the
garbage. This is unlawful under state and federal environmental laws and regulations.
Always take used batteries to your local battery - recycling center.
2. Do not dispose of the batteries found in the remote control of your BeatBlock in fire.
3. The batteries found in the remote control of your BeatBlock should be recycled or
disposed of as per state and local guidelines.
2 - Way 4” Active Bluetooth Speakers
1”Black Silk Dome
4” Paper Cone
2x30 Watts
55Hz - 20kHz
Bluetooth, Stereo RCA, 3.5mm, optical
2 USB-(1x 2100mAh, 1x 1000 mAh)
368x220x187(mm)
High quality, durable hand stitched
material with leather aesthetics
Made in China
